mods-image-preview

1import { atom, read, update } from 'claude-code'
2import type { EngineInterface, Register } from 'claude-code'
3
4import type { Mode, Preview } from '../types'
5import { fromBase64, toBase64 } from './base64'
6import { planBand } from './layout'
7import { ideCommand, viewerCommands } from './open'
8import { decodePng, isPng } from './png'
9import { downsample, fitBox, markCells, markHex, markId, quadrantCells, windowCells, windowKey, type Fit } from './thumb'
10
11const previews = atom({ plugin: 'mods-image-preview', key: 'previews' } as const, [] as Preview[])
12const mode = atom({ plugin: 'mods-image-preview', key: 'mode' } as const, 'blocks' as Mode)
13
14const POLL_MS = 300
15const PENDING_TICKS = 10
16const MAX_READ_BYTES = 4 * 1024 * 1024
17const TOKEN = /\[Image #(\d+)\]/g
18const IMAGE_FILE = /^(\d+)\.(png|jpe?g|gif|webp|bmp|tiff?|heic)$/i
19const WEB_IMAGE = /\.(png|jpe?g|gif|webp)$/i
20const CLAUDE_TEMP = /^claude(-\d+)?$/
21const ALT_DENY = /\balt\b/i
22const SIZES: Record<string, [number, number]> = { small: [16, 4], medium: [24, 6], large: [40, 10] }
23// 렌더 시점 축소 여유분으로 사분면 격자의 2배 해상도 원본 보관
24const SOURCE_SCALE = 2
25const IDE_TIMEOUT_MS = 10_000
26const VIEWER_TIMEOUT_MS = 5_000
27const PORT = /^\d{1,5}$/
28// 오버레이 보조 프로세스가 spec 갱신이 15초 끊기면 스스로 끝나므로 그보다 짧은 생존 신호 간격
29const HEARTBEAT_MS = 5_000
30
31type Picture = { bytes: Uint8Array; path: string }
32
33let located: { sessionId: string; dir: string } | undefined
34let bandRequestId: string | undefined
35let isPolling = false
36const attempts = new Map<number, number>()
37const probed = new Set<number>()
38const opened = new Set<string>()
39const overlay = { isRunning: false, writtenAt: 0 }
40
41export const register: Register = (on, options) => {
42  const box: [number, number] = SIZES[String(options.size)] ?? [24, 6]
43  const renderer = String(options.renderer)
44  const openMode = String(options.open)
45
46  on('session.start', async ($, e, next) => {
47    const chosen = await chooseMode($, renderer)
48    await update($, mode, () => chosen)
49    await update($, previews, () => [])
50    if (chosen === 'overlay') await pruneLinks($)
51    // 이미지 붙여넣기는 prompt.edit 를 거치지 않아 초안 폴링으로 우회
52    $.clock.every(POLL_MS, () => {
53      void poll($, box, openMode)
54    })
55
56    return next(e)
57  })
58
59  on('prompt.submit', async ($, e, next) => {
60    await update($, previews, () => [])
61
62    if ((await read($, mode)) === 'window') await syncOverlay($, [])
63
64    return next(e)
65  })
66
67  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
68    if (e.surface !== 'terminal' || e.props.hasSurvey) return next(e)
69
70    const list = await read($, previews)
71
72    if (list.length === 0) return next(e)
73
74    const current = await read($, mode)
75    const { Box, Button, Image, Raster, Text } = $.ui.resolve(e)
76    // IDE 탭이 원본을 보여 주는 이미지는 흐린 썸네일 대신 한 줄 표시라 폭 배분에서 제외
77    const plan = planBand(
78      list.filter(preview => !preview.isInIde),
79      e.props.maxRows,
80      e.props.bodyColumns,
81      box,
82    )
83    const fits = new Map(plan.tiles.map(tile => [tile.n, tile.fit]))
84    bandRequestId = e.requestId
85
86    const picture = (preview: Preview, fit: Fit | undefined) => {
87      if (!fit) return <Text dimColor>{preview.note ?? '...'}</Text>
88
89      if (current === 'pixels' && preview.file) {
90        return (
91          <Image
92            key={`image-${preview.n}`}
93            source={{ file: preview.file, format: 'png' }}
94            columns={fit.columns}
95            rows={fit.rows}
96            alt={`Image #${preview.n}`}
97          />
98        )
99      }
100
101      // 보조 프로세스가 화면에서 이 단색 칸을 찾아 원본 이미지 창으로 덮는 마커
102      if (current === 'window' && preview.source) {
103        const key = overlayKey(preview.n)
104
105        return <Raster key={`raster-${preview.n}`} columns={fit.columns} rows={fit.rows} cells={windowCells(key, fit.columns, fit.rows)} />
106      }
107
108      const cells =
109        current === 'overlay' && preview.id !== undefined
110          ? markCells(preview.id, fit.columns, fit.rows)
111          : blockCells(preview, fit)
112
113      return <Raster key={`raster-${preview.n}`} columns={fit.columns} rows={fit.rows} cells={cells} />
114    }
115
116    // 번호를 누르면 IDE 탭이나 OS 뷰어로 원본 화질 확인
117    const label = (preview: Preview) => {
118      const { source } = preview
119
120      if (!source) return <Text dimColor>#{preview.n}</Text>
121
122      return <Button key={`open-${preview.n}`} label={`#${preview.n}`} plain dimColor onPress={() => void openOriginal($, source, true)} />
123    }
124
125    return (
126      <Box flexDirection="row" alignItems="flex-end" columnGap={1}>
127        {list.map(preview =>
128          preview.isInIde ? (
129            <Box key={`tile-${preview.n}`} flexDirection="row" columnGap={1}>
130              {label(preview)}
131              <Text dimColor>in IDE</Text>
132            </Box>
133          ) : plan.isCompact ? (
134            <Box key={`tile-${preview.n}`} flexDirection="row" columnGap={1}>
135              {picture(preview, fits.get(preview.n))}
136              {label(preview)}
137            </Box>
138          ) : (
139            <Box key={`tile-${preview.n}`} flexDirection="column" alignItems="center" borderStyle="round" borderDimColor>
140              {picture(preview, fits.get(preview.n))}
141              {label(preview)}
142            </Box>
143          ),
144        )}
145      </Box>
146    )
147  })
148}
149
150function blockCells(preview: Preview, fit: Fit): string {
