bureau

1// bureau: the session's agents in Le Bureau des agents (devlikemasta/bureau-des-agents, MIT), in a side pane. Its
2// pixel-art office and its engine run here unchanged, on a canvas of our own; instead of the agents of a mission the
3// Bureau would start itself, they play this session: Max is Claude, and each subagent Claude calls walks in through
4// the door, works at a desk of its trade, hands its report in and leaves. Nothing runs, nothing is billed: the
5// office only watches.
6
7import { atom, read, update } from 'claude-code'
8import type { EngineInterface, Register } from 'claude-code'
9
10import { Office } from './office'
11import { renderPane } from './view'
12
13const PANE = 'bureau'
14/** The engine's own clock: its walks and timers advance in small steps. */
15const TICK_MS = 125
16/** A frame (drawn and encoded, about 50 ms) at most this often while something moves, */
17const MOVE_FRAME_MS = 300
18/** and once a second when the office is still, so it keeps blinking and twinkling. */
19const IDLE_MS = 1000
20
21const frameAtom = atom({ plugin: 'bureau', key: 'frame' } as const, 0)
22
23const COMMANDS = [
24  { name: 'bureau', description: "Ouvre le Bureau des agents dans un panneau" },
25  { name: 'bureau-auto', description: 'Ouvre le bureau tout seul quand Claude appelle un agent, ou plus' },
26] as const
27
28// Module state: the office lives here, rebuilt empty on a reload.
29const office = new Office()
30let isPaneOpen = false
31let lastStep = 0
32let lastFrame = 0
33
34async function openPane($: EngineInterface): Promise<boolean> {
35  const r = await $.ui.open({ id: PANE, title: 'Bureau' })
36  isPaneOpen = true
37  return r.isPlaced
38}
39
40/** Something happened in the office: the pane's list says so now, not at the next tick. */
41async function poke($: EngineInterface) {
42  if (isPaneOpen) await update($, frameAtom, n => n + 1)
43}
44
45/** The engine moves on; the pane redraws while something moves, and once a second otherwise. */
46async function tick($: EngineInterface) {
47  const now = await $.clock.now()
48  const dt = lastStep ? (now - lastStep) / 1000 : 0
49  lastStep = now
50  const isMoving = office.step(dt)
51  if (!isPaneOpen) return
52  if (now - lastFrame >= (isMoving ? MOVE_FRAME_MS : IDLE_MS)) {
53    lastFrame = now
54    await update($, frameAtom, n => n + 1)
55  }
56}
57
58export const register: Register = on => {
59  on('session.start', async ($, e, next) => {
60    for (const c of COMMANDS) await $.command.register(c)
61    isPaneOpen = (await $.ui.panes()).some(p => p.id === PANE)
62    $.clock.every(TICK_MS, () => void tick($).catch(() => undefined))
63    return next(e)
64  })
65
66  // ── Max: the main conversation ─────────────────────────────────────────
67
68  on('turn.start', async ($, e, next) => {
69    office.turnStart(e.text)
70    await poke($)
71    return next(e)
72  })
73
74  on('turn.complete', async ($, e, next) => {
75    const result = await next(e)
76    const now = await $.clock.now()
77    if (e.agentId === undefined) office.turnEnd(e.reason !== 'error', e.durationMs)
78    else office.leave(e.agentId, e.reason !== 'error', now)
79    await poke($)
80    return result
81  })
82
83  on('tool.call', async ($, e, next) => {
84    const input = e as unknown as Record<string, unknown>
85    office.act(e.tool, input, e.tool_use_id, e.agentId)
86    await poke($)
87    if (e.agentId === undefined && e.tool === 'AskUserQuestion') {
88      office.ask(e.tool_use_id)
89      const ran = await next(e)
90      office.answered(e.tool_use_id)
91      return ran
92    }
93    return next(e)
94  })
95
96  // ── A subagent: a teammate walks in ────────────────────────────────────
97
98  on('agent.spawn', async ($, e, next) => {
99    const r = await next(e)
100    if (r.deny !== undefined || !r.agentId) return r
101    office.hire(r.agentId, e.subagentType, e.description, e.prompt, await $.clock.now())
102    if (!isPaneOpen && (await $.store.get('isAuto')) !== false) await openPane($).catch(() => undefined)
103    await poke($)
104    return r
105  })
106
107  // /clear starts a new conversation: the office empties and Max goes back to the door.
