Runway

1import { atom, read, update } from 'claude-code'
2import type { ElementTable, EngineInterface, Register, RenderElement } from 'claude-code'
3
4import type { Context, Limit } from '../types'
5import { OLD_AFTER, brief, contextDetailsOf, detailsOf, fitting, isReading, labelOf, oldDetailsOf, severityOf, thresholdOf, viewOf } from './format'
6import type { LimitView, Segment, Severity, Tone } from './format'
7import { METER_HEIGHT, meterRuns, meterSvg } from './meter'
8import type { MeterRole } from './meter'
9
10const limitsAtom = atom({ plugin: 'Runway', key: 'limits' } as const, [])
11const contextAtom = atom({ plugin: 'Runway', key: 'context' } as const, null)
12const readingAtAtom = atom({ plugin: 'Runway', key: 'readingAt' } as const, 0)
13const nowAtom = atom({ plugin: 'Runway', key: 'now' } as const, 0)
14const toastedAtom = atom({ plugin: 'Runway', key: 'toasted' } as const, {})
15
16// The store key every chat saves its latest reading under, for the next chat to start from.
17const LATEST = 'latest'
18
19// Checked against light and dark surfaces alike, since a mod cannot tell which
20// theme it draws on: accent, warning and critical fills, and the muted ink.
21const COLORS: Record<Severity, string> = {
22  normal: '#3987e5',
23  warning: '#c98500',
24  critical: '#d03b3b',
25}
26const MUTED = '#898781'
27
28const GAP = 3
29const MIN_TILE = 22
30const MAX_TILE = 48
31// More CSS pixels than a desktop cell holds, so a meter drawn this wide is
32// always narrowed to its tile rather than falling short of it.
33const PX_PER_CELL = 9
34
35type Elements = Pick<ElementTable<'terminal'>, 'Box' | 'Text'>
36type Meter = (view: LimitView, width: number, color: string, alt: string) => RenderElement
37
38function layoutOf(columns: number, count: number) {
39  const fit = Math.floor((columns - GAP * (count - 1)) / count)
40
41  return fit >= MIN_TILE
42    ? { direction: 'row' as const, tile: Math.min(MAX_TILE, fit) }
43    : { direction: 'column' as const, tile: Math.min(MAX_TILE, columns) }
44}
45
46function altOf(limit: Limit, view: LimitView) {
47  const used = `${labelOf(limit.kind)} limit, ${Math.round(view.percent)}% used`
48
49  return view.elapsed === undefined ? used : `${used}, ${Math.round(view.elapsed * 100)}% of the window gone`
50}
51
52function runStyle(role: MeterRole, color: string) {
53  switch (role) {
54    case 'fill':
55      return { color }
56    case 'mark-fill':
57      return { color, bold: true }
58    case 'mark-empty':
59      return { color: MUTED }
60    case 'empty':
61      return { dimColor: true }
62  }
63}
64
65const markOf = (severity: Severity) => (severity === 'critical' ? '◆ ' : '▲ ')
66
67// A label and its percentage; the label alone where the reading is too old to show.
68type FigureProps = { elements: Elements; label: string; percent?: number | undefined }
69
70function Figure({ elements, label, percent }: FigureProps) {
71  const { Box, Text } = elements
72
73  if (percent === undefined) {
74    return (
75      <Box flexShrink={0}>
76        <Text>{label}</Text>
77      </Box>
78    )
79  }
80
81  const severity = severityOf(percent)
82
83  return (
84    <Box flexShrink={0}>
85      <Text>{`${label} `}</Text>
86      {severity !== 'normal' && <Text color={COLORS[severity]}>{markOf(severity)}</Text>}
87      <Text bold>{`${Math.round(percent)}%`}</Text>
88    </Box>
89  )
90}
91
92// The cells a tile `width` across has left beside its figure, after the gap between them.