151  if (!preview.thumb || !preview.thumbWidth || !preview.thumbHeight) return ''
152
153  const thumb = { width: preview.thumbWidth, height: preview.thumbHeight, data: fromBase64(preview.thumb) }
154
155  return quadrantCells(downsample(thumb, fit.pxWidth * 2, fit.pxHeight))
156}
157
158async function poll($: EngineInterface, box: [number, number], openMode: string): Promise<void> {
159  if (isPolling) return
160
161  isPolling = true
162
163  try {
164    const { text } = await $.prompt.read()
165    const wanted = [...new Set([...text.matchAll(TOKEN)].map(match => Number(match[1])))]
166    const current = await read($, previews)
167    const chosen = await read($, mode)
168    const shown = current.map(preview => preview.n)
169    const isSettled =
170      current.every(preview => !preview.isPending) &&
171      wanted.length === shown.length &&
172      wanted.every((n, i) => n === shown[i])
173
174    if (isSettled) {
175      if (chosen === 'pixels') await probePixels($, current)
176      if (chosen === 'window' && current.length > 0 && (await $.clock.now()) - overlay.writtenAt >= HEARTBEAT_MS) {
177        await syncOverlay($, current)
178      }
179
180      return
181    }
182
183    for (const n of attempts.keys()) if (!wanted.includes(n)) attempts.delete(n)
184
185    const nextPreviews: Preview[] = []
186
187    for (const n of wanted) {
188      const known = current.find(preview => preview.n === n)
189      nextPreviews.push(known && !known.isPending ? known : await loadPreview($, n, box, chosen))
190    }
191
192    await update($, previews, () => nextPreviews)
193
194    if (chosen === 'window') await syncOverlay($, nextPreviews)
195
196    for (const { source } of nextPreviews) {
197      if (!source || opened.has(source)) continue
198
199      opened.add(source)
200
201      if (openMode === 'off') continue
202
203      void openOriginal($, source, openMode === 'viewer').then(where => {
204        if (where !== 'ide') return
205
206        return update($, previews, list => list.map(preview => (preview.source === source ? { ...preview, isInIde: true } : preview)))
207      })
208    }
209  } finally {
210    isPolling = false
211  }
212}
213
214async function loadPreview($: EngineInterface, n: number, box: [number, number], chosen: Mode): Promise<Preview> {
215  const [maxColumns, maxRows] = box
216  const file = await findImage($, n)
217
218  if (!file) {
219    const tries = (attempts.get(n) ?? 0) + 1
220    attempts.set(n, tries)
221
222    return tries < PENDING_TICKS ? { n, isPending: true } : { n, note: 'not found' }
223  }
224
225  try {
226    const picture = await readPicture($, file, maxColumns * 4)
227    const image = decodePng(picture.bytes)
228    const fit = fitBox(image.width, image.height, maxColumns, maxRows)
229    const thumb = downsample(image, fit.pxWidth * 2 * SOURCE_SCALE, fit.pxHeight * SOURCE_SCALE)
230    const preview: Preview = {
231      n,
232      source: file,
233      width: image.width,
234      height: image.height,
235      thumb: toBase64(thumb.data),
236      thumbWidth: thumb.width,
237      thumbHeight: thumb.height,
238    }
239
240    if (chosen === 'pixels') return { ...preview, file: picture.path }
241
242    if (chosen === 'overlay') {
243      const source = WEB_IMAGE.test(file) ? file : picture.path
244      const id = markId(source)
245
246      if (await linkForOverlay($, source, id)) return { ...preview, id }
247    }
248
249    return preview
250  } catch {
251    return { n, source: file, note: 'unsupported' }
252  }
253}
254
255// 엔진이 kitty 그래픽 질의에 응답이 없으면 alt 를 그리므로 블록 폴백 근거
256async function probePixels($: EngineInterface, list: Preview[]): Promise<void> {
257  const target = list.find(preview => preview.file && !probed.has(preview.n))
258
259  if (!target?.file || !bandRequestId) return
260
261  const { deny } = await $.ui.blit({
262    requestId: bandRequestId,
263    key: `image-${target.n}`,
264    source: { file: target.file, format: 'png' },
265  })
266
267  if (deny === undefined) {
268    probed.add(target.n)
269  } else if (ALT_DENY.test(deny)) {
270    probed.add(target.n)
271    await update($, mode, () => 'blocks')
272  }
273}
274
275async function linkForOverlay($: EngineInterface, source: string, id: number): Promise<boolean> {
276  const dir = await overlayDir($)
277
278  if (!dir) return false
279
280  const made = await $.process.run(['mkdir', '-p', dir])
281
282  if (made.exitCode !== 0) return false
283
284  const { exitCode } = await $.process.run(['ln', '-sfn', source, `${dir}/${markHex(id)}`])
285
286  return exitCode === 0
287}
288
289async function pruneLinks($: EngineInterface): Promise<void> {
290  const dir = await overlayDir($)
291
292  if (dir && (await $.fs.exists(dir))) await $.process.run(['find', dir, '-type', 'l', '-mmin', '+1440', '-delete'])
293}
294
295async function overlayDir($: EngineInterface): Promise<string | undefined> {
296  const home = await $.env.get('HOME')
297
298  return home ? `${home}/.claude/claude-mods-image-preview` : undefined
299}
300
301async function readPicture($: EngineInterface, file: string, edge: number): Promise<Picture> {
302  const { size } = await $.fs.stat(file)
303
304  if (size <= MAX_READ_BYTES) {
305    const bytes = fromBase64((await $.fs.read(file, { as: 'bytes' })).base64)
306
307    if (isPng(bytes)) return { bytes, path: file }
308  }
309
310  // PNG 가 아니거나 읽기 상한 초과 시 OS 별 변환기로 만든 축소 PNG 폴백
311  const out = `${file.replace(/[\\/]images[\\/][^\\/]+$/, '')}/claude-mods-image-preview/${file.replace(/^.*[\\/]/, '')}.png`
