image-preview

1import { atom, read, update } from 'claude-code'
2import type { EngineInterface, Register } from 'claude-code'
3
4import type { PastedImage } from '../types'
5import { fitPane, fitRow, imageNumbers, pngSize } from './layout'
6import type { Size } from './layout'
7
8// Pasting an image raises no prompt.edit (the tag only shows up on the next keystroke),
9// so the draft is polled instead.
10const POLL_MS = 200
11
12const images = atom({ plugin: 'image-preview', key: 'images' } as const, [] as PastedImage[])
13// The image number shown enlarged in the pane, or null while the pane is closed.
14const zoomed = atom({ plugin: 'image-preview', key: 'zoomed' } as const, null as number | null)
15
16const PANE = 'image-preview'
17// Rows under the enlarged picture: the label and the buttons.
18const PANE_CHROME_ROWS = 2
19// How to enlarge, drawn right of the tiles; its width is held back from them.
20const HINT = 'zoom: click #N, or ctrl+x tab then 1-9'
21const HINT_COLUMNS = HINT.length + 1
22
23// Where this session's pastes are cached, and where their PNG copies go.
24type Dirs = { sessionId: string; images: string; converted: string }
25
26let tmpRoot: string | undefined
27let found: Dirs | undefined
28// The image numbers last drawn, so an unchanged draft doesn't rewrite state; undefined
29// while a drawn image's file is still missing, so the next poll looks again.
30let shownKey: string | undefined
31let isChecking = false
32const sizes = new Map<string, Size | null>()
33// Cached file -> its PNG copy, or null when no converter could read it.
34const converted = new Map<string, string | null>()
35
36// Claude Code caches each paste as <tmp>/<project>/<session>/images/<n>.<ext>, the extension
37// that of the pasted picture (png, jpg, gif, webp...). The project folder is named after a
38// working directory that may since have moved, so find it by the session id instead of
39// rebuilding it. PNG copies of the other formats go in a sibling folder, <session>/image-preview.
40async function dirs($: EngineInterface): Promise<Dirs | undefined> {
41  const sessionId = await $.session.id()
42  if (found?.sessionId === sessionId) return found
43  if (tmpRoot === undefined) {
44    const fromEnv = await $.env.get('CLAUDE_CODE_TMPDIR')
45    tmpRoot = fromEnv ?? `/tmp/claude-${(await $.process.run(['id', '-u'])).stdout.trim()}`
46  }
47  const entries = await $.fs.list(tmpRoot).catch(() => [])
48  for (const entry of entries) {
49    const session = `${tmpRoot}/${entry.name}/${sessionId}`
50    if (entry.kind === 'dir' && (await $.fs.exists(`${session}/images`))) {
51      found = { sessionId, images: `${session}/images`, converted: `${session}/image-preview` }
52      return found
53    }
54  }
55  return undefined
56}
57
58/** The cached file of image n, whatever its extension, or undefined while there is none. */
59async function cached($: EngineInterface, where: Dirs, n: number): Promise<string | undefined> {
60  const name = new RegExp(`^${n}\\.[A-Za-z0-9]+$`)
61  const entries = await $.fs.list(where.images).catch(() => [])
62  const entry = entries.find(one => one.kind === 'file' && name.test(one.name))
63  return entry === undefined ? undefined : `${where.images}/${entry.name}`
64}
65
66// sips ships with macOS; ImageMagick is the usual tool elsewhere. `[0]` takes a GIF's first frame.
67function converters(src: string, dst: string): string[][] {
68  return [
69    ['sips', '-s', 'format', 'png', src, '--out', dst],
70    ['magick', `${src}[0]`, dst],
71    ['convert', `${src}[0]`, dst],
72  ]
73}
74
75// Only these are handed to a converter: ImageMagick picks its decoder from the file's
76// content, and formats such as SVG, PDF or MVG run delegates, so anything else stays
77// "no preview". A converter that hangs must not stall the poll, hence the timeout.
