1import { atom, read, update } from 'claude-code'
2import type { EngineInterface, Register, Timer } from 'claude-code'
3
4import type { Diagram, Picture } from '../types'
5
6const MAX_DIAGRAMS = 50
7const PANE = 'diagram'
8
9// How the mod colors itself, picked in /config (`palette`). `terminal` paints no
10// colors of its own: text, borders and backgrounds follow each person's terminal,
11// whatever its theme. The presets paint a full palette whatever Claude Code's theme is.
12type Ink = { color?: string; dimColor?: boolean }
13type Palette = {
14  text: Ink
15  muted: Ink
16  accent: Ink
17  rule: { borderColor?: string; borderDimColor?: boolean }
18  highlight: { borderColor?: string; borderDimColor?: boolean }
19  background?: string
20  surface?: string
21}
22
23const PALETTES: Record<string, Palette> = {
24  terminal: {
25    text: {},
26    muted: { dimColor: true },
27    accent: { color: 'claude' },
28    rule: { borderDimColor: true },
29    highlight: { borderColor: 'claude' },
30  },
31  // Braver's Solarized Light: base2 for the card, a step darker than the base3 cream of the chat.
32  'solarized-light': {
33    text: { color: '#073642' },
34    muted: { color: '#586e75' },
35    accent: { color: '#cb4b16' },
36    rule: { borderColor: '#93a1a1' },
37    highlight: { borderColor: '#cb4b16' },
38    background: '#eee8d5',
39    surface: '#e3dbc6',
40  },
41  'solarized-dark': {
42    text: { color: '#93a1a1' },
43    muted: { color: '#839496' },
44    accent: { color: '#cb4b16' },
45    rule: { borderColor: '#586e75' },
46    highlight: { borderColor: '#cb4b16' },
47    background: '#073642',
48    surface: '#0d3f4c',
49  },
50}
51
52// The title types itself back in this many characters per frame once a turn ends.
53const REVEAL_STEP = 3
54const REVEAL_FRAME_MS = 25
55
56const list = atom({ plugin: 'diagrams', key: 'list' } as const, [])
57const index = atom({ plugin: 'diagrams', key: 'index' } as const, 0)
58const isOpen = atom({ plugin: 'diagrams', key: 'isOpen' } as const, false)
59// How much of the chip's title shows; -1 is all of it.
60const reveal = atom({ plugin: 'diagrams', key: 'reveal' } as const, -1)
61// How many columns the full-screen view is panned right, for a diagram wider than the pane.
62const pan = atom({ plugin: 'diagrams', key: 'pan' } as const, 0)
63// Which multiplexer full screen zoomed ('herdr', 'tmux' or ''), so close undoes only its own zoom.
64const zoomedBy = atom({ plugin: 'diagrams', key: 'zoomedBy' } as const, '')
65const isFull = atom({ plugin: 'diagrams', key: 'isFull' } as const, false)
66// Show the text version even where a picture is rendered.
67const isText = atom({ plugin: 'diagrams', key: 'isText' } as const, false)
68// The frame of the working chip's pulse.
69const pulse = atom({ plugin: 'diagrams', key: 'pulse' } as const, 0)
70const PULSE = ['◇', '◈', '◆', '◈']
71const PULSE_FRAME_MS = 300
72
73// The Mermaid renderer when `mmdc` isn't installed: pinned, fetched once into npx's cache.
74const MERMAID_CLI = '@mermaid-js/mermaid-cli@11.17.0'
75// The first render downloads the renderer and a headless Chrome.
76const RENDER_TIMEOUT_MS = 300_000
77// A terminal cell's width over its height (16x30 px in kitty, 8x17 in most), for
78// sizing a picture in cells with its shape kept.
79const CELL_ASPECT = 0.53
80// Pictures render at 2x, so on a Retina screen with 16 px cells this many image
81// pixels make one column at actual size; a picture is never stretched past it.
82const PIXELS_PER_COLUMN = 16
83// What full screen asks the dock for: more than any terminal has, so it gets the most it can.
84const FULL_COLUMNS = 1000
85
86const STYLE = `The user's diagrams mod pins every diagram you write to a small chip on the right above the prompt, which they expand to see it large, with a history.
87- Put each diagram in its own fenced code block (\`\`\`text), drawn with Unicode box-drawing characters (┌ ─ ┐ │ └ ┘ ├ ┤ ┬ ┴ ┼) and arrows (──▶ ◀── ▲ ▼).
88- Write a short title naming what it shows, in bold on its own line just before the block, e.g. "**Slack request flow**". The chip shows it.
89- Keep each diagram at most 100 columns wide and about 25 lines tall; split a big picture into several blocks, each with its own title.`
90
91const MERMAID_STYLE = `- Right after each diagram's block, write the same diagram as a \`\`\`mermaid block (flowchart, sequenceDiagram, stateDiagram-v2 or erDiagram, whichever fits); the mod renders it as a picture. Quote flowchart node labels (A["..."]) and edge labels (-->|"..."|); in sequence, state and ER diagrams write labels bare, since quotes there show literally. Keep it as simple as the text version.`
92
93// Box-drawing and arrow characters; a fenced block with enough of them is a diagram.
94const DRAWING = /[┌┐└┘├┤┬┴┼─│═║╔╗╚╝╭╮╯╰▶◀▲▼►◄→←↑↓]/g
95const MIN_DRAWING_CHARS = 12
96const FENCE = /(^|\n)```([^\n]*)\n([\s\S]*?)\n```/g
97
98type Part = { kind: 'text'; text: string } | { kind: 'diagram'; diagram: Diagram }
99
100export const register: Register = (on, options) => {
101  const S = PALETTES[String(options.palette)] ?? PALETTES.terminal!
