1import type { EngineInterface, Register, Timer } from 'claude-code'
2
3import type { AgentRow, AgentRowStatus, Progress, TodoFile, TodoItem, TodoStatus } from '../types'
4import { ACCENT, DANGER, GREEN, clock, tokens, orchestratorSvg, plural, agentColor, agentLabel, agentSvg, stopInsetPx, cardWidth, elapsed, boardHead, fileCards, heroSvg, longItems, ticketSvg, setWidth, timelineSvg } from './cards'
5import type { AgentView, FileView, ItemStatus, ItemView, TaskView, Usage, View } from './cards'
6
7const PANE = 'claudeopticon'
8const TITLE = 'Claudeopticon'
9/** Whether this load of the mod has reopened a pane that carried an older title. */
10let isRetitled = false
11const DIR = '.claude_todo'
12const TICK_MS = 1000
13const SCAN_EVERY = 3
14/** Ticks between full resyncs: every file reread whatever its mtime, the categories reloaded, the agent list asked again. */
15const RESYNC_EVERY = 60
16const CLOCK_MS = 5000
17const ITEMS_SHOWN = 12
18/** The corner button's offsets from the card's lower right corner, in cells: about even in px. */
19const ACTION_RIGHT = 2
20const ACTION_BOTTOM = 1
21/** Rows from a live agent card's top edge to its Stop button, on the title row left of the badge. */
22const STOP_TOP = 1
23/** The Stop button's label: a circle with a bar, the stop sign. */
24const STOP_GLYPH = '\u2296'
25/** The cells one corner button and its gap take, to set the tip left of them all. */
26const ACTION_CELLS = 5
27/** The narrowest a ticket may be drawn side by side with others, in px; narrower, columns stack. */
28const MIN_TICKET_PX = 300
29/** CSS pixels per pane cell on the desktop: a slight overestimate, since a card wider than the pane scales down to fit. */
30const CELL_PX = 8.5
31const MAX_UP = 8
32const LINK_MIN_CHARS = 12
33
34const PROGRESS_TOOL = 'mcp__claudeopticon__report_progress'
35const MOVE_TOOL = 'mcp__claudeopticon__move_ticket'
36
37/** Appended to each agent's prompt: about 100 tokens, and each report rides along with a tool call. */
38export const PROGRESS_NOTE = `
39
40Progress: if you have the ${PROGRESS_TOOL} tool, call it once you have a plan, with done (steps finished), total (steps planned) and step (a few words on the current step). If your task covers items in the project's .claude_todo/ files, also pass items: each one quoted from its line, or its #T ID. Call it again after each step, in the same message as your next tool call. Raise total if the plan grows; pass items again only if they change.`
41
42/** An agent's report, held to sense: whole steps, at least one planned, never more done than planned. */
43export function readProgress(input: Record<string, unknown>): Progress | undefined {
44  const total = Math.max(1, Math.round(Number(input.total)))
45  const done = Math.min(total, Math.max(0, Math.round(Number(input.done))))
46  if (!Number.isFinite(total) || !Number.isFinite(done)) {
47    return undefined
48  }
49  const step = typeof input.step === 'string' && input.step.trim() !== '' ? input.step.trim().slice(0, 120) : undefined
50
51  return step === undefined ? { done, total } : { done, total, step }
52}
53
54/** The items an agent claims in a report: up to 20 quoted lines or IDs; undefined when it named none. */
55export function readClaims(input: Record<string, unknown>): string[] | undefined {
56  if (!Array.isArray(input.items)) {
57    return undefined
58  }
59  const claims = input.items
60    .filter((one): one is string => typeof one === 'string' && one.trim() !== '')
61    .map(one => one.trim().slice(0, 300))
62    .slice(0, 20)
63
64  return claims.length === 0 ? undefined : claims
65}
66
67/** How long a claim stands before the next progress reply asks the agent to confirm it. */
68export const CLAIM_CHECK_MS = 10 * 60_000
69
70/**
71 * The reply to a progress report. Every 10 minutes it asks the agent to confirm the items it
72 * claimed, or, when it claimed none, to name them if its task covers any: about 40 tokens, carried
73 * by a call the agent makes anyway.
74 */
75export function progressReply(claims: readonly string[] | undefined, isDue: boolean): string {
76  if (!isDue) {
77    return 'Noted.'
78  }
79  if (claims === undefined || claims.length === 0) {
80    return 'Noted. If your task covers items in .claude_todo/, pass them as items in your next report.'
81  }
82
83  return `Noted. You said you handle: ${claims.map(claim => `"${claim.slice(0, 80)}"`).join('; ')}. If that changed, pass the current items in your next report.`
84}
85
86/** When each agent's claim was last set or confirmed, by agent ID. */
87const claimCheckedAt = new Map<string, number>()
88
89const CLAIM_MIN_CHARS = 12
90const CLAIM_MIN_WORDS = 3
91const CLAIM_MIN_SHARE = 0.7
92
93function words(text: string): Set<string> {
94  return new Set(normalize(text).split(/[^a-z0-9]+/).filter(word => word.length >= 3))
95}
96
97/**
98 * How well a claim names an item, from 0 to 1: 1 when it gives the item's ID or holds the item's
99 * text (or the item holds the claim); else the share of the shorter one's words the two have in
100 * common, counted only from 3 shared words and a 70% share, so a loose paraphrase still lands.
101 */
102export function claimScore(claim: string, item: TodoItem): number {
103  const c = normalize(claim)
104  if (item.id !== undefined && new RegExp(`#${item.id.toLowerCase()}(?![0-9a-z])`).test(c)) {
105    return 1
106  }
107  const t = normalize(item.text)
108  if (Math.min(c.length, t.length) >= CLAIM_MIN_CHARS && (t.includes(c) || c.includes(t))) {
109    return 1
110  }
111  const a = words(claim)
112  const b = words(item.text)
113  const shared = [...a].filter(word => b.has(word)).length
114  const share = shared / Math.max(1, Math.min(a.size, b.size))
115
116  return shared >= CLAIM_MIN_WORDS && share >= CLAIM_MIN_SHARE ? share : 0
117}
118
119/**
120 * What the pane draws, held by this session's own process. Each session runs its own copy of the
121 * mod, so this can hold nothing but this session's project and agents. A hot reload starts it
122 * over; the next scan and agent list fill it again within a few seconds.
123 */
124let todoFiles: TodoFile[] = []
125let agentRows: AgentRow[] = []
126let clockMs = 0
127const expandedFiles = new Set<string>()
128/** Files whose long items show whole, past 8 lines, by the pane's file ID. */
129const openText = new Set<string>()
130let isTicketView = true
131let usage: Usage | undefined
132
133/**
134 * What the main conversation (the orchestrator) did itself this session: the one-line summary of
135 * each of its tool calls (the call's own `description`, as the transcript shows it), with its start
136 * time, newest last, the last 1000 kept. Agent calls stay out: they are the agents' work.
137 */
138export type OrchestratorEntry = { id: number; line: string; at: number; isRunning: boolean }
139let orchestrator: { isActive: boolean; history: OrchestratorEntry[] } = { isActive: false, history: [] }
140let callCount = 0
141/** Which page of the history the card shows: 0 the newest. */
142let orchestratorPage = 0
143/** Categories the person hid, by name; their items leave the list and the board (search still finds them). */
144const hiddenCategories = new Set<string>()
145/** Tickets already sent to Claude this session, by file and item key. */
146const sentTickets = new Set<string>()
147let isFinishedShown = false
148let isCompletedShown = false
149let sortBy: 'file' | 'category' = 'file'
150let query = ''
151function redraw($: EngineInterface): void {
152  $.ui.invalidate('ui.render')
153  saveAgents($)
154}
155
156// ---------------------------------------------------------------- agents kept across a reload
157
158/** The agent rows kept in the store per session, so a plugin reload keeps each agent's data. */
159const KEPT_AGENTS = 200
160let isAgentsLoaded = false
161let savedAgents = ''
162
163async function agentsKey($: EngineInterface): Promise<string> {
164  return `agents:${await $.session.id()}`
165}
166
167/** Reads a stored list back into rows, keeping only entries with the fields every row has. */
168export function readKeptAgents(stored: unknown): AgentRow[] {
169  if (!Array.isArray(stored)) {
170    return []
171  }
172
173  return stored.filter((row): row is AgentRow =>
174    typeof row === 'object' && row !== null && typeof row.id === 'string' && typeof row.description === 'string'
175    && typeof row.type === 'string' && typeof row.status === 'string' && typeof row.startedAt === 'number'
176    && typeof row.toolCalls === 'number' && typeof row.brief === 'string')
177}
178
179/**
180 * Loads the rows this session kept, once per load of the mod, under the rows already seen: a row
181 * seen since the load wins. An agent whose ticket match already ran is not matched again.
182 */
183async function loadAgents($: EngineInterface): Promise<void> {
184  if (isAgentsLoaded) {
185    return
186  }
187  isAgentsLoaded = true
188  const kept = readKeptAgents(await $.store.get(await agentsKey($)).catch(() => undefined))
189  const seen = new Set(agentRows.map(row => row.id))
190  agentRows = [...kept.filter(row => !seen.has(row.id)), ...agentRows]
191  for (const row of kept) {
192    if (row.autoClaims !== undefined) {
193      matchedAgents.add(row.id)
194    }
195  }
196  // The first store after a load rewrites the list, without entries that did not read back.
197  savedAgents = ''
198}
199
200/** Stores the rows when they changed since the last store, after the kept rows are loaded. */
201function saveAgents($: EngineInterface): void {
202  if (!isAgentsLoaded) {
203    return
204  }
205  const rows = agentRows.slice(-KEPT_AGENTS)
206  const text = JSON.stringify(rows)
207  if (text === savedAgents) {
208    return
209  }
210  savedAgents = text
211  void agentsKey($).then(key => $.store.set(key, rows)).catch(() => undefined)
212}
213
214const ENDED: readonly AgentRowStatus[] = ['completed', 'failed', 'killed', 'ended']
215
216// ---------------------------------------------------------------- todo
217
218const CHECKBOX = /^\s*[-*+] \[([ xX~>])\]\s+(.*)$/
219const ITEM_ID = /#([A-Za-z]+\d+)\b/
220
221/** An item's text as the pane shows it: Markdown bold and strike markers taken out, spaces trimmed. */
222export function plainText(markdown: string): string {
223  return markdown.replace(/\*\*|__|~~/g, '').trim()
224}
225
226/** Reads the checkbox items of one todo file, in the format the RULES block gives Claude. */
227export function parseTodo(markdown: string): TodoItem[] {
228  const items: TodoItem[] = []
229  for (const line of markdown.split('\n')) {
230    const match = CHECKBOX.exec(line)
231    if (match === null) {
232      continue
233    }
234    const box = match[1] ?? ' '
235    const status: TodoStatus =
236      box === 'x' || box === 'X' ? 'completed' : box === '~' || box === '>' ? 'in_progress' : 'pending'
237    const text = plainText(match[2] ?? '')
238    const id = ITEM_ID.exec(text)?.[1]
239    items.push(id === undefined ? { text, status } : { text, status, id })
240  }
241
242  return items
243}
244
245export function count(items: readonly TodoItem[]): { done: number; active: number; total: number } {
246  return {
247    done: items.filter(item => item.status === 'completed').length,
248    active: items.filter(item => item.status === 'in_progress').length,
249    total: items.length,
250  }
251}
252
253/**
254 * Finds the project's own todo folder: `.claude_todo/` at the root of the repo the session works
255 * in, or of its main checkout from a git worktree (whose `.git` file names it; `.claude_todo/` may
256 * be gitignored, so a worktree may have none). Outside a repo, only the session folder's own. Never
257 * the `.claude_todo/` in the home `.claude` folder, which belongs to no project.
258 */
259export async function findTodoDir($: EngineInterface): Promise<string | undefined> {
260  return findTodoDirWith({
261    exists: path => $.fs.exists(path),
262    kind: path => $.fs.stat(path).then(stat => stat.kind).catch(() => undefined),
263    realPath: path => $.fs.stat(path, { resolve: true }).then(stat => stat.realPath).catch(() => undefined),
264    read: path => $.fs.read(path).then(text => (typeof text === 'string' ? text : '')).catch(() => ''),
265  })
266}
267
268/** The file system calls the todo lookup makes, apart from `$` so a test can lay out folders. */
269export type TodoFs = {
270  exists: (path: string) => Promise<boolean>
271  kind: (path: string) => Promise<string | undefined>
272  realPath: (path: string) => Promise<string | undefined>
273  read: (path: string) => Promise<string>
274}
275
276export async function findTodoDirWith(fs: TodoFs): Promise<string | undefined> {
277  const found = await repoTodoDir(fs)
278  if (found === undefined) {
279    return undefined
280  }
281  const real = await fs.realPath(found)
282
283  return real !== undefined && isGlobalTodo(real) ? undefined : found
284}
285
286/** True for the global todo folder, `<home>/.claude/.claude_todo`, which the mod never reads. A project's own `<repo>/.claude/.claude_todo` is not it. */
287export function isGlobalTodo(realPath: string): boolean {
288  return /^\/(Users|home)\/[^/]+\/\.claude\/\.claude_todo\/?$|^\/root\/\.claude\/\.claude_todo\/?$/.test(realPath)
289}
290
291/**
292 * The nearest `.claude_todo/`, from the session folder up to the repo root: a subfolder with a todo
293 * of its own keeps it. With none up to the root, a worktree uses its main checkout's. Outside a
294 * repo, only the session folder's own counts.
