Realms

1// claude-realms: this session's private Linux desktop, live in a pane.
2//
3// The realm itself (labwc desktop or Omarchy VM) and the agent's desktop
4// tools live in the plugin's MCP server. This module is the person's side of
5// it: the /realm command, a pane that streams the realm's screen (pixels in
6// kitty/Ghostty, half-block cells in any other terminal), taking control of
7// the desktop, a status line, and a guard that keeps Bash commands from
8// re-pointing GUI tools at the person's own screen while a realm is in use.
9
10import type { EngineInterface, PluginOptions, Register } from 'claude-code'
11import { hostEscape } from './guard'
12
13type $ = EngineInterface
14
15const PANE = 'realm'
16const SERVER = 'realms'
17const STATUS_POLL_MS = 3000
18const INPUT_HISTORY = 128
19
20type Live = { id: string; kind: string; size?: string | null; memory_mb?: number | null; vnc_socket?: string | null }
21type Job = { state: string; log: string[]; error?: string }
22type Status = {
23  enabled: boolean
24  kind: string
25  live: Live | null
26  setup: { ready: boolean; message: string; install_command?: string | null; steps: string[] }
27  frames_argv: string[]
28  input_path?: string
29  controlled?: boolean
30  jobs?: Record<string, Job>
31  events?: { at: number; text: string }[]
32  driver_tools?: number
33}
34type Picture =
35  | { kind: 'image'; source: { file: string; format: 'rgb'; width: number; height: number; generation: number } }
36  | { kind: 'raster'; columns: number; rows: number; cells: string }
37type Mode = 'image' | 'raster'
38type Control = { pid: number; socket: string; python: string; client: string; ancestors: { pid: number }[] }
39
40// The plugin's server: its tools' name prefix as Claude Code lists them, and
41// how the mod reaches it for the person's own actions
42const toolPrefix = 'mcp__plugin_realms_realms__'
43let control: Control | null = null
44let connectError: string | null = null
45let status: Status | null = null
46let poller: { cancel: () => void } | null = null
47
48// The pane and its stream
49let isPaneOpen = false
50let isDismissed = false
51let stream: AsyncGenerator<unknown, unknown, unknown> | null = null
52let streamGeneration = 0
53let streamSocket: string | null = null
54let streamBox = { columns: 0, rows: 0 }
55let mode: Mode = 'image'
56let modeLocked = false
57let picture: Picture | null = null
58let framebuffer = { width: 1920, height: 1080 }
59let viewError: string | null = null
60let box = { columns: 80, rows: 22 }
61let restartTimer: { cancel: () => void } | null = null
62
63// Taking control
64let isControlled = false
65let inputEvents: { [key: string]: unknown }[] = []
66let inputId = 0
67let inputEpoch = ''
68
69
70// Setup jobs the server is running, to report how they ended
71let fastPoller: { cancel: () => void } | null = null
72let callsInFlight = 0
73let runningJobs = new Set<string>()
74
75// The terminal: Codemux (its browser pane hosts the full view) and the shape
76// of a text cell (height / width), which keeps the realm's 16:9 picture 16:9.
77let inCodemux = false
78let cellAspect = 2.1
79// The realm a Codemux browser pane already shows, so it opens once per realm
80let browserShownFor: string | null = null
81
82// Where the realm is watched: the terminal pane, or (in Codemux, whose
83// terminal draws no pictures) a Codemux browser pane at full resolution.
84function viewsInBrowser(): boolean {
85  const where = option<string>('view_in', 'auto')
86  return where === 'browser' || (where === 'auto' && inCodemux)
87}
88
89let options: PluginOptions = {}
90
91function option<T extends string | number | boolean>(name: string, fallback: T): T {
92  const value = options[name]
93  return (typeof value === typeof fallback ? value : fallback) as T
94}
95
96// ------------------------------------------------------------------ server
97//
98// The person's actions reach the plugin's server over its private control
99// socket, not through $.mcp: Claude Code routes a plugin's own MCP calls
100// through the tool permission flow, which would ask the person to approve
101// their own clicks. The server publishes, under XDG_RUNTIME_DIR, which
102// processes it descends from; the one below this Claude Code process is ours.