102  // Full screen can wear its own palette, the card keeping the terminal's colors.
103  const fullS = PALETTES[String(options.fullScreenPalette)] ?? S
104  const isPictures = options.pictures !== 'off'
105  const theme = String(options.palette).endsWith('dark') ? 'dark' : 'neutral'
106  let revealing: Timer | undefined
107  let pulsing: Timer | undefined
108
109  on('session.start', async ($, e, next) => {
110    // A reload drops the timers, so a title stuck half typed shows whole.
111    await update($, reveal, () => -1)
112    await $.command.register({
113      name: 'diagrams',
114      description: 'Expand or collapse the diagram card above the prompt',
115    })
116
117    return next(e)
118  })
119
120  on('prompt.compose', async ($, e, next) => {
121    const composed = await next(e)
122
123    return {
124      sections: [...composed.sections, { id: 'diagrams:style', text: isPictures ? `${STYLE}\n${MERMAID_STYLE}` : STYLE, scope: 'session' }],
125    }
126  })
127
128  // While a turn runs the chip's symbol pulses, so it reads as working.
129  on('turn.start', async ($, e, next) => {
130    pulsing?.cancel()
131    pulsing = $.clock.every(PULSE_FRAME_MS, () => void update($, pulse, n => (n + 1) % PULSE.length))
132
133    return next(e)
134  })
135
136  on('turn.complete', async ($, e, next) => {
137    const done = await next(e)
138
139    if (e.agentId) {
140      return done
141    }
142
143    pulsing?.cancel()
144
145    if (!e.isAborted) {
146      for (const diagram of diagramsIn(e.answer)) {
147        await pin($, diagram)
148      }
149
150      // Rendering takes seconds (minutes the first time): outside this dispatch.
151      if (isPictures) {
152        $.clock.after(0, () => void renderPictures($, S.background ?? 'transparent', theme))
153      }
154    }
155
156    // The chip sat as a bare symbol while the turn ran; type its title back in.
157    revealing?.cancel()
158    await update($, reveal, () => 0)
159    revealing = $.clock.every(REVEAL_FRAME_MS, async () => {
160      const title = (await current($))?.title ?? ''
161      const shown = await update($, reveal, n => (n < 0 || n + REVEAL_STEP >= title.length ? -1 : n + REVEAL_STEP))
162
163      if (shown < 0) {
164        revealing?.cancel()
165      }
166    })
167
168    return done
169  })
170
171  // An earlier version registered this tool, and a registration outlives the code
172  // that made it (there is no unregister), so calls to it still arrive: pin the diagram.
173  on('tool.call', { tool: 'mcp__diagrams__show_diagram' }, async ($, e) => {
174    const args = e as unknown as { title?: unknown; diagram?: unknown }
175    const source = typeof args.diagram === 'string' ? args.diagram.replace(/\s+$/, '') : ''
176
177    if (!isDiagram(source)) {
178      return { deny: 'That is not a diagram. Write diagrams in a fenced ```text block in your reply instead.' }
179    }
180
181    const title = typeof args.title === 'string' && args.title.trim() ? args.title.trim() : 'Diagram'
182    await pin($, { title, source })
183
184    return { result: `Diagram "${title}" is pinned to the chip above the prompt. Next time, write diagrams in a fenced \`\`\`text block in your reply; the mod pins those too.` }
185  })
186
187  // Esc and the corner mark close full screen without our own close call.
188  on('ui.close', { id: PANE }, async ($, e, next) => {
189    const closed = await next(e)
190    await update($, isFull, () => false)
191    await unzoom($)
192
193    return closed
194  })
195
196  on('command.run', { command: 'diagrams' }, async $ => {
197    if ((await read($, list)).length === 0) {
198      return { text: 'No diagrams yet in this session.' }
199    }
200
201    const expanded = await update($, isOpen, open => !open)
202
203    return { text: expanded ? 'Diagram expanded above the prompt.' : 'Diagram collapsed.' }
204  })
205
206  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
207    const all = await read($, list)
208    const at = clamp(await read($, index), all.length)
209    const diagram = all[at]
210
211    if (!diagram || e.props.hasSurvey) {
212      return next(e)
213    }
214
215    const elements = $.ui.resolve(e)
216    const { Box, Button, Text } = elements
217    // Pictures draw only where the surface has Image (the terminal); elsewhere the text.
218    const Image = 'Image' in elements ? elements.Image : undefined
219    const step = (by: number) => () => update($, index, i => clamp(i + by, all.length))
220    const showsPicture = isPictures && !!Image && !!diagram.picture && !(await read($, isText))
221    const toggle: Action[] = isPictures && diagram.picture
222      ? [{ key: 'view', label: showsPicture ? '⌗ text' : '▦ picture', onPress: () => update($, isText, text => !text) }]
223      : []
224    const expand = () => update($, isOpen, () => true)
225    const collapse = () => update($, isOpen, () => false)
226    const fullScreen = async () => {
227      await collapse()
228      await openPane($)
229    }
230    const navigation = all.length > 1 && (
231      <Box gap={1} flexShrink={0}>
232        {/* Words beside the arrows: a one-cell arrow is too small to hit. */}
233        <Button key="prev" label="‹ prev" plain onPress={step(-1)} />
234        <Text {...S.muted}>
235          {at + 1}/{all.length}
236        </Text>
237        <Button key="next" label="next ›" plain onPress={step(1)} />
238      </Box>
239    )
240
241    // While Claude works the chip is a bare symbol, out of the way, that still expands.