312  await $.fs.write(out, '')
313
314  for (const argv of converters(file, out, edge)) {
315    try {
316      const { exitCode } = await $.process.run(argv)
317
318      if (exitCode !== 0) continue
319
320      const bytes = fromBase64((await $.fs.read(out, { as: 'bytes' })).base64)
321
322      if (isPng(bytes)) return { bytes, path: out }
323    } catch {
324      continue
325    }
326  }
327
328  throw new Error('no converter')
329}
330
331function converters(file: string, out: string, edge: number): string[][] {
332  const quote = (value: string) => `'${value.replace(/'/g, "''")}'`
333  const resize = `${edge}x${edge}>`
334  const script =
335    '& { param($in, $out, $edge) Add-Type -AssemblyName System.Drawing; ' +
336    '$s = [System.Drawing.Image]::FromFile($in); ' +
337    '$k = [Math]::Min(1, $edge / [Math]::Max($s.Width, $s.Height)); ' +
338    '$b = New-Object System.Drawing.Bitmap ([int][Math]::Max(1, $s.Width * $k)), ([int][Math]::Max(1, $s.Height * $k)); ' +
339    '$g = [System.Drawing.Graphics]::FromImage($b); $g.DrawImage($s, 0, 0, $b.Width, $b.Height); ' +
340    '$b.Save($out, [System.Drawing.Imaging.ImageFormat]::Png) }'
341
342  return [
343    ['sips', '-s', 'format', 'png', '-Z', String(edge), file, '--out', out],
344    ['magick', file, '-resize', resize, out],
345    ['convert', file, '-resize', resize, out],
346    ['powershell', '-NoProfile', '-NonInteractive', '-Command', `${script} ${quote(file)} ${quote(out)} ${edge}`],
347  ]
348}
349
350async function findImage($: EngineInterface, n: number): Promise<string | undefined> {
351  const dir = await imagesDir($)
352
353  if (!dir) return undefined
354
355  const entry = (await $.fs.list(dir)).find(item => item.kind === 'file' && Number(IMAGE_FILE.exec(item.name)?.[1]) === n)
356
357  return entry ? `${dir}/${entry.name}` : undefined
358}
359
360// 엔진이 붙여넣기 즉시 이미지를 쓰는 <temp>/claude-<uid>/<project>/<session>/images 기준
361async function imagesDir($: EngineInterface): Promise<string | undefined> {
362  const sessionId = await $.session.id()
363
364  if (located?.sessionId === sessionId) return located.dir
365
366  for (const root of await tempRoots($)) {
367    for (const project of await childDirs($, root)) {
368      const dir = `${root}/${project}/${sessionId}/images`
369
370      if (await $.fs.exists(dir)) {
371        located = { sessionId, dir }
372
373        return dir
374      }
375    }
376  }
377
378  return undefined
379}
380
381async function tempRoots($: EngineInterface): Promise<string[]> {
382  const override = await $.env.get('CLAUDE_CODE_TMPDIR')
383  const parents = [override, '/tmp', '/private/tmp', await $.env.get('TMPDIR'), await $.env.get('TEMP')]
384  const roots = override ? [override] : []
385
386  for (const parent of parents) {
387    if (!parent) continue
388
389    const base = parent.replace(/[\\/]+$/, '')
390
391    for (const name of await childDirs($, base)) if (CLAUDE_TEMP.test(name)) roots.push(`${base}/${name}`)
392  }
393
394  return [...new Set(roots)]
395}
396
397async function childDirs($: EngineInterface, path: string): Promise<string[]> {
398  try {
399    return (await $.fs.list(path)).filter(item => item.kind === 'dir').map(item => item.name)
400  } catch {
401    return []
402  }
403}
404
405// IDE 편집기 탭은 원본 화질 그대로이고 makeFrontmost 를 끄면 입력 포커스가 프롬프트에 남는 기준
406async function openOriginal($: EngineInterface, file: string, useViewer: boolean): Promise<'ide' | 'viewer' | undefined> {
407  if (await openInIde($, file)) return 'ide'
408  if (useViewer && (await openInViewer($, file))) return 'viewer'
409
410  return undefined
411}
412
413async function openInIde($: EngineInterface, file: string): Promise<boolean> {
414  try {
415    const { isError } = await $.mcp.call('ide', 'openFile', { filePath: file, preview: true, makeFrontmost: false })
416
417    if (!isError) return true
418  } catch {
419    // 엔진이 IDE 내부 도구를 내주지 않으면 IDE 터미널이 알려 준 서버로 직접 연결하는 폴백
420  }
421
422  try {
423    const port = await $.env.get('CLAUDE_CODE_SSE_PORT')
424    const dir = await claudeDir($)
425
426    if (!port || !PORT.test(port) || !dir || (await $.env.get('OS')) !== 'Windows_NT') return false
427
428    const lock = `${dir}/ide/${port}.lock`
429
430    if (!(await $.fs.exists(lock))) return false
431
432    const { exitCode } = await $.process.run(ideCommand(port, lock, file), { timeoutMs: IDE_TIMEOUT_MS })
433
434    return exitCode === 0
435  } catch {
436    return false
437  }
438}
439
440async function openInViewer($: EngineInterface, file: string): Promise<boolean> {
441  try {
442    const isWindows = (await $.env.get('OS')) === 'Windows_NT'
443
444    for (const argv of viewerCommands(file, isWindows)) {
445      try {
446        const { exitCode } = await $.process.run(argv, { timeoutMs: VIEWER_TIMEOUT_MS })
447
448        // explorer 는 열기에 성공해도 종료 코드 1 을 돌려주는 기준
449        if (exitCode === 0 || isWindows) return true
450      } catch {
451        continue
452      }
453    }
454  } catch {
455    return false
456  }
457
458  return false
459}
460
461async function claudeDir($: EngineInterface): Promise<string | undefined> {
462  const configured = await $.env.get('CLAUDE_CONFIG_DIR')
463
464  if (configured) return configured
465
466  const home = (await $.env.get('USERPROFILE')) ?? (await $.env.get('HOME'))
467
468  return home ? `${home}/.claude` : undefined
469}
470
471// 세션마다 마커 색이 달라 한 화면에 뜬 여러 세션의 썸네일을 구분하는 기준
472function overlayKey(n: number): number {
473  return windowKey(n, located ? markId(located.sessionId) : 0)
474}
475