295 */
296async function repoTodoDir(fs: TodoFs): Promise<string | undefined> {
297  for (let depth = 0; depth <= MAX_UP; depth += 1) {
298    const prefix = '../'.repeat(depth)
299    if (await fs.exists(`${prefix}${DIR}`)) {
300      // Taken only inside a repo: the walk must reach a .git at or above this folder.
301      for (let up = depth; up <= MAX_UP; up += 1) {
302        if (await fs.exists(`${'../'.repeat(up)}.git`)) {
303          return `${prefix}${DIR}`
304        }
305      }
306
307      return depth === 0 ? DIR : undefined
308    }
309    const git = `${prefix}.git`
310    if (!(await fs.exists(git))) {
311      continue
312    }
313    if ((await fs.kind(git)) === 'file') {
314      const gitdir = /^gitdir:\s*(.+)$/m.exec(await fs.read(git))?.[1]?.trim()
315      const main = gitdir?.split('/.git/worktrees/')[0]
316
317      return main !== undefined && main !== gitdir && (await fs.exists(`${main}/${DIR}`)) ? `${main}/${DIR}` : undefined
318    }
319
320    return undefined
321  }
322
323  return undefined
324}
325
326// ---------------------------------------------------------------- folders
327
328/** One `.claude_todo/` folder: `path` as the engine's fs takes it, `rel` from its checkout's root. */
329export type TodoFolder = { path: string; rel: string; isOther: boolean; real?: string }
330
331/** Most folders the pane reads: a repo with more is cut, primary folder first, then by path. */
332export const MAX_FOLDERS = 20
333
334/**
335 * The `.claude_todo/` folders in the output of `git ls-files -z`: every entry with a `.claude_todo`
336 * segment is cut to the folder path ending there. An ignored folder lists as a collapsed directory
337 * entry (`x/.claude_todo/`), which cuts the same way. Duplicates drop; the order is by path.
338 */
339export function todoFoldersIn(listing: string, root: string): { path: string; rel: string }[] {
340  const rels = new Set<string>()
341  for (const entry of listing.split('\0')) {
342    const parts = entry.split('/').filter(part => part !== '')
343    const at = parts.indexOf(DIR)
344    if (at >= 0) {
345      rels.add(parts.slice(0, at + 1).join('/'))
346    }
347  }
348
349  return [...rels].sort().map(rel => ({ path: `${root}/${rel}`, rel }))
350}
351
352/**
353 * The repo root and, from a git worktree, its main checkout, from the output of
354 * `git rev-parse --path-format=absolute --show-toplevel --git-common-dir`.
355 */
356export function repoRoots(stdout: string): { root: string; main?: string } | undefined {
357  const [top, common] = stdout.split('\n').map(line => line.trim())
358  if (top === undefined || top === '' || !top.startsWith('/')) {
359    return undefined
360  }
361  const main = common !== undefined && common !== `${top}/.git` && common.endsWith('/.git') ? common.slice(0, -'/.git'.length) : undefined
362
363  return main === undefined || main === '' ? { root: top } : { root: top, main }
364}
365
366/**
367 * The folders the pane reads from those found: the global ones dropped, a place found twice kept
368 * once (the primary's entry when it is one of them, else the first), the primary folder first and
369 * the rest by path, cut to MAX_FOLDERS. `primary` is the `path` of the one folder the nearest-up
370 * rule picks.
371 */
372export function pickFolders(found: readonly { path: string; rel: string; real?: string }[], primary: string | undefined, globals: ReadonlySet<string>): TodoFolder[] {
373  const byRel = new Map<string, { path: string; rel: string; real?: string }>()
374  for (const one of found) {
375    if (globals.has(one.path)) {
376      continue
377    }
378    const held = byRel.get(one.rel)
379    if (held === undefined || (one.path === primary && held.path !== primary)) {
380      byRel.set(one.rel, one)
381    }
382  }
383  const kept = [...byRel.values()]
384  const first = kept.filter(one => one.path === primary)
385  const rest = kept.filter(one => one.path !== primary).sort((a, b) => (a.rel < b.rel ? -1 : a.rel > b.rel ? 1 : 0))
386
387  return [...first.map(one => ({ ...one, isOther: false })), ...rest.map(one => ({ ...one, isOther: true }))].slice(0, MAX_FOLDERS)
388}
389
390/** The `.claude_todo/` folders of a checkout, tracked, untracked and ignored, through git. */
391async function listFolders($: EngineInterface, root: string): Promise<{ path: string; rel: string }[]> {
392  const run = async (argv: string[]) => {
393    const done = await $.process.run(argv, { cwd: root })
394
395    return done.exitCode === 0 ? done.stdout : ''
396  }
397  const tracked = await run(['git', 'ls-files', '-z', '--cached', '--others', '--exclude-standard'])
398  const ignored = await run(['git', 'ls-files', '-z', '--others', '--ignored', '--exclude-standard', '--directory'])
399
400  return todoFoldersIn(`${tracked}\0${ignored}`, root)
401}
402
403/** The real path of a folder, or undefined when it cannot be resolved. */
404function realOf($: EngineInterface, path: string): Promise<string | undefined> {
405  return $.fs.stat(path, { resolve: true }).then(stat => stat.realPath).catch(() => undefined)
406}
407
408/** The repo root of the session, kept to name a folder found later by its place in the repo. */
409let repoRoot: string | undefined
410/** Where the central todo lives: the root of the main checkout (the repo root outside a worktree). */
411let centralRoot: string | undefined
412
413/**
414 * Finds every `.claude_todo/` folder of the repo (and of the main checkout, from a worktree) with
415 * git. Outside a repo, or when git fails, only the nearest one by the old rule counts. A path git
416 * lists but the disk no longer has (a tracked file deleted) is dropped.
417 */
418async function discoverFolders($: EngineInterface): Promise<TodoFolder[]> {
419  const nearest = await findTodoDir($).catch(() => undefined)
420  const nearestReal = nearest === undefined ? undefined : await realOf($, nearest)
421  const alone: TodoFolder[] = nearest === undefined ? [] : [{ path: nearest, rel: nearest, isOther: false, ...(nearestReal === undefined ? {} : { real: nearestReal }) }]
422  try {
423    const top = await $.process.run(['git', 'rev-parse', '--path-format=absolute', '--show-toplevel', '--git-common-dir'])
424    const roots = top.exitCode === 0 ? repoRoots(top.stdout) : undefined
425    if (roots === undefined) {
426      return alone
427    }
428    repoRoot = roots.root
429    centralRoot = roots.main ?? roots.root
430    // Consolidate and Delete are off in a linked worktree and when the main folder is the global one.
431    const centralPath = `${centralRoot}/${DIR}`
432    centralBlocked = roots.main !== undefined || isGlobalTodo(centralPath) || isGlobalTodo((await realOf($, centralPath)) ?? centralPath)
433    const listed = [...(await listFolders($, roots.root)), ...(roots.main === undefined ? [] : await listFolders($, roots.main))]
434    const found: { path: string; rel: string; real?: string }[] = []
435    const globals = new Set<string>()
436    let primary: string | undefined
437    for (const one of listed) {
438      if (!(await $.fs.exists(one.path).catch(() => false))) {
439        continue
440      }
441      const real = await realOf($, one.path)
442      found.push(real === undefined ? one : { ...one, real })
443      if (isGlobalTodo(real ?? one.path)) {
444        globals.add(one.path)
445      }
446      if (real !== undefined && real === nearestReal && primary === undefined) {
447        primary = one.path
448      }
449    }
450    if (nearest !== undefined && primary === undefined) {
451      // The nearest folder git did not list: keep it, named by its place in the repo when that shows.
452      found.unshift({ path: nearest, rel: relIn(nearestReal, roots.root) ?? nearest, ...(nearestReal === undefined ? {} : { real: nearestReal }) })
453      primary = nearest
454    }
455
456    return pickFolders(found, primary, globals)
457  } catch {
458    return alone
459  }
460}
461
462/** A real path from the repo root, or undefined when it lies outside the root. */
463function relIn(real: string | undefined, root: string | undefined): string | undefined {
464  return real !== undefined && root !== undefined && real.startsWith(`${root}/`) ? real.slice(root.length + 1) : undefined
465}
466
467/** The folders found when the mod started; undefined until then. Git runs once per load; a reload does it again. */
468let todoFolders: TodoFolder[] | undefined
469let folderSearch: Promise<TodoFolder[]> | undefined
470/** The nearest folder the last scan saw, to look it up among the known ones only when it changes. */
471let nearestSeen: string | undefined
472
473function ensureFolders($: EngineInterface): Promise<TodoFolder[]> {
474  if (todoFolders !== undefined) {
475    return Promise.resolve(todoFolders)
476  }
477  folderSearch ??= discoverFolders($).then(async found => {
478    await loadDuplicates($, found).catch(() => undefined)
479    todoFolders = found
480
481    return found
482  })
483
484  return folderSearch
485}
486
487// ---------------------------------------------------------------- consolidating
488
489/**
490 * Folders whose todo was copied into the central one: they stay off the board, and the Delete
491 * duplicate todos button stays while any of them exists. Kept in the store by repo root, so a reload
492 * or a new session knows them. `wasPrimary`: the folder was the primary one when it was copied.
493 */
494let dupFolders: { path: string; real?: string; wasPrimary?: boolean }[] = []
495/** By source file (absolute path): the IDs renumbered when it was copied, old (lowercase) to new. */
496let renameMap: Record<string, Record<string, string>> = {}
497/** By source file (absolute path): the source lines (trailing spaces cut) folded into an identical central ticket, not copied. */
498let foldMap: Record<string, string[]> = {}
499/** What the last coverage check looked at, so the board's scan checks again only after a file changed. */
500let lastCoverageSig: string | undefined
501/** True when Consolidate and Delete are off: a linked worktree, or a main folder that would be the global one. */
502let centralBlocked = false
503/** The renumbered IDs Claude has not been told of yet. */
504let pendingRenames: string[] = []
505
506const dupKey = (): string | undefined => (centralRoot === undefined ? undefined : `duplicates:${centralRoot}`)
507const metaKey = (): string | undefined => (centralRoot === undefined ? undefined : `duplicates-meta:${centralRoot}`)
508
509function isDuplicate(folder: { path: string; real?: string }): boolean {
510  return dupFolders.some(one => one.path === folder.path || (one.real !== undefined && one.real === folder.real))
511}
512
513/** The central folder: `<root of the main checkout>/.claude_todo`. */
514function centralFolder(): string | undefined {
515  return centralRoot === undefined ? undefined : `${centralRoot}/${DIR}`
516}
517
518/** The folders on the board: the known ones, less the duplicates. When the primary one was a duplicate, the central one takes its place. */
519function visibleFolders(): TodoFolder[] {
520  const all = todoFolders ?? []
521  const shown = all.filter(one => !isDuplicate(one))
522  const lostPrimary = all.some(one => !one.isOther && isDuplicate(one)) && !shown.some(one => !one.isOther)
523
524  return lostPrimary ? shown.map(one => (one.path === centralFolder() ? { ...one, isOther: false } : one)) : shown
525}
526
527/** True when the Consolidate todos button shows: a repo's main checkout (not a worktree, not the global folder), and more than one folder on the board. */
528function canConsolidate(): boolean {
529  return !centralBlocked && centralRoot !== undefined && visibleFolders().length > 1
530}
531
532/** True when the Delete duplicate todos button shows: the same gate, and a recorded duplicate folder. */
533function canDelete(): boolean {
534  return !centralBlocked && centralRoot !== undefined && dupFolders.length > 0
535}
536
537/** Writes the renumbering and fold records to the store. */
538async function saveMeta($: EngineInterface): Promise<void> {
539  const meta = metaKey()
540  if (meta !== undefined) {
541    await $.store.set(meta, { primary: dupFolders.filter(one => one.wasPrimary === true).map(one => one.path), renames: renameMap, folds: foldMap }).catch(() => undefined)
542  }
543}
544
545/** Writes the duplicate record and the renumbering record to the store. */
546async function saveRecord($: EngineInterface): Promise<void> {
547  const key = dupKey()
548  if (key === undefined) {
549    return
550  }
551  await $.store.set(key, dupFolders.map(one => one.path)).catch(() => undefined)
552  await saveMeta($)
553}
554
555/** Keeps the recorded duplicates that still exist on disk, and rewrites the record when some are gone. */
556async function loadDuplicates($: EngineInterface, found: readonly TodoFolder[] = todoFolders ?? []): Promise<void> {
557  const key = dupKey()
558  const meta = metaKey()
559  if (key === undefined || meta === undefined) {
560    return
561  }
562  const stored = await $.store.get(key).catch(() => undefined)
563  const kept = (await $.store.get(meta).catch(() => undefined)) as { primary?: unknown; renames?: unknown; folds?: unknown } | undefined
564  const primary = new Set(Array.isArray(kept?.primary) ? kept.primary.filter((one): one is string => typeof one === 'string') : [])
565  if (typeof kept?.renames === 'object' && kept.renames !== null) {
566    renameMap = { ...(kept.renames as typeof renameMap), ...renameMap }
567  }
568  // Only arrays of strings read back as folds: a malformed entry means no folds, so its lines must be copied.