93function roomBeside(label: string, percent: number | undefined, width: number) {
94  const severity = percent === undefined ? 'normal' : severityOf(percent)
95  const figure = percent === undefined ? label : `${label} ${severity === 'normal' ? '' : markOf(severity)}${Math.round(percent)}%`
96
97  return width - figure.length - 1
98}
99
100function toneStyle(tone: Tone) {
101  switch (tone) {
102    case 'plain':
103      return {}
104    case 'dim':
105      return { dimColor: true }
106    case 'warning':
107      return { color: COLORS.warning }
108  }
109}
110
111type DetailProps = { elements: Elements; segments: readonly Segment[] }
112
113// Measured to fit rather than left to wrap. A lone run is plain text, the likeliest to be
114// cut short with an ellipsis where a surface's text runs wider than measured.
115function Detail({ elements, segments }: DetailProps) {
116  const { Box, Text } = elements
117  const [only] = segments
118
119  return (
120    <Box flexShrink={1} minWidth={0}>
121      {segments.length === 1 && only !== undefined ? (
122        <Text {...toneStyle(only.tone)} wrap="truncate-end">
123          {only.text}
124        </Text>
125      ) : (
126        <Text wrap="truncate-end">
127          {segments.map(segment => (
128            <Text {...toneStyle(segment.tone)}>{segment.text}</Text>
129          ))}
130        </Text>
131      )}
132    </Box>
133  )
134}
135
136type HeaderProps = {
137  elements: Elements
138  label: string
139  percent?: number | undefined
140  candidates: readonly Segment[][]
141  width: number
142}
143
144// The figure, and the fullest detail that fits beside it on one line.
145function Header({ elements, label, percent, candidates, width }: HeaderProps) {
146  const { Box } = elements
147  const segments = fitting(candidates, roomBeside(label, percent, width))
148
149  return (
150    <Box justifyContent="space-between" alignItems="flex-start" columnGap={1}>
151      <Figure elements={elements} label={label} percent={percent} />
152      {segments.length > 0 && <Detail elements={elements} segments={segments} />}
153    </Box>
154  )
155}
156
157// A tile's two parts: its figure and detail, and its meter, which a reading too old to
158// show goes without.
159type Column = { header: RenderElement; meter?: RenderElement }
160
161type Shape = { width: number; isBrief: boolean; isOld: boolean; meter: Meter }
162
163function limitColumn(elements: Elements, limit: Limit, view: LimitView, { width, isBrief, isOld, meter }: Shape): Column {
164  const label = labelOf(limit.kind)
165  const pick = (candidates: readonly Segment[][]) => (isBrief ? brief(candidates) : candidates)
166
167  if (isOld) {
168    return { header: <Header elements={elements} label={label} candidates={pick(oldDetailsOf(view))} width={width} /> }
169  }
170
171  return {
172    header: <Header elements={elements} label={label} percent={view.percent} candidates={pick(detailsOf(view))} width={width} />,
173    meter: meter(view, width, COLORS[severityOf(view.percent)], altOf(limit, view)),
174  }
175}
176
177function contextColumn(elements: Elements, context: Context, width: number, meter: Meter): Column {
178  return {
179    header: <Header elements={elements} label="Context" percent={context.percent} candidates={contextDetailsOf(context)} width={width} />,
180    meter: meter(
181      { percent: context.percent, hasReset: false },
182      width,
183      COLORS[severityOf(context.percent)],
184      `Context window, ${Math.round(context.percent)}% full`,
185    ),
186  }
187}
188
189type BandProps = {
190  elements: Elements
191  limits: readonly Limit[]
192  context: Context | null
193  now: number
194  readingAt: number
195  columns: number
196  isBrief: boolean
197  meter: Meter
198}
199
200function Band({ elements, limits, context, now, readingAt, columns, isBrief, meter }: BandProps) {
201  const { Box, Text } = elements
202
203  if (limits.length === 0 && !context) {
204    return (
205      <Box>
206        <Text dimColor>Rate limits show up here after the first reply</Text>
207      </Box>
208    )
209  }
210
211  const { direction, tile } = layoutOf(columns, limits.length + (context ? 1 : 0))
212  // The newest reading any chat has: too old, and its numbers are left out rather than shown wrong.
