image-shelf

1import { atom, read, update } from 'claude-code'
2import type { EngineInterface, Register } from 'claude-code'
3
4import type { Shot } from '../types'
5
6// image-shelf: each [Image #N] in the prompt box shows on a shelf at the left above the
7// prompt. Nothing opens on paste. Pressing an image opens a copy of it in Preview, whose
8// Markup tools draw on it; once Preview saves (Cmd+S, or on close), the shelf marks it
9// edited and, at Enter, Claude is told to read the edited copy.
10//
11// Claude Code writes each paste to /private/tmp/claude-<uid>/<project>/<session>/images/
12// <N>.png; that is its internal layout, not an API. The picture itself is drawn only
13// where the terminal can (Ghostty, kitty, WezTerm, outside tmux); elsewhere the shelf
14// shows a button per image, and a floating window of our own (panel/shelf.swift, as a
15// desktop pet sits over the screen) shows the pictures over blank rows the band holds.
16
17const shots = atom({ plugin: 'image-shelf', key: 'shots' } as const, [])
18const inBox = atom({ plugin: 'image-shelf', key: 'inBox' } as const, [])
19// Rows the floating window's grid takes; the band holds that many blank rows.
20const roomRows = atom({ plugin: 'image-shelf', key: 'roomRows' } as const, 4)
21
22const PLACEHOLDER = /\[Image #(\d+)\]/g
23// A terminal cell is about twice as tall as it is wide.
24const CELL = 2
25const ROWS = 6
26
27type Setup = { edits: string; tmp: string; session: string; canDraw: boolean; tmuxPane: string; home: string }
28
29// Rows the floating window's pictures take, and what sits under the band down to the
30// pane's bottom (the buttons sit above the pictures): a spacer, the prompt between its two rules,
31// and the status lines. ~/.config/image-shelf.json may say otherwise (dx, dy in points).
32const PANEL_ROWS = 4
33type Tuning = { dx: number; dy: number; statusLines: number; spacer: number }
34const TUNING: Tuning = { dx: 0, dy: -5.5, statusLines: 1, spacer: 0 }
35
36// Module variables start over on a hot reload; everything a drawing reads is in $.state.
37let setup: Promise<Setup> | undefined
38let images: string | undefined
39let isTicking = false
40let panel: Promise<string | undefined> | undefined
41let isPanelUp = false
42let lastShelf = ''
43// What the band last drew with, so the tick can keep the floating window in step as
44// the prompt grows or shrinks between draws.
45let lastColumns = 80
46let lastMaxRows = 0
47let lastShown = false
48const capturing = new Set<number>()
49const thumbs = new Map<string, string>()
50
51const numbersIn = (text: string) => [...new Set([...text.matchAll(PLACEHOLDER)].map(m => Number(m[1])))]
52
53const isSame = (a: readonly number[], b: readonly number[]) => a.length === b.length && a.every((n, i) => n === b[i])
54
55const setUp = ($: EngineInterface) => {
56  setup ??= (async () => {
57    const session = await $.session.id()
58    const uid = (await $.process.run(['id', '-u'])).stdout.trim()
59    const edits = `/private/tmp/image-shelf/${session.slice(0, 8)}`
60    await $.process.run(['mkdir', '-p', edits])
61    const [program, term, tmux, tmuxPane, home] = await Promise.all([$.env.get('TERM_PROGRAM'), $.env.get('TERM'), $.env.get('TMUX'), $.env.get('TMUX_PANE'), $.env.get('HOME')])
62    const canDraw = !tmux && (/^(ghostty|wezterm)$/i.test(program ?? '') || /kitty|ghostty/i.test(term ?? ''))
63    return { edits, tmp: `/private/tmp/claude-${uid}`, session, canDraw, tmuxPane: tmux ? (tmuxPane ?? '') : '', home: home ?? '' }
64  })()
65  return setup
66}
67
68// <tmp>/<project>/<session>/images, whichever project folder holds this session.
69const imagesOf = async ($: EngineInterface, tmp: string, session: string) => {
70  for (const entry of await $.fs.list(tmp).catch(() => [])) {
71    if (entry.kind === 'file') continue
72    const at = `${tmp}/${entry.name}/${session}/images`
73    if (await $.fs.exists(at).catch(() => false)) return at
74  }
75  return undefined
76}
77
78// Claude Code's copy lands a moment after the placeholder does.
79const engineCopy = async ($: EngineInterface, n: number) => {
80  const { tmp, session } = await setUp($)
81  for (let attempt = 0; attempt < 120; attempt++) {
82    images ??= await imagesOf($, tmp, session)
83    if (images !== undefined) {
84      const entry = (await $.fs.list(images).catch(() => [])).find(e => new RegExp(`^${n}\\.[a-z]+$`).test(e.name))
85      if (entry !== undefined) return `${images}/${entry.name}`
86    }
87    await $.clock.sleep(50)
88  }
89  return undefined
90}
91
92// Size and a small PNG for the shelf: a screenshot can be 10 MB, the shelf needs 480 px.