569  if (typeof kept?.folds === 'object' && kept.folds !== null) {
570    const clean = Object.fromEntries(Object.entries(kept.folds as Record<string, unknown>).map(([file, list]) => [file, Array.isArray(list) ? list.filter((one): one is string => typeof one === 'string') : []]))
571    foldMap = { ...clean, ...foldMap }
572  }
573  // The record and what this load already knows: a store that fails must not unhide a folder.
574  const paths = [...new Set([...(Array.isArray(stored) ? stored.filter((one): one is string => typeof one === 'string') : []), ...dupFolders.map(one => one.path)])]
575  const alive: typeof dupFolders = []
576  for (const path of paths) {
577    if (!path.startsWith('/') || !(await $.fs.exists(path).catch(() => false))) {
578      continue
579    }
580    const real = found.find(one => one.path === path)?.real ?? (await realOf($, path))
581    const was = primary.has(path) || dupFolders.some(one => one.path === path && one.wasPrimary === true)
582    alive.push({ path, ...(real === undefined ? {} : { real }), ...(was ? { wasPrimary: true } : {}) })
583  }
584  dupFolders = alive
585  if (alive.length !== paths.length) {
586    // An empty list is the cleared record.
587    await saveRecord($)
588  }
589  await dropUncovered($, true)
590}
591
592/** Every checkbox line of a todo file's text, as written. */
593export function itemLines(markdown: string): string[] {
594  return markdown.split('\n').filter(line => CHECKBOX.test(line))
595}
596
597/** Every line of the text with something on it, trailing spaces cut. */
598export function nonBlankLines(markdown: string): string[] {
599  return markdown.split('\n').map(line => line.trimEnd()).filter(line => line.trim() !== '')
600}
601
602/** An item line as compared between files: its box and text, with only its own leading `#T` ID taken out. */
603export function lineSignature(line: string): string {
604  const match = CHECKBOX.exec(line)
605  const box = (match?.[1] ?? ' ').replace(/[xX]/, 'x').replace('>', '~')
606
607  return `${box} ${plainText(match?.[2] ?? '').replace(/^#[A-Za-z]+\d+\s*/, '').replace(/\s+/g, ' ').trim().toLowerCase()}`
608}
609
610/** What a line must match in the central file to count as copied: the exact line (after the renumbering), item lines and prose alike. */
611export function coverKey(line: string): string {
612  return `t:${line.trimEnd()}`
613}
614
615/** The line with every `#ID` in the map replaced by its new one (one pass, so a new ID is never renamed again). */
616export function applyRenames(line: string, renames: Readonly<Record<string, string>>): string {
617  return line.replace(/#([A-Za-z]+\d+)\b/g, (whole, id: string) => {
618    const fresh = renames[id.toLowerCase()]
619
620    return fresh === undefined ? whole : `#${fresh}`
621  })
622}
623
624/**
625 * The lines of one source file with every item ID that `used` has already replaced by the next free
626 * ID of its letters (`#T3` when `#T1` and `#T2` are taken), and the references to it in the other
627 * lines of the file rewritten the same way. `used` (lowercase IDs) gains each ID the file ends up with.
628 * `renames` maps old (lowercase) to new; `pairs` lists them as written, for the toast.
629 */
630export function renumberLines(lines: readonly string[], used: Set<string>): { lines: string[]; renames: Record<string, string>; pairs: { from: string; to: string }[] } {
631  const renames: Record<string, string> = {}
632  const pairs: { from: string; to: string }[] = []
633  // A new number also skips this source's own IDs, so one clash never pushes a later line out.
634  const own = lines.flatMap(line => {
635    const id = CHECKBOX.test(line) ? ITEM_ID.exec(line)?.[1] : undefined
636
637    return id === undefined ? [] : [id.toLowerCase()]
638  })
639  const nextFree = (letters: string) => {
640    let top = 0
641    for (const id of [...used, ...own]) {
642      const m = /^([a-z]+)(\d+)$/.exec(id)
643      if (m !== null && m[1] === letters.toLowerCase()) {
644        top = Math.max(top, Number(m[2]))
645      }
646    }
647
648    return `${letters}${top + 1}`
649  }
650  for (const line of lines) {
651    const id = CHECKBOX.test(line) ? ITEM_ID.exec(line)?.[1] : undefined
652    if (id === undefined) {
653      continue
654    }
655    if (renames[id.toLowerCase()] !== undefined) {
656      continue
657    }
658    if (!used.has(id.toLowerCase())) {
659      used.add(id.toLowerCase())
660      continue
661    }
662    const fresh = nextFree(/^[A-Za-z]+/.exec(id)?.[0] ?? 'T')
663    used.add(fresh.toLowerCase())
664    renames[id.toLowerCase()] = fresh
665    pairs.push({ from: id, to: fresh })
666  }
667
668  return { lines: lines.map(line => applyRenames(line, renames)), renames, pairs }
669}
670
671/** The text of a target file with new sections added: kept as it was, then each `## From <place>` block. */
672export function appendSections(existing: string, sections: readonly { place: string; lines: readonly string[] }[]): string {
673  let text = existing
674  for (const section of sections) {
675    const gap = text.trim() === '' ? '' : text.endsWith('\n') ? '\n' : '\n\n'
676    text = `${text}${gap}## From ${section.place}\n\n${section.lines.join('\n')}\n`
677  }
678
679  return text
680}
681
682/** The non-blank lines under each `## From <place>` heading of the text, one list per heading, up to the next `## ` heading. */
683export function sectionBlocks(text: string, place: string): string[][] {
684  const blocks: string[][] = []
685  let current: string[] | undefined
686  for (const line of text.split('\n').map(one => one.trimEnd())) {
687    if (line.trim() === `## From ${place}`) {
688      current = []
689      blocks.push(current)
690    } else if (line.startsWith('## ')) {
691      current = undefined
692    } else if (current !== undefined && line.trim() !== '') {
693      current.push(line)
694    }
695  }
696
697  return blocks
698}
699
700/** True when the text already holds the `## From <place>` section of that source. */
701export function hasSection(text: string, place: string): boolean {
702  return text.split('\n').some(line => line.trim() === `## From ${place}`)
703}
704
705/** The one-time note for Claude after IDs were renumbered. */
706export function renameNote(lines: readonly string[]): string | undefined {
707  return lines.length === 0
708    ? undefined
709    : [
710        'The Claudeopticon pane (the claudeopticon mod) consolidated several .claude_todo/ folders into the repo\'s main one. These item IDs collided and were renumbered in the copies. Use the new IDs from now on:',
711        ...lines,
712      ].join('\n')
713}
714
715/** Where a folder sits in its checkout, for the heading in the central file: its path without `.claude_todo`. */
716function placeOf(rel: string): string {
717  const place = rel.slice(0, Math.max(0, rel.length - DIR.length)).replace(/\/$/, '')
718
719  return place === '' ? 'the root of another checkout' : place
720}
721
722/** A folder's place in its checkout, for telling same-named files apart: its path without `.claude_todo`; empty at the repo root. */
723export function folderPlace(rel: string): string {
724  return rel.slice(0, Math.max(0, rel.length - DIR.length)).replace(/\/$/, '')
725}
726
727/** The `.md` files of a folder, top level and archive, as names inside it. */
728async function mdFiles($: EngineInterface, folder: string, isStrict = false): Promise<string[]> {
729  const names: string[] = []
730  for (const [dir, prefix] of [[folder, ''], [`${folder}/archive`, 'archive/']] as const) {
731    // Strict, a folder that will not answer or list is an error, not an empty or absent folder.
732    if (!(isStrict ? await $.fs.exists(dir) : await $.fs.exists(dir).catch(() => false))) {
733      continue
734    }
735    for (const entry of isStrict ? await $.fs.list(dir) : await $.fs.list(dir).catch(() => [])) {
736      if (entry.kind === 'file' && entry.name.endsWith('.md')) {
737        names.push(`${prefix}${entry.name}`)
738      }
739    }
740  }
741
742  return names
743}
744
745/** The text of a file that must read: a failed read is an error, not an empty file. */
746async function readStrict($: EngineInterface, path: string): Promise<string> {
747  const text = await $.fs.read(path)
748  if (typeof text !== 'string') {
749    throw new Error(`could not read ${path}`)
750  }
751
752  return text
753}
754
755async function readText($: EngineInterface, path: string): Promise<string> {
756  const text = await $.fs.read(path).catch(() => '')
757
758  return typeof text === 'string' ? text : ''
759}
760
761/** Writes a file, making its folder first through `mkdir -p` (no shell) when the plain write fails. */
762async function writeFile($: EngineInterface, path: string, text: string): Promise<void> {
763  try {
764    await $.fs.write(path, text)
765  } catch (error) {
766    const dir = path.slice(0, path.lastIndexOf('/'))
767    const made = await $.process.run(['mkdir', '-p', dir]).catch(() => undefined)
768    if (made?.exitCode !== 0) {
769      throw error
770    }
771    await $.fs.write(path, text)
772  }
773}
774
775let isWorking = false
776
777/**
778 * The parts of a ticket line that a fold compares: everything but the item's own leading `#T<n>` ID,
779 * kept letter for letter (bullet, box, spacing, text), and that ID. Undefined for any other line.
780 */
781export function foldParts(line: string): { key: string; id: string } | undefined {
782  const m = /^(\s*[-*+] \[[ xX~>]\]\s+)#([A-Za-z]+\d+)(?=\s|$)(.*)$/.exec(line.trimEnd())
783
784  return m === null ? undefined : { key: `${m[1]}#${m[3]}`, id: m[2]! }
785}
786
787/**
788 * Moves the work to one central todo, `<root of the main checkout>/.claude_todo/`: the non-blank
789 * lines of every other folder's files go into the central file of the same name (archive files into
790 * the central `archive/`), in order, under a `## From <place>` heading. A line the central file
791 * already holds (exactly, after the file's recorded renames) is not copied again. A ticket line
792 * identical, apart from its own ID, to a ticket line of the central file or one queued for it in
793 * this press is folded: not copied, its ID mapped to the existing ticket's (references follow, and
794 * the fold is recorded so Delete knows). Any other ticket whose ID the central folder uses gets the
795 * next free ID. Each target file is written once, if it did not change since it was read; the sources
796 * are never touched. Then the folders are found again (the one discovery outside startup), the
797 * sources join the duplicates, and a folder not fully covered leaves them again. Off in a linked
798 * worktree and when the main folder would be the global one.
799 */
800async function consolidate($: EngineInterface): Promise<void> {
801  const central = centralFolder()
802  if (isWorking || central === undefined || !canConsolidate()) {
803    return
804  }
805  isWorking = true
806  try {
807    await dropUncovered($, true)
808    if (!canConsolidate()) {
809      return
810    }
811    const realCentral = await realOf($, central)
812    const sources: { path: string; real: string; rel: string; wasPrimary: boolean }[] = []
813    for (const one of visibleFolders()) {
814      if (one.path === central || (realCentral !== undefined && one.real === realCentral) || !one.path.startsWith('/')) {
815        continue
816      }
817      const real = one.real ?? (await realOf($, one.path))
818      if (real !== undefined) {
819        sources.push({ path: one.path, real, rel: one.rel, wasPrimary: !one.isOther })
820      }
821    }
822    if (sources.length === 0) {
823      return
824    }
825    const used = new Set<string>()
826    const texts = new Map<string, string>()
827    const centralText = async (name: string) => {
828      const held = texts.get(name)
829      if (held !== undefined) {
830        return held
831      }
832      const path = `${central}/${name}`
833      // An existing central file that cannot be read aborts the press: it is never written over.
834      const text = (await $.fs.exists(path)) ? await readStrict($, path) : ''
835      texts.set(name, text)
836
837      return text
838    }
839    for (const name of await mdFiles($, central, true)) {
840      for (const line of itemLines(await centralText(name))) {
841        const id = ITEM_ID.exec(line)?.[1]
842        if (id !== undefined) {
843          used.add(id.toLowerCase())
844        }
845      }
846    }
847    // Per target: the central lines still free to cover a source line, and the tickets a fold may join.
848    const free = new Map<string, Map<string, number>>()
849    const whole = new Map<string, Map<string, number>>()
850    const tickets = new Map<string, Map<string, string>>()
851    const stateFor = async (name: string) => {
852      if (!free.has(name)) {
853        const held = new Map<string, number>()
854        const ids = new Map<string, string>()
855        for (const line of nonBlankLines(await centralText(name))) {
856          held.set(coverKey(line), (held.get(coverKey(line)) ?? 0) + 1)
857          const parts = foldParts(line)
858          if (parts !== undefined && !ids.has(parts.key)) {
859            ids.set(parts.key, parts.id)
860          }
861        }
862        free.set(name, held)
863        whole.set(name, new Map(held))
864        tickets.set(name, ids)
865      }
866
867      return { held: free.get(name)!, all: whole.get(name)!, ids: tickets.get(name)! }
868    }
869    type Block = { place: string; lines: string[] }
870    type Commit = { target?: string; file: string; renames: Record<string, string>; folds: string[]; told: string[] }
871    const sections = new Map<string, Block[]>()
872    const commits: Commit[] = []
873    // A source that will not list or read stays on the board: nothing of it was copied.