213  const shape = { width: tile, isBrief, isOld: now - readingAt >= OLD_AFTER, meter }
214  const all = [
215    ...limits.map(limit => limitColumn(elements, limit, viewOf(limit, now, readingAt), shape)),
216    ...(context ? [contextColumn(elements, context, tile, meter)] : []),
217  ]
218
219  if (direction === 'column') {
220    return (
221      <Box flexDirection="column">
222        {all.map(column => (
223          <Box flexDirection="column" width={tile}>
224            {column.header}
225            {column.meter !== undefined && column.meter}
226          </Box>
227        ))}
228      </Box>
229    )
230  }
231
232  // The figures in one row and the meters in the next, so every meter starts on the
233  // same line, whatever the text above it does. Each cell is a column, so a header
234  // stretches across its tile and its detail sits at the tile's right end.
235  return (
236    <Box flexDirection="column">
237      <Box columnGap={GAP}>
238        {all.map(column => (
239          <Box flexDirection="column" width={tile}>
240            {column.header}
241          </Box>
242        ))}
243      </Box>
244      <Box columnGap={GAP}>
245        {all.map(column => (
246          <Box flexDirection="column" width={tile}>
247            {column.meter !== undefined && column.meter}
248          </Box>
249        ))}
250      </Box>
251    </Box>
252  )
253}
254
255// Keep this chat's context fill once a reply has reported it.
256async function measureContext($: EngineInterface, usage: { tokens?: number; window: number; percent?: number }) {
257  const { tokens, window, percent } = usage
258
259  if (tokens !== undefined && percent !== undefined) {
260    await update($, contextAtom, () => ({ tokens, window, percent }))
261  }
262}
263
264async function tick($: EngineInterface) {
265  const now = await $.clock.now()
266  await update($, nowAtom, () => now)
267}
268
269// Show a reading; this chat's own readings are also saved for the next chat.
270async function adopt($: EngineInterface, limits: Limit[], at: number, isOwn: boolean) {
271  await update($, limitsAtom, () => limits)
272  await update($, readingAtAtom, () => at)
273
274  if (isOwn) {
275    await $.store.set(LATEST, { limits, at })
276  }
277}
278
279// Take the reading another chat saved when it is newer than the one on show.
280async function catchUp($: EngineInterface) {
281  const saved = await $.store.get(LATEST)
282
283  if (isReading(saved) && saved.at > (await read($, readingAtAtom))) {
284    await adopt($, saved.limits, saved.at, false)
285  }
286}
287
288async function refresh($: EngineInterface) {
289  await tick($)
290  // A store that cannot be read leaves this chat's own reading on show.
291  await catchUp($).catch(() => undefined)
292}
293
294// Toasts each window once per threshold it crosses; a reset re-arms it.
295async function alert($: EngineInterface, limits: readonly Limit[]) {
296  const toasted = await read($, toastedAtom)
297  const reached: Record<string, number> = {}
298
299  for (const limit of limits) {
300    const threshold = thresholdOf(limit.percentUsed)
301
302    if (threshold === undefined) {
303      continue
304    }
305
306    const last = toasted[limit.kind]
307
308    if (last === undefined || threshold > last) {
309      $.ui.toast(`${labelOf(limit.kind)} limit at ${Math.round(limit.percentUsed)}%`, {
310        timeoutMs: 8000,
311      })
312    }
313
314    reached[limit.kind] = threshold
315  }
316
317  await update($, toastedAtom, () => reached)
318}
319
320export const register: Register = on => {
321  on('session.start', async ($, e, next) => {
322    // The chat's own context, which is live. Its rate limits are left to replies and to
323    // the saved reading: what the engine holds at a start may be a quiet chat's last
324    // numbers, and stamping them now would pass them off as new to every chat.
325    const { context } = await $.session.usage()
326    await measureContext($, context)
327    await refresh($)
328    // Takes up a newer reading another chat saved within seconds, so every chat shows the same.
329    $.clock.every(5_000, () => void catchUp($).catch(() => undefined))
330    // Keeps the countdowns current between replies.