476async function syncOverlay($: EngineInterface, list: Preview[]): Promise<void> {
477  if (!located) return
478
479  const spec = `${located.dir.replace(/[\\/]images$/, '')}/claude-mods-image-preview/overlay.txt`
480  const lines = list
481    .filter(preview => preview.source && !preview.isInIde && preview.width)
482    .map(preview => `${overlayKey(preview.n).toString(16).padStart(6, '0')}\t${preview.source}`)
483
484  await $.fs.write(spec, lines.length > 0 ? `${lines.join('\n')}\n` : '')
485  overlay.writtenAt = await $.clock.now()
486
487  if (lines.length > 0 && !overlay.isRunning) await startOverlay($, spec)
488}
489
490// 모듈이 내려가면 엔진이 자식을 끝내고, 비정상 종료면 이 세션은 블록 렌더러로 되돌리는 기준
491async function startOverlay($: EngineInterface, spec: string): Promise<void> {
492  const root = $.plugin.root
493  const candidates = [`${root}/hooks/overlay.ps1`, `${root}/../hooks/overlay.ps1`]
494  let script: string | undefined
495
496  for (const path of candidates) {
497    if (await $.fs.exists(path)) {
498      script = path
499      break
500    }
501  }
502
503  if (!script) {
504    await update($, mode, () => 'blocks')
505    return
506  }
507
508  overlay.isRunning = true
509
510  const argv = ['powershell', '-NoProfile', '-NonInteractive', '-ExecutionPolicy', 'Bypass', '-File', script, '-Spec', spec]
511
512  void (async () => {
513    let code: number | null = -1
514
515    try {
516      const child = $.process.spawn({ argv })
517
518      for await (const piece of child) {
519        if (piece.stream === 'stderr') $.ui.log(piece.text, { to: 'debug' })
520      }
521
522      code = (await child.result).code
523    } catch {
524      code = -1
525    }
526
527    overlay.isRunning = false
528
529    if (code !== 0) await update($, mode, () => 'blocks')
530  })()
531}
532
533async function chooseMode($: EngineInterface, renderer: string): Promise<Mode> {
534  if (renderer === 'window') return (await $.env.get('OS')) === 'Windows_NT' ? 'window' : 'blocks'
535  if (renderer === 'blocks' || renderer === 'pixels' || renderer === 'overlay') return renderer
536  if (await advertisesOverlay($)) return 'overlay'
537
538  return (await drawsPixels($)) ? 'pixels' : 'blocks'
539}
540
541// 이미 떠 있는 tmux 창은 새 환경 변수를 못 받아 tmux 전역 환경을 함께 확인하는 기준
542async function advertisesOverlay($: EngineInterface): Promise<boolean> {
543  const isTmux = Boolean(await $.env.get('TMUX'))
544
545  // tmux 안에서 truecolor 가 꺼지면 마커 색이 256색으로 깨지는 문제 방지
546  if (isTmux && !(await $.env.get('CLAUDE_CODE_TMUX_TRUECOLOR'))) return false
547  if ((await $.env.get('CLAUDE_MODS_IMAGE_OVERLAY')) === '1') return true
548  if (!isTmux) return false
549
550  try {
551    const { exitCode, stdout } = await $.process.run(['tmux', 'show-environment', '-g', 'CLAUDE_MODS_IMAGE_OVERLAY'])
552
553    return exitCode === 0 && stdout.trim() === 'CLAUDE_MODS_IMAGE_OVERLAY=1'
554  } catch {
555    return false
556  }
557}
558
559async function drawsPixels($: EngineInterface): Promise<boolean> {
560  if ((await $.env.get('TMUX')) || (await $.env.get('STY')) || (await $.env.get('SSH_CONNECTION'))) return false
561
562  const term = await $.env.get('TERM')
563  const program = await $.env.get('TERM_PROGRAM')
564
565  return term === 'xterm-kitty' || term === 'xterm-ghostty' || program === 'ghostty' || Boolean(await $.env.get('KITTY_WINDOW_ID'))
566}
567

1type Base64Constructor = Uint8ArrayConstructor & { fromBase64: (text: string) => Uint8Array }
2type Base64Bytes = Uint8Array & { toBase64: () => string }
3
4export function fromBase64(text: string): Uint8Array {
5  return (Uint8Array as Base64Constructor).fromBase64(text)
6}
7
8export function toBase64(bytes: Uint8Array): string {
9  return (bytes as Base64Bytes).toBase64()
10}
11

1import { fitBox, type Fit } from './thumb'
2
3export type TileInput = { n: number; width?: number; height?: number }
4
5export type TilePlan = { n: number; fit?: Fit }
6
7export type BandPlan = { isCompact: boolean; tiles: TilePlan[] }
8
9const BORDER_ROWS = 2
10const LABEL_ROWS = 1
11const GAP = 1
12
13// 테두리를 두면 설정 크기보다 작아지는 좁은 밴드는 번호를 옆에 두는 압축 배치 기준
14export function planBand(list: TileInput[], maxRows: number, bodyColumns: number, box: [number, number]): BandPlan {
15  const [boxColumns, boxRows] = box
16  const isCompact = maxRows - BORDER_ROWS - LABEL_ROWS < boxRows
17  const rowBudget = isCompact ? Math.max(1, Math.min(boxRows, maxRows)) : boxRows
18  const count = Math.max(1, list.length)
19  const chrome = isCompact ? 1 + Math.max(...list.map(item => `#${item.n}`.length), 2) : 2
20  const perTile = Math.floor((bodyColumns - GAP * (count - 1)) / count) - chrome
21  const columnBudget = Math.max(2, Math.min(boxColumns, perTile))
22
23  return {
24    isCompact,
25    tiles: list.map(item => ({
26      n: item.n,
27      fit: item.width && item.height ? fitBox(item.width, item.height, columnBudget, rowBudget) : undefined,
28    })),
29  }
30}
31

1// IDE MCP 서버에 openFile 한 번 보내는 웹소켓 클라이언트, 명령줄 따옴표 깨짐 방지로 큰따옴표 없음
2const IDE_SCRIPT = [
3  '& { param($port, $lock, $file)',
4  "$ErrorActionPreference = 'Stop';",
5  '$token = (Get-Content -Raw -LiteralPath $lock | ConvertFrom-Json).authToken;',
6  '$ws = New-Object System.Net.WebSockets.ClientWebSocket;',
7  "$ws.Options.AddSubProtocol('mcp');",
8  "$ws.Options.SetRequestHeader('x-claude-code-ide-authorization', $token);",
9  '$none = [Threading.CancellationToken]::None;',
10  "if (-not $ws.ConnectAsync([Uri]('ws://127.0.0.1:' + $port), $none).Wait(3000)) { exit 1 };",
11  '$buffer = New-Object byte[] 65536;',