874    const unreadable = new Set<string>()
875    for (const source of sources) {
876      const place = placeOf(source.rel)
877      const names = await mdFiles($, source.path, true).catch(() => undefined)
878      if (names === undefined) {
879        unreadable.add(source.path)
880        continue
881      }
882      for (const name of names) {
883        const path = `${source.path}/${name}`
884        const text = await readStrict($, path).catch(() => undefined)
885        if (text === undefined) {
886          unreadable.add(source.path)
887          continue
888        }
889        const lines = nonBlankLines(text)
890        const { held, all: whole, ids } = await stateFor(name)
891        const old = renameMap[path] ?? {}
892        const oldFolds = new Set(foldMap[path] ?? [])
893        const fold: Record<string, string> = {}
894        // What the lines already in the central file still need of the old record; the rest is stale.
895        const keepOld: Record<string, string> = {}
896        const keepFolds: string[] = []
897        const folded: string[] = []
898        const told: string[] = []
899        const toCopy: string[] = []
900        for (const line of lines) {
901          // Already in the central file: exactly, after this file's renames. A recorded fold may share its line.
902          const key = coverKey(applyRenames(line, old))
903          // A recorded fold may share its central line, used or not; any other line uses it up.
904          if (oldFolds.has(line) ? (whole.get(key) ?? 0) > 0 : (held.get(key) ?? 0) > 0) {
905            if (oldFolds.has(line)) {
906              keepFolds.push(line)
907            } else {
908              held.set(key, (held.get(key) ?? 0) - 1)
909            }
910            for (const [, id] of line.matchAll(/#([A-Za-z]+\d+)\b/g)) {
911              if (id !== undefined && old[id.toLowerCase()] !== undefined) {
912                keepOld[id.toLowerCase()] = old[id.toLowerCase()]!
913              }
914            }
915            continue
916          }
917          const parts = foldParts(line)
918          const target = parts === undefined ? undefined : ids.get(parts.key)
919          if (parts !== undefined && target !== undefined) {
920            if (target.toLowerCase() !== parts.id.toLowerCase()) {
921              fold[parts.id.toLowerCase()] = target
922            }
923            folded.push(line)
924            told.push(`- ${place}/${name}: #${parts.id} folded into #${target}`)
925            continue
926          }
927          toCopy.push(line)
928        }
929        const fresh = renumberLines(toCopy, used)
930        // New copies take no old renaming: a recreated file must not inherit a stale one.
931        const now = { ...fold, ...fresh.renames }
932        const out = toCopy.map(line => applyRenames(line, now))
933        told.push(...fresh.pairs.map(pair => `- ${place}/${name}: #${pair.from} is now #${pair.to}`))
934        for (const line of out) {
935          const parts = foldParts(line)
936          if (parts !== undefined && !ids.has(parts.key)) {
937            ids.set(parts.key, parts.id)
938          }
939        }
940        if (out.length > 0) {
941          sections.set(name, [...(sections.get(name) ?? []), { place, lines: out }])
942        }
943        commits.push({ ...(out.length > 0 ? { target: name } : {}), file: path, renames: { ...keepOld, ...now }, folds: [...keepFolds, ...folded], told })
944      }
945    }
946    let files = 0
947    const told: string[] = []
948    const skipped = new Set<string>()
949    const commit = (one: Commit) => {
950      // Always replaced, an empty one too: a file copied again must not keep an older renumbering.
951      renameMap = { ...renameMap, [one.file]: one.renames }
952      foldMap = { ...foldMap, [one.file]: [...new Set(one.folds)] }
953      told.push(...one.told)
954    }
955    for (const one of commits.filter(c => c.target === undefined)) {
956      commit(one)
957    }
958    const notCopied = new Set<string>()
959    for (const [name, blocks] of sections) {
960      const path = `${central}/${name}`
961      // The target may have changed since the press read it: then it is not written, and its sources stay uncovered.
962      const now = (await $.fs.exists(path)) ? await readStrict($, path) : ''
963      if (now !== (await centralText(name))) {
964        skipped.add(`${DIR}/${name}`)
965        // Its sources were not copied: they stay off the duplicates record, so a failed check later cannot hide them.
966        for (const one of commits.filter(c => c.target === name)) {
967          notCopied.add(one.file.slice(0, one.file.length - name.length - 1))
968        }
969        continue
970      }
971      await writeFile($, path, appendSections(now, blocks))
972      files += 1
973      for (const one of commits.filter(c => c.target === name)) {
974        commit(one)
975      }
976      // The renumbering is kept as each file lands, so a press that fails later still knows it.
977      await saveMeta($)
978    }
979    // The union of the old record and the new sources, in memory at once; the coverage check then
980    // lets go of any folder that is not fully in the central one.
981    const fresh = sources.filter(one => !unreadable.has(one.path) && !notCopied.has(one.path)).map(one => ({ path: one.path, real: one.real, ...(one.wasPrimary ? { wasPrimary: true as const } : {}) }))
982    dupFolders = [...dupFolders.filter(one => !fresh.some(now => now.path === one.path)), ...fresh]
983    await saveRecord($)
984    await dropUncovered($, true)
985    pendingRenames = [...pendingRenames, ...told]
986    // The one discovery outside startup: the git index again, now with the central folder in it.
987    todoFolders = undefined
988    folderSearch = undefined
989    nearestSeen = undefined
990    await ensureFolders($)
991    await scan($, true)
992    if (skipped.size > 0) {
993      $.ui.toast(`Not written, changed meanwhile: ${[...skipped].join(', ')}. Their folders stay on the board. Press Consolidate todos again.`)
994    }
995    $.ui.toast(`Consolidated ${files} ${files === 1 ? 'file' : 'files'} into ${DIR}/ at the repo root.${skipped.size === 0 && unreadable.size === 0 ? ' The old folders are off the board.' : ''}${told.length > 0 ? ` Renumbered: ${told.map(line => line.slice(2)).join('; ')}` : ''}`)
996  } catch (error) {
997    $.ui.toast(`Could not consolidate: ${error instanceof Error ? error.message : String(error)}`)
998  } finally {
999    isWorking = false
1000    redraw($)
1001  }
1002}
1003
1004/** One file of a duplicate folder, as the coverage check judged it. `empty`: no non-blank line. */
1005type FileCover = { name: string; path: string; text: string; state: 'covered' | 'uncovered' | 'empty' }
1006
1007/**
1008 * The one coverage rule, for the board and for Delete: a file of a duplicate folder is covered when
1009 * every non-blank line of it, after its recorded renames, is a line of the central file of the same
1010 * name, and a central line covers only one source line. A line recorded as folded (`foldMap`) may
1011 * share its central line; no other line may. Folders are judged in order, sharing the central lines.
1012 * A file that cannot be read counts as uncovered. A central file that cannot be read throws.
1013 */
1014async function coverageOf($: EngineInterface, central: string, folders: readonly { path: string }[]): Promise<Map<string, FileCover[] | undefined>> {
1015  const have = new Map<string, Map<string, number>>()
1016  // What each central file holds before anything is used: a recorded fold is judged against this.
1017  const whole = new Map<string, Map<string, number>>()
1018  const covers = async (name: string) => {
1019    let held = have.get(name)
1020    if (held === undefined) {
1021      held = new Map()
1022      const path = `${central}/${name}`
1023      const text = (await $.fs.exists(path).catch(() => false)) ? await readStrict($, path) : ''
1024      for (const line of nonBlankLines(text)) {
1025        held.set(coverKey(line), (held.get(coverKey(line)) ?? 0) + 1)
1026      }
1027      have.set(name, held)
1028      whole.set(name, new Map(held))
1029    }
1030
1031    return held
1032  }
1033  const out = new Map<string, FileCover[] | undefined>()
1034  for (const dup of folders) {
1035    const files: FileCover[] = []
1036    // A folder that will not list is not judged: nothing is known of it.
1037    const names = await mdFiles($, dup.path, true).catch(() => undefined)
1038    if (names === undefined) {
1039      out.set(dup.path, undefined)
1040      continue
1041    }
1042    for (const name of names) {
1043      const path = `${dup.path}/${name}`
1044      const text = await readStrict($, path).catch(() => undefined)
1045      if (text === undefined) {
1046        files.push({ name, path, text: '', state: 'uncovered' })
1047        continue
1048      }
1049      const lines = nonBlankLines(text)
1050      if (lines.length === 0) {
1051        files.push({ name, path, text, state: 'empty' })
1052        continue
1053      }
1054      const renames = renameMap[path] ?? {}
1055      const folded = new Set(foldMap[path] ?? [])
1056      const held = await covers(name)
1057      const left = new Map(held)
1058      const isCovered = lines.every(line => {
1059        const key = coverKey(applyRenames(line, renames))
1060        if (folded.has(line)) {
1061          return (whole.get(name)?.get(key) ?? 0) > 0
1062        }
1063        const n = left.get(key) ?? 0
1064        left.set(key, n - 1)
1065
1066        return n > 0
1067      })
1068      if (isCovered) {
1069        // The lines used stay used for the next file.
1070        for (const [key, n] of left) {
1071          held.set(key, n)
1072        }
1073      }
1074      files.push({ name, path, text, state: isCovered ? 'covered' : 'uncovered' })
1075    }
1076    out.set(dup.path, files)
1077  }
1078
1079  return out
1080}
1081
1082/** The names and mtimes of the `.md` files of the central folder and the duplicate folders: a cheap sign that a coverage check is due. */
1083async function coverageSignature($: EngineInterface, central: string): Promise<string> {
1084  const parts: string[] = []
1085  for (const folder of [central, ...dupFolders.map(one => one.path)]) {
1086    for (const [dir, prefix] of [[folder, ''], [`${folder}/archive`, 'archive/']] as const) {
1087      if (await $.fs.exists(dir).catch(() => false)) {
1088        for (const entry of await $.fs.list(dir).catch(() => [])) {
1089          if (entry.kind === 'file' && entry.name.endsWith('.md')) {
1090            parts.push(`${dir}/${prefix}${entry.name}:${entry.mtimeMs}:${entry.size}`)
1091          }
1092        }
1093      }
1094    }
1095  }
1096
1097  return parts.join('|')
1098}
1099
1100/**
1101 * A recorded duplicate counts only while all its non-blank lines are covered by the central folder.
1102 * A folder that is not leaves the record (and the store), shows on the board again, and is a
1103 * Consolidate source again. Checked at load, at each full resync, before Consolidate and Delete, and
1104 * at the board's scan whenever a file of those folders changed. Off where Consolidate and Delete are.
1105 */
1106async function dropUncovered($: EngineInterface, isForced = false): Promise<void> {
1107  const central = centralFolder()
1108  if (central === undefined || centralBlocked || dupFolders.length === 0) {
1109    return
1110  }
1111  try {
1112    const sign = await coverageSignature($, central)
1113    if (!isForced && sign === lastCoverageSig) {
1114      return
1115    }
1116    const cover = await coverageOf($, central, dupFolders)
1117    // Remembered only after a check that ran, so a failed one is tried again on the next scan.
1118    lastCoverageSig = sign
1119    const kept = dupFolders.filter(one => !(cover.get(one.path) ?? []).some(file => file.state === 'uncovered'))
1120    if (kept.length !== dupFolders.length) {
1121      dupFolders = kept
1122      lastCoverageSig = undefined
1123      await saveRecord($)
1124    }
1125  } catch {
1126    // A central file that cannot be read changes nothing: the record stays as it was.
1127  }
1128}
1129
1130/**
1131 * Whether files may be removed from a recorded duplicate folder: an absolute path with no `..`,
1132 * ending in `.claude_todo`, that is its own real path (so no symlink is in it), inside the main
1133 * checkout, and neither the central folder nor the global one.
1134 */
1135async function isTrustedFolder($: EngineInterface, path: string, central: string, realCentral: string | undefined): Promise<boolean> {
1136  const parts = path.split('/')
1137  if (!path.startsWith('/') || parts.includes('..') || parts.filter(part => part !== '').pop() !== DIR || path === central) {
1138    return false
1139  }
1140  const real = await realOf($, path)
1141  const root = centralRoot === undefined ? undefined : await realOf($, centralRoot)
1142  if (real === undefined || real !== path || root === undefined || !real.startsWith(`${root}/`) || isGlobalTodo(real)) {
1143    return false
1144  }
1145
1146  return realCentral === undefined || real !== realCentral
1147}
1148
1149/** True for a regular file that is its own real path: no symlink in the file or the folders above it. */
1150async function isPlainFile($: EngineInterface, path: string): Promise<boolean> {
1151  const stat = await $.fs.stat(path).catch(() => undefined)
1152
1153  return stat !== undefined && stat.kind === 'file' && (await realOf($, path)) === path
1154}
1155
1156/**
1157 * Merges the entries of a duplicate folder's `categories.json` into the central book, keys mapped to
1158 * the central items (a renumbered ID follows its rename). True when the central book now holds them.
