Worktree Radar

1import { atom, read, update } from 'claude-code'
2import type { EngineInterface, PluginOptions, Register } from 'claude-code'
3
4import type { RadarConfig } from '../types'
5
6import { commandRequestOf } from './command'
7import type { Host, RadarOptions } from './host'
8import Limits from './limits'
9import { BAND_TITLE, COMMAND_DESCRIPTION, COMMAND_HINT } from './names'
10import { createRadar, type Radar } from './radar'
11import { bandLinesOf, controlsOf, frameOf } from './rows'
12import { forgetRadar, keepRadar, loadRadar, pruneSaved, saveRadar, savedRadarOf, type SavedRadar } from './saved'
13import { clipChars, messageOf, sanitize } from './text'
14import { TOOL_DESCRIPTION, TOOL_INPUT_SCHEMA, toolJsonOf, toolRequestOf } from './tool'
15import { bandView } from './view'
16
17/**
18 * The radar's session state. The band draws from it, so every write
19 * redraws the band; a reload of the module keeps it. A new process starts
20 * without it, and `/clear`, `/resume` and `/branch` reset it: an open radar
21 * is also saved in the store for the session's resume (saved.ts).
22 */
23const RADAR = atom({ plugin: 'worktree-radar', key: 'radar' } as const, null)
24const SNAPSHOT = atom({ plugin: 'worktree-radar', key: 'snapshot' } as const, null)
25const PROBLEM = atom({ plugin: 'worktree-radar', key: 'problem' } as const, null)
26const COMMENTS = atom({ plugin: 'worktree-radar', key: 'comments' } as const, {})
27const STATUS = atom({ plugin: 'worktree-radar', key: 'status' } as const, null)
28const HELP_SHOWN = atom({ plugin: 'worktree-radar', key: 'helpShown' } as const, false)
29const COMPACT = atom({ plugin: 'worktree-radar', key: 'compact' } as const, false)
30const DUE_MARKS = atom({ plugin: 'worktree-radar', key: 'dueMarks' } as const, {})
31const THEME_SETTING = atom({ plugin: 'worktree-radar', key: 'themeSetting' } as const, null)
32
33/**
34 * Reads the person's settings, each checked: `userConfig` in plugin.json.
35 *
36 * @param options the values Claude Code hands `register`
37 * @returns the settings, defaults filled in
38 */
39function optionsOf(options: PluginOptions): RadarOptions {
40  const seconds = typeof options['pollSeconds'] === 'number' ? options['pollSeconds'] : 4
41
42  return {
43    notifyReady: options['notifyReady'] !== false,
44    pollMs: Math.round(Math.min(Math.max(seconds, 1), 60) * 1000),
45  }
46}
47
48/**
49 * Binds the radar's engine calls to one hook's `$`.
50 *
51 * @param $ the engine, as a hook receives it
52 * @param options the person's settings
53 * @returns the calls, as a plain record
54 */
55function hostOf($: EngineInterface, options: RadarOptions): Host {
56  return {
57    cwd: () => $.session.cwd(),
58    sessionId: () => $.session.id(),
59    run: (argv, init) => $.process.run(argv, init),
60    agents: () =>
61      $.agent.list().then(
62        agents => agents.map(agent => ({ id: agent.id, name: agent.name ?? null, description: agent.description, status: agent.status })),
63        () => [],
64      ),
65    themeSetting: () =>
66      $.config.list().then(
67        rows => {
68          const value = rows.find(row => row.key === 'theme')?.value
69
70          return typeof value === 'string' ? value : null
71        },
72        () => null,
73      ),
74    readText: path => $.fs.read(path).then(
75      text => text,
76      () => null,
77    ),
78    now: () => $.clock.now(),
79    after: (ms, fn) => $.clock.after(ms, fn),
80    invalidate: () => $.ui.invalidate('ui.render'),
81    toast: text => $.ui.toast(text),
82    notify: async text => {
83      await $.ui.notify(text, { title: BAND_TITLE })
84    },
85    submit: async text => {
86      await $.prompt.submit({ text })
87    },
88    store: {
89      get: key => $.store.get(key),
90      set: (key, value) => $.store.set(key, value),
91      delete: key => $.store.delete(key),
92      keys: () => $.store.keys(),
93    },
94    state: {
95      radar: {
96        get: () => read($, RADAR),
97        set: async fn => {
98          await update($, RADAR, fn)
99        },
100      },
101      snapshot: {
102        get: () => read($, SNAPSHOT),
103        set: async fn => {
104          await update($, SNAPSHOT, fn)
105        },
106      },
107      problem: {
108        get: () => read($, PROBLEM),
109        set: async fn => {
110          await update($, PROBLEM, fn)
111        },
112      },
113      comments: {
114        get: () => read($, COMMENTS),
115        set: async fn => {
116          await update($, COMMENTS, fn)
117        },
118      },
119      status: {
120        get: () => read($, STATUS),
121        set: async fn => {
122          await update($, STATUS, fn)
123        },
124      },
125      helpShown: {
126        get: () => read($, HELP_SHOWN),
127        set: async fn => {
128          await update($, HELP_SHOWN, fn)
129        },
130      },
131      compact: {
132        get: () => read($, COMPACT),
133        set: async fn => {
134          await update($, COMPACT, fn)
135        },
136      },
137      dueMarks: {
138        get: () => read($, DUE_MARKS),
139        set: async fn => {
140          await update($, DUE_MARKS, fn)
141        },
142      },
143      themeSetting: {
144        get: () => read($, THEME_SETTING),
145        set: async fn => {
146          await update($, THEME_SETTING, fn)
147        },
148      },
149    },
150    options,
151  }
152}
153
154/**
155 * The session the open radar is saved under: the one it opened or reopened
156 * in. `$.session.id()` lags a `/resume` or `/branch`, answering the session
157 * left until the next command, so a save in between must not ask it. Null
158 * while closed, and after a reload of the module, when it has caught up.
159 */
160let savedAs: string | null = null
161
162/**
163 * Saves the open radar as it stands, after a change a person or a caller
164 * made (folding, the status line, a comment), so a process that dies
165 * before `session.end` still comes back with it. The due marks a read finds
166 * ride along with these saves and the one at `session.end`, not on their
167 * own: a read can land in the lag `savedAs` covers, and only refines the
168 * rebase order.
169 *
170 * @param host the engine's calls
171 */
172async function keepChange(host: Host): Promise<void> {
173  try {
174    await keepRadar(host, savedAs ?? (await host.sessionId()))
175  } catch {
176    // It comes back as it was at its last save, or at session.end
177  }
178}
179
180/**
181 * Opens the radar on a folder, replacing one open before, and starts its
182 * polls; the first read follows at once. It is saved for the session's
183 * resume as it opens, and again on each change (`keepChange`): a process
184 * that dies without ending the session still comes back with it.
185 *
186 * @param host the engine's calls
187 * @param radar the radar's polls and reads
188 * @param config what to watch
189 * @returns once the first read is done
190 */
191async function openRadar(host: Host, radar: Radar, config: RadarConfig): Promise<void> {
192  radar.stop()
193  await host.state.radar.set(() => config)
194  await host.state.snapshot.set(() => null)
195  await host.state.problem.set(() => null)
196
197  try {
198    const sessionId = await host.sessionId()
199
200    savedAs = sessionId
201    await keepRadar(host, sessionId)
202    void pruneSaved(host, sessionId).catch(() => undefined)
203  } catch {
204    // It opens all the same, and is saved when the session ends
205  }
206
207  await radar.start(host)
208}
209
210/**
211 * Stops the radar and empties the state the band draws from.
212 */
213async function clearRadar(host: Host, radar: Radar): Promise<void> {
214  radar.stop()
215  savedAs = null
216  await host.state.radar.set(() => null)
217  await host.state.snapshot.set(() => null)
218  await host.state.problem.set(() => null)
219  await host.state.status.set(() => null)
220  await host.state.helpShown.set(() => false)
221}
222
223/**
224 * Closes the radar, and drops what the session saved for its resume.
225 */
226async function closeRadar(host: Host, radar: Radar): Promise<void> {
227  await clearRadar(host, radar)
228
229  try {
230    await forgetRadar(host, await host.sessionId())
231  } catch {
232    // A resume would open it again: closed, it stays closed in this session
233  }
234}
235
236/**
237 * Opens a radar a session left, as it was left, and saves it for this
238 * session; with none, the radar is closed. Called where the state starts
239 * over: a new process, `/clear`, `/resume` and `/branch`.
240 *
241 * @param host the engine's calls
242 * @param radar the radar's polls and reads
243 * @param saved what the session left, or null
244 * @param sessionId the session it opens in: the conversation on screen
245 */
246async function reopenRadar(host: Host, radar: Radar, saved: SavedRadar | null, sessionId: string): Promise<void> {
247  radar.stop()
248
249  if (saved === null) {
250    // The engine reset the state already; an open radar left here would be
251    // another conversation's
252    if ((await host.state.radar.get()) !== null) {
253      await clearRadar(host, radar)
254    }
255
256    return
257  }
258
259  await host.state.compact.set(() => saved.compact)
260  await host.state.status.set(() => saved.status)
261  await host.state.comments.set(() => ({ ...saved.comments }))
262  await host.state.dueMarks.set(() => ({ ...saved.dueMarks }))
263  await host.state.helpShown.set(() => false)
264  await host.state.snapshot.set(() => null)
265  await host.state.problem.set(() => null)
266  // Last, so the band's first drawing has the rest
267  await host.state.radar.set(() => saved.radar)
268  savedAs = sessionId
269  await saveRadar(host, sessionId, { ...saved, savedAt: await host.now() }).catch(() => undefined)
270  void radar.start(host).catch(() => undefined)
271}
272
273/**
274 * The tool's answer with the radar's latest read.
275 */
276async function answerOf(host: Host): Promise<{ result: string } | { deny: string }> {
277  const [snapshot, problem] = await Promise.all([host.state.snapshot.get(), host.state.problem.get()])
278
279  if (snapshot === null) {
280    return { deny: `The radar cannot read the repository: ${problem ?? 'no read yet'}` }
281  }
282
283  return { result: toolJsonOf(snapshot) }
284}
285
286/**
287 * Registers the radar: `/radar` and the `radar` tool open a live view of
288 * the repository's branches and worktrees in the band above the prompt,
289 * kept fresh by polls while it is open.
290 */
291export const register: Register = (on, pluginOptions) => {
292  const options = optionsOf(pluginOptions)
293  const radar = createRadar()
294  /**
295   * Whether `session.start` ran for this module: at a process's start
296   * `classic.SessionStart` fires before it, and `session.start` opens what a
297   * resumed session left.
298   */
299  let hasStarted = false
300  /**
301   * The radar the session that just ended had open, for the conversation
302   * that follows it in this process (`/clear`, `/branch`).
303   */
304  let ended: SavedRadar | null = null
305
306  on('session.start', async ($, e, next) => {
307    hasStarted = true
308
309    try {
310      await $.command.register({
311        name: 'radar',
312        description: COMMAND_DESCRIPTION,
313        argumentHint: COMMAND_HINT,
314        immediate: true,
315      })
316    } catch (error) {
317      $.ui.log(`worktree-radar: could not register /radar: ${messageOf(error)}`)
318    }
319
320    try {
321      await $.tool.register({
322        name: 'radar',
323        description: TOOL_DESCRIPTION,
324        inputSchema: TOOL_INPUT_SCHEMA,
325        isDeferred: false,
326      })
327    } catch (error) {
328      $.ui.log(`worktree-radar: could not register its tool: ${messageOf(error)}`)
329    }
330
331    // A reload of the module cancels its timers but keeps the state: an
332    // open radar polls again. A new process starts with no state: a resumed
333    // session (`claude --continue`, `--resume`) opens the radar it left open
334    const host = hostOf($, options)
335
336    if ((await host.state.radar.get()) !== null) {
337      void radar.start(host).catch(() => undefined)
338    } else if (e.isInteractive) {
339      void host
340        .sessionId()
341        .then(async sessionId => reopenRadar(host, radar, await loadRadar(host, sessionId), sessionId))
342        .catch(() => undefined)
343    }
344
345    return next(e)
346  })
347
348  /**
349   * `/clear`, `/resume` and `/branch` (`fork`) reset the session state, and
350   * the conversation goes on under another session id, `e.session_id`
351   * (`$.session.id()` still answers the old one here). The resumed
352   * conversation gets the radar it left, or none; `/branch` carries the
353   * radar on whole, and `/clear` without its caller's wake list: the wakes
354   * were asked for by the conversation it cleared.
355   */
356  on('classic.SessionStart', { source: ['clear', 'resume', 'fork'] }, async ($, e, next) => {
357    const carried = ended
358
359    ended = null
360
361    if (hasStarted) {
362      const host = hostOf($, options)
363      const saved =
364        e.source === 'resume'
365          ? await loadRadar(host, e.session_id)
366          : e.source === 'clear' && carried !== null
367            ? { ...carried, radar: { ...carried.radar, wake: [] } }
368            : carried
369
370      await reopenRadar(host, radar, saved, e.session_id)
371    }
372
373    return next(e)
374  }).catch(($, e, next) => next(e))
375
376  /**
377   * The session ends: an exit, `/clear`, `/resume` or `/branch`. An open
378   * radar is saved under its id as it stands, for a resume, and kept for the
379   * conversation that follows in this process. A closed one writes nothing.