12  'function Send($message) { $bytes = [Text.Encoding]::UTF8.GetBytes(($message | ConvertTo-Json -Compress -Depth 6)); [void]$ws.SendAsync([ArraySegment[byte]]$bytes, 0, $true, $none).Wait(3000) };',
13  "function Receive { $text = ''; do { $task = $ws.ReceiveAsync([ArraySegment[byte]]$buffer, $none); if (-not $task.Wait(5000)) { exit 1 }; $text += [Text.Encoding]::UTF8.GetString($buffer, 0, $task.Result.Count) } until ($task.Result.EndOfMessage); $text | ConvertFrom-Json };",
14  "Send @{ jsonrpc = '2.0'; id = 1; method = 'initialize'; params = @{ protocolVersion = '2025-06-18'; capabilities = @{}; clientInfo = @{ name = 'mods-image-preview'; version = '1' } } };",
15  'do { $reply = Receive } until ($reply.id -eq 1);',
16  "Send @{ jsonrpc = '2.0'; method = 'notifications/initialized' };",
17  "Send @{ jsonrpc = '2.0'; id = 2; method = 'tools/call'; params = @{ name = 'openFile'; arguments = @{ filePath = $file; preview = $true; makeFrontmost = $false } } };",
18  'do { $reply = Receive } until ($reply.id -eq 2);',
19  "[void]$ws.CloseAsync(1000, '', $none).Wait(1000);",
20  'if ($reply.error -or $reply.result.isError) { exit 1 } }',
21].join(' ')
22
23export function ideCommand(port: string, lock: string, file: string): string[] {
24  const quote = (value: string) => `'${value.replace(/'/g, "''")}'`
25
26  return ['powershell', '-NoProfile', '-NonInteractive', '-Command', `${IDE_SCRIPT} ${quote(port)} ${quote(lock)} ${quote(file)}`]
27}
28
29export function viewerCommands(file: string, isWindows: boolean): string[][] {
30  return isWindows ? [['explorer', file.replace(/\//g, '\\')]] : [['xdg-open', file], ['open', file]]
31}
32

1export type Rgba = { width: number; height: number; data: Uint8Array }
2
3const SIGNATURE = [137, 80, 78, 71, 13, 10, 26, 10]
4const MAX_PIXELS = 16_000_000
5
6const LEN_BASE = [3, 4, 5, 6, 7, 8, 9, 10, 11, 13, 15, 17, 19, 23, 27, 31, 35, 43, 51, 59, 67, 83, 99, 115, 131, 163, 195, 227, 258]
7const LEN_EXTRA = [0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 1, 2, 2, 2, 2, 3, 3, 3, 3, 4, 4, 4, 4, 5, 5, 5, 5, 0]
8const DIST_BASE = [1, 2, 3, 4, 5, 7, 9, 13, 17, 25, 33, 49, 65, 97, 129, 193, 257, 385, 513, 769, 1025, 1537, 2049, 3073, 4097, 6145, 8193, 12289, 16385, 24577]
9const DIST_EXTRA = [0, 0, 0, 0, 1, 1, 2, 2, 3, 3, 4, 4, 5, 5, 6, 6, 7, 7, 8, 8, 9, 9, 10, 10, 11, 11, 12, 12, 13, 13]
10const CODE_LENGTH_ORDER = [16, 17, 18, 0, 8, 7, 9, 6, 10, 5, 11, 4, 12, 3, 13, 2, 14, 1, 15]
11
12const CHANNELS: Record<number, number> = { 0: 1, 2: 3, 3: 1, 4: 2, 6: 4 }
13
14const ADAM7 = [
15  [0, 0, 8, 8],
16  [4, 0, 8, 8],
17  [0, 4, 4, 8],
18  [2, 0, 4, 4],
19  [0, 2, 2, 4],
20  [1, 0, 2, 2],
21  [0, 1, 1, 2],
22]
23
24type Huffman = { table: Int32Array; bits: number }
25
26type Header = {
27  width: number
28  height: number
29  depth: number
30  colorType: number
31  interlace: number
32}
33
34export function isPng(bytes: Uint8Array): boolean {
35  return bytes.length >= 8 && SIGNATURE.every((b, i) => bytes[i] === b)
36}
37
38export function pngSize(bytes: Uint8Array): { width: number; height: number } {
39  if (!isPng(bytes) || bytes.length < 24) throw new Error('not a PNG')
40
41  return { width: u32(bytes, 16), height: u32(bytes, 20) }
42}
43
44export function decodePng(bytes: Uint8Array): Rgba {
45  if (!isPng(bytes)) throw new Error('not a PNG')
46
47  let header: Header | undefined
48  let palette: Uint8Array | undefined
49  let transparency: Uint8Array | undefined
50  const idat: Uint8Array[] = []
51  let pos = 8
52
53  while (pos + 8 <= bytes.length) {
54    const length = u32(bytes, pos)
55    const type = String.fromCharCode(bytes[pos + 4], bytes[pos + 5], bytes[pos + 6], bytes[pos + 7])
56    const body = bytes.subarray(pos + 8, pos + 8 + length)
57    pos += 12 + length
58
59    if (type === 'IHDR') {
60      header = {
61        width: u32(body, 0),
62        height: u32(body, 4),
63        depth: body[8],
64        colorType: body[9],
65        interlace: body[12],
66      }
67    } else if (type === 'PLTE') {
68      palette = body
69    } else if (type === 'tRNS') {
70      transparency = body
71    } else if (type === 'IDAT') {
72      idat.push(body)
73    } else if (type === 'IEND') {
74      break
75    }
76  }
77
78  if (!header) throw new Error('PNG without IHDR')
79
80  const { width, height, depth, colorType, interlace } = header
81  const channels = CHANNELS[colorType]
82
83  if (!channels) throw new Error(`PNG color type ${colorType}`)
84  if (width === 0 || height === 0 || width * height > MAX_PIXELS) throw new Error('PNG too large')
85  if (colorType === 3 && !palette) throw new Error('PNG without PLTE')
86
87  const bitsPerPixel = channels * depth
88  const stride = Math.max(1, bitsPerPixel >> 3)
89  const passes = interlace === 1 ? ADAM7 : [[0, 0, 1, 1]]
90  const sizes = passes.map(([x0, y0, dx, dy]) => [passLength(width, x0, dx), passLength(height, y0, dy)])
91  const rawLength = sizes.reduce((sum, [w, h]) => sum + (w && h ? h * (1 + Math.ceil((w * bitsPerPixel) / 8)) : 0), 0)
92  const raw = inflate(concat(idat).subarray(2), rawLength)
93  const out = new Uint8Array(width * height * 4)
94  const sample = makeSampler(colorType, depth, palette, transparency)
95  let offset = 0
96
97  passes.forEach(([x0, y0, dx, dy], index) => {
98    const [pw, ph] = sizes[index]
99
100    if (!pw || !ph) return
101
102    const rowBytes = Math.ceil((pw * bitsPerPixel) / 8)
103    let previous: Uint8Array = new Uint8Array(rowBytes)
104
105    for (let y = 0; y < ph; y++) {
106      const filter = raw[offset]
107      const row = raw.subarray(offset + 1, offset + 1 + rowBytes)