108  on('session.end', async ($, e, next) => {
109    const result = await next(e)
110    if (e.reason === 'clear') office.reset()
111    await poke($)
112    return result
113  })
114
115  // ── Commands and the pane ──────────────────────────────────────────────
116
117  on('command.run', { command: 'bureau' }, async $ => {
118    const isPlaced = await openPane($)
119    return { text: isPlaced ? 'Bureau ouvert.' : 'Bureau ouvert ; élargis la fenêtre pour le voir.' }
120  })
121
122  on('command.run', { command: 'bureau-auto' }, async $ => {
123    const isAuto = (await $.store.get('isAuto')) === false
124    await $.store.set('isAuto', isAuto)
125    return { text: isAuto ? 'Le bureau s’ouvre tout seul quand Claude appelle un agent.' : 'Le bureau ne s’ouvre plus qu’avec /bureau.' }
126  })
127
128  on('ui.close', async ($, e, next) => {
129    const result = await next(e)
130    if (e.id === PANE) isPaneOpen = false
131    return result
132  })
133
134  on('ui.render', { component: 'Pane', requestId: PANE }, async ($, e) => {
135    await read($, frameAtom)
136    const now = await $.clock.now()
137    const png = office.frame(new Date(now))
138    return renderPane($.ui.resolve(e) as Parameters<typeof renderPane>[0], e.surface, office, png, e.props.bodyColumns, now)
139  })
140}
141

1// The office: Le Bureau des agents' own world and renderer (hooks/engine, unchanged but for the canvas they draw on),
2// fed with this session's events instead of the events of a `claude -p` the Bureau would run itself. Max is the
3// main conversation; each subagent is a teammate hired for its trade, who walks in, works, hands in its report
4// and leaves. A frame is the engine's 352 × 256 image, encoded as a PNG.
5
6import { describeAct, NAMES } from './engine/activity'
7import { H, W } from './engine/layout'
8import { makeCanvas } from './engine/pixels'
9import type { ActKind, OfficeEvent, PlanItem, Role } from './engine/protocol'
10import { Renderer } from './engine/render'
11import type { TimeOfDay } from './engine/room'
12import { World } from './engine/world'
13import { base64, encodePng } from './png'
14
15export { H, W }
16
17/** The trade of a subagent, from the agent type Claude called it as. */
18export function roleOf(type: string): Role {
19  const t = type.toLowerCase()
20  if (/explor|research|search|find|scout|guide|cherch/.test(t)) return 'recherche'
21  if (/design|frontend|\bui\b|ux|visual|animat/.test(t)) return 'design'
22  if (/review|test|code|refactor|devops|secur|implement|debug|fix|build|migrat|develop/.test(t)) return 'code'
23  if (/doc|writ|spec|copy|content|redac/.test(t)) return 'redaction'
24  if (/plan|analy|data|observ|metric|estimat|audit|rag/.test(t)) return 'analyse'
25  return 'renfort'
26}
27
28export const timeOfDay = (hour: number): TimeOfDay => (hour >= 8 && hour < 18 ? 'day' : hour >= 18 && hour < 21 ? 'evening' : 'night')
29
30/** What the pane lists under the picture: who is in, what they do right now. */
31export type Member = {
32  id: string
33  name: string
34  role: Role
35  task: string
36  label: string
37  startedAt: number
38  endedAt: number | null
39  ok: boolean | null
40}
41
42export class Office {
43  world = new World()
44  private renderer = new Renderer()
45  private canvas = makeCanvas(W, H)
46  private g = this.canvas.getContext('2d')
47  /** The lead's bubble; null between turns. */
48  leadLabel: string | null = null
49  members = new Map<string, Member>()
50  stats = { agents: 0, searches: 0, pages: 0, reads: 0, writes: 0, commands: 0 }
51
52  private apply(ev: OfficeEvent) {
53    this.world.apply(ev, true)
54  }
55
56  private count(kind: ActKind) {
57    const s = this.stats
58    if (kind === 'search') s.searches++
59    else if (kind === 'web') s.pages++
60    else if (kind === 'read') s.reads++
61    else if (kind === 'write' || kind === 'edit') s.writes++
62    else if (kind === 'bash') s.commands++
63  }
64
65  /** A turn of the main conversation starts: Max sits down to it. */
66  turnStart(text: string) {
67    if (!this.world.missionActive) this.apply({ k: 'start', text })
68    this.apply({ k: 'think', who: 'chef' })
69    this.leadLabel = 'Réfléchit'
70  }
71
72  /** A turn of the main conversation ends; with nobody still at work, Max goes back to the door to greet you. */
73  turnEnd(ok: boolean, ms: number) {
74    this.leadLabel = null
75    const busy = [...this.members.values()].some(m => m.endedAt === null)