380   */
381  on('session.end', async ($, e, next) => {
382    const host = hostOf($, options)
383
384    ended = null
385
386    try {
387      ended = await savedRadarOf(host)
388
389      if (ended !== null) {
390        await saveRadar(host, e.sessionId, ended)
391      }
392    } catch {
393      // It comes back as it was when it opened
394    }
395
396    return next(e)
397  })
398
399  on('command.run', { command: 'radar' }, async ($, e) => {
400    const host = hostOf($, options)
401    const request = commandRequestOf(e.args)
402    const open = await host.state.radar.get()
403    const root = open?.root ?? (await host.cwd())
404
405    switch (request.kind) {
406      case 'toggle':
407        if (open !== null) {
408          await closeRadar(host, radar)
409        } else {
410          void openRadar(host, radar, { root, base: null, wake: [] }).catch(() => undefined)
411        }
412
413        return {}
414      case 'open':
415        void openRadar(host, radar, { root: await host.cwd(), base: request.base, wake: open?.wake ?? [] }).catch(
416          () => undefined,
417        )
418
419        return {}
420      case 'close':
421        await closeRadar(host, radar)
422
423        return {}
424      case 'help':
425        await host.state.helpShown.set(() => true)
426
427        if (open === null) {
428          void openRadar(host, radar, { root, base: null, wake: [] }).catch(() => undefined)
429        }
430
431        return {}
432      case 'hold':
433      case 'unhold': {
434        const why = await radar.setHold(host, root, request.branch, request.kind === 'hold' ? request.reason : null)
435        const branch = sanitize(request.branch)
436
437        host.toast(why ?? (request.kind === 'hold' ? `Holding ${branch}` : `${branch} is no longer held`))
438
439        if (why === null && open !== null) {
440          await radar.readNow(host)
441        }
442
443        return {}
444      }
445      case 'usage':
446        return { text: `Usage: /radar ${COMMAND_HINT}` }
447    }
448  })
449
450  on('tool.call', { tool: /^mcp__worktree-radar__radar$/ }, async ($, e) => {
451    const host = hostOf($, options)
452    const request = toolRequestOf(e as unknown as Readonly<Record<string, unknown>>)
453
454    if ('error' in request) {
455      return { deny: request.error }
456    }
457
458    const open = await host.state.radar.get()
459    const root = open?.root ?? (await host.cwd())
460
461    switch (request.action) {
462      case 'open':
463        await openRadar(host, radar, { root: await host.cwd(), base: request.base, wake: request.wake })
464
465        return answerOf(host)
466      case 'close':
467        await closeRadar(host, radar)
468
469        return { result: 'The radar is closed.' }
470      case 'snapshot':
471        if (open === null) {
472          return { deny: 'The radar is not open: call it with action "open" first.' }
473        }
474
475        await radar.readNow(host)
476
477        return answerOf(host)
478      case 'hold':
479      case 'unhold': {
480        const why = await radar.setHold(host, root, request.branch, request.action === 'hold' ? request.reason : null)
481
482        if (why !== null) {
483          return { deny: why }
484        }
485
486        if (open === null) {
487          return { result: request.action === 'hold' ? `Holding ${request.branch}.` : `${request.branch} is no longer held.` }
488        }
489
490        await radar.readNow(host)
491
492        return answerOf(host)
493      }
494      case 'comment': {
495        const why = await radar.setComment(host, root, request.branch, request.text, request.keep)
496
497        if (why !== null) {
498          return { deny: why }
499        }
500
501        if (open === null) {
502          return { result: `Comment set on ${request.branch}.` }
503        }
504
505        await keepChange(host)
506        await radar.readNow(host)
507
508        return answerOf(host)
509      }
510      case 'status': {
511        const text = request.text.trim()
512
513        await host.state.status.set(() => (text === '' ? null : clipChars(text, Limits.COMMENT_CHARS)))
514        await keepChange(host)
515
516        return { result: text === '' ? 'Status line cleared.' : 'Status line set.' }
517      }
518    }
519  }).catch(($, e, next) => (next.called ? next(e) : { deny: 'worktree-radar failed to answer; see claude --debug' }))
520
521  // The theme changes in /config: the base's color follows at once. The
522  // change passes on as it came; should another hook refuse it, the next
523  // read sets the color back from what /config holds
524  on('config.set', { key: 'theme' }, ($, e, next) => {
525    const value = e.value
526
527    if (typeof value === 'string') {
528      void hostOf($, options).state.themeSetting.set(() => value)
529    }
530
531    return next(e)
532  })
533
534  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
535    const host = hostOf($, options)
536    const open = await host.state.radar.get()
537
538    if (open === null || e.props.hasSurvey || (e.surface !== 'terminal' && e.surface !== 'desktop')) {
539      return next(e)
540    }
541
542    const [snapshot, problem, status, isHelpShown, isCompact, themeSetting, now] = await Promise.all([
543      host.state.snapshot.get(),
544      host.state.problem.get(),
545      host.state.status.get(),
546      host.state.helpShown.get(),
547      host.state.compact.get(),
548      host.state.themeSetting.get(),
549      host.now(),
550    ])
551    const columns = e.props.bodyColumns
552    const frame = frameOf(columns, e.props.maxRows)
553    const lines = bandLinesOf({
554      snapshot,
555      problem,
556      status,
557      root: open.root,
558      now,
559      columns: frame.columns,
560      maxRows: frame.maxRows,
561      isHelpShown,
562      isCompact,
563      themeSetting,
564    })
565    const controls = controlsOf(frame.columns, isHelpShown, isCompact)
566
567    // Compact, the band is its status line; the help still shows whole
568    return bandView($.ui.resolve(e), lines, columns, frame, isCompact && !isHelpShown, controls, {
569      help: () => {
570        void hostOf($, options).state.helpShown.set(shown => !shown)
571      },
572      compact: () => {
573        const host = hostOf($, options)
574
575        void host.state.compact
576          .set(compact => !compact)
577          .then(() => keepChange(host))
578          .catch(() => undefined)
579      },
580      exit: () => {
581        void closeRadar(hostOf($, options), radar)
582      },
583    })
584  })
585}
586

1/**
2 * What `/radar` was asked, from its arguments.
3 */
4
5export type CommandRequest =
6  | { readonly kind: 'toggle' }
7  | { readonly kind: 'open'; readonly base: string }
8  | { readonly kind: 'close' }
9  | { readonly kind: 'help' }
10  | { readonly kind: 'hold'; readonly branch: string; readonly reason: string }
11  | { readonly kind: 'unhold'; readonly branch: string }
12  | { readonly kind: 'usage' }
13
14/**
15 * Reads `/radar`'s arguments: none toggles the radar, `off` closes it,
16 * `help` opens it on its help, a branch name opens it on that base,
17 * `hold <branch> [reason]` and `unhold <branch>` park a branch and let it
18 * go.
19 *
20 * @param args what followed the command
21 * @returns the request
22 */
23export function commandRequestOf(args: string): CommandRequest {
24  const words = args.trim().split(/\s+/).filter(word => word !== '')
25  const [first, branch, ...rest] = words
26
27  if (first === undefined) {
28    return { kind: 'toggle' }
29  }
30
31  if ((first === 'off' || first === 'close') && words.length === 1) {
32    return { kind: 'close' }
33  }
34
35  if (first === 'help' && words.length === 1) {
36    return { kind: 'help' }
37  }
38
39  if (first === 'hold' && branch !== undefined) {
40    return { kind: 'hold', branch, reason: rest.join(' ') }
41  }
42
43  if (first === 'unhold' && branch !== undefined && rest.length === 0) {
44    return { kind: 'unhold', branch }
45  }
46
47  return words.length === 1 && first !== 'hold' && first !== 'unhold' ? { kind: 'open', base: first } : { kind: 'usage' }
48}
49

1import type { Timer } from 'claude-code'
2
3import type { CallerComment, RadarConfig, Snapshot } from '../types'
4
5import type { Run } from './git'
6import type { AgentRow } from './sessions'
7
8/**
9 * One value of the radar's session state: read it, or write it from its
10 * current value, which redraws the band.
11 */
12export type StateCell<T> = {
13  readonly get: () => Promise<T>
14  readonly set: (fn: (value: T) => T) => Promise<void>
15}
16
17/**
18 * The radar's session state, value by value (`PluginState['worktree-radar']`).
19 */
20export type RadarState = {
21  readonly radar: StateCell<RadarConfig | null>
22  readonly snapshot: StateCell<Snapshot | null>
23  readonly problem: StateCell<string | null>
24  readonly comments: StateCell<Record<string, CallerComment>>
25  readonly status: StateCell<string | null>
26  readonly helpShown: StateCell<boolean>
27  readonly compact: StateCell<boolean>
28  readonly dueMarks: StateCell<Record<string, string>>
29  readonly themeSetting: StateCell<string | null>
30}
31
32/**
33 * The person's settings for the radar (`userConfig` in plugin.json).
34 */
35export type RadarOptions = {
36  /**
37   * Raise a native notification when a branch becomes READY.
38   */
39  readonly notifyReady: boolean
40  /**
41   * Between two checks for a change, in milliseconds.
42   */
43  readonly pollMs: number
44}
45
46/**
47 * What the radar asks of the engine, bound to one hook's `$` by `hostOf`
48 * in register.tsx: every engine call the mod makes is spelled there, where
49 * `claude plugin validate` reads it, and the rest of the code takes this
50 * plain record instead of `$`.
51 */
52export type Host = {
53  /**
54   * The session's working folder: where the radar opens by default.
55   */
56  readonly cwd: () => Promise<string>
57  /**
58   * The session's id: what `claude --resume` returns to, and the key of the
59   * radar it left open.
60   */
61  readonly sessionId: () => Promise<string>
62  /**
63   * Runs a program by its argument vector, no shell: git, and
64   * `claude agents --json` for the sessions.
65   */
66  readonly run: Run
67  /**
68   * The subagents of this session, as `$.agent.list()` gives them; none
69   * where the engine cannot say.
70   */
71  readonly agents: () => Promise<readonly AgentRow[]>
72  /**
73   * The person's theme setting, `$.config.list()`'s `theme` row; null where
74   * it cannot be read.
75   */
76  readonly themeSetting: () => Promise<string | null>
77  /**
78   * A file's text, or null where it cannot be read.
79   */
80  readonly readText: (path: string) => Promise<string | null>
81  /**
82   * Milliseconds since the epoch.
83   */
84  readonly now: () => Promise<number>
85  readonly after: (ms: number, fn: () => void) => Timer
86  /**
87   * Draws the band again from what the state holds.
88   */
89  readonly invalidate: () => void
90  readonly toast: (text: string) => void
91  /**
92   * A native notification by the person's own channel.
93   */
94  readonly notify: (text: string) => Promise<void>
95  /**
96   * Queues a prompt that starts a turn once the session is idle.
97   */
98  readonly submit: (text: string) => Promise<void>
99  /**
100   * The plugin's store, kept between sessions and shared by every session on
101   * the machine: the holds, per repository, and the radar each session left
102   * open, per session.
103   */
104  readonly store: {
105    readonly get: (key: string) => Promise<unknown>
106    readonly set: (key: string, value: unknown) => Promise<void>
107    readonly delete: (key: string) => Promise<void>
108    readonly keys: () => Promise<string[]>
109  }
110  readonly state: RadarState
111  readonly options: RadarOptions
112}
113

1/**
2 * The radar's fixed numbers, in one place.
3 */
4const Limits = {
5  /**
6   * How long one git run may take. Git under `/mnt/c` and on network shares
7   * is slow; a run past this counts as failed.
8   */
9  GIT_TIMEOUT_MS: 20_000,
10  /**
11   * How long `claude agents --json` may take.
12   */
13  SESSIONS_TIMEOUT_MS: 10_000,
14  /**
15   * Git runs in flight at once during a read.
16   */
17  GIT_PARALLEL: 8,
18  /**
19   * Between two checks for a change while the radar is open.
20   */
21  POLL_MS: 4_000,
22  /**
23   * How long a change must stand still before the radar reads the
24   * repository again: a commit, a rebase or a checkout moves several refs
25   * in a row.
26   */
27  SETTLE_MS: 2_000,
28  /**
29   * Longest a caller's comment or status line is kept, in characters.
30   */
31  COMMENT_CHARS: 200,
32  /**
33   * Longest a hold's reason is kept, in characters.
34   */
35  REASON_CHARS: 200,
36  /**
37   * How far back the base's first-parent line is read to tell a branch that
38   * landed through a merge from a fresh one; a tip older than that reads as
39   * fresh unless the branch's reflog shows it landed.
40   */
41  FIRST_PARENT_COMMITS: 10_000,
42  /**
43   * Names a summary lists before `+n more`.
44   */
45  LIST_NAMES: 3,
46  /**
47   * Sessions whose open radar the store keeps for a resume; past it, the
48   * one saved longest ago is dropped. One is a few hundred bytes, more with
49   * a caller's comments.
50   */
51  SAVED_SESSIONS: 50,
52} as const
53
54export default Limits
55

1/**
2 * The words the radar shows, and the names it registers.
3 */
4
5export const BAND_TITLE = 'Worktree Radar'
6
7export const COMMAND_NAME = 'radar'
8
9export const COMMAND_DESCRIPTION =
10  'Live view of your branches and worktrees above the prompt: what lands cleanly, what conflicts, who is still working'
11
12export const COMMAND_HINT = '[base] | help | hold <branch> [reason] | unhold <branch> | off'
13
14export const TOOL_NAME = 'radar'
15

1import type { Timer } from 'claude-code'
2
3import type { Hold, RadarConfig } from '../types'
4
5import { commentsAfter, readSnapshot } from './analysis'
6import { dueMarksOf, eventsOf, wakeTextOf, type RadarEvent } from './changes'
7import { gitOf, type Git } from './git'
8import type { Host } from './host'
9import Limits from './limits'
10import { HEADS_FORMAT, parseWorktrees, placeOf } from './repo'
11import { folderKeyOf, parseSessions, SESSIONS_ARGV, type AgentRow, type SessionRow } from './sessions'
12import { clipChars, sanitize } from './text'
13
14/**
15 * The radar at work while it is open: the polls that notice a change, the
16 * reads that follow it, and what a read tells the session.
17 *
18 * A poll is cheap (the branch tips, the worktree list, the sessions, the
19 * holds, the session's own agents); a read runs every simulated merge, so it runs only once a change has settled, one
20 * at a time. The band redraws from the state each read writes.
21 */
22
23/**
24 * The store key prefix of a repository's holds; the repository's shared
25 * `.git` folder follows, so every worktree of it sees the same holds.
26 */
27export const HOLDS_KEY_PREFIX = 'holds:'
28
29/**
30 * How long a read may stand before the radar reads again with no change
31 * seen: uncommitted changes and branch ages move without a ref moving.
32 */
33export const REFRESH_MS = 60_000
34
35/**
36 * Polls between two listings of the sessions; the polls between reuse the
37 * last list.
38 */
39export const SESSIONS_EVERY = 2
40
41export function holdsKeyOf(commonDir: string): string {
42  return `${HOLDS_KEY_PREFIX}${folderKeyOf(commonDir)}`
43}
44
45/**
46 * The holds a store value holds, each checked: what the store holds is
47 * untrusted.
48 *
49 * @param value what the store answered
50 * @returns the holds by branch
51 */
52export function holdsIn(value: unknown): Record<string, Hold> {
53  const holds: Record<string, Hold> = {}
54
55  if (value === null || typeof value !== 'object' || Array.isArray(value)) {
56    return holds
57  }
58
59  for (const [branch, hold] of Object.entries(value as Record<string, unknown>)) {
60    const fields = hold as Record<string, unknown> | null
61
62    if (fields !== null && typeof fields === 'object' && typeof fields['reason'] === 'string' && typeof fields['at'] === 'number') {
63      holds[branch] = { reason: fields['reason'], at: fields['at'] }
64    }
65  }
66
67  return holds
68}
69
70/**
71 * What a poll saw: one string that changes when anything the lanes depend
72 * on moved, and the sessions it listed on the way.