108      offset += 1 + rowBytes
109      unfilter(filter, row, previous, stride)
110
111      for (let x = 0; x < pw; x++) {
112        sample(row, x, out, ((y0 + y * dy) * width + x0 + x * dx) * 4)
113      }
114
115      previous = row
116    }
117  })
118
119  return { width, height, data: out }
120}
121
122function passLength(size: number, start: number, step: number): number {
123  return size > start ? Math.ceil((size - start) / step) : 0
124}
125
126function u32(bytes: Uint8Array, at: number): number {
127  return ((bytes[at] << 24) | (bytes[at + 1] << 16) | (bytes[at + 2] << 8) | bytes[at + 3]) >>> 0
128}
129
130function concat(parts: Uint8Array[]): Uint8Array {
131  const out = new Uint8Array(parts.reduce((sum, part) => sum + part.length, 0))
132  let at = 0
133
134  for (const part of parts) {
135    out.set(part, at)
136    at += part.length
137  }
138
139  return out
140}
141
142function unfilter(filter: number, row: Uint8Array, previous: Uint8Array, stride: number): void {
143  const length = row.length
144
145  if (filter === 1) {
146    for (let i = stride; i < length; i++) row[i] = (row[i] + row[i - stride]) & 255
147  } else if (filter === 2) {
148    for (let i = 0; i < length; i++) row[i] = (row[i] + previous[i]) & 255
149  } else if (filter === 3) {
150    for (let i = 0; i < length; i++) {
151      const left = i >= stride ? row[i - stride] : 0
152      row[i] = (row[i] + ((left + previous[i]) >> 1)) & 255
153    }
154  } else if (filter === 4) {
155    for (let i = 0; i < length; i++) {
156      const a = i >= stride ? row[i - stride] : 0
157      const b = previous[i]
158      const c = i >= stride ? previous[i - stride] : 0
159      const p = a + b - c
160      const pa = Math.abs(p - a)
161      const pb = Math.abs(p - b)
162      const pc = Math.abs(p - c)
163      row[i] = (row[i] + (pa <= pb && pa <= pc ? a : pb <= pc ? b : c)) & 255
164    }
165  } else if (filter !== 0) {
166    throw new Error(`PNG filter ${filter}`)
167  }
168}
169
170type Sampler = (row: Uint8Array, x: number, out: Uint8Array, at: number) => void
171
172function makeSampler(colorType: number, depth: number, palette?: Uint8Array, transparency?: Uint8Array): Sampler {
173  const max = (1 << depth) - 1
174  const read = depth === 16
175    ? (row: Uint8Array, i: number) => (row[i * 2] << 8) | row[i * 2 + 1]
176    : depth === 8
177      ? (row: Uint8Array, i: number) => row[i]
178      : (row: Uint8Array, i: number) => (row[(i * depth) >> 3] >> (8 - depth - ((i * depth) & 7))) & max
179  const scale = (v: number) => (depth === 16 ? v >> 8 : depth === 8 ? v : Math.round((v * 255) / max))
180  const keyGray = transparency && transparency.length >= 2 ? (transparency[0] << 8) | transparency[1] : -1
181  const keyRgb = transparency && transparency.length >= 6
182    ? [(transparency[0] << 8) | transparency[1], (transparency[2] << 8) | transparency[3], (transparency[4] << 8) | transparency[5]]
183    : undefined
184
185  if (colorType === 0) {
186    return (row, x, out, at) => {
187      const v = read(row, x)
188      out[at] = out[at + 1] = out[at + 2] = scale(v)
189      out[at + 3] = v === keyGray ? 0 : 255
190    }
191  }
192
193  if (colorType === 2) {
194    return (row, x, out, at) => {
195      const r = read(row, x * 3)
196      const g = read(row, x * 3 + 1)
197      const b = read(row, x * 3 + 2)
198      out[at] = scale(r)
199      out[at + 1] = scale(g)
200      out[at + 2] = scale(b)
201      out[at + 3] = keyRgb && r === keyRgb[0] && g === keyRgb[1] && b === keyRgb[2] ? 0 : 255
202    }
203  }
204
205  if (colorType === 3) {
206    const colors = palette as Uint8Array
207
208    return (row, x, out, at) => {
209      const index = read(row, x)
210      out[at] = colors[index * 3] ?? 0
211      out[at + 1] = colors[index * 3 + 1] ?? 0
212      out[at + 2] = colors[index * 3 + 2] ?? 0
213      out[at + 3] = transparency && index < transparency.length ? transparency[index] : 255
214    }
215  }
216
217  if (colorType === 4) {
218    return (row, x, out, at) => {
219      out[at] = out[at + 1] = out[at + 2] = scale(read(row, x * 2))
220      out[at + 3] = scale(read(row, x * 2 + 1))
221    }
222  }
223
224  return (row, x, out, at) => {
225    out[at] = scale(read(row, x * 4))
226    out[at + 1] = scale(read(row, x * 4 + 1))
227    out[at + 2] = scale(read(row, x * 4 + 2))
228    out[at + 3] = scale(read(row, x * 4 + 3))
229  }
230}
231
232export function inflate(data: Uint8Array, expected: number): Uint8Array {
233  let out = new Uint8Array(Math.max(expected, 1024))
234  let length = 0
235  let pos = 0
236  let bitBuffer = 0
237  let bitCount = 0
238
239  const need = (n: number) => {
240    while (bitCount < n) {
241      bitBuffer |= (pos < data.length ? data[pos] : 0) << bitCount
242      pos++
243      bitCount += 8
244    }
245  }
246  const bits = (n: number) => {
247    need(n)
248    const value = bitBuffer & ((1 << n) - 1)
249    bitBuffer >>>= n
250    bitCount -= n
251
252    return value
253  }
254  const symbol = (code: Huffman) => {
255    need(code.bits)
256    const entry = code.table[bitBuffer & ((1 << code.bits) - 1)]
257
258    if (entry < 0) throw new Error('bad Huffman code')
259
260    bitBuffer >>>= entry & 15
261    bitCount -= entry & 15
262
263    return entry >> 4
264  }
265  const reserve = (n: number) => {
266    if (length + n <= out.length) return
267
268    const grown = new Uint8Array(Math.max(out.length * 2, length + n))
269    grown.set(out.subarray(0, length))
270    out = grown
271  }
272
273  let isLast = false
274
275  while (!isLast) {
