1import { atom, read, update } from 'claude-code'
2import type { EngineInterface, Register, Timer } from 'claude-code'
3
4import type { AgentCard, AgentTally, Check, Gate, Layout, LogLine, Loop, Main, Turn, Usage, View } from '../types'
5import {
6  LOG_WHO_MAX,
7  DEFAULT_ABORTS,
8  DEFAULT_AGENTS,
9  DEFAULT_CACHE,
10  DEFAULT_CONTEXT,
11  DEFAULT_GATE,
12  DEFAULT_MAIN,
13  DEFAULT_OPTIONS,
14  DEFAULT_PROMPT,
15  DEFAULT_TESTS,
16  DEFAULT_TURN,
17  DEFAULT_USAGE,
18  DEFAULT_VIEW,
19  EDIT_TOOLS,
20  SAMPLE_MS,
21  SCHEMA_VERSION,
22  admitCards,
23  afterCall,
24  applyStep,
25  bucketOf,
26  cardTitle,
27  describeInput,
28  fmtDuration,
29  gateSummary,
30  gauge,
31  gridOrder,
32  isSampling,
33  listOf,
34  normalize,
35  normalizeCard,
36  normalizeDeck,
37  normalizeGate,
38  normalizeLog,
39  noteTool,
40  PALETTES,
41  parseConfig,
42  promptLine,
43  receiptOf,
44  redact,
45  recordCheck,
46  reduceDeck,
47  settleCheck,
48  shorten,
49  stepLoop,
50  tallyByType,
51  totals,
52} from './core'
53import type { Config, Deck, DeckEvent, DeckOptions } from './core'
54import { draw } from './draw'
55
56const PANE = 'sessiondeck'
57const TITLE = 'Sessiondeck'
58const PANE_COLUMNS = 66
59
60
61// ---------------------------------------------------------------- state
62
63const meta = atom({ plugin: 'sessiondeck', key: 'meta' } as const, { schemaVersion: SCHEMA_VERSION })
64const main = atom({ plugin: 'sessiondeck', key: 'main' } as const, DEFAULT_MAIN)
65const usage = atom({ plugin: 'sessiondeck', key: 'usage' } as const, DEFAULT_USAGE)
66const gate = atom({ plugin: 'sessiondeck', key: 'gate' } as const, DEFAULT_GATE)
67const agents = atom({ plugin: 'sessiondeck', key: 'agents' } as const, [])
68const loops = atom({ plugin: 'sessiondeck', key: 'loops' } as const, [])
69const log = atom({ plugin: 'sessiondeck', key: 'log' } as const, [])
70const turn = atom({ plugin: 'sessiondeck', key: 'turn' } as const, DEFAULT_TURN)
71const receipt = atom({ plugin: 'sessiondeck', key: 'receipt' } as const, null)
72const view = atom({ plugin: 'sessiondeck', key: 'view' } as const, DEFAULT_VIEW)
73const prompt = atom({ plugin: 'sessiondeck', key: 'prompt' } as const, DEFAULT_PROMPT)
74const cache = atom({ plugin: 'sessiondeck', key: 'cache' } as const, DEFAULT_CACHE)
75const tools = atom({ plugin: 'sessiondeck', key: 'tools' } as const, {})
76const hotFiles = atom({ plugin: 'sessiondeck', key: 'hotFiles' } as const, {})
77const tests = atom({ plugin: 'sessiondeck', key: 'tests' } as const, DEFAULT_TESTS)
78const aborts = atom({ plugin: 'sessiondeck', key: 'aborts' } as const, DEFAULT_ABORTS)
79const agentStats = atom({ plugin: 'sessiondeck', key: 'agentStats' } as const, DEFAULT_AGENTS)
80const context = atom({ plugin: 'sessiondeck', key: 'context' } as const, DEFAULT_CONTEXT)
81
82// Every read goes through these, so a value saved under an older shape still reads.
83async function getMain($: EngineInterface): Promise<Main> {
84  return normalize(DEFAULT_MAIN, await read($, main))
85}
86async function getUsage($: EngineInterface): Promise<Usage> {
87  return normalize(DEFAULT_USAGE, await read($, usage))
88}
89async function getGate($: EngineInterface): Promise<Gate> {
90  return normalizeGate(await read($, gate))
91}
92async function getCards($: EngineInterface): Promise<AgentCard[]> {
93  return listOf<unknown>(await read($, agents)).map(normalizeCard)
94}
95async function getLoops($: EngineInterface): Promise<Loop[]> {
96  return listOf<Loop>(await read($, loops))
97}
98async function getLog($: EngineInterface): Promise<LogLine[]> {
99  return normalizeLog(await read($, log))
100}
101async function getTurn($: EngineInterface): Promise<Turn> {
102  return normalize(DEFAULT_TURN, await read($, turn))
103}
104async function getView($: EngineInterface): Promise<View> {
105  return normalize(DEFAULT_VIEW, await read($, view))
106}
107async function getDeck($: EngineInterface): Promise<Deck> {
108  const [p, c, t, h, ts, a, ag, cx] = await Promise.all([
109    read($, prompt),
110    read($, cache),
111    read($, tools),
112    read($, hotFiles),
113    read($, tests),
114    read($, aborts),
115    read($, agentStats),
116    read($, context),
117  ])
118  return normalizeDeck({ prompt: p, cache: c, tools: t, hotFiles: h, tests: ts, aborts: a, agents: ag, context: cx })
119}
120
121// One log line per load says the deck stopped updating; repeating it every call would flood the log.
122let reported = false
123
124/** A deck slice's failure stays in the deck: the call that fed it still resolves. */
125async function safely($: EngineInterface, work: () => Promise<unknown>): Promise<void> {
126  try {
127    await work()
128  } catch (err) {
129    if (reported) return
130    reported = true
131    try {
132      await say($, 'sessiondeck', `deck update failed: ${String(err).slice(0, 80)}`, 'error')
133    } catch {}
134  }
135}
136
137// Each write is computed from a whole-deck read, so two calls settling together would
138// otherwise each write from the same read and one would be lost.
139let queue: Promise<unknown> = Promise.resolve()
140function serial<T>(work: () => Promise<T>): Promise<T> {
141  const run = queue.then(work)
142  queue = run.catch(() => undefined)
143  return run
144}
145
146function apply($: EngineInterface, e: DeckEvent, opts: DeckOptions = DEFAULT_OPTIONS): Promise<void> {
147  return serial(async () => {
148    const d = await getDeck($)
149    const n = reduceDeck(d, e, opts)
150    if (n.prompt !== d.prompt) await update($, prompt, () => n.prompt)
151    if (n.cache !== d.cache) await update($, cache, () => n.cache)
152    if (n.tools !== d.tools) await update($, tools, () => n.tools)
153    if (n.hotFiles !== d.hotFiles) await update($, hotFiles, () => n.hotFiles)
154    if (n.tests !== d.tests) await update($, tests, () => n.tests)
155    if (n.aborts !== d.aborts) await update($, aborts, () => n.aborts)
156    if (n.agents !== d.agents) await update($, agentStats, () => n.agents)
157    if (n.context !== d.context) await update($, context, () => n.context)
158  })
159}
160
161async function admit($: EngineInterface, cap: number) {
162  await serial(async () => {
163    const [cards, d] = await Promise.all([getCards($), getDeck($)])
164    if (admitCards(cards, d.agents.byType, cap).cards === cards) return
165    // Card writes outside serial (spawn, step, status) can land mid-update; update re-runs
166    // this on the fresh list, so the last run's folded matches the list it wrote.
167    let folded: Record<string, AgentTally> | null = null
168    await update($, agents, list => {
169      const fresh = listOf<unknown>(list).map(normalizeCard)
170      const kept = admitCards(fresh, d.agents.byType, cap)
171      folded = kept.cards === fresh ? null : kept.folded
172      return kept.cards
173    })
174    const byType = folded
175    if (byType) await update($, agentStats, () => ({ ...d.agents, byType }))
176  })
177}
178
179let sampler: Timer | null = null
180
181async function ensureSampler($: EngineInterface) {
182  if (sampler) return
183  const [d, cards] = await Promise.all([getDeck($), getCards($)])
184  if (sampler || !isSampling(d.prompt, cards)) return
185  sampler = $.clock.every(SAMPLE_MS, () => void safely($, () => tick($)))
186}
187
188async function tick($: EngineInterface) {
189  const [d, cards] = await Promise.all([getDeck($), getCards($)])
190  if (!isSampling(d.prompt, cards)) {
191    sampler?.cancel()
192    sampler = null
193    return
194  }
195  const { spawning: _, ...counts } = totals(tallyByType(cards, d.agents.byType))
196  await apply($, { kind: 'tick', at: await $.clock.now(), counts })
197}
198
199/** A stored shape older than this build's: drop what cannot be read, keep the rest. */
200async function migrate($: EngineInterface) {
201  const m = await read($, meta)
202  if ((m?.schemaVersion ?? 0) >= SCHEMA_VERSION) return
203  await update($, log, list => normalizeLog(list))
204  await update($, agents, list => listOf<unknown>(list).map(normalizeCard))
205  await update($, gate, g => normalizeGate(g))
206  await update($, meta, () => ({ schemaVersion: SCHEMA_VERSION }))
207}
208
209async function say($: EngineInterface, who: string, text: string, kind: LogLine['kind'] = 'info', agentId: string | null = null) {
210  const line: LogLine = { at: await $.clock.now(), who, text, kind, agentId }
211  await update($, log, list => [...normalizeLog(list), line].slice(-60))
212}
213
214/** Every agent this session, the cards the cap folded into agentStats included. */
215async function agentCounts($: EngineInterface): Promise<{ live: number; total: number }> {
216  const [cards, d] = await Promise.all([getCards($), getDeck($)])
217  const t = totals(tallyByType(cards, d.agents.byType))
218  return { live: t.spawning + t.running, total: t.spawning + t.running + t.done + t.error }
219}
220
221async function refreshStatus($: EngineInterface, cfg: Config) {
222  if (!cfg.statusLine) return $.ui.status(undefined)
223  const [u, g, a] = await Promise.all([getUsage($), getGate($), agentCounts($)])
224  const s = gateSummary(g)
225  const parts = [
226    u.pct !== null ? `ctx ${Math.round(u.pct)}%` : null,
227    a.total > 0 ? `agents ${a.live}/${a.total}` : null,
228    s.deny > 0 ? `denied ${s.deny}` : null,
229  ]
230  // Only fields with something to say; with none, no status entry at all.
231  const shown = parts.filter(Boolean)
232  $.ui.status(shown.length > 0 ? shown.join(' · ') : undefined)
233}
234
235async function whoIs($: EngineInterface, agentId: string | undefined) {
236  if (!agentId) return 'main'
237  const card = (await getCards($)).find(c => c.id === agentId)
238  return card ? shorten(cardTitle(card), LOG_WHO_MAX) : 'agent'
239}
240
241async function openPane($: EngineInterface) {
242  // columns apply when docked beside the transcript, rows when seated inline above the prompt.
243  return $.ui.open({ id: PANE, title: TITLE, columns: PANE_COLUMNS, rows: 8 })
244}
245
246async function resetAll($: EngineInterface) {
247  // Serial with apply: a deck write in flight would otherwise land after the reset.
248  await serial(async () => {
249    await update($, main, m => ({ ...DEFAULT_MAIN, model: normalize(DEFAULT_MAIN, m).model, mode: normalize(DEFAULT_MAIN, m).mode }))
250    await update($, gate, () => DEFAULT_GATE)
251    await update($, agents, () => [])
252    await update($, loops, () => [])
253    await update($, log, () => [])
254    await update($, turn, () => DEFAULT_TURN)
255    await update($, receipt, () => null)
256    await update($, view, () => DEFAULT_VIEW)
257    await update($, prompt, () => DEFAULT_PROMPT)
258    await update($, cache, () => DEFAULT_CACHE)
259    await update($, tools, () => ({}))
260    await update($, hotFiles, () => ({}))
261    await update($, tests, () => DEFAULT_TESTS)
262    await update($, aborts, () => DEFAULT_ABORTS)
263    await update($, agentStats, () => DEFAULT_AGENTS)
264    await update($, context, () => DEFAULT_CONTEXT)
265    // The context gauge waits for the next measurement rather than showing the pre-clear fill.
266    await update($, usage, x => ({ ...normalize(DEFAULT_USAGE, x), pct: null, tokens: null }))
267  })
268}
269
270/** The session's cost read fresh, not from the last measurement: the receipt subtracts two of these. */
271async function costNow($: EngineInterface): Promise<number | null> {
272  const u = await $.session.usage().catch(() => null)
273  return u?.cost?.usd ?? null
274}
275
276async function noteMode($: EngineInterface, mode: string | undefined) {
277  if (mode) await update($, main, m => (normalize(DEFAULT_MAIN, m).mode === mode ? normalize(DEFAULT_MAIN, m) : { ...normalize(DEFAULT_MAIN, m), mode }))
278}
279
280// ---------------------------------------------------------------- hooks
281
282export const register: Register = (on, options) => {
283  const cfg = parseConfig(options)
284  const C = PALETTES[cfg.palette]
285  const deckOptions: DeckOptions = { testPattern: cfg.testPattern }
286  // tool.check carries no loop id; the tool.call around it does, keyed by the call's id.
287  const callLoop = new Map<string, string | null>()
288
289  on('session.start', async ($, e, next) => {
290    await $.command.register({
291      name: 'sessiondeck',
292      description: 'Sessiondeck, the live agent dashboard: open, close, reset, or set the layout',
293      argumentHint: '[open|close|reset|layout auto|compact|wide|mini]',
294    })
295    await migrate($)
296    if (cfg.isTestPatternFallback) await say($, 'sessiondeck', 'testPattern did not compile; using the default', 'error')
297    // A host without usage (headless, an SDK host, a session not yet bound) just starts without it.
298    const u = await $.session.usage().catch(() => null)
299    if (u) {
300      await update($, usage, x => ({
301        ...normalize(DEFAULT_USAGE, x),
302        pct: u.context.percent ?? null,
303        tokens: u.context.tokens ?? null,
304        window: u.context.window,
305        costUsd: u.cost?.usd ?? null,
306        limits: u.rateLimits.map(r => ({ kind: r.kind, pct: r.percentUsed })),
307      }))
308    }
309    if (cfg.openOnStart) void openPane($).catch(() => undefined)
310    await refreshStatus($, cfg)
311    return next(e)
312  })
313
314  on('session.end', async ($, e, next) => {
315    if (e.reason === 'clear') {
316      await resetAll($)
317      await refreshStatus($, cfg)
318    }
319    return next(e)
320  })
321
322  on('command.run', { command: 'sessiondeck' }, async ($, e) => {
323    const [verb = 'open', arg = ''] = e.args.trim().split(/\s+/)
324    if (verb === 'close') {
325      await $.ui.close({ id: PANE })
326      return { text: 'Sessiondeck closed.' }
327    }
328    if (verb === 'reset') {
329      await resetAll($)
330      await refreshStatus($, cfg)
331      return { text: 'Sessiondeck reset.' }
332    }
333    if (verb === 'layout') {
334      const layout: Layout | null = arg === 'compact' || arg === 'wide' || arg === 'auto' || arg === 'mini' ? arg : null
335      if (!layout) return { text: 'Usage: /sessiondeck layout auto|compact|wide|mini' }
336      await update($, view, v => ({ ...normalize(DEFAULT_VIEW, v), layout }))
337      const opened = await openPane($)
338      return { text: opened.isPlaced ? `Sessiondeck layout: ${layout}.` : `Layout set to ${layout}; the pane is not shown yet: ${opened.reason}` }
339    }
340    const opened = await openPane($)
341    if (!opened.isPlaced) return { text: `Sessiondeck is not shown yet: ${opened.reason}` }
342    return { text: 'Sessiondeck opened. Focus it with ctrl+x tab; 1-9 select agents, n/b walk past nine, x clears; f/s/o open the gate rows.' }
343  })
344
345  on('classic.UserPromptSubmit', async ($, e, next) => {
346    await noteMode($, e.permission_mode)
347    const r = await next(e)
348    await safely($, () => apply($, { kind: 'prompt', text: e.prompt }, deckOptions))
349    return r
350  })
351
352  on('turn.start', async ($, e, next) => {
353    const [now, cost, a] = await Promise.all([$.clock.now(), costNow($), agentCounts($)])
354    await update($, turn, () => ({ ...DEFAULT_TURN, startedAt: now, costAtStart: cost, agentsAtStart: a.total }))
355    await update($, main, m => ({ ...normalize(DEFAULT_MAIN, m), isRunning: true }))
356    if (e.text) {
357      const p = promptLine(redact(e.text))
358      await say($, p.who, p.text)
359    }
360    const r = await next(e)
361    await safely($, async () => {
362      await apply($, { kind: 'turn.start', at: now, turnId: e.turnId, text: e.text }, deckOptions)
363      await ensureSampler($)
364    })
365    return r
366  })
367
368  on('turn.step', async function* ($, e, next) {
369    // The main loop's model is known when its request starts; a long first request shouldn't read "—".
