image-peek

1import { atom, read, update } from 'claude-code'
2import type { EngineInterface, Register } from 'claude-code'
3
4import type { PastedImage } from '../types'
5import { fitRow, imageNumbers, pngSize } from './layout'
6import type { Size } from './layout'
7
8// Pasting an image raises no prompt.edit (the tag only shows up on the next keystroke),
9// so the draft is polled instead.
10const POLL_MS = 200
11
12const images = atom({ plugin: 'image-peek', key: 'images' } as const, [] as PastedImage[])
13
14let tmpRoot: string | undefined
15let found: { sessionId: string; dir: string } | undefined
16// The image numbers last drawn, so an unchanged draft doesn't rewrite state; undefined
17// while a drawn image's file is still missing, so the next poll looks again.
18let shownKey: string | undefined
19let isChecking = false
20const sizes = new Map<string, Size | null>()
21
22// Claude Code caches each paste as <tmp>/<project>/<session>/images/<n>.png. The project
23// folder is named after a working directory that may since have moved, so find it by the
24// session id instead of rebuilding it.
25async function imagesDir($: EngineInterface): Promise<string | undefined> {
26  const sessionId = await $.session.id()
27  if (found?.sessionId === sessionId) return found.dir
28  if (tmpRoot === undefined) {
29    const fromEnv = await $.env.get('CLAUDE_CODE_TMPDIR')
30    tmpRoot = fromEnv ?? `/tmp/claude-${(await $.process.run(['id', '-u'])).stdout.trim()}`
31  }
32  const entries = await $.fs.list(tmpRoot).catch(() => [])
33  for (const entry of entries) {
34    const dir = `${tmpRoot}/${entry.name}/${sessionId}/images`
35    if (entry.kind === 'dir' && (await $.fs.exists(dir))) {
36      found = { sessionId, dir }
37      return dir
38    }
39  }
40  return undefined
41}
42
43async function describe($: EngineInterface, dir: string | undefined, n: number): Promise<PastedImage> {
44  const path = `${dir}/${n}.png`
45  if (dir === undefined || !(await $.fs.exists(path))) return { n, path: null, size: null }
46  if (!sizes.has(path)) {
47    const head = await $.fs.read(path, { as: 'bytes' }).then(
48      ({ base64 }) => pngSize(base64),
49      () => undefined, // too big to read: still drawable, just without its aspect ratio
50    )
51    if (head === null) return { n, path: null, size: null }
52    sizes.set(path, head ?? null)
53  }
54  return { n, path, size: sizes.get(path) ?? null }
55}
56
57// 新版 Claude Code 不再把貼圖寫進 <tmp>/<project>/<session>/images，改存成系統暫存資料夾
58// （macOS 的 $TMPDIR）裡的 clipboard-<時間>.png。草稿裡有 k 張圖，就拿最新的 k 個檔，
59// 依時間順序對到由小到大的 [Image #N]。
60async function clipboardFiles($: EngineInterface): Promise<string[]> {
61  const dir = ((await $.env.get('TMPDIR')) ?? '/tmp').replace(/\/+$/, '')
62  const entries = await $.fs.list(dir).catch(() => [])
63  return entries
64    .filter(entry => entry.kind !== 'dir' && /^clipboard-.*\.png$/i.test(entry.name))
65    .map(entry => entry.name)
66    .sort()
67    .map(name => `${dir}/${name}`)
68}
69
70async function sized($: EngineInterface, n: number, path: string): Promise<PastedImage> {
71  if (!sizes.has(path)) {
72    const head = await $.fs.read(path, { as: 'bytes' }).then(
73      ({ base64 }) => pngSize(base64),
74      () => undefined,
75    )
76    if (head === null) return { n, path: null, size: null }
77    sizes.set(path, head ?? null)
78  }
79  return { n, path, size: sizes.get(path) ?? null }
80}
81
82async function show($: EngineInterface, draft: string) {
83  const numbers = imageNumbers(draft).slice().sort((a, b) => a - b)
84  const key = numbers.join(',')
85  if (key === shownKey) return
86  const dir = numbers.length > 0 ? await imagesDir($) : undefined
87  let list: PastedImage[] = []
88  for (const n of numbers) list.push(await describe($, dir, n))
89  // 舊位置找不到時，改用暫存資料夾裡最新的貼圖
90  if (list.some(image => image.path === null)) {
91    const files = await clipboardFiles($)
92    const recent = files.slice(Math.max(0, files.length - numbers.length))
93    const offset = numbers.length - recent.length
94    list = []
95    for (const [i, n] of numbers.entries()) {
96      const path = i >= offset ? recent[i - offset] : undefined
97      list.push(path ? await sized($, n, path) : { n, path: null, size: null })
98    }
99  }
100  shownKey = list.every(image => image.path !== null) ? key : undefined
101  await update($, images, () => list)
102}
103
104async function check($: EngineInterface) {
105  if (isChecking) return
106  isChecking = true
107  try {
108    await show($, (await $.prompt.read()).text)
109  } finally {
110    isChecking = false
111  }
112}
113
114export const register: Register = on => {
115  on('session.start', async ($, e, next) => {
116    $.clock.every(POLL_MS, () => check($))
117    return next(e)
118  })
119
120  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
121    if (e.surface !== 'terminal' || e.props.hasSurvey) return next(e)
122    const list = await read($, images)
123    if (list.length === 0) return next(e)
124
125    const { Box, Image, Text } = $.ui.resolve(e)
126    const cells = fitRow(list.map(image => image.size), e.props.maxRows, e.props.bodyColumns)
127    const below = await next(e)
128
129    return (
130      <Box flexDirection="column">
131        <Box flexDirection="row" columnGap={1}>
132          {list.map((image, i) => {
133            const { columns, rows } = cells[i] ?? { columns: 4, rows: 1 }
134            return (
135              <Box flexDirection="column" alignItems="center" borderStyle="round" borderDimColor>
136                {image.path === null ? (
137                  <Box width={columns} height={rows} alignItems="center" justifyContent="center">
138                    <Text dimColor wrap="truncate">no preview</Text>
139                  </Box>
140                ) : (
141                  <Image
142                    key={`image-${image.n}`}
143                    source={{ file: image.path, format: 'png' }}
144                    columns={columns}
145                    rows={rows}
146                    alt={`[Image #${image.n}]`}
147                  />
148                )}
149                <Text dimColor>#{image.n}</Text>
150              </Box>
151            )
152          })}
153        </Box>
154        {below}
155      </Box>
156    )
157  })
158}
159

