1import { atom, read, update } from 'claude-code'
2import type { EngineInterface, Register } from 'claude-code'
3
4import type { Exhibit, Tile } from '../types'
5import { applyOutcome, bandCells, isAnimating, isInterruption, isUnfinished, opOf, statsLine, statsOf, wallCells, wallLayout } from './lacquer'
6import type { Stats, WallLayout } from './lacquer'
7
8const tiles = atom({ plugin: 'fault-lacquer', key: 'tiles' } as const, [])
9const band = atom({ plugin: 'fault-lacquer', key: 'band' } as const, true)
10const totals = atom({ plugin: 'fault-lacquer', key: 'totals' } as const, { cracks: 0, repaired: 0 })
11
12const PANE = 'fault-lacquer'
13const BAND_KEY = 'strip'
14const WALL_KEY = 'wall'
15const FRAME_MS = 33
16const GALLERY = 'gallery'
17const GALLERY_MAX = 200
18const TILE_MIN_ROWS = 7
19
20// The animation's own bookkeeping lives in the module: it is cosmetic, and a reload starts it afresh.
21let wall: Tile[] = []
22let frame = 0
23let settled = true
24// The frame clock runs only while something animates.
25let timer: { cancel: () => void } | null = null
26// The newest frame painted, so a slow frame never paints over a newer one.
27let painted = 0
28let bandSite: { requestId: string; columns: number } | null = null
29let paneSite: { requestId: string; layout: WallLayout; maxRows: number } | null = null
30
31/** One animation frame: repaint whatever is mounted while a crack grows or gold sweeps, then go quiet. */
32async function tick($: EngineInterface): Promise<void> {
33  const now = Date.now()
34  const animating = isAnimating(wall, now)
35  if (!animating && settled) {
36    // Nothing moves: stop the clock until the next outcome starts it again.
37    if (timer !== null) timer.cancel()
38    timer = null
39    return
40  }
41  // One more frame after the animation ends, so the resting state is what stays on screen.
42  settled = !animating
43  frame += 1
44  const mine = frame
45  const opts = { now, frame }
46  if (mine < painted) return
47  painted = mine
48  if (bandSite !== null) {
49    const cells = bandCells(wall, bandSite.columns, opts).encode()
50    const res = await $.ui.blit({ requestId: bandSite.requestId, key: BAND_KEY, cells, columns: bandSite.columns, rows: 1 })
51    if (res.deny !== undefined) bandSite = null
52  }
53  if (paneSite !== null) {
54    const layout = paneSite.layout
55    if (wallLayout(wall.length, layout.columns, paneSite.maxRows).rows !== layout.rows) {
56      // More tiles than the mounted Raster holds: a resize is a redraw, not a blit.
57      $.ui.invalidate('ui.render')
58      return
59    }
60    const cells = wallCells(wall, layout, opts).encode()
61    const res = await $.ui.blit({ requestId: paneSite.requestId, key: WALL_KEY, cells, columns: layout.columns, rows: layout.rows })
62    if (res.deny !== undefined) paneSite = null
63  }
64}
65
66/** Starts the frame clock if it is not running; the callback returns its frame, so frames never overlap. */
67function startClock($: EngineInterface): void {
68  if (timer !== null) return
69  timer = $.clock.every(FRAME_MS, () => tick($))
70}
71
72/** The session's stats: every crack and repair counted, and what is broken on the wall now. */
73function sessionStats(list: readonly Tile[], t: { cracks: number; repaired: number }): Stats {
74  return { cracks: t.cracks, repaired: t.repaired, broken: list.filter(x => x.state === 'cracked').length }
75}
76
77/** Adds this session to the lifetime gallery, newest last. */
78async function exhibit($: EngineInterface, list: readonly Tile[]): Promise<void> {
79  const t = await read($, totals)
80  if (t.cracks === 0 && list.length === 0) return
81  const s = sessionStats(list, t)
82  const worst = list.slice().sort((p, q) => q.fails - p.fails)[0]
83  const entry: Exhibit = { at: Date.now(), cracks: s.cracks, repaired: s.repaired, broken: s.broken, worst: worst === undefined ? '' : worst.label }
84  const prior = await $.store.get(GALLERY)
85  const past = Array.isArray(prior) ? (prior as Exhibit[]) : []
86  await $.store.set(GALLERY, [...past, entry].slice(-GALLERY_MAX))
87}
88
89/** The lifetime gallery as one line. */
90async function galleryLine($: EngineInterface): Promise<string> {
91  const prior = await $.store.get(GALLERY)
92  const past = Array.isArray(prior) ? (prior as Exhibit[]) : []
93  if (past.length === 0) return 'Fault Lacquer gallery: no finished sessions yet.'
