1import { frame, frameModel, modelSvg, hex, DURATION_MS } from './draw.js'
2
3const KEY = 'wasted'
4const FRAME_MS = 50 // terminal: blit at 20 fps
5const DESKTOP_EVERY = 2 // desktop: redraw every 2nd tick, 10 fps
6
7// When the current death started, or null when nothing is playing
8let diedAt = null
9// The word the spinner showed when the tool failed
10let deathWord = 'Working'
11// The terminal spinner (agent id) whose Raster is on screen, or null
12let mounted = null
13// Whether a desktop spinner is drawing the effect
14let onDesktop = false
15let tick = 0
16// Whether this death's sound has started
17let played = false
18
19export function register(on) {
20  on('session.start', async ($, e, next) => {
21    $.clock.every(FRAME_MS, async () => {
22      if (diedAt === null) return
23      const t = Date.now() - diedAt
24      tick += 1
25      if (t >= DURATION_MS) {
26        // Effect over: give the spinner back
27        diedAt = null
28        mounted = null
29        onDesktop = false
30        $.ui.invalidate('ui.render')
31        return
32      }
33      // The mod ships no sound: it plays sounds/custom.wav if the user added one,
34      // and only once the effect is on screen (no sound from `claude -p`,
35      // background subagents, or an Esc that took the spinner away)
36      if (!played && (mounted !== null || onDesktop)) {
37        played = true
38        // Not awaited: play resolves only when the clip ends. No file, or no
39        // player on this machine: silence.
40        $.audio.play({ asset: 'sounds/custom.wav' }).catch(() => {})
41      }
42      // Desktop has no blit: redraw the site, which runs the render hook again
43      if (onDesktop && tick % DESKTOP_EVERY === 0) $.ui.invalidate('ui.render')
44      if (mounted === null) return
45      const r = await $.ui.blit({ requestId: mounted, key: KEY, ...frame(t, deathWord) })
46      if (r && r.deny) {
47        // Raster no longer mounted: ask for a redraw, which draws the current
48        // frame if the spinner is still on screen (also covers a site that
49        // refuses blits, at the slower invalidate rate)
50        mounted = null
51        $.ui.invalidate('ui.render')
52      }
53    })
54    return next(e)
55  })
56
57  on('tool.call', async ($, e, next) => {
58    const r = await next(e)
59    // Ignore failures while a death is already playing
60    if (r && r.isError && diedAt === null) {
61      diedAt = Date.now()
62      tick = 0
63      played = false
64      $.ui.invalidate('ui.render')
65    }
66    return r
67  })
68
69  on('ui.render', { component: 'Spinner' }, async ($, e, next) => {
70    if (diedAt === null || (e.surface !== 'terminal' && e.surface !== 'desktop')) {
71      if (e.props && e.props.word) deathWord = e.props.word
72      return next(e)
73    }
74    const t = Date.now() - diedAt
75    if (e.surface === 'terminal') {
76      const { Raster } = $.ui.resolve(e)
77      mounted = e.requestId
78      return Raster({ key: KEY, ...frame(t, deathWord) })
79    }
80    // Desktop: the same pixel model, drawn as SVG
81    const { Box, Text, Svg } = $.ui.resolve(e)
82    const model = frameModel(t, deathWord)
83    onDesktop = true
84    return Box({
85      flexDirection: 'column',
86      children: [
87        Text({ color: hex(model.wordColor), children: [model.label] }),
88        Svg({ source: modelSvg(model), alt: 'WASTED' }),
89      ],
90    })
91  })
92}
93

1// Pure drawing for the WASTED effect. No mods API here, so a plain node
2// script can render the same frames to PNG (scripts/render-frames.mjs).
3
4export const DURATION_MS = 2500
5export const COLUMNS = 76
6export const ROWS = 10 // 1 word row + 9 rows of half-block pixels
7
8const DEFAULT = 0x01000000 // terminal default color
9const PX_W = COLUMNS
10const PX_H = (ROWS - 1) * 2 // 18 pixels tall, two per cell with ▀/▄
11
12const CLAUDE_ORANGE = 0xd77757
13const DEAD_GREY = 0x6e6e6e
14const RED = 0xd3302f
15const SHADOW = 0x1a0606
16
17// Timeline
18const GREY_END = 500 // word drains to grey
19const IN_START = 450 // lettering starts to appear
20const IN_END = 1400 // lettering settled, then holds until DURATION_MS
21const SCALE_FROM = 2.15
22const SCALE_TO = 2
23const SHADOW_OFF = 1 // shadow offset in output pixels, right and down
24
25// Hand-drawn 5x7 lettering. Original glyphs, not any existing typeface.
26const GLYPHS = {
27  W: ['#...#', '#...#', '#...#', '#.#.#', '#.#.#', '#.#.#', '.#.#.'],
28  A: ['.###.', '#...#', '#...#', '#####', '#...#', '#...#', '#...#'],
29  S: ['.####', '#....', '#....', '.###.', '....#', '....#', '####.'],
30  T: ['#####', '..#..', '..#..', '..#..', '..#..', '..#..', '..#..'],
31  E: ['#####', '#....', '#....', '####.', '#....', '#....', '#####'],
32  D: ['####.', '#...#', '#...#', '#...#', '#...#', '#...#', '####.'],
33}
34
35// The word as one bitmap: 6 glyphs, 1 pixel gap -> 35 x 7
36const BITMAP = (() => {
37  const rows = []
38  for (let y = 0; y < 7; y++) {
39    rows.push([...'WASTED'].map((ch) => GLYPHS[ch][y]).join('.'))