73 */
74type Probe = {
75  readonly fingerprint: string
76  readonly sessions: SessionRow[] | null
77}
78
79export type Radar = {
80  /**
81   * Starts the polls for the open radar, and reads at once.
82   */
83  readonly start: (host: Host) => Promise<void>
84  /**
85   * Stops the polls; a read under way is dropped.
86   */
87  readonly stop: () => void
88  /**
89   * Reads now, after any read under way.
90   */
91  readonly readNow: (host: Host) => Promise<void>
92  /**
93   * Holds a branch with a reason, or lets go of it with null.
94   *
95   * @returns null, or why not
96   */
97  readonly setHold: (host: Host, root: string, branch: string, reason: string | null) => Promise<string | null>
98  /**
99   * Comments on a branch's current tip, or on every tip until it lands
100   * (`isKept`); clears the comment with an empty text.
101   *
102   * @returns null, or why not
103   */
104  readonly setComment: (host: Host, root: string, branch: string, text: string, isKept: boolean) => Promise<string | null>
105}
106
107/**
108 * Lists the machine's Claude sessions.
109 *
110 * @param host the engine's calls
111 * @returns the sessions, or null where `claude agents --json` failed
112 */
113async function sessionsOf(host: Host): Promise<SessionRow[] | null> {
114  try {
115    const out = await host.run(SESSIONS_ARGV, { timeoutMs: Limits.SESSIONS_TIMEOUT_MS })
116
117    return out.exitCode === 0 ? parseSessions(out.stdout) : null
118  } catch {
119    return null
120  }
121}
122
123/**
124 * Takes the cheap fingerprint of a repository. Two things in it move no ref:
125 * the holds, which another session sets, and the state of the session's own
126 * agents that work in a worktree, which says whether one is still at work
127 * while its worktree's lock stays.
128 *
129 * @param host the engine's calls
130 * @param git git, bound to the radar's folder
131 * @param holds the repository's holds, as the store has them now
132 * @param agents the session's own agents, as `$.agent.list()` has them now
133 * @param listed the sessions listed a moment ago, to skip listing them again
134 * @returns the fingerprint, or null where git failed
135 */
136async function probeOf(
137  host: Host,
138  git: Git,
139  holds: Readonly<Record<string, Hold>>,
140  agents: readonly AgentRow[],
141  listed?: SessionRow[] | null,
142): Promise<Probe | null> {
143  const [heads, trees, sessions] = await Promise.all([
144    git(['for-each-ref', `--format=${HEADS_FORMAT}`, 'refs/heads']),
145    git(['worktree', 'list', '--porcelain']),
146    listed === undefined ? sessionsOf(host) : Promise.resolve(listed),
147  ])
148
149  if (heads === null || trees === null) {
150    return null
151  }
152
153  const roots = parseWorktrees(trees.stdout).map(tree => folderKeyOf(tree.path))
154  const here = (sessions ?? [])
155    .filter(session => roots.some(root => folderKeyOf(session.cwd) === root || folderKeyOf(session.cwd).startsWith(`${root}/`)))
156    .map(session => `${session.id}:${session.status}:${folderKeyOf(session.cwd)}`)
157    .sort()
158
159  const held = Object.entries(holds)
160    .map(([branch, hold]) => `${branch}:${hold.at}:${hold.reason}`)
161    .sort()
162  // An agent's worktree is named for it, and its lock names it too
163  const working = agents
164    .filter(agent => trees.stdout.includes(`agent-${agent.id}`))
165    .map(agent => `${agent.id}:${agent.status}`)
166    .sort()
167
168  return {
169    fingerprint: [heads.stdout, trees.stdout, sessions === null ? '?' : here.join('\n'), held.join('\n'), working.join('\n')].join('\0'),
170    sessions,
171  }
172}
173
174/**
175 * Makes the radar of one session. Its timers and reads are the module's: a
176 * reload of the module starts them over, from the state the host kept.
177 *
178 * @returns the radar
179 */
180export function createRadar(): Radar {
181  let generation = 0
182  let timer: Timer | null = null
183  let shownFingerprint: string | null = null
184  let pendingFingerprint: string | null = null
185  let lastReadAt = 0
186  let ticks = 0
187  let lastSessions: SessionRow[] | null | undefined
188  let running: Promise<void> | null = null
189  let queued: Promise<void> | null = null
190  const commonDirs = new Map<string, string>()
191  const reported = new Set<string>()
192  // The wake the session has not taken yet, and the events found since
193  let pendingWake: Promise<void> | null = null
194  let outbox: RadarEvent[] = []
195
196  const schedule = (host: Host, at: number, ms: number): void => {
197    timer?.cancel()
198    timer = host.after(ms, () => {
199      void tick(host, at).catch(() => schedule(host, at, host.options.pollMs))
200    })
201  }
202
203  const holdsFor = async (host: Host, git: Git, root: string): Promise<Record<string, Hold>> => {
204    let commonDir = commonDirs.get(root)
205
206    if (commonDir === undefined) {
207      commonDir = (await placeOf(git))?.commonDir
208
209      if (commonDir === undefined) {
210        return {}
211      }
212
213      commonDirs.set(root, commonDir)
214    }
215
216    return holdsIn(await host.store.get(holdsKeyOf(commonDir)).catch(() => undefined))
217  }
218
219  /**
220   * Sends what the outbox holds as one wake, unless the session has not
221   * taken the last one yet: a submitted prompt settles only once its turn
222   * starts, after whatever turn the session is in. The events found
223   * meanwhile go out together once it has, so a long turn ends in one wake,
224   * not one per read. Nothing waits on it: a read that waited stalled the
225   * polls for the whole turn, and a read the session's own tool call ran
226   * waited on a wake that could start only after that call.
227   */
228  const sendWakes = (host: Host): void => {
229    if (pendingWake !== null || outbox.length === 0) {
230      return
231    }
232
233    const text = wakeTextOf(outbox)
234
235    outbox = []
236    pendingWake = host
237      .submit(text)
238      .catch(() => undefined)
239      .finally(() => {
240        pendingWake = null
241        sendWakes(host)
242      })
243  }
244
245  const announce = async (host: Host, radar: RadarConfig, events: readonly RadarEvent[]): Promise<void> => {
246    const fresh = events.filter(event => !reported.has(event.key))
247
248    for (const event of fresh) {
249      reported.add(event.key)
250    }
251
252    outbox.push(...fresh.filter(event => radar.wake.includes(event.kind)))
253    sendWakes(host)
254
255    const ready = fresh.filter(event => event.kind === 'ready')
256
257    if (host.options.notifyReady && ready.length > 0) {
258      const text = ready.map(event => `${event.branch?.name ?? ''} is ready to land (#${event.branch?.rank ?? '?'})`).join(' · ')
259
260      await host.notify(sanitize(text)).catch(() => undefined)
261    }
262  }
263
264  const read = async (host: Host): Promise<void> => {
265    const at = generation
266    const radar = await host.state.radar.get()
267
268    if (radar === null) {
269      return
270    }
271
272    const git = gitOf(host.run, radar.root)
273    const [holds, agents] = await Promise.all([holdsFor(host, git, radar.root), host.agents()])
274    const probe = await probeOf(host, git, holds, agents)
275
276    lastSessions = probe?.sessions
277    const [comments, dueMarks, now, self] = await Promise.all([
278      host.state.comments.get(),
279      host.state.dueMarks.get(),
280      host.now(),
281      host.sessionId().catch(() => null),
282    ])
283    const result = await readSnapshot({
284      git,
285      readText: host.readText,
286      sessions: probe?.sessions ?? null,
287      agents,
288      self,
289      holds,
290      comments,
291      dueMarks,
292      base: radar.base,
293      now,
294    })
295
296    if (at !== generation) {
297      return
298    }
299
300    lastReadAt = now
301
302    if (result.problem !== undefined) {
303      await host.state.problem.set(() => result.problem)
304
305      return
306    }
307
308    commonDirs.set(radar.root, result.commonDir)
309    shownFingerprint = probe?.fingerprint ?? null
310
311    const [before, theme, shownTheme] = await Promise.all([
312      host.state.snapshot.get(),
313      host.themeSetting(),
314      host.state.themeSetting.get(),
315    ])
316
317    // The theme picks the base's color; a read keeps it current
318    if (theme !== shownTheme) {
319      await host.state.themeSetting.set(() => theme)
320    }
321
322    await host.state.snapshot.set(() => result.snapshot)
323    await host.state.problem.set(() => null)
324    await host.state.dueMarks.set(marks => dueMarksOf(marks, result.snapshot))
325    await host.state.comments.set(comments => commentsAfter(comments, result.snapshot))
326    await announce(host, radar, eventsOf(before, result.snapshot))
327  }
328
329  const readNow = (host: Host): Promise<void> => {
330    if (queued !== null) {
331      return queued
332    }
333
334    const runRead = (): Promise<void> => {
335      running = read(host).finally(() => {
336        running = null
337      })
338
339      return running
340    }
341
342    if (running === null) {
343      return runRead()
344    }
345
346    queued = running
347      .catch(() => undefined)
348      .then(() => {
349        queued = null
350
351        return runRead()
352      })
353
354    return queued
355  }
356
357  const tick = async (host: Host, at: number): Promise<void> => {
358    if (at !== generation) {
359      return
360    }
361
362    const radar = await host.state.radar.get()
363
364    if (radar === null) {
365      return
366    }
367
368    // Listing the sessions starts the claude CLI: every other poll is enough
369    ticks += 1
370
371    const git = gitOf(host.run, radar.root)
372    const [holds, agents] = await Promise.all([holdsFor(host, git, radar.root), host.agents()])
373    const probe = await probeOf(host, git, holds, agents, ticks % SESSIONS_EVERY === 0 ? undefined : lastSessions)
374    const now = await host.now()
375
376    lastSessions = probe?.sessions
377
378    if (at !== generation) {
379      return
380    }
381
382    if (probe !== null && probe.fingerprint !== shownFingerprint) {
383      // A change reads once it stands still: a commit, a rebase or a
384      // checkout moves several refs in a row
385      if (probe.fingerprint !== pendingFingerprint) {
386        pendingFingerprint = probe.fingerprint
387        schedule(host, at, Limits.SETTLE_MS)
388
389        return
390      }
391
392      pendingFingerprint = null
393      await readNow(host)
394    } else if (now - lastReadAt >= REFRESH_MS) {
395      await readNow(host)
396    } else {
397      // Ages move on between reads
398      host.invalidate()
399    }
400
401    schedule(host, at, host.options.pollMs)
402  }
403
404  return {
405    start: async host => {
406      generation += 1
407      shownFingerprint = null
408      pendingFingerprint = null
409
410      const at = generation
411
412      await readNow(host)
413
414      if (at === generation) {
415        schedule(host, at, host.options.pollMs)
416      }
417    },
418    stop: () => {
419      generation += 1
420      timer?.cancel()
421      timer = null
422      shownFingerprint = null
423      pendingFingerprint = null
424      // A closed radar wakes no one; a wake already submitted is the engine's
425      outbox = []
426    },
427    readNow,
428    setHold: async (host, root, branch, reason) => {
429      const git = gitOf(host.run, root)
430      const place = await placeOf(git)
431
432      if (place === null) {
433        return 'not in a git repository'
434      }
435
436      if (reason !== null && (await git(['rev-parse', '--verify', '--quiet', `refs/heads/${branch}`])) === null) {
437        return `no branch named ${branch}`
438      }
439
440      const key = holdsKeyOf(place.commonDir)
441      const holds = holdsIn(await host.store.get(key).catch(() => undefined))
442
443      if (reason === null) {
444        delete holds[branch]
445      } else {
446        holds[branch] = { reason: clipChars(reason.trim(), Limits.REASON_CHARS), at: await host.now() }
447      }
448
449      await host.store.set(key, holds)
450
451      return null
452    },
453    setComment: async (host, root, branch, text, isKept) => {
454      const tip = await gitOf(host.run, root)(['rev-parse', '--verify', '--quiet', `refs/heads/${branch}`])
455
456      if (tip === null) {
457        return `no branch named ${branch}`
458      }
459
460      const sha = tip.stdout.trim()
461      const kept = clipChars(text.trim(), Limits.COMMENT_CHARS)
462
463      await host.state.comments.set(comments => {
464        const next = { ...comments }
465
466        if (kept === '') {
467          delete next[branch]
468        } else {
469          next[branch] = { sha, text: kept, isKept }
470        }
471
472        return next
473      })
474
475      return null
476    },
477  }
478}
479

1import type { Color, ThemeKey } from 'claude-code'
2
3import type { BranchInfo, Lane, Snapshot } from '../types'
4
5import { shortList } from './analysis'
6import { BAND_TITLE } from './names'
7import { cellWidth, padEnd, sanitize, truncateEnd, truncateMiddle } from './text'
8
9/**
10 * The band's lines, laid out in cells before anything is drawn: pure, so
11 * every width can be tested without the engine.
12 */
13
14/**
15 * A run of text drawn in one style.
16 */
17export type Segment = {
18  readonly text: string
19  /**
20   * A theme key, which follows the person's theme; a raw color only where a
21   * constant says why.
22   */
23  readonly color?: Color
24  readonly dim?: boolean
25  readonly bold?: boolean
26  readonly italic?: boolean
27}
28
29export type Line = {
30  readonly key: string
31  readonly segments: readonly Segment[]
32}
33
34export type BandModel = {
35  readonly snapshot: Snapshot | null
36  readonly problem: string | null
37  /**
38   * A caller's line under the queue.
39   */
40  readonly status: string | null
41  /**
42   * The folder the radar was opened from.
43   */
44  readonly root: string
45  /**
46   * Now, in milliseconds since the epoch.
47   */
48  readonly now: number
49  /**
50   * The cells each line may take.
51   */
52  readonly columns: number
53  /**
54   * The rows the band shows whole; past them it scrolls.
55   */
56  readonly maxRows: number
57  /**
58   * Whether the help stands in for the queue.
59   */
60  readonly isHelpShown: boolean
61  /**
62   * Whether the queue is folded into the header's one line.
63   */
64  readonly isCompact: boolean
65  /**
66   * The person's theme setting, for the base's color; null where unknown.
67   */
68  readonly themeSetting: string | null
69}
70
71/**
72 * The band's title, leading the status line (the foot, or the compact
73 * line).