94  let cracks = 0
95  let repaired = 0
96  for (const x of past) {
97    cracks += x.cracks
98    repaired += x.repaired
99  }
100  const kept = past.length >= GALLERY_MAX ? ` (the last ${GALLERY_MAX})` : ''
101  return `Fault Lacquer gallery: ${past.length} session${past.length === 1 ? '' : 's'}${kept} · ${cracks} crack${cracks === 1 ? '' : 's'} · ${repaired} repaired in gold.`
102}
103
104export const register: Register = on => {
105  on('session.start', async ($, e, next) => {
106    await $.command.register({
107      name: 'kintsugi',
108      description: 'Fault Lacquer: open the kintsugi wall of failed and mended operations',
109      argumentHint: '[band on|off | gallery | clear]',
110      immediate: true,
111    })
112    wall = await read($, tiles)
113    timer = null
114    settled = false
115    startClock($)
116    return next(e)
117  })
118
119  on('session.end', async ($, e, next) => {
120    await exhibit($, await read($, tiles))
121    // A /clear or a resume starts a new session without a session.start: drop the ended wall from screen.
122    wall = []
123    bandSite = null
124    paneSite = null
125    await update($, tiles, () => [])
126    await update($, totals, () => ({ cracks: 0, repaired: 0 }))
127    $.ui.invalidate('ui.render')
128    return next(e)
129  })
130
131  on('command.run', { command: 'kintsugi' }, async ($, e) => {
132    const args = e.args.trim().toLowerCase()
133    if (args === 'band on' || args === 'band off') {
134      await update($, band, () => args === 'band on')
135      return { text: `Fault Lacquer: band ${args === 'band on' ? 'on' : 'off'}.` }
136    }
137    if (args === 'gallery') return { text: await galleryLine($) }
138    if (args === 'clear') {
139      // A clean slate: the wall and this session's crack and repair counts (the gallery keeps past sessions).
140      wall = await update($, tiles, () => [])
141      await update($, totals, () => ({ cracks: 0, repaired: 0 }))
142      return { text: 'Fault Lacquer: the wall is clear.' }
143    }
144    await $.ui.open({ id: PANE, title: 'Kintsugi', rows: 16 })
145    const list = await read($, tiles)
146    const t = await read($, totals)
147    return { text: list.length === 0 && t.cracks === 0 ? 'Fault Lacquer: nothing has broken yet.' : `Fault Lacquer: ${statsLine(sessionStats(list, t))}.` }
148  })
149
150  on('tool.call', async ($, e, next) => {
151    const ran = await next(e)
152    if (ran.deny !== undefined) return ran
153    const op = opOf(e as { tool: string })
154    if (op === null) return ran
155    const result = ran.result as Record<string, unknown> | undefined
156    // A run that never finished in the foreground, or an edit held for review, proves nothing either way.
157    if (e.tool === 'Bash' && isUnfinished(result)) return ran
158    if (result !== undefined && result !== null && typeof result === 'object' && result.staged === true) return ran
159    // A fetch that came back with an HTTP error is a failure even though the tool itself succeeded.
160    const httpFailed = e.tool === 'WebFetch' && typeof result?.code === 'number' && (result.code as number) >= 400
161    const failed = ran.isError === true || httpFailed
162    if (ran.isError === true && isInterruption(String(ran.text ?? (typeof ran.result === 'string' ? ran.result : '')))) return ran
163    const now = Date.now()
164    // Decided against the current wall (update's compare-and-swap), never a snapshot taken before the call ran.
165    let changed = false
166    const next_ = await update($, tiles, cur => {
167      const out = applyOutcome(cur, op, failed, now)
168      changed = out !== cur
169      return out
170    })
171    if (!changed) return ran
172    wall = next_
173    await update($, totals, t => (failed ? { ...t, cracks: t.cracks + 1 } : { ...t, repaired: t.repaired + 1 }))
174    settled = false
175    startClock($)
176    return ran
177  })
178
179  on('ui.render', { component: 'AbovePrompt' }, async ($, e, next) => {
180    if (e.props.hasSurvey) return next(e)
181    const list = await read($, tiles)
182    const isOn = await read($, band)
183    if (!isOn || list.length === 0) {
184      if (bandSite !== null && bandSite.requestId === e.requestId) bandSite = null
185      return next(e)
186    }
187    const t = await read($, totals)
188    // One row here: the mods beneath get the rest of the band.