93const look = async ($: EngineInterface, n: number, file: string, gen: number) => {
94  const { edits } = await setUp($)
95  const info = await $.process.run(['sips', '-g', 'pixelWidth', '-g', 'pixelHeight', file])
96  const width = Number(/pixelWidth: (\d+)/.exec(info.stdout)?.[1] ?? 0)
97  const height = Number(/pixelHeight: (\d+)/.exec(info.stdout)?.[1] ?? 0)
98  const thumb = `${edits}/${n}.thumb-${gen}.png`
99  const made = await $.process.run(['sips', '-s', 'format', 'png', '-Z', '480', file, '--out', thumb])
100  return made.exitCode === 0 && width > 0 && height > 0 ? { width, height, thumb } : undefined
101}
102
103const mtimeOf = async ($: EngineInterface, file: string) => (await $.fs.stat(file).catch(() => undefined))?.mtimeMs ?? 0
104
105// A new paste: copy it where Preview may write, so the original stays as pasted.
106const capture = async ($: EngineInterface, n: number) => {
107  const found = await engineCopy($, n)
108  if (found === undefined) return
109  const { edits } = await setUp($)
110  const copy = `${edits}/${n}.png`
111  const made = await $.process.run(['sips', '-s', 'format', 'png', found, '--out', copy])
112  if (made.exitCode !== 0) return
113  const seen = await look($, n, copy, 0)
114  const shot: Shot = { n, copy, thumb: seen?.thumb ?? '', madeAt: await mtimeOf($, copy), isEdited: false, gen: 0, width: seen?.width ?? 0, height: seen?.height ?? 0 }
115  await update($, shots, list => [...list.filter(s => s.n !== n), shot])
116}
117
118// Preview saved: the copy's mtime moved on. Remake the thumbnail and mark it edited.
119const watchEdits = async ($: EngineInterface) => {
120  for (const shot of await read($, shots)) {
121    if (shot.copy === '') continue
122    const at = await mtimeOf($, shot.copy)
123    const last = shot.madeAt
124    if (at === 0 || at === last) continue
125    const gen = shot.gen + 1
126    const seen = await look($, shot.n, shot.copy, gen).catch(() => undefined)
127    await update($, shots, list => list.map(s => (s.n === shot.n ? { ...s, madeAt: at, isEdited: true, gen, thumb: seen?.thumb ?? s.thumb, width: seen?.width ?? s.width, height: seen?.height ?? s.height } : s)))
128  }
129}
130
131// Numbers run up through a session, so only an unknown N is a new paste.
132const sync = async ($: EngineInterface, text: string) => {
133  await setUp($)
134  const ns = numbersIn(text)
135  if (!isSame(ns, await read($, inBox))) await update($, inBox, () => ns)
136  const known = await read($, shots)
137  for (const n of ns) {
138    if (capturing.has(n) || known.some(s => s.n === n)) continue
139    capturing.add(n)
140    void capture($, n).finally(() => capturing.delete(n))
141  }
142}
143
144const tick = async ($: EngineInterface) => {
145  if (isTicking) return
146  isTicking = true
147  try {
148    await sync($, (await $.prompt.read()).text)
149    await watchEdits($)
150    const { canDraw } = await setUp($)
151    if (!canDraw) {
152      const ns = await read($, inBox)
153      // In the prompt's order, as the band writes it: shots is in the order copies finished.
154      const all = await read($, shots)
155      await writeShelf($, ns.flatMap(n => all.filter(s => s.n === n)), lastShown && ns.length > 0, lastColumns)
156      const { edits } = await setUp($)
157      const told = Number(/"rows":(\d+)/.exec(await $.fs.read(`${edits}/layout.json`).catch(() => ''))?.[1] ?? PANEL_ROWS)
158      if (told !== (await read($, roomRows))) await update($, roomRows, () => told)
159    }
160  } finally {
161    isTicking = false
162  }
163}
164
165const open = async ($: EngineInterface, n: number) => {
166  const shot = (await read($, shots)).find(s => s.n === n)
167  if (shot === undefined || shot.copy === '') {
168    $.ui.toast(`Image #${n} 還在準備，等一下再點`)
169    return
170  }
171  // The editor writes the edit over the copy; its new mtime marks it edited.