103
104async function locate($: $): Promise<Control | null> {
105  if (control && (await $.fs.exists(control.socket))) return control
106  control = null
107  const probe = await $.process.run(['/bin/sh', '-c', 'echo "$PPID $(id -u)"'])
108  const [pid, uid] = probe.stdout.trim().split(' ').map(Number)
109  const runtime = (await $.env.get('XDG_RUNTIME_DIR')) || '/tmp'
110  for (const base of [runtime, '/tmp']) {
111    const directory = base + '/claude-realms-' + uid
112    if (!(await $.fs.exists(directory))) continue
113    const entries = await $.fs.list(directory)
114    const candidates: Control[] = []
115    for (const entry of entries) {
116      if (!entry.name.endsWith('.json')) continue
117      try {
118        const data = JSON.parse(await $.fs.read(directory + '/' + entry.name)) as Control
119        if (data.ancestors.some((process) => process.pid === pid) && (await $.fs.exists(data.socket))) candidates.push(data)
120      } catch {}
121    }
122    candidates.sort((a, b) => b.pid - a.pid)
123    if (candidates[0]) {
124      control = candidates[0]
125      connectError = null
126      return control
127    }
128  }
129  connectError = 'the realms server is not running (still starting, or it stopped: /mcp shows it and can reconnect plugin:realms:realms)'
130  return null
131}
132
133const SLOW = new Set(['on', 'setup', 'doctor', 'shot', 'driver', 'push', 'pull', 'stop', 'off'])
134
135async function realm($: $, args: Record<string, unknown>): Promise<{ text: string; data: unknown; isError: boolean }> {
136  const found = await locate($)
137  if (!found) return { text: 'Realms: ' + connectError, data: null, isError: true }
138  const timeoutMs = SLOW.has(String(args.action)) ? 10 * 60 * 1000 : 30 * 1000
139  const result = await $.process.run([found.python, '-I', '-S', found.client, found.socket, JSON.stringify(args)], { timeoutMs })
140  let reply: { texts?: string[]; isError?: boolean; unreachable?: boolean } = {}
141  try {
142    reply = JSON.parse(result.stdout)
143  } catch {
144    return { text: 'Realms: no reply from the server ' + result.stderr.trim(), data: null, isError: true }
145  }
146  if (reply.unreachable) control = null
147  const [first = '', second] = reply.texts ?? []
148  let data: unknown = null
149  if (second !== undefined) {
150    try {
151      data = JSON.parse(second)
152    } catch {
153      data = second
154    }
155  }
156  return { text: first, data, isError: Boolean(reply.isError) }
157}
158
159// One status request at a time: polls that pile up behind a slow reply would
160// tie up the server's worker threads that the agent's own calls need.
161let refreshing: Promise<Status | null> | null = null
162
163function refresh($: $): Promise<Status | null> {
164  if (!refreshing) refreshing = refreshOnce($).finally(() => { refreshing = null })
165  return refreshing
166}
167
168async function refreshOnce($: $): Promise<Status | null> {
169  try {
170    const { data, isError } = await realm($, { action: 'status' })
171    if (!isError && data && typeof data === 'object') status = data as Status
172  } catch (error) {
173    $.ui.log('claude-realms: status failed: ' + String(error), { to: 'debug' })
174  }
175  isControlled = status?.controlled ?? isControlled
176  showStatusLine($)
177  await followJobs($)
178  await syncStream($)
179  return status
180}
181
182function showStatusLine($: $) {
183  // The footer toggle (SessionMode) shows the realm's state; it redraws here.
184  $.ui.invalidate('ui.render')
185}
186
187// The realm at full resolution in the browser (noVNC), with control.
188async function openFullView($: $) {
189  const { text, data, isError } = await realm($, { action: 'watch', control: true })
190  const url = (data as { url?: string } | null)?.url
191  if (isError || !url) {
192    $.ui.toast(text)
193    return
194  }
195  const where = option<string>('full_view', 'auto')
196  if ((where === 'auto' && inCodemux) || where === 'codemux') {
197    // Codemux's own browser pane: full resolution, beside the conversation.
198    let pane = await $.process.run(['codemux', 'browser', 'open', url], { timeoutMs: 15000 }).catch(() => ({ exitCode: 1 }))
199    if (pane.exitCode !== 0) {
200      // No browser pane yet in this workspace: make one, then show the realm.
201      await $.process.run(['codemux', 'browser', 'create'], { timeoutMs: 15000 }).catch(() => undefined)
202      pane = await $.process.run(['codemux', 'browser', 'open', url], { timeoutMs: 15000 }).catch(() => ({ exitCode: 1 }))
203    }
204    if (pane.exitCode === 0) {
205      browserShownFor = status?.live?.id ?? null
206      $.ui.toast('The realm is open in a Codemux browser pane')
207      return
208    }
209  }
210  const opened = await $.process.run(['xdg-open', url], { timeoutMs: 10000 }).catch(() => ({ exitCode: 1 }))
211  if (opened.exitCode === 0) {
212    $.ui.toast('Full view opened in your browser')
213  } else {
214    await $.ui.copy({ text: url }).catch(() => undefined)
215    $.ui.toast('Full view link copied to the clipboard')
216  }
217}
218
219async function togglePane($: $) {
220  if (isPaneOpen) await closePane($)
221  else if (viewsInBrowser() && status?.live) await openFullView($)
222  else await openPane($, { asked: true })
223}
224
225function startPolling($: $) {
226  if (poller) return
227  poller = $.clock.every(STATUS_POLL_MS, () => {
228    if (!isPaneOpen && !status?.live) {
229      poller?.cancel()
230      poller = null
231      return
232    }
233    void refresh($)
234  })
235}
236
237// ------------------------------------------------------------------ stream
238
239function isOurTool(tool: string): boolean {
240  return tool.startsWith(toolPrefix)
241}
242
243async function syncStream($: $) {
244  const socket = isPaneOpen ? status?.live?.vnc_socket ?? null : null
245  if (!socket) {
246    if (stream) await stopStream($)
247    if (!status?.live) picture = null
248    return
249  }
250  if (stream && streamSocket === socket) return
251  await stopStream($)
252  void runStream($, socket)
253}
254
255async function stopStream($: $) {
256  streamGeneration += 1
257  const current = stream
258  stream = null
259  streamSocket = null
260  restartTimer?.cancel()
261  restartTimer = null
262  // Ending the stream's loop ends the viewer process. Not awaited: a stream
263  // is only interruptible at its next piece, and the generation check above
264  // already drops anything a stopped stream still says.