40  }
41  return rows
42})()
43const BM_W = BITMAP[0].length
44const BM_H = BITMAP.length
45
46const clamp01 = (x) => Math.max(0, Math.min(1, x))
47const easeOut = (x) => 1 - Math.pow(1 - x, 3)
48
49function lerpColor(a, b, t) {
50  const ch = (shift) => Math.round(((a >> shift) & 255) + (((b >> shift) & 255) - ((a >> shift) & 255)) * t)
51  return (ch(16) << 16) | (ch(8) << 8) | ch(0)
52}
53
54// Is output pixel (px, py) inside the lettering at this scale, centered?
55function inLetters(px, py, scale) {
56  const bx = Math.floor((px + 0.5 - PX_W / 2) / scale + BM_W / 2)
57  const by = Math.floor((py + 0.5 - PX_H / 2) / scale + BM_H / 2)
58  if (bx < 0 || by < 0 || bx >= BM_W || by >= BM_H) return false
59  return BITMAP[by][bx] === '#'
60}
61
62// The shared pixel model: one frame of the effect, independent of surface.
63// `label` and `wordColor` are the dead spinner line; `pixels` is a
64// PX_W x PX_H grid, row-major, each a 0xRRGGBB color or null (transparent).
65export function frameModel(tMs, word) {
66  const wordColor = lerpColor(CLAUDE_ORANGE, DEAD_GREY, easeOut(clamp01(tMs / GREY_END)))
67  // A Raster refuses the whole tree over one cell that isn't a width-1
68  // character, so anything but printable Latin becomes '?'
69  const printable = (cp) => (cp >= 0x20 && cp <= 0x7e) || (cp >= 0xa0 && cp <= 0x24f)
70  const safe = [...(word || 'Working')].map((ch) => (printable(ch.codePointAt(0)) ? ch : '?')).join('')
71  const label = '✻ ' + safe + '…'
72
73  // WASTED, zooming in from slightly bigger and fading up from black
74  const p = clamp01((tMs - IN_START) / (IN_END - IN_START))
75  const alpha = easeOut(p)
76  const scale = SCALE_FROM + (SCALE_TO - SCALE_FROM) * easeOut(p)
77  const red = lerpColor(0x000000, RED, alpha)
78  const shadow = lerpColor(0x000000, SHADOW, alpha)
79
80  const pixels = new Array(PX_W * PX_H).fill(null)
81  if (p > 0) {
82    for (let py = 0; py < PX_H; py++) {
83      for (let px = 0; px < PX_W; px++) {
84        if (inLetters(px, py, scale)) pixels[py * PX_W + px] = red
85        else if (inLetters(px - SHADOW_OFF, py - SHADOW_OFF, scale)) pixels[py * PX_W + px] = shadow
86      }
87    }
88  }
89  return { label, wordColor, width: PX_W, height: PX_H, pixels }
90}
91
92// Terminal: the model as a flat array of [codePoint, fg, bg] per cell,
93// row-major, two pixels per cell with ▀/▄.
94export function modelCells(model) {
95  const cells = new Array(COLUMNS * ROWS * 3)
96  const put = (col, row, ch, fg, bg) => {
97    const i = (row * COLUMNS + col) * 3
98    cells[i] = ch.codePointAt(0)
99    cells[i + 1] = fg
100    cells[i + 2] = bg
101  }
102
103  const label = [...model.label].slice(0, COLUMNS)
104  for (let c = 0; c < COLUMNS; c++) put(c, 0, label[c] ?? ' ', model.wordColor, DEFAULT)
105
106  const pixel = (x, y) => model.pixels[y * PX_W + x]
107  for (let row = 1; row < ROWS; row++) {
108    const top = (row - 1) * 2
109    for (let c = 0; c < COLUMNS; c++) {
110      const a = pixel(c, top)
111      const b = pixel(c, top + 1)
112      if (a === null && b === null) put(c, row, ' ', DEFAULT, DEFAULT)
113      else if (b === null) put(c, row, '▀', a, DEFAULT)
114      else if (a === null) put(c, row, '▄', b, DEFAULT)
115      else put(c, row, '▀', a, b)
116    }
117  }
118  return cells
119}
120
121// Pack cells into the base64 string a Raster takes: u32 little-endian triples.
122export function packCells(cells) {
123  return new Uint8Array(Uint32Array.from(cells).buffer).toBase64()
124}
125
126export const hex = (color) => '#' + color.toString(16).padStart(6, '0')
127
128// Desktop: the model's pixels as an SVG document, one <rect> per pixel,
129// grouped by color. Same grid as the terminal, square pixels.
130export const SVG_PX = 6 // CSS pixels per model pixel
131export const SVG_MAX = 131072
132
133export function modelSvg(model) {
134  const byColor = new Map()
135  model.pixels.forEach((color, i) => {
136    if (color === null) return
137    const rect = `<rect x="${i % model.width}" y="${Math.floor(i / model.width)}" width="1" height="1"/>`
138    byColor.set(color, (byColor.get(color) ?? '') + rect)
139  })
140  let groups = ''
141  for (const [color, rects] of byColor) groups += `<g fill="${hex(color)}">${rects}</g>`
142  const w = model.width * SVG_PX
143  const h = model.height * SVG_PX
144  return (
145    `<svg xmlns="http://www.w3.org/2000/svg" width="${w}" height="${h}" ` +
146    `viewBox="0 0 ${model.width} ${model.height}" shape-rendering="crispEdges">${groups}</svg>`
147  )
148}
149
150// Terminal Raster props for one frame
151export function frame(tMs, word) {
152  return { columns: COLUMNS, rows: ROWS, cells: packCells(modelCells(frameModel(tMs, word))) }
153}