1159 */
1160async function mergeBook($: EngineInterface, dup: { path: string }, central: string): Promise<boolean> {
1161  try {
1162    const mine = JSON.parse(await readText($, `${dup.path}/categories.json`)) as Partial<CategoryBook>
1163    // An existing central book that will not read stops the merge: it is never replaced blind.
1164    const hasBook = await $.fs.exists(`${central}/categories.json`).catch(() => false)
1165    const text = hasBook ? await readStrict($, `${central}/categories.json`) : ''
1166    const theirs = text.trim() === '' ? ({} as Partial<CategoryBook>) : (JSON.parse(text) as Partial<CategoryBook>)
1167    const names = Array.isArray(theirs.categories) ? theirs.categories.filter((name): name is string => typeof name === 'string') : []
1168    const items: Record<string, string> = typeof theirs.items === 'object' && theirs.items !== null ? { ...theirs.items } : {}
1169    const renames = Object.assign({}, ...Object.entries(renameMap).filter(([file]) => file.startsWith(`${dup.path}/`)).map(([, map]) => map)) as Record<string, string>
1170    for (const [key, category] of Object.entries(typeof mine.items === 'object' && mine.items !== null ? mine.items : {})) {
1171      if (typeof category !== 'string') {
1172        continue
1173      }
1174      const bare = key.includes('::') ? key.slice(key.indexOf('::') + 2) : key
1175      const fresh = bare.startsWith('#') ? renames[bare.slice(1)] : undefined
1176      const mapped = fresh === undefined ? bare : `#${fresh.toLowerCase()}`
1177      if (!names.includes(category) && names.length < MAX_CATEGORIES) {
1178        names.push(category)
1179      }
1180      // A category the central book has no room for: keep the old book rather than lose it.
1181      if (!names.includes(category)) {
1182        return false
1183      }
1184      if (items[mapped] === undefined) {
1185        items[mapped] = category
1186      }
1187    }
1188    // Changed since the read: skip it, so an edit made meanwhile is not lost.
1189    if ((hasBook ? await readStrict($, `${central}/categories.json`) : '') !== text) {
1190      return false
1191    }
1192    await $.fs.write(`${central}/categories.json`, `${JSON.stringify({ categories: names, items }, null, 2)}\n`)
1193
1194    return true
1195  } catch {
1196    return false
1197  }
1198}
1199
1200/**

1/**
2 * The desktop look, to the Stage UI style guide (v1.10), with two deliberate
3 * exceptions: the cards follow the system theme (the stage palette when dark, the guide's
4 * light page tokens when light, LIGHT_CSS; STG-1 keeps the stage black in every theme), and each
5 * live agent has a color that its todo items blink (AGENT_COLORS; COL-8 names no category by
6 * color). Violet is progress and live (COL-1); failed is orange (COL-7). Motion is CSS, so reduced
7 * motion stops it (MOT-2). A card's markup holds nothing that changes with the clock alone: a
8 * redraw that changes no data sends the same markup, so the pane does not reload the image.
9 */
10
11export type ItemStatus = 'pending' | 'in_progress' | 'completed'
12
13export type ItemView = {
14  text: string
15  status: ItemStatus
16  owners: number[]
17  /** The item's stable key: its ID (`#t12`) when it has one, else its normalized text; qualified by folder outside the primary folder. */
18  key: string
19  /** The key without the folder: how the line is found in its file. Same as `key` when absent. */
20  localKey?: string
21  /** The source of the item, which the pane never shows: its folder, its file in that folder, and its path from the repo root. */
22  folder?: string
23  file?: string
24  path?: string
25  /** Shown in progress only because a live agent works on it: its box is still `- [ ]`. */
26  isHeld?: true
27}
28
29export type FileView = {
30  /** The file's path inside its folder. */
31  name: string
32  /** The file's ID in the pane: its name, or its folder and name when another file has that name. */
33  id: string
34  /** Where its folder sits in the repo (no `.claude_todo`); empty at the root. Shown only to tell same-named files apart. */
35  place?: string
36  done: number
37  active: number
38  total: number
39  owners: number[]
40  items: ItemView[]
41  mtimeMs: number
42  isArchived?: boolean
43  /** Category headings inside the card: each names the index of its first item. */
44  groups?: { name: string; from: number; count: number }[]
45}
46
47export type AgentView = {
48  index: number
49  description: string
50  type: string
51  model?: string
52  status: 'pending' | 'running' | 'waiting' | 'idle' | 'completed' | 'failed' | 'killed' | 'ended'
53  isEnded: boolean
54  startedAt: number
55  endedAt?: number
56  toolCalls: number
57  /** The tokens of every model request the agent made, every kind summed. */
58  tokens?: number
59  /** Its last turn ended and nothing followed: finished, but never stopped. Not live. */
60  isIdle?: boolean
61  idleSince?: number
62  doing?: string
63  /** The open todo items the agent works on, by text. */
64  links: string[]
65  progress?: { done: number; total: number; step?: string }
66}
67
68export type View = {
69  /** Every todo file, those with open items first; each carries all its items: linked, in progress, open, done. */
70  files: FileView[]
71  agents: AgentView[]
72  /** Counts over the files at the top of `.claude_todo/`; the archive is not in them. */
73  done: number
74  active: number
75  total: number
76  /** Done items in the completed ledger: checked items at the top level and every done item in the archive. */
77  completed: number
78  live: number
79  now: number
80  /** The session's token burn, when the mod has counted any. */
81  usage?: Usage
82}
83
84/**
85 * Tokens the session has used, main conversation and subagents, every kind (input, output, cache
86 * read and cache write) summed from each finished turn; what the total stood at when the
87 * conversation last compacted; and since when the mod has counted.
88 */
89export type Usage = { tokens: number; atCompact?: number; since: number }
90
91/** "950", "84.3k", "1.23M", "17.38M": a token count, to 2 decimals in millions and 1 in thousands. */
92export function tokens(n: number): string {
93  return n >= 1_000_000 ? `${(n / 1_000_000).toFixed(2)}M` : n >= 1000 ? `${(n / 1000).toFixed(1)}k` : String(Math.round(n))
94}
95
96// Stage UI tokens: section 3.3 (fixed) and 3.4 (stage palette).
97export const ACCENT = '#8B5CF6'
98export const PROGRESS_END = '#C084FC'
99export const INDICATOR = '#7C3AED'
100export const PRIMARY = '#22D3EE'
101export const SUGGESTED = '#10303B'
102export const DANGER = '#FB923C'
103export const STAGE_DANGER = '#FF7A33'
104export const GREEN = '#34D399'
105const STAGE_BG = '#07080F'
106const CARD = '#171A26'
107const ACTOR = '#1E2233'
108const STAGE_GRAY = '#9AA0B4'
109
110const LABEL = 'rgba(255,255,255,.88)'
111const SUB = 'rgba(255,255,255,.62)'
112const FAINT = 'rgba(255,255,255,.38)'
113const TRACK = 'rgba(255,255,255,.22)'
114const RULE = 'rgba(255,255,255,.08)'
115
116const PAD = 16
117let W = 384
118let INNER = W - PAD * 2
119
120/** The cards' width in CSS pixels, set once per draw from the pane's width. */
121export function setWidth(px: number): void {
122  W = Math.round(Math.min(960, Math.max(300, px)))
123  INNER = W - PAD * 2
124}
125
126export function agentLabel(index: number): string {
127  return `A${index + 1}`
128}
129
130/**
131 * Agent colors, a deliberate exception to Stage UI COL-8: each live agent
132 * blinks a color, and so does each todo item it works on. Six colors of a brand-neutral categorical
133 * palette, at their dark steps, in fixed order, checked for color-vision deficiency; never cycled, so an
134 * agent past the sixth is gray. The A1, A2 labels stay, so color is never the only cue (COL-9).
135 */
136export const AGENT_COLORS = ['#3987e5', '#d95926', '#199e70', '#c98500', '#d55181', '#9085e9']
137
138export function agentColor(index: number): string {
139  return AGENT_COLORS[index] ?? STAGE_GRAY_FALLBACK
140}
141
142const STAGE_GRAY_FALLBACK = '#9AA0B4'
143
144/**
145 * The light theme: each dark-palette color as drawn, and its Stage UI light page token (section
146 * 3.2). A CSS rule beats a presentation attribute, so one block per card swaps them all when the
147 * system is light; the desktop app on its default "system" theme follows the same setting. Agent
148 * colors and the violet progress stay as they are.
149 */
150const LIGHT: readonly (readonly [string, string, string])[] = [
151  ['fill', STAGE_BG, '#FFFFFF'],
152  ['stroke', STAGE_BG, '#FFFFFF'],
153  ['fill', 'rgba(255,255,255,.88)', '#10131C'],
154  ['fill', 'rgba(255,255,255,.62)', '#5A6072'],
155  ['fill', 'rgba(255,255,255,.38)', 'rgba(16,19,28,.45)'],
156  ['stroke', 'rgba(255,255,255,.38)', 'rgba(16,19,28,.45)'],
157  ['fill', 'rgba(255,255,255,.22)', 'rgba(16,19,28,.12)'],
158  ['stroke', 'rgba(255,255,255,.22)', 'rgba(16,19,28,.12)'],
159  ['stroke', 'rgba(255,255,255,.08)', 'rgba(16,19,28,.08)'],
160  ['fill', 'rgba(255,255,255,.1)', 'rgba(16,19,28,.06)'],
161  ['stroke', 'rgba(255,255,255,.6)', 'rgba(16,19,28,.35)'],
162  ['fill', '#171A26', '#F1F3F8'],
163  ['fill', '#1E2233', '#E1E4EE'],
164  ['fill', '#10303B', '#DDF6FB'],
165  ['fill', '#9AA0B4', '#6B7186'],
166  ['stroke', '#FFFFFF', '#10131C'],
167  ['stroke', '#9AA0B4', '#6B7186'],
168  ['fill', '#FB923C', '#B83C0B'],
169  ['fill', 'rgba(251,146,60,.16)', '#FFEDE3'],
170  ['fill', '#34D399', '#047857'],
171  ['fill', '#22D3EE', '#0E7490'],
172]
173
174export const LIGHT_CSS = `@media (prefers-color-scheme:light){${LIGHT.map(([prop, dark, light]) => `[${prop}="${dark}"]{${prop}:${light}}`).join('')}rect[fill="${STAGE_BG}"]{stroke:rgba(16,19,28,.12);stroke-width:2}}`
175const BLINK_S = 1.2
176const MAX_LINKS_SHOWN = 3
177
178/**
179 * The blink animations one card uses: a class per set of colors, which blinks each color in turn,
180 * 1.2 s per color. Reduced motion holds the first color solid.
181 */
182class Blinks {
183  private readonly rules = new Map<string, string>()
184
185  cls(colors: readonly string[]): string {
186    const id = colors.join(',')
187    const known = this.rules.get(id)
188    if (known !== undefined) {
189      return known.split('{')[0]?.slice(1) ?? ''
190    }
191    const name = `k${this.rules.size}`
192    const n = colors.length
193    const frames = colors
194      .map((color, k) => `${((k / n) * 100).toFixed(2)}%{fill:${color};opacity:1}${(((k + 0.5) / n) * 100).toFixed(2)}%{fill:${color};opacity:.25}`)
195      .join('')
196    this.rules.set(id, `.${name}{animation:${name} ${(BLINK_S * n).toFixed(1)}s steps(1,end) infinite}@keyframes ${name}{${frames}}`)
197
198    return name
199  }
200
201  css(): string {
202    const names = [...this.rules.values()].map(rule => `.${rule.split('{')[0]?.slice(1)}`)
203
204    return [...this.rules.values()].join('\n') + (names.length === 0 ? '' : `\n@media (prefers-reduced-motion:reduce){${names.join(',')}{animation:none}}`)
205  }
206}
207
208export function elapsed(ms: number): string {
209  const seconds = Math.max(0, Math.round(ms / 1000))
210  const minutes = Math.floor(seconds / 60)
211
212  return minutes === 0 ? `${seconds}s` : `${minutes}m ${String(seconds % 60).padStart(2, '0')}s`
213}
214
215/** "1 agent", "3 agents" (TXT-4). */
216export function plural(n: number, noun: string): string {
217  return `${n} ${noun}${n === 1 ? '' : 's'}`
218}
219
220function esc(text: string): string {
221  return text.replace(/&/g, '&amp;').replace(/</g, '&lt;').replace(/>/g, '&gt;').replace(/"/g, '&quot;')
222}
223
224/** Ends a single-line text with an ellipsis when it does not fit (TYP-3). */
225function fit(text: string, px: number, size: number, weight = 400, isMono = false): string {
226  const glyph = size * (isMono ? 0.62 : weight >= 500 ? 0.55 : 0.52)
227  const room = Math.max(1, Math.floor(px / glyph))
228
229  return text.length > room ? `${text.slice(0, Math.max(1, room - 1)).trimEnd()}…` : text
230}
231
232/** A drawn card: its SVG and its size in CSS pixels, so the pane sizes its frame to it. */
233export type Card = { source: string; width: number; height: number; alt: string }
234
235
236function stage(height: number, body: string, alt: string, css = ''): Card {
237  const source = `<svg xmlns="http://www.w3.org/2000/svg" width="${W}" height="${height}" viewBox="0 0 ${W} ${height}" role="img" aria-label="${esc(alt)}">
238<defs><linearGradient id="progress" x1="0" x2="1"><stop offset="0.7" stop-color="${ACCENT}"/><stop offset="1" stop-color="${PROGRESS_END}"/></linearGradient></defs>
239<style>
240text{font-family:"Instrument Sans","Helvetica Neue",Arial,sans-serif;font-variant-numeric:tabular-nums;-webkit-font-smoothing:antialiased}
241.mono{font-family:"Fragment Mono",ui-monospace,Menlo,monospace}
242.blink{animation:blink 1.2s steps(1,end) infinite}
243@keyframes blink{50%{opacity:.25}}
244.pulse{animation:pulse 1.2s cubic-bezier(0,0,.2,1) infinite;transform-box:fill-box;transform-origin:center}
245@keyframes pulse{0%{opacity:.6;transform:scale(1)}100%{opacity:0;transform:scale(2.4)}}
246@media (prefers-reduced-motion:reduce){.blink,.pulse{animation:none}.pulse{opacity:0}}
247${LIGHT_CSS}
248${css}
249</style>
250<rect width="${W}" height="${height}" rx="12" fill="${STAGE_BG}"/>
251${body}</svg>`
252
253  return { source, width: W, height, alt }
254}
255
256/** A wall-clock time in the local time zone, `14:32:05`. */
257export function clock(ms: number): string {
258  const at = new Date(ms)
259  const two = (n: number) => String(n).padStart(2, '0')
260
261  return `${two(at.getHours())}:${two(at.getMinutes())}:${two(at.getSeconds())}`
262}
263
264/**
265 * The Orchestrator card: one line per tool call summary, newest first, each with its start time in
266 * small text on the right; a call still running has a live dot, a finished one a quiet one.