265  if (current) void current.return(undefined).catch(() => undefined)
266  void $
267}
268
269function restartStream($: $) {
270  restartTimer?.cancel()
271  restartTimer = $.clock.after(50, async () => {
272    restartTimer = null
273    picture = null
274    await stopStream($)
275    await syncStream($)
276    $.ui.invalidate('ui.render')
277  })
278}
279
280function setMode($: $, next: Mode, why?: string) {
281  if (mode === next) return
282  mode = next
283  if (why) $.ui.log('claude-realms: live view switched to ' + next + ': ' + why, { to: 'debug' })
284  restartStream($)
285}
286
287async function runStream($: $, socket: string) {
288  if (!status) return
289  const generation = ++streamGeneration
290  const requested = { ...box }
291  const argv = [
292    ...status.frames_argv,
293    '--socket', socket,
294    '--mode', mode,
295    '--columns', String(requested.columns),
296    '--rows', String(requested.rows),
297    '--fps', String(option('view_fps', 10)),
298    ...(status.input_path ? ['--input', status.input_path] : []),
299  ]
300  const child = $.process.spawn({ argv }) as unknown as AsyncGenerator<{ stream: string; text: string }, unknown, unknown>
301  stream = child
302  streamSocket = socket
303  streamBox = requested
304  viewError = null
305  let pending = ''
306  try {
307    for await (const { stream: pipe, text } of child) {
308      if (generation !== streamGeneration) break
309      if (pipe !== 'stdout') continue
310      const lines = (pending + text).split('\n')
311      pending = lines.pop() ?? ''
312      for (const line of lines) await onLine($, line)
313    }
314  } catch (error) {
315    viewError = 'the live view stopped: ' + String(error)
316  } finally {
317    if (stream === child) {
318      stream = null
319      streamSocket = null
320    }
321  }
322  if (generation === streamGeneration && isPaneOpen) $.ui.invalidate('ui.render')
323}
324
325async function onLine($: $, line: string) {
326  if (line.startsWith('@hello ')) {
327    const hello = JSON.parse(line.slice(7)) as { width: number; height: number }
328    framebuffer = { width: hello.width, height: hello.height }
329    $.ui.invalidate('ui.render')
330    return
331  }
332  if (line.startsWith('@size ')) {
333    const [, w, h] = line.split(' ')
334    framebuffer = { width: Number(w), height: Number(h) }
335    restartStream($)
336    return
337  }
338  if (line.startsWith('@error ')) {
339    viewError = line.slice(7)
340    $.ui.invalidate('ui.render')
341    return
342  }
343  const frame = /^@file (\S+) (\d+) (\d+) (\d+)$/.exec(line)
344  if (frame) {
345    const source = { file: frame[1]!, format: 'rgb' as const, width: Number(frame[2]), height: Number(frame[3]), generation: Number(frame[4]) }
346    if (picture?.kind !== 'image') {
347      picture = { kind: 'image', source }
348      $.ui.invalidate('ui.render')
349      return
350    }
351    picture = { kind: 'image', source }
352    const result = await $.ui.blit({ requestId: PANE, key: 'view', source })
353    // Only refusals that mean "this terminal shows no pictures" switch to
354    // coloured cells; others (a redraw in flight, a busy surface) pass.
355    if (result.deny && /draws no placeholder images|cannot read files on this machine|8-bit image id/.test(result.deny)) {
356      if (!modeLocked) setMode($, 'raster', result.deny)
357    }
358    return
359  }
360  const raster = /^@raster (\d+) (\d+) (\S+)$/.exec(line)
361  if (raster) {
362    const columns = Number(raster[1])
363    const rows = Number(raster[2])
364    const cells = raster[3]!
365    if (columns !== box.columns || rows !== box.rows) {
366      restartStream($)
367      return
368    }
369    if (picture?.kind !== 'raster' || picture.columns !== columns || picture.rows !== rows) {
370      picture = { kind: 'raster', columns, rows, cells }
371      $.ui.invalidate('ui.render')
372      return
373    }
374    picture = { kind: 'raster', columns, rows, cells }
375    const result = await $.ui.blit({ requestId: PANE, key: 'view', cells })
376    if (result.deny) restartStream($)
377  }
378}
379
380// Fit the realm's aspect into the pane, knowing how tall a text cell is
381// against its width (about 2 in kitty and Ghostty, 2.4 in Codemux).