242    if (e.props.isWorking && !(await read($, isOpen))) {
243      return (
244        <Box justifyContent="flex-end">
245          <Box borderStyle="round" {...S.rule} paddingX={1} gap={1}>
246            <Button key="open-symbol" label={PULSE[(await read($, pulse)) % PULSE.length]!} plain onPress={expand} />
247            {all.length > 1 && <Text {...S.muted}>{all.length}</Text>}
248            <Button key="open" label="⤢" plain onPress={expand} />
249          </Box>
250        </Box>
251      )
252    }
253
254    if (await read($, isOpen)) {
255      return <Box justifyContent="flex-end">{expandedCard()}</Box>
256    }
257
258    // Full screen is open: the chip says so and closes it.
259    if (await read($, isFull)) {
260      return (
261        <Box justifyContent="flex-end">
262          <Box borderStyle="round" {...S.highlight} paddingX={1} gap={1}>
263            <Text {...S.accent}>⛶</Text>
264            <Text bold {...S.text} wrap="truncate-end">
265              {diagram.title}
266            </Text>
267            <Text {...S.muted}>in full screen</Text>
268            <Button key="close-full" label="close" onPress={() => closePane($)} />
269          </Box>
270        </Box>
271      )
272    }
273
274    const shown = await read($, reveal)
275    const title = shown < 0 ? diagram.title : diagram.title.slice(0, shown)
276
277    return (
278      <Box justifyContent="flex-end">
279        <Box borderStyle="round" {...S.rule} paddingX={1} gap={1}>
280          <Text {...S.accent}>◆</Text>
281          {/* The whole title expands too, not only the small button at the end. */}
282          <Button key="open-title" label={title || ' '} plain onPress={expand} />
283          {shown < 0 && navigation}
284          <Button key="open" label="expand" variant="primary" onPress={expand} />
285        </Box>
286      </Box>
287    )
288
289    // The chip grown into a card in place. Painting it over the chat (an absolute
290    // Box above the band) left the chat garbled in a fullscreen terminal, so it takes
291    // its rows; a diagram taller than the band's room is cut, with full screen offered.
292    function expandedCard() {
293      const lines = diagram!.source.split('\n')
294      // One width for every diagram in the history, so switching doesn't move the controls.
295      const widest = Math.max(...all.flatMap(one => one.source.split('\n').map(line => [...line].length)), 56)
296      // Wide enough for every diagram's text and, with pictures on, its picture at actual size.
297      const pictured = isPictures ? Math.max(0, ...all.map(one => (one.picture ? Math.ceil(one.picture.width / PIXELS_PER_COLUMN) : 0))) : 0
298      const width = Math.min(e.props.bodyColumns, Math.max(widest, pictured) + 4)
299      // The band's rows less the card's own: two border rows, the title bar, the footer
300      // and the "more lines" note; more than that and the band scrolls, cutting off the top.
301      const room = Math.max(4, e.props.maxRows - 5)
302      const hidden = Math.max(0, lines.length - room)
303
304      return (
305        <Box flexDirection="column" width={width} borderStyle="round" {...S.highlight} backgroundColor={S.background}>
306          <Box gap={1} paddingX={1} backgroundColor={S.surface}>
307            <Text {...S.accent} backgroundColor={S.surface}>
308              ◉
309            </Text>
310            <Text bold {...S.text} backgroundColor={S.surface} wrap="truncate-end">
311              {diagram!.title}
312            </Text>
313          </Box>
314          {showsPicture ? (
315            pictureBox(S, Box, Image!, diagram!, width - 4, room)
316          ) : (
317            diagramLines(S, Box, Text, hidden > 0 ? lines.slice(0, room) : lines, 0)
318          )}
319          {!showsPicture && hidden > 0 && (
320            <Text {...S.muted} backgroundColor={S.background}>
321              {`  … ${hidden} more lines in full screen`}
322            </Text>
323          )}
324          {/* Every control on the bottom row, which sits on the prompt and so stays put. */}
325          <Box justifyContent="space-between" paddingX={1} backgroundColor={S.background}>
326            <Box flexShrink={0}>{navigation || <Text backgroundColor={S.background}> </Text>}</Box>
327            {actions(S, Box, Button, Text, [
328              ...toggle,
329              { key: 'full', label: '⛶ full', onPress: fullScreen },
330              { key: 'browser', label: '↗ browser', onPress: () => openInBrowser($, diagram!) },
331              { key: 'copy', label: '⧉ copy', onPress: press => copy($, diagram!, press.surface, showsPicture) },
332              { key: 'close', label: '✕ close', onPress: collapse },
333            ])}
334          </Box>
335        </Box>
336      )
337    }
338
339  })
340
341  // Full screen: Claude Code's pane, which the person scrolls with the arrows.
342  on('ui.render', { component: 'Pane', requestId: PANE }, async ($, e) => {
343    const S = fullS
344    const diagram = await current($)
345    const elements = $.ui.resolve(e)
346    const { Box, Button, Text } = elements
347    const Image = 'Image' in elements ? elements.Image : undefined
348
349    if (!diagram) {
350      return <Text {...S.muted}>No diagrams yet.</Text>
351    }
352
353    const lines = diagram.source.split('\n')
354    // The pane's width less its padding; a wider diagram pans sideways instead of being cut.
355    const visible = Math.max(10, e.props.bodyColumns - 2)
356    const widest = Math.max(...lines.map(line => [...line].length))
357    const maxPan = Math.max(0, widest - visible)
358    const left = Math.min(await read($, pan), maxPan)
359    const panBy = (by: number) => () => update($, pan, at => Math.max(0, Math.min(at + by, maxPan)))
360    const step = Math.max(10, Math.floor(visible / 2))
361    const showsPicture = isPictures && !!Image && !!diagram.picture && !(await read($, isText))
362
363    // At least the pane's height, so the palette fills it and the footer sits at its
364    // bottom; a taller diagram makes it longer and the person scrolls with the arrows.