74 */
75export function titleOf(): Segment[] {
76  return [{ text: BAND_TITLE, bold: true }]
77}
78
79export const LANE_LABELS: Readonly<Record<Lane, string>> = {
80  READY: 'ready',
81  NEEDS_REBASE: 'needs rebase',
82  STACKED: 'stacked',
83  IN_PROGRESS: 'in progress',
84  HOLD: 'on hold',
85  CLEANUP: 'cleanup',
86}
87
88/**
89 * The lane labels of a narrow band.
90 */
91export const SHORT_LANE_LABELS: Readonly<Record<Lane, string>> = {
92  READY: 'ready',
93  NEEDS_REBASE: 'rebase',
94  STACKED: 'stack',
95  IN_PROGRESS: 'wip',
96  HOLD: 'hold',
97  CLEANUP: 'done',
98}
99
100/**
101 * What each lane means, for the help; `{base}` stands for the base branch.
102 */
103export const LANE_MEANINGS: Readonly<Record<Lane, string>> = {
104  READY: 'merges cleanly into {base}, nothing uncommitted, no busy session in its worktree',
105  NEEDS_REBASE: 'conflicts with {base}: it needs a rebase before it can land',
106  STACKED: 'holds every commit of another open branch: that one lands first',
107  IN_PROGRESS: 'uncommitted changes, a rebase under way, or a busy Claude session or a running subagent in its worktree',
108  HOLD: 'parked by you with /radar hold: out of the landing order, whatever else it shows, until you let it go',
109  CLEANUP: 'nothing left to land: landed in {base}, or no commits and no session',
110}
111
112/**
113 * Theme keys, so the lanes follow the person's theme.
114 */
115export const LANE_COLORS: Readonly<Record<Lane, ThemeKey>> = {
116  READY: 'success',
117  NEEDS_REBASE: 'error',
118  STACKED: 'warning',
119  IN_PROGRESS: 'suggestion',
120  HOLD: 'merged',
121  CLEANUP: 'inactive',
122}
123
124/**
125 * Lanes folded into one line each, in this order, while the band has too
126 * few rows: the ones that need nobody's action first, the ones waiting on
127 * a rebase last. The ready lane never folds whole: its head stays, in
128 * landing order, and only its tail folds (`bandLinesOf`).
129 */
130const FOLD_ORDER: readonly Lane[] = ['CLEANUP', 'IN_PROGRESS', 'HOLD', 'STACKED', 'NEEDS_REBASE']
131
132/**
133 * From this width on a row shows every column; below it the commits ahead
134 * and the comments go and the lane labels shorten; below the next, the age
135 * and the details go too.
136 */
137export const WIDE_COLUMNS = 64
138export const MEDIUM_COLUMNS = 40
139
140/**
141 * The fixed columns: the rank (` 1 `), the gap after the branch, commits
142 * ahead (`   +3`) and the age of the last commit (`  25m`), the numbers
143 * right-aligned, and the gap before the detail and before a comment.
144 */
145const RANK_CELLS = 3
146const GAP_CELLS = 2
147const AHEAD_CELLS = 5
148const AGE_CELLS = 5
149
150/**
151 * The most of what the fixed columns leave that the branch column may
152 * take, per width: wide, then medium; and the least it takes, so its name
153 * (`BRANCH`) fits.
154 */
155const BRANCH_SHARE = { wide: 0.45, medium: 0.5 } as const
156const BRANCH_MIN_CELLS = 6
157
158/**
159 * With comments shown, the most of what the row leaves after the branch
160 * that the detail column may take, and the least a comment column is worth:
161 * below it, the comments go.
162 */
163const DETAIL_SHARE = 0.6
164const DETAIL_MIN_CELLS = 6
165const COMMENT_MIN_CELLS = 16
166
167/**
168 * The comment column's name, which the header must show where the column
169 * starts: before the controls at the header's end.
170 */
171const COMMENT_NAME = 'COMMENT'
172
173/**
174 * The base branch's color in the status line, by the person's theme
175 * setting. A dark theme gets xterm's orange 208, the one the owner's own
176 * status line names the branch with, so the two agree (6.9:1 on #1e1e1e).
177 * On white 208 reads 2.4:1 (seen live in the light theme, the band's one
178 * color under 4.4:1), so a light theme gets 130, a darker orange (4.7:1).
179 * Where the background is unknown (`auto`, which follows the terminal, a
180 * custom theme, the setting not read), 166 between them: 3.8:1 on white,
181 * 4.4:1 on #1e1e1e. Raw colors: no theme key is an orange that reads on
182 * white (Claude's own `claude` is 3.2:1 there), and a mod cannot learn
183 * which theme `auto` chose.
184 *
185 * @param themeSetting the theme setting, `/config`'s `theme` row
186 * @returns the color
187 */
188export function baseColorOf(themeSetting: string | null): string {
189  if (themeSetting?.startsWith('dark') === true) {
190    return '#ff8700'
191  }
192
193  return themeSetting?.startsWith('light') === true ? '#af5f00' : '#d75f00'
194}
195
196/**
197 * What marks a comment as Claude's words: the mark Claude Code draws its
198 * own lines with (`✻ Crunched for 7s`), in Claude's color.
199 */
200const COMMENT_MARK: Segment = { text: '✻ ', color: 'claude' }
201
202/**
203 * The queue's columns at one width: each one's cells, 0 for a column the
204 * width leaves out. The branch column is as wide as the longest name, up
205 * to its share; the others are fixed, so every row of a drawing lines up.
206 */
207export type TableColumns = {
208  readonly branch: number
209  readonly lane: number
210  readonly labels: Readonly<Record<Lane, string>>
211  readonly ahead: number
212  readonly age: number
213  readonly hasDetail: boolean
214  /**
215   * The detail column's cells when a comment column follows it; 0 when the
216   * detail takes the rest of the row.
217   */
218  readonly detail: number
219  /**
220   * The comment column's cells; 0 when no comment is shown.
221   */
222  readonly comment: number
223}
224
225/**
226 * Sizes the queue's columns to the band and the branches it shows. A
227 * comment column comes only on a wide band, while a row shown has a
228 * comment; the detail column is then as wide as its longest, up to its
229 * share, and the comment takes the rest. The comment column reaches the
230 * row's end, under the header's controls: it is at least wide enough for
231 * its name to start before them, the detail giving up cells for that, and
232 * goes when the detail would be left too few.
233 *
234 * @param columns the cells a row may take
235 * @param names the branches' names, sanitized
236 * @param details the cells each shown branch's detail takes
237 * @param isCommented whether a branch shown has a comment
238 * @param reserved the cells the controls take at the header's end
239 * @returns the columns
240 */
241export function tableColumnsOf(
242  columns: number,
243  names: readonly string[],
244  details: readonly number[] = [],
245  isCommented = false,
246  reserved = 0,
247): TableColumns {
248  const shortLabel = Math.max(...Object.values(SHORT_LANE_LABELS).map(label => label.length))
249  const longest = Math.max(BRANCH_MIN_CELLS, ...names.map(cellWidth))
250  const fit = (left: number, share: number): number => Math.max(Math.min(longest, Math.floor(left * share)), 1)
251
252  if (columns >= WIDE_COLUMNS) {
253    const lane = Math.max(...Object.values(LANE_LABELS).map(label => label.length))
254    const left = columns - RANK_CELLS - GAP_CELLS - lane - AHEAD_CELLS - AGE_CELLS - GAP_CELLS
255
256    const branch = fit(left, BRANCH_SHARE.wide)
257    const rest = left - branch
258    const least = Math.max(COMMENT_MIN_CELLS, reserved + COMMENT_NAME.length)
259    const detail = Math.min(Math.max(DETAIL_MIN_CELLS, ...details), Math.floor(rest * DETAIL_SHARE), rest - GAP_CELLS - least)
260    const comment = rest - detail - GAP_CELLS
261    const isShown = isCommented && detail >= DETAIL_MIN_CELLS && comment >= least
262
263    return {
264      branch,
265      lane,
266      labels: LANE_LABELS,
267      ahead: AHEAD_CELLS,
268      age: AGE_CELLS,
269      hasDetail: true,
270      detail: isShown ? detail : 0,
271      comment: isShown ? comment : 0,
272    }
273  }
274
275  if (columns >= MEDIUM_COLUMNS) {
276    const left = columns - RANK_CELLS - GAP_CELLS - shortLabel - AGE_CELLS - GAP_CELLS
277
278    return {
279      branch: fit(left, BRANCH_SHARE.medium),
280      lane: shortLabel,
281      labels: SHORT_LANE_LABELS,
282      ahead: 0,
283      age: AGE_CELLS,
284      hasDetail: true,
285      detail: 0,
286      comment: 0,
287    }
288  }
289
290  return {
291    branch: Math.max(Math.min(longest, columns - RANK_CELLS - GAP_CELLS - shortLabel), 1),
292    lane: shortLabel,
293    labels: SHORT_LANE_LABELS,
294    ahead: 0,
295    age: 0,
296    hasDetail: false,
297    detail: 0,
298    comment: 0,
299  }
300}
301
302/**
303 * The row naming the queue's columns, aligned with them.
304 *
305 * @param table the columns
306 * @param columns the cells the row may take
307 * @returns the row
308 */
309export function columnHeaderOf(table: TableColumns, columns: number): Line {
310  const name = (text: string): Segment => ({ text, dim: true })
311  const groups: Segment[][] = [
312    [name('#'.padStart(RANK_CELLS - 1).padEnd(RANK_CELLS))],
313    [name(padEnd(truncateEnd('BRANCH', table.branch), table.branch))],
314    [name(' '.repeat(GAP_CELLS)), name(padEnd(truncateEnd('LANE', table.lane), table.lane))],
315  ]
316
317  if (table.ahead > 0) {
318    groups.push([name('AHEAD'.padStart(table.ahead))])
319  }
320
321  if (table.age > 0) {
322    groups.push([name('AGE'.padStart(table.age))])
323  }
324
325  if (table.hasDetail) {
326    groups.push([name(' '.repeat(GAP_CELLS)), name(table.comment > 0 ? padEnd('DETAIL', table.detail) : 'DETAIL')])
327  }
328
329  if (table.comment > 0) {
330    groups.push([name(' '.repeat(GAP_CELLS)), name(COMMENT_NAME)])
331  }
332
333  // A column name is shown whole or not at all, never cut
334  return { key: 'columns', segments: fitWhole(groups, columns) }
335}
336
337/**
338 * One of the header's controls, drawn as its hotkey, a colon and its label
339 * (`h: help`).
340 */
341export type Control = {
342  readonly key: 'help' | 'compact' | 'exit'
343  readonly hotkey: string
344  readonly label: string
345}
346
347/**
348 * Below this width the controls' labels shorten to one character each, so
349 * the header keeps room for the counts.
350 */
351export const SHORT_CONTROLS_BELOW = 90
352
353/**
354 * The header's controls: the help, the compact line and closing the radar,
355 * each labelled for what a press does now.
356 *
357 * @param columns the cells the band's lines take
358 * @param isHelpShown whether the help is shown
359 * @param isCompact whether the queue is folded into one line
360 * @returns the controls, in drawing order
361 */
362export function controlsOf(columns: number, isHelpShown: boolean, isCompact: boolean): Control[] {
363  const isShort = columns < SHORT_CONTROLS_BELOW
364
365  return [
366    { key: 'help', hotkey: 'h', label: isShort ? '?' : isHelpShown ? 'back' : 'help' },
367    { key: 'compact', hotkey: 'c', label: isShort ? (isCompact ? '+' : '-') : isCompact ? 'expand' : 'compact' },
368    { key: 'exit', hotkey: 'x', label: isShort ? '×' : 'exit' },
369  ]
370}
371
372/**
373 * The cells the controls take at the header's end: a gap before them, each
374 * `k: label`, a gap between two.
375 *
376 * @param controls the controls
377 * @returns their width in cells
378 */
379export function controlsCellsOf(controls: readonly Control[]): number {
380  return controls.reduce((sum, control) => sum + 1 + cellWidth(`${control.hotkey}: ${control.label}`), 0)
381}
382
383/**
384 * The cells the header's text may take beside the controls.
385 */
386function headerRoomOf(model: BandModel, columns: number): number {
387  return columns - controlsCellsOf(controlsOf(columns, model.isHelpShown, model.isCompact))
388}
389
390/**
391 * What the frame around the band takes: a border and a cell of padding on
392 * each side, a border row above and below.
393 */
394export const FRAME_CELLS = 4
395export const FRAME_ROWS = 2
396
397/**
398 * Below this width the band drops its frame, so the rows keep the cells.
399 */
400export const FRAME_MIN_COLUMNS = 24
401
402/**
403 * The room the band's lines get inside its frame.
404 */
405export type Frame = {
406  readonly isFramed: boolean
407  /**
408   * The cells each line may take.
409   */
410  readonly columns: number
411  /**
412   * The rows the lines show whole.
413   */
414  readonly maxRows: number
415}
416
417/**
418 * Fits the frame to the band: framed from `FRAME_MIN_COLUMNS` on, the lines
419 * laid out inside the border and its padding.
420 *
421 * @param columns the cells the band's tree is laid out in (`bodyColumns`)
422 * @param maxRows the rows the band shows whole
423 * @returns the frame and the room inside it
424 */
425export function frameOf(columns: number, maxRows: number): Frame {
426  return columns >= FRAME_MIN_COLUMNS
427    ? { isFramed: true, columns: columns - FRAME_CELLS, maxRows: Math.max(maxRows - FRAME_ROWS, 1) }
428    : { isFramed: false, columns, maxRows }
429}
430
431/**
432 * An age as people read it: `42s`, `5m`, `3h`, `2d`.
433 *
434 * @param seconds the age
435 * @returns the age in its largest whole unit
436 */
437export function ageOf(seconds: number): string {
438  for (const [unit, size] of [
439    ['d', 86_400],
440    ['h', 3_600],
441    ['m', 60],
442  ] as const) {
443    if (seconds >= size) {
444      return `${Math.floor(seconds / size)}${unit}`
445    }
446  }
447
448  return `${Math.max(Math.floor(seconds), 0)}s`
449}
450
451/**
452 * The cells a line takes.
453 */
454export function lineWidthOf(line: Line): number {
455  return line.segments.reduce((sum, segment) => sum + cellWidth(segment.text), 0)
456}
457
458/**
459 * Cuts a line's segments at a width, the last one kept ending in `…`.