382function fit(bodyColumns: number, viewportRows: number, maxColumns: number, maxRows: number) {
383  const room = Math.max(6, Math.min(maxRows, viewportRows - 8))
384  let columns = Math.max(16, Math.min(maxColumns, bodyColumns))
385  let rows = Math.max(4, Math.round((columns * framebuffer.height) / framebuffer.width / cellAspect))
386  if (rows > room) {
387    rows = room
388    columns = Math.max(16, Math.min(columns, Math.round((rows * cellAspect * framebuffer.width) / framebuffer.height)))
389  }
390  return { columns, rows }
391}
392
393// ------------------------------------------------------------------ setup
394
395function startFastPolling($: $) {
396  if (fastPoller) return
397  fastPoller = $.clock.every(500, () => {
398    if (callsInFlight === 0 && runningJobs.size === 0) {
399      fastPoller?.cancel()
400      fastPoller = null
401      return
402    }
403    void refresh($)
404  })
405}
406
407// Follow the server's setup jobs and say how they ended.
408async function followJobs($: $) {
409  const jobs = status?.jobs ?? {}
410  const running = new Set(Object.entries(jobs).filter(([, job]) => job.state === 'running').map(([name]) => name))
411  if (running.size) startFastPolling($)
412  for (const name of runningJobs) {
413    if (running.has(name)) continue
414    const job = jobs[name]
415    if (job?.state === 'failed') $.ui.toast('Realm setup failed: ' + (job.error ?? 'unknown error'))
416  }
417  runningJobs = running
418}
419
420// ------------------------------------------------------------------- pane
421
422async function openPane($: $, { asked }: { asked: boolean }) {
423  const opened = await $.ui.open({ id: PANE, title: 'Realm' })
424  if (!opened.isPlaced && !asked) {
425    // Opened unasked in a narrow terminal it would pop up later; offer instead.
426    await $.ui.close({ id: PANE })
427    $.ui.toast('The realm is live · /realm view to watch it')
428    return false
429  }
430  isPaneOpen = true
431  isDismissed = false
432  startPolling($)
433  await refresh($)
434  return true
435}
436
437async function closePane($: $) {
438  await $.ui.close({ id: PANE })
439}
440
441async function takeControl($: $, held: boolean) {
442  const { isError, text } = await realm($, { action: 'control', control: held })
443  if (isError) {
444    $.ui.toast(text)
445    return
446  }
447  isControlled = held
448  inputEvents = []
449  inputId = 0
450  // A fresh epoch tells the viewer that ids start over for this takeover.
451  inputEpoch = held ? String(Date.now()) + '-' + Math.random().toString(36).slice(2, 8) : ''
452  if (held) {
453    await $.ui.focus({ requestId: PANE, key: 'takeover' }).catch(() => undefined)
454  }
455  showStatusLine($)
456  $.ui.invalidate('ui.render')
457}
458
459async function writeInput($: $, events: { [key: string]: unknown }[]) {
460  if (!status?.input_path || !isControlled) return
461  for (const event of events) inputEvents.push({ ...event, id: ++inputId })
462  inputEvents = inputEvents.slice(-INPUT_HISTORY)
463  await $.fs.write(status.input_path, JSON.stringify({ epoch: inputEpoch, events: inputEvents }))
464}
465
466// ---------------------------------------------------------------- command
467
468const USAGE = [
469  '/realm              status of this session\'s realm',
470  '/realm view [image|raster]   watch it live in a pane',
471  '/realm on [omarchy] start it (regular realm, or the Omarchy VM)',
472  '/realm off          stop it and turn agent use off for this session',
473  '/realm stop         power it down, keep its home',
474  '/realm control      take or hand back control of its desktop',
475  '/realm full         open it full size in your browser (noVNC)',
476  '/realm watch        copy that browser link instead',
477  '/realm setup [omarchy]   install what it needs',
478  '/realm size WxH     resize the regular realm',
479  '/realm launch CMD   start a program on the realm desktop',
480  '/realm repair       reconnect the desktop driver, keep the desktop',
481  '/realm list         realms and VM disks kept on this machine, with sizes',
482  '/realm delete ID    delete one stopped realm or VM disk',
483  '/realm clean        delete every stopped realm except this session\'s',
484  '/realm driver [check|update|rollback]',
485  '/realm doctor',
486].join('\n')
487
488function describeSetup(data: unknown, started: boolean): string {
489  const setup = (data as { setup?: Status['setup'] } | null)?.setup
490  if (!setup) return ''
491  // Once the setup job runs, its own progress (in /realm status) says the rest.