370    if (!e.agentId) {
371      await update($, main, m => {
372        const x = normalize(DEFAULT_MAIN, m)
373        return { ...x, model: e.model, effort: String(e.effort ?? x.effort), steps: x.steps + 1 }
374      })
375      const result = yield* next(e)
376      await safely($, () => apply($, { kind: 'step', agentId: null, usage: result.usage }, deckOptions))
377      return result
378    }
379    const result = yield* next(e)
380    const id = e.agentId
381    const cards = await getCards($)
382    if (cards.some(c => c.id === id)) {
383      const step = { model: e.model, usage: result.usage, stopReason: result.stopReason }
384      await update($, agents, list => listOf<unknown>(list).map(normalizeCard).map(c => (c.id === id ? applyStep(c, step) : c)))
385      if (result.stopReason === 'max_tokens') await say($, await whoIs($, id), 'hit max_tokens', 'error', id)
386    } else {
387      const now = await $.clock.now()
388      await update($, loops, l => stepLoop(listOf<Loop>(l), id, now))
389    }
390    return result
391  })
392
393  on('session.measure', async ($, e, next) => {
394    await update($, usage, x => ({
395      ...normalize(DEFAULT_USAGE, x),
396      pct: e.context.percent ?? null,
397      tokens: e.context.tokens ?? null,
398      window: e.context.window,
399      costUsd: e.cost?.usd ?? null,
400      limits: e.rateLimits.map(r => ({ kind: r.kind, pct: r.percentUsed })),
401    }))
402    if (e.changed.includes('context')) await refreshStatus($, cfg)
403    const r = await next(e)
404    await safely($, async () => apply($, { kind: 'measure', percent: e.context.percent ?? null, at: await $.clock.now() }, deckOptions))
405    return r
406  })
407
408  on('session.compact', async ($, e, next) => {
409    const done = await next(e)
410    if (!e.agentId && e.trigger !== 'precompute') {
411      const now = await $.clock.now()
412      await update($, usage, x => {
413        const u = normalize(DEFAULT_USAGE, x)
414        return { ...u, compactions: u.compactions + 1, lastCompactAt: now }
415      })
416      await say($, 'main', `context compacted (${e.trigger})`)
417      await safely($, () => apply($, { kind: 'compact', at: now }, deckOptions))
418    }
419    return done
420  })
421
422  on('tool.check', async ($, e, next) => {
423    const verdict = await next(e)
424    if (e.tool_use_id) {
425      const check: Check = {
426        id: e.tool_use_id,
427        tool: e.tool,
428        bucket: bucketOf(e.tool),
429        verdict: verdict.decision === 'allow' ? 'rule' : verdict.decision,
430        inSubagent: Boolean(callLoop.get(e.tool_use_id)),
431        detail: shorten(describeInput(e.tool, e.input), 90),
432        at: await $.clock.now(),
433      }
434      await update($, gate, g => recordCheck(normalizeGate(g), check))
435      // The status line updates when the call settles; only a refusal ends here.
436      if (verdict.decision === 'deny') {
437        await say($, 'gate', `denied by rule · ${check.detail}`, 'error')
438        await refreshStatus($, cfg)
439      }
440    }
441    return verdict
442  })
443
444  on('tool.call', async ($, e, next) => {
445    callLoop.set(e.tool_use_id, e.agentId ?? null)
446    const calledAt = await $.clock.now()
447    const ran = await next(e).finally(() => callLoop.delete(e.tool_use_id))
448    const didRun = ran.deny === undefined
449    // Settle this call's pending ask, if it had one; skip the write (and the redraw) otherwise.
450    const g0 = await getGate($)
451    const isSettled = settleCheck(g0, e.tool_use_id, didRun) !== g0
452    if (isSettled) await update($, gate, g => settleCheck(normalizeGate(g), e.tool_use_id, didRun))
453    await safely($, async () => {
454      const settledAt = await $.clock.now()
455      await apply($, {
456        kind: 'tool',
457        tool: e.tool,
458        agentId: e.agentId ?? null,
459        outcome: !didRun ? 'denied' : ran.isError ? 'error' : 'ok',
460        // A call that waited on an ask measures the human, not the tool.
461        ms: isSettled ? null : settledAt - calledAt,
462        filePath: e.tool === 'Edit' || e.tool === 'Write' ? e.file_path : e.tool === 'NotebookEdit' ? e.notebook_path : null,
463        command: e.tool === 'Bash' ? e.command : null,
464        at: settledAt,
465      }, deckOptions)
466    })
467    if (e.tool === 'Agent') {
468      if (isSettled) await refreshStatus($, cfg)
469      return ran
470    }
471    const hasFailed = didRun && ran.isError === true
472    const isEdit = !hasFailed && didRun && EDIT_TOOLS.has(e.tool)
473    const t0 = await getTurn($)
474    if (isEdit || hasFailed || (!e.agentId && t0.errorStreak > 0)) {
475      await update($, turn, t => afterCall(normalize(DEFAULT_TURN, t), { inSubagent: Boolean(e.agentId), hasFailed, isEdit }))
476    }
477    const text = shorten(describeInput(e.tool, e), 64)
478    if (e.agentId) {
479      const id = e.agentId
480      await update($, agents, list =>
481        listOf<unknown>(list)
482          .map(normalizeCard)
483          .map(c => (c.id === id ? noteTool(c, { tool: e.tool, text, isError: hasFailed || ran.deny !== undefined }) : c)),
484      )
485    }
486    // The log keeps what is worth a glance: refusals, errors and edits; the rest is on the cards.
487    if (ran.deny !== undefined) await say($, await whoIs($, e.agentId), `${text}  denied`, 'error', e.agentId ?? null)
488    else if (hasFailed) await say($, await whoIs($, e.agentId), `${text}  ✗`, 'error', e.agentId ?? null)
489    else if (isEdit) await say($, await whoIs($, e.agentId), text, 'info', e.agentId ?? null)
490    if (isSettled || !didRun) await refreshStatus($, cfg)
491    return ran
492  })
493
494  on('agent.spawn', async ($, e, next) => {
495    const started = await next(e)
496    if (!e.parentAgentId) await noteMode($, e.permissionMode)
497    if (started.deny !== undefined || !started.agentId) return started
498    const id = started.agentId
499    const card: AgentCard = {
500      ...normalizeCard({}),
501      id,
502      type: e.name ?? e.subagentType,
503      model: started.model,
504      description: e.description,
505      spawnedAt: await $.clock.now(),
506      parentAgentId: e.parentAgentId ?? null,
507    }
508    await update($, agents, list => [...listOf<unknown>(list).map(normalizeCard), card])
509    await safely($, async () => {
510      await admit($, cfg.maxCards)
511      await ensureSampler($)
512    })
513    await update($, loops, l => listOf<Loop>(l).filter(x => x.id !== id))
514    await say($, shorten(cardTitle(card), LOG_WHO_MAX), `spawned · ${card.type}`, 'info', id)
515    await refreshStatus($, cfg)
516    return started
517  })
518
519  on('turn.complete', async ($, e, next) => {
520    const done = await next(e)
521    const id = e.agentId
522    const now = await $.clock.now()
523    await safely($, () => apply($, { kind: 'turn.complete', agentId: id ?? null, turnId: e.turnId, isAborted: e.isAborted, at: now }, deckOptions))
524    if (!id) {
525      const [t, a, cost] = await Promise.all([getTurn($), agentCounts($), costNow($)])
526      const r = receiptOf(t, {
527        durationMs: e.durationMs,
528        agentsSince: a.total - t.agentsAtStart,
529        costNow: cost,
530        reason: e.reason,
531      })
532      await update($, receipt, () => r)
533      await update($, main, m => ({ ...normalize(DEFAULT_MAIN, m), isRunning: false }))
534      await refreshStatus($, cfg)
535      return done
536    }
537    const cards = await getCards($)
538    if (cards.some(c => c.id === id)) {
539      const status = e.reason === 'answer' ? 'done' : e.reason === 'aborted' ? 'stopped' : 'failed'
540      await update($, agents, list =>
541        listOf<unknown>(list)
542          .map(normalizeCard)
543          .map(c => (c.id === id ? { ...c, status, endedAt: now, answer: shorten(e.answer, 400) } : c)),
544      )
545      const card = cards.find(c => c.id === id)
546      const took = card ? fmtDuration(now - card.spawnedAt) : ''
547      await say($, await whoIs($, id), status === 'done' ? `done · ${took}` : status, status === 'done' ? 'done' : 'error', id)
548      await safely($, () => admit($, cfg.maxCards))
549    } else {
550      await update($, loops, l => listOf<Loop>(l).map(x => (x.id === id ? { ...x, isDone: true, lastAt: now } : x)))
551    }
552    await refreshStatus($, cfg)
553    return done
554  })
555
556  on('turn.abort', async ($, e, next) => {
557    const r = await next(e)
558    await safely($, async () => apply($, { kind: 'abort', turnId: e.turnId, at: await $.clock.now() }, deckOptions))
559    return r
560  })
561
562  // ---------------------------------------------------------------- drawing
563
564  on('ui.render', { component: 'Pane', requestId: PANE }, async ($, e) => {
565    const [m, u, g, cards, lp, lines, t, r, v, now, deck] = await Promise.all([
566      getMain($),
567      getUsage($),
568      getGate($),
569      getCards($),
570      getLoops($),
571      getLog($),
572      getTurn($),
573      read($, receipt),
574      getView($),
575      $.clock.now(),
576      getDeck($),
577    ])
578    // Re-arms the sampler after a hot reload dropped it; starting a timer writes no state.
579    void safely($, () => ensureSampler($))
580    return draw(
581      {
582        surface: e.surface,
583        bodyColumns: e.props.bodyColumns,
584        bodyRows: e.props.scroll?.bodyRows ?? e.viewport?.rows ?? 40,
585        placement: e.props.placement,
586        viewedAgentId: e.props.view?.agentId ?? null,
587      },
588      $.ui.resolve(e),
589      { m, u, g, cards, lp, lines, t, r, v, now, deck },
590      cfg,
591      C,
592      {
593        toggleGate: async b => {
594          await update($, view, x => ({ ...normalize(DEFAULT_VIEW, x), gateOpen: normalize(DEFAULT_VIEW, x).gateOpen === b ? null : b }))
595        },
596        toggleExpanded: async id => {
597          await update($, view, x => ({ ...normalize(DEFAULT_VIEW, x), expanded: normalize(DEFAULT_VIEW, x).expanded === id ? null : id }))
598        },
599        select: async i => {
600          const card = gridOrder(await getCards($))[i]
601          if (card) await update($, view, x => ({ ...normalize(DEFAULT_VIEW, x), cursor: i, expanded: card.id }))
602        },
603        move: async delta => {
604          const order = gridOrder(await getCards($))
605          const n = order.length
606          if (n === 0) return
607          await update($, view, x => {
608            const at = normalize(DEFAULT_VIEW, x).cursor
609            const cursor = at === null ? 0 : (at + delta + n) % n
610            return { ...normalize(DEFAULT_VIEW, x), cursor, expanded: order[cursor]?.id ?? null }
611          })
612        },
613        clear: async () => {
614          await update($, view, x => ({ ...normalize(DEFAULT_VIEW, x), cursor: null, expanded: null }))
615        },
616      },
617    )
618  })
619}
620

1// Pure data: defaults, reducers, formatting and layout math. Nothing here touches `$`, so every
2// behaviour is testable directly (the test kit cannot raise a subagent's tool call or a
3// permission check inside a call; these functions are what the hooks apply).
4import type {
5  AgentCard,
6  Agents,
7  AgentState,
8  AgentTally,
9  Aborts,
10  Bucket,
11  Cache,
12  Check,
13  Context,
14  ContextSample,
15  Gate,
16  HotFiles,
17  Layout,
18  LogLine,
19  Loop,
20  Main,
21  Prompt,
22  Receipt,
23  Tally,
24  Tests,
25  ToolNote,
26  Tools,
27  ToolStat,
28  Turn,
29  Usage,
30  View,
31} from '../types'
32
33export const SCHEMA_VERSION = 3
34
35// ---------------------------------------------------------------- defaults
36
37export const DEFAULT_MAIN: Main = { model: '', effort: '', mode: '', steps: 0, isRunning: false }
38export const DEFAULT_USAGE: Usage = {
39  pct: null,
40  tokens: null,
41  window: 0,
42  costUsd: null,
43  limits: [],
44  compactions: 0,
45  lastCompactAt: null,
46}
47const ZERO: Tally = { rule: 0, ask: 0, cleared: 0, deny: 0 }
48export const DEFAULT_GATE: Gate = { recent: [], totals: { file: ZERO, shell: ZERO, other: ZERO } }
49export const DEFAULT_TURN: Turn = { edits: 0, errorStreak: 0, errors: 0, startedAt: 0, costAtStart: null, agentsAtStart: 0 }
50export const DEFAULT_VIEW: View = { expanded: null, gateOpen: null, layout: null, cursor: null }
51
52const isObject = (v: unknown): v is Record<string, unknown> => typeof v === 'object' && v !== null && !Array.isArray(v)
53
54/** A stored object merged over its defaults, so a value saved under an older shape still reads. */
55export const normalize = <T extends object>(def: T, stored: unknown): T =>
56  isObject(stored) ? ({ ...def, ...stored } as T) : def
57
58/** A stored list, or empty when what is stored is not a list. */
59export const listOf = <T>(stored: unknown): T[] => (Array.isArray(stored) ? (stored as T[]) : [])
60
61export const normalizeGate = (stored: unknown): Gate => {
62  const g = normalize(DEFAULT_GATE, stored)
63  const totals = normalize(DEFAULT_GATE.totals, g.totals)
64  return {
65    recent: listOf<Check>(g.recent),
66    totals: { file: normalize(ZERO, totals.file), shell: normalize(ZERO, totals.shell), other: normalize(ZERO, totals.other) },
67  }
68}
69
70export const normalizeCard = (stored: unknown): AgentCard =>
71  normalize<AgentCard>(
72    {
73      id: '',
74      type: 'agent',
75      model: '',
76      description: '',
77      status: 'running',
78      spawnedAt: 0,
79      endedAt: null,
80      ctx: 0,
81      out: 0,
82      steps: 0,
83      lastStop: null,
84      tools: [],
85      answer: '',
86      parentAgentId: null,
87    },
88    stored,
89  )
90
91export const normalizeLog = (stored: unknown): LogLine[] =>
92  listOf<Record<string, unknown>>(stored).map(l => ({
93    at: typeof l.at === 'number' ? l.at : 0,
94    who: String(l.who ?? ''),
95    text: String(l.text ?? ''),
96    agentId: typeof l.agentId === 'string' ? l.agentId : null,
97    kind: l.kind === 'error' || l.kind === 'done' ? l.kind : 'info',
98  }))
99
100// ---------------------------------------------------------------- config
101
102export type Panel = 'main' | 'prompt' | 'gate' | 'agents' | 'tools' | 'turn' | 'loops' | 'receipt' | 'log'
103const PANELS: readonly Panel[] = ['main', 'prompt', 'gate', 'agents', 'tools', 'turn', 'loops', 'receipt', 'log']
104
105export type Config = {
106  panels: Panel[]
107  motion: boolean
108  maxCards: number
109  layout: Layout
110  palette: Palette
111  openOnStart: boolean
112  statusLine: boolean
113  testPattern: RegExp
114  isTestPatternFallback: boolean
115  historyMinutes: number
116  charts: boolean
117}
118
119export const GATE_LABEL = 'GATE'
120
121// Flags stay 'i': a user pattern cannot add g or y, which would make .test stateful inside the pure reducer.