78const CONVERTIBLE = /\.(jpe?g|gif|webp)$/i
79const CONVERT_TIMEOUT_MS = 10_000
80
81// The Image element draws PNG only, so any other paste is converted once to
82// <session>/image-preview/<n>.png. sips exits 0 even when it can't read the file, and a
83// missing converter rejects, so the copy's existence is what decides.
84async function toPng($: EngineInterface, where: Dirs, n: number, path: string): Promise<string | null> {
85  if (/\.png$/i.test(path)) return path
86  if (!CONVERTIBLE.test(path)) return null
87  const known = converted.get(path)
88  if (known !== undefined) return known
89  const out = `${where.converted}/${n}.png`
90  if (!(await $.fs.exists(out))) {
91    if (!(await $.fs.exists(where.converted))) await $.process.run(['mkdir', '-p', where.converted], { timeoutMs: CONVERT_TIMEOUT_MS }).catch(() => undefined)
92    for (const argv of converters(path, out)) {
93      const ran = await $.process.run(argv, { timeoutMs: CONVERT_TIMEOUT_MS }).catch(() => undefined)
94      if (ran?.exitCode === 0 && (await $.fs.exists(out))) break
95    }
96  }
97  const result = (await $.fs.exists(out)) ? out : null
98  converted.set(path, result)
99  return result
100}
101
102async function describe($: EngineInterface, where: Dirs | undefined, n: number): Promise<PastedImage> {
103  const path = where === undefined ? undefined : await cached($, where, n)
104  if (where === undefined || path === undefined) return { n, path: null, png: null, size: null }
105  const png = await toPng($, where, n, path)
106  if (png === null) return { n, path, png: null, size: null }
107  if (!sizes.has(png)) {
108    const head = await $.fs.read(png, { as: 'bytes' }).then(
109      ({ base64 }) => pngSize(base64),
110      () => undefined, // too big to read: still drawable, just without its aspect ratio
111    )
112    if (head === null) return { n, path, png: null, size: null } // not a PNG after all
113    sizes.set(png, head ?? null)
114  }
115  return { n, path, png, size: sizes.get(png) ?? null }
116}
117
118async function show($: EngineInterface, draft: string) {
119  const numbers = imageNumbers(draft)
120  const key = numbers.join(',')
121  if (key === shownKey) return
122  const where = numbers.length > 0 ? await dirs($) : undefined
123  const list: PastedImage[] = []
124  for (const n of numbers) list.push(await describe($, where, n))
125  shownKey = list.every(image => image.path !== null) ? key : undefined
126  await update($, images, () => list)
127  // The enlarged image left the draft (sent, or its tag deleted): close its pane.
128  const open = await read($, zoomed)
129  if (open !== null && !numbers.includes(open)) await closeZoom($)
130}
131
132// Opens the pane as the press's own first call: anything awaited before $.ui.open loses
133// the press, and the pane then counts as opened unasked (seated only from 144 columns).
134// A pane that still can't be seated falls back to Preview, so a press always shows the picture.
135async function zoom($: EngineInterface, image: PastedImage) {
136  if (image.path === null) return
137  // Nothing to draw in a pane: open the original as it is.
138  if (image.png === null) {
139    await $.process.run(['open', image.path])
140    return
141  }
142  const opened = $.ui.open({ id: PANE, title: `Image #${image.n}`, focus: true, closeOnEscape: true, rows: 30 })
143  await update($, zoomed, () => image.n)
144  const result = await opened.catch(() => undefined)
145  if (result?.isPlaced !== true) {
146    await $.ui.close({ id: PANE })
147    await update($, zoomed, () => null)
148    await $.process.run(['open', image.path])
149  }
150}
151
152async function closeZoom($: EngineInterface) {
153  await update($, zoomed, () => null)
154  await $.ui.close({ id: PANE })
155}
156
157async function check($: EngineInterface) {
158  if (isChecking) return
159  isChecking = true
160  try {
161    await show($, (await $.prompt.read()).text)
162  } finally {
163    isChecking = false
164  }
165}
166
167export const register: Register = on => {
168  on('session.start', async ($, e, next) => {
169    $.clock.every(POLL_MS, () => check($))
170    return next(e)
171  })
172
173  on('ui.render', { component: 'Pane', requestId: PANE }, async ($, e, next) => {
174    // Image is terminal-only; the Desktop app previews pastes itself.