460 *
461 * @param segments the line's runs, sanitized
462 * @param cells the cells it may take
463 * @returns the runs that fit
464 */
465export function fitSegments(segments: readonly Segment[], cells: number): Segment[] {
466  const out: Segment[] = []
467  let left = cells
468
469  for (const segment of segments) {
470    const width = cellWidth(segment.text)
471
472    if (width <= left) {
473      out.push(segment)
474      left -= width
475
476      continue
477    }
478
479    if (left > 0) {
480      out.push({ ...segment, text: truncateEnd(segment.text, left) })
481    }
482
483    break
484  }
485
486  return out
487}
488
489/**
490 * What the radar reads about a row's branch beside its lane: why it is
491 * there and what comes next, from the facts alone. A caller's words are the
492 * comment's, never here.
493 *
494 * @param branch the branch
495 * @param base the base branch's name
496 * @returns the detail's runs, sanitized
497 */
498export function detailOf(branch: BranchInfo, base: string, ranks: ReadonlyMap<string, number> = new Map()): Segment[] {
499  const parts: Segment[] = []
500  const tree = branch.worktree
501  const name = (text: string): string => sanitize(text)
502  // Another branch in a detail is named with its place in the landing order
503  // when it has one (`#1 feat/x`)
504  const ref = (other: string): string => {
505    const rank = ranks.get(other)
506
507    return rank === undefined ? name(other) : `#${rank} ${name(other)}`
508  }
509
510  switch (branch.lane) {
511    case 'READY':
512      if (branch.dependents.length > 0) {
513        parts.push({ text: `${name(shortList(branch.dependents, 1))} stacked on it` })
514      }
515
516      // Ready already says it merges cleanly: the detail only adds what else
517      if (branch.breaks.length > 0) {
518        parts.push({ text: `forces a rebase of ${shortList(branch.breaks.map(broken => ref(broken.branch)), 1)}` })
519      }
520
521      break
522    case 'NEEDS_REBASE':
523      parts.push({ text: `conflicts: ${name(shortList(branch.conflicts ?? [], 1))}` })
524      parts.push(
525        (branch.waitsFor?.length ?? 0) > 0
526          ? { text: `rebase after ${shortList((branch.waitsFor ?? []).map(ref), 1)}` }
527          : { text: 'rebase due', color: 'error' },
528      )
529      break
530    case 'STACKED':
531      parts.push({ text: `lands after ${ref(branch.stackedOn ?? '')}` })
532      break
533    case 'IN_PROGRESS': {
534      const busy = tree?.sessions.find(session => session.status !== 'idle')
535
536      if (tree?.isRebasing) {
537        parts.push({ text: 'rebasing' })
538      } else if (busy?.kind === 'agent') {
539        // An agent's own name is an id: its task says more, or its session
540        parts.push({
541          text: busy.description ? `agent: ${name(busy.description)}` : busy.parent ? `agent of ${name(busy.parent)}` : `agent ${name(busy.name)}`,
542        })
543      } else if (busy !== undefined) {
544        parts.push({ text: `session ${name(busy.name)} ${name(busy.status)}` })
545      }
546
547      if (tree?.isBeingRemoved) {
548        parts.push({ text: 'worktree being removed' })
549      } else if ((tree?.dirty ?? 0) > 0) {
550        parts.push({ text: `${tree?.dirty} uncommitted` })
551      }
552
553      if (branch.ahead === 0) {
554        parts.push({ text: branch.isLanded ? `landed in ${name(base)}` : 'no commits yet' })
555      }
556
557      break
558    }
559    case 'HOLD':
560      parts.push({ text: branch.hold?.reason ? name(branch.hold.reason) : 'held' })
561      break
562    case 'CLEANUP':
563      if (branch.isLanded || tree === null) {
564        parts.push({ text: branch.isLanded ? `landed in ${name(base)}` : `nothing beyond ${name(base)}` })
565      }
566
567      // Where it is, the snapshot says; here, that there is one to remove
568      if (tree !== null) {
569        parts.push({ text: tree.isBeingRemoved ? 'worktree being removed' : 'has a worktree' })
570      }
571
572      break
573  }
574
575  return parts.flatMap((part, at) => (at === 0 ? [part] : [{ text: ' · ', dim: true }, part]))
576}
577
578/**
579 * A caller's comment on a row: Claude's words, as only the model calls the
580 * radar's tool, marked as Claude Code marks its own lines and quoted, the
581 * quote cut inside its marks to fit.
582 *
583 * @param branch the branch
584 * @param cells the cells the comment may take
585 * @returns the comment's runs, sanitized; none without a comment or room
586 */
587export function commentOf(branch: BranchInfo, cells: number): Segment[] {
588  const marks = cellWidth(COMMENT_MARK.text) + 2
589  const text = branch.comment === null ? '' : sanitize(branch.comment)
590
591  if (text === '' || cells <= marks) {
592    return []
593  }
594
595  return [COMMENT_MARK, { text: `“${truncateEnd(text, cells - marks)}”`, color: 'inactive', italic: true }]
596}
597
598/**
599 * One branch's row.
600 *
601 * @param branch the branch
602 * @param base the base branch's name
603 * @param table the queue's columns
604 * @param columns the cells the row may take
605 * @param nowSeconds now, in seconds since the epoch
606 * @param ranks the landing order's places, by branch
607 * @returns the row
608 */
609export function rowOf(
610  branch: BranchInfo,
611  base: string,
612  table: TableColumns,
613  columns: number,
614  nowSeconds: number,
615  ranks: ReadonlyMap<string, number> = new Map(),
616): Line {
617  // A branch out of the landing order has no place in it: a dim dash
618  const rank = branch.rank === null ? '-' : String(branch.rank)
619  const segments: Segment[] = [
620    { text: rank.padStart(RANK_CELLS - 1).padEnd(RANK_CELLS), bold: branch.rank !== null, dim: branch.rank === null },
621    { text: padEnd(truncateMiddle(sanitize(branch.name), table.branch), table.branch) },
622    { text: ' '.repeat(GAP_CELLS) },
623    { text: padEnd(table.labels[branch.lane], table.lane), color: LANE_COLORS[branch.lane] },
624  ]
625
626  if (table.ahead > 0) {
627    segments.push({ text: (branch.ahead > 0 ? `+${branch.ahead}` : '').padStart(table.ahead) })
628  }
629
630  // The age of a branch with work of its own, beside what it has ahead
631  if (table.age > 0) {
632    segments.push({ text: (branch.ahead > 0 ? ageOf(nowSeconds - branch.lastCommitAt) : '').padStart(table.age) })
633  }
634
635  if (table.hasDetail) {
636    const detail = detailOf(branch, base, ranks)
637
638    segments.push({ text: ' '.repeat(GAP_CELLS) })
639
640    if (table.comment > 0) {
641      const fitted = fitSegments(detail, table.detail)
642
643      segments.push(...fitted, { text: ' '.repeat(table.detail - lineWidthOf({ key: '', segments: fitted }) + GAP_CELLS) })
644      segments.push(...commentOf(branch, table.comment))
645    } else {
646      segments.push(...detail)
647    }
648  }
649
650  return { key: `row:${branch.name}`, segments: fitSegments(segments, columns) }
651}
652
653/**
654 * The line that stands for a folded lane, or for the rest of one whose head
655 * has rows of its own: its label, how many it holds (`+` for the rest),
656 * and their names.
657 *
658 * @param lane the lane
659 * @param branches the branches the line stands for
660 * @param columns the cells it may take
661 * @param isRest whether rows above show the lane's first branches
662 */
663function foldedLineOf(lane: Lane, branches: readonly BranchInfo[], columns: number, isRest = false): Line {
664  return {
665    key: `fold:${lane}`,
666    segments: fitSegments(
667      [
668        { text: '   ' },
669        { text: `${LANE_LABELS[lane]} (${isRest ? '+' : ''}${branches.length}): `, color: LANE_COLORS[lane] },
670        { text: sanitize(branches.map(branch => branch.name).join(', ')), dim: true },
671      ],
672      columns,
673    ),
674  }
675}
676
677/**
678 * Where the radar looks: the repository and the base everything lands on.
679 */
680function placeOf(model: BandModel, snapshot: Snapshot): Segment[] {
681  return [
682    { text: sanitize(nameOf(snapshot.repo || model.root)) },
683    { text: ' ' },
684    { text: `[${sanitize(snapshot.base.name)}]`, color: baseColorOf(model.themeSetting) },
685  ]
686}
687
688/**
689 * What lands next: the branch ranked #1, or that nothing is ready.
690 */
691function nextOf(snapshot: Snapshot): Segment[] {
692  return snapshot.next === null
693    ? [{ text: 'nothing ready to land', dim: true }]
694    : [{ text: 'land next → ', dim: true }, { text: sanitize(snapshot.next), color: 'success', bold: true }]
695}
696
697/**
698 * Joins groups of runs with a dim ` · `, leaving out empty ones.
699 */
700function joined(groups: readonly (readonly Segment[])[]): Segment[] {
701  return groups
702    .filter(group => group.length > 0)
703    .flatMap((group, at) => (at === 0 ? [...group] : [{ text: ' · ', dim: true }, ...group]))
704}
705
706/**
707 * The first of several layouts that fits whole, else the last cut to fit:
708 * a line that gives up its least needed parts first.
709 */
710function firstFitting(layouts: readonly (readonly Segment[])[], cells: number): Segment[] {
711  const fitting = layouts.find(layout => lineWidthOf({ key: '', segments: layout }) <= cells)
712
713  return fitting === undefined ? fitSegments(layouts[layouts.length - 1] ?? [], cells) : [...fitting]
714}
715
716/**
717 * The top line when there is no queue to show: the help's heading, the
718 * read under way, or why there is none; compact, the whole band in a line.
719 */
720function headerOf(model: BandModel, snapshot: Snapshot | null, columns: number): Line {
721  const room = headerRoomOf(model, columns)
722
723  if (model.isHelpShown) {
724    return { key: 'header', segments: fitSegments([{ text: 'Help', bold: true }, { text: ' · what each part of the band means', dim: true }], room) }
725  }
726
727  if (snapshot === null) {
728    const repo = sanitize(nameOf(model.root))
729
730    return {
731      key: 'header',
732      segments: fitSegments(
733        joined([
734          titleOf(),
735          model.problem === null ? [{ text: `reading ${repo}…`, dim: true }] : [{ text: sanitize(model.problem), color: 'error' }],
736        ]),
737        room,
738      ),
739    }
740  }
741
742  // Compact, the band is this line, read as the foot's status line is
743  const failed: Segment[] = model.problem === null ? [] : [{ text: 'last read failed', color: 'error' }]
744
745  return { key: 'header', segments: firstFitting(statusLayoutsOf(model, snapshot, failed), room) }
746}
747
748/**
749 * Keeps whole groups of runs while they fit, in order, and stops at the
750 * first that does not: for lines where a cut piece would read wrong (the
751 * column names, the counts).
752 *
753 * @param groups the groups, each drawn whole or not at all
754 * @param cells the cells they may take
755 * @returns the runs of the groups that fit
756 */
757export function fitWhole(groups: readonly (readonly Segment[])[], cells: number): Segment[] {
758  const out: Segment[] = []
759  let left = cells
760
761  for (const group of groups) {
762    const width = lineWidthOf({ key: '', segments: group })
763
764    if (width > left) {
765      break
766    }
767
768    out.push(...group)
769    left -= width
770  }
771
772  return out
773}
774
775/**
776 * What each lane holds, in lane order: `3 ready`, `1 stacked`; with the
777 * short labels, `2 rebase`, `1 wip`.
778 */
779function countsOf(snapshot: Snapshot, labels: Readonly<Record<Lane, string>> = LANE_LABELS): Segment[] {
780  return (Object.keys(labels) as Lane[]).flatMap((lane, at, lanes) => {
781    const count = snapshot.branches.filter(branch => branch.lane === lane).length
782    const isFirst = lanes.slice(0, at).every(earlier => !snapshot.branches.some(branch => branch.lane === earlier))
783
784    return count === 0
785      ? []
786      : [...(isFirst ? [] : [{ text: ' · ', dim: true }]), { text: `${count} ${labels[lane]}`, color: LANE_COLORS[lane] }]
787  })
788}
789
790/**
791 * The status line's layouts, fullest first: the title, the place, the
792 * counts and what lands next; then the counts in short labels, then without
793 * the title, without the place, without the counts.
794 */
795function statusLayoutsOf(model: BandModel, snapshot: Snapshot, after: readonly Segment[]): Segment[][] {
796  const place = placeOf(model, snapshot)
797  const counts = countsOf(snapshot)
798  const short = countsOf(snapshot, SHORT_LANE_LABELS)
799  const next = nextOf(snapshot)
800
801  return [
802    joined([titleOf(), place, counts, next, after]),
803    joined([titleOf(), place, short, next, after]),
804    joined([place, short, next, after]),
805    joined([short, next, after]),
806    joined([next, after]),
807  ]
808}
809
810/**
811 * Cells between the foot's left part and its messages, at the least, and
812 * the fewest cells a message is shown in.
813 */
814const FOOT_GAP_CELLS = 3
815const FOOT_MESSAGE_MIN_CELLS = 10
816
817/**
818 * How many of the status line's fullest layouts a message may push the
819 * line down through: the long labels and the title, not the place.
820 */
821const MESSAGE_OUTRANKS = 3
822
823/**
824 * The foot, a status line read left to right: the radar, where it looks,
825 * what each lane holds, what lands next. Its right end is for messages: a
826 * caller's line, then what to know (who works in the main worktree and
827 * what is uncommitted there, sessions unknown, a failed read). A narrow band gives up the messages,
828 * then the long lane labels, the title, the place and the
829 * counts, before what lands next.
830 */
831function footOf(model: BandModel, snapshot: Snapshot, columns: number): Line {
832  const layouts = statusLayoutsOf(model, snapshot, [])
833  const messages = joined(messagesOf(model, snapshot).map(message => [message]))
834  const messageCells = lineWidthOf({ key: '', segments: messages })
835  const widthOf = (segments: readonly Segment[]) => lineWidthOf({ key: '', segments })
836  // A message is worth the long labels and the title, never the place, the
837  // counts or what lands next: past those it is cut
838  const roomy = layouts
839    .slice(0, MESSAGE_OUTRANKS)
840    .find(layout => messageCells > 0 && widthOf(layout) + FOOT_GAP_CELLS + messageCells <= columns)
841  const left = roomy ?? firstFitting(layouts, columns)
842  const leftCells = widthOf(left)
843  const room = columns - leftCells - FOOT_GAP_CELLS
844  const shown = room >= FOOT_MESSAGE_MIN_CELLS ? fitSegments(messages, room) : []
845  const shownCells = widthOf(shown)
846
847  return {
848    key: 'foot',
849    segments: shownCells === 0 ? left : [...left, { text: ' '.repeat(columns - leftCells - shownCells) }, ...shown],
850  }
851}
852
853/**
854 * The messages at the foot's right end: a caller's line first, then what
855 * to know.