276    if (pos > data.length + 4) throw new Error('truncated deflate stream')
277
278    isLast = bits(1) === 1
279    const type = bits(2)
280
281    if (type === 0) {
282      pos -= bitCount >> 3
283      bitBuffer = 0
284      bitCount = 0
285      const size = data[pos] | (data[pos + 1] << 8)
286      pos += 4
287      reserve(size)
288      out.set(data.subarray(pos, pos + size), length)
289      length += size
290      pos += size
291      continue
292    }
293
294    if (type === 3) throw new Error('bad deflate block')
295
296    const [literals, distances] = type === 1 ? fixedTables() : readDynamicTables(bits, symbol)
297
298    for (;;) {
299      const value = symbol(literals)
300
301      if (value < 256) {
302        reserve(1)
303        out[length++] = value
304        continue
305      }
306
307      if (value === 256) break
308
309      const lengthIndex = value - 257
310      const size = LEN_BASE[lengthIndex] + bits(LEN_EXTRA[lengthIndex])
311      const distanceIndex = symbol(distances)
312      const distance = DIST_BASE[distanceIndex] + bits(DIST_EXTRA[distanceIndex])
313
314      if (distance > length) throw new Error('bad deflate distance')
315
316      reserve(size)
317
318      for (let i = 0; i < size; i++) {
319        out[length] = out[length - distance]
320        length++
321      }
322    }
323  }
324
325  return out.subarray(0, length)
326}
327
328let fixed: [Huffman, Huffman] | undefined
329
330function fixedTables(): [Huffman, Huffman] {
331  if (fixed) return fixed
332
333  const literal = new Uint8Array(288)
334  literal.fill(8, 0, 144)
335  literal.fill(9, 144, 256)
336  literal.fill(7, 256, 280)
337  literal.fill(8, 280, 288)
338  fixed = [buildHuffman(literal), buildHuffman(new Uint8Array(30).fill(5))]
339
340  return fixed
341}
342
343function readDynamicTables(bits: (n: number) => number, symbol: (code: Huffman) => number): [Huffman, Huffman] {
344  const literalCount = bits(5) + 257
345  const distanceCount = bits(5) + 1
346  const codeLengthCount = bits(4) + 4
347  const codeLengths = new Uint8Array(19)
348
349  for (let i = 0; i < codeLengthCount; i++) codeLengths[CODE_LENGTH_ORDER[i]] = bits(3)
350
351  const codeLengthTable = buildHuffman(codeLengths)
352  const lengths = new Uint8Array(literalCount + distanceCount)
353  let i = 0
354
355  while (i < lengths.length) {
356    const value = symbol(codeLengthTable)
357
358    if (value < 16) {
359      lengths[i++] = value
360    } else if (value === 16) {
361      if (i === 0) throw new Error('bad code length repeat')
362
363      const repeat = 3 + bits(2)
364      lengths.fill(lengths[i - 1], i, i + repeat)
365      i += repeat
366    } else {
367      const repeat = value === 17 ? 3 + bits(3) : 11 + bits(7)
368      i += repeat
369    }
370  }
371
372  return [buildHuffman(lengths.subarray(0, literalCount)), buildHuffman(lengths.subarray(literalCount))]
373}
374
375function buildHuffman(lengths: Uint8Array): Huffman {
376  let maxBits = 1
377
378  for (const length of lengths) if (length > maxBits) maxBits = length
379
380  const counts = new Int32Array(16)
381
382  for (const length of lengths) counts[length]++
383
384  counts[0] = 0
385  const nextCode = new Int32Array(16)
386  let code = 0
387
388  for (let size = 1; size < 16; size++) {
389    code = (code + counts[size - 1]) << 1
390    nextCode[size] = code
391  }
392
393  const table = new Int32Array(1 << maxBits).fill(-1)
394
395  lengths.forEach((size, value) => {
396    if (!size) return
397
398    const assigned = nextCode[size]++
399    let reversed = 0
400
401    for (let k = 0; k < size; k++) reversed = (reversed << 1) | ((assigned >> k) & 1)
402    for (let at = reversed; at < table.length; at += 1 << size) table[at] = (value << 4) | size
403  })
404
405  return { table, bits: maxBits }
406}
407

1import { toBase64 } from './base64'
2import type { Rgba } from './png'
3
4export type Fit = { columns: number; rows: number; pxWidth: number; pxHeight: number }
5
6const DEFAULT_COLOR = 0x01000000
7const OPAQUE = 128
8// 사분면 마스크별 전경 글리프, 비트는 왼위 1 오른위 2 왼아래 4 오른아래 8
9const QUADRANT = [
10  0x20, 0x2598, 0x259d, 0x2580, 0x2596, 0x258c, 0x259e, 0x259b,
11  0x2597, 0x259a, 0x2590, 0x259c, 0x2584, 0x2599, 0x259f, 0x2588,
12]
13// 동률이면 앞선 분할을 고르므로 반블록 ▀ 우선
14const SPLITS = [0b0011, 0b0101, 0b1001, 0b0001, 0b0010, 0b0100, 0b1000]
15
16export function fitBox(width: number, height: number, maxColumns: number, maxRows: number): Fit {
17  const scale = Math.min(maxColumns / width, (maxRows * 2) / height)
18  const pxWidth = Math.max(1, Math.min(maxColumns, Math.round(width * scale)))
19  const pxHeight = Math.max(1, Math.min(maxRows * 2, Math.round(height * scale)))
20
21  return { columns: pxWidth, rows: Math.ceil(pxHeight / 2), pxWidth, pxHeight }
22}
23
24export function downsample(image: Rgba, width: number, height: number): Rgba {
25  const { width: sourceWidth, height: sourceHeight, data } = image
26  const out = new Uint8Array(width * height * 4)
27
28  for (let ty = 0; ty < height; ty++) {
29    const y0 = Math.floor((ty * sourceHeight) / height)
30    const y1 = Math.max(y0 + 1, Math.floor(((ty + 1) * sourceHeight) / height))
31
32    for (let tx = 0; tx < width; tx++) {
33      const x0 = Math.floor((tx * sourceWidth) / width)
34      const x1 = Math.max(x0 + 1, Math.floor(((tx + 1) * sourceWidth) / width))
35      let r = 0
36      let g = 0
37      let b = 0
38      let a = 0
39      let count = 0
40
41      for (let y = y0; y < y1; y++) {
42        for (let x = x0; x < x1; x++) {
43          const i = (y * sourceWidth + x) * 4