172  const binary = await buildEditor($)
173  if (binary === undefined) {
174    await $.process.run(['open', '-a', 'Preview', shot.copy])
175    return
176  }
177  await $.process.run([binary, `${$.plugin.root}/editor/editor.html`, shot.copy, shot.copy, `Image #${n}`, 'zh-Hant'], { timeoutMs: 3_600_000 }).catch(() => undefined)
178}
179
180const pictureOf = async ($: EngineInterface, shot: Shot) => {
181  const held = thumbs.get(shot.thumb)
182  if (held !== undefined) return held
183  const { base64 } = await $.fs.read(shot.thumb, { as: 'bytes' })
184  thumbs.set(shot.thumb, base64)
185  return base64
186}
187
188// A Swift program of the mod's, compiled once per version of its source and named by it.
189const build = async ($: EngineInterface, source: string, name: string) => {
190  const text = await $.fs.read(source)
191  const digest = [...new Uint8Array(await crypto.subtle.digest('SHA-256', new TextEncoder().encode(text)))].slice(0, 6).map(b => b.toString(16).padStart(2, '0')).join('')
192  const binary = `/private/tmp/image-shelf/bin/${name}-${digest}`
193  if (await $.fs.exists(binary).catch(() => false)) return binary
194  await $.process.run(['mkdir', '-p', '/private/tmp/image-shelf/bin'])
195  const part = `${binary}.${crypto.randomUUID().slice(0, 8)}`
196  const made = await $.process.run(['xcrun', 'swiftc', '-O', source, '-o', part], { timeoutMs: 180_000 }).catch(() => undefined)
197  if (made?.exitCode !== 0) return undefined
198  return (await $.process.run(['mv', '-f', part, binary])).exitCode === 0 ? binary : undefined
199}
200
201// The floating window, and the markup editor (editor/, from paste-preview, MIT).
202const buildPanel = ($: EngineInterface) => build($, `${$.plugin.root}/panel/shelf.swift`, 'shelf')
203let editor: Promise<string | undefined> | undefined
204const buildEditor = ($: EngineInterface) => {
205  editor ??= build($, `${$.plugin.root}/editor/editor.swift`, 'editor').catch(() => undefined)
206  return editor
207}
208
209const tuningOf = async ($: EngineInterface, home: string): Promise<Tuning> => {
210  const text = await $.fs.read(`${home}/.config/image-shelf.json`).catch(() => '')
211  try {
212    return { ...TUNING, ...(text === '' ? {} : JSON.parse(text)) }
213  } catch {
214    return TUNING
215  }
216}
217
218// Started the first time there is something to show; it quits with Claude Code.
219const startPanel = ($: EngineInterface, shelfFile: string) => {
220  panel ??= (async () => {
221    const binary = await buildPanel($)
222    if (binary === undefined) {
223      $.ui.toast('image-shelf：浮動視窗編譯失敗（需要 Xcode Command Line Tools）')
224      return undefined
225    }
226    isPanelUp = true
227    void (async () => {
228      try {
229        for await (const _ of $.process.spawn({ argv: [binary, shelfFile] })) { /* it says nothing */ }
230      } catch {}
231      isPanelUp = false
232      panel = undefined
233    })()
234    return binary
235  })().catch(() => undefined)
236  return panel
237}
238
239// Display width in cells: CJK and emoji take two.
240const widthOf = (text: string) => [...text].reduce((sum, ch) => sum + ((ch.codePointAt(0) ?? 0) >= 0x1100 ? 2 : 1), 0)
241
242const promptRows = (text: string, columns: number) => text.split('\n').reduce((sum, line) => sum + Math.max(1, Math.ceil((widthOf(line) + 2) / Math.max(10, columns))), 0)
243
244// What the floating window reads: the pictures, and where the band's blank rows are.
245const writeShelf = async ($: EngineInterface, list: Shot[], isVisible: boolean, columns: number) => {
246  const { edits, tmuxPane, home } = await setUp($)
247  const tuning = await tuningOf($, home)
248  const text = isVisible ? (await $.prompt.read().catch(() => ({ text: '' }))).text : ''
249  const rowsBelow = tuning.spacer + 2 + promptRows(text, columns) + tuning.statusLines
250  const items = list.filter(s => s.thumb !== '').map(s => ({ n: s.n, thumb: s.thumb, copy: s.copy, edited: s.isEdited }))
251  const editorBinary = items.length > 0 ? ((await buildEditor($)) ?? '') : ''
252  const shelf = JSON.stringify({ visible: isVisible && items.length > 0, items, rows: PANEL_ROWS, rowsBelow, editor: editorBinary, page: `${$.plugin.root}/editor/editor.html`, tmuxPane, maxRows: lastMaxRows, dx: tuning.dx, dy: tuning.dy })
253  const file = `${edits}/shelf.json`
254  if (shelf !== lastShelf) {
255    lastShelf = shelf
256    await $.fs.write(file, shelf)
257  }
258  // Started again if it quit (or was stopped) while there are pictures to show.
259  if (items.length > 0 && !isPanelUp) void startPanel($, file)
260}
261
262// Same height for all, `rows` tall, as wide as the picture's shape asks.