122export const safeRegExp = (source: string, fallback: string): { re: RegExp; isFallback: boolean } => {
123  try {
124    return { re: new RegExp(source || fallback, 'i'), isFallback: false }
125  } catch {
126    return { re: new RegExp(fallback, 'i'), isFallback: true }
127  }
128}
129
130/** The plugin's `/config` values, read leniently: anything malformed falls back to the default. */
131export const parseConfig = (o: Readonly<Record<string, unknown>>): Config => {
132  const str = (k: string, d: string) => (typeof o[k] === 'string' && o[k] !== '' ? (o[k] as string) : d)
133  const bool = (k: string, d: boolean) => (typeof o[k] === 'boolean' ? (o[k] as boolean) : d)
134  const panels = str('panels', PANELS.join(','))
135    .split(',')
136    .map(s => s.trim())
137    .filter((p): p is Panel => (PANELS as readonly string[]).includes(p))
138  const layout = str('layout', 'auto')
139  const max = typeof o.maxCards === 'number' && Number.isFinite(o.maxCards) ? Math.round(o.maxCards) : MAX_CARDS
140  const pattern = safeRegExp(str('testPattern', DEFAULT_TEST_PATTERN), DEFAULT_TEST_PATTERN)
141  const minutes = typeof o.historyMinutes === 'number' && Number.isFinite(o.historyMinutes) ? Math.round(o.historyMinutes) : 30
142  return {
143    panels: panels.length > 0 ? [...new Set(panels)] : [...PANELS],
144    motion: str('motion', 'while-active') !== 'off',
145    maxCards: Math.min(200, Math.max(1, max)),
146    layout: layout === 'compact' || layout === 'wide' || layout === 'mini' ? layout : 'auto',
147    palette: oneOf(str('palette', 'theme'), ['theme', 'pastel', 'dracula'], 'theme'),
148    openOnStart: bool('openOnStart', true),
149    statusLine: bool('statusLine', true),
150    testPattern: pattern.re,
151    isTestPatternFallback: pattern.isFallback,
152    historyMinutes: Math.min(30, Math.max(1, minutes)),
153    charts: bool('charts', true),
154  }
155}
156
157// ---------------------------------------------------------------- palette
158
159export type Palette = 'theme' | 'pastel' | 'dracula'
160export type Colors = Record<'main' | 'agent' | 'gate' | 'cleared' | 'amber' | 'warn' | 'dim' | 'faint' | 'text', string> & {
161  /** Painted behind the whole deck; absent, the host's own background shows through. */
162  bg?: string
163}
164
165/**
166 * `theme` names the person's own theme colours (they follow light, dark and colour-blind themes);
167 * `pastel` is fixed hex tuned for dark terminals.
168 */
169export const PALETTES: Record<Palette, Colors> = {
170  theme: {
171    main: 'claude',
172    agent: 'suggestion',
173    gate: 'success',
174    cleared: 'permission',
175    amber: 'warning',
176    warn: 'error',
177    dim: 'inactive',
178    faint: 'subtle',
179    text: 'text',
180  },
181  pastel: {
182    main: '#7dd3fc',
183    agent: '#93c5fd',
184    gate: '#86efac',
185    cleared: '#5eead4',
186    amber: '#fcd34d',
187    warn: '#fca5a5',
188    dim: '#6b7280',
189    faint: '#3f4654',
190    text: '#e5e7eb',
191    bg: '#111827',
192  },
193  dracula: {
194    main: '#bd93f9',
195    agent: '#8be9fd',
196    gate: '#50fa7b',
197    cleared: '#ff79c6',
198    amber: '#ffb86c',
199    warn: '#ff5555',
200    dim: '#6272a4',
201    faint: '#44475a',
202    text: '#f8f8f2',
203    bg: '#282a36',
204  },
205}
206
207/** SVG cannot name theme keys: mid-tone colours that read on light and dark backgrounds. */
208export const SVG_COLORS = { running: '#3b82f6', done: '#16a34a', failed: '#dc2626', other: '#8b5cf6', label: '#6b7280' }
209
210// ---------------------------------------------------------------- formatting
211
212/** `claude-opus-5-5` → `Opus 5.5`; anything else is shown as given. */
213/**
214 * A model id as people say it, from any provider's spelling: `claude-opus-5-5[1m]` → `Opus 5.5 1M`,
215 * `us.anthropic.claude-sonnet-4-5-20250929-v1:0` → `Sonnet 4.5`, `claude-3-5-haiku-20241022` →
216 * `Haiku 3.5`. Anything else is shown as given, cut to 22 characters.
217 */
218export const prettyModel = (id: string) => {
219  if (!id) return '—'
220  const cap = (f: string) => f.charAt(0).toUpperCase() + f.slice(1)
221  const big = /\[1m\]|-1m\b/i.test(id) ? ' 1M' : ''
222  const now = /claude-([a-z]+)-(\d+)(?:-(\d{1,2}))?(?:-\d{8})?(?![\d])/i.exec(id)
223  if (now?.[1] && !/^\d/.test(now[1])) return `${cap(now[1].toLowerCase())} ${now[2]}${now[3] ? `.${now[3]}` : ''}${big}`
224  const old = /claude-(\d+)(?:-(\d))?-([a-z]+)/i.exec(id)
225  if (old?.[3]) return `${cap(old[3].toLowerCase())} ${old[1]}${old[2] ? `.${old[2]}` : ''}${big}`
226  return shorten(id, 22)
227}
228
229/** Longest name a log line keeps; the log's name column grows to the longest one shown, up to this. */
230export const LOG_WHO_MAX = 26
231
232export const shorten = (s: string, n: number) => {
233  const one = s.replace(/\s+/g, ' ').trim()
234  return n <= 0 ? '' : one.length > n ? `${one.slice(0, Math.max(0, n - 1)).trimEnd()}…` : one
235}
236
237export const kTokens = (n: number) =>
238  n >= 1_000_000 ? `${(n / 1_000_000).toFixed(1)}M` : n >= 1000 ? `${Math.round(n / 1000)}k` : String(n)
239
240export const fmtDuration = (ms: number) => {
241  const s = Math.max(0, Math.round(ms / 1000))
242  if (s < 60) return `${s}s`
243  const m = Math.floor(s / 60)
244  return m < 60 ? `${m}m${String(s % 60).padStart(2, '0')}s` : `${Math.floor(m / 60)}h${String(m % 60).padStart(2, '0')}m`
245}
246
247/** A running clock as the live cards draw it: m:ss, or XhYY past an hour. */
248export const fmtTimer = (ms: number) => {
249  const s = Math.max(0, Math.floor(ms / 1000))
250  const m = Math.floor(s / 60)
251  return m < 60 ? `${m}:${String(s % 60).padStart(2, '0')}` : `${Math.floor(m / 60)}h${String(m % 60).padStart(2, '0')}`
252}
253
254export const fmtClock = (ms: number) => (ms > 0 ? new Date(ms).toTimeString().slice(0, 8) : '--:--:--')
255
256/** `1 error`, `2 errors`. */
257export const plural = (n: number, word: string) => `${n} ${word}${n === 1 ? '' : 's'}`
258
259export const fmtUsd = (n: number) => (n >= 100 ? `$${Math.round(n)}` : `$${n.toFixed(2)}`)
260
261/** A gauge of `width` cells: ▰ filled, ▱ empty. */
262export const gauge = (pct: number, width: number) => {
263  const full = Math.max(0, Math.min(width, Math.round((pct / 100) * width)))
264  return { on: '▰'.repeat(full), off: '▱'.repeat(width - full) }
265}
266
267/** A rate-limit window's short name: `five_hour` → `5h`, `seven_day_opus` → `7d opus`. */
268export const limitLabel = (kind: string) =>
269  kind
270    .replace(/five[_ -]?hours?/i, '5h')
271    .replace(/seven[_ -]?days?/i, '7d')
272    .replace(/[_-]+/g, ' ')
273    .trim()
274
275// ---------------------------------------------------------------- redaction
276
277const SECRETS: [RegExp, string][] = [
278  [/(authorization\s*[:=]\s*)(bearer\s+|basic\s+)?\S+/gi, '$1$2•••'],
279  [/\b(bearer)\s+[A-Za-z0-9._~+/-]{8,}=*/gi, '$1 •••'],
280  [/\b(sk|pk|rk|ghp|gho|ghs|github_pat|xox[abprs])[-_][A-Za-z0-9_-]{8,}/g, '•••'],
281  [/((?:api[_-]?key|access[_-]?token|token|secret|password|passwd|pwd)\s*[=:]\s*)("[^"]*"|'[^']*'|\S+)/gi, '$1•••'],
282  [/(--(?:token|password|api-key|secret)[= ])\S+/gi, '$1•••'],
283  [/(\b[A-Z][A-Z0-9_]*(?:KEY|TOKEN|SECRET|PASSWORD)=)\S+/g, '$1•••'],
284  [/(\b[a-z][a-z0-9+.-]*:\/\/[^\s/:@]+:)[^\s@]+@/gi, '$1•••@'],
285]
286
287/** What the gate drill-down may store: credentials masked before anything is written to state. */
288export const redact = (s: string) => SECRETS.reduce((t, [re, to]) => t.replace(re, to), s)
289
290// ---------------------------------------------------------------- tools and gate
291
292const FILE_TOOLS = new Set(['Read', 'Edit', 'Write', 'NotebookEdit', 'Glob', 'Grep'])
293const SHELL_TOOLS = new Set(['Bash', 'PowerShell'])
294export const EDIT_TOOLS = new Set(['Edit', 'Write', 'NotebookEdit'])
295
296export const bucketOf = (tool: string): Bucket =>
297  FILE_TOOLS.has(tool) ? 'file' : SHELL_TOOLS.has(tool) ? 'shell' : 'other'
298
299/** One line saying what a call was about: its command, path or pattern; redacted. */
300export const describeInput = (tool: string, input: unknown) => {
301  const i = isObject(input) ? input : {}
302  const path = typeof i.file_path === 'string' ? i.file_path.split(/[\\/]/).slice(-2).join('/') : ''
303  const what =
304    typeof i.command === 'string'
305      ? i.command
306      : path || (typeof i.pattern === 'string' ? i.pattern : typeof i.url === 'string' ? i.url : typeof i.description === 'string' ? i.description : '')
307  return redact(what ? `${tool} → ${what}` : tool)
308}
309
310/** Keeps the last `max` checks, but never drops a pending ask: its settle must still find it. */
311export const trimRecent = (list: Check[], max: number): Check[] => {
312  let extra = list.length - max
313  if (extra <= 0) return list
314  const out: Check[] = []
315  for (const c of list) {
316    if (extra > 0 && c.verdict !== 'ask') {
317      extra -= 1
318      continue
319    }
320    out.push(c)
321  }
322  return out.slice(-max * 2)
323}
324
325export const recordCheck = (g: Gate, c: Check): Gate => {
326  const t = g.totals[c.bucket]
327  return {
328    recent: trimRecent([...g.recent, c], 80),
329    totals: { ...g.totals, [c.bucket]: { ...t, [c.verdict]: t[c.verdict] + 1 } },
330  }
331}
332
333/** An `ask` settled by the call that followed it: it ran (cleared) or was refused (deny). */
334export const settleCheck = (g: Gate, id: string, didRun: boolean): Gate => {
335  const c = g.recent.find(r => r.id === id && r.verdict === 'ask')
336  if (!c) return g
337  const verdict = didRun ? 'cleared' : 'deny'
338  const t = g.totals[c.bucket]
339  return {
340    recent: g.recent.map(r => (r === c ? { ...r, verdict } : r)),
341    totals: { ...g.totals, [c.bucket]: { ...t, ask: Math.max(0, t.ask - 1), [verdict]: t[verdict] + 1 } },
342  }
343}
344
345export const gateSummary = (g: Gate) => {
346  const all = (['file', 'shell', 'other'] as const).reduce(
347    (s, k) => ({
348      rule: s.rule + g.totals[k].rule,
349      ask: s.ask + g.totals[k].ask,
350      cleared: s.cleared + g.totals[k].cleared,
351      deny: s.deny + g.totals[k].deny,
352    }),
353    { ...ZERO },
354  )
355  return { ...all, total: all.rule + all.ask + all.cleared + all.deny }
356}
357
358// ---------------------------------------------------------------- turn
359
360/**
361 * The turn after one tool call. Errors count in the main loop only (a subagent's failure is its
362 * own); edits count from every loop, so delegated work still counts.
363 */
364export const afterCall = (t: Turn, c: { inSubagent: boolean; hasFailed: boolean; isEdit: boolean }): Turn => ({
365  ...t,
366  errorStreak: c.inSubagent ? t.errorStreak : c.hasFailed ? t.errorStreak + 1 : 0,
367  errors: t.errors + (!c.inSubagent && c.hasFailed ? 1 : 0),
368  edits: t.edits + (c.isEdit ? 1 : 0),
369})
370
371export const receiptOf = (t: Turn, o: { durationMs: number; agentsSince: number; costNow: number | null; reason: string }): Receipt => ({
372  durationMs: o.durationMs,
373  agents: o.agentsSince,
374  edits: t.edits,
375  errors: t.errors,
376  costDelta: o.costNow !== null && t.costAtStart !== null && o.costNow - t.costAtStart >= 0.005 ? o.costNow - t.costAtStart : null,
377  reason: o.reason,
378  startedAt: t.startedAt,
379})
380
381// ---------------------------------------------------------------- agents and loops
382
383export type StepUsage = { input_tokens?: number; cache_read_input_tokens?: number; cache_creation_input_tokens?: number; output_tokens?: number } | null
384
385/** A card after one of its model requests: its context is the latest step's whole input; output adds up. */
386export const applyStep = (c: AgentCard, s: { model: string; usage: StepUsage; stopReason: string | null }): AgentCard => {
387  const u = s.usage ?? {}
388  const ctx = (u.input_tokens ?? 0) + (u.cache_read_input_tokens ?? 0) + (u.cache_creation_input_tokens ?? 0)
389  return {
390    ...c,
391    model: c.model || s.model,
392    steps: c.steps + 1,
393    ctx: ctx > 0 ? ctx : c.ctx,
394    out: c.out + (u.output_tokens ?? 0),
395    lastStop: s.stopReason,
396  }
397}
398
399export const noteTool = (c: AgentCard, n: ToolNote): AgentCard => ({ ...c, tools: [...c.tools, n].slice(-3) })
400
401export const stepLoop = (loops: Loop[], id: string, at: number): Loop[] => {
402  const found = loops.find(l => l.id === id)
403  const next = found
404    ? loops.map(l => (l === found ? { ...l, steps: l.steps + 1, lastAt: at } : l))
405    : [...loops, { id, steps: 1, firstAt: at, lastAt: at, isDone: false }]
406  return next.slice(-60)
407}
408
409export const LOOP_ACTIVE_MS = 15_000
410export const isLoopActive = (l: Loop, now: number) => !l.isDone && now - l.lastAt < LOOP_ACTIVE_MS
411
412/** Swimlane geometry: each agent's bar on one shared axis from the first spawn to now. */
413export const lanes = (cards: AgentCard[], now: number, width: number) => {
414  const start = Math.min(...cards.map(c => c.spawnedAt).filter(n => n > 0), now)
415  const span = Math.max(1, now - start)
416  return cards.map(c => {
417    const from = Math.floor(((Math.max(c.spawnedAt, start) - start) / span) * width)
418    const to = Math.max(from + 1, Math.ceil((((c.endedAt ?? now) - start) / span) * width))
419    return { id: c.id, before: Math.min(from, width), bar: Math.min(to, width) - Math.min(from, width), after: width - Math.min(to, width) }
420  })
421}
422
423// ---------------------------------------------------------------- layout
424
425/** How many log lines fit: what the other panels leave, never fewer than 4 nor more than 8. */
426export const logRows = (bodyRows: number, used: number) => Math.max(4, Math.min(8, bodyRows - used - 3))
427
428/** Legend items that fit on one row of `width` cells, in order; the rest are dropped. */
429export const fitLegend = <T extends { label: string }>(items: T[], width: number) => {
430  const out: T[] = []
431  let used = 0
432  for (const it of items) {
433    const w = it.label.length + 4
434    if (used + w > width) break
435    out.push(it)
436    used += w
437  }
438  return out
439}
440
441export type TitlePart = { swatch?: { glyph: string; ch: string }; text: string; short: string }
442export type FittedTitle = { sep: string; parts: TitlePart[] }
443
444export const titleText = (f: FittedTitle) => f.parts.map(p => (p.swatch?.glyph ?? '') + p.text).join(f.sep)
445
446/** Every part long or every part short, so a narrow title never loses its last count to truncation. */
447export const fitTitle = (parts: TitlePart[], width: number): FittedTitle => {
448  const long = { sep: ' · ', parts }
449  if (titleText(long).length <= width) return long
450  const spaced = { sep: ' ', parts: parts.map(p => ({ ...p, text: p.short })) }
451  if (titleText(spaced).length <= width) return spaced
452  return { sep: ' ', parts: parts.map(p => ({ ...p, text: p.swatch ? p.short.trimStart() : p.short })) }
453}
454
455/** A card's title row: the task in the agent's own words, the type only when there is none. */
456export const cardTitle = (c: AgentCard) => c.description || c.type
457
458/** A title split over two rows at a word boundary: `first` cells on row one, `rest` on row two. */
459export const titleLines = (title: string, first: number, rest: number): [string, string] => {
460  const t = title.replace(/\s+/g, ' ').trim()
461  if (t.length <= first) return [t, '']
462  const cut = t.lastIndexOf(' ', first)
463  const at = cut > 0 ? cut : first
464  return [t.slice(0, at).trim(), shorten(t.slice(at), rest)]
465}
466
467/**
468 * What a turn's opening text was, for the log: the person's words, or for a turn the engine
469 * opened with a tagged message (a subagent's hand-back, a task notification), that message's kind.