365    return (
366      <Box flexDirection="column" width={e.props.bodyColumns} minHeight={e.props.scroll.bodyRows} backgroundColor={S.background}>
367        <Box gap={1} paddingX={1} backgroundColor={S.surface}>
368          <Text {...S.accent} backgroundColor={S.surface}>
369            ◉
370          </Text>
371          <Text bold {...S.text} backgroundColor={S.surface} wrap="truncate-end">
372            {diagram.title}
373          </Text>
374        </Box>
375        <Box flexDirection="column" flexGrow={1} backgroundColor={S.background}>
376          {showsPicture
377            ? pictureBox(S, Box, Image!, diagram, visible, Math.max(4, e.props.scroll.bodyRows - 4), true)
378            : diagramLines(S, Box, Text, lines.map(line => [...line].slice(left, left + visible).join('')), 1)}
379        </Box>
380        <Box justifyContent="space-between" paddingX={1} backgroundColor={S.background}>
381          {!showsPicture && maxPan > 0 ? (
382            <Box gap={1} flexShrink={0}>
383              <Button key="left" label="◀" plain onPress={panBy(-step)} />
384              <Text {...S.muted} backgroundColor={S.background}>
385                columns {left + 1}–{Math.min(left + visible, widest)} of {widest}
386              </Text>
387              <Button key="right" label="▶" plain onPress={panBy(step)} />
388            </Box>
389          ) : (
390            <Text backgroundColor={S.background}> </Text>
391          )}
392          {actions(S, Box, Button, Text, [
393            ...(isPictures && diagram.picture
394              ? [{ key: 'view', label: showsPicture ? '⌗ text' : '▦ picture', onPress: () => update($, isText, text => !text) }]
395              : []),
396            { key: 'browser', label: '↗ browser', onPress: () => openInBrowser($, diagram) },
397            { key: 'copy', label: '⧉ copy', onPress: press => copy($, diagram, press.surface, showsPicture) },
398            { key: 'close', label: '✕ close', onPress: () => closePane($) },
399          ])}
400        </Box>
401      </Box>
402    )
403  })
404}
405
406type Elements = ReturnType<EngineInterface['ui']['resolve']>
407type TerminalImage = Extract<Elements, { Image: unknown }>['Image']
408
409// The diagram as plain Text rows, not Code: Code paints its own background over the palette.
410function diagramLines(S: Palette, Box: Elements['Box'], Text: Elements['Text'], lines: readonly string[], paddingY: number) {
411  return (
412    <Box flexDirection="column" paddingX={1} paddingY={paddingY} backgroundColor={S.background}>
413      {lines.map((line, row) => (
414        <Text key={`line-${row}`} {...S.text} backgroundColor={S.background} wrap="truncate-end">
415          {line || ' '}
416        </Text>
417      ))}
418    </Box>
419  )
420}
421
422// Diagrams whose render failed this load, so a broken one isn't retried after every turn.
423const failed = new Set<string>()
424let isRendering = false
425
426// Renders the pinned diagrams that have Mermaid and no picture yet, one at a time.
427async function renderPictures($: EngineInterface, background: string, theme: string) {
428  if (isRendering) {
429    return
430  }
431
432  isRendering = true
433
434  try {
435    for (const diagram of await read($, list)) {
436      if (!diagram.mermaid || diagram.picture || failed.has(diagram.mermaid)) {
437        continue
438      }
439
440      const picture = await render($, diagram.mermaid, background, theme)
441
442      if (picture) {
443        await update($, list, all => all.map(one => (one.mermaid === diagram.mermaid ? { ...one, picture } : one)))
444      } else {
445        failed.add(diagram.mermaid)
446        $.ui.toast(`Could not render "${diagram.title}" as a picture; showing the text`)
447      }
448    }
449  } finally {
450    isRendering = false
451  }
452}
453
454// The picture at actual size, its shape kept, shrunk only when the room is smaller;
455// in full screen (`grows`) as large as the room.
456function pictureBox(S: Palette, Box: Elements['Box'], Image: TerminalImage, diagram: Diagram, columns: number, rows: number, grows = false) {
457  const picture = diagram.picture!
458  const rowsPerColumn = (picture.height / picture.width) * CELL_ASPECT
459  const wide = Math.min(255, grows ? columns : picture.width / PIXELS_PER_COLUMN, columns, rows / rowsPerColumn)
460
461  return (
462    <Box paddingX={1} justifyContent="center" backgroundColor={S.background}>
463      <Image
464        source={{ file: picture.path, format: 'png' }}
465        columns={Math.max(1, Math.round(wide))}
466        rows={Math.max(1, Math.min(255, Math.round(wide * rowsPerColumn)))}
467        alt={diagram.title}
468      />
469    </Box>
470  )
471}
472
473// Renders Mermaid to a PNG in the temp folder with mmdc, or the pinned renderer through npx.
474async function render($: EngineInterface, mermaid: string, background: string, theme: string): Promise<Picture | undefined> {
475  const folder = ((await $.env.get('TMPDIR')) ?? '/tmp').replace(/\/$/, '')
476  const name = `${folder}/claude-diagram-${hash(`${mermaid}|${background}|${theme}`)}`
477  await $.fs.write(`${name}.mmd`, mermaid)
478  const args = ['-i', `${name}.mmd`, '-o', `${name}.png`, '-b', background, '-t', theme, '-s', '2', '-q']
479
480  for (const argv of [['mmdc', ...args], ['npx', '-y', '-p', MERMAID_CLI, 'mmdc', ...args]]) {
481    const isDone = await $.process.run(argv, { timeoutMs: RENDER_TIMEOUT_MS }).then(
482      run => run.exitCode === 0,
483      () => false,
484    )
485
486    if (isDone) {
487      const { base64 } = await $.fs.read(`${name}.png`, { as: 'bytes' })
488      const size = pngSize(base64)
489
490      return size && { path: `${name}.png`, ...size }
491    }
492  }
493
494  return undefined
495}
496
497// A PNG's size from its header: width and height are the big-endian words at bytes 16 and 20.