856 */
857function messagesOf(model: BandModel, snapshot: Snapshot): Segment[] {
858  const dirty = snapshot.base.mainWorktreeDirty ?? 0
859  const sessions = snapshot.base.mainWorktreeSessions
860  const messages: Segment[] = []
861
862  if (model.status !== null && model.status !== '') {
863    messages.push({ text: sanitize(model.status), color: 'remember' })
864  }
865
866  // Who works in the main worktree, then what is uncommitted there: work
867  // that shows on no branch's row
868  const main = [
869    ...(sessions.length === 1 ? [`session ${sanitize(sessions[0]?.name ?? '')}`] : []),
870    ...(sessions.length > 1 ? [`${sessions.length} sessions`] : []),
871    ...(dirty > 0 ? [`${dirty} uncommitted`] : []),
872  ]
873
874  if (main.length > 0) {
875    messages.push({ text: `main worktree: ${main.join(', ')}`, color: 'warning' })
876  }
877
878  if (!snapshot.areSessionsKnown) {
879    messages.push({ text: 'sessions unknown', dim: true })
880  }
881
882  if (model.problem !== null) {
883    messages.push({ text: `last read failed: ${sanitize(model.problem)}`, color: 'error' })
884  }
885
886  return messages
887}
888
889function nameOf(path: string): string {
890  const parts = path.split(/[\\/]/).filter(part => part !== '')
891
892  return parts[parts.length - 1] ?? path
893}
894
895/**
896 * Lays the band out: the header, a row per branch, and the foot, in at most
897 * `maxRows` lines. When rows run short, lanes fold into a line each
898 * (`FOLD_ORDER`), then the ready lane's tail folds behind its head, then
899 * what still does not fit is cut from the bottom: the foot always stays,
900 * its counts naming every lane. Past `maxRows`, Claude Code cuts the band's
901 * bottom itself, and the foot with it.
902 *
903 * @param model what the band shows and the room it has
904 * @returns the lines, each at most `columns` wide
905 */
906export function bandLinesOf(model: BandModel): Line[] {
907  const columns = Math.max(model.columns, 1)
908  const { snapshot } = model
909
910  if (model.isHelpShown) {
911    return [headerOf(model, snapshot, columns), ...helpLinesOf(snapshot?.base.name ?? 'the base', columns)]
912  }
913
914  if (snapshot === null) {
915    return [headerOf(model, null, columns)]
916  }
917
918  const header = headerOf(model, snapshot, columns)
919
920  if (model.isCompact) {
921    return [header]
922  }
923  if (snapshot.branches.length === 0) {
924    return [
925      {
926        key: 'empty',
927        segments: fitSegments([{ text: `no branches besides ${sanitize(snapshot.base.name)}`, dim: true }], headerRoomOf(model, columns)),
928      },
929      footOf(model, snapshot, columns),
930    ]
931  }
932
933  const foot = footOf(model, snapshot, columns)
934
935  const nowSeconds = Math.floor(model.now / 1000)
936  const folded = new Set<Lane>()
937  // The column names and the foot take a row each
938  const room = Math.max(model.maxRows - 2, 1)
939  const rowsWith = (): number =>
940    snapshot.branches.filter(branch => !folded.has(branch.lane)).length +
941    [...folded].filter(lane => snapshot.branches.some(branch => branch.lane === lane)).length
942
943  for (const lane of FOLD_ORDER) {
944    if (rowsWith() <= room) {
945      break
946    }
947
948    // A lane of one branch takes a row either way
949    if (snapshot.branches.filter(branch => branch.lane === lane).length > 1) {
950      folded.add(lane)
951    }
952  }
953
954  // The ready lane keeps its head, in landing order; a tail of two or more
955  // folds into one line after it
956  const ready = snapshot.branches.filter(branch => branch.lane === 'READY')
957  const over = rowsWith() - room
958  const trimmed = over > 0 ? Math.max(ready.length - over - 1, 1) : ready.length
959  const head = ready.length - trimmed >= 2 ? trimmed : ready.length
960  const rest = ready.slice(head)
961
962  const ranks = new Map(snapshot.branches.flatMap(branch => (branch.rank === null ? [] : [[branch.name, branch.rank] as const])))
963  const shown = snapshot.branches.filter(branch => !folded.has(branch.lane) && !rest.includes(branch))
964  const table = tableColumnsOf(
965    columns,
966    shown.map(branch => sanitize(branch.name)),
967    shown.map(branch => lineWidthOf({ key: '', segments: detailOf(branch, snapshot.base.name, ranks) })),
968    shown.some(branch => branch.comment !== null && branch.comment !== ''),
969    columns - headerRoomOf(model, columns),
970  )
971  const body: Line[] = []
972
973  for (const lane of Object.keys(LANE_LABELS) as Lane[]) {
974    const inLane = snapshot.branches.filter(branch => branch.lane === lane)
975
976    if (inLane.length === 0) {
977      continue
978    }
979
980    if (folded.has(lane)) {
981      body.push(foldedLineOf(lane, inLane, columns))
982    } else {
983      body.push(
984        ...inLane.filter(branch => !rest.includes(branch)).map(branch => rowOf(branch, snapshot.base.name, table, columns, nowSeconds, ranks)),
985      )
986
987      if (lane === 'READY' && rest.length > 0) {
988        body.push(foldedLineOf(lane, rest, columns, true))
989      }
990    }
991  }
992
993  // Still too many: the lanes lowest in the order go, the foot stays
994  return [columnHeaderOf(table, headerRoomOf(model, columns)), ...body.slice(0, room), foot]
995}
996
997/**
998 * Breaks text into lines of at most `cells` cells at its spaces; a word
999 * longer than a line is cut.
1000 *
1001 * @param text one paragraph, sanitized
1002 * @param cells the cells a line may take
1003 * @returns the lines
1004 */
1005export function wrapWords(text: string, cells: number): string[] {
1006  const lines: string[] = []
1007  let line = ''
1008
1009  for (const word of text.split(' ').filter(part => part !== '')) {
1010    const next = line === '' ? word : `${line} ${word}`
1011
1012    if (cellWidth(next) <= cells) {
1013      line = next
1014
1015      continue
1016    }
1017
1018    if (line !== '') {
1019      lines.push(line)
1020    }
1021
1022    line = cellWidth(word) <= cells ? word : truncateEnd(word, cells)
1023  }
1024
1025  return line === '' ? lines : [...lines, line]
1026}
1027
1028/**
1029 * One entry of the help: a term in its own style, what it means beside it.
1030 */
1031type HelpEntry = {
1032  /**
1033   * A mark drawn before the term, in its own style (a comment's ✻).
1034   */
1035  readonly mark?: Segment
1036  readonly term: Segment
1037  readonly meaning: string
1038}
1039
1040/**
1041 * Cells the help's term column takes, its gap included.
1042 */
1043const TERM_CELLS = 24
1044
1045/**
1046 * Below this width a meaning goes under its term, not beside it.
1047 */
1048const SIDE_BY_SIDE_COLUMNS = TERM_CELLS + 20
1049
1050/**
1051 * What the lanes, the notes and the controls mean, laid out to the band.
1052 *
1053 * @param base the base branch's name
1054 * @param columns the cells each line may take
1055 * @returns the help's lines, under the header
1056 */
1057export function helpLinesOf(base: string, columns: number): Line[] {
1058  const onto = sanitize(base)
1059  const sections: readonly { readonly title: string; readonly entries: readonly HelpEntry[] }[] = [
1060    {
1061      title: 'Lanes',
1062      entries: (Object.keys(LANE_LABELS) as Lane[]).map(lane => ({
1063        term: { text: LANE_LABELS[lane], color: LANE_COLORS[lane] },
1064        meaning: LANE_MEANINGS[lane].replaceAll('{base}', onto),
1065      })),
1066    },
1067    {
1068      title: 'On a row',
1069      entries: [
1070        {
1071          term: { text: '1 2 3', bold: true },
1072          meaning:
1073            'the order to land the ready branches in: stack parents first, then whichever forces the least rebase work on the others, then whichever finished first. A branch with - in place of a number cannot land yet: its lane and detail say why',
1074        },
1075        { term: { text: '+3' }, meaning: `commits the branch has that ${onto} lacks` },
1076        { term: { text: '5m' }, meaning: 'since its last commit' },
1077        { term: { text: 'rebase due', color: 'error' }, meaning: 'rebase it now: nothing that lands before it still conflicts with it' },
1078        { term: { text: 'rebase after #2 X' }, meaning: 'X lands first and conflicts with it too; a rebase now would have to be done again' },
1079        { term: { text: 'lands after #1 X' }, meaning: 'stacked on X: it lands once X has landed' },
1080        { term: { text: 'forces a rebase of X' }, meaning: 'landing this branch makes X conflict' },
1081        { term: { text: 'X stacked on it' }, meaning: 'X holds this branch: this one lands first' },
1082        { term: { text: `landed in ${onto}` }, meaning: `its work reached ${onto}: through a merge, or a fast-forward its reflog shows` },
1083        {
1084          mark: COMMENT_MARK,
1085          term: { text: '“handed back”', color: 'inactive', italic: true },
1086          meaning: 'a comment: words Claude left on the branch through the radar\'s tool, shown until the branch moves, or, kept, until it lands. The details beside it are the radar\'s own',
1087        },
1088      ],
1089    },
1090    {
1091      title: 'Status line',
1092      entries: [
1093        { term: { text: `repo [${onto}]` }, meaning: `the repository, and the base branch everything lands on` },
1094        { term: { text: '3 ready · 1 stacked' }, meaning: 'how many branches each lane holds' },
1095        { term: { text: 'land next → X' }, meaning: 'the branch ranked #1' },
1096        { term: { text: 'at the right' }, meaning: 'messages: a skill\'s line, uncommitted files in the main worktree, a failed read' },
1097      ],
1098    },
1099    {
1100      title: 'Controls',
1101      entries: [
1102        { term: { text: 'h' }, meaning: 'this help, and back; the band takes keys after ctrl+x tab or a click' },
1103        { term: { text: 'c' }, meaning: 'folds the radar into its status line: the counts, then what lands next' },
1104        { term: { text: 'x' }, meaning: 'exits the radar, as /radar does' },
1105        {
1106          term: { text: '/radar hold <branch>' },
1107          meaning:
1108            'parks a branch. Words after it are the reason, shown on its row: /radar hold feat/x waits on review. It leaves the ready lane and next skips it. Only the radar notes it: the branch and git stay as they are. Every session of this repository on this machine sees the hold until /radar unhold <branch>',
1109        },
1110      ],
1111    },
1112  ]
1113  const isSideBySide = columns >= SIDE_BY_SIDE_COLUMNS
1114  const lines: Line[] = []
1115
1116  sections.forEach((section, at) => {
1117    // An empty row between two sections; a space, so the row keeps its height
1118    if (at > 0) {
1119      lines.push({ key: `help:gap:${section.title}`, segments: [{ text: ' ' }] })
1120    }
1121
1122    lines.push({ key: `help:${section.title}`, segments: fitSegments([{ text: section.title, bold: true }], columns) })
1123
1124    for (const entry of section.entries) {
1125      const key = `help:${section.title}:${entry.term.text}`
1126      const marked: Segment[] = [{ text: '  ' }, ...(entry.mark === undefined ? [] : [entry.mark]), entry.term]
1127      const term = fitSegments(marked, Math.max(columns, 1))
1128
1129      if (isSideBySide) {
1130        const cells = lineWidthOf({ key: '', segments: term })
1131
1132        wrapWords(entry.meaning, columns - TERM_CELLS).forEach((text, at) => {
1133          lines.push({
1134            key: `${key}:${at}`,
1135            segments: fitSegments(
1136              [...(at === 0 ? [...term, { text: ' '.repeat(Math.max(TERM_CELLS - cells, 0)) }] : [{ text: ' '.repeat(TERM_CELLS) }]), { text, dim: true }],
1137              columns,
1138            ),
1139          })
1140        })
1141
1142        continue
1143      }
1144
1145      lines.push({ key, segments: term })
1146      wrapWords(entry.meaning, Math.max(columns - 4, 1)).forEach((text, at) => {
1147        lines.push({ key: `${key}:${at}`, segments: fitSegments([{ text: '    ' }, { text, dim: true }], columns) })
1148      })
1149    }
1150  })
1151
1152  return lines
1153}
1154

1import type { CallerComment, RadarConfig } from '../types'
2
3import { wakeEventsOf } from './changes'
4import type { Host } from './host'
5import Limits from './limits'
6import { clipChars } from './text'
7
8/**
9 * The radar a session left open, kept in the store for its resume. The
10 * session state does not outlive the process, and `/clear`, `/resume` and
11 * `/branch` reset it; the store outlives both.
12 *
13 * One key per session, by its id: `claude --continue`, `claude --resume
14 * <id>` and `/resume` return to a session under its own id, so its key finds
15 * what it left. A new session has a new id and finds nothing.
16 */
17
18/**
19 * The store key prefix of a session's radar; the session's id follows.
20 */
21export const SAVED_KEY_PREFIX = 'resume:'
22
23/**
24 * What a session's radar comes back as: the open radar with its caller's
25 * wake list, the view, and what a caller set. The read is not kept: a
26 * resumed radar reads again. Neither is the help, which is a passing look.
27 */
28export type SavedRadar = {
29  readonly radar: RadarConfig
30  readonly compact: boolean
31  readonly status: string | null
32  readonly comments: Readonly<Record<string, CallerComment>>
33  readonly dueMarks: Readonly<Record<string, string>>
34  /**
35   * When it was saved, in milliseconds since the epoch.
36   */
37  readonly savedAt: number
38}
39
40export function savedKeyOf(sessionId: string): string {
41  return `${SAVED_KEY_PREFIX}${sessionId}`
42}
43
44function fieldsOf(value: unknown): Readonly<Record<string, unknown>> | null {
45  return value !== null && typeof value === 'object' && !Array.isArray(value) ? (value as Record<string, unknown>) : null
46}
47
48function commentsIn(value: unknown): Record<string, CallerComment> {
49  const comments: Record<string, CallerComment> = {}
50
51  for (const [branch, comment] of Object.entries(fieldsOf(value) ?? {})) {
52    const fields = fieldsOf(comment)
53
54    if (fields !== null && typeof fields['sha'] === 'string' && typeof fields['text'] === 'string' && fields['text'] !== '') {
55      comments[branch] = { sha: fields['sha'], text: clipChars(fields['text'], Limits.COMMENT_CHARS), isKept: fields['isKept'] === true }
56    }
57  }
58
59  return comments
60}
61
62function dueMarksIn(value: unknown): Record<string, string> {
63  const marks: Record<string, string> = {}
64
65  for (const [branch, sha] of Object.entries(fieldsOf(value) ?? {})) {
66    if (typeof sha === 'string') {
67      marks[branch] = sha
68    }
69  }
70
71  return marks
72}
73
74/**
75 * The radar a store value holds, each field checked: what the store holds
76 * is untrusted, and a field it lacks takes its default.