331    $.clock.every(60_000, () => void tick($))
332
333    return next(e)
334  })
335
336  on('session.measure', async ($, e, next) => {
337    await measureContext($, e.context)
338
339    if (e.rateLimits.length > 0) {
340      await adopt($, [...e.rateLimits], await $.clock.now(), true)
341
342      if (e.changed.includes('rateLimits')) {
343        await alert($, e.rateLimits)
344      }
345    }
346
347    await tick($)
348
349    return next(e)
350  })
351
352  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
353    if (e.props.hasSurvey) {
354      return next(e)
355    }
356
357    const limits = await read($, limitsAtom)
358    const context = await read($, contextAtom)
359    const readingAt = await read($, readingAtAtom)
360    const now = (await read($, nowAtom)) || (await $.clock.now())
361    const columns = e.props.bodyColumns
362
363    if (e.surface === 'desktop') {
364      const { Box, Text, Svg } = $.ui.resolve(e)
365      const meter: Meter = (view, width, color, alt) => (
366        <Svg
367          source={meterSvg(width * PX_PER_CELL, view.percent, view.elapsed, color, MUTED)}
368          alt={alt}
369          height={METER_HEIGHT}
370        />
371      )
372
373      return (
374        <Band
375          elements={{ Box, Text }}
376          limits={limits}
377          context={context}
378          now={now}
379          readingAt={readingAt}
380          columns={columns}
381          isBrief
382          meter={meter}
383        />
384      )
385    }
386
387    if (e.surface === 'terminal') {
388      const { Box, Text } = $.ui.resolve(e)
389      const meter: Meter = (view, width, color) => (
390        <Box>
391          {meterRuns(width, view.percent, view.elapsed).map(run => (
392            <Text {...runStyle(run.role, color)}>{run.text}</Text>
393          ))}
394        </Box>
395      )
396
397      return (
398        <Band elements={{ Box, Text }} limits={limits} context={context} now={now} readingAt={readingAt} columns={columns} isBrief={false} meter={meter} />
399      )
400    }
401
402    return next(e)
403  })
404}
405

1import type { Context, Limit, Reading } from '../types'
2
3const HOUR = 3_600_000
4
5const LABELS: Record<string, string> = {
6  five_hour: '5-hour',
7  seven_day: 'Weekly',
8  spend_limit: 'Spend',
9}
10
11export const THRESHOLDS = [80, 95]
12
13export type Severity = 'normal' | 'warning' | 'critical'
14
15const capitalize = (text: string) => text.charAt(0).toUpperCase() + text.slice(1)
16
17export function labelOf(kind: string) {
18  const label = LABELS[kind]
19
20  if (label !== undefined) {
21    return label
22  }
23
24  // Per-model weekly windows, such as seven_day_opus.
25  if (kind.startsWith('seven_day_')) {
26    return `Weekly · ${capitalize(kind.slice('seven_day_'.length))}`
27  }
28
29  return capitalize(kind.replaceAll('_', ' '))
30}
31
32// How long a window runs, where the kind says; a spend limit has no fixed length.
33export function windowMsOf(kind: string) {
34  if (kind === 'five_hour') {
35    return 5 * HOUR
36  }
37
38  return kind === 'seven_day' || kind.startsWith('seven_day_') ? 7 * 24 * HOUR : undefined
39}
40
41export function formatDuration(ms: number) {
42  const minutes = Math.max(0, Math.round(ms / 60_000))
43  const days = Math.floor(minutes / 1440)
44  const hours = Math.floor((minutes % 1440) / 60)
45  const rest = minutes % 60
46
47  if (days > 0) {
48    return hours > 0 ? `${days}d ${hours}h` : `${days}d`
49  }
50
51  if (hours > 0) {
52    return rest > 0 ? `${hours}h ${rest}m` : `${hours}h`
53  }
54
55  return `${rest}m`
56}
57
58export function timeUntil(resetsAt: string | undefined, now: number) {
59  return resetsAt === undefined ? undefined : formatDuration(Date.parse(resetsAt) - now)
60}
61
62export const severityOf = (percentUsed: number): Severity =>
63  percentUsed >= 95 ? 'critical' : percentUsed >= 80 ? 'warning' : 'normal'
64
65// The highest threshold a window has reached, or undefined below the first.