498export function pngSize(base64: string) {
499  const alphabet = 'ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/'
500  const bytes: number[] = []
501
502  for (let at = 0; at + 4 <= Math.min(base64.length, 32); at += 4) {
503    const word = [0, 1, 2, 3].reduce((sum, i) => (sum << 6) | Math.max(0, alphabet.indexOf(base64[at + i] ?? 'A')), 0)
504    bytes.push((word >> 16) & 255, (word >> 8) & 255, word & 255)
505  }
506
507  const word = (at: number) => (((bytes[at] ?? 0) << 24) | ((bytes[at + 1] ?? 0) << 16) | ((bytes[at + 2] ?? 0) << 8) | (bytes[at + 3] ?? 0)) >>> 0
508  const width = word(16)
509  const height = word(20)
510
511  return width > 0 && height > 0 ? { width, height } : undefined
512}
513
514function hash(text: string) {
515  let value = 5381
516
517  for (const char of text) {
518    value = ((value * 33) ^ char.codePointAt(0)!) >>> 0
519  }
520
521  return value.toString(36)
522}
523
524async function openPane($: EngineInterface) {
525  await update($, pan, () => 0)
526  await $.ui.close({ id: PANE })
527  await zoom($)
528  await update($, isFull, () => true)
529  // Docked beside a fullscreen transcript, ask for every column the dock will give.
530  await $.ui.open({ id: PANE, title: 'Diagram', focus: true, closeOnEscape: true, holdToasts: true, columns: FULL_COLUMNS })
531}
532
533type Action = { key: string; label: string; onPress: Parameters<Elements['Button']>[0]['onPress'] }
534
535async function closePane($: EngineInterface) {
536  await $.ui.close({ id: PANE })
537  await update($, isFull, () => false)
538  await unzoom($)
539}
540
541// Full screen makes the terminal pane fill its window first when it sits in a
542// multiplexer split (herdr or tmux), and close puts it back; elsewhere nothing changes.
543async function zoom($: EngineInterface) {
544  const run = (argv: string[]) => $.process.run(argv).then(r => (r.exitCode === 0 ? r.stdout : undefined), () => undefined)
545  const herdrPane = await $.env.get('HERDR_PANE_ID')
546
547  if (herdrPane) {
548    const herdr = (await $.env.get('HERDR_BIN_PATH')) || 'herdr'
549    const layout = await run([herdr, 'pane', 'layout', '--pane', herdrPane])
550    const isZoomed = layout === undefined || /"zoomed"\s*:\s*true/.test(layout)
551
552    if (!isZoomed && (await run([herdr, 'pane', 'zoom', '--pane', herdrPane, '--on'])) !== undefined) {
553      await update($, zoomedBy, () => 'herdr')
554    }
555
556    return
557  }
558
559  const tmuxPane = await $.env.get('TMUX_PANE')
560
561  if (tmuxPane && (await run(['tmux', 'display', '-p', '-t', tmuxPane, '#{window_zoomed_flag}']))?.trim() === '0') {
562    if ((await run(['tmux', 'resize-pane', '-Z', '-t', tmuxPane])) !== undefined) {
563      await update($, zoomedBy, () => 'tmux')
564    }
565  }
566}
567
568async function unzoom($: EngineInterface) {
569  const by = await read($, zoomedBy)
570
571  if (!by) {
572    return
573  }
574
575  await update($, zoomedBy, () => '')
576  const run = (argv: string[]) => $.process.run(argv).catch(() => undefined)
577
578  if (by === 'herdr') {
579    const herdrPane = await $.env.get('HERDR_PANE_ID')
580    const herdr = (await $.env.get('HERDR_BIN_PATH')) || 'herdr'
581
582    if (herdrPane) {
583      await run([herdr, 'pane', 'zoom', '--pane', herdrPane, '--off'])
584    }
585  } else if (by === 'tmux') {
586    const tmuxPane = await $.env.get('TMUX_PANE')
587
588    if (tmuxPane) {
589      await run(['tmux', 'resize-pane', '-Z', '-t', tmuxPane])
590    }
591  }
592}
593
594// A row of quiet text buttons, dots between them: no brackets, no hotkey labels.
595function actions(S: Palette, Box: Elements['Box'], Button: Elements['Button'], Text: Elements['Text'], list: readonly Action[]) {
596  return (
597    <Box gap={1} flexShrink={0}>
598      {list.flatMap((action, at) => [
599        ...(at > 0 ? [<Text key={`dot-${action.key}`} {...S.muted} backgroundColor={S.background}>·</Text>] : []),
600        <Button key={action.key} label={action.label} plain onPress={action.onPress} />,
601      ])}
602    </Box>
603  )
604}
605
606// Writes the diagram as a page to the temp folder and opens it in the default browser:
607// readable on any screen, light or dark, and nothing to install.
608async function openInBrowser($: EngineInterface, diagram: Diagram) {
609  const folder = ((await $.env.get('TMPDIR')) ?? '/tmp').replace(/\/$/, '')
610  const slug = diagram.title.toLowerCase().replace(/[^a-z0-9]+/g, '-').replace(/^-|-$/g, '') || 'diagram'
611  const path = `${folder}/claude-diagram-${slug}.html`
612  // The picture goes into the page itself, so the file stands alone.