267 */
268export function orchestratorSvg(entries: readonly { line: string; at: number; isRunning: boolean }[]): Card {
269  const h = 22 + entries.length * 22
270  const parts = entries.map((entry, k) => {
271    const y = 30 + k * 22
272    const dot = entry.isRunning
273      ? `<circle cx="${PAD + 5}" cy="${y - 4}" r="4" fill="${ACCENT}"/><circle cx="${PAD + 5}" cy="${y - 4}" r="4" fill="${ACCENT}" class="pulse"/>`
274      : `<circle cx="${PAD + 5}" cy="${y - 4}" r="3" fill="${FAINT}"/>`
275
276    return `${dot}<text x="${PAD + 18}" y="${y}" fill="${entry.isRunning ? LABEL : SUB}" font-size="13">${esc(fit(entry.line, INNER - 18 - 64, 13))}</text>
277<text x="${W - PAD}" y="${y}" text-anchor="end" fill="${FAINT}" font-size="10.5" class="mono">${clock(entry.at)}</text>`
278  })
279
280  return stage(h, parts.join('\n'), `Orchestrator: ${entries.map(entry => `${clock(entry.at)} ${entry.line}`).join('; ')}`)
281}
282
283/** A background task as the pane draws it: its short name, what kind it is, and how it stands. */
284export type TaskView = {
285  name: string
286  kind: 'shell' | 'monitor' | 'workflow'
287  /** `ended`: the helper agent that started it ended, and no word came of how the task ended. */
288  status: 'running' | 'completed' | 'failed' | 'killed' | 'ended'
289  startedAt: number
290  endedAt?: number
291}
292
293/** An actor disk: 12 px radius, letter 500; the state dot at its lower right (STG-DRAW-7, CMP-AV-4). */
294function actor(cx: number, cy: number, index: number, state: 'working' | 'failed' | 'none', isMatch: boolean, blinks: Blinks): string {
295  const color = agentColor(index)
296  const ring = isMatch ? `<circle cx="${cx}" cy="${cy}" r="14.5" fill="none" stroke="${color}" stroke-width="1.5"/>` : ''
297  const dot =
298    state === 'none'
299      ? ''
300      : state === 'failed'
301        ? `<circle cx="${cx + 8.5}" cy="${cy + 8.5}" r="4.5" fill="${STAGE_DANGER}" stroke="${STAGE_BG}" stroke-width="2"/>`
302        : `<circle cx="${cx + 8.5}" cy="${cy + 8.5}" r="4.5" fill="${color}" stroke="${STAGE_BG}" stroke-width="2" class="${blinks.cls([color])}"/>`
303
304  return `${ring}<circle cx="${cx}" cy="${cy}" r="12" fill="${ACTOR}" stroke="rgba(255,255,255,.6)" stroke-width="1.2"/>
305<text x="${cx}" y="${cy + 4}" text-anchor="middle" fill="${LABEL}" font-size="${index >= 9 ? 9.5 : 11}" font-weight="500">${agentLabel(index)}</text>${dot}`
306}
307
308/** A 4 px progress strip: white 22% track, `--progress` fill (STG-DRAW-5); the working share in white 38%. */
309function strip(x: number, y: number, w: number, done: number, active: number, total: number): string {
310  const wDone = total === 0 ? 0 : (done / total) * w
311  const wActive = total === 0 ? 0 : (active / total) * w
312
313  return `<rect x="${x}" y="${y}" width="${w}" height="4" rx="2" fill="${TRACK}"/>
314${wActive > 0 ? `<rect x="${x + wDone}" y="${y}" width="${wActive}" height="4" rx="2" fill="${FAINT}"/>` : ''}
315${wDone > 0 ? `<rect x="${x}" y="${y}" width="${Math.max(wDone, 4)}" height="4" rx="2" fill="url(#progress)"/>` : ''}`
316}
317
318function badgeWidth(label: string): number {
319  return Math.round(label.length * 6.4 + 12)
320}
321
322/** A status badge: 22 px high, radius 4, 500 12 px (CMP-BDG-1). */
323function badge(right: number, y: number, label: string, kind: 'live' | 'ok' | 'danger' | 'neutral'): string {
324  const w = badgeWidth(label)
325  const fill = kind === 'live' ? INDICATOR : kind === 'danger' ? 'rgba(251,146,60,.16)' : 'rgba(255,255,255,.1)'
326  const ink = kind === 'live' ? '#FFFFFF' : kind === 'danger' ? DANGER : kind === 'ok' ? GREEN : STAGE_GRAY
327
328  return `<rect x="${right - w}" y="${y - 15}" width="${w}" height="22" rx="4" fill="${fill}"/>
329<text x="${right - w / 2}" y="${y}" text-anchor="middle" fill="${ink}" font-size="12" font-weight="500">${esc(label)}</text>`
330}
331
332// ---------------------------------------------------------------- summary
333
334function ringArc(cx: number, cy: number, r: number, share: number): string {
335  const sweep = Math.min(Math.max(share, 0.0001), 0.9999)
336  const a1 = (sweep - 0.25) * 2 * Math.PI
337
338  return `M ${cx} ${cy - r} A ${r} ${r} 0 ${sweep > 0.5 ? 1 : 0} 1 ${(cx + r * Math.cos(a1)).toFixed(2)} ${(cy + r * Math.sin(a1)).toFixed(2)}`
339}
340
341/** A figure in a gauge's place: the number large, then its title and line, aligned with the rings. */
342function stat(cx: number, cy: number, value: string, title: string, detail: string): string {
343  const r = 34
344  // 32 px, smaller when the number would not fit its third of the card (a bold digit is about 0.6 em).
345  const size = Math.min(32, Math.floor((W / 3 - 16) / (value.length * 0.6)))
346
347  return `<text x="${cx}" y="${cy + 11}" text-anchor="middle" fill="${LABEL}" font-size="${size}" font-weight="700" letter-spacing="-0.5">${esc(value)}</text>
348<text x="${cx}" y="${cy + r + 24}" text-anchor="middle" fill="${LABEL}" font-size="14" font-weight="500">${esc(title)}</text>
349<text x="${cx}" y="${cy + r + 42}" text-anchor="middle" fill="${SUB}" font-size="12">${esc(detail)}</text>`
350}
351
352function gauge(cx: number, cy: number, share: number | undefined, value: string, unit: string, title: string, detail: string, stroke = 'url(#progress)', valueSize = 22): string {
353  const r = 34
354  const arc = share === undefined || share <= 0 ? '' : `<path d="${ringArc(cx, cy, r, share)}" fill="none" stroke="${stroke}" stroke-width="6" stroke-linecap="round"/>`
355
356  return `<circle cx="${cx}" cy="${cy}" r="${r}" fill="none" stroke="${TRACK}" stroke-width="6"/>${arc}
357<text x="${cx}" y="${cy + valueSize * 0.32}" text-anchor="middle" fill="${LABEL}" font-size="${valueSize}" font-weight="700">${esc(value)}<tspan fill="${SUB}" font-size="13" font-weight="500">${esc(unit)}</tspan></text>
358<text x="${cx}" y="${cy + r + 24}" text-anchor="middle" fill="${LABEL}" font-size="14" font-weight="500">${esc(title)}</text>
359<text x="${cx}" y="${cy + r + 42}" text-anchor="middle" fill="${SUB}" font-size="12">${esc(detail)}</text>`
360}
361
362/**
363 * The share of the agents' work done: a finished agent counts whole, a running one by the share
364 * of its plan it reports done, and one that has not reported counts as nothing yet.
365 */
366export function agentShare(agents: readonly AgentView[]): number {
367  if (agents.length === 0) {
368    return 0
369  }
370  const sum = agents.reduce((total, agent) => {
371    if (agent.isEnded || agent.isIdle) {
372      return total + 1
373    }
374    const progress = agent.progress
375
376    return total + (progress === undefined ? 0 : progress.done / progress.total)
377  }, 0)
378
379  return sum / agents.length
380}
381
382/** Two gauges: the share of todo items done, and the share of agents finished, with a live dot. */
383export function heroSvg(view: View): Card {
384  const n = view.agents.length
385  const ended = n - view.live
386  const at = [W / 6 + 4, W / 2, (W * 5) / 6 - 4]
387  const todo =
388    view.total === 0
389      ? gauge(at[0]!, 62, undefined, '', '', 'Todo', 'No items')
390      : gauge(at[0]!, 62, view.done / view.total, String(Math.round((view.done / view.total) * 100)), '%', 'Todo', `${view.done} of ${view.total} done`)
391  const agents =
392    n === 0
393      ? gauge(at[1]!, 62, undefined, '', '', 'Agents', 'None yet')
394      : gauge(at[1]!, 62, agentShare(view.agents), String(view.live), ' live', 'Agents', `${ended} of ${plural(n, 'agent')} finished`)
395  // Token burn: a number, not a ring.
396  const usage = view.usage
397  const burn =
398    usage === undefined
399      ? stat(at[2]!, 62, '', 'Tokens', 'None counted yet')
400      : stat(
401          at[2]!,
402          62,
403          tokens(usage.tokens),
404          'Tokens',
405          usage.atCompact === undefined ? 'No compaction yet' : `${tokens(usage.tokens - usage.atCompact)} since compact`,
406        )
407  const live =
408    view.live > 0
409      ? `<circle cx="${W - PAD - 4}" cy="${PAD + 4}" r="4" fill="${ACCENT}" class="pulse"/>
410<circle cx="${W - PAD - 4}" cy="${PAD + 4}" r="4" fill="${ACCENT}"/>
411<text x="${W - PAD - 14}" y="${PAD + 8}" text-anchor="end" fill="${SUB}" font-size="12">Live</text>`
412      : ''
413
414  return stage(166, `${todo}${agents}${burn}${live}`, `Todo ${view.done} of ${view.total} done. ${view.live} of ${plural(n, 'agent')} live.${usage === undefined ? '' : ` ${tokens(usage.tokens)} tokens used${usage.atCompact === undefined ? '' : `, ${tokens(usage.tokens - usage.atCompact)} since compact`}.`}`)
415}
416
417// ---------------------------------------------------------------- todo
418
419function itemMark(x: number, y: number, status: ItemStatus, owners: readonly number[], blinks: Blinks): string {
420  if (status === 'completed') {
421    return `<path d="M ${x - 4} ${y} l 2.8 2.8 l 5.2 -5.6" fill="none" stroke="#FFFFFF" stroke-width="1.6" stroke-linecap="round" stroke-linejoin="round"/>`
422  }
423  if (owners.length > 0) {
424    const colors = owners.map(agentColor)
425
426    return `<circle cx="${x}" cy="${y}" r="5" fill="${colors[0]}" class="${blinks.cls(colors)}"/>`
427  }
428  if (status === 'in_progress') {
429    return `<circle cx="${x}" cy="${y}" r="4" fill="${STAGE_GRAY}"/>`
430  }
431
432  return `<circle cx="${x}" cy="${y}" r="4.5" fill="none" stroke="${FAINT}" stroke-width="1.2"/>`
433}
434
435const ITEMS_PER_CARD = 40
436const LINE_H = 18
437const MAX_LINES = 8
438
439/**
440 * Breaks a text into lines that fit `px` at `size`, at spaces where it can and inside a long word
441 * where it must; past `maxLines` the last line ends with an ellipsis (TYP-3: long free text wraps).