189    const below = await next({ ...e, props: { ...e.props, maxRows: Math.max(0, e.props.maxRows - 1) } })
190    const { Box, Text } = $.ui.resolve(e)
191    if (e.surface !== 'terminal') {
192      return (
193        <Box flexDirection="column">
194          <Text>◈ kintsugi: {statsLine(sessionStats(list, t))}</Text>
195          {below}
196        </Box>
197      )
198    }
199    const { Raster } = $.ui.resolve(e)
200    const columns = Math.max(20, Math.min(512, e.props.bodyColumns))
201    bandSite = { requestId: e.requestId, columns }
202    const cells = bandCells(list, columns, { now: Date.now(), frame }, sessionStats(list, t)).encode()
203    return (
204      <Box flexDirection="column">
205        <Raster key={BAND_KEY} columns={columns} rows={1} cells={cells} />
206        {below}
207      </Box>
208    )
209  })
210
211  on('ui.render', { component: 'Pane', requestId: PANE }, async ($, e) => {
212    const list = await read($, tiles)
213    const s = sessionStats(list, await read($, totals))
214    const { Box, Text } = $.ui.resolve(e)
215    if (list.length === 0) {
216      paneSite = null
217      return (
218        <Box flexDirection="column">
219          <Text bold>Kintsugi</Text>
220          <Text dimColor>Nothing has broken yet. When an operation fails its tile cracks; the run that fixes it mends the crack in gold.</Text>
221        </Box>
222      )
223    }
224    const broken = list.filter(t => t.state === 'cracked').map(t => t.label)
225    if (e.surface !== 'terminal') {
226      paneSite = null
227      return (
228        <Box flexDirection="column">
229          <Text bold>Kintsugi</Text>
230          <Text>{statsLine(s)}</Text>
231          {list.map(t => (
232            <Text key={t.key}>
233              {t.state === 'gold' ? '◆ mended' : '× broken'} · {t.label} · failed {t.fails}×
234            </Text>
235          ))}
236        </Box>
237      )
238    }
239    const { Raster } = $.ui.resolve(e)
240    // The pane's own body, less the header and the legend lines: never the whole terminal.
241    const bodyRows = e.props.scroll?.bodyRows ?? Math.floor((e.viewport?.rows ?? 40) / 3)
242    const maxRows = Math.max(TILE_MIN_ROWS, bodyRows - 4)
243    const layout = wallLayout(list.length, e.props.bodyColumns, maxRows)
244    paneSite = { requestId: e.requestId, layout, maxRows }
245    const cells = wallCells(list, layout, { now: Date.now(), frame }).encode()
246    return (
247      <Box flexDirection="column">
248        <Text bold color="yellow">
249          ◈ KINTSUGI · {statsLine(s)}
250        </Text>
251        <Raster key={WALL_KEY} columns={layout.columns} rows={layout.rows} cells={cells} />
252        {layout.shown < list.length && <Text dimColor>{list.length - layout.shown} older tiles not shown.</Text>}
253        <Text dimColor>
254          Lacquer tile = an operation that failed. White cracks: still broken. Gold seams: a later run fixed it. × failures ◆ repairs.
255        </Text>
256        {broken.length > 0 && <Text color="red">still broken: {broken.slice(0, 8).join(' · ')}</Text>}
257      </Box>
258    )
259  })
260}
261
262

1import type { Tile } from '../types'
2
3/** The terminal's own colour, as a Raster cell spells it. */
4export const DEFAULT = 0x01000000
5
6export const TILE_COLUMNS = 16
7export const TILE_ROWS = 5 // four art rows and a label row
8export const MAX_TILES = 48
9export const CRACK_MS = 650
10export const SHAKE_MS = 260
11export const GOLD_MS = 1300
12export const SHIMMER_MS = 3200
13export const FLASH_MS = 900
14
15const PORCELAIN = 0xf3efe4
16const PORCELAIN_DIM = 0xb9b4a6
17const GOLD = 0xffcc4d
18const GOLD_DEEP = 0xc9921c
19const GLINT = 0xfff6cf
20const BROKEN_RED = 0xff5d6c
21const LABEL_BG = 0x0b0c26
22const GAP_BG = 0x06061a
23
24// ── Raster plumbing ──────────────────────────────────────────────────────────
25
26/** Standard padded base64, without relying on the environment's encoders. */
27export function base64(bytes: Uint8Array): string {
28  const abc = 'ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/'
29  let out = ''
30  let i = 0
31  for (; i + 2 < bytes.length; i += 3) {
32    const n = ((bytes[i] as number) << 16) | ((bytes[i + 1] as number) << 8) | (bytes[i + 2] as number)
33    out += abc[(n >> 18) & 63]! + abc[(n >> 12) & 63]! + abc[(n >> 6) & 63]! + abc[n & 63]!