492  const lines = started ? [] : [setup.message]
493  if (setup.install_command) lines.push('Run: ! ' + setup.install_command)
494  return lines.join('\n')
495}
496
497async function command($: $, raw: string): Promise<string> {
498  const [verb = 'status', ...rest] = raw.trim().split(/\s+/).filter(Boolean)
499  switch (verb) {
500    case 'help':
501      return USAGE
502    case 'status': {
503      const { text, data, isError } = await realm($, { action: 'status' })
504      if (!isError && data) status = data as Status
505      showStatusLine($)
506      const jobs = Object.entries(status?.jobs ?? {})
507        .map(([name, job]) => '  ' + name + ': ' + job.state + (job.error ? ' (' + job.error + ')' : job.log.length ? ' · ' + job.log.at(-1) : ''))
508        .join('\n')
509      const events = (status?.events ?? []).map((event) => '  ' + event.text).join('\n')
510      return [text, jobs && 'Setup jobs:\n' + jobs, events && 'Recent:\n' + events, '/realm help lists commands.'].filter(Boolean).join('\n')
511    }
512    case 'view': {
513      if (rest[0] === 'image' || rest[0] === 'raster') {
514        modeLocked = true
515        setMode($, rest[0])
516      } else if (rest[0] === 'auto') {
517        modeLocked = false
518      }
519      if (viewsInBrowser() && !rest[0] && status?.live) {
520        await openFullView($)
521        return 'Watching ' + status.live.id + ' at full resolution in a Codemux browser pane. (/realm view raster shows the small cell preview here.)'
522      }
523      await openPane($, { asked: true })
524      return status?.live ? 'Watching ' + status.live.id + ' in the Realm pane.' : 'Realm pane open; nothing is running yet.'
525    }
526    case 'hide':
527      await closePane($)
528      return 'Realm pane closed.'
529    case 'on': {
530      const kind = rest[0] === 'omarchy' || rest[0] === 'vm' ? 'omarchy' : 'realm'
531      const { text, isError } = await realm($, { action: 'on', kind })
532      await refresh($)
533      if (!isError) {
534        if (viewsInBrowser() && status?.live) await openFullView($)
535        else await openPane($, { asked: true })
536      }
537      return text
538    }
539    case 'off':
540    case 'stop': {
541      const { text } = await realm($, { action: verb })
542      if (isControlled) isControlled = false
543      await refresh($)
544      return text
545    }
546    case 'control':
547      await takeControl($, !isControlled)
548      return isControlled ? 'You hold the realm desktop; the agent waits. /realm control hands it back.' : 'The agent has the realm desktop again.'
549    case 'full':
550      await openFullView($)
551      return 'Opening the full view…'
552    case 'watch': {
553      const { text, data, isError } = await realm($, { action: 'watch', control: rest[0] === 'control' })
554      const url = (data as { url?: string } | null)?.url
555      if (!isError && url) {
556        const copied = await $.ui.copy({ text: url }).catch(() => ({ isCopied: false }))
557        return text + ((copied as { isCopied?: boolean }).isCopied ? '\n(link copied to the clipboard)' : '')
558      }
559      return text
560    }
561    case 'setup': {
562      const { text, data } = await realm($, { action: 'setup', ...(rest[0] ? { kind: rest[0] === 'omarchy' ? 'omarchy' : 'realm' } : {}) })
563      startPolling($)
564      await refresh($)
565      const started = ((data as { started?: string[] } | null)?.started ?? []).length > 0
566      return [text, describeSetup(data, started)].filter((line, index, all) => line && all.indexOf(line) === index).join('\n')
567    }
568    case 'size': {
569      const { text } = await realm($, { action: 'size', size: rest[0] ?? '' })
570      await refresh($)
571      return text
572    }
573    case 'list': {
574      const { text } = await realm($, { action: 'list' })
575      return text
576    }
577    case 'delete': {
578      if (!rest[0]) return 'Usage: /realm delete ID (see /realm list)'
579      const { text } = await realm($, { action: 'delete', id: rest[0] })
580      return text
581    }
582    case 'clean': {
583      const { text } = await realm($, { action: 'clean' })
584      return text
585    }
586    case 'repair': {
587      const { text } = await realm($, { action: 'repair' })
588      return text
589    }
590    case 'launch': {
591      const { text } = await realm($, { action: 'launch', command: rest.join(' ') })
592      return text
593    }
594    case 'driver': {
595      const { text } = await realm($, { action: 'driver', operation: rest[0] ?? 'status' })
596      return text
597    }
598    case 'doctor': {
599      const { text } = await realm($, { action: 'doctor' })
600      return text
601    }
602    case 'shot': {
603      const { text, isError } = await realm($, { action: 'shot' })
604      return isError ? text : 'Captured the realm screen (the agent can see it with realm shot).'
605    }
606    default:
607      return 'Unknown: /realm ' + raw + '\n' + USAGE
608  }
609}
610
611// --------------------------------------------------------------- register
612
613export const register: Register = (on, pluginOptions) => {
614  options = pluginOptions
615  mode = option<string>('view_mode', 'auto') === 'raster' ? 'raster' : 'image'
616  modeLocked = option<string>('view_mode', 'auto') !== 'auto'
617
618  on('session.start', async ($, e, next) => {
619    // Codemux marks its terminal panes (CODEMUX=1, TERM_PROGRAM=codemux). Its
620    // terminal is xterm.js, which shows no pictures, so the realm's view there
621    // is a Codemux browser pane instead.