66export const thresholdOf = (percentUsed: number) =>
67  THRESHOLDS.filter(threshold => percentUsed >= threshold).at(-1)
68
69export type Pace = {
70  // How far through its window the clock is, 0 to 1.
71  elapsed: number
72  // `early`: too soon, or too little used, to project. `limit`: at the average
73  // rate so far the window runs out `hitsLimitInMs` from now, before it resets.
74  outlook: 'early' | 'on-track' | 'limit'
75  hitsLimitInMs?: number
76}
77
78export function paceOf(limit: Limit, now: number): Pace | undefined {
79  const windowMs = windowMsOf(limit.kind)
80  const resetsAt = limit.resetsAt === undefined ? NaN : Date.parse(limit.resetsAt)
81
82  if (windowMs === undefined || Number.isNaN(resetsAt)) {
83    return undefined
84  }
85
86  const remainingMs = Math.max(0, resetsAt - now)
87  const elapsedMs = Math.min(windowMs, windowMs - remainingMs)
88  const elapsed = elapsedMs / windowMs
89
90  if (elapsed < 0.1 || limit.percentUsed < 5 || limit.percentUsed >= 100) {
91    return { elapsed, outlook: 'early' }
92  }
93
94  const hitsLimitInMs = ((100 - limit.percentUsed) / limit.percentUsed) * elapsedMs
95
96  return hitsLimitInMs < remainingMs
97    ? { elapsed, outlook: 'limit', hitsLimitInMs }
98    : { elapsed, outlook: 'on-track' }
99}
100
101// Token counts as people say them: 950, 82k, 1.2M.
102export function compactTokens(count: number) {
103  if (count < 1000) {
104    return String(count)
105  }
106
107  if (count < 1_000_000) {
108    return `${Math.round(count / 1000)}k`
109  }
110
111  return `${(count / 1_000_000).toFixed(1).replace(/\.0$/, '')}M`
112}
113
114// A reading older than this is shown with its age, and without a forecast.
115export const STALE_AFTER = 2 * 60_000
116// A reading older than this is not shown as numbers at all: limits count use anywhere,
117// and only a reply brings new ones, so by now they may well be wrong.
118export const OLD_AFTER = 60 * 60_000
119
120export type LimitView = {
121  // What the figure and the meter show: 0 once the window has reset since the reading.
122  percent: number
123  // How far through its window the clock is, for the meter's mark.
124  elapsed?: number
125  // How long until the window runs out at this pace, when that comes before the reset.
126  forecastMs?: number
127  // The time left until the window resets, as text.
128  resets?: string
129  // How old the reading is, as text, once it is stale.
130  age?: string
131  hasReset: boolean
132  // How long ago the window reset, as text, once it has.
133  resetAgo?: string
134}
135
136// What one window looks like now, from a reading taken at `readingAt`.
137export function viewOf(limit: Limit, now: number, readingAt: number): LimitView {
138  const resetAt = limit.resetsAt === undefined ? NaN : Date.parse(limit.resetsAt)
139  const age = readingAt > 0 && now - readingAt >= STALE_AFTER ? formatDuration(now - readingAt) : undefined
140
141  if (resetAt <= now) {
142    return { percent: 0, hasReset: true, age, resetAgo: formatDuration(now - resetAt) }
143  }
144
145  const pace = paceOf(limit, now)
146
147  return {
148    percent: limit.percentUsed,
149    elapsed: pace?.elapsed,
150    forecastMs: age === undefined && pace?.outlook === 'limit' ? pace.hitsLimitInMs : undefined,
151    resets: timeUntil(limit.resetsAt, now),
152    age,
153    hasReset: false,
154  }
155}
156
157export type Tone = 'plain' | 'dim' | 'warning'
158
159// A run of the line beside a figure, and how it is inked.
160export type Segment = { text: string; tone: Tone }
161
162const dim = (text: string): Segment => ({ text, tone: 'dim' })
163const plain = (text: string): Segment => ({ text, tone: 'plain' })
164
165// A lead, then notes after it, dimmed and set off by dots.