470 */
471const ENGINE_TAG = /^\s*<([a-z][\w-]*)/i
472
473export const promptLine = (text: string): { who: string; text: string } => {
474  const tag = ENGINE_TAG.exec(text)?.[1]
475  if (!tag) return { who: 'you', text: shorten(text, 70) }
476  const from = /\bfrom="([^"]+)"/.exec(text)?.[1]
477  return { who: 'engine', text: shorten(`${tag.replace(/[-_]/g, ' ')}${from ? ` from ${from.slice(0, 8)}` : ''}`, 70) }
478}
479
480export const elapsedOf = (c: AgentCard, now: number) => (c.endedAt ?? now) - c.spawnedAt
481
482// ---------------------------------------------------------------- deck
483
484export const PROMPT_CHARS = 48
485export const LATENCY_WINDOW = 20
486export const ABORT_CAP = 20
487export const SAMPLE_CAP = 180
488export const SAMPLE_MS = 10_000
489export const HOT_FILE_WARN = 4
490export const TOOLS_SHOWN = 8
491export const MAX_CARDS = 64
492export const DEFAULT_TEST_PATTERN = '\\b(vitest|jest|pytest|go test|cargo test|npm test|pnpm test|bun test|mocha)\\b'
493export const HOT_FILE_TOOLS: ReadonlySet<string> = new Set(['Edit', 'Write', 'MultiEdit', 'NotebookEdit'])
494
495export type Deck = {
496  prompt: Prompt
497  cache: Cache
498  tools: Tools
499  hotFiles: HotFiles
500  tests: Tests
501  aborts: Aborts
502  agents: Agents
503  context: Context
504}
505
506export type DeckOptions = { testPattern: RegExp }
507
508export type DeckEvent =
509  | { kind: 'prompt'; text: string }
510  | { kind: 'turn.start'; at: number; turnId: string; text: string }
511  | { kind: 'step'; agentId: string | null; usage: StepUsage }
512  | {
513      kind: 'tool'
514      tool: string
515      agentId: string | null
516      outcome: 'ok' | 'error' | 'denied'
517      ms: number | null
518      filePath: string | null
519      command: string | null
520      at: number
521    }
522  | { kind: 'turn.complete'; agentId: string | null; turnId: string; isAborted: boolean; at: number }
523  | { kind: 'abort'; turnId: string; at: number }
524  | { kind: 'measure'; percent: number | null; at: number }
525  | { kind: 'compact'; at: number }
526  | { kind: 'tick'; at: number; counts: Omit<AgentTally, 'spawning'> }
527  | { kind: 'reset' }
528
529type ToolEvent = Extract<DeckEvent, { kind: 'tool' }>
530
531export const DEFAULT_PROMPT: Prompt = { text: '', startedAt: null, status: 'idle' }
532export const DEFAULT_CACHE: Cache = { read: 0, input: 0, creation: 0 }
533export const DEFAULT_TESTS: Tests = { light: 'off', pass: 0, fail: 0, lastAt: null }
534export const DEFAULT_ABORTS: Aborts = { count: 0, at: [], turnIds: [] }
535export const DEFAULT_AGENTS: Agents = { byType: {}, history: [] }
536export const DEFAULT_CONTEXT: Context = { history: [], compactPending: false, lastPercent: null }
537export const DEFAULT_DECK: Deck = {
538  prompt: DEFAULT_PROMPT,
539  cache: DEFAULT_CACHE,
540  tools: {},
541  hotFiles: {},
542  tests: DEFAULT_TESTS,
543  aborts: DEFAULT_ABORTS,
544  agents: DEFAULT_AGENTS,
545  context: DEFAULT_CONTEXT,
546}
547export const DEFAULT_OPTIONS: DeckOptions = { testPattern: new RegExp(DEFAULT_TEST_PATTERN, 'i') }
548
549const DEFAULT_TOOL_STAT: ToolStat = { calls: 0, errors: 0, denies: 0, recentMs: [], recentOk: [], lastOk: true }
550const ZERO_TALLY: AgentTally = { spawning: 0, running: 0, done: 0, error: 0 }
551
552const recordOf = <T>(stored: unknown, each: (v: unknown) => T): Record<string, T> =>
553  isObject(stored) ? Object.fromEntries(Object.entries(stored).map(([k, v]) => [k, each(v)])) : {}
554
555const isNumber = (v: unknown): v is number => typeof v === 'number' && Number.isFinite(v)
556const numberOr = (v: unknown, def: number): number => (isNumber(v) ? v : def)
557const numberOrNull = (v: unknown): number | null => (isNumber(v) ? v : null)
558const oneOf = <T extends string>(v: unknown, all: readonly T[], def: T): T => all.find(x => x === v) ?? def
559const fieldsOf = (stored: unknown): Record<string, unknown> => (isObject(stored) ? stored : {})
560const timed = (stored: unknown): Record<string, unknown>[] =>
561  listOf<unknown>(stored).filter((v): v is Record<string, unknown> => isObject(v) && isNumber(v.at))
562
563const PROMPT_STATUSES = ['idle', 'running', 'done', 'aborted'] as const
564const TEST_LIGHTS = ['off', 'pass', 'fail'] as const
565
566const normalizeToolStat = (stored: unknown): ToolStat => {
567  const s = fieldsOf(stored)
568  return {
569    calls: numberOr(s.calls, 0),
570    errors: numberOr(s.errors, 0),
571    denies: numberOr(s.denies, 0),
572    recentMs: listOf<unknown>(s.recentMs).filter(isNumber),
573    recentOk: listOf<unknown>(s.recentOk).filter((v): v is boolean => typeof v === 'boolean'),
574    lastOk: typeof s.lastOk === 'boolean' ? s.lastOk : true,
575  }
576}
577
578const normalizeTally = (stored: unknown): AgentTally => {
579  const t = fieldsOf(stored)
580  return { spawning: numberOr(t.spawning, 0), running: numberOr(t.running, 0), done: numberOr(t.done, 0), error: numberOr(t.error, 0) }
581}
582
583/** Every field coerced to its type, so no corrupt stored value can throw in a reducer or a render. */
584export const normalizeDeck = (stored: Partial<Record<keyof Deck, unknown>>): Deck => {
585  const p = fieldsOf(stored.prompt)
586  const c = fieldsOf(stored.cache)
587  const t = fieldsOf(stored.tests)
588  const a = fieldsOf(stored.aborts)
589  const ag = fieldsOf(stored.agents)
590  const cx = fieldsOf(stored.context)
591  return {
592    prompt: {
593      text: typeof p.text === 'string' ? p.text : '',
594      startedAt: numberOrNull(p.startedAt),
595      status: oneOf(p.status, PROMPT_STATUSES, 'idle'),
596    },
597    cache: { read: numberOr(c.read, 0), input: numberOr(c.input, 0), creation: numberOr(c.creation, 0) },
598    tools: recordOf(stored.tools, normalizeToolStat),
599    hotFiles: recordOf(stored.hotFiles, v => numberOr(v, 0)),
600    tests: { light: oneOf(t.light, TEST_LIGHTS, 'off'), pass: numberOr(t.pass, 0), fail: numberOr(t.fail, 0), lastAt: numberOrNull(t.lastAt) },
601    aborts: {
602      count: numberOr(a.count, 0),
603      at: listOf<unknown>(a.at).filter(isNumber),
604      turnIds: listOf<unknown>(a.turnIds).filter((v): v is string => typeof v === 'string'),
605    },
606    agents: {
607      byType: recordOf(ag.byType, normalizeTally),
608      history: timed(ag.history).map(h => ({ at: numberOr(h.at, 0), running: numberOr(h.running, 0), done: numberOr(h.done, 0), error: numberOr(h.error, 0) })),
609    },
610    context: {
611      history: timed(cx.history).map(h => ({
612        at: numberOr(h.at, 0),
613        percent: numberOr(h.percent, 0),
614        cacheHit: numberOr(h.cacheHit, 0),
615        compacted: h.compacted === true,
616      })),
617      compactPending: cx.compactPending === true,
618      lastPercent: numberOrNull(cx.lastPercent),
619    },
620  }
621}
622
623const capped = <T>(list: T[], item: T, cap: number): T[] => [...list, item].slice(-cap)
624
625const noteAbort = (a: Aborts, turnId: string, at: number): Aborts =>
626  a.turnIds.includes(turnId)
627    ? a
628    : { count: a.count + 1, at: capped(a.at, at, ABORT_CAP), turnIds: capped(a.turnIds, turnId, ABORT_CAP) }
629
630const recordTool = (s: ToolStat, e: ToolEvent): ToolStat => ({
631  calls: s.calls + 1,
632  errors: s.errors + (e.outcome === 'error' ? 1 : 0),
633  denies: s.denies + (e.outcome === 'denied' ? 1 : 0),
634  recentMs: e.ms !== null && e.outcome !== 'denied' ? capped(s.recentMs, e.ms, LATENCY_WINDOW) : s.recentMs,
635  recentOk: capped(s.recentOk, e.outcome === 'ok', LATENCY_WINDOW),
636  lastOk: e.outcome === 'ok',
637})
638
639const recordEdit = (h: HotFiles, e: ToolEvent): HotFiles =>
640  HOT_FILE_TOOLS.has(e.tool) && e.outcome !== 'denied' && e.filePath !== null
641    ? { ...h, [e.filePath]: (h[e.filePath] ?? 0) + 1 }
642    : h
643
644const recordTest = (t: Tests, e: ToolEvent, pattern: RegExp): Tests => {
645  if (e.tool !== 'Bash' || e.outcome === 'denied' || e.command === null || !pattern.test(e.command)) return t
646  return e.outcome === 'ok'
647    ? { light: 'pass', pass: t.pass + 1, fail: t.fail, lastAt: e.at }
648    : { light: 'fail', pass: t.pass, fail: t.fail + 1, lastAt: e.at }
649}
650
651/** A sample that coalesces into the previous one keeps that one's compaction mark. */
652const sampleContext = (c: Context, s: ContextSample, coalesce: boolean): Context => {
653  const last = c.history.at(-1)
654  const history =
655    coalesce && last && s.at - last.at < SAMPLE_MS
656      ? [...c.history.slice(0, -1), { ...s, compacted: s.compacted || last.compacted }]
657      : capped(c.history, s, SAMPLE_CAP)
658  return { history, compactPending: false, lastPercent: s.percent }
659}
660
661export const reduceDeck = (d: Deck, e: DeckEvent, opts: DeckOptions = DEFAULT_OPTIONS): Deck => {
662  switch (e.kind) {
663    case 'prompt':
664      return { ...d, prompt: { ...d.prompt, text: shorten(redact(e.text), PROMPT_CHARS) } }
665    case 'turn.start': {
666      // A plugin beneath can abort the turn inside its own start, before this event is applied.
667      const status = d.aborts.turnIds.includes(e.turnId) ? 'aborted' : 'running'
668      // A turn an engine message opened (a task notification, a hand-back) keeps the human's prompt.
669      const isHuman = e.text.trim() !== '' && !ENGINE_TAG.test(e.text)
670      const text = isHuman ? shorten(redact(e.text), PROMPT_CHARS) : d.prompt.text
671      return { ...d, prompt: { text, status, startedAt: e.at }, hotFiles: {} }
672    }
673    case 'step': {
674      if (e.agentId !== null) return d
675      const u = e.usage ?? {}
676      return {
677        ...d,
678        cache: {
679          read: d.cache.read + (u.cache_read_input_tokens ?? 0),
680          input: d.cache.input + (u.input_tokens ?? 0),
681          creation: d.cache.creation + (u.cache_creation_input_tokens ?? 0),
682        },
683      }
684    }
685    case 'tool':
686      return {
687        ...d,
688        tools: { ...d.tools, [e.tool]: recordTool(d.tools[e.tool] ?? DEFAULT_TOOL_STAT, e) },
689        hotFiles: recordEdit(d.hotFiles, e),
690        tests: recordTest(d.tests, e, opts.testPattern),
691      }
692    case 'turn.complete': {
693      if (e.agentId !== null) return d
694      const isAborted = e.isAborted || d.prompt.status === 'aborted'
695      return {
696        ...d,
697        prompt: { ...d.prompt, status: isAborted ? 'aborted' : 'done' },
698        aborts: isAborted ? noteAbort(d.aborts, e.turnId, e.at) : d.aborts,
699      }
700    }
701    case 'abort':
702      return { ...d, prompt: { ...d.prompt, status: 'aborted' }, aborts: noteAbort(d.aborts, e.turnId, e.at) }
703    case 'measure':
704      if (e.percent === null) return d
705      return {
706        ...d,
707        context: sampleContext(d.context, { at: e.at, percent: e.percent, cacheHit: cacheHit(d.cache), compacted: d.context.compactPending }, true),
708      }
709    case 'compact':
710      return d.context.compactPending ? d : { ...d, context: { ...d.context, compactPending: true } }
711    case 'tick': {
712      const { running, done, error } = e.counts
713      const p = d.context.lastPercent
714      return {
715        ...d,
716        agents: { ...d.agents, history: capped(d.agents.history, { at: e.at, running, done, error }, SAMPLE_CAP) },
717        context:
718          p === null
719            ? d.context
720            : sampleContext(d.context, { at: e.at, percent: p, cacheHit: cacheHit(d.cache), compacted: d.context.compactPending }, false),
721      }
722    }
723    case 'reset':
724      return DEFAULT_DECK
725    default:
726      return d
727  }
728}
729
730export const cacheHit = (c: Cache): number => {
731  const sum = c.read + c.input + c.creation
732  return sum === 0 ? 0 : c.read / sum
733}
734
735export const meanMs = (s: ToolStat): number | null =>
736  s.recentMs.length === 0 ? null : s.recentMs.reduce((a, b) => a + b, 0) / s.recentMs.length
737
738export const badDots = (s: ToolStat): number => Math.min(4, s.recentOk.filter(ok => !ok).length)
739
740export const topTools = (t: Tools, n: number = TOOLS_SHOWN): [string, ToolStat][] =>
741  Object.entries(t)
742    .sort(([a, x], [b, y]) => y.calls - x.calls || (a < b ? -1 : a > b ? 1 : 0))
743    .slice(0, n)
744
745export const toolName = (tool: string): string => (tool.startsWith('mcp__') ? (tool.split('__').at(-1) ?? tool) : tool)
746
747export const hotFile = (h: HotFiles): { path: string; edits: number } | null =>
748  Object.entries(h).reduce<{ path: string; edits: number } | null>(
749    (best, [path, edits]) => (!best || edits > best.edits || (edits === best.edits && path < best.path) ? { path, edits } : best),
750    null,
751  )
752
753export const stateOf = (c: AgentCard): AgentState => {
754  if (c.status === 'failed' || c.status === 'stopped') return 'error'
755  if (c.status === 'done') return 'done'
756  if (c.status !== 'running') return 'running'
757  if (c.steps === 0) return 'spawning'
758  return c.tools.at(-1)?.isError ? 'error' : 'running'
759}
760
761export const laneOf = (c: AgentCard): string => {
762  if (c.type !== '' && c.type !== 'teammate') return c.type
763  return c.description.trim().split(/\s+/)[0] || 'other'
764}
765
766const addTally = (t: AgentTally, s: AgentState): AgentTally => ({ ...t, [s]: t[s] + 1 })
767
768export const tallyByType = (cards: AgentCard[], folded: Record<string, AgentTally>): Record<string, AgentTally> =>
769  cards.reduce<Record<string, AgentTally>>((out, c) => {
770    const lane = laneOf(c)
771    return { ...out, [lane]: addTally(out[lane] ?? ZERO_TALLY, stateOf(c)) }
772  }, folded)
773
774export const totals = (byType: Record<string, AgentTally>): AgentTally =>
775  Object.values(byType).reduce(
776    (a, t) => ({ spawning: a.spawning + t.spawning, running: a.running + t.running, done: a.done + t.done, error: a.error + t.error }),
777    ZERO_TALLY,
778  )
779
780export const admitCards = (
781  cards: AgentCard[],
782  folded: Record<string, AgentTally>,
783  cap: number,
784): { cards: AgentCard[]; folded: Record<string, AgentTally> } => {
785  const extra = cards.length - cap
786  if (extra <= 0) return { cards, folded }
787  const dropped = new Set(
788    cards
789      .filter(c => {
790        const s = stateOf(c)
791        return s === 'done' || s === 'error'
792      })
793      .sort((a, b) => a.spawnedAt - b.spawnedAt)
794      .slice(0, extra),
795  )
796  if (dropped.size === 0) return { cards, folded }
797  return { cards: cards.filter(c => !dropped.has(c)), folded: tallyByType([...dropped], folded) }
798}
799
800export const gridOrder = (cards: AgentCard[]): AgentCard[] => {
801  const count = new Map<string, number>()
802  for (const c of cards) count.set(laneOf(c), (count.get(laneOf(c)) ?? 0) + 1)
803  return [...cards].sort((a, b) => {
804    const la = laneOf(a)
805    const lb = laneOf(b)
806    return (count.get(lb) ?? 0) - (count.get(la) ?? 0) || (la < lb ? -1 : la > lb ? 1 : 0) || a.spawnedAt - b.spawnedAt
807  })
808}
809
810export const isSampling = (p: Prompt, cards: AgentCard[]): boolean =>
811  p.status === 'running' ||
812  cards.some(c => {
813    const s = stateOf(c)
814    return s === 'spawning' || s === 'running'
815  })
816

1import type { Elements, RenderElement, RenderSurface } from 'claude-code'
2
3import type { AgentCard, Bucket, Check, Gate, Layout, LogLine, Loop, Main, Receipt, Turn, Usage, View } from '../types'