34  }
35  const rest = bytes.length - i
36  if (rest === 1) {
37    const n = (bytes[i] as number) << 16
38    out += abc[(n >> 18) & 63]! + abc[(n >> 12) & 63]! + '=='
39  } else if (rest === 2) {
40    const n = ((bytes[i] as number) << 16) | ((bytes[i + 1] as number) << 8)
41    out += abc[(n >> 18) & 63]! + abc[(n >> 12) & 63]! + abc[(n >> 6) & 63]! + '='
42  }
43  return out
44}
45
46export class Grid {
47  readonly cells: Uint32Array
48  constructor(
49    readonly columns: number,
50    readonly rows: number,
51  ) {
52    this.cells = new Uint32Array(columns * rows * 3)
53    for (let i = 0; i < columns * rows; i += 1) {
54      this.cells[i * 3] = 0x20
55      this.cells[i * 3 + 1] = DEFAULT
56      this.cells[i * 3 + 2] = DEFAULT
57    }
58  }
59
60  set(x: number, y: number, code: number, fg: number, bg: number): void {
61    if (x < 0 || y < 0 || x >= this.columns || y >= this.rows) return
62    const i = (y * this.columns + x) * 3
63    this.cells[i] = code
64    this.cells[i + 1] = fg
65    this.cells[i + 2] = bg
66  }
67
68  /** Writes text, one printable width-1 character per cell; anything else becomes '?'. */
69  text(x: number, y: number, text: string, fg: number, bg: number): number {
70    let col = x
71    for (const ch of text) {
72      if (col >= this.columns) break
73      this.set(col, y, safeCode(ch), fg, bg)
74      col += 1
75    }
76    return col
77  }
78
79  encode(): string {
80    const bytes = new Uint8Array(this.cells.length * 4)
81    for (let i = 0; i < this.cells.length; i += 1) {
82      const v = this.cells[i] as number
83      bytes[i * 4] = v & 0xff
84      bytes[i * 4 + 1] = (v >>> 8) & 0xff
85      bytes[i * 4 + 2] = (v >>> 16) & 0xff
86      bytes[i * 4 + 3] = (v >>> 24) & 0xff
87    }
88    return base64(bytes)
89  }
90}
91
92/** A code point the Raster accepts: printable, width 1, in the BMP. Everything else is '?'. */
93export function safeCode(ch: string): number {
94  const c = ch.codePointAt(0) ?? 0x3f
95  // A conservative allowlist of characters every terminal draws in exactly one cell: ASCII,
96  // Latin, Greek and Cyrillic letters (no combining marks), common punctuation, arrows, math,
97  // box drawing, blocks, geometric shapes and braille. Joiners, variation selectors and
98  // everything else draw as "?".
99  const ranges: Array<[number, number]> = [
100    [0x20, 0x7e], [0xa0, 0xac], [0xae, 0x2ff], [0x370, 0x482], [0x48a, 0x52f],
101    [0x2010, 0x2027], [0x2030, 0x205e], [0x20a0, 0x20bf], [0x2100, 0x214f], [0x2190, 0x21ff],
102    [0x2200, 0x22ff], [0x2500, 0x25ff], [0x2800, 0x28ff],
103  ]
104  for (const [lo, hi] of ranges) if (c >= lo && c <= hi) return c
105  return 0x3f
106}
107
108export function rgb(r: number, g: number, b: number): number {
109  const c = (v: number) => Math.max(0, Math.min(255, Math.round(v)))
110  return (c(r) << 16) | (c(g) << 8) | c(b)
111}
112
113function mix(a: number, b: number, t: number): number {
114  const k = Math.max(0, Math.min(1, t))
115  return rgb(
116    ((a >> 16) & 255) * (1 - k) + ((b >> 16) & 255) * k,
117    ((a >> 8) & 255) * (1 - k) + ((b >> 8) & 255) * k,
118    (a & 255) * (1 - k) + (b & 255) * k,
119  )
120}
121
122// ── Operations → tiles ───────────────────────────────────────────────────────
123
124export type Op = { key: string; label: string; tool: string }
125
126function baseName(path: string): string {
127  const parts = path.split('/').filter(p => p.length > 0)
128  return parts[parts.length - 1] ?? path
129}
130
131/** A shell command as a short display label: no leading `cd x &&`, no env assignments, single spaces. Display only: never identity. */
132export function normalizeCommand(command: string): string {
133  let text = command.replace(/\s+/g, ' ').trim()
134  for (let guard = 0; guard < 4; guard += 1) {
135    const cd = /^cd\s+("[^"]*"|'[^']*'|\S+)\s*(&&|;)\s*/.exec(text)
136    if (cd === null) break
137    text = text.slice(cd[0].length)
138  }
139  text = text.replace(/^(?:[A-Za-z_][A-Za-z0-9_]*=(?:"[^"]*"|'[^']*'|\S*)\s+)+/, '')
140  return text
141}
142
143function shorten(text: string, room: number): string {
144  return text.length > room ? `${text.slice(0, room - 1)}…` : text
145}
146
147/** Which tile a tool call belongs to, or null for calls that are not operations worth a tile. */
148export function opOf(e: { tool: string; [k: string]: unknown }): Op | null {
149  const tool = String(e.tool)
150  const file = typeof e.file_path === 'string' ? e.file_path : typeof e.notebook_path === 'string' ? e.notebook_path : undefined
151  if (tool === 'Bash') {
152    // Identity is the exact command: `cd web && npm test` and `cd api && npm test` are different operations,
153    // and whitespace inside quotes matters. The label is the short, normalized form.
