peek

1import { atom, read, update } from 'claude-code'
2import type { EngineInterface, Register } from 'claude-code'
3
4import type { Preview, Size } from '../types'
5import { fitRow, isSame, placeholders, pngSize } from './images'
6
7// Pasting an image raises no prompt.edit (the placeholder only lands with the next key),
8// so the draft is polled instead
9const POLL_MS = 200
10const EXTENSIONS = ['png', 'jpg', 'jpeg', 'gif', 'webp']
11
12const previewsAtom = atom({ plugin: 'peek', key: 'previews' } as const, [] as Preview[])
13
14// Only cached once found: the folder appears with the session's first paste
15let imagesDir: string | null = null
16let isPolling = false
17const sizes = new Map<string, Size | null>()
18
19// Claude Code writes each pasted image to <tmp>/claude-<uid>/<project-slug>/<sessionId>/images/N.<ext>,
20// keeping its original format.
21// The path is internal and may move between releases; when it does, tiles say "no preview".
22async function findImagesDir($: EngineInterface): Promise<string | null> {
23  const sessionId = await $.session.id()
24  const custom = await $.env.get('CLAUDE_CODE_TMPDIR')
25  const roots = custom
26    ? [custom]
27    : (await $.fs.list('/tmp').catch(() => []))
28        .filter(entry => entry.name.startsWith('claude-'))
29        .map(entry => `/tmp/${entry.name}`)
30
31  for (const root of roots) {
32    for (const project of await $.fs.list(root).catch(() => [])) {
33      const dir = `${root}/${project.name}/${sessionId}/images`
34
35      if (project.kind === 'dir' && (await $.fs.exists(dir))) {
36        return dir
37      }
38    }
39  }
40
41  return null
42}
43
44async function findSource($: EngineInterface, n: number): Promise<string | null> {
45  for (const extension of EXTENSIONS) {
46    const file = `${imagesDir}/${n}.${extension}`
47
48    if (await $.fs.exists(file)) {
49      return file
50    }
51  }
52
53  return null
54}
55
56// Image draws PNG only, so other formats get a PNG copy once, through macOS sips.
57// The copy stays inside Claude Code's cache, which only this user can enter.
58async function toPng($: EngineInterface, source: string, n: number): Promise<string | null> {
59  if (source.endsWith('.png')) {
60    return source
61  }
62
63  const dir = `${imagesDir}/peek`
64  const file = `${dir}/${n}.png`
65
66  if (await $.fs.exists(file)) {
67    return file
68  }
69
70  const converted = await $.process.run(['mkdir', '-p', dir])
71    .then(() => $.process.run(['sips', '-s', 'format', 'png', '-Z', '512', source, '--out', file]))
72    .catch(() => null)
73
74  return converted?.exitCode === 0 ? file : null
75}
76
77async function resolvePreview($: EngineInterface, n: number): Promise<Preview> {
78  imagesDir ??= await findImagesDir($)
79
80  const source = imagesDir ? await findSource($, n) : null
81  const file = source ? await toPng($, source, n) : null
82
83  if (!file) {
84    return { n, file: null, size: null }
85  }
86
87  if (!sizes.has(file)) {
88    // Over the 4 MiB read cap it still draws, just without its aspect ratio
89    const size = await $.fs.read(file, { as: 'bytes' }).then(({ base64 }) => pngSize(base64), () => null)
90    sizes.set(file, size)
91  }
92
93  return { n, file, size: sizes.get(file) ?? null }
94}
95
96async function poll($: EngineInterface): Promise<void> {
97  if (isPolling) {
98    return
99  }
100
101  isPolling = true
102
103  try {
104    const { text } = await $.prompt.read()
105    const known = await read($, previewsAtom)
106    const numbers = placeholders(text)
107
108    if (numbers.length === 0 && known.length === 0) {
109      return
110    }
111
112    const previews = await Promise.all(
113      numbers.map(n => known.find(preview => preview.n === n && preview.file) ?? resolvePreview($, n)),
114    )
115
116    if (!isSame(previews, known)) {
117      await update($, previewsAtom, () => previews)
118    }
119  } finally {
120    isPolling = false
121  }
122}
123
124export const register: Register = on => {
125  on('session.start', async ($, e, next) => {
126    $.clock.every(POLL_MS, () => poll($))
127
128    return next(e)
129  })
130
131  on('prompt.submit', async ($, e, next) => {
132    await update($, previewsAtom, () => [])
133
134    return next(e)
135  })
136
137  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
138    // The desktop composer already shows its own thumbnails
139    if (e.surface !== 'terminal' || e.props.hasSurvey) {
140      return next(e)
141    }
142
143    const previews = await read($, previewsAtom)
144
145    if (previews.length === 0) {
146      return next(e)
147    }
148
149    const { Box, Image, Text } = $.ui.resolve(e)
150    const cells = fitRow(previews.map(preview => preview.size), e.props.maxRows, e.props.bodyColumns)
151    const below = await next(e)
152
153    return (
154      <Box flexDirection="column">
155        <Box flexDirection="row" columnGap={1}>
156          {previews.map((preview, i) => {
157            const { columns, rows } = cells[i] ?? { columns: 6, rows: 1 }
158
159            return (
160              <Box key={`tile-${preview.n}`} flexDirection="column" alignItems="center" borderStyle="round" borderDimColor>
161                {preview.file ? (
162                  <Image
163                    key={`image-${preview.n}`}
164                    source={{ file: preview.file, format: 'png' }}
165                    columns={columns}
166                    rows={rows}
167                    alt={`[Image #${preview.n}]`}
168                  />
169                ) : (
170                  <Box width={columns} height={rows} alignItems="center" justifyContent="center">
171                    <Text dimColor wrap="truncate">no preview</Text>
172                  </Box>
173                )}
174                <Text dimColor>#{preview.n}</Text>
175              </Box>
176            )
177          })}
178        </Box>
179        {below}
180      </Box>
181    )
182  })
183}
184