4import { bandPanels, bandTitles, chartColors, titleColumns, windowMinutes, type BandPanel, type ChartInput } from './charts'
5import {
6  LOG_WHO_MAX,
7  GATE_LABEL,
8  HOT_FILE_WARN,
9  SVG_COLORS,
10  badDots,
11  cacheHit,
12  cardTitle,
13  fitLegend,
14  fitTitle,
15  fmtClock,
16  fmtDuration,
17  fmtTimer,
18  fmtUsd,
19  gateSummary,
20  gauge,
21  gridOrder,
22  hotFile,
23  isLoopActive,
24  kTokens,
25  laneOf,
26  lanes,
27  limitLabel,
28  logRows,
29  meanMs,
30  plural,
31  prettyModel,
32  shorten,
33  stateOf,
34  tallyByType,
35  titleLines,
36  toolName,
37  topTools,
38  totals,
39} from './core'
40import type { Colors, Config, Deck, Panel } from './core'
41import { encodeCells, type Palette as RasterPalette } from './raster'
42import { CELL_PX, GAUGE_HEIGHT, gaugeSvg, gaugeWidth, gridSvg, hex } from './svg'
43
44export type PaneView = { surface: RenderSurface; bodyColumns: number; bodyRows: number; placement: 'dock' | 'inline'; viewedAgentId: string | null }
45export type DrawData = { m: Main; u: Usage; g: Gate; cards: AgentCard[]; lp: Loop[]; lines: LogLine[]; t: Turn; r: Receipt | null; v: View; now: number; deck: Deck }
46export type Actions = {
47  toggleGate: (b: Bucket) => Promise<void>
48  toggleExpanded: (id: string) => Promise<void>
49  select: (i: number) => Promise<void>
50  move: (delta: 1 | -1) => Promise<void>
51  clear: () => Promise<void>
52}
53
54/** The terminal draws the band as Raster, the desktop as Svg; inline above the prompt the pane has no rows to spare. */
55export const bandRows = (p: { surface: RenderSurface; placement: 'dock' | 'inline'; layout: Layout; columns: number; rows: number; charts: boolean }): 0 | 4 | 6 =>
56  (p.surface !== 'terminal' && p.surface !== 'desktop') || p.placement !== 'dock' || p.layout === 'mini' || p.columns < 60 || p.rows < 15 || !p.charts ? 0 : p.rows >= 30 ? 6 : 4
57
58const lastSegments = (path: string) => path.split('/').filter(Boolean).slice(-2).join('/')
59const sumTotals = (t: { rule: number; ask: number; cleared: number; deny: number }) => t.rule + t.ask + t.cleared + t.deny
60const chartHex = (colors: RasterPalette, ch: string) => hex(colors[ch] ?? 0)
61
62export const draw = (pv: PaneView, els: Elements[RenderSurface], d: DrawData, cfg: Config, C: Colors, act: Actions): RenderElement => {
63  const { Box, Text, Button } = els
64  const hasClient = 'Client' in els
65  const { m, u, g, cards, lp, lines, t, r, v, now, deck } = d
66  const W = Math.max(40, pv.bodyColumns)
67  const layout = v.layout ?? cfg.layout
68  const isWide = layout === 'wide' || (layout === 'auto' && W >= 110)
69  const colW = isWide ? Math.floor((W - 2) / 2) : W
70  const modelName = prettyModel(m.model)
71  const viewed = pv.viewedAgentId
72  const running = cards.filter(c => c.status === 'running')
73  const motion = cfg.motion && hasClient
74  const s = gateSummary(g)
75  const order = gridOrder(cards)
76  const tally = totals(tallyByType(cards, deck.agents.byType))
77  const hot = hotFile(deck.hotFiles)
78  const top = topTools(deck.tools)
79  const hasCache = deck.cache.read + deck.cache.input + deck.cache.creation > 0
80  const cachePct = Math.round(cacheHit(deck.cache) * 100)
81  const promptStatus =
82    s.ask > 0
83      ? `waiting on you: ${plural(s.ask, 'permission ask')}`
84      : deck.prompt.status === 'idle'
85        ? 'waiting on you'
86        : deck.prompt.status
87  const testsWord = deck.tests.light === 'pass' ? `PASS ${deck.tests.pass}` : deck.tests.light === 'fail' ? `FAIL ${deck.tests.fail}` : null
88  const Raster = 'Raster' in els ? els.Raster : null
89  const Svg = pv.surface !== 'terminal' && 'Svg' in els ? els.Svg : null
90  // The desktop paints Text in a proportional font over a grid measured in code-font cells (ADR 0005).
91  const isDesktop = pv.surface === 'desktop'
92  const DesktopSvg = isDesktop ? Svg : null
93  const chartPalette = chartColors(cfg.palette)
94  const nBand = Raster || DesktopSvg ? bandRows({ surface: pv.surface, placement: pv.placement, layout, columns: pv.bodyColumns, rows: pv.bodyRows, charts: cfg.charts }) : 0
95  const chartInput: ChartInput = { context: deck.context.history, history: deck.agents.history, cards, cursor: v.cursor, now, minutes: cfg.historyMinutes }
96  const band = nBand > 0 ? bandPanels(chartInput, pv.bodyColumns, nBand * 2) : null
97  const bandCost = band ? nBand + 3 : 0
98  // A panel with nothing to show yet takes no room: most sessions never spawn an agent.
99  const isEmpty: Record<Panel, boolean> = {
100    main: false,
101    prompt: deck.prompt.status === 'idle' && deck.prompt.text === '',
102    gate: g.recent.length === 0 && s.total === 0,
103    agents: cards.length === 0,
104    tools: top.length === 0,
105    turn: !testsWord && !hot && deck.aborts.count === 0 && s.total === 0,
106    loops: lp.length === 0,
107    receipt: !m.isRunning && !r,
108    log: false,
109  }
110  const panels = cfg.panels.filter(q => !isEmpty[q])
111  const decider = m.mode === 'auto' ? 'classifier' : 'you'
112
113  // A connector between panels: animated while its flow is live, a dim line otherwise.
114  const rail = (key: string, active: boolean, color: string, width: number, marks: number[] = [], isMerge = false) =>
115    motion ? (
116      <els.Client
117        key={key}
118        module="./rail.tsx"
119        width={width}
120        height={1}
121        props={{ active, width, color, dim: C.faint, marks, isMerge }}
122      />
123    ) : (
124      <Text color={C.faint}>{'─'.repeat(Math.max(1, width))}</Text>
125    )
126
127  // A start time of 0 is unknown (state saved before it was recorded): no clock, not decades.
128  const clock = (key: string, since: number, endAt: number | null, color: string) =>
129    since <= 0 ? (
130      <Text color={color}>—</Text>
131    ) : hasClient ? (
132      <els.Client key={key} module="./elapsed.tsx" props={{ since, now, endAt, color }} />
133    ) : (
134      <Text color={color}>{fmtTimer((endAt ?? now) - since)}</Text>
135    )
136
137  // ---- main
138  const effortN = { low: 1, medium: 2, high: 3, xhigh: 4, max: 4 }[m.effort] ?? 0
139  const effortGauge = { on: '▮'.repeat(effortN), off: '▯'.repeat(4 - effortN) }
140  const ctxGauge = u.pct !== null ? gauge(u.pct, 10) : null
141  const gaugeSvgOf = (Svg: NonNullable<typeof DesktopSvg>, g: { on: string; off: string }, isWarn: boolean, alt: string) => (
142    <Svg source={gaugeSvg(g, chartHex(chartPalette, isWarn ? 'e' : 'c'), chartHex(chartPalette, 's'))} alt={alt} width={gaugeWidth(g)} height={GAUGE_HEIGHT} />
143  )
144  // Each phrase is its own Text in a wrapping row, so a row too wide for the proportional font breaks between phrases.
145  const desktopMainRows = (Svg: NonNullable<typeof DesktopSvg>) => [
146    <Box flexWrap="wrap" columnGap={2}>
147      <Box columnGap={1} alignItems="center">
148        <Text dimColor>effort</Text>
149        {gaugeSvgOf(Svg, effortGauge, false, `effort ${m.effort || '—'}`)}
150        <Text color={C.main} bold>
151          {m.effort || '—'}
152        </Text>
153      </Box>
154      {m.mode ? <Text dimColor>{`mode ${m.mode}`}</Text> : null}
155      <Text dimColor>{`${m.steps} req`}</Text>
156    </Box>,
157    ctxGauge ? (
158      <Box flexWrap="wrap" columnGap={2}>
159        <Box columnGap={1} alignItems="center">
160          <Text dimColor>ctx</Text>
161          {gaugeSvgOf(Svg, ctxGauge, (u.pct ?? 0) >= 80, `context ${Math.round(u.pct ?? 0)}%`)}
162          <Text bold>{`${Math.round(u.pct ?? 0)}%`}</Text>
163        </Box>
164        {u.tokens !== null ? <Text dimColor>{`${kTokens(u.tokens)}/${kTokens(u.window)}`}</Text> : null}
165        {u.compactions > 0 ? <Text color={C.amber}>{`⟲${u.compactions}`}</Text> : null}
166        {hasCache ? <Text dimColor>{`cache hit ${cachePct}%`}</Text> : null}
167      </Box>
168    ) : null,
169    u.costUsd !== null || u.limits.length > 0 ? (
170      <Box flexWrap="wrap" columnGap={2}>
171        {u.costUsd !== null ? <Text color={C.text}>{fmtUsd(u.costUsd)}</Text> : null}
172        {u.limits.slice(0, 2).map(l => (
173          <Box columnGap={1} alignItems="center">
174            <Text dimColor>{limitLabel(l.kind)}</Text>
175            {gaugeSvgOf(Svg, gauge(l.pct, 5), l.pct >= 80, `${limitLabel(l.kind)} ${Math.round(l.pct)}%`)}
176            <Text dimColor>{`${Math.round(l.pct)}%`}</Text>
177          </Box>
178        ))}
179      </Box>
180    ) : null,
181  ]
182  const terminalMainRows = () => [
183    <Text wrap="truncate">
184      <Text dimColor>effort </Text>
185      <Text color={C.main}>{effortGauge.on + effortGauge.off} </Text>
186      <Text color={C.main} bold>
187        {m.effort || '—'}
188      </Text>
189      {m.mode ? <Text dimColor>{`   mode ${m.mode}`}</Text> : null}
190      <Text dimColor>{`   ${m.steps} req`}</Text>
191    </Text>,
192    ctxGauge ? (
193      <Text wrap="truncate">
194        <Text dimColor>ctx </Text>
195        <Text color={u.pct !== null && u.pct >= 80 ? C.warn : C.main}>{ctxGauge.on}</Text>
196        <Text color={C.faint}>{ctxGauge.off}</Text>
197        <Text bold>{` ${Math.round(u.pct ?? 0)}%`}</Text>
198        {u.tokens !== null ? <Text dimColor>{` ${kTokens(u.tokens)}/${kTokens(u.window)}`}</Text> : null}
199        {u.compactions > 0 ? <Text color={C.amber}>{`  ⟲${u.compactions}`}</Text> : null}
200        {hasCache ? <Text dimColor>{`  cache hit ${cachePct}%`}</Text> : null}
201      </Text>
202    ) : null,
203    u.costUsd !== null || u.limits.length > 0 ? (
204      <Text wrap="truncate">
205        {u.costUsd !== null ? <Text color={C.text}>{`${fmtUsd(u.costUsd)}   `}</Text> : null}
206        {u.limits.slice(0, 2).map(l => {
207          const lg = gauge(l.pct, 5)
208          return (
209            <Text wrap="truncate">
210              <Text dimColor>{`${limitLabel(l.kind)} `}</Text>
211              <Text color={l.pct >= 80 ? C.warn : C.main}>{lg.on}</Text>
212              <Text color={C.faint}>{lg.off}</Text>
213              <Text dimColor>{` ${Math.round(l.pct)}%  `}</Text>
214            </Text>
215          )
216        })}
217      </Text>
218    ) : null,
219  ]
220  const mainPanel = (w: number) => (
221    <Box flexDirection="column" borderStyle="round" borderColor={C.main} paddingX={1} width={w}>
222      <Box justifyContent="space-between">
223        <Text color={C.main} bold>
224          {modelName} · main
225        </Text>
226        <Text color={m.isRunning ? C.main : C.dim}>{m.isRunning ? '● working' : '○ idle'}</Text>
227      </Box>
228      {DesktopSvg ? desktopMainRows(DesktopSvg) : terminalMainRows()}
229    </Box>
230  )
231
232  // ---- prompt: the turn in flight, and whether it waits on you
233  const promptStart = deck.prompt.startedAt ?? 0
234  // Between an abort and the main turn.complete, the receipt still belongs to the turn before.
235  const isOwnReceipt = r !== null && promptStart > 0 && (r.startedAt ?? 0) >= promptStart
236  const promptEnd = deck.prompt.status === 'running' ? null : isOwnReceipt ? promptStart + r.durationMs : now
237  // The stored prompt is already short (48 characters), so the desktop wraps it whole instead of cutting it to the row.
238  const promptPanel = (w: number) =>
239    isDesktop ? (
240      <Box width={w} flexWrap="wrap" columnGap={1}>
241        <Text bold>PROMPT</Text>
242        <Text wrap="wrap">{`"${deck.prompt.text}"`}</Text>
243        <Box flexShrink={0}>{clock('prompt-clock', promptStart, promptEnd, C.dim)}</Box>
244        <Text color={s.ask > 0 ? C.amber : C.dim} wrap="wrap">{`· ${promptStatus}`}</Text>
245      </Box>
246    ) : (
247      <Box width={w}>
248        <Text wrap="truncate">
249          <Text bold>PROMPT  </Text>
250          <Text>{`"${shorten(deck.prompt.text, Math.max(8, w - promptStatus.length - 22))}" `}</Text>
251        </Text>
252        <Box flexShrink={0}>{clock('prompt-clock', promptStart, promptEnd, C.dim)}</Box>
253        <Text color={s.ask > 0 ? C.amber : C.dim} wrap="truncate">{` · ${promptStatus}`}</Text>
254      </Box>
255    )
256
257  // ---- gate
258  const verdictColor = (c: Check) =>
259    c.verdict === 'rule' ? C.gate : c.verdict === 'cleared' ? C.cleared : c.verdict === 'ask' ? C.amber : C.warn
260  const gatePanel = (w: number) => {
261    const strip = g.recent.slice(-Math.max(8, w - 4))
262    const open = v.gateOpen
263    return (
264      <Box flexDirection="column" borderStyle="round" borderColor={C.gate} paddingX={1} width={w}>
265        <Box justifyContent="space-between">
266          <Text color={C.gate} bold>
267            {GATE_LABEL} · permissions
268          </Text>
269          <Text dimColor>{`${s.total} checks`}</Text>
270        </Box>
271        <Box>
272          {strip.length === 0 ? <Text color={C.faint}>no checks yet</Text> : null}
273          {strip.map(c => (
274            <Text color={verdictColor(c)} dimColor={c.inSubagent}>
275              {c.verdict === 'deny' ? '✗' : '■'}
276            </Text>
277          ))}
278        </Box>
279        <Text wrap="truncate">
280          <Text color={C.gate}>■</Text>
281          <Text dimColor>{` ${s.rule} allowed  `}</Text>
282          <Text color={C.cleared}>■</Text>
283          <Text dimColor>{` ${s.cleared} ${decider}  `}</Text>
284          {s.ask > 0 ? <Text color={C.amber}>{`■ ${s.ask} pending  `}</Text> : null}
285          <Text color={s.deny > 0 ? C.warn : C.dim}>{`✗ ${s.deny} denied`}</Text>
286          {w >= 80 && g.recent.some(c => c.inSubagent) ? <Text color={C.faint}>{'  dim: in subagents'}</Text> : null}
287        </Text>
288        <Box columnGap={2}>
289          {(['file', 'shell', 'other'] as const).map((b: Bucket) => {
290            const tl = g.totals[b]
291            const n = tl.rule + tl.ask + tl.cleared + tl.deny
292            return (
293              <Button
294                key={`gate-${b}`}
295                plain
296                hotkey={b[0]}
297                label={`${b} ${n}${open === b ? ' ▾' : ''}`}
298                dimColor={n === 0}
299                onPress={() => act.toggleGate(b)}
300              />
301            )
302          })}
303        </Box>
304        {open
305          ? g.recent
306              .filter(c => c.bucket === open)
307              .slice(-5)
308              .map(c => (
309                <Text wrap="truncate">
310                  <Text color={verdictColor(c)}>{c.verdict === 'deny' ? '✗ ' : '■ '}</Text>
311                  <Text color={C.dim}>{`${(c.verdict === 'rule' ? 'allowed' : c.verdict === 'cleared' ? decider : c.verdict === 'ask' ? 'pending' : 'denied').padEnd(10)} `}</Text>
312                  <Text dimColor={c.inSubagent}>{shorten(c.detail, Math.max(10, w - 18))}</Text>
313                </Text>
314              ))
315          : null}
316      </Box>
317    )
318  }
319
320  // ---- agents: cards up to the limit, swimlanes beyond it
321  const statusColor = (c: AgentCard) => (c.status === 'failed' ? C.warn : c.status === 'done' ? C.gate : C.agent)
322  const glyph = (c: AgentCard) => (c.status === 'running' ? '◐' : c.status === 'done' ? '✓' : c.status === 'failed' ? '✗' : '■')
323  const expandOnPress = (id: string) => () => act.toggleExpanded(id)
324
325  // Cards need 20 columns each; more agents than fit side by side switch to lanes.