154    const exact = String(e.command ?? '').trim()
155    if (exact.length === 0) return null
156    return { key: `Bash:${exact}`, label: shorten(normalizeCommand(exact), TILE_COLUMNS - 2), tool }
157  }
158  if (file !== undefined && file.length > 0) {
159    const verb = tool === 'NotebookEdit' ? 'Nb' : tool
160    return { key: `${tool}:${file}`, label: shorten(`${verb} ${baseName(file)}`, TILE_COLUMNS - 2), tool }
161  }
162  const short = tool.startsWith('mcp__') ? tool.split('__').slice(1).join('/') : tool
163  // The arguments that define the operation: for the built-in lookups their target and scope (a retried
164  // WebFetch with a different prompt is the same fetch); for an MCP tool every plain argument (the issue number).
165  const fields = IDENTITY[tool] ?? (tool.startsWith('mcp__') ? Object.keys(e).filter(k => !IGNORED_ARGS.has(k)) : null)
166  if (fields === null) return null
167  const args = fields
168    .slice()
169    .sort()
170    .map(k => [k, e[k]] as const)
171    .filter(([, v]) => v !== undefined && v !== null && typeof v !== 'object')
172  if (args.length === 0 && !tool.startsWith('mcp__')) return null
173  const target = [e.url, e.pattern, e.query].find(v => typeof v === 'string' && v.length > 0)
174  const shown = typeof target === 'string' ? `${short} ${target}` : short
175  return { key: `${tool}:${JSON.stringify(args)}`, label: shorten(shown, TILE_COLUMNS - 2), tool }
176}
177
178const IDENTITY: Record<string, string[]> = {
179  WebFetch: ['url'],
180  WebSearch: ['query', 'allowed_domains', 'blocked_domains'],
181  Grep: ['pattern', 'path', 'glob', 'type'],
182  Glob: ['pattern', 'path'],
183}
184
185const IGNORED_ARGS = new Set(['tool', 'tool_use_id', 'agentId', 'consent', 'description'])
186
187/**
188 * A result the person or the engine cut short is not a failure of the operation. Only the engine's own
189 * short messages count: a test log that merely contains "interrupted" is a real failure.
190 */
191export function isInterruption(text: string): boolean {
192  const t = text.trim()
193  if (t.length > 300) return false
194  return /^\[?request interrupted by user[^\]]*\]?$|^the user (?:doesn't want|rejected|declined)|request was aborted|aborted before completion|^interrupted\b/i.test(t)
195}
196
197/** A Bash run that never finished in the foreground (backgrounded, timed out, interrupted) proved nothing. */
198export function isUnfinished(result: unknown): boolean {
199  if (result === null || typeof result !== 'object') return false
200  const r = result as Record<string, unknown>
201  return r.interrupted === true || r.backgroundTaskId !== undefined || r.backgroundedByUser === true || r.timedOutAfterMs !== undefined || r.backgroundedByTurnAbort === true
202}
203
204function hashSeed(text: string): number {
205  let h = 2166136261
206  for (let i = 0; i < text.length; i += 1) {
207    h ^= text.charCodeAt(i)
208    h = Math.imul(h, 16777619)
209  }
210  return h >>> 0
211}
212
213/** The wall after one finished operation: a failure cracks (or re-cracks) its tile; a success repairs a cracked one. */
214export function applyOutcome(tiles: readonly Tile[], op: Op, failed: boolean, now: number): Tile[] {
215  const index = tiles.findIndex(t => t.key === op.key)
216  if (index < 0) {
217    if (!failed) return tiles as Tile[]
218    const tile: Tile = { key: op.key, label: op.label, tool: op.tool, fails: 1, repairs: 0, state: 'cracked', seed: hashSeed(op.key), crackedAt: now, repairedAt: 0, lastAt: now }
219    return trim([...tiles, tile])
220  }
221  const was = tiles[index] as Tile
222  let tile: Tile
223  if (failed) tile = { ...was, fails: was.fails + 1, state: 'cracked', crackedAt: now, lastAt: now }
224  else if (was.state === 'cracked') tile = { ...was, repairs: was.repairs + 1, state: 'gold', repairedAt: now, lastAt: now }
225  else return tiles as Tile[]
226  const out = tiles.slice()
227  out[index] = tile
228  return out
