usage-bars

1import { atom, read, update } from 'claude-code'
2import type { Register } from 'claude-code'
3
4import { accentOf, barSvg, formatCost, formatReset, toGauges } from './gauge'
5
6const gauges = atom({ plugin: 'usage-bars', key: 'gauges' } as const, null)
7const cost = atom({ plugin: 'usage-bars', key: 'cost' } as const, null)
8const BAR_WIDTH = 88
9const BAR_HEIGHT = 10
10// The layout counts character cells (~8px each), not pixels: reserve them.
11const BAR_CELLS = Math.ceil(BAR_WIDTH / 8)
12const TRACK = '#2a2e3f'
13
14export const register: Register = on => {
15  on('session.measure', async ($, e, next) => {
16    await update($, gauges, () => toGauges(e))
17    await update($, cost, () => e.cost?.usd ?? null)
18    return next(e)
19  })
20
21  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
22    if (e.props.hasSurvey || e.surface === 'terminal') return next(e)
23
24    const usage = await $.session.usage()
25    const items = (await read($, gauges)) ?? toGauges(usage)
26    const spent = (await read($, cost)) ?? usage.cost?.usd ?? null
27    const now = await $.clock.now()
28    const { Box, Text, Svg } = $.ui.resolve(e)
29
30    return (
31      <Box gap={2} paddingX={1} alignItems="center">
32        {items.map(g => {
33          const reset = formatReset(g.resetsAt, now)
34          return (
35            <Box key={g.label} gap={1} alignItems="center">
36              <Text dimColor>{g.label}</Text>
37              <Box width={BAR_CELLS} flexShrink={0}>
38                <Svg
39                  source={barSvg(g, BAR_WIDTH, BAR_HEIGHT, TRACK)}
40                  alt={`${g.label} ${Math.round(g.percent)}%`}
41                  width={BAR_WIDTH}
42                  height={BAR_HEIGHT}
43                />
44              </Box>
45              <Text bold color={accentOf(g)}>{Math.round(g.percent)}%</Text>
46              {g.detail ? <Text dimColor>{g.detail}</Text> : null}
47              {reset ? <Text dimColor>↻{reset}</Text> : null}
48            </Box>
49          )
50        })}
51        {spent !== null ? (
52          <Box key="cost" gap={1}>
53            <Text dimColor>spent</Text>
54            <Text bold color="#cbb68c">{formatCost(spent)}</Text>
55          </Box>
56        ) : null}
57      </Box>
58    )
59  })
60}
61

1import type { Gauge } from '../types'
2
3type Usage = {
4  context: { percent?: number; tokens?: number; window: number }
5  rateLimits: { kind: string; percentUsed: number; resetsAt?: string }[]
6  cost?: { usd: number }
7}
8
9const LABELS: Record<string, string> = { five_hour: '5h', seven_day: '7d', spend_limit: 'spend' }
10
11// Gradient start/end per gauge; any gauge past 85% turns to the hot palette.
12const PALETTES: Record<string, [string, string]> = {
13  context: ['#5a7ca3', '#86a3c7'],
14  '5h': ['#8379ab', '#a89ec8'],
15  '7d': ['#5f9488', '#8fb8aa'],
16  spend: ['#a89166', '#cbb68c'],
17}
18const HOT: [string, string] = ['#c58a5c', '#c3665f']
19
20const compact = (n: number) => (n >= 1000 ? `${Math.round(n / 1000)}k` : `${n}`)
21
22// Context always; subscription windows when the account reports them. Without
23// any window (API key), the context bar also carries its token counts.
24export const toGauges = (u: Usage): Gauge[] => {
25  const windows = u.rateLimits.filter(r => LABELS[r.kind])
26  const detail =
27    windows.length === 0 && u.context.tokens !== undefined
28      ? `${compact(u.context.tokens)}/${compact(u.context.window)}`
29      : undefined
30  return [
31    { label: 'context', percent: u.context.percent ?? 0, detail },
32    ...windows.map(r => ({ label: LABELS[r.kind], percent: r.percentUsed, resetsAt: r.resetsAt })),
33  ]
34}
35
36export const formatCost = (usd: number) => `$${usd < 10 ? usd.toFixed(2) : usd.toFixed(1)}`
37
38const channel = (hex: string, i: number) => parseInt(hex.slice(1 + i * 2, 3 + i * 2), 16)
39
40const mix = (a: string, b: string, t: number) =>
41  '#' +
42  [0, 1, 2]
43    .map(i => Math.round(channel(a, i) + (channel(b, i) - channel(a, i)) * t).toString(16).padStart(2, '0'))
44    .join('')
45
46const paletteOf = (g: Gauge) => (g.percent >= 85 ? HOT : (PALETTES[g.label] ?? PALETTES.context))
47
48// One entry per dot: its gradient color when filled, null when empty.
49export const dotColors = (g: Gauge, count: number): (string | null)[] => {
50  const [from, to] = paletteOf(g)
51  const filled = Math.min(count, Math.max(g.percent > 0 ? 1 : 0, Math.round((g.percent / 100) * count)))
52  return Array.from({ length: count }, (_, i) =>
53    i < filled ? mix(from, to, count > 1 ? i / (count - 1) : 0) : null,
54  )
55}
56
57// Rounded pill bar: a track, and a gradient fill clipped to the same radius.
58export const barSvg = (g: Gauge, width: number, height: number, track: string) => {
59  const [from, to] = paletteOf(g)
60  const r = height / 2
61  const fillW = g.percent > 0 ? Math.max(height, (Math.min(100, g.percent) / 100) * width) : 0
62  const fill = fillW
63    ? `<rect width="${fillW}" height="${height}" rx="${r}" fill="url(#g)"/>`
64    : ''
65  return (
66    `<svg xmlns="http://www.w3.org/2000/svg" width="${width}" height="${height}" viewBox="0 0 ${width} ${height}">` +
67    `<defs><linearGradient id="g" gradientUnits="userSpaceOnUse" x1="0" y1="0" x2="${Math.max(fillW, 1)}" y2="0">` +
68    `<stop offset="0" stop-color="${from}"/><stop offset="1" stop-color="${to}"/></linearGradient></defs>` +
69    `<rect width="${width}" height="${height}" rx="${r}" fill="${track}"/>${fill}</svg>`
70  )
71}
72
73export const accentOf =(g: Gauge) => paletteOf(g)[1]
74
75export const formatReset = (resetsAt: string | undefined, now: number) => {
76  if (!resetsAt) return ''
77  const mins = Math.max(0, Math.round((Date.parse(resetsAt) - now) / 60000))
78  if (mins >= 2880) return `${Math.round(mins / 1440)}j`
79  const h = Math.floor(mins / 60)
80  return h ? `${h}h${String(mins % 60).padStart(2, '0')}` : `${mins}min`
81}
82

1export type Gauge = { label: string; percent: number; resetsAt?: string; detail?: string }
2
3declare module 'claude-code' {
4  interface PluginState {
5    'usage-bars': { gauges: Gauge[] | null; cost: number | null }
6  }
7}
8