77 *
78 * @param value what the store answered
79 * @returns the radar, or null where the value names no folder to watch
80 */
81export function savedRadarIn(value: unknown): SavedRadar | null {
82  const fields = fieldsOf(value)
83  const radar = fieldsOf(fields?.['radar'])
84  const root = radar?.['root']
85  const base = radar?.['base']
86  const status = fields?.['status']
87  const savedAt = fields?.['savedAt']
88
89  if (fields === null || radar === null || typeof root !== 'string' || root === '') {
90    return null
91  }
92
93  return {
94    radar: {
95      root,
96      base: typeof base === 'string' && base !== '' ? base : null,
97      wake: wakeEventsOf(radar['wake']),
98    },
99    compact: fields['compact'] === true,
100    status: typeof status === 'string' && status !== '' ? clipChars(status, Limits.COMMENT_CHARS) : null,
101    comments: commentsIn(fields['comments']),
102    dueMarks: dueMarksIn(fields['dueMarks']),
103    savedAt: typeof savedAt === 'number' && Number.isFinite(savedAt) ? savedAt : 0,
104  }
105}
106
107/**
108 * The keys to drop so that at most `keep` remain: the ones saved longest
109 * ago.
110 *
111 * @param saved each key and when it was saved
112 * @param keep how many to keep
113 * @returns the keys to drop
114 */
115export function droppedKeysOf(saved: readonly { readonly key: string; readonly savedAt: number }[], keep: number): string[] {
116  return [...saved]
117    .sort((a, b) => b.savedAt - a.savedAt || a.key.localeCompare(b.key))
118    .slice(Math.max(keep, 0))
119    .map(entry => entry.key)
120}
121
122/**
123 * The open radar as the session state holds it now.
124 *
125 * @param host the engine's calls
126 * @returns the radar to save, or null while it is closed
127 */
128export async function savedRadarOf(host: Host): Promise<SavedRadar | null> {
129  const [radar, compact, status, comments, dueMarks, savedAt] = await Promise.all([
130    host.state.radar.get(),
131    host.state.compact.get(),
132    host.state.status.get(),
133    host.state.comments.get(),
134    host.state.dueMarks.get(),
135    host.now(),
136  ])
137
138  return radar === null ? null : { radar, compact, status, comments, dueMarks, savedAt }
139}
140
141/**
142 * Saves a session's radar under its id.
143 *
144 * @param host the engine's calls
145 * @param sessionId the session's id
146 * @param saved the radar
147 */
148export async function saveRadar(host: Host, sessionId: string, saved: SavedRadar): Promise<void> {
149  await host.store.set(savedKeyOf(sessionId), saved)
150}
151
152/**
153 * Saves the radar as the session state holds it now, if it is open.
154 *
155 * @param host the engine's calls
156 * @param sessionId the session's id
157 */
158export async function keepRadar(host: Host, sessionId: string): Promise<void> {
159  const saved = await savedRadarOf(host)
160
161  if (saved !== null) {
162    await saveRadar(host, sessionId, saved)
163  }
164}
165
166/**
167 * Drops what a session saved: its radar was closed.
168 */
169export async function forgetRadar(host: Host, sessionId: string): Promise<void> {
170  await host.store.delete(savedKeyOf(sessionId))
171}
172
173/**
174 * The radar a session left open, if any.
175 *
176 * @param host the engine's calls
177 * @param sessionId the session's id
178 * @returns the radar, or null
179 */
180export async function loadRadar(host: Host, sessionId: string): Promise<SavedRadar | null> {
181  return savedRadarIn(await host.store.get(savedKeyOf(sessionId)))
182}
183
184/**
185 * Drops the sessions saved longest ago past `SAVED_SESSIONS`, keeping the
186 * one just saved: every session that ends with the radar open leaves a key,
187 * and most are never resumed.
188 *
189 * Each session's own key keeps sessions from writing over each other. A
190 * drop can still race a session saving the dropped key at that moment: that
191 * session comes back closed, nothing else.
192 *
193 * @param host the engine's calls
194 * @param sessionId the session just saved
195 */
196export async function pruneSaved(host: Host, sessionId: string): Promise<void> {
197  const kept = savedKeyOf(sessionId)
198  const others = (await host.store.keys()).filter(key => key.startsWith(SAVED_KEY_PREFIX) && key !== kept)
199
200  if (others.length < Limits.SAVED_SESSIONS) {
201    return
202  }
203
204  const saved = await Promise.all(
205    others.map(async key => ({ key, savedAt: savedRadarIn(await host.store.get(key))?.savedAt ?? 0 })),
206  )
207
208  for (const dropped of droppedKeysOf(saved, Limits.SAVED_SESSIONS - 1)) {
209    await host.store.delete(dropped)
210  }
211}
212

1import { EMOJI, EMOJI_MODIFIER_BASE, WIDE, ZERO_WIDTH } from './cell-widths'
2
3/**
4 * Characters that never reach the terminal as themselves: C0 and C1
5 * controls (an escape sequence in a file name or a file's text draws as
6 * text), the bidirectional controls Claude Code itself strips (they could
7 * reorder what a name shows) and lone surrogates.
8 */
9const UNSAFE_CHARACTERS = /[\u0000-\u001F\u007F-\u009F\u061C\u202A-\u202E\u2066-\u2069\uD800-\uDFFF]/gu
10
11/**
12 * Combining marks one character keeps: enough for every script, few enough
13 * that a name stacked with thousands of marks cannot pass as one cell.
14 */
15const MAX_MARKS = 8
16
17const MARK_RUN = new RegExp(`([\\p{Mn}\\p{Me}]{${MAX_MARKS}})[\\p{Mn}\\p{Me}]+`, 'gu')
18
19/**
20 * Makes untrusted text safe to draw on one row: a C0 control or DEL becomes
21 * its Control Picture (a tab `␉`, a line feed `␊`, an escape `␛`), any other
22 * unsafe character U+FFFD, and a run of combining marks is cut to
23 * `MAX_MARKS`.
24 *
25 * @param text a file name, or one line of a file with its tabs expanded
26 * @returns the text, safe to draw
27 */
28export function sanitize(text: string): string {
29  return text
30    .replace(UNSAFE_CHARACTERS, char => {
31      const code = char.charCodeAt(0)
32
33      return code < 0x20 ? String.fromCharCode(0x2400 + code) : code === 0x7f ? '\u2421' : '\uFFFD'
34    })
35    .replace(MARK_RUN, '$1')
36}
37
38/**
39 * Whether a code point lies in one of a table's [first, last] pairs.
40 */
41function isIn(table: readonly number[], cp: number): boolean {
42  let lo = 0
43  let hi = table.length / 2
44
45  while (lo < hi) {
46    const mid = (lo + hi) >> 1
47
48    if ((table[mid * 2] ?? 0) <= cp) {
49      lo = mid + 1
50    } else {
51      hi = mid
52    }
53  }
54
55  return lo > 0 && cp <= (table[lo * 2 - 1] ?? -1)
56}
57
58/**
59 * The cells one code point takes on its own: 0, 1 or 2.
60 */
61function codePointWidth(cp: number): number {
62  return isIn(ZERO_WIDTH, cp) ? 0 : isIn(WIDE, cp) ? 2 : 1
63}
64
65/**
66 * Whether a code point can start an emoji cluster: the Emoji property, from
67 * U+203C on and outside U+2C00 – U+1EFFF, as Bun counts it.
68 */
69function isEmojiBase(cp: number): boolean {
70  return cp >= 0x203c && (cp < 0x2c00 || cp >= 0x1f000) && isIn(EMOJI, cp)
71}
72
73const isRegionalIndicator = (cp: number) => cp >= 0x1f1e6 && cp <= 0x1f1ff
74const isSkinTone = (cp: number) => cp >= 0x1f3fb && cp <= 0x1f3ff
75
76const SEGMENTER =
77  typeof Intl.Segmenter === 'function' ? new Intl.Segmenter(undefined, { granularity: 'grapheme' }) : null
78
79const SKIN_TONE = /[\u{1F3FB}-\u{1F3FF}]/u
80
81/**
82 * Splits a grapheme before each skin tone that follows no Emoji_Modifier_Base
83 * (`‼🏽` is two characters), as Bun does and Unicode's current rules do not.
84 */
85function splitSkinTones(grapheme: string): string[] {
86  if (!SKIN_TONE.test(grapheme)) {
87    return [grapheme]
88  }
89
90  const parts: string[] = []
91  let part = ''
92  let previous = -1
93
94  for (const char of grapheme) {
95    const cp = char.codePointAt(0) ?? 0
96
97    if (isSkinTone(cp) && part !== '' && !isIn(EMOJI_MODIFIER_BASE, previous)) {
98      parts.push(part)
99      part = ''
100    }
101
102    part += char
103    previous = cp
104  }
105
106  return [...parts, part]
107}
108
109/**
110 * Splits text into what Claude Code measures as one character: graphemes
111 * by `Intl.Segmenter`, split where Bun breaks and Unicode does not, or code
112 * points where the runtime has no segmenter.
113 */
114function graphemesOf(text: string): string[] {
115  if (SEGMENTER === null) {
116    return Array.from(text)
117  }
118
119  return Array.from(SEGMENTER.segment(text), part => part.segment).flatMap(splitSkinTones)
120}
121
122/**
123 * The cells one grapheme takes, by the rules Claude Code measures with
124 * (Bun's `stringWidth`, East Asian Ambiguous as narrow): a flag, a keycap
125 * and an emoji with a skin tone or a joiner take 2; VS16 widens an emoji to
126 * 2; anything else is the sum of its code points.
127 *
128 * Without `Intl.Segmenter` a grapheme is one code point, and the joiner,
129 * VS16 and the keycap mark count a cell each, so text is never measured
130 * narrower than it draws.
131 */
132function graphemeWidth(grapheme: string): number {
133  const first = grapheme.codePointAt(0) ?? 0
134
135  if (grapheme.length === 1 && first < 0x80) {
136    return first >= 0x20 && first < 0x7f ? 1 : 0
137  }
138
139  if (SEGMENTER === null) {
140    return first === 0x200d || first === 0xfe0f || first === 0x20e3 ? 1 : codePointWidth(first)
141  }
142
143  let count = 0
144  let sum = 0
145  let hasKeycap = false
146  let hasRegional = false
147  let hasSkinTone = false
148  let hasJoiner = false
149  let hasVs15 = false
150  let hasVs16 = false
151
152  for (const char of grapheme) {
153    const cp = char.codePointAt(0) ?? 0
154
155    count += 1
156    sum += codePointWidth(cp)
157    hasKeycap ||= cp === 0x20e3
158    hasRegional ||= isRegionalIndicator(cp)
159    hasSkinTone ||= isSkinTone(cp)
160    hasJoiner ||= cp === 0x200d
161    hasVs15 ||= cp === 0xfe0e
162    hasVs16 ||= cp === 0xfe0f
163  }
164
165  const isEmoji = isEmojiBase(first)
166
167  if (hasRegional && count >= 2) {
168    return 2
169  }
170
171  if (hasKeycap) {
172    return 2
173  }
174
175  if (hasRegional) {
176    return 1
177  }
178
179  if (isEmoji && (hasSkinTone || hasJoiner)) {
180    return 2
181  }
182
183  if (hasVs15 || hasVs16) {
184    const base = codePointWidth(first)
185
186    return base === 2 || (hasVs16 && (isEmoji || first === 0xa9 || first === 0xae)) ? 2 : base
187  }
188
189  return sum
190}
191
192const PRINTABLE_ASCII = /^[\u0020-\u007E]*$/
193
194/**
195 * The terminal cells text takes, as Claude Code measures it: CJK and most
196 * emoji two, combining marks none.
197 *
198 * @param text one line of text, sanitized
199 * @returns its width in cells
200 */
201export function cellWidth(text: string): number {
202  if (PRINTABLE_ASCII.test(text)) {
203    return text.length
204  }
205
206  let width = 0
207
208  for (const grapheme of graphemesOf(text)) {
209    width += graphemeWidth(grapheme)
210  }
211
212  return width
213}
214
215
216/**
217 * Cuts text to a width in cells, keeping its start and end around an
218 * ellipsis; a grapheme is never split.
219 *
220 * @param text one line of text, sanitized
221 * @param cells the cells it may take
222 * @returns the text if it fits, else its start, `…` and its end, at most
223 *   `cells` wide; the start gets the odd cell
224 */
225export function truncateMiddle(text: string, cells: number): string {
226  if (cells <= 0) {
227    return ''
228  }
229
230  if (cellWidth(text) <= cells) {
231    return text
232  }
233
234  if (cells === 1) {
235    return '…'
236  }
237
238  const parts = graphemesOf(text).map(grapheme => ({ grapheme, width: graphemeWidth(grapheme) }))
239  const room = cells - 1
240  let head = 0
241  let headCells = 0
242
243  while (head < parts.length && headCells + (parts[head]?.width ?? 0) <= Math.ceil(room / 2)) {
244    headCells += parts[head]?.width ?? 0
245    head += 1
246  }
247
248  // The end takes what the start left, a cell a wide character did not fit
249  // in included
250  let tail = parts.length
251  let tailCells = 0
252
253  while (tail > head && tailCells + (parts[tail - 1]?.width ?? 0) <= room - headCells) {
254    tailCells += parts[tail - 1]?.width ?? 0
255    tail -= 1
256  }
257
258  const join = (from: number, to: number) =>
259    parts
260      .slice(from, to)
261      .map(part => part.grapheme)
262      .join('')
263
264  return `${join(0, head)}…${join(tail, parts.length)}`
265}
266
267/**
268 * Cuts text to a width in cells, ending it with an ellipsis; a grapheme is
269 * never split.
270 *
271 * @param text one line of text, sanitized
272 * @param cells the cells it may take
273 * @returns the text if it fits, else its start and `…`, at most `cells` wide
274 */
275export function truncateEnd(text: string, cells: number): string {
276  if (cells <= 0) {
277    return ''
278  }
279
280  if (cellWidth(text) <= cells) {
281    return text
282  }
283
284  let kept = ''
285  let used = 0
286
287  for (const grapheme of graphemesOf(text)) {
288    const width = graphemeWidth(grapheme)
289
290    if (used + width > cells - 1) {
291      break
292    }
293
294    kept += grapheme
295    used += width
296  }
297
298  return `${kept}…`
299}
300
301/**
302 * Pads text with spaces to a width in cells, so a row's Button presses
303 * across it.