229}
230
231/** Keep the wall bounded: drop the oldest repaired tiles first, then the oldest broken ones. */
232function trim(tiles: Tile[]): Tile[] {
233  if (tiles.length <= MAX_TILES) return tiles
234  const out = tiles.slice()
235  while (out.length > MAX_TILES) {
236    let victim = -1
237    for (let i = 0; i < out.length; i += 1) if ((out[i] as Tile).state === 'gold') { victim = i; break }
238    out.splice(victim < 0 ? 0 : victim, 1)
239  }
240  return out
241}
242
243export type Stats = { cracks: number; repaired: number; broken: number }
244
245export function statsOf(tiles: readonly Tile[]): Stats {
246  let cracks = 0
247  let repaired = 0
248  let broken = 0
249  for (const t of tiles) {
250    cracks += t.fails
251    if (t.state === 'gold') repaired += 1
252    else broken += 1
253  }
254  return { cracks, repaired, broken }
255}
256
257export function statsLine(s: Stats): string {
258  const plural = (n: number, word: string) => `${n} ${word}${n === 1 ? '' : 's'}`
259  return `${plural(s.cracks, 'crack')} · ${s.repaired} repaired in gold · ${s.broken} still broken`
260}
261
262/** True while any tile is mid-animation at `now`. */
263export function isAnimating(tiles: readonly Tile[], now: number): boolean {
264  return tiles.some(t => now - t.crackedAt < Math.max(CRACK_MS, FLASH_MS) || (t.state === 'gold' && now - t.repairedAt < GOLD_MS + SHIMMER_MS))
265}
266
267// ── Crack geometry ───────────────────────────────────────────────────────────
268
269function prng(seed: number): () => number {
270  let s = seed >>> 0 || 1
271  return () => {
272    s ^= s << 13
273    s >>>= 0
274    s ^= s >>> 17
275    s ^= s << 5
276    s >>>= 0
277    return s / 4294967296
278  }
279}
280
281export type Point = { x: number; y: number }
282
283/**
284 * The tile's cracks in sub-pixels (2 across and 4 down per cell): from each impact point, a few jagged
285 * branches running out to the edges. One impact per failure, up to three, all from the tile's seed.
286 */
287export function crackPaths(seed: number, fails: number, width: number, height: number): Point[][] {
288  const paths: Point[][] = []
289  const impacts = Math.max(1, Math.min(3, fails))
290  for (let k = 0; k < impacts; k += 1) {
291    const rand = prng(seed + k * 7919)
292    const ox = width * (0.3 + rand() * 0.4)
293    const oy = height * (0.25 + rand() * 0.5)
294    const branches = 3 + Math.floor(rand() * 2)
295    const turn = rand() * Math.PI * 2
296    for (let b = 0; b < branches; b += 1) {
297      let angle = turn + (b / branches) * Math.PI * 2 + (rand() - 0.5) * 0.9
298      let x = ox
299      let y = oy
300      const path: Point[] = [{ x: Math.round(x), y: Math.round(y) }]
301      for (let step = 0; step < 60; step += 1) {
302        angle += (rand() - 0.5) * 0.9
303        x += Math.cos(angle) * 1.6
304        y += Math.sin(angle) * 1.1
305        if (x < 0 || y < 0 || x > width - 1 || y > height - 1) break
306        path.push({ x: Math.round(x), y: Math.round(y) })
307      }
308      paths.push(path)
309    }
310  }
311  return paths
312}
313
314/** Every sub-pixel along a path, in order, with a gap-free line between its points. */
315export function rasterize(path: readonly Point[]): Point[] {
316  const out: Point[] = []
317  for (let i = 0; i < path.length; i += 1) {
318    const a = path[i] as Point
319    if (i === 0) {
320      out.push(a)
321      continue
322    }
323    const p = path[i - 1] as Point
324    let x0 = p.x
325    let y0 = p.y
326    const dx = Math.abs(a.x - x0)
327    const dy = -Math.abs(a.y - y0)
328    const sx = x0 < a.x ? 1 : -1
329    const sy = y0 < a.y ? 1 : -1
330    let err = dx + dy
331    for (let guard = 0; guard < 64; guard += 1) {
332      if (x0 === a.x && y0 === a.y) break
333      const e2 = 2 * err
334      if (e2 >= dy) {
335        err += dy
336        x0 += sx
337      }
338      if (e2 <= dx) {
339        err += dx
340        y0 += sy