175    if (e.surface !== 'terminal') return next(e)
176    const { Box, Button, Image, Text } = $.ui.resolve(e)
177    const n = await read($, zoomed)
178    const image = (await read($, images)).find(one => one.n === n)
179    if (n === null || image === undefined || image.path === null || image.png === null) {
180      return <Text dimColor>No image to show.</Text>
181    }
182    const { columns, rows } = fitPane(image.size, e.props.scroll.bodyRows - PANE_CHROME_ROWS, e.props.bodyColumns)
183    const path = image.path
184    const size = image.size === null ? '' : `  ${image.size.width}×${image.size.height}`
185    return (
186      <Box flexDirection="column">
187        <Image key={`zoom-${n}`} source={{ file: image.png, format: 'png' }} columns={columns} rows={rows} alt={`[Image #${n}]`} />
188        <Box flexDirection="row" columnGap={2}>
189          <Text dimColor>#{n}{size}</Text>
190          <Button key="preview" hotkey="o" onPress={() => void $.process.run(['open', path])}>Open in Preview</Button>
191          <Button key="close" role="dismiss" hotkey="x" onPress={() => void closeZoom($)}>Close</Button>
192        </Box>
193      </Box>
194    )
195  })
196
197  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
198    if (e.surface !== 'terminal' || e.props.hasSurvey) return next(e)
199    const list = await read($, images)
200    if (list.length === 0) return next(e)
201
202    const { Box, Button, Image, Text } = $.ui.resolve(e)
203    const cells = fitRow(list.map(image => image.size), e.props.maxRows, e.props.bodyColumns - HINT_COLUMNS)
204    const below = await next(e)
205
206    return (
207      <Box flexDirection="column">
208        <Box flexDirection="row" columnGap={1}>
209          {list.map((image, i) => {
210            const { columns, rows } = cells[i] ?? { columns: 4, rows: 1 }
211            return (
212              <Box flexDirection="column" alignItems="center" borderStyle="round" borderDimColor>
213                {image.png === null ? (
214                  <Box width={columns} height={rows} alignItems="center" justifyContent="center">
215                    <Text dimColor wrap="truncate">no preview</Text>
216                  </Box>
217                ) : (
218                  <Image
219                    key={`image-${image.n}`}
220                    source={{ file: image.png, format: 'png' }}
221                    columns={columns}
222                    rows={rows}
223                    alt={`[Image #${image.n}]`}
224                  />
225                )}
226                {image.path === null ? (
227                  <Text dimColor>#{image.n}</Text>
228                ) : (
229                  <Button
230                    key={`zoom-${image.n}`}
231                    plain
232                    dimColor
233                    hotkey={image.n <= 9 ? String(image.n) : undefined}
234                    onPress={() => void zoom($, image)}
235                  >
236                    {`#${image.n}`}
237                  </Button>
238                )}
239              </Box>
240            )
241          })}
242          <Box alignSelf="flex-end">
243            <Text dimColor>{HINT}</Text>
244          </Box>
245        </Box>
246        {below}
247      </Box>
248    )
249  })
250}
251

1export type Size = { width: number; height: number }
2export type Cells = { columns: number; rows: number }
3
4const TILE_ROWS = 6
5const MAX_COLUMNS = 32
6const MIN_COLUMNS = 4
7// A terminal cell is about twice as tall as it is wide.