44          const alpha = data[i + 3]
45          r += data[i] * alpha
46          g += data[i + 1] * alpha
47          b += data[i + 2] * alpha
48          a += alpha
49          count++
50        }
51      }
52
53      const o = (ty * width + tx) * 4
54
55      if (a > 0) {
56        out[o] = Math.round(r / a)
57        out[o + 1] = Math.round(g / a)
58        out[o + 2] = Math.round(b / a)
59      }
60
61      out[o + 3] = Math.round(a / count)
62    }
63  }
64
65  return { width, height, data: out }
66}
67
68// 셀마다 2x2 픽셀을 오차 제곱합이 가장 작은 두 색 분할로 근사해 반블록보다 가로 해상도 2배
69export function quadrantCells(image: Rgba): string {
70  const { width, height, data } = image
71  const columns = Math.ceil(width / 2)
72  const rows = Math.ceil(height / 2)
73  const words = new Uint32Array(columns * rows * 3)
74  const quad: (number | undefined)[] = [0, 0, 0, 0]
75
76  const pixel = (x: number, y: number) => {
77    if (x >= width || y >= height) return undefined
78
79    const i = (y * width + x) * 4
80
81    return data[i + 3] < OPAQUE ? undefined : i
82  }
83
84  const mean = (mask: number) => {
85    let r = 0
86    let g = 0
87    let b = 0
88    let count = 0
89
90    for (let bit = 0; bit < 4; bit++) {
91      const i = quad[bit]
92
93      if (!(mask & (1 << bit)) || i === undefined) continue
94
95      r += data[i]
96      g += data[i + 1]
97      b += data[i + 2]
98      count++
99    }
100
101    return [r / count, g / count, b / count]
102  }
103
104  const pack = ([r, g, b]: number[]) => (Math.round(r) << 16) | (Math.round(g) << 8) | Math.round(b)
105
106  const error = (mask: number, fg: number[], bg: number[]) => {
107    let sum = 0
108
109    for (let bit = 0; bit < 4; bit++) {
110      const i = quad[bit] as number
111      const c = mask & (1 << bit) ? fg : bg
112      sum += (data[i] - c[0]) ** 2 + (data[i + 1] - c[1]) ** 2 + (data[i + 2] - c[2]) ** 2
113    }
114
115    return sum
116  }
117
118  for (let cy = 0; cy < rows; cy++) {
119    for (let cx = 0; cx < columns; cx++) {
120      quad[0] = pixel(cx * 2, cy * 2)
121      quad[1] = pixel(cx * 2 + 1, cy * 2)
122      quad[2] = pixel(cx * 2, cy * 2 + 1)
123      quad[3] = pixel(cx * 2 + 1, cy * 2 + 1)
124
125      const opaque = quad.reduce<number>((mask, i, bit) => (i === undefined ? mask : mask | (1 << bit)), 0)
126      const w = (cy * columns + cx) * 3
127
128      if (opaque === 0) {
129        words[w] = QUADRANT[0]
130        words[w + 1] = DEFAULT_COLOR
131        words[w + 2] = DEFAULT_COLOR
132        continue
133      }
134
135      // 투명 픽셀은 터미널 배경에 맡기므로 불투명 픽셀만 전경 한 색
136      if (opaque !== 0b1111) {
137        words[w] = QUADRANT[opaque]
138        words[w + 1] = pack(mean(opaque))
139        words[w + 2] = DEFAULT_COLOR
140        continue
141      }
142
143      let best = { mask: 0, fg: [0, 0, 0], bg: [0, 0, 0], error: Infinity }
144
145      for (const mask of SPLITS) {
146        const fg = mean(mask)
147        const bg = mean(~mask & 0b1111)
148        const sum = error(mask, fg, bg)
149
150        if (sum < best.error) best = { mask, fg, bg, error: sum }
151      }
152
153      words[w] = QUADRANT[best.mask]
154      words[w + 1] = pack(best.fg)
155      words[w + 2] = pack(best.bg)
156    }
157  }
158
159  return toBase64(new Uint8Array(words.buffer))
160}
161
162// 화면 캡처로 찾을 단색 마커, 터미널이 채널당 4비트로 줄여 그려도 그대로 남는 0x11 배수 색만 사용
163export function windowKey(n: number, salt: number): number {
164  return 0x220000 | ((0x11 * (salt & 3)) << 8) | (0x11 * (4 + (n % 12)))
165}
166
167export function windowCells(key: number, columns: number, rows: number): string {
168  const words = new Uint32Array(columns * rows * 3)
169
170  for (let i = 0; i < columns * rows; i++) {
171    words[i * 3] = 0x20
172    words[i * 3 + 1] = DEFAULT_COLOR
173    words[i * 3 + 2] = key
174  }
175
176  return toBase64(new Uint8Array(words.buffer))
177}
178
179const MARK_FIRST = 0x2800
180const MARK_MAGIC = 0xa
181const MARK_STEP = 17
182const MARK_MAX_ROWS = 16
183
184export function markId(path: string): number {
185  let hash = 0x811c9dc5
186
187  for (let i = 0; i < path.length; i++) hash = Math.imul(hash ^ path.charCodeAt(i), 0x01000193) >>> 0
188
189  return hash & 0xfffff
190}
191
192export function markHex(id: number): string {
193  return id.toString(16).padStart(5, '0')
194}
195
196export function markCells(id: number, columns: number, rows: number): string {
197  if (rows > MARK_MAX_ROWS) throw new Error(`marker rows over ${MARK_MAX_ROWS}`)
198
199  const n = [MARK_MAGIC, (id >> 16) & 15, (id >> 12) & 15, (id >> 8) & 15, (id >> 4) & 15, id & 15].map(v => v * MARK_STEP)
200  const fg = (n[0] << 16) | (n[1] << 8) | n[2]
201  const bg = (n[3] << 16) | (n[4] << 8) | n[5]
202  const words = new Uint32Array(columns * rows * 3)
203
204  for (let row = 0; row < rows; row++) {
205    for (let x = 0; x < columns; x++) {
206      const w = (row * columns + x) * 3
207      words[w] = MARK_FIRST + ((row << 4) | (rows - 1))
208      words[w + 1] = fg
209      words[w + 2] = bg
210    }
211  }
212
213  return toBase64(new Uint8Array(words.buffer))
214}
215

1export type Mode = 'blocks' | 'pixels' | 'overlay' | 'window'
2
3export type Preview = {
4  n: number
5  source?: string
6  width?: number
7  height?: number
8  thumb?: string
9  thumbWidth?: number
10  thumbHeight?: number
11  file?: string
12  id?: number
13  note?: string
14  isPending?: boolean
15  isInIde?: boolean
16}
17
18declare module 'claude-code' {
19  interface PluginState {
20    'mods-image-preview': { previews: Preview[]; mode: Mode }
21  }
22}
23