341      }
342      out.push({ x: x0, y: y0 })
343    }
344  }
345  return out
346}
347
348const BRAILLE_BITS = [
349  [0x01, 0x08],
350  [0x02, 0x10],
351  [0x04, 0x20],
352  [0x40, 0x80],
353]
354
355// ── Drawing ──────────────────────────────────────────────────────────────────
356
357/** Glossy lacquer: deep indigo with a soft diagonal highlight; a broken tile shows two shard tones. */
358function lacquerBg(cx: number, cy: number, cols: number, rows: number, shard: boolean, warm: boolean): number {
359  const t = (cx / Math.max(1, cols - 1)) * 0.6 + (cy / Math.max(1, rows - 1)) * 0.4
360  let base = mix(0x34389a, 0x0f1036, t)
361  const gloss = Math.abs(cx - cy * 2 - cols * 0.25)
362  if (gloss < 2.2) base = mix(base, 0x7d83e0, 0.35 * (1 - gloss / 2.2))
363  if (shard) base = mix(base, 0x0a0b25, 0.32)
364  if (warm) base = mix(base, 0x3a2a12, 0.12)
365  return base
366}
367
368export type DrawOptions = { now: number; frame: number }
369
370/** One tile at (x0, y0) in grid cells: lacquer, shards, cracks growing or filled with gold, label and counts. */
371export function drawTile(grid: Grid, tile: Tile, x0: number, y0: number, opts: DrawOptions): void {
372  const { now, frame } = opts
373  const artRows = TILE_ROWS - 1
374  const width = TILE_COLUMNS * 2
375  const height = artRows * 4
376  const sinceCrack = now - tile.crackedAt
377  const shake = sinceCrack < SHAKE_MS ? (frame % 2 === 0 ? 1 : -1) : 0
378  const growth = Math.min(1, sinceCrack / CRACK_MS)
379  const gold = tile.state === 'gold'
380  const sinceGold = now - tile.repairedAt
381  const sweep = gold ? Math.min(1, sinceGold / GOLD_MS) : 0
382  const shimmering = gold && sinceGold >= GOLD_MS && sinceGold < GOLD_MS + SHIMMER_MS
383  const paths = crackPaths(tile.seed, tile.fails, width, height)
384
385  // Per sub-pixel: 1 = porcelain crack, 2 = gold seam, 3 = gold glint.
386  const marks = new Uint8Array(width * height)
387  const first = paths[0] ?? []
388  for (const path of paths) {
389    const dots = rasterize(path)
390    const shown = Math.ceil(dots.length * growth)
391    for (let i = 0; i < shown; i += 1) {
392      const d = dots[i] as Point
393      if (d.x < 0 || d.y < 0 || d.x >= width || d.y >= height) continue
394      const along = i / Math.max(1, dots.length - 1)
395      let mark = 1
396      if (gold && along <= sweep) mark = 2
397      if (shimmering) {
398        const phase = ((sinceGold - GOLD_MS) / 900) % 1.6
399        if (Math.abs(along - phase) < 0.08) mark = 3
400      }
401      if (gold && sweep < 1 && Math.abs(along - sweep) < 0.05) mark = 3
402      marks[d.y * width + d.x] = Math.max(marks[d.y * width + d.x] as number, mark)
403    }
404  }
405
406  // Which side of the first crack a cell falls on decides its shard tone.
407  const a = first[0] ?? { x: width / 2, y: height / 2 }
408  const b = first[first.length - 1] ?? { x: width, y: height }
409  for (let cy = 0; cy < artRows; cy += 1) {
410    for (let cx = 0; cx < TILE_COLUMNS; cx += 1) {
411      const px = cx * 2 + 1
412      const py = cy * 4 + 2
413      const side = (b.x - a.x) * (py - a.y) - (b.y - a.y) * (px - a.x) > 0
414      const bg = lacquerBg(cx, cy, TILE_COLUMNS, artRows, side, gold)
415      let bits = 0
416      let best = 0
417      for (let dy = 0; dy < 4; dy += 1) {
418        for (let dx = 0; dx < 2; dx += 1) {
419          const m = marks[(cy * 4 + dy) * width + cx * 2 + dx] as number
420          if (m > 0) {
421            bits |= (BRAILLE_BITS[dy] as number[])[dx] as number
422            best = Math.max(best, m)
423          }
424        }
425      }
426      const fg = best === 3 ? GLINT : best === 2 ? (frame % 20 < 10 || !shimmering ? GOLD : GOLD_DEEP) : growth < 1 ? PORCELAIN : PORCELAIN_DIM
427      grid.set(x0 + cx + shake, y0 + cy, bits === 0 ? 0x20 : 0x2800 + bits, bits === 0 ? DEFAULT : fg, bg)
428    }
429  }
430
431  // Label row: what broke, and how often it broke and was mended.