326  const fitCards = (w: number) => Math.max(1, Math.floor((w + 1) / 21))
327
328  // Nine numbered entries share one row; below 12 columns each, a label is its number and a state glyph.
329  const STATE_GLYPH = { spawning: '·', running: '●', done: '✓', error: '✗' } as const
330  const stateColor = { spawning: C.dim, running: C.agent, done: C.gate, error: C.warn } as const
331  const numbered = (w: number) => {
332    const first = order.slice(0, 9)
333    const per = Math.floor((w - (first.length - 1)) / first.length)
334    return (
335      <Box columnGap={1} width={w} overflow="hidden">
336        {first.map((c, i) => {
337          const state = stateOf(c)
338          const dim = v.cursor !== null && v.cursor !== i
339          const onPress = () => act.select(i)
340          return per >= 12 ? (
341            <Button key={`agent-${i}`} plain hotkey={String(i + 1)} label={shorten(`${i + 1} ${laneOf(c)} ${kTokens(c.ctx)} ${state}`, per)} dimColor={dim} onPress={onPress} />
342          ) : (
343            <Box>
344              <Button key={`agent-${i}`} plain hotkey={String(i + 1)} label={String(i + 1)} dimColor={dim} onPress={onPress} />
345              <Text color={stateColor[state]}>{STATE_GLYPH[state]}</Text>
346            </Box>
347          )
348        })}
349      </Box>
350    )
351  }
352  const cursorCard = v.cursor !== null ? order[v.cursor] : undefined
353  const hasNav = cards.length > 9
354  const hasClear = v.cursor !== null || v.expanded !== null
355  const dropped = band?.dropped ?? 0
356  const hasCursorRow = cards.length > 0 && (hasNav || hasClear || cursorCard !== undefined)
357  const cursorRow = (w: number) => (
358    <Box columnGap={2} width={w}>
359      {hasNav ? <Button key="cursor-next" plain hotkey="n" label="n next" onPress={() => act.move(1)} /> : null}
360      {hasNav ? <Button key="cursor-back" plain hotkey="b" label="b back" onPress={() => act.move(-1)} /> : null}
361      {hasClear ? <Button key="cursor-clear" plain hotkey="x" label="x clear" onPress={() => act.clear()} /> : null}
362      {cursorCard ? (
363        <Text color={C.amber} wrap="truncate">
364          {`cursor ▸ #${cursorCard.id.slice(0, 6)} ${cursorCard.type} ${kTokens(cursorCard.ctx)} ${toolName(cursorCard.tools.at(-1)?.tool ?? '')}`.trimEnd()}
365        </Text>
366      ) : null}
367    </Box>
368  )
369
370  const agentsPanel = (w: number) => {
371    const fit = fitCards(w)
372    const useLanes = cards.length > fit
373    const header = (
374      <Box flexDirection="column" width={w}>
375        <Box justifyContent="space-between" width={w}>
376          <Text bold>{`agents · ${tally.spawning + tally.running} running · ${tally.spawning + tally.running + tally.done + tally.error} total`}</Text>
377          {cards.length > 0 ? <Text color={C.faint}>1-{Math.min(cards.length, 9)} select</Text> : null}
378        </Box>
379        {cards.length > 0 ? numbered(w) : null}
380        {hasCursorRow ? cursorRow(w) : null}
381      </Box>
382    )
383    if (cards.length === 0) {
384      return (
385        <Box flexDirection="column" width={w}>
386          {header}
387          <Text color={C.faint}>no subagents yet</Text>
388        </Box>
389      )
390    }
391    if (useLanes) {
392      const shown = cards.slice(-6)
393      const barW = Math.max(8, w - 28)
394      const geo = lanes(shown, now, barW)
395      return (
396        <Box flexDirection="column" width={w}>
397          {header}
398          {cards.length > shown.length ? <Text color={C.faint}>{`+${cards.length - shown.length} earlier`}</Text> : null}
399          {shown.map((c, i) => {
400            const gm = geo[i]
401            const isViewed = viewed === c.id
402            return (
403              <Box>
404                <Text color={statusColor(c)} bold={isViewed}>{`${isViewed ? '▶' : glyph(c)} `}</Text>
405                <Box width={17}>
406                  <Button key={`card-${c.id}`} plain label={shorten(cardTitle(c), 14)} onPress={expandOnPress(c.id)} />
407                </Box>
408                <Text color={C.faint}>{' ' + '·'.repeat(gm?.before ?? 0)}</Text>
409                <Text color={statusColor(c)}>{'━'.repeat(gm?.bar ?? 1)}</Text>
410                <Text color={C.faint}>{'·'.repeat(gm?.after ?? 0) + ' '}</Text>
411                {clock(`lane-clock-${c.id}`, c.spawnedAt, c.endedAt, C.dim)}
412              </Box>
413            )
414          })}
415        </Box>
416      )
417    }
418    const shown = cards.slice(-fit)
419    const cardW = Math.max(20, Math.floor((w - (shown.length - 1)) / shown.length))
420    const centers = shown.map((_, i) => i * (cardW + 1) + Math.floor(cardW / 2))
421    return (
422      <Box flexDirection="column" width={w}>
423        {header}
424        {rail('fan-out', running.length > 0, C.agent, w, centers)}
425        <Box columnGap={1}>
426          {shown.map((c, i) => {
427            const isViewed = viewed === c.id
428            const sameModel = !c.model || prettyModel(c.model) === modelName
429            return (
430              <Box
431                flexDirection="column"
432                borderStyle={isViewed ? 'double' : 'round'}
433                borderColor={c.lastStop === 'max_tokens' ? C.warn : C.agent}
434                borderDimColor={c.status !== 'running' && !isViewed}
435                width={cardW}
436                paddingX={1}
437              >
438                <Button key={`card-${c.id}`} plain label={titleLines(cardTitle(c), cardW - 7, cardW - 4)[0]} onPress={expandOnPress(c.id)} />
439                <Text bold wrap="truncate">
440                  {titleLines(cardTitle(c), cardW - 7, cardW - 4)[1]}
441                </Text>
442                <Text color={C.dim} wrap="truncate">
443                  {sameModel ? c.type : `${c.type} · ${prettyModel(c.model)}`}
444                </Text>
445                <Text dimColor wrap="truncate">
446                  {c.steps > 0 ? `ctx ${kTokens(c.ctx)} · out ${kTokens(c.out)} · ${c.steps} st` : 'starting…'}
447                </Text>
448                <Box>
449                  <Text color={c.lastStop === 'max_tokens' ? C.warn : statusColor(c)}>
450                    {cardW >= 26 ? `${glyph(c)} ${c.lastStop === 'max_tokens' ? 'max_tokens' : c.status} ` : `${glyph(c)} `}
451                  </Text>
452                  <Box flexShrink={0}>{clock(`card-clock-${c.id}`, c.spawnedAt, c.endedAt, C.dim)}</Box>
453                </Box>
454              </Box>
455            )
456          })}
457        </Box>
458        {rail('merge', running.length > 0, C.agent, w, centers, true)}
459      </Box>
460    )
461  }
462
463  const expandedCard = cards.find(c => c.id === v.expanded)
464  const expandedPanel = (w: number) =>
465    expandedCard ? (
466      <Box flexDirection="column" borderStyle="single" borderColor={C.agent} paddingX={1} width={w}>
467        <Text bold wrap="wrap">
468          {expandedCard.description || expandedCard.type}
469        </Text>
470        <Text dimColor wrap="truncate">{`${expandedCard.type} · ${prettyModel(expandedCard.model)} · ${expandedCard.status} · ${expandedCard.steps} steps`}</Text>
471        {expandedCard.tools.length === 0 ? <Text color={C.faint}>no tool calls yet</Text> : null}
472        {expandedCard.tools.map(n => (
473          <Text color={n.isError ? C.warn : C.text} wrap="truncate">
474            {`${n.isError ? '✗' : '·'} ${n.text}`}
475          </Text>
476        ))}
477        {expandedCard.answer ? (
478          <Text dimColor wrap="wrap">
479            {`» ${shorten(expandedCard.answer, 240)}`}
480          </Text>
481        ) : null}
482      </Box>
483    ) : null
484
485  // ---- other loops (workflow agents, forks): ids that match no card
486  const loopsPanel = (w: number) => {
487    if (lp.length === 0) return null
488    const active = lp.filter(l => isLoopActive(l, now)).length
489    const dots = lp.slice(-Math.max(4, w - 38))
490    return (
491      <Box width={w}>
492        <Text bold>other loops </Text>
493        <Text dimColor>{`${lp.length} seen · ${active} active  `}</Text>
494        {dots.map(l => (
495          <Text color={isLoopActive(l, now) ? C.agent : l.isDone ? C.dim : C.faint}>{isLoopActive(l, now) ? '●' : l.isDone ? '✓' : '○'}</Text>
496        ))}
497      </Box>
498    )
499  }
500
501  // ---- receipt: the turn now, or the last one
502  const receiptPanel = (w: number) => {
503    return (
504      <Box flexDirection="column" borderStyle="round" borderColor={C.main} borderDimColor={!m.isRunning} paddingX={1} width={w}>
505        {m.isRunning ? (
506          <Box>
507            <Text color={C.main} wrap="truncate">{`◐ back to ${modelName.toLowerCase()} · turn `}</Text>
508            <Box flexShrink={0}>{clock('turn-clock', t.startedAt, null, C.main)}</Box>
509            {w >= 60 ? <Text dimColor wrap="truncate">{` · ${plural(t.edits, 'edit')} · ${plural(t.errors, 'error')}`}</Text> : null}
510          </Box>
511        ) : r ? (
512          <Text wrap="truncate">
513            <Text color={r.reason === 'answer' ? C.gate : C.warn}>{r.reason === 'answer' ? '✓ ' : '✗ '}</Text>
514            <Text>{`last turn ${fmtDuration(r.durationMs)} · ${plural(r.agents, 'agent')} · ${plural(r.edits, 'edit')} · ${plural(r.errors, 'error')}`}</Text>
515            {r.costDelta !== null ? <Text color={C.main}>{` · +${fmtUsd(r.costDelta)}`}</Text> : null}
516          </Text>
517        ) : (
518          <Text color={C.faint}>no turn finished yet</Text>
519        )}
520      </Box>
521    )
522  }
523
524  // ---- tools: the busiest tools, their mean latency and recent failures
525  const toolUnits = top.map(([name, st]) => {
526    const mean = meanMs(st)
527    const dots = badDots(st)
528    return `${toolName(name)} ${mean === null ? '—' : `${(mean / 1000).toFixed(1)}s`}${dots > 0 ? ` ${'•'.repeat(dots)}` : ''}`
529  })
530  const toolsPanel = (w: number) =>
531    isDesktop ? (
532      <Box width={w} flexWrap="wrap" columnGap={2}>
533        <Text>TOOLS</Text>
534        {toolUnits.map(t => (
535          <Text>{t}</Text>
536        ))}
537      </Box>
538    ) : (
539      <Box width={w}>
540        <Text wrap="truncate">{`TOOLS  ${toolUnits.join('  ')}`}</Text>
541      </Box>
542    )
543
544  // ---- turn: tests, the file under churn, aborts, and the gate's tallies
545  const testsColor = deck.tests.light === 'pass' ? C.gate : C.warn
546  const hotColor = hot && hot.edits >= HOT_FILE_WARN ? C.amber : C.text
547  const hotText = hot ? `hot file ${lastSegments(hot.path)} ×${hot.edits}${hot.edits >= HOT_FILE_WARN ? ' ⚠' : ''}` : null
548  const gateText = `gate file ${sumTotals(g.totals.file)} · shell ${sumTotals(g.totals.shell)} · ask ${s.ask}`
549  const turnPanel = (w: number) =>
550    isDesktop ? (
551      <Box width={w} flexWrap="wrap" columnGap={3}>
552        <Text bold>TURN</Text>
553        {testsWord ? <Text color={testsColor}>{`tests ■ ${testsWord}`}</Text> : <Text dimColor>tests —</Text>}
554        {hotText ? <Text color={hotColor}>{hotText}</Text> : null}
555        <Text dimColor>{`aborts ${deck.aborts.count}`}</Text>
556        <Text dimColor>{gateText}</Text>
557      </Box>
558    ) : (
559      <Box width={w}>
560        <Text wrap="truncate">
561          <Text bold>TURN  </Text>
562          {testsWord ? <Text color={testsColor}>{`tests ■ ${testsWord}`}</Text> : <Text dimColor>tests —</Text>}
563          {hotText ? <Text color={hotColor}>{`   ${hotText}`}</Text> : null}
564          <Text dimColor>{`   aborts ${deck.aborts.count}`}</Text>
565          <Text dimColor>{`   ${gateText}`}</Text>
566        </Text>
567      </Box>
568    )
569
570  // ---- log: whatever rows the other panels leave, 4 to 8
571  const oneLiners = panels.filter(q => q === 'prompt' || q === 'tools' || q === 'turn').length
572  const agentRows = cards.length > 0 ? 1 + (hasCursorRow ? 1 : 0) : 0
573  const used =
574    2 + 5 + 6 + (v.gateOpen ? 5 : 0) + (cards.length > fitCards(colW) ? 3 + Math.min(6, cards.length) : 8) + (expandedCard ? 8 : 0) + (lp.length ? 1 : 0) + 3 + bandCost + oneLiners + agentRows
575  const nLog = logRows(pv.bodyRows, used)
576  const shownLines = (viewed ? lines.filter(l => l.agentId === viewed) : lines).slice(-nLog)
577  const colorOf = (l: LogLine) =>
578    l.kind === 'error' ? C.warn : l.who === 'main' ? C.main : l.who === 'gate' ? C.gate : l.who === 'you' ? C.text : C.agent
579  // The name column fits the longest name on screen, capped so the message keeps room, with a two-space gap after it.
580  const whoW = Math.min(LOG_WHO_MAX, Math.max(8, ...shownLines.map(l => l.who.length))) + 2
581  const logPanel = (w: number) => (
582    <Box flexDirection="column" borderStyle="round" borderColor={C.faint} paddingX={1} width={w}>
583      <Text dimColor>{viewed ? 'session log · this agent' : 'session log'}</Text>
584      {shownLines.length === 0 ? <Text color={C.faint}>nothing yet</Text> : null}
585      {shownLines.map(l => (
586        <Box>
587          <Box width={10} flexShrink={0}>
588            <Text color={C.faint}>{fmtClock(l.at)}</Text>
589          </Box>
590          <Box width={whoW} paddingRight={2} flexShrink={0}>
591            <Text color={colorOf(l)} bold wrap="truncate">
592              {l.who}
593            </Text>
594          </Box>
595          <Text color={l.kind === 'error' ? C.warn : C.text} wrap={isDesktop ? 'wrap' : 'truncate'}>
596            {l.text}
597          </Text>
598        </Box>
599      ))}
600    </Box>
601  )
602
603  const panelOf: Record<Panel, (w: number) => RenderElement | null> = {
604    main: mainPanel,
605    prompt: promptPanel,
606    gate: gatePanel,
607    agents: agentsPanel,
608    tools: toolsPanel,
609    turn: turnPanel,
610    loops: loopsPanel,
611    receipt: receiptPanel,
612    log: logPanel,
613  }
614
615  // One-line panels are transparent to the flow: a connector links the bordered panels around them.