442 */
443export function wrap(text: string, px: number, size: number, weight = 400, maxLines = MAX_LINES): string[] {
444  const room = Math.max(8, Math.floor(px / (size * (weight >= 500 ? 0.55 : 0.52))))
445  const lines: string[] = []
446  let line = ''
447  for (const word of text.split(/\s+/).filter(one => one !== '')) {
448    let rest = word
449    while (rest.length > room) {
450      if (line !== '') {
451        lines.push(line)
452        line = ''
453      }
454      lines.push(rest.slice(0, room))
455      rest = rest.slice(room)
456    }
457    if (line === '') {
458      line = rest
459    } else if (line.length + 1 + rest.length <= room) {
460      line = `${line} ${rest}`
461    } else {
462      lines.push(line)
463      line = rest
464    }
465  }
466  if (line !== '' || lines.length === 0) {
467    lines.push(line)
468  }
469  if (lines.length <= maxLines) {
470    return lines
471  }
472  const kept = lines.slice(0, maxLines)
473  kept[maxLines - 1] = `${(kept[maxLines - 1] ?? '').slice(0, Math.max(1, room - 1)).trimEnd()}…`
474
475  return kept
476}
477
478/**
479 * One todo file as cards: the first carries its name, count and strip; then up to `limit` of its
480 * items in the view's order, 40 to a card, so a file of any length stays inside the SVG limit. An
481 * item longer than 8 lines stops there with an ellipsis, unless `isTextOpen` shows every item whole.
482 */
483/**
484 * One ticket as a Stage UI card, `width` px wide: a 12 px container on the tonal card fill; a top
485 * row with the status mark, an ID chip, a category chip and a status badge; the item's text, up to
486 * 4 lines; and the agents on it as colored chips. In progress draws a violet accent bar (progress,
487 * COL-1); a ticket an agent works on draws its border and bar in the agent's color instead. When
488 * `actions` (a count), a bottom row of its own is kept free for the pane's buttons and their tips.
489 */
490export function ticketSvg(item: ItemView, view: View, width: number, info: { id?: string; category?: string; isSent: boolean; actions?: number }): Card {
491  const w = Math.max(200, Math.round(width))
492  const pad = 14
493  const blinks = new Blinks()
494  const owner = item.owners[0]
495  const accent = owner !== undefined ? agentColor(owner) : item.status === 'in_progress' ? ACCENT : undefined
496  const parts: string[] = []
497  let x = pad
498  const top = 22
499  // Status mark
500  if (item.status === 'completed') {
501    parts.push(`<path d="M ${x} ${top - 1} l 2.8 2.8 l 5.2 -5.6" fill="none" stroke="#FFFFFF" stroke-width="1.6" stroke-linecap="round" stroke-linejoin="round"/>`)
502  } else if (owner !== undefined) {
503    const colors = item.owners.map(agentColor)
504    parts.push(`<circle cx="${x + 4}" cy="${top - 3}" r="4.5" fill="${colors[0]}" class="${blinks.cls(colors)}"/>`)
505  } else if (item.status === 'in_progress') {
506    parts.push(`<circle cx="${x + 4}" cy="${top - 3}" r="4" fill="${STAGE_GRAY}"/>`)
507  } else {
508    parts.push(`<circle cx="${x + 4}" cy="${top - 3}" r="4.5" fill="none" stroke="${FAINT}" stroke-width="1.2"/>`)
509  }
510  x += 16
511  // Status badge, right
512  const status = info.isSent && item.status !== 'completed' ? { label: 'Sent', kind: 'neutral' as const } : item.status === 'completed' ? { label: 'Done', kind: 'ok' as const } : item.status === 'in_progress' ? { label: 'In progress', kind: 'live' as const } : { label: 'Open', kind: 'neutral' as const }
513  const badgeRight = w - pad
514  parts.push(badge(badgeRight, top + 2, status.label, status.kind))
515  const room = badgeRight - badgeWidth(status.label) - 8
516  // ID chip
517  if (info.id !== undefined && x + 40 < room) {
518    const cw = Math.round(info.id.length * 7 + 14)
519    parts.push(`<rect x="${x}" y="${top - 13}" width="${cw}" height="20" rx="8" fill="rgba(255,255,255,.1)"/>
520<text x="${x + cw / 2}" y="${top + 1}" text-anchor="middle" fill="${LABEL}" font-size="11" class="mono">${esc(info.id)}</text>`)
521    x += cw + 6
522  }
523  // Category chip
524  if (info.category !== undefined && x + 40 < room) {
525    const label = fit(info.category, room - x - 16, 11, 500)
526    const cw = Math.round(label.length * 6 + 16)
527    parts.push(`<rect x="${x + 0.5}" y="${top - 12.5}" width="${cw}" height="19" rx="9.5" fill="none" stroke="rgba(255,255,255,.22)"/>
528<text x="${x + cw / 2}" y="${top + 1}" text-anchor="middle" fill="${SUB}" font-size="11" font-weight="500">${esc(label)}</text>`)
529  }
530  // Body
531  const text = info.id === undefined ? item.text : item.text.replace(info.id, '').replace(/^\s*[:.-]?\s*/, '')
532  const lines = wrap(text, w - pad * 2, 13, 400, 4)
533  let y = top + 26
534  const ink = item.status === 'completed' ? FAINT : LABEL
535  const strike = item.status === 'completed' ? ' text-decoration="line-through"' : ''
536  parts.push(`<text x="${pad}" y="${y}" fill="${ink}" font-size="13"${strike}>${lines.map((line, k) => `<tspan x="${pad}" dy="${k === 0 ? 0 : 18}">${esc(line)}</tspan>`).join('')}</text>`)
537  y += (lines.length - 1) * 18 + 10
538  // Agents
539  if (item.owners.length > 0) {
540    let ax = pad
541    for (const o of item.owners) {
542      const label = agentLabel(o)
543      const cw = Math.round(label.length * 7 + 14)
544      parts.push(`<rect x="${ax}" y="${y}" width="${cw}" height="18" rx="9" fill="${agentColor(o)}"/>
545<text x="${ax + cw / 2}" y="${y + 13}" text-anchor="middle" fill="#FFFFFF" font-size="10.5" font-weight="700">${label}</text>`)
546      ax += cw + 6
547    }
548    const working = view.agents[owner ?? 0]
549    if (working !== undefined) {
550      parts.push(`<text x="${ax + 2}" y="${y + 13}" fill="${SUB}" font-size="11">${esc(fit(working.description, w - ax - pad - 2, 11))}</text>`)
551    }
552    y += 26
553  }
554  if ((info.actions ?? 0) > 0) {
555    y += SEND_ROW_PX
556  }
557  const h = y + 8
558  const frame = `<rect x="0.75" y="0.75" width="${w - 1.5}" height="${h - 1.5}" rx="12" fill="${CARD}" stroke="${owner !== undefined ? agentColor(owner) : RULE}" stroke-width="${owner !== undefined ? 1.5 : 1}"/>`
559  const bar = accent === undefined ? '' : `<rect x="0" y="12" width="3" height="${h - 24}" rx="1.5" fill="${accent}"/>`
560  const body = item.status === 'completed' ? `<g opacity=".6">${parts.join('\n')}</g>` : parts.join('\n')
561  const source = `<svg xmlns="http://www.w3.org/2000/svg" width="${w}" height="${h}" viewBox="0 0 ${w} ${h}" role="img" aria-label="${esc(`${status.label}: ${item.text.slice(0, 120)}`)}">
562<style>
563text{font-family:"Instrument Sans","Helvetica Neue",Arial,sans-serif;font-variant-numeric:tabular-nums;-webkit-font-smoothing:antialiased}
564.mono{font-family:"Fragment Mono",ui-monospace,Menlo,monospace}
565${LIGHT_CSS}
566${blinks.css()}
567</style>
568${frame}${bar}
569${body}</svg>`
570
571  return { source, width: w, height: h, alt: `${status.label}: ${item.text.slice(0, 200)}` }
572}
573
574/** The button row's height: a native button, raised one row off the card's bottom edge. */
575export const SEND_ROW_PX = 60
576
577/** The pane's card width, for laying tickets out in columns beside it. */
578export function cardWidth(): number {
579  return W
580}
581
582/** How many of the first `limit` items of a file run past 8 lines, for the Show full text button. */
583export function longItems(file: FileView, limit: number): number {
584  return file.items.slice(0, limit).filter(item => {
585    const room = INNER - 24 - item.owners.length * 32
586
587    return wrap(item.text, room, 13, item.owners.length > 0 ? 500 : 400, Number.POSITIVE_INFINITY).length > MAX_LINES
588  }).length
589}
590
591export function fileCards(file: FileView, view: View, limit: number, isTextOpen = false): Card[] {
592  const shown = file.items.slice(0, limit)
593  const cards: Card[] = []
594  let parts: string[] = []
595  let blinks = new Blinks()
596  let y = 0
597  let count = 0
598  let first = 0
599  const begin = (isFirst: boolean) => {
600    parts = []
601    blinks = new Blinks()
602    y = 8
603    count = 0
604    if (isFirst) {
605      y = 26
606      parts.push(`<text x="${PAD}" y="${y}" fill="${LABEL}" font-size="14" font-weight="500">${esc(fit(file.name, INNER - 70, 14, 500))}</text>
607<text x="${W - PAD}" y="${y}" text-anchor="end" fill="${SUB}" font-size="12">${file.done} of ${file.total}</text>`)
608      parts.push(strip(PAD, y + 9, INNER, file.done, file.active, file.total))
609      y += 22
610    }
611    y += 18
612  }
613  const flush = () => {
614    const body = file.isArchived === true ? `<g opacity=".55">${parts.join('\n')}</g>` : parts.join('\n')
615    const card = stage(y - 6, body, `${file.name}: ${file.done} of ${file.total} done${first > 0 ? `, items ${first + 1} on` : ''}`, blinks.css())
616    cards.push(card)
617  }
618  begin(true)
619  shown.forEach((item, index) => {
620    if (count === ITEMS_PER_CARD) {
621      flush()
622      first = index
623      begin(false)
624    }
625    const group = file.groups?.find(one => one.from === index)
626    if (group !== undefined) {
627      parts.push(`<text x="${PAD}" y="${y + 2}" fill="${SUB}" font-size="12" font-weight="500">${esc(fit(group.name, INNER - 40, 12, 500))}</text>
628<text x="${W - PAD}" y="${y + 2}" text-anchor="end" fill="${FAINT}" font-size="11">${group.count}</text>
629<line x1="${PAD}" y1="${y + 9}" x2="${W - PAD}" y2="${y + 9}" stroke="${RULE}"/>`)
630      y += 30
631    }
632    const isMatch = item.owners.length > 0
633    const weight = isMatch ? 500 : 400
634    const room = INNER - 24 - item.owners.length * 32
635    const lines = wrap(item.text, room, 13, weight, isTextOpen ? Number.POSITIVE_INFINITY : MAX_LINES)
636    const extra = (lines.length - 1) * LINE_H
637    if (isMatch) {
638      parts.push(`<rect x="${PAD - 8}" y="${y - 17}" width="${INNER + 16}" height="${32 + extra}" rx="8" fill="${SUGGESTED}"/>`)
639    }
640    parts.push(itemMark(PAD + 6, y - 1, item.status, item.owners, blinks))
641    const ink = isMatch || item.status === 'in_progress' ? LABEL : item.status === 'completed' ? FAINT : LABEL
642    const strike = item.status === 'completed' ? ' text-decoration="line-through"' : ''
643    const tspans = lines.map((line, k) => `<tspan x="${PAD + 22}" dy="${k === 0 ? 0 : LINE_H}">${esc(line)}</tspan>`).join('')
644    parts.push(`<text x="${PAD + 22}" y="${y + 3}" fill="${ink}" font-size="13" font-weight="${weight}"${strike}>${tspans}</text>`)
645    item.owners.forEach((owner, k) => {
646      const agent = view.agents[owner]
647      const failed = agent?.status === 'failed' || agent?.status === 'killed'
648      parts.push(actor(W - PAD - 6 - k * 32, y - 1, owner, failed ? 'failed' : agent?.isEnded === false ? 'working' : 'none', true, blinks))
649    })
650    y += 34 + extra
651    count += 1
652  })
653  if (count > 0 || cards.length === 0) {
654    flush()
655  }
656
657  return cards
658}
659
660/** The height of one file row in the board header. */
661const HEAD_ROW_PX = 44
662
663/**
664 * The ticket board's header: one row per file, each with its name, its own progress strip and its
665 * own "done of total". With one file it is the same card as the list view's first card. A file's
666 * place (its folder) shows in dim text after the name only when another row has the same name,
667 * since the two rows would look the same. Archived files are grayed.
668 */
669export function boardHead(files: readonly FileView[]): Card {
670  const counts = new Map<string, number>()
671  for (const file of files) {
672    counts.set(file.name, (counts.get(file.name) ?? 0) + 1)
673  }
674  const rows = files.map((file, i) => {
675    const y = 26 + i * HEAD_ROW_PX
676    const place = (counts.get(file.name) ?? 0) > 1 && file.place !== undefined && file.place !== '' ? file.place : undefined
677    const room = INNER - 70
678    const placeText = place === undefined ? undefined : fit(place, Math.floor(room / 2), 12)
679    const nameText = fit(file.name, placeText === undefined ? room : room - placeText.length * 12 * 0.52 - 10, 14, 500)
680    // The place rides in the name's own text, so the gap is the font's, not a width guess.