263const columnsOf = (shot: Shot, rows: number) => Math.max(4, Math.min(48, Math.round((rows * CELL * shot.width) / shot.height)))
264
265export const register: Register = on => {
266  on('session.start', async ($, e, next) => {
267    // A reload (or a new version of the mod) brings a fresh panel: the one an earlier load
268    // started for this session goes, so an edited panel/shelf.swift takes effect.
269    void setUp($).then(({ edits }) => $.process.run(['pkill', '-f', `image-shelf/bin/shelf-[0-9a-f]+ ${edits}/shelf.json`])).catch(() => undefined)
270    $.clock.every(700, () => void tick($).catch(() => undefined))
271    return next(e)
272  })
273
274  on('prompt.edit', async ($, e, next) => {
275    const box = await next(e)
276    await sync($, box.text).catch(() => undefined)
277    return box
278  })
279
280  // At Enter: Claude is pointed at each edited copy. The original paste still goes along;
281  // the note says which one to trust.
282  on('prompt.submit', async ($, e, next) => {
283    await watchEdits($).catch(() => undefined)
284    const ns = numbersIn(e.text)
285    const edited = (await read($, shots).catch(() => [] as Shot[])).filter(s => s.isEdited && ns.includes(s.n))
286    if (edited.length === 0) return next(e)
287    const notes = edited.map(s => `The person edited [Image #${s.n}] in Preview before sending (drew on, cropped or annotated it). The attached original is the unedited paste; the edited picture is ${s.copy}. Read that file and work from the edited version.`)
288    return next({ ...e, context: [...(e.context ?? []), ...notes] })
289  })
290
291  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
292    const { canDraw } = await setUp($)
293    const ns = await read($, inBox)
294    const all = await read($, shots)
295    const isShown = e.surface === 'terminal' && !e.props.hasSurvey && ns.length > 0
296    lastColumns = e.props.bodyColumns
297    lastMaxRows = e.props.maxRows
298    lastShown = isShown
299    if (!canDraw) void writeShelf($, ns.flatMap(n => all.filter(s => s.n === n)), isShown, e.props.bodyColumns).catch(() => undefined)
300    if (e.surface !== 'terminal' || e.props.hasSurvey || ns.length === 0) return next(e)
301    const { Box, Text, Button, Image } = $.ui.resolve(e)
302    const rows = Math.max(3, Math.min(ROWS, e.props.maxRows - 2))
303
304    // Where the terminal cannot draw, blank rows for the floating window to cover.
305    const room = !canDraw && all.some(s => ns.includes(s.n) && s.thumb !== '')
306      ? <Box key="room" height={Math.max(1, Math.min(PANEL_ROWS, e.props.maxRows))} />
307      : null
308
309    // Here the floating window shows the pictures and takes the clicks: only its room.
310    if (!canDraw) return room === null ? next(e) : <Box flexDirection="column">{room}</Box>
311
312    return (
313      <Box flexDirection="column">
314      <Box flexDirection="row" flexWrap="wrap" columnGap={2} justifyContent="flex-start">
315        {await Promise.all(ns.map(async (n, i) => {
316          const shot = all.find(s => s.n === n)
317          const label = `#${n}${shot?.isEdited ? ' 已編輯' : ''}`
318          const hotkey = i < 9 ? { hotkey: String(i + 1) } : {}
319          const png = canDraw && shot !== undefined && shot.thumb !== '' ? await pictureOf($, shot).catch(() => undefined) : undefined
320          return (
321            <Box key={`shot-${n}`} flexDirection="column">
322              {png !== undefined && shot !== undefined && (
323                <Image key={`img-${n}`} source={{ png }} columns={columnsOf(shot, rows)} rows={rows} alt={`#${n}`} />
324              )}
325              {shot === undefined
326                ? <Text key={`wait-${n}`} dimColor>#{n} …</Text>
327                : <Button key={`open-${n}`} label={`🖼 ${label}`} plain {...hotkey} onPress={() => void open($, n)} />}
328            </Box>
329          )
330        }))}
331      </Box>
332      {room}
333      </Box>
334    )
335  })
336}
337

1// One pasted image: the N of its [Image #N], the editable copy Preview opens, and the
2// small PNG the band draws where the terminal can draw pictures.
3export type Shot = {
4  n: number
5  // The copy in our own folder; '' until Claude Code's copy of the paste is found.
6  copy: string
7  thumb: string
8  // The copy's mtime when it was made; a later one means Preview saved an edit.
9  madeAt: number
10  isEdited: boolean
11  // Bumped each time the picture changes, so the thumbnail is read again.
12  gen: number
13  width: number
14  height: number
15}
16
17declare module 'claude-code' {
18  interface PluginState {
19    'image-shelf': { shots: Shot[]; inBox: number[]; roomRows: number }
20  }
21}
22