622    inCodemux = (await $.env.get('CODEMUX')) === '1' || (await $.env.get('TERM_PROGRAM')) === 'codemux'
623      || Boolean(await $.env.get('CODEMUX_PANE_ID'))
624    const aspect = option<number>('view_cell_aspect', 0)
625    cellAspect = aspect >= 1 && aspect <= 4 ? aspect : inCodemux ? 2.4 : 2.1
626    await $.command.register({
627      name: 'realm',
628      description: "This session's private Linux desktop: status, view, on/off, control, setup",
629      argumentHint: 'view | on [omarchy] | off | stop | control | watch | list | delete ID | clean | setup [omarchy] | launch CMD | driver | doctor',
630    })
631    void (async () => {
632      // The server starts with the session; give it a moment to publish itself.
633      for (let attempt = 0; attempt < 20 && !(await locate($)); attempt++) await $.clock.sleep(500)
634      await refresh($)
635      if (status?.live) startPolling($)
636    })()
637    return next(e)
638  })
639
640  on('command.run', { command: 'realm' }, async ($, e) => {
641    try {
642      return { text: await command($, e.args) }
643    } catch (error) {
644      return { text: 'claude-realms: ' + String(error) }
645    }
646  })
647
648  // The agent used the realm: pick up the new state, and show the desktop the
649  // first time it goes live unless the person closed the pane this session.
650  on('tool.call', async ($, e, next) => {
651    if (!isOurTool(e.tool)) return next(e)
652    // Only Claude Code knows which loop made a call: tell the server when a
653    // subagent did, so one that asked for its own realm gets it.
654    const agentId = (e as { agentId?: string }).agentId
655    const wasLive = Boolean(status?.live)
656    callsInFlight++
657    startFastPolling($)
658    let result
659    try {
660      result = await next(agentId ? ({ ...e, _agent: agentId } as typeof e) : e)
661    } finally {
662      callsInFlight--
663    }
664    await refresh($)
665    if (!wasLive && status?.live && !isDismissed && option('auto_view', true)) {
666      if (viewsInBrowser()) {
667        if (browserShownFor !== status.live.id) void openFullView($)
668      } else if (!isPaneOpen) {
669        void openPane($, { asked: false })
670      }
671    }
672    if (status?.live) startPolling($)
673    return result
674  })
675
676  on('tool.call', { tool: 'Bash' }, ($, e, next) => {
677    if (!status?.live || !option('host_guard', true)) return next(e)
678    const refusal = hostEscape((e as { command?: unknown }).command)
679    return refusal ? { deny: refusal } : next(e)
680  })
681
682  on('ui.close', async ($, e, next) => {
683    if (e.id !== PANE) return next(e)
684    isPaneOpen = false
685    if (e.origin?.kind === 'person') isDismissed = true
686    if (isControlled) await takeControl($, false)
687    await stopStream($)
688    picture = null
689    return next(e)
690  })
691
692  on('ui.message', async ($, e, next) => {
693    if (e.element !== 'takeover') return next(e)
694    const data = e.data as { events?: { [key: string]: unknown }[] } | null
695    if (data?.events?.length) await writeInput($, data.events)
696    return {}
697  })
698
699  on('session.end', async ($, e, next) => {
700    poller?.cancel()
701    poller = null
702    await stopStream($)
703    return next(e)
704  })
705
706  // A toggle at the right of the prompt footer while a realm is live: one
707  // press opens the Realm pane, another closes it.
708  on('ui.render', { component: 'SessionMode' }, async ($, e, next) => {
709    const live = status?.live
710    if (!live && !isPaneOpen) return next(e)
711    const engine = await next(e)
712    const { Box, Button } = $.ui.resolve(e)
713    const label = (isPaneOpen ? '◉ ' : '◈ ') + (live ? (live.kind === 'omarchy-vm' ? 'omarchy realm' : 'realm') + (isControlled ? ' · yours' : ' live') : 'realm')
714    return (
715      <Box flexDirection="row" gap={2}>
716        {engine}
717        <Button key="realm-toggle" plain label={label} onPress={() => togglePane($)} />
718      </Box>
719    )
720  })
721
722  on('ui.render', { component: 'Pane', requestId: PANE }, async ($, e) => {
723    const { Box, Text, Button } = $.ui.resolve(e)
724    const live = status?.live
725    const header = live ? (
726      <Text bold>
727        {live.kind === 'omarchy-vm' ? 'Omarchy VM ' : 'Realm '}
728        {live.id}
729        <Text dimColor>{'  ' + (live.size ?? (live.memory_mb ? live.memory_mb + ' MB' : '')) + (isControlled ? '  · you have control' : '  · agent has control')}</Text>
730      </Text>
731    ) : (
732      <Text bold>Realm</Text>
733    )
734    const controls = (
735      <Box flexDirection="row" gap={1}>
736        {live && (
737          <Button key="control" hotkey="t" label={isControlled ? 'Hand back' : 'Take control'} variant={isControlled ? 'primary' : undefined} onPress={() => takeControl($, !isControlled)} />
738        )}