304 *
305 * @param text one line of text, sanitized
306 * @param cells the width wanted
307 * @returns the text, `cells` wide when it was narrower
308 */
309export function padEnd(text: string, cells: number): string {
310  const width = cellWidth(text)
311
312  return width >= cells ? text : text + ' '.repeat(cells - width)
313}
314
315/**
316 * Caps text at a number of UTF-16 units, ending it with an ellipsis; a
317 * surrogate pair is never split. A size cap for long lines, not a fit to a
318 * row: measuring every line of a large file in cells would cost too much.
319 *
320 * @param text the text
321 * @param max the most UTF-16 units to keep, the ellipsis included
322 * @returns the text, at most `max` units long
323 */
324export function clipChars(text: string, max: number): string {
325  if (text.length <= max) {
326    return text
327  }
328
329  if (max <= 0) {
330    return ''
331  }
332
333  const cut = max - 1
334  const code = text.charCodeAt(cut - 1)
335  const end = cut > 0 && code >= 0xd800 && code <= 0xdbff ? cut - 1 : cut
336
337  return `${text.slice(0, end)}…`
338}
339
340
341/**
342 * A count and its noun: `1 line`, `2 lines`.
343 *
344 * @param count the count
345 * @param noun the noun in the singular
346 * @returns the phrase
347 */
348export function plural(count: number, noun: string): string {
349  return `${count.toLocaleString('en-US')} ${noun}${count === 1 ? '' : 's'}`
350}
351
352/**
353 * An error's message, one short line, safe to draw.
354 *
355 * @param error what was thrown or rejected
356 * @returns the message
357 */
358export function messageOf(error: unknown): string {
359  const message = error instanceof Error ? error.message : String(error)
360
361  return clipChars(sanitize(message.split('\n')[0] ?? ''), 200)
362}
363

1import type { Snapshot, WakeEvent } from '../types'
2
3import { WAKE_EVENTS, wakeEventsOf } from './changes'
4
5/**
6 * The tool the model calls to drive the radar: its description and schema,
7 * the reading of a call's input, and the JSON it answers with.
8 */
9
10export const TOOL_ACTIONS = ['open', 'close', 'snapshot', 'hold', 'unhold', 'comment', 'status'] as const
11
12export type ToolAction = (typeof TOOL_ACTIONS)[number]
13
14export const TOOL_DESCRIPTION = [
15  'Worktree Radar: a live, read-only view of every local branch and worktree of the repository, drawn above the prompt, sorted into lanes on their way into the base branch.',
16  'Lanes: READY (clean worktree, no busy session, merges cleanly; ranked, land #1 first), NEEDS_REBASE (conflicts with the base; isRebaseDue when nothing ahead of it in waitsFor still conflicts with it), STACKED (holds another open branch; land that first), IN_PROGRESS (uncommitted changes, a rebase under way, or a busy Claude session or a running subagent there; worktree.sessions lists both, kind session or agent), HOLD, CLEANUP (nothing beyond the base and no session).',
17  'It never merges, rebases, tags, pushes or moves a ref.',
18  'Actions: open (starts the radar for the session folder and returns the snapshot; `wake` lists events that wake this session with a one-line report, which asks for nothing: ' +
19    WAKE_EVENTS.join(', ') +
20    '), snapshot (reads now and returns the facts as JSON), close, hold/unhold (park a branch, with a reason), comment (a short comment shown on the branch row until its tip moves; with `keep`, until it lands or is gone; empty text clears), status (one line under the queue; empty clears).',
21].join(' ')
22
23export const TOOL_INPUT_SCHEMA = {
24  type: 'object',
25  properties: {
26    action: { type: 'string', enum: [...TOOL_ACTIONS] },
27    base: {
28      type: 'string',
29      description: 'open: the base branch. Detected when left out: origin/HEAD, else main, else master.',
30    },
31    wake: {
32      type: 'array',
33      items: { type: 'string', enum: [...WAKE_EVENTS] },
34      description: 'open: the events that wake this session. None when left out.',
35    },
36    branch: { type: 'string', description: 'hold, unhold, comment: the branch.' },
37    reason: { type: 'string', description: 'hold: why it is held.' },
38    text: { type: 'string', description: "comment: the comment on the branch's current tip; status: the line under the queue. Empty clears." },
39    keep: {
40      type: 'boolean',
41      description: 'comment: true keeps it on the tips that follow, until it is cleared, the branch is gone or it lands.',
42    },
43  },
44  required: ['action'],
45  additionalProperties: false,
46} as const
47
48/**
49 * A call's input, read.
50 */
51export type ToolRequest =
52  | { readonly action: 'open'; readonly base: string | null; readonly wake: WakeEvent[] }
53  | { readonly action: 'close' | 'snapshot' }
54  | { readonly action: 'hold'; readonly branch: string; readonly reason: string }
55  | { readonly action: 'unhold'; readonly branch: string }
56  | { readonly action: 'comment'; readonly branch: string; readonly text: string; readonly keep: boolean }
57  | { readonly action: 'status'; readonly text: string }
58
59function textField(input: Readonly<Record<string, unknown>>, name: string): string | null {
60  const value = input[name]
61
62  return typeof value === 'string' ? value : null
63}
64
65/**
66 * Reads a call's input.
67 *
68 * @param input the call's arguments
69 * @returns the request, or why it cannot be read
70 */
71export function toolRequestOf(input: Readonly<Record<string, unknown>>): ToolRequest | { readonly error: string } {
72  const action = input['action']
73  const branch = textField(input, 'branch')?.trim() ?? ''
74
75  switch (action) {
76    case 'open': {
77      const base = textField(input, 'base')?.trim() ?? ''
78
79      return { action, base: base === '' ? null : base, wake: wakeEventsOf(input['wake']) }
80    }
81    case 'close':
82    case 'snapshot':
83      return { action }
84    case 'hold':
85    case 'unhold':
86    case 'comment':
87      if (branch === '') {
88        return { error: `${action} needs a branch` }
89      }
90
91      return action === 'hold'
92        ? { action, branch, reason: textField(input, 'reason') ?? '' }
93        : action === 'unhold'
94          ? { action, branch }
95          : { action, branch, text: textField(input, 'text') ?? '', keep: input['keep'] === true }
96    case 'status':
97      return { action, text: textField(input, 'text') ?? '' }
98    default:
99      return { error: `action must be one of ${TOOL_ACTIONS.join(', ')}` }
100  }
101}
102
103/**
104 * The snapshot as the tool answers it: every fact but the branches' file
105 * lists, which can run to thousands of paths; `fileCount` stands in.
106 *
107 * @param snapshot the radar's read
108 * @returns the JSON text
109 */
110export function toolJsonOf(snapshot: Snapshot): string {
111  return JSON.stringify({
112    ...snapshot,
113    branches: snapshot.branches.map(({ files, ...branch }) => ({ ...branch, fileCount: files.length })),
114  })
115}
116

1import type { ElementTable, RenderElement } from 'claude-code'
2
3import type { Control, Frame, Line, Segment } from './rows'
4
5/**
6 * The elements the band draws with, from the table `$.ui.resolve(e)` hands
7 * the render hook: the band is raised on the terminal and the desktop.
8 */
9export type Ui = Pick<ElementTable<'terminal' | 'desktop'>, 'Box' | 'Text' | 'Button'>
10
11/**
12 * What the band's controls do, by their keys.
13 */
14export type BandActions = Readonly<Record<Control['key'], () => void>>
15
16/**
17 * The frame's look: rounded, in the color of the prompt's own border, so
18 * the band reads as a panel of Claude Code's.
19 */
20export const FRAME_STYLE = { borderStyle: 'round', borderColor: 'promptBorder', paddingX: 1 } as const
21
22/**
23 * Cells a wide band keeps its text from its sides: the frame's border and
24 * padding. The status line under the frame, and the compact line with no
25 * frame, keep as many, so every line starts where the table's does.
26 */
27const INSET = FRAME_STYLE.paddingX + 1
28
29/**
30 * Draws the band's lines, one row each, with the controls (`h: help`,
31 * `c: compact`, `x: exit`) after the first. On a wide band the lines sit in
32 * a frame and the status line (`foot`) under it, so the two read apart
33 * without a rule between them; compact, the band is its one line with no
34 * frame, an empty row above it keeping it apart from what Claude Code draws
35 * there (the spinner, a tip) as the frame's top edge does. A narrow band has
36 * no frame: the lines follow one another.
37 *
38 * @param ui the surface's elements
39 * @param lines the lines, laid out by `bandLinesOf` for the frame's room
40 * @param columns the cells the band's tree is laid out in, frame included
41 * @param frame the frame, from `frameOf`
42 * @param isCompact whether the band is its compact line
43 * @param controls the first line's controls, from `controlsOf`
44 * @param actions what the controls do
45 * @returns the band's tree
46 */
47export function bandView(
48  ui: Ui,
49  lines: readonly Line[],
50  columns: number,
51  frame: Frame,
52  isCompact: boolean,
53  controls: readonly Control[],
54  actions: BandActions,
55): RenderElement {
56  const { Box, Text, Button } = ui
57  const runs = (segments: readonly Segment[]) =>
58    segments.map((segment, part) => (
59      <Text
60        key={`${part}`}
61        {...(segment.color === undefined ? {} : { color: segment.color })}
62        {...(segment.dim ? { dimColor: true } : {})}
63        {...(segment.bold ? { bold: true } : {})}
64        {...(segment.italic ? { italic: true } : {})}
65      >
66        {segment.text}
67      </Text>
68    ))
69  const rowOf = (line: Line, isFirst: boolean) => (
70    <Box key={line.key} flexDirection="row" width={frame.columns}>
71      <Box flexGrow={1} flexShrink={1}>
72        <Text wrap="truncate-end">{runs(line.segments)}</Text>
73      </Box>
74      {isFirst ? (
75        <Box flexDirection="row" flexShrink={0} columnGap={1} marginLeft={1}>
76          {controls.map(control => (
77            <Button
78              key={control.key}
79              label={control.label}
80              hotkey={control.hotkey}
81              plain
82              dimColor
83              {...(control.key === 'exit' ? { role: 'dismiss' as const } : {})}
84              onPress={actions[control.key]}
85            />
86          ))}
87        </Box>
88      ) : null}
89    </Box>
90  )
91
92  if (!frame.isFramed) {
93    return (
94      <Box flexDirection="column" width={columns} marginTop={isCompact ? 1 : 0}>
95        {lines.map((line, at) => rowOf(line, at === 0))}
96      </Box>
97    )
98  }
99
100  const panel = lines.filter(line => line.key !== 'foot')
101  const foot = lines.find(line => line.key === 'foot')
102
103  return (
104    <Box flexDirection="column" width={columns}>
105      {isCompact ? (
106        <Box key="line" flexDirection="column" width={columns} paddingX={INSET} marginTop={1}>
107          {panel.map((line, at) => rowOf(line, at === 0))}
108        </Box>
109      ) : (
110        <Box key="frame" flexDirection="column" width={columns} {...FRAME_STYLE}>
111          {panel.map((line, at) => rowOf(line, at === 0))}
112        </Box>
113      )}
114      {foot === undefined ? null : (
115        <Box key="status" flexDirection="column" width={columns} paddingX={INSET}>
116          {rowOf(foot, false)}
117        </Box>
118      )}
119    </Box>
120  )
121}
122

1import type { ProcessRunInit, ProcessRunResult } from 'claude-code'
2
3import Limits from './limits'
4
5/**
6 * Every git run the radar makes goes through one `Git`, which `gitOf` binds
7 * to the engine's process call.
8 */
9
10/**
11 * Set over the session's environment for every git run: a read never takes
12 * a lock a commit running beside it needs (so a status never writes the
13 * index), and git speaks plain C, whatever the person's language.
14 */
15export const GIT_ENV: Readonly<Record<string, string>> = { GIT_OPTIONAL_LOCKS: '0', LC_ALL: 'C' }
16
17/**
18 * Runs a program by its argument vector, no shell; resolves once it exits.
19 */
20export type Run = (argv: readonly string[], init: ProcessRunInit) => Promise<ProcessRunResult>
21
22export type GitOptions = {
23  /**
24   * Where git runs; the folder `gitOf` was bound to when left out.
25   */
26  readonly cwd?: string
27  /**
28   * Set over `GIT_ENV`.
29   */
30  readonly env?: Readonly<Record<string, string>>
31  /**
32   * The exit codes that count as an answer; `[0]` when left out.
33   */
34  readonly ok?: readonly number[]
35}
36
37export type GitOutput = {
38  readonly code: number
39  readonly stdout: string
40}
41
42/**
43 * Runs git with its arguments, the command first.
44 *
45 * @returns the exit code and what git wrote, or null where it exited with
46 *   another code, could not start (no git), ran out of time or wrote more
47 *   than the engine reads
48 */
49export type Git = (args: readonly string[], options?: GitOptions) => Promise<GitOutput | null>
50
51/**
52 * Binds git to the engine's process call and a folder.
53 *
54 * @param run the engine's process call
55 * @param cwd the folder git runs in unless a call names another
56 * @returns the git runner
57 */
58export function gitOf(run: Run, cwd: string): Git {
59  return async (args, options = {}) => {
60    try {
61      const result = await run(['git', ...args], {
62        cwd: options.cwd ?? cwd,
63        env: { ...GIT_ENV, ...options.env },
64        timeoutMs: Limits.GIT_TIMEOUT_MS,
65      })
66
67      if (result.isStdoutTruncated || !(options.ok ?? [0]).includes(result.exitCode)) {
68        return null
69      }
70
71      return { code: result.exitCode, stdout: result.stdout }
72    } catch {
73      return null
74    }
75  }
76}
77
78/**
79 * Maps items through an async function, at most `limit` at a time, keeping
80 * their order.
81 *
82 * @param items the inputs
83 * @param limit how many run at once
84 * @param fn the work for one input
85 * @returns the outputs, in the inputs' order
86 */
87export async function mapLimit<T, R>(
88  items: readonly T[],
89  limit: number,
90  fn: (item: T) => Promise<R>,
91): Promise<R[]> {
92  const out: R[] = new Array<R>(items.length)
93  let next = 0
94
95  const worker = async (): Promise<void> => {
96    while (next < items.length) {
97      const at = next
98
99      next += 1
100      out[at] = await fn(items[at] as T)
101    }
102  }
103
104  await Promise.all(Array.from({ length: Math.min(limit, items.length) }, worker))
105
106  return out
107}
108