616  const isOneLine = (q: Panel) => q === 'prompt' || q === 'tools' || q === 'turn'
617  const isUnlinked = (q: Panel | undefined) => q === undefined || q === 'agents' || q === 'loops'
618  const column = (ps: Panel[], w: number) => (
619    <Box flexDirection="column" width={w}>
620      {ps.map((q, i) => {
621        const prev = ps.slice(0, i).filter(x => !isOneLine(x)).at(-1)
622        const link = q === 'log' || isOneLine(q) || isUnlinked(q) || isUnlinked(prev) ? null : rail(`link-${q}`, m.isRunning, C.main, w)
623        return (
624          <Box flexDirection="column">
625            {link}
626            {panelOf[q](w)}
627            {q === 'agents' ? expandedPanel(w) : null}
628          </Box>
629        )
630      })}
631    </Box>
632  )
633
634  // Desktop draws the agents' time axis as SVG under the panels.
635  const svgLanes =
636    Svg && cards.length > 0
637      ? (() => {
638          const rowH = 18
639          const pxW = 520
640          const geo = lanes(cards.slice(-10), now, 100)
641          const rects = cards
642            .slice(-10)
643            .map((c, i) => {
644              const gm = geo[i]
645              const x = 150 + ((gm?.before ?? 0) / 100) * (pxW - 160)
646              const wpx = Math.max(3, ((gm?.bar ?? 1) / 100) * (pxW - 160))
647              const fill = c.status === 'running' ? SVG_COLORS.running : c.status === 'done' ? SVG_COLORS.done : c.status === 'failed' ? SVG_COLORS.failed : SVG_COLORS.other
648              const label = shorten(cardTitle(c), 22).replace(/[<&>]/g, '')
649              return `<text x="4" y="${i * rowH + 13}" font-size="11" fill="${SVG_COLORS.label}">${label}</text><rect x="${x}" y="${i * rowH + 4}" width="${wpx}" height="10" rx="3" fill="${fill}"/>`
650            })
651            .join('')
652          const svgH = Math.min(10, cards.length) * rowH + 4
653          return (
654            <Svg
655              source={`<svg xmlns="http://www.w3.org/2000/svg" width="${pxW}" height="${svgH}" viewBox="0 0 ${pxW} ${svgH}">${rects}</svg>`}
656              alt={`${cards.length} agents on a time axis`}
657              width={pxW}
658              height={svgH}
659            />
660          )
661        })()
662      : null
663
664  // Inline above the prompt (the terminal's main screen), the pane is a summary of at most 8 rows.
665  const isMini = layout === 'mini' || (layout === 'auto' && pv.placement === 'inline')
666  if (isMini) {
667    const live = [...cards.filter(c => c.status === 'running'), ...cards.filter(c => c.status !== 'running').reverse()].slice(0, 3)
668    const counts = ` ${s.rule} allowed · ${s.cleared} ${decider}${s.ask > 0 ? ` · ${s.ask} pending` : ''} · ${s.deny} denied`
669    const strip = g.recent.slice(-Math.max(4, W - GATE_LABEL.length - 1 - counts.length))
670    const mg = u.pct !== null ? gauge(u.pct, 6) : null
671    const hasSignals = deck.prompt.status !== 'idle' || testsWord !== null || deck.aborts.count > 0 || hot !== null
672    return (
673      <Box flexDirection="column" width={W}>
674        <Text wrap="truncate">
675          <Text color={C.main} bold>
676            {modelName}
677          </Text>
678          <Text color={m.isRunning ? C.main : C.dim}>{m.isRunning ? ' ● working' : ' ○ idle'}</Text>
679          {mg ? <Text dimColor> · ctx </Text> : null}
680          {mg ? <Text color={(u.pct ?? 0) >= 80 ? C.warn : C.main}>{mg.on}</Text> : null}
681          {mg ? <Text color={C.faint}>{mg.off}</Text> : null}
682          {mg ? <Text>{` ${Math.round(u.pct ?? 0)}%`}</Text> : null}
683          {u.compactions > 0 ? <Text color={C.amber}>{` ⟲${u.compactions}`}</Text> : null}
684          {hasCache ? <Text dimColor>{` · cache ${cachePct}%`}</Text> : null}
685          {u.costUsd !== null ? <Text dimColor>{` · ${fmtUsd(u.costUsd)}`}</Text> : null}
686        </Text>
687        {strip.length > 0 ? (
688          <Box>
689            <Text dimColor>{`${GATE_LABEL.toLowerCase()} `}</Text>
690            {strip.map(c => (
691              <Text color={verdictColor(c)} dimColor={c.inSubagent}>
692                {c.verdict === 'deny' ? '✗' : '■'}
693              </Text>
694            ))}
695            <Text color={s.deny > 0 ? C.warn : s.ask > 0 ? C.amber : C.dim} wrap="truncate">
696              {counts}
697            </Text>
698          </Box>
699        ) : null}
700        {live.map(c => (
701          <Box>
702            <Text color={statusColor(c)}>{`${glyph(c)} `}</Text>
703            <Box width={Math.max(10, W - 30)}>
704              <Text wrap="truncate">{cardTitle(c)}</Text>
705            </Box>
706            <Text dimColor>{c.steps > 0 ? ` ctx ${kTokens(c.ctx)} ` : ' '}</Text>
707            {clock(`mini-clock-${c.id}`, c.spawnedAt, c.endedAt, C.dim)}
708          </Box>
709        ))}
710        {cards.length > live.length ? (
711          <Text color={C.faint} wrap="truncate">{`+${cards.length - live.length} more agents · /sessiondeck layout compact for all`}</Text>
712        ) : null}
713        {hasSignals ? (
714        <Text dimColor wrap="truncate">
715          {`"${shorten(deck.prompt.text, 24)}" ${promptStatus} · tests ${testsWord ?? '—'} · aborts ${deck.aborts.count}${hot ? ` · hot ${lastSegments(hot.path)} ×${hot.edits}` : ''}${lp.length > 0 ? ` · loops ${lp.length}` : ''}`}
716        </Text>
717        ) : null}
718        {!m.isRunning && r ? (
719          <Text dimColor wrap="truncate">
720            {`last turn ${fmtDuration(r.durationMs)} · ${plural(r.agents, 'agent')} · ${plural(r.edits, 'edit')} · ${plural(r.errors, 'error')}${r.costDelta !== null ? ` · +${fmtUsd(r.costDelta)}` : ''}`}
721          </Text>
722        ) : null}
723      </Box>
724    )
725  }
726
727  const legend = fitLegend(
728    [
729      { label: 'main', color: C.main },
730      { label: 'agents', color: C.agent },
731      { label: GATE_LABEL.toLowerCase(), color: C.gate },
732    ],
733    W,
734  )
735
736  const sinceWindow = now - windowMinutes(chartInput) * 60_000
737  const inWindow = <T extends { at: number }>(samples: T[]) => samples.filter(x => x.at >= sinceWindow)
738  const ctxPct = u.pct ?? deck.context.history.at(-1)?.percent ?? null
739  const bandTitle = bandTitles({
740    contextPct: ctxPct,
741    cachePct: hasCache ? cachePct : null,
742    compacted: inWindow(deck.context.history).some(x => x.compacted),
743    running: tally.spawning + tally.running,
744    done: tally.done,
745    error: tally.error,
746    dropped,
747    minutes: windowMinutes(chartInput),
748    peak: Math.max(0, ...inWindow(deck.agents.history).map(x => x.running + x.done + x.error)),
749  })
750  const bandPanel = (p: BandPanel) => {
751    const title = fitTitle(bandTitle[p.key], titleColumns(p))
752    return (
753      <Box flexDirection="column" borderStyle="round" borderColor={C.faint} width={p.width}>
754        <Box paddingLeft={1} width={p.width - 2}>
755          <Text wrap="truncate">
756            {title.parts.map((part, i) => (
757              <Text>
758                {i > 0 ? <Text color={C.faint}>{title.sep}</Text> : null}
759                {part.swatch ? <Text color={chartHex(chartPalette, part.swatch.ch)}>{part.swatch.glyph}</Text> : null}
760                {part.text}
761              </Text>
762            ))}
763          </Text>
764        </Box>
765        {Raster ? <Raster key={`band-${p.key}`} columns={p.width - 2} rows={nBand} cells={encodeCells(p.grid, chartPalette).cells} /> : null}
766        {DesktopSvg ? (
767          <Box key={`band-${p.key}`} width={p.width - 2}>
768            <DesktopSvg
769              source={gridSvg(p.grid, chartPalette)}
770              alt={title.parts.map(part => part.text.trim()).filter(Boolean).join(', ')}
771              width={(p.width - 2) * CELL_PX}
772              height={p.grid.length * CELL_PX}
773            />
774          </Box>
775        ) : null}
776      </Box>
777    )
778  }
779
780  const body = isWide ? (
781    <Box flexDirection="column">
782      <Box columnGap={2}>
783        {column(panels.filter(q => q === 'main' || q === 'prompt' || q === 'gate'), colW)}
784        {column(panels.filter(q => q === 'agents' || q === 'tools' || q === 'turn' || q === 'loops' || q === 'receipt'), colW)}
785      </Box>
786      {panels.includes('log') ? logPanel(W) : null}
787    </Box>
788  ) : (
789    column(panels, W)
790  )
791
792  return (
793    <Box flexDirection="column" width={W} backgroundColor={C.bg}>
794      {band ? <Box>{band.panels.map(bandPanel)}</Box> : null}
795      <Box justifyContent="center">
796        <Text bold wrap="truncate">
797          <Text>SESSIONDECK</Text>
798          <Text color={C.dim}> · </Text>
799          <Text color={C.main}>{modelName.toUpperCase()}</Text>
800          <Text>{m.isRunning ? ' WORKS' : ' IDLE'}</Text>
801        </Text>
802      </Box>
803      <Box justifyContent="center" columnGap={2}>
804        {legend.map(l => (
805          <Text>
806            <Text color={l.color}>■</Text>
807            <Text dimColor>{` ${l.label}`}</Text>
808          </Text>
809        ))}
810      </Box>
811      {body}
812      {svgLanes}
813    </Box>
814  )
815}
816

1import type { AgentCard, AgentSample, ContextSample } from '../types'
2import { gridOrder, laneOf, stateOf, type Palette as ThemePalette, type TitlePart } from './core'
3import type { Palette as RasterPalette } from './raster'
4
5export type Grid = string[]
6export type ChartInput = { context: ContextSample[]; history: AgentSample[]; cards: AgentCard[]; cursor: number | null; now: number; minutes: number }
7
8export const CHART_COLORS: RasterPalette = {
9  '.': null,
10  c: 0x7dd3fc,
11  t: 0xfcd34d,
12  h: 0x3f4654,
13  s: 0x6b7280,
14  r: 0x3b82f6,
15  d: 0x16a34a,
16  e: 0xdc2626,
17  u: 0xf59e0b,
18  A: 0x93c5fd,
19  B: 0xc4b5fd,
20  C: 0x86efac,
21  D: 0xfca5a5,
22  E: 0x5eead4,
23  F: 0xe5e7eb,
24}
25
26const DRACULA_COLORS: RasterPalette = {
27  '.': null,
28  c: 0x8be9fd,
29  t: 0xf1fa8c,
30  h: 0x44475a,
31  s: 0x6272a4,
32  r: 0xbd93f9,
33  d: 0x50fa7b,
34  e: 0xff5555,
35  u: 0xffb86c,
36  A: 0x8be9fd,
37  B: 0xbd93f9,
38  C: 0x50fa7b,
39  D: 0xff79c6,
40  E: 0xf1fa8c,
41  F: 0xf8f8f2,
42}
43
44export const chartColors = (palette: ThemePalette): RasterPalette => (palette === 'dracula' ? DRACULA_COLORS : CHART_COLORS)
45
46const LANE_BARS = 'ABCDEF'
47const STATE_CHAR = { spawning: 's', running: 'r', done: 'd', error: 'e' } as const
48
49export const blank = (width: number, height: number): Grid => Array.from({ length: Math.max(0, height) }, () => '.'.repeat(Math.max(0, width)))
50
51const put = (grid: Grid, x: number, y: number, ch: string) => {
52  const row = grid[y]
53  if (row === undefined || x < 0 || x >= row.length || !Number.isInteger(x)) return
54  grid[y] = row.slice(0, x) + ch + row.slice(x + 1)
55}
56
57const fillUp = (grid: Grid, x: number, from: number, to: number, ch: string) => {
58  const height = grid.length
59  for (let p = from; p < to; p++) put(grid, x, height - 1 - p, ch)
60}
61
62// Both charts span the session so far, at least a minute and at most `minutes`, so a young
63// session fills the width and the two x axes agree.
64const windowMs = (i: ChartInput): number => {
65  const full = i.minutes * 60_000
66  const ats = [...i.context, ...i.history].map(s => s.at)
67  if (ats.length === 0) return full
68  return Math.max(60_000, Math.min(full, i.now - Math.min(...ats)))
69}
70
71export const windowMinutes = (i: ChartInput): number => Math.max(1, Math.round(windowMs(i) / 60_000))
72
73// Column x shows the latest sample before its end, so a sample holds until the next one replaces it.
74const byColumn = <T extends { at: number }>(samples: T[], i: ChartInput, width: number): (T | null)[] => {
75  const window = windowMs(i)
76  const span = window / width
77  const start = i.now - window
78  return Array.from({ length: width }, (_, x) => {
79    const end = start + (x + 1) * span
80    let best: T | null = null
81    for (const s of samples) if (s.at < end && (best === null || s.at >= best.at)) best = s
82    return best
83  })
84}
85
86export const contextChart = (i: ChartInput, width: number, height: number): Grid => {
87  const grid = blank(width, height)
88  byColumn(i.context, i, width).forEach((s, x) => {
89    if (s === null) return
90    if (s.compacted) return fillUp(grid, x, 0, height, 't')
91    fillUp(grid, x, 0, Math.round((s.percent / 100) * height), 'c')
92    put(grid, x, height - 1 - Math.round(s.cacheHit * (height - 1)), 'h')
93  })
94  return grid
95}
96
97export const historyChart = (i: ChartInput, width: number, height: number): Grid => {
98  const grid = blank(width, height)
99  const cols = byColumn(i.history, i, width)
100  const y = Math.max(1, ...cols.map(s => (s === null ? 0 : s.running + s.done + s.error)))
101  cols.forEach((s, x) => {
102    if (s === null) return
103    const r = Math.round((s.running / y) * height)
104    const d = Math.round(((s.running + s.done) / y) * height)
105    const e = Math.round(((s.running + s.done + s.error) / y) * height)
106    fillUp(grid, x, 0, r, 'r')
107    fillUp(grid, x, r, d, 'd')
108    fillUp(grid, x, d, e, 'e')
109  })
110  return grid
111}
112
113type Placed = { card: AgentCard; index: number; x: number; y: number }
114type Bar = { lane: number; y: number; to: number }
115type Layout = { size: 4 | 2 | 1; placed: Placed[]; bars: Bar[]; dropped: number }
116
117// Each lane starts a new cell row behind a 1 px bar; cell rows that fall below the area are dropped.
118const layout = (cards: AgentCard[], width: number, height: number, size: 4 | 2 | 1): Layout => {
119  const gap = size === 1 ? 0 : 1
120  const step = size + gap
121  const perRow = Math.floor((width - 2 + gap) / step)
122  const rows = Math.floor((height + gap) / step)
123  const ordered = gridOrder(cards)
124  const placed: Placed[] = []
125  const bars: Bar[] = []
126  let row = 0
127  let lane = -1
128  let prev: string | null = null
129  let col = 0
130  ordered.forEach((card, index) => {
131    const name = laneOf(card)
132    if (name !== prev) {
133      if (prev !== null) row++
134      prev = name
135      lane++
136      col = 0
137    } else if (col === perRow) {
138      row++
139      col = 0
140    }
141    if (perRow > 0 && row < rows) {
142      const y = row * step
143      placed.push({ card, index, x: 2 + col * step, y })
144      const last = bars.at(-1)
145      if (last !== undefined && last.lane === lane) last.to = y + size
146      else bars.push({ lane, y, to: y + size })
147    }
148    col++
149  })
150  return { size, placed, bars, dropped: ordered.length - placed.length }
151}
152
153const SIZES = [4, 2, 1] as const
154
155export const cellSize = (cards: AgentCard[], width: number, height: number): 4 | 2 | 1 =>
156  SIZES.find(size => layout(cards, width, height, size).dropped === 0) ?? 1
157
158export const agentGrid = (i: ChartInput, width: number, height: number): { grid: Grid; dropped: number } => {
159  const grid = blank(width, height)
160  const { size, placed, bars, dropped } = layout(i.cards, width, height, cellSize(i.cards, width, height))
161  for (const b of bars) for (let y = b.y; y < b.to; y++) put(grid, 0, y, LANE_BARS.charAt(b.lane % LANE_BARS.length))
162  for (const p of placed) {
163    const isCursor = p.index === i.cursor
164    const fill = isCursor && size < 4 ? 'u' : STATE_CHAR[stateOf(p.card)]
165    for (let dy = 0; dy < size; dy++)
166      for (let dx = 0; dx < size; dx++) {
167        const isEdge = dx === 0 || dy === 0 || dx === size - 1 || dy === size - 1
168        put(grid, p.x + dx, p.y + dy, isCursor && isEdge ? 'u' : fill)
169      }
170  }
171  return { grid, dropped }
172}
173
174export type BandPanel = { key: 'context' | 'agents' | 'history'; width: number; grid: Grid }
175
176// The title row loses the two border columns and its one column of left padding.