613  const picture = diagram.picture
614    ? await $.fs.read(diagram.picture.path, { as: 'bytes' }).then(read => read.base64, () => undefined)
615    : undefined
616  await $.fs.write(path, page(diagram, picture))
617
618  for (const opener of ['open', 'xdg-open']) {
619    // A missing opener throws or exits non-zero; either way, try the next one.
620    const opened = await $.process.run([opener, path]).then(
621      run => run.exitCode === 0,
622      () => false,
623    )
624
625    if (opened) {
626      $.ui.toast('Diagram opened in your browser')
627
628      return
629    }
630  }
631
632  $.ui.toast(`Diagram page written to ${path}`)
633}
634
635// The browser page: the picture when there is one (base64 PNG), with the text a
636// tab away, and copy buttons for each.
637function page(diagram: Diagram, picture?: string) {
638  const escape = (text: string) => text.replace(/&/g, '&amp;').replace(/</g, '&lt;').replace(/>/g, '&gt;')
639  const title = escape(diagram.title)
640  const text = JSON.stringify(copyText(diagram)).replace(/</g, '\\u003c')
641
642  return `<!doctype html>
643<html lang="en">
644<head>
645<meta charset="utf-8">
646<meta name="viewport" content="width=device-width, initial-scale=1">
647<title>${title}</title>
648<style>
649  /* Theme tokens: the system's choice, or the one picked with the moon/sun button. */
650  :root {
651    --bg: #f7f6f3; --dots: #e4e1da; --surface: #ffffff; --text: #1d1f23; --muted: #6f737a;
652    --line: #e7e4dd; --hover: #f1efea; --accent: #d0602a; --paper: #ffffff;
653    --bar: rgb(255 255 255 / .9); --bar-line: #e2dfd8; --bar-text: #4d5158; --bar-hover: #f1efea;
654    color-scheme: light;
655  }
656  :root[data-theme="dark"] {
657    --bg: #121316; --dots: #26282d; --surface: #1c1e22; --text: #f2f2f0; --muted: #a9adb4;
658    --line: #34373e; --hover: #2a2d33; --accent: #f08a58; --paper: #fbfaf7;
659    --bar: #33373e; --bar-line: #4a4f57; --bar-text: #e4e6ea; --bar-hover: #474c55;
660    color-scheme: dark;
661  }
662  @media (prefers-color-scheme: dark) {
663    :root:not([data-theme="light"]) {
664      --bg: #121316; --dots: #26282d; --surface: #1c1e22; --text: #f2f2f0; --muted: #a9adb4;
665      --line: #34373e; --hover: #2a2d33; --accent: #f08a58; --paper: #fbfaf7;
666      --bar: #33373e; --bar-line: #4a4f57; --bar-text: #e4e6ea; --bar-hover: #474c55;
667      color-scheme: dark;
668    }
669  }
670  * { box-sizing: border-box; }
671  html, body { height: 100%; margin: 0; }
672  body {
673    display: flex; flex-direction: column; background: var(--bg); color: var(--text); overflow: hidden;
674    background-image: radial-gradient(var(--dots) 1px, transparent 1px); background-size: 20px 20px;
675    font: 14px/1.5 ui-sans-serif, -apple-system, BlinkMacSystemFont, "Segoe UI", sans-serif;
676    -webkit-font-smoothing: antialiased; transition: background-color .2s;
677  }
678  header { display: flex; align-items: center; gap: 10px; padding: 16px 22px; }
679  .mark { width: 8px; height: 8px; border-radius: 2px; background: var(--accent); transform: rotate(45deg); flex: none; }
680  h1 { margin: 0; font-size: 15px; font-weight: 600; letter-spacing: -0.01em; white-space: nowrap; overflow: hidden; text-overflow: ellipsis; }
681  /* The stage scrolls when zoomed past the window; dragging pans it. */
682  main { flex: 1; overflow: auto; display: grid; padding: 12px 24px 96px; cursor: grab; }
683  main.dragging { cursor: grabbing; user-select: none; }
684  .sheet {
685    margin: auto; border-radius: 14px; overflow: hidden;
686    box-shadow: 0 0 0 1px var(--line), 0 1px 2px rgb(0 0 0 / .04), 0 12px 32px rgb(0 0 0 / .08);
687  }
688  /* The picture is drawn dark on transparent: it sits on paper in both themes. */
689  img { display: block; padding: 24px; background: var(--paper); -webkit-user-drag: none; }
690  /* The text on the plain sheet, in the page's own ink. */
691  pre {
692    margin: 0; padding: 28px 32px; color: var(--text); background: var(--surface);
693    font: 14px/1.35 ui-monospace, "SF Mono", "JetBrains Mono", Menlo, Consolas, monospace;
694  }
695  .hidden { display: none; }
696  nav {
697    position: fixed; left: 50%; bottom: 20px; transform: translateX(-50%); display: flex; align-items: center; gap: 2px;
698    padding: 5px; background: var(--bar); backdrop-filter: blur(10px); border: 1px solid var(--bar-line);
699    border-radius: 12px; box-shadow: 0 10px 32px rgb(0 0 0 / .18); white-space: nowrap; max-width: calc(100vw - 24px); overflow-x: auto;
700  }
701  nav button {
702    font: inherit; font-size: 13px; color: var(--bar-text); background: none; border: 0; border-radius: 8px;
703    padding: 5px 10px; cursor: pointer; transition: color .15s, background .15s;
704  }
705  nav button:hover, nav button[aria-pressed="true"] { color: var(--text); background: var(--bar-hover); }
706  nav button.done { color: var(--accent); }
707  nav .icon { width: 30px; padding: 5px 0; font-size: 16px; line-height: 1; }
708  nav output { min-width: 48px; text-align: center; font-size: 12px; color: var(--bar-text); font-variant-numeric: tabular-nums; }
709  nav .rule { width: 1px; height: 18px; margin: 0 6px; background: var(--bar-line); flex: none; }
710</style>
711</head>
712<body>
713<header><span class="mark"></span><h1>${title}</h1></header>
714<main id="stage">
715  <div class="sheet">
717    <pre id="diagram"${picture ? ' class="hidden"' : ''}>${escape(diagram.source)}</pre>
718  </div>
719</main>
720<nav>
721  <button class="icon" id="zoom-out" title="Zoom out (−)">−</button>
722  <output id="zoom">100%</output>
723  <button class="icon" id="zoom-in" title="Zoom in (+)">+</button>
724  <button id="fit" title="Fit to window (0)">Fit</button>
725  ${picture ? '<span class="rule"></span><button id="show-picture" aria-pressed="true">Picture</button><button id="show-text" aria-pressed="false">Text</button>' : ''}
726  <span class="rule"></span>
727  ${picture ? '<button id="copy-image">Copy picture</button>' : ''}
728  <button id="copy">Copy${picture ? ' text' : ''}</button>
729  <span class="rule"></span>
730  <button class="icon" id="theme" title="Switch light and dark">☾</button>
731</nav>
732<script>
733  // The theme: the system's until picked; the pick is remembered for every diagram page.