1export type Size = { width: number; height: number }
2export type Cells = { columns: number; rows: number }
3
4const TILE_ROWS = 6
5const MAX_COLUMNS = 32
6const MIN_COLUMNS = 4
7// A terminal cell is about twice as tall as it is wide.
8const CELL_ASPECT = 2
9// Used when the size is unknown (file over $.fs.read's 4 MiB cap, or no file).
10const FALLBACK: Size = { width: 16, height: 10 }
11// Each tile adds a border on every side and a label row under the picture.
12const TILE_CHROME_ROWS = 3
13const TILE_CHROME_COLUMNS = 2
14const GAP = 1
15
16/** The distinct image numbers a draft references, in the order they first appear. */
17export function imageNumbers(draft: string): number[] {
18  const seen = new Set<number>()
19  for (const match of draft.matchAll(/\[Image #(\d+)\]/g)) seen.add(Number(match[1]))
20  return [...seen]
21}
22
23/** Width and height from a PNG's IHDR chunk, or null when the bytes aren't a PNG. */
24export function pngSize(base64: string): Size | null {
25  // 24 bytes cover the signature and IHDR's width and height; 32 base64 chars decode to exactly 24.
26  const head = Uint8Array.from(atob(base64.slice(0, 32)), char => char.charCodeAt(0))
27  const signature = [0x89, 0x50, 0x4e, 0x47, 0x0d, 0x0a, 0x1a, 0x0a]
28  if (head.length < 24 || signature.some((byte, i) => head[i] !== byte)) return null
29  const view = new DataView(head.buffer, head.byteOffset, head.byteLength)
30  const width = view.getUint32(16)
31  const height = view.getUint32(20)
32  return width > 0 && height > 0 ? { width, height } : null
33}
34
35/** A picture box `rows` tall that keeps the picture's aspect ratio. */
36export function fitCells(size: Size | null, tileRows = TILE_ROWS): Cells {
37  const { width, height } = size ?? FALLBACK
38  let rows = tileRows
39  let columns = Math.round((rows * CELL_ASPECT * width) / height)
40  if (columns > MAX_COLUMNS) {
41    columns = MAX_COLUMNS
42    rows = Math.max(1, Math.round((MAX_COLUMNS * height) / (CELL_ASPECT * width)))
43  }
44  return { columns: Math.max(MIN_COLUMNS, columns), rows: Math.min(rows, tileRows) }
45}
46
47/**
48 * Picture boxes for one row of tiles that fits the band whole, so it never scrolls:
49 * the tallest tiles whose chrome fits in `maxRows` and whose total width fits in `bodyColumns`.
50 */
51export function fitRow(sizes: readonly (Size | null)[], maxRows: number, bodyColumns: number): Cells[] {
52  const tallest = Math.max(1, Math.min(TILE_ROWS, maxRows - TILE_CHROME_ROWS))
53  for (let tileRows = tallest; tileRows > 1; tileRows--) {
54    const cells = sizes.map(size => fitCells(size, tileRows))
55    const width = cells.reduce((sum, c) => sum + c.columns + TILE_CHROME_COLUMNS, 0) + GAP * (cells.length - 1)
56    if (width <= bodyColumns) return cells
57  }
58  return sizes.map(size => fitCells(size, 1))
59}
60

1export type PastedImage = {
2  n: number
3  /** Absolute path of the cached PNG; null when it can't be found. */
4  path: string | null
5  /** Pixel size; null when unknown, and the tile falls back to a default shape. */
6  size: { width: number; height: number } | null
7}
8
9declare module 'claude-code' {
10  interface PluginState {
11    'image-peek': { images: PastedImage[] }
12  }
13}
14