739        {live && <Button key="full" hotkey="f" label="Full view" onPress={() => openFullView($)} />}
740        {live && <Button key="stop" hotkey="x" label="Stop" onPress={() => command($, 'stop').then(() => undefined)} />}
741        {!live && <Button key="start" hotkey="s" label="Start realm" onPress={() => command($, 'on').then((text) => $.ui.toast(text))} />}
742        <Button key="hide" role="dismiss" label="Close" onPress={() => closePane($)} />
743      </Box>
744    )
745
746    if (!live) {
747      const setup = status?.setup
748      return (
749        <Box flexDirection="column" gap={1}>
750          {header}
751          <Text>{connectError ? 'The realms server is not connected: ' + connectError : !status ? 'Connecting…' : !status.enabled ? 'Realm use is off for this session.' : setup && !setup.ready ? setup.message : 'No realm is running. It starts when the agent first uses a desktop tool.'}</Text>
752          {setup?.install_command && <Text dimColor>{'Run: ! ' + setup.install_command}</Text>}
753          {controls}
754        </Box>
755      )
756    }
757
758    if (e.surface !== 'terminal') {
759      return (
760        <Box flexDirection="column" gap={1}>
761          {header}
762          <Text>The live picture draws in the terminal. Full view opens it in your browser.</Text>
763          {controls}
764        </Box>
765      )
766    }
767
768    const { Image, Raster, Client } = $.ui.resolve(e)
769    const viewportRows = e.viewport?.rows ?? 40
770    const bodyColumns = (e.props as { bodyColumns?: number }).bodyColumns ?? e.viewport?.columns ?? 80
771    const target = mode === 'image' ? fit(bodyColumns, viewportRows, 255, 255) : fit(bodyColumns, viewportRows, 512, 256)
772    if (target.columns !== box.columns || target.rows !== box.rows) {
773      box = target
774      // Raster cells are sized at the source; pixels scale in the terminal.
775      if (mode === 'raster' && stream && (streamBox.columns !== box.columns || streamBox.rows !== box.rows)) restartStream($)
776    }
777    let view
778    if (picture?.kind === 'image' && mode === 'image') {
779      view = <Image key="view" source={picture.source} columns={box.columns} rows={box.rows} alt="the realm's screen" />
780    } else if (picture?.kind === 'raster' && mode === 'raster' && picture.columns === box.columns && picture.rows === box.rows) {
781      view = <Raster key="view" columns={picture.columns} rows={picture.rows} cells={picture.cells} />
782    } else {
783      view = <Text dimColor>{viewError ?? "Connecting to the realm's screen…"}</Text>
784    }
785    return (
786      <Box flexDirection="column">
787        {header}
788        <Box flexDirection="column">
789          {view}
790          {isControlled && picture && (
791            <Box position="absolute" top={0} left={0}>
792              <Client key="takeover" module="./takeover.tsx" width={box.columns} height={box.rows} />
793            </Box>
794          )}
795        </Box>
796        <Text dimColor>
797          {isControlled
798            ? 'Click the picture, then type: keys and clicks go to the realm. Esc returns the keyboard.'
799            : mode === 'raster'
800              ? 'This terminal can only show a low-resolution preview (Ghostty and kitty show it sharp). Full view (f) opens it sharp in your browser.'
801              : 'Live view of the realm. The agent works here, never on your screen.'}
802        </Text>
803        {controls}
804      </Box>
805    )
806  })
807}
808

1// Refuses Bash commands that re-point GUI tooling at the person's own desktop
2// while this session works in a realm (a port of realms_core/host_guard.py).
3//
4// A realm's tools never see the host display, bus or input handles, but nothing
5// stops a command from putting them back: `env WAYLAND_DISPLAY=wayland-1 app`
6// is enough for a GUI tool to act on the real desktop while the agent believes
7// it is working privately. This is an agent-judgment guardrail, not a
8// containment boundary: it reports one recognised pattern out loud.
9
10export const GUARDED_KEYS = [
11  'WAYLAND_DISPLAY',
12  'HYPRLAND_INSTANCE_SIGNATURE',
13  'HYPRLAND_CMD',
14  'DISPLAY',
15  'XDG_RUNTIME_DIR',
16  'DBUS_SESSION_BUS_ADDRESS',
17  'AT_SPI_BUS_ADDRESS',
18  'SWAYSOCK',
19  'I3SOCK',
20  'YDOTOOL_SOCKET',
21  'CUA_INJECT_SOCKET',
22  'CUA_DRIVER_SOCKET',
23  'XAUTHORITY',
24] as const
25
26const PREFIXES = new Set(['env', 'export', 'declare', 'typeset', 'setenv', ';', '&&', '||', '|', '&'])
27const ASSIGNMENT = /^([A-Za-z_][A-Za-z0-9_]*)=([\s\S]*)$/
28const OPERATORS = /[;&|]+$/
29
30// Shell words as POSIX sh splits them (quotes, escapes, comments); null when
31// the text does not parse, which the guard treats as ordinary.
32export function shellWords(text: string): string[] | null {
33  const words: string[] = []
34  let word = ''
35  let hasWord = false
36  let i = 0
37  while (i < text.length) {
38    const c = text[i]!