734  const themeButton = document.getElementById('theme')
735  const isDark = () => (document.documentElement.dataset.theme ?? (matchMedia('(prefers-color-scheme: dark)').matches ? 'dark' : 'light')) === 'dark'
736  const paintTheme = () => { themeButton.textContent = isDark() ? '☀' : '☾' }
737  try { const kept = localStorage.getItem('diagram-theme'); if (kept) document.documentElement.dataset.theme = kept } catch {}
738  paintTheme()
739  themeButton.onclick = () => {
740    const next = isDark() ? 'light' : 'dark'
741    document.documentElement.dataset.theme = next
742    try { localStorage.setItem('diagram-theme', next) } catch {}
743    paintTheme()
744  }
745  matchMedia('(prefers-color-scheme: dark)').addEventListener('change', paintTheme)
746
747  const stage = document.getElementById('stage')
748  const pre = document.getElementById('diagram')
749  const img = document.getElementById('picture')
750  const label = document.getElementById('zoom')
751  let isText = !img
752  let zoom = 1
753
754  // 100% is the picture at its natural size (rendered at 2x) or the text at 14px.
755  const shown = () => (isText ? pre : img)
756  function base() {
757    if (isText) {
758      pre.style.fontSize = '14px'
759      return { width: pre.scrollWidth, height: pre.scrollHeight }
760    }
761    return { width: img.naturalWidth / 2 + 48, height: img.naturalHeight / 2 + 48 }
762  }
763  function apply() {
764    if (isText) pre.style.fontSize = 14 * zoom + 'px'
765    else img.style.width = (img.naturalWidth / 2) * zoom + 48 + 'px'
766    label.textContent = Math.round(zoom * 100) + '%'
767  }
768  function setZoom(next) { zoom = Math.min(8, Math.max(0.1, next)); apply() }
769  function fit() {
770    const size = base()
771    setZoom(Math.min(1, (stage.clientWidth - 48) / size.width, (stage.clientHeight - 108) / size.height))
772  }
773  document.getElementById('zoom-in').onclick = () => setZoom(zoom * 1.25)
774  document.getElementById('zoom-out').onclick = () => setZoom(zoom / 1.25)
775  document.getElementById('fit').onclick = fit
776  addEventListener('keydown', e => {
777    if (e.key === '+' || e.key === '=') setZoom(zoom * 1.25)
778    else if (e.key === '-') setZoom(zoom / 1.25)
779    else if (e.key === '0') fit()
780  })
781  // Pinch or ctrl+scroll zooms.
782  stage.addEventListener('wheel', e => {
783    if (!e.ctrlKey) return
784    e.preventDefault()
785    setZoom(zoom * Math.exp(-e.deltaY / 200))
786  }, { passive: false })
787  let drag
788  stage.addEventListener('pointerdown', e => { drag = { x: e.clientX, y: e.clientY, left: stage.scrollLeft, top: stage.scrollTop }; stage.classList.add('dragging') })
789  addEventListener('pointermove', e => { if (drag) { stage.scrollLeft = drag.left - (e.clientX - drag.x); stage.scrollTop = drag.top - (e.clientY - drag.y) } })
790  addEventListener('pointerup', () => { drag = undefined; stage.classList.remove('dragging') })
791
792  function flash(button, text) {
793    const before = button.textContent
794    button.textContent = text
795    button.classList.add('done')
796    setTimeout(() => { button.textContent = before; button.classList.remove('done') }, 1400)
797  }
798  const copy = document.getElementById('copy')
799  copy.onclick = async () => {
800    try { await navigator.clipboard.writeText(${text}); flash(copy, 'Copied') }
801    catch { flash(copy, 'Select and copy') }
802  }
803
804  if (img) {
805    const showPicture = document.getElementById('show-picture')
806    const showText = document.getElementById('show-text')
807    function show(text) {
808      isText = text
809      img.classList.toggle('hidden', text)
810      pre.classList.toggle('hidden', !text)
811      showPicture.setAttribute('aria-pressed', String(!text))
812      showText.setAttribute('aria-pressed', String(text))
813      fit()
814    }
815    showPicture.onclick = () => show(false)
816    showText.onclick = () => show(true)
817    const copyImage = document.getElementById('copy-image')
818    copyImage.onclick = async () => {
819      try {
820        const blob = await (await fetch(img.src)).blob()
821        await navigator.clipboard.write([new ClipboardItem({ 'image/png': blob })])
822        flash(copyImage, 'Copied')
823      } catch { flash(copyImage, 'Right-click to copy') }
824    }
825    img.complete ? fit() : img.addEventListener('load', fit)
826  } else {
827    fit()
828  }
829</script>
830</body>
831</html>
832`
833}
834
835// Adds a diagram to the history, or finds it there, and points the chip at it.