8const CELL_ASPECT = 2
9// Used when the size is unknown (file over $.fs.read's 4 MiB cap, or no file).
10const FALLBACK: Size = { width: 16, height: 10 }
11// Each tile adds a border on every side and a label row under the picture.
12const TILE_CHROME_ROWS = 3
13const TILE_CHROME_COLUMNS = 2
14const GAP = 1
15
16/** The distinct image numbers a draft references, in the order they first appear. */
17export function imageNumbers(draft: string): number[] {
18  const seen = new Set<number>()
19  for (const match of draft.matchAll(/\[Image #(\d+)\]/g)) seen.add(Number(match[1]))
20  return [...seen]
21}
22
23/** Width and height from a PNG's IHDR chunk, or null when the bytes aren't a PNG. */
24export function pngSize(base64: string): Size | null {
25  // 24 bytes cover the signature and IHDR's width and height; 32 base64 chars decode to exactly 24.
26  const head = Uint8Array.from(atob(base64.slice(0, 32)), char => char.charCodeAt(0))
27  const signature = [0x89, 0x50, 0x4e, 0x47, 0x0d, 0x0a, 0x1a, 0x0a]
28  if (head.length < 24 || signature.some((byte, i) => head[i] !== byte)) return null
29  const view = new DataView(head.buffer, head.byteOffset, head.byteLength)
30  const width = view.getUint32(16)
31  const height = view.getUint32(20)
32  return width > 0 && height > 0 ? { width, height } : null
33}
34
35/** A picture box `rows` tall that keeps the picture's aspect ratio. */
36export function fitCells(size: Size | null, tileRows = TILE_ROWS, maxColumns = MAX_COLUMNS): Cells {
37  const { width, height } = size ?? FALLBACK
38  let rows = tileRows
39  let columns = Math.round((rows * CELL_ASPECT * width) / height)
40  if (columns > maxColumns) {
41    columns = maxColumns
42    rows = Math.max(1, Math.round((maxColumns * height) / (CELL_ASPECT * width)))
43  }
44  return { columns: Math.max(MIN_COLUMNS, columns), rows: Math.min(rows, tileRows) }
45}
46
47/** The enlarged picture: as big as the pane's body allows, aspect kept, within the Image element's 255 cap. */
48export function fitPane(size: Size | null, bodyRows: number, bodyColumns: number): Cells {
49  return fitCells(size, Math.max(1, Math.min(255, bodyRows)), Math.max(MIN_COLUMNS, Math.min(255, bodyColumns)))
50}
51
52/**
53 * Picture boxes for one row of tiles that fits the band whole, so it never scrolls:
54 * the tallest tiles whose chrome fits in `maxRows` and whose total width fits in `bodyColumns`.
55 */
56export function fitRow(sizes: readonly (Size | null)[], maxRows: number, bodyColumns: number): Cells[] {
57  const tallest = Math.max(1, Math.min(TILE_ROWS, maxRows - TILE_CHROME_ROWS))
58  for (let tileRows = tallest; tileRows > 1; tileRows--) {
59    const cells = sizes.map(size => fitCells(size, tileRows))
60    const width = cells.reduce((sum, c) => sum + c.columns + TILE_CHROME_COLUMNS, 0) + GAP * (cells.length - 1)
61    if (width <= bodyColumns) return cells
62  }
63  return sizes.map(size => fitCells(size, 1))
64}
65

1export type PastedImage = {
2  n: number
3  /** The cached paste as Claude Code saved it (.png, .jpg, .gif, .webp...); null when it can't be found. */
4  path: string | null
5  /** A PNG of it for the Image element: `path` itself, or a converted copy; null when no converter could read it. */
6  png: string | null
7  /** Pixel size; null when unknown, and the tile falls back to a default shape. */
8  size: { width: number; height: number } | null
9}
10
11declare module 'claude-code' {
12  interface PluginState {
13    'image-preview': { images: PastedImage[]; zoomed: number | null }
14  }
15}
16