432  const flash = tile.state === 'cracked' && now - tile.crackedAt < FLASH_MS && frame % 6 < 3
433  const labelBg = flash ? 0x4a0f1c : LABEL_BG
434  for (let cx = 0; cx < TILE_COLUMNS; cx += 1) grid.set(x0 + cx, y0 + artRows, 0x20, DEFAULT, labelBg)
435  const fails = `×${tile.fails}`
436  const mends = tile.repairs > 0 ? ` ◆${tile.repairs}` : ''
437  const start = x0 + TILE_COLUMNS - fails.length - mends.length - 1
438  grid.text(x0 + 1, y0 + artRows, shorten(tile.label, Math.max(1, start - x0 - 2)), gold ? GOLD : PORCELAIN, labelBg)
439  grid.text(start, y0 + artRows, fails, BROKEN_RED, labelBg)
440  if (mends.length > 0) grid.text(start + fails.length, y0 + artRows, mends, GOLD, labelBg)
441}
442
443export type WallLayout = { columns: number; rows: number; perRow: number; shown: number }
444
445/** How a wall of `count` tiles fits `columns` cells across and at most `maxRows` down. */
446export function wallLayout(count: number, columns: number, maxRows: number): WallLayout {
447  const cols = Math.max(TILE_COLUMNS + 2, Math.min(512, columns))
448  const perRow = Math.max(1, Math.floor((cols - 1) / (TILE_COLUMNS + 1)))
449  const fitRows = Math.max(1, Math.floor((Math.min(256, maxRows) - 1) / (TILE_ROWS + 1)))
450  const shown = Math.min(count, perRow * fitRows)
451  const tileRows = Math.max(1, Math.ceil(shown / perRow))
452  return { columns: cols, rows: Math.min(256, tileRows * (TILE_ROWS + 1) + 1), perRow, shown }
453}
454
455/** The full wall: newest tiles first, on a near-black grout. */
456export function wallCells(tiles: readonly Tile[], layout: WallLayout, opts: DrawOptions): Grid {
457  const grid = new Grid(layout.columns, layout.rows)
458  for (let y = 0; y < layout.rows; y += 1) for (let x = 0; x < layout.columns; x += 1) grid.set(x, y, 0x20, DEFAULT, GAP_BG)
459  const order = tiles.slice().sort((p, q) => q.lastAt - p.lastAt).slice(0, layout.shown)
460  order.forEach((tile, i) => {
461    const x = 1 + (i % layout.perRow) * (TILE_COLUMNS + 1)
462    const y = 1 + Math.floor(i / layout.perRow) * (TILE_ROWS + 1)
463    drawTile(grid, tile, x, y, opts)
464  })
465  return grid
466}
467
468/** The band: one row of mini-tiles (broken ones crack-white, mended ones gold), then the tally. */
469export function bandCells(tiles: readonly Tile[], columns: number, opts: DrawOptions, stats?: Stats): Grid {
470  const cols = Math.max(20, Math.min(512, columns))
471  const grid = new Grid(cols, 1)
472  const order = tiles.slice().sort((p, q) => q.lastAt - p.lastAt)
473  const s = stats ?? statsOf(tiles)
474  const tally = ` ◈ ${statsLine(s)}`
475  const room = Math.max(0, Math.floor((cols - tally.length - 1) / 3))
476  let x = 0
477  for (const tile of order.slice(0, room)) {
478    const gold = tile.state === 'gold'
479    const fresh = !gold && opts.now - tile.crackedAt < FLASH_MS && opts.frame % 6 < 3
480    const glint = gold && opts.now - tile.repairedAt < GOLD_MS && opts.frame % 4 < 2
481    const bg = fresh ? 0x5a1222 : gold ? 0x2a2050 : 0x1d1f5c
482    const fg = gold ? (glint ? GLINT : GOLD) : PORCELAIN
483    grid.set(x, 0, gold ? 0x2871 : 0x2847, fg, bg) // ⡱ ⡇
484    grid.set(x + 1, 0, gold ? 0x288e : 0x28b8, fg, bg) // ⢎ ⢸
485    x += 3
486  }
487  if (order.length > room && room > 0) grid.text(Math.max(0, x - 1), 0, '…', PORCELAIN_DIM, DEFAULT)
488  grid.text(x, 0, tally, s.broken > 0 ? PORCELAIN : GOLD, DEFAULT)
489  return grid
490}
491

1/** One operation's tile on the wall. It exists from the operation's first failure on. */
2export type Tile = {
3  key: string
4  label: string
5  tool: string
6  fails: number
7  repairs: number
8  state: 'cracked' | 'gold'
9  seed: number
10  crackedAt: number
11  repairedAt: number
12  lastAt: number
13}
14
15/** One finished session, as the lifetime gallery keeps it. */
16export type Exhibit = { at: number; cracks: number; repaired: number; broken: number; worst: string }
17
18declare module 'claude-code' {
19  interface PluginState {
20    'fault-lacquer': {
21      tiles: Tile[]
22      band: boolean
23      // Every crack and repair this session, kept apart from the bounded wall (which drops old tiles).
24      totals: { cracks: number; repaired: number }
25    }
26  }
27}
28