166function withNotes(lead: Segment[], notes: readonly string[]): Segment[] {
167  if (notes.length === 0) {
168    return lead
169  }
170
171  const text = notes.join(' · ')
172
173  return [...lead, dim(lead.length > 0 ? ` · ${text}` : text)]
174}
175
176// The line beside a window's figure, fullest first. The band shows the first that
177// fits, so a narrow tile drops the reading's age, then the reset, never wrapping.
178export function detailsOf(view: LimitView): Segment[][] {
179  if (view.hasReset) {
180    const ago = view.resetAgo === undefined || view.resetAgo === '0m' ? 'just now' : `${view.resetAgo} ago`
181
182    return [[dim(`reset ${ago}`)], [dim('reset')]]
183  }
184
185  const resets = view.resets === undefined ? [] : [`resets in ${view.resets}`]
186  const notes = view.age === undefined ? resets : [`as of ${view.age} ago`, ...resets]
187
188  if (view.percent >= 100) {
189    // The figure already says the limit is reached; when it comes back matters more.
190    const reached = [plain('Limit reached')]
191
192    return [withNotes(reached, notes), withNotes(reached, resets), withNotes([], resets)]
193  }
194
195  if (view.forecastMs !== undefined) {
196    const forecast = formatDuration(view.forecastMs)
197    // An arrow, not a second ▲: a projection, beside the figure's own warning.
198    const arrow: Segment = { text: '→ ', tone: 'warning' }
199    const lead = [arrow, plain(`limit in ~${forecast}`)]
200
201    return [withNotes(lead, notes), lead, [arrow, plain(`~${forecast}`)]]
202  }
203
204  return [withNotes([], notes), withNotes([], resets)]
205}
206
207// The desktop counts its width in cells of its code font, and its text runs wider, so
208// there each figure gets a single fact beside it, short enough for any tile: the
209// forecast, the reset or the reached limit's return, never a second fact after a dot.
210export const brief = (candidates: readonly Segment[][]) =>
211  candidates.filter(segments => !segments.some(segment => segment.text.includes(' · ')))
212
213export const briefDetailsOf = (view: LimitView) => brief(detailsOf(view))
214
215// The line beside a window whose reading is too old to show: when it reset, which stays
216// true however old the reading, else that there is nothing recent; fullest first.
217export function oldDetailsOf(view: LimitView): Segment[][] {
218  return view.hasReset ? detailsOf(view) : [[dim('no recent reading · a reply updates it')], [dim('no recent reading')]]
219}
220
221// The line beside the context figure, fullest first.
222export function contextDetailsOf(context: Context): Segment[][] {
223  const tokens = compactTokens(context.tokens)
224
225  return [[dim(`${tokens} of ${compactTokens(context.window)}`)], [dim(tokens)]]
226}
227
228export const widthOf = (segments: readonly Segment[]) =>
229  segments.reduce((width, segment) => width + segment.text.length, 0)
230
231// The fullest of `candidates` that takes at most `room` cells; none when even the sparest is wider.
232export function fitting(candidates: readonly Segment[][], room: number): Segment[] {
233  return candidates.find(segments => widthOf(segments) <= room) ?? []
234}
235
236// Whether a value read back from the store is a reading this mod saved.
237export function isReading(value: unknown): value is Reading {
238  if (typeof value !== 'object' || value === null) {
239    return false
240  }
241
242  const { limits, at } = value as Partial<Reading>
243
244  return typeof at === 'number' && Array.isArray(limits) && limits.every(
245    limit => typeof limit === 'object' && limit !== null
246      && typeof limit.kind === 'string' && typeof limit.percentUsed === 'number',
247  )
248}
249

1// The meter in two forms: glyph runs for the terminal, an SVG for the desktop.
2// Both mark how far through its window the clock is, so use running ahead of
3// time shows as fill past the mark.