39    if (c === "'") {
40      const end = text.indexOf("'", i + 1)
41      if (end < 0) return null
42      word += text.slice(i + 1, end)
43      hasWord = true
44      i = end + 1
45    } else if (c === '"') {
46      i += 1
47      let closed = false
48      while (i < text.length) {
49        const d = text[i]!
50        if (d === '\\' && i + 1 < text.length && '"\\$`\n'.includes(text[i + 1]!)) {
51          word += text[i + 1]
52          i += 2
53        } else if (d === '"') {
54          closed = true
55          i += 1
56          break
57        } else {
58          word += d
59          i += 1
60        }
61      }
62      if (!closed) return null
63      hasWord = true
64    } else if (c === '\\') {
65      if (i + 1 < text.length) word += text[i + 1]
66      hasWord = true
67      i += 2
68    } else if (c === '#' && !hasWord) {
69      const end = text.indexOf('\n', i)
70      i = end < 0 ? text.length : end
71    } else if (/\s/.test(c)) {
72      if (hasWord) words.push(word)
73      word = ''
74      hasWord = false
75      i += 1
76    } else {
77      word += c
78      hasWord = true
79      i += 1
80    }
81  }
82  if (hasWord) words.push(word)
83  return words
84}
85
86// A guarded key is only an escape when it is pointed somewhere real.
87export function isHostValue(key: string, value: string): boolean {
88  if (!value) return false
89  if (key === 'XDG_RUNTIME_DIR') return /^\/run\/user\/[0-9]+\/?$/.test(value)
90  if (key === 'DISPLAY') return /^:[0-9]+(\.[0-9]+)?$/.test(value)
91  if (key === 'DBUS_SESSION_BUS_ADDRESS' || key === 'AT_SPI_BUS_ADDRESS')
92    return /\/run\/user\/[0-9]+\/(bus|at-spi)/.test(value)
93  return true
94}
95
96function splitOperator(token: string): [string, boolean] {
97  return [token.replace(OPERATORS, ''), OPERATORS.test(token)]
98}
99
100// The refusal for a command that re-points a guarded key, else null.
101export function hostEscape(command: unknown): string | null {
102  if (typeof command !== 'string' || !command.trim()) return null
103  const tokens = shellWords(command)
104  if (tokens === null) return null
105  const found: string[] = []
106  tokens.forEach((token, index) => {
107    const [bare] = splitOperator(token)
108    const match = ASSIGNMENT.exec(bare)
109    if (!match) return
110    const key = match[1]!
111    const value = match[2]!
112    if (!(GUARDED_KEYS as readonly string[]).includes(key) || !isHostValue(key, value)) return
113    const [previous, ended] = index ? splitOperator(tokens[index - 1]!) : ['', true]
114    if (index === 0 || ended || PREFIXES.has(previous) || ASSIGNMENT.test(previous)) found.push(key)
115  })
116  if (found.length === 0) return null
117  return (
118    'Blocked: this command re-points ' +
119    [...new Set(found)].join(', ') +
120    " at the person's own desktop while this session works in a realm. That is how an agent " +
121    'ends up driving the real screen while reporting it is working privately. Use realm_exec or ' +
122    'realm_launch for the realm, or ask the person (they can run /realm off for host access).'
123  )
124}
125

1// Laid over the live realm picture while the person holds control: forwards
2// what they type and click to the realm's desktop. Keys arrive as presses (the
3// terminal reports no releases); pointer positions arrive in cells, with the
4// sub-cell fraction where the terminal reports pixels.
5
6import type { ClientModule, ClientPointerEvent, JsonValue } from 'claude-code'
7
8type Event = { [key: string]: JsonValue }
9type State = { queue: Event[] }
10
11const Takeover: ClientModule<JsonValue, State> = (_props, surface) => {
12  if (surface.state === undefined) {
13    const state: State = { queue: [] }
14    surface.onKey((e) => {
15      const event: Event = { t: 'key', key: e.key }
16      if (e.ctrl) event.ctrl = true
17      if (e.shift) event.shift = true
18      if (e.meta) event.meta = true
19      state.queue.push(event)
20    })
21    surface.onPointer((e: ClientPointerEvent) => {
22      if (e.type === 'enter' || e.type === 'leave') return
23      // A hover move without a button carries no information for the desktop
24      // worth a post per frame; drags (move with a button) do.
25      if (e.type === 'move' && !e.button) return
26      state.queue.push({
27        t: 'ptr',
28        type: e.type,
29        button: e.button ?? 'left',
30        x: e.fine?.x ?? e.x + 0.5,
31        y: e.fine?.y ?? e.y + 0.5,
32        columns: surface.columns,
33        rows: surface.rows,
34      })
35    })
36    // One post per frame at most: send everything queued since the last one.
37    surface.every(30, () => {
38      if (state.queue.length === 0) return
39      const events = state.queue.splice(0)
40      surface.post({ events })
41    })
42    surface.setState(state)
43  }
44  const { Box } = surface.elements
45  return <Box width="100%" height="100%" />
46}
47
48export default Takeover
49