1import type { Preview, Size } from '../types'
2
3export type Cells = { columns: number; rows: number }
4
5const TILE_ROWS = 8
6const MAX_COLUMNS = 40
7const MIN_COLUMNS = 6
8// A terminal cell is about twice as tall as it is wide
9const CELL_ASPECT = 2
10// A tile's border on each side plus the label row
11const CHROME_ROWS = 3
12const CHROME_COLUMNS = 2
13const GAP = 1
14const UNKNOWN: Size = { width: 16, height: 10 }
15
16// The numbers of the [Image #N] placeholders in a draft, in order, once each
17export function placeholders(text: string): number[] {
18  const numbers = [...text.matchAll(/\[Image #(\d+)\]/g)].map(match => Number(match[1]))
19
20  return [...new Set(numbers)]
21}
22
23// Width and height from the PNG header, null when the bytes are not a PNG
24export function pngSize(base64: string): Size | null {
25  // 32 base64 characters decode to the 24 bytes holding the signature and IHDR size
26  const head = Uint8Array.from(atob(base64.slice(0, 32)), char => char.charCodeAt(0))
27  const signature = [0x89, 0x50, 0x4e, 0x47, 0x0d, 0x0a, 0x1a, 0x0a]
28
29  if (head.length < 24 || signature.some((byte, i) => head[i] !== byte)) {
30    return null
31  }
32
33  const view = new DataView(head.buffer)
34  const width = view.getUint32(16)
35  const height = view.getUint32(20)
36
37  return width > 0 && height > 0 ? { width, height } : null
38}
39
40// A picture box at most `maxRows` tall that keeps the image's aspect ratio
41export function fit(size: Size | null, maxRows: number): Cells {
42  const { width, height } = size ?? UNKNOWN
43  let rows = maxRows
44  let columns = Math.round((rows * CELL_ASPECT * width) / height)
45
46  if (columns > MAX_COLUMNS) {
47    columns = MAX_COLUMNS
48    rows = Math.max(1, Math.round((MAX_COLUMNS * height) / (CELL_ASPECT * width)))
49  }
50
51  return { columns: Math.max(MIN_COLUMNS, columns), rows: Math.min(rows, maxRows) }
52}
53
54// The tallest boxes that fit one row of tiles into the band, so it never scrolls
55export function fitRow(sizes: readonly (Size | null)[], bandRows: number, bandColumns: number): Cells[] {
56  const tallest = Math.max(1, Math.min(TILE_ROWS, bandRows - CHROME_ROWS))
57
58  for (let rows = tallest; rows > 1; rows--) {
59    const cells = sizes.map(size => fit(size, rows))
60    const width = cells.reduce((sum, cell) => sum + cell.columns + CHROME_COLUMNS, 0) + GAP * (cells.length - 1)
61
62    if (width <= bandColumns) {
63      return cells
64    }
65  }
66
67  return sizes.map(size => fit(size, 1))
68}
69
70export function isSame(a: Preview[], b: Preview[]): boolean {
71  return a.length === b.length && a.every((preview, i) => preview.n === b[i]?.n && preview.file === b[i]?.file)
72}
73

1export type Size = { width: number; height: number }
2
3export type Preview = { n: number; file: string | null; size: Size | null }
4
5declare module 'claude-code' {
6  interface PluginState {
7    peek: { previews: Preview[] }
8  }
9}
10