4
5export type MeterRole = 'fill' | 'empty' | 'mark-fill' | 'mark-empty'
6
7export type MeterRun = { text: string; role: MeterRole }
8
9const clamp = (value: number, low: number, high: number) => Math.min(high, Math.max(low, value))
10
11export function meterRuns(width: number, percent: number, elapsed?: number): MeterRun[] {
12  const cells = Math.max(1, Math.floor(width))
13  const halves = Math.round((clamp(percent, 0, 100) / 100) * cells * 2)
14  // Any use at all shows as at least half a cell.
15  const units = percent > 0 ? Math.max(1, halves) : 0
16  const full = Math.floor(units / 2)
17  const hasHalf = units % 2 === 1
18  const mark = elapsed === undefined ? -1 : Math.min(cells - 1, Math.floor(clamp(elapsed, 0, 1) * cells))
19  const runs: MeterRun[] = []
20
21  for (let cell = 0; cell < cells; cell++) {
22    const isFilled = cell < full || (cell === full && hasHalf)
23    const glyph =
24      cell === mark
25        ? { text: isFilled ? '┿' : '┼', role: isFilled ? 'mark-fill' : 'mark-empty' }
26        : cell < full
27          ? { text: '━', role: 'fill' }
28          : isFilled
29            ? { text: '╸', role: 'fill' }
30            : { text: '─', role: 'empty' }
31    const last = runs.at(-1)
32
33    if (last?.role === glyph.role) {
34      last.text += glyph.text
35    } else {
36      runs.push(glyph as MeterRun)
37    }
38  }
39
40  return runs
41}
42
43export const METER_HEIGHT = 9
44
45export function meterSvg(width: number, percent: number, elapsed: number | undefined, color: string, markColor: string) {
46  const w = Math.max(24, Math.round(width))
47  const barY = 2
48  const barH = 5
49  const radius = barH / 2
50  // Any use at all shows as at least the rounded end.
51  const fillW = percent > 0 ? Math.max(barH, (clamp(percent, 0, 100) / 100) * w) : 0
52  const markX = elapsed === undefined ? undefined : clamp(elapsed * w, 1, w - 1)
53  // A tick standing proud of the bar, so it reads over the fill and the track.
54  const mark =
55    markX === undefined
56      ? ''
57      : `<rect x="${(markX - 1).toFixed(1)}" width="2" height="${METER_HEIGHT}" rx="1" fill="${markColor}"/>`
58
59  return (
60    // Stretches to whatever width the surface gives it, the height kept.
61    `<svg xmlns="http://www.w3.org/2000/svg" width="${w}" height="${METER_HEIGHT}" viewBox="0 0 ${w} ${METER_HEIGHT}" preserveAspectRatio="none">` +
62    `<defs><clipPath id="track"><rect y="${barY}" width="${w}" height="${barH}" rx="${radius}"/></clipPath></defs>` +
63    `<rect y="${barY}" width="${w}" height="${barH}" rx="${radius}" fill="${color}" fill-opacity="0.22"/>` +
64    `<rect clip-path="url(#track)" y="${barY}" width="${fillW.toFixed(1)}" height="${barH}" rx="${radius}" fill="${color}"/>` +
65    mark +
66    `</svg>`
67  )
68}
69

1// One rate-limit window as the engine reports it (SessionRateLimit).
2export type Limit = { kind: string; percentUsed: number; resetsAt?: string }
3
4// How full this chat's context window is, from the last reply.
5export type Context = { percent: number; tokens: number; window: number }
6
7// The latest limits any chat has seen and when, kept in the mod's store so a new chat can
8// show them before its own first reply.
9export type Reading = { limits: Limit[]; at: number }
10
11declare module 'claude-code' {
12  interface PluginState {
13    'Runway': {
14      // This chat's context window; null until a reply reports it.
15      context: Context | null
16      // The windows of the reading on show.
17      limits: Limit[]
18      // When that reading was taken, in milliseconds since the epoch; 0 before any.
19      readingAt: number
20      // The time the band counts down from, moved on once a minute.
21      now: number
22      // The threshold each window last toasted at, so each crossing toasts once.
23      toasted: Record<string, number>
24    }
25  }
26}
27