681    const placeSpan = placeText === undefined ? '' : `<tspan dx="10" fill="${FAINT}" font-size="12" font-weight="400">${esc(placeText)}</tspan>`
682    const body = `<text x="${PAD}" y="${y}" fill="${LABEL}" font-size="14" font-weight="500">${esc(nameText)}${placeSpan}</text>
683<text x="${W - PAD}" y="${y}" text-anchor="end" fill="${SUB}" font-size="12">${file.done} of ${file.total}</text>
684${strip(PAD, y + 9, INNER, file.done, file.active, file.total)}`
685
686    return file.isArchived === true ? `<g opacity=".55">${body}</g>` : body
687  })
688  const height = 26 + Math.max(0, files.length - 1) * HEAD_ROW_PX + 34
689
690  return stage(height, rows.join('\n'), files.map(file => `${file.name}: ${file.done} of ${file.total} done`).join('; '))
691}
692
693// ---------------------------------------------------------------- agents
694
695function agentBadge(agent: AgentView): { label: string; kind: 'live' | 'ok' | 'danger' | 'neutral' } {
696  if (agent.isIdle) {
697    return { label: 'Idle', kind: 'neutral' }
698  }
699  if (agent.status === 'completed') {
700    return { label: 'Done', kind: 'ok' }
701  }
702  if (agent.status === 'failed') {
703    return { label: 'Failed', kind: 'danger' }
704  }
705  if (agent.status === 'killed') {
706    return { label: 'Stopped', kind: 'danger' }
707  }
708  if (agent.status === 'running') {
709    return { label: 'Running', kind: 'live' }
710  }
711
712  return { label: `${agent.status.charAt(0).toUpperCase()}${agent.status.slice(1)}`, kind: 'neutral' }
713}
714
715/** A span of wall-clock time the timeline shows: from `start` to `end`, in ms since the epoch. */
716/**
717 * The agents' timeline, from the first agent's start to now: one strip per agent. The right end
718 * reads "Now" and a running strip pulses at its head.
719 */
720export function timelineSvg(view: View, all: readonly AgentView[]): Card {
721  const t0 = Math.min(...all.map(a => a.startedAt))
722  const t1 = view.now
723  const agents = [...all]
724  const n = agents.length
725  const parts: string[] = []
726  const blinks = new Blinks()
727  const plotX = PAD + 34
728  const plotW = INNER - 34 - 52
729  const span = Math.max(1000, t1 - t0)
730  const x = (t: number) => plotX + ((Math.min(Math.max(t, t0), t1) - t0) / span) * plotW
731  const top = 26
732  const rowH = 30
733  const axisY = top + Math.max(n, 1) * rowH - 8
734  for (const f of [0, 0.5, 1]) {
735    const gx = plotX + f * plotW
736    const t = t0 + f * span
737    const tick = f === 1 ? 'Now' : `${elapsed(view.now - t)} ago`
738    parts.push(`<line x1="${gx}" y1="${top - 16}" x2="${gx}" y2="${axisY}" stroke="${RULE}"/>
739<text x="${gx}" y="${axisY + 16}" text-anchor="${f === 0 ? 'start' : f === 1 ? 'end' : 'middle'}" fill="${FAINT}" font-size="11">${tick}</text>`)
740  }
741  if (n === 0) {
742    parts.push(`<text x="${plotX + plotW / 2}" y="${top + 4}" text-anchor="middle" fill="${SUB}" font-size="12">No agents ran in this window</text>`)
743  }
744  agents.forEach((agent, i) => {
745    const y = top + i * rowH
746    const end = agent.endedAt ?? agent.idleSince ?? view.now
747    const x0 = x(agent.startedAt)
748    const w = Math.max(6, x(end) - x0)
749    const failed = agent.status === 'failed' || agent.status === 'killed'
750    parts.push(agent.isEnded ? '<g opacity=".55">' : '<g>')
751    parts.push(actor(PAD + 12, y - 2, agent.index, failed ? 'failed' : agent.isEnded ? 'none' : 'working', false, blinks))
752    const fill = agent.isEnded ? (failed ? STAGE_DANGER : TRACK) : 'url(#progress)'
753    parts.push(`<rect x="${x0}" y="${y - 4}" width="${w}" height="4" rx="2" fill="${fill}"/>`)
754    if (agent.status === 'completed' && end <= t1) {
755      parts.push(`<path d="M ${x0 + w + 5} ${y - 2} l 2.4 2.4 l 4.6 -5" fill="none" stroke="#FFFFFF" stroke-width="1.5" stroke-linecap="round" stroke-linejoin="round"/>`)
756    } else if (!agent.isEnded && !agent.isIdle) {
757      parts.push(`<circle cx="${x0 + w}" cy="${y - 2}" r="4" fill="${ACCENT}" class="pulse"/>
758<circle cx="${x0 + w}" cy="${y - 2}" r="3.5" fill="${ACCENT}"/>`)
759    }
760    parts.push(`<text x="${W - PAD}" y="${y + 2}" text-anchor="end" fill="${SUB}" font-size="12">${elapsed(end - agent.startedAt)}</text></g>`)
761  })
762
763  return stage(axisY + 28, parts.join('\n'), `Timeline of ${plural(n, 'agent')}`, blinks.css())
764}
765
766/** One agent: actor, name and status badge; the item it works on; meta; current tool call. */
767/** The room left of a live agent's badge that the card keeps free for the pane's Stop button. */
768export const STOP_PX = 44
769/** The gap between a live agent's Stop button and its badge. */
770const STOP_GAP_PX = 8
771/**
772 * How far an agent card's title row sits below its usual place: the pane places the Stop button
773 * in whole text rows, and one row down puts its center 5 px below a badge at the usual place.
774 */
775const HEAD_DROP_PX = 5
776
777/** How far a live agent's Stop button sits from the card's right padding: past the badge and a gap. */
778export function stopInsetPx(agent: AgentView): number {
779  return badgeWidth(agentBadge(agent).label) + STOP_GAP_PX
780}
781
782export function agentSvg(agent: AgentView, view: View): Card {
783  const parts: string[] = []
784  // A live agent's title ends short of its Stop button, left of the badge.
785  const stop = agent.isEnded ? 0 : STOP_PX
786  const failed = agent.status === 'failed' || agent.status === 'killed'
787  const { label, kind } = agentBadge(agent)
788  const bw = badgeWidth(label)
789  const blinks = new Blinks()
790  const color = agentColor(agent.index)
791  const shownLinks = agent.links.slice(0, MAX_LINKS_SHOWN)
792  const moreLinks = agent.links.length - shownLinks.length
793  const hasLink = shownLinks.length > 0
794  const progress = agent.isEnded ? undefined : agent.progress
795  const lines = 2 + shownLinks.length + (moreLinks > 0 ? 1 : 0) + (!agent.isEnded && agent.doing !== undefined ? 1 : 0) + (progress !== undefined ? 1 : 0)
796  const h = 20 + HEAD_DROP_PX + lines * 20 + (progress !== undefined ? 8 : 0)
797  if (hasLink && !agent.isEnded) {
798    parts.push(`<rect x="1" y="1" width="${W - 2}" height="${h - 2}" rx="11" fill="none" stroke="${color}" stroke-opacity=".55"/>`)
799  }
800  parts.push(actor(PAD + 12, 26 + HEAD_DROP_PX, agent.index, failed ? 'failed' : agent.isEnded ? 'none' : 'working', hasLink && !agent.isEnded, blinks))
801  let ty = 31 + HEAD_DROP_PX
802  const tx = PAD + 36
803  parts.push(`<text x="${tx}" y="${ty}" fill="${agent.isEnded ? SUB : LABEL}" font-size="14" font-weight="500">${esc(fit(agent.description, INNER - 44 - bw - stop, 14, 500))}</text>`)
804  parts.push(badge(W - PAD, ty, label, kind))
805  ty += 20
806  for (const link of shownLinks) {
807    parts.push(`<circle cx="${tx + 4}" cy="${ty - 4}" r="4" fill="${color}" class="${blinks.cls([color])}"/>
808<text x="${tx + 14}" y="${ty}" fill="${SUB}" font-size="12">Working on <tspan fill="${color}" font-weight="500">${esc(fit(link, INNER - 130, 12, 500))}</tspan></text>`)
809    ty += 20
810  }
811  if (moreLinks > 0) {
812    parts.push(`<text x="${tx + 14}" y="${ty}" fill="${SUB}" font-size="12">and ${plural(moreLinks, 'more item')}</text>`)
813    ty += 20
814  }
815  if (progress !== undefined) {
816    const percent = Math.round((progress.done / progress.total) * 100)
817    const label = `Step ${Math.min(progress.done + 1, progress.total)} of ${progress.total}${progress.step ? `: ${progress.step}` : ''}`
818    parts.push(`<text x="${tx}" y="${ty}" fill="${LABEL}" font-size="12" font-weight="500">${esc(fit(label, INNER - 90, 12, 500))}</text>
819<text x="${W - PAD}" y="${ty}" text-anchor="end" fill="${SUB}" font-size="12">${percent}%</text>`)
820    parts.push(strip(tx, ty + 7, W - PAD - tx, progress.done, 0, progress.total))
821    ty += 28
822  }
823  const ran = elapsed((agent.endedAt ?? agent.idleSince ?? view.now) - agent.startedAt)
824  const isIdle = agent.isIdle === true && agent.idleSince !== undefined
825  const when = agent.endedAt !== undefined ? [`ran ${ran}`, `ended ${elapsed(view.now - agent.endedAt)} ago`] : isIdle ? [`ran ${ran}`] : [ran]
826  // An idle agent's note leads, so a narrow card never cuts it off.
827  const meta = [isIdle ? `Finished ${clock(agent.idleSince!)}, not stopped` : undefined, agent.type, agent.model, ...when, plural(agent.toolCalls, 'tool call'), agent.tokens ? `${tokens(agent.tokens)} tokens` : undefined]
828    .filter((part): part is string => part !== undefined && part !== '')
829    .join('\u2002·\u2002')
830  parts.push(`<text x="${tx}" y="${ty}" fill="${SUB}" font-size="12">${esc(fit(meta, INNER - 40, 12))}</text>`)
831  ty += 20
832  if (!agent.isEnded && agent.doing !== undefined) {
833    // An idle agent's call has long returned: it is the last one, not the current one.
834    const doing = agent.isIdle ? `Last: ${agent.doing}` : agent.doing
835    parts.push(`<text x="${tx}" y="${ty}" fill="${SUB}" font-size="12" class="mono">${esc(fit(doing, INNER - 44, 12, 400, true))}</text>`)
836  }
837
838  // A finished agent stays in the ledger, grayed out (STG-DRAW-6: a quiet item draws at reduced opacity).
839  const body = agent.isEnded ? `<g opacity=".55">${parts.join('\n')}</g>` : parts.join('\n')
840
841  return stage(h, body, `${agentLabel(agent.index)}, ${agent.description}: ${label}`, blinks.css())
842}
843

1export type TodoStatus = 'pending' | 'in_progress' | 'completed'
2
3export type TodoItem = {
4  text: string
5  status: TodoStatus
6  /** The item's ID without its `#` (`T12`), when the line carries one. */
7  id?: string
8}
9
10export type TodoFile = {
11  /** The file's path under its `.claude_todo/` folder: `OPEN.md`, or `archive/OLD.md` for an archived one. */
12  name: string
13  /** The path of the `.claude_todo/` folder the file lives in, as the engine's fs takes it. Folder plus name identify a file. */
14  folder: string
15  /** The folder's path from the repo root, ending in `.claude_todo` (`mods/x/.claude_todo`); `folder` when not known. */
16  rel?: string
17  /** True for a folder other than the primary one (the nearest to the session folder): its item keys carry its place, so equal IDs stay apart. The pane never shows the folder. */
18  isOther?: true
19  mtimeMs: number
20  items: TodoItem[]
21  /** True for a file in `.claude_todo/archive/`: finished work, listed in the completed ledger. */
22  isArchived?: boolean
23}
24
25/** `ended`: the agent left the engine's agent list with no word of how it ended. */
26export type AgentRowStatus = 'pending' | 'running' | 'waiting' | 'idle' | 'completed' | 'failed' | 'killed' | 'ended'
27
28export type AgentRow = {
29  id: string
30  description: string
31  type: string
32  model?: string
33  status: AgentRowStatus
34  startedAt: number
35  endedAt?: number
36  toolCalls: number
37  /** The tokens of every model request the agent made, every kind summed. */
38  tokens?: number
39  doing?: string
40  /** The description and the head of the prompt, lowercased, for linking to todo items. */
41  brief: string
42  /** What SendMessage addresses the agent by, when it has a name. */
43  name?: string
44  /**
45   * When the agent's last turn ended with nothing after it: the work is done, but the agent was
46   * never stopped. Cleared by its next tool call or model request.
47   */
48  idleSince?: number
49  /** The agent's own report through `report_progress`: steps done of its plan, and the current one. */
50  progress?: Progress
51  /** The todo items the agent says it handles, as it quoted them through `report_progress`. */
52  claims?: string[]
53  /** The todo items Haiku matched to the agent's task when it started, by their text. */
54  autoClaims?: string[]
55}
56
57export type Progress = { done: number; total: number; step?: string }
58