836async function pin($: EngineInterface, diagram: Diagram) {
837  const all = await update($, list, prior =>
838    prior.some(one => one.source === diagram.source) ? prior : [...prior, diagram].slice(-MAX_DIAGRAMS),
839  )
840  await update($, index, () => all.findIndex(one => one.source === diagram.source))
841}
842
843async function current($: EngineInterface) {
844  const all = await read($, list)
845
846  return all[clamp(await read($, index), all.length)]
847}
848
849// Copies what the card shows: the picture as an image where the machine has a tool
850// for that (macOS, or xclip), else the text.
851async function copy($: EngineInterface, diagram: Diagram, surface: Parameters<EngineInterface['ui']['copy']>[0]['surface'], isPicture: boolean) {
852  if (isPicture && diagram.picture && (await copyImage($, diagram.picture.path))) {
853    $.ui.toast('Picture copied, ready to paste into Slack, GitHub or Notion')
854
855    return
856  }
857
858  const copied = await $.ui.copy({ text: copyText(diagram), surface })
859  $.ui.toast(copied.isCopied ? 'Diagram copied, ready to paste into Slack, GitHub or Notion' : 'Could not copy the diagram')
860}
861
862async function copyImage($: EngineInterface, path: string) {
863  const tools = [
864    ['osascript', '-e', `set the clipboard to (read (POSIX file ${JSON.stringify(path)}) as «class PNGf»)`],
865    ['xclip', '-selection', 'clipboard', '-t', 'image/png', '-i', path],
866  ]
867
868  for (const argv of tools) {
869    if (await $.process.run(argv).then(run => run.exitCode === 0, () => false)) {
870      return true
871    }
872  }
873
874  return false
875}
876
877// What copy puts on the clipboard: the title as a plain line (Slack shows **bold** as
878// asterisks) and the diagram fenced, so Slack, GitHub and Notion keep it monospace.
879export function copyText(diagram: Diagram) {
880  return `${diagram.title}\n\`\`\`\n${diagram.source}\n\`\`\`\n`
881}
882
883function clamp(i: number, length: number) {
884  return Math.max(0, Math.min(i, length - 1))
885}
886
887function isDiagram(source: string) {
888  return (source.match(DRAWING) ?? []).length >= MIN_DRAWING_CHARS && source.split('\n').length >= 3
889}
890
891// A reply split into its prose and its diagrams. A short line just before a
892// diagram becomes its title and leaves the prose.
893export function partsOf(text: string): Part[] {
894  const parts: Part[] = []
895  let from = 0
896
897  for (const match of text.matchAll(FENCE)) {
898    const language = (match[2] ?? '').trim().toLowerCase()
899    const source = (match[3] ?? '').replace(/\s+$/, '')
900    const isMermaid = language === 'mermaid'
901
902    if (!isMermaid && !isDiagram(source)) {
903      continue
904    }
905
906    const before = text.slice(from, match.index + (match[1] ?? '').length)
907    const previous = parts.at(-1)
908
909    // A Mermaid block right after a text diagram is that diagram's picture.
910    if (isMermaid && !before.trim() && previous?.kind === 'diagram' && !previous.diagram.mermaid) {
911      previous.diagram.mermaid = source
912      from = match.index + match[0].length
913      continue
914    }
915
916    const { prose, title } = splitTitle(before)
917
918    if (prose.trim()) {
919      parts.push({ kind: 'text', text: prose.trim() })
920    }
921
922    parts.push({ kind: 'diagram', diagram: isMermaid ? { title, source, mermaid: source } : { title, source } })
923    from = match.index + match[0].length
924  }
925
926  const rest = text.slice(from)
927
928  if (rest.trim()) {
929    parts.push({ kind: 'text', text: rest.trim() })
930  }
931
932  return parts
933}
934
935export function diagramsIn(text: string): Diagram[] {
936  return partsOf(text).flatMap(part => (part.kind === 'diagram' ? [part.diagram] : []))
937}
938
939function splitTitle(before: string) {
940  const lines = before.replace(/\s+$/, '').split('\n')
941  const last = lines.at(-1)?.trim() ?? ''
942  const plain = last.replace(/^#+\s*/, '').replace(/[*_`]/g, '').replace(/:$/, '').trim()
943  const isTitleLine = plain.length > 0 && plain.length <= 60 && (/^(\*\*|__|#)/.test(last) || /:$/.test(last))
944
945  if (isTitleLine) {
946    return { prose: lines.slice(0, -1).join('\n'), title: plain }
947  }
948
949  return { prose: before, title: 'Diagram' }
950}
951

1// A rendered picture of a diagram: the PNG's path and its size in pixels.
2export type Picture = { path: string; width: number; height: number }
3
4export type Diagram = { title: string; source: string; mermaid?: string; picture?: Picture }
5
6declare module 'claude-code' {
7  interface PluginState {
8    diagrams: {
9      list: Diagram[]
10      index: number
11      isOpen: boolean
12      reveal: number
13      pan: number
14      zoomedBy: string
15      isFull: boolean
16      isText: boolean
17      pulse: number
18    }
19  }
20}
21