177export const titleColumns = (p: BandPanel) => p.width - 3
178
179export type TitleFacts = {
180  contextPct: number | null
181  cachePct: number | null
182  compacted: boolean
183  running: number
184  done: number
185  error: number
186  dropped: number
187  minutes: number
188  peak: number
189}
190
191const pct = (n: number | null) => (n === null ? '—' : `${Math.round(n)}`)
192
193// The short context form drops `%` so context, cache and the compaction mark all fit at 100% in the 60-column floor.
194export const bandTitles = (f: TitleFacts): Record<BandPanel['key'], TitlePart[]> => ({
195  context: [
196    { swatch: { glyph: '■', ch: 'c' }, text: ` context ${f.contextPct === null ? '—' : `${pct(f.contextPct)}%`}`, short: ` ctx ${pct(f.contextPct)}` },
197    { swatch: { glyph: '■', ch: 'h' }, text: ` cache ${f.cachePct === null ? '—' : `${pct(f.cachePct)}%`}`, short: ` cache ${pct(f.cachePct)}` },
198    ...(f.compacted ? [{ swatch: { glyph: '▌', ch: 't' }, text: 'compact', short: '' }] : []),
199  ],
200  agents: [
201    { swatch: { glyph: '■', ch: 'r' }, text: ` ${f.running} run`, short: ` ${f.running}` },
202    { swatch: { glyph: '■', ch: 'd' }, text: ` ${f.done} done`, short: ` ${f.done}` },
203    { swatch: { glyph: '■', ch: 'e' }, text: ` ${f.error} err`, short: ` ${f.error}` },
204    ...(f.dropped > 0 ? [{ text: `+${f.dropped} off-grid`, short: `+${f.dropped}` }] : []),
205  ],
206  history: [
207    { text: `history ${f.minutes}m`, short: `${f.minutes}m` },
208    { text: `peak ${f.peak}`, short: `↑${f.peak}` },
209  ],
210})
211
212// Each panel's grid is its width less the two border columns.
213export const bandPanels = (i: ChartInput, width: number, height: number): { panels: BandPanel[]; dropped: number } => {
214  if (i.cards.length === 0) return { panels: [{ key: 'context', width, grid: contextChart(i, width - 2, height) }], dropped: 0 }
215  const c = Math.floor(0.4 * width)
216  const g = Math.floor(0.3 * width)
217  const h = width - c - g
218  const agents = agentGrid(i, g - 2, height)
219  return {
220    panels: [
221      { key: 'context', width: c, grid: contextChart(i, c - 2, height) },
222      { key: 'agents', width: g, grid: agents.grid },
223      { key: 'history', width: h, grid: historyChart(i, h - 2, height) },
224    ],
225    dropped: agents.dropped,
226  }
227}
228

1// The runtime ships these (RasterProps documents toBase64); lib es2023 has no types for them.
2declare global {
3  interface Uint8Array { toBase64(): string }
4  interface Uint8ArrayConstructor { fromBase64(base64: string): Uint8Array }
5}
6
7export type Palette = Record<string, number | null>
8
9export const DEFAULT_COLOR = 0x01000000
10
11const UPPER = 0x2580
12const LOWER = 0x2584
13const SPACE = 0x20
14
15type Color = number | null
16
17const cell = (top: Color, bottom: Color): [number, number, number] => {
18  if (top === null) return bottom === null ? [SPACE, DEFAULT_COLOR, DEFAULT_COLOR] : [LOWER, bottom, DEFAULT_COLOR]
19  return [UPPER, top, bottom ?? DEFAULT_COLOR]
20}
21
22const colorAt = (row: string | undefined, x: number, palette: Palette): Color =>
23  palette[row?.[x] ?? '.'] ?? null
24
25export const encodeCells = (grid: readonly string[], palette: Palette): { columns: number; rows: number; cells: string } => {
26  const columns = grid[0]?.length ?? 0
27  const rows = Math.ceil(grid.length / 2)
28  const words = new Uint32Array(columns * rows * 3)
29  for (let y = 0; y < rows; y++) {
30    for (let x = 0; x < columns; x++) {
31      const top = colorAt(grid[2 * y], x, palette)
32      const bottom = colorAt(grid[2 * y + 1], x, palette)
33      words.set(cell(top, bottom), (y * columns + x) * 3)
34    }
35  }
36  return { columns, rows, cells: new Uint8Array(words.buffer).toBase64() }
37}
38
39export const decodeCells = (cells: string): Uint32Array => {
40  const bytes = Uint8Array.fromBase64(cells)
41  return new Uint32Array(bytes.buffer, bytes.byteOffset, bytes.byteLength / 4)
42}
43
44export const upscale2x = (grid: readonly string[]): string[] =>
45  grid.flatMap(row => {
46    const wide = [...row].map(c => c + c).join('')
47    return [wide, wide]
48  })
49

1import type { Grid } from './charts'
2import type { Palette } from './raster'
3
4// A grid pixel is half a terminal cell, about square; 7 px keeps a cell inside the desktop's code-font advance.
5export const CELL_PX = 7
6
7const SEG_W = 6
8const SEG_GAP = 2
9const SEG_H = 8
10
11export const hex = (n: number) => `#${n.toString(16).padStart(6, '0')}`
12
13/** The band's palette grid as SVG: one rect per run of a color along a row, in grid units. */
14export const gridSvg = (grid: Grid, palette: Palette): string => {
15  const columns = grid[0]?.length ?? 0
16  const rows = grid.length
17  const rects: string[] = []
18  grid.forEach((row, y) => {
19    let x = 0
20    while (x < row.length) {
21      const ch = row.charAt(x)
22      let end = x + 1
23      while (end < row.length && row.charAt(end) === ch) end++
24      const color = palette[ch] ?? null
25      if (color !== null) rects.push(`<rect x="${x}" y="${y}" width="${end - x}" height="1" fill="${hex(color)}"/>`)
26      x = end
27    }
28  })
29  return `<svg xmlns="http://www.w3.org/2000/svg" width="${columns * CELL_PX}" height="${rows * CELL_PX}" viewBox="0 0 ${columns} ${rows}" preserveAspectRatio="none" shape-rendering="crispEdges">${rects.join('')}</svg>`
30}
31
32type Gauge = { on: string; off: string }
33
34const segments = (g: Gauge) => [...g.on].length + [...g.off].length
35export const gaugeWidth = (g: Gauge) => Math.max(0, segments(g) * (SEG_W + SEG_GAP) - SEG_GAP)
36export const GAUGE_HEIGHT = SEG_H + 2
37
38/** A text gauge (`▰▰▱`) as SVG segments: filled in `on`, outlined in `off`. */
39export const gaugeSvg = (g: Gauge, on: string, off: string): string => {
40  const full = [...g.on].length
41  const segs = Array.from({ length: segments(g) }, (_, i) => {
42    const x = i * (SEG_W + SEG_GAP)
43    return i < full
44      ? `<rect x="${x}" y="1" width="${SEG_W}" height="${SEG_H}" rx="1.5" fill="${on}"/>`
45      : `<rect x="${x + 0.5}" y="1.5" width="${SEG_W - 1}" height="${SEG_H - 1}" rx="1.5" fill="none" stroke="${off}"/>`
46  })
47  return `<svg xmlns="http://www.w3.org/2000/svg" width="${gaugeWidth(g)}" height="${GAUGE_HEIGHT}" viewBox="0 0 ${gaugeWidth(g)} ${GAUGE_HEIGHT}">${segs.join('')}</svg>`
48}
49

1// A connector drawn on the surface's own frame clock: packets travel along it while `active`,
2// and it rests as a plain dim line otherwise. Only this region redraws; the pane does not.
3import type { ClientModule } from 'claude-code'
4
5type Props = {
6  active: boolean
7  width: number
8  color: string
9  dim: string
10  /** Cells where a branch drops (┬); the rest of the line is ─. */
11  marks: number[]
12  /** Draw ┴ instead of ┬ at the marks: a merge into what is below. */
13  isMerge: boolean
14}
15
16type Ref = { phase: number; active: boolean }
17type State = { ref: Ref }
18
19const STEP_MS = 110
20
21const Rail: ClientModule<Props, State> = (props, surface) => {
22  const { Box, Text } = surface.elements
23  const ref = surface.state?.ref ?? { phase: 0, active: props.active }
24  ref.active = props.active
25  if (surface.state === undefined) {
26    surface.setState({ ref })
27    surface.every(STEP_MS, () => {
28      if (ref.active) {
29        ref.phase += 1
30        surface.setState({ ref })
31      }
32    })
33  }
34
35  const width = Math.max(1, surface.columns || props.width)
36  const cells = Array.from({ length: width }, () => '─')
37  for (const m of props.marks) if (m >= 0 && m < width) cells[m] = props.isMerge ? '┴' : '┬'
38
39  if (!props.active) {
40    return (
41      <Box>
42        <Text color={props.dim}>{cells.join('')}</Text>
43      </Box>
44    )
45  }
46
47  // Two packets per 24 cells, a bright head and a trailing dot, moving left to right.
48  const lit = new Map<number, string>()
49  for (let base = 0; base < width + 24; base += 24) {
50    const head = (base + ref.phase) % (width + 24)
51    if (head < width) lit.set(head, '●')
52    if (head - 1 >= 0 && head - 1 < width) lit.set(head - 1, '•')
53  }
54  // Runs, not cells: consecutive cells of one kind share a Text, a handful of nodes per frame.
55  const runs: { text: string; isLit: boolean }[] = []
56  cells.forEach((ch, i) => {
57    const isLit = lit.has(i)
58    const last = runs[runs.length - 1]
59    const glyph = lit.get(i) ?? ch
60    if (last && last.isLit === isLit) last.text += glyph
61    else runs.push({ text: glyph, isLit })
62  })
63  return (
64    <Box>
65      {runs.map(r => (
66        <Text color={r.isLit ? props.color : props.dim} bold={r.isLit}>
67          {r.text}
68        </Text>
69      ))}
70    </Box>
71  )
72}
73
74export default Rail
75

1// A running agent's clock, ticking on the surface's frame clock so the pane need not redraw.
2// `since` and `now` come from the hooks module's $.clock; between redraws it adds its own ticks.
3import type { ClientModule } from 'claude-code'
4
5type Props = { since: number; now: number; endAt: number | null; color: string }
6type Ref = { base: number; ticks: number; lastNow: number; isRunning: boolean }
7type State = { ref: Ref }
8
9const fmt = (ms: number) => {
10  const s = Math.max(0, Math.floor(ms / 1000))
11  const m = Math.floor(s / 60)
12  return m < 60 ? `${m}:${String(s % 60).padStart(2, '0')}` : `${Math.floor(m / 60)}h${String(m % 60).padStart(2, '0')}`
13}
14
15const Elapsed: ClientModule<Props, State> = (props, surface) => {
16  const { Text } = surface.elements
17  const ref = surface.state?.ref ?? { base: 0, ticks: 0, lastNow: -1, isRunning: true }
18  if (props.now !== ref.lastNow) {
19    // A fresh reading from the hooks module: restart the local count from it.
20    ref.lastNow = props.now
21    ref.base = (props.endAt ?? props.now) - props.since
22    ref.ticks = 0
23  }
24  ref.isRunning = props.endAt === null
25  if (surface.state === undefined) {
26    surface.setState({ ref })
27    surface.every(1000, () => {
28      if (ref.isRunning) {
29        ref.ticks += 1
30        surface.setState({ ref })
31      }
32    })
33  }
34  return <Text color={props.color}>{fmt(ref.base + ref.ticks * 1000)}</Text>
35}
36
37export default Elapsed
38

1export type Bucket = 'file' | 'shell' | 'other'
2
3/** rule: settings allowed it. ask: put to the decider, outcome pending. cleared: asked, then ran. deny: refused. */
4export type Verdict = 'rule' | 'ask' | 'cleared' | 'deny'
5
6export type Main = { model: string; effort: string; mode: string; steps: number; isRunning: boolean }
7
8export type Usage = {
9  pct: number | null
10  tokens: number | null
11  window: number
12  costUsd: number | null
13  limits: { kind: string; pct: number }[]
14  compactions: number
15  lastCompactAt: number | null
16}
17
18export type Check = {
19  id: string
20  tool: string
21  bucket: Bucket
22  verdict: Verdict
23  inSubagent: boolean
24  detail: string
25  at: number
26}
27
28export type Tally = { rule: number; ask: number; cleared: number; deny: number }
29
30export type Gate = { recent: Check[]; totals: Record<Bucket, Tally> }
31
32export type ToolNote = { tool: string; text: string; isError: boolean }
33
34export type AgentCard = {
35  id: string
36  type: string
37  model: string
38  description: string
39  status: string
40  spawnedAt: number
41  endedAt: number | null
42  /** The agent's context now: input + cache read + cache write of its latest step. */
43  ctx: number
44  /** Output tokens summed over its steps. */
45  out: number
46  steps: number
47  lastStop: string | null
48  tools: ToolNote[]
49  answer: string
50  parentAgentId: string | null
51}
52
53/** A model loop whose id matches no card: a workflow agent, a compaction or a memory fork. */
54export type Loop = { id: string; steps: number; firstAt: number; lastAt: number; isDone: boolean }
55
56export type LogLine = {
57  at: number
58  who: string
59  text: string
60  agentId: string | null
61  kind: 'info' | 'error' | 'done'
62}
63
64export type Turn = {
65  edits: number
66  errorStreak: number
67  errors: number
68  startedAt: number
69  costAtStart: number | null
70  /** Agents this session when the turn started, so the receipt counts the turn's own. */
71  agentsAtStart: number
72}
73
74export type Receipt = {
75  durationMs: number
76  agents: number
77  edits: number
78  errors: number
79  costDelta: number | null
80  reason: string
81  /** Absent on a receipt saved before this field existed. */
82  startedAt?: number
83}
84
85export type Layout = 'auto' | 'compact' | 'wide' | 'mini'
86
87export type View = { expanded: string | null; gateOpen: Bucket | null; layout: Layout | null; cursor: number | null }
88
89export type PromptStatus = 'idle' | 'running' | 'done' | 'aborted'
90
91export type Prompt = { text: string; startedAt: number | null; status: PromptStatus }
92
93export type Cache = { read: number; input: number; creation: number }
94
95export type ToolStat = { calls: number; errors: number; denies: number; recentMs: number[]; recentOk: boolean[]; lastOk: boolean }
96
97export type Tools = Record<string, ToolStat>
98
99/** File path to edits this turn. */
100export type HotFiles = Record<string, number>
101
102export type Tests = { light: 'off' | 'pass' | 'fail'; pass: number; fail: number; lastAt: number | null }
103
104export type Aborts = { count: number; at: number[]; turnIds: string[] }
105
106export type AgentState = 'spawning' | 'running' | 'done' | 'error'
107
108export type AgentTally = { spawning: number; running: number; done: number; error: number }
109
110export type AgentSample = { at: number; running: number; done: number; error: number }
111
112/** `byType` holds only the tallies of cards the cap dropped. */
113export type Agents = { byType: Record<string, AgentTally>; history: AgentSample[] }
114
115export type ContextSample = { at: number; percent: number; cacheHit: number; compacted: boolean }
116
117export type Context = { history: ContextSample[]; compactPending: boolean; lastPercent: number | null }
118
119declare module 'claude-code' {
120  interface PluginState {
121    'sessiondeck': {
122      meta: { schemaVersion: number }
123      main: Main
124      usage: Usage
125      gate: Gate
126      agents: AgentCard[]
127      loops: Loop[]
128      log: LogLine[]
129      turn: Turn
130      receipt: Receipt | null
131      view: View
132      prompt: Prompt
133      cache: Cache
134      tools: Tools
135      hotFiles: HotFiles
136      tests: Tests
137      aborts: Aborts
138      agentStats: Agents
139      context: Context
140    }
141  }
142}
143