76    if (!busy) this.apply({ k: 'end', ok, text: '', ms })
77  }
78
79  /** A tool call, by Max (`who` absent) or by a teammate. */
80  act(tool: string, input: Record<string, unknown>, callId: string, who?: string) {
81    const d = describeAct(tool, input)
82    this.count(d.kind)
83    const id = who ?? 'chef'
84    if (!who) {
85      this.leadLabel = d.label
86      const todos = input['todos']
87      if (tool === 'TodoWrite' && Array.isArray(todos)) {
88        const items: PlanItem[] = todos
89          .filter((x): x is Record<string, unknown> => Boolean(x) && typeof x === 'object')
90          .map(x => ({ text: String(x['content'] ?? ''), status: x['status'] === 'completed' ? 'completed' : x['status'] === 'in_progress' ? 'in_progress' : 'pending' }))
91        this.apply({ k: 'plan', items })
92      }
93    } else {
94      const m = this.members.get(who)
95      if (!m) return
96      m.label = d.label
97    }
98    this.apply({ k: 'act', who: id, id: callId, kind: d.kind, tool, label: d.label, detail: d.detail })
99  }
100
101  /** Max asks you something: a hand goes up until you answer. */
102  ask(callId: string) {
103    this.leadLabel = 'Te pose une question'
104    this.apply({ k: 'ask', who: 'chef', requestId: callId, tool: 'AskUserQuestion', label: '', detail: '', full: false })
105  }
106  answered(callId: string) {
107    this.apply({ k: 'ask_done', requestId: callId, allow: true })
108  }
109
110  /** A subagent starts: a teammate of its trade comes in through the door. */
111  hire(id: string, type: string, task: string, prompt: string, now: number) {
112    if (this.members.has(id)) return
113    const role = roleOf(type)
114    const taken = new Set([...this.world.actors.values()].map(a => a.name))
115    const pool = NAMES[role]
116    const name = pool.find(n => !taken.has(n)) ?? `${pool[0]} ${taken.size}`
117    this.members.set(id, { id, name, role, task, label: 'Arrive', startedAt: now, endedAt: null, ok: null })
118    this.stats.agents++
119    this.apply({ k: 'hire', id, role, type, name, task, prompt })
120  }
121
122  /** A subagent's run ended: its report goes on Max's desk, then it leaves. */
123  leave(id: string, ok: boolean, now: number) {
124    const m = this.members.get(id)
125    if (!m || m.endedAt !== null) return
126    m.endedAt = now
127    m.ok = ok
128    m.label = ok ? 'Rend son rapport' : 'A échoué'
129    this.apply({ k: 'leave', who: id, ok, tokens: 0, tools: 0, ms: now - m.startedAt })
130  }
131
132  /** Moves the world on by `dt` seconds; true while something moves. Forgets teammates who have walked out. */
133  step(dt: number): boolean {
134    const moving = this.world.update(dt)
135    for (const [id, m] of this.members) if (m.endedAt !== null && !this.world.actors.has(id)) this.members.delete(id)
136    return moving
137  }
138
139  reset() {
140    this.world.resetAll()
141    this.members.clear()
142    this.leadLabel = null
143    this.stats = { agents: 0, searches: 0, pages: 0, reads: 0, writes: 0, commands: 0 }
144  }
145
146  /** The office as it stands, a PNG in base64. */
147  frame(now: Date): string {
148    this.renderer.draw(this.g, this.world, timeOfDay(now.getHours()), now)
149    return base64(encodePng(this.canvas.data, W, H))
150  }
151}
152

1// The pane: a header row, the office as a picture (an SVG holding the frame's PNG on the desktop, the PNG itself on
2// a terminal that shows pictures), a line per agent with its bubble, and the session's counts. Host elements and
3// theme colours for the text, as the other mods draw.
4
5import type { Elements, RenderElement, RenderSurface } from 'claude-code'
6
7import { ROLES } from './engine/activity'
8import { H, W, type Member, type Office } from './office'
9
10type TermEls = Elements['terminal']
11type DeskEls = Elements['desktop']
12
13const NAME_W = 9
14const ROLE_W = 15
15const MAX_PX = 704
16
17const clock = (ms: number) => {
18  const s = Math.max(0, Math.floor(ms / 1000))
19  return `${Math.floor(s / 60)}:${String(s % 60).padStart(2, '0')}`
20}
21
22function summary(o: Office): string {
23  const team = [...o.members.values()]
24  const working = team.filter(m => m.endedAt === null).length
25  const parts = [o.leadLabel === null ? 'Max t’attend' : 'Max au travail']
26  if (working) parts.push(`${working} agent${working > 1 ? 's' : ''} au travail`)
27  return parts.join(' · ')
28}
29
30export function renderPane(E: TermEls, surface: RenderSurface, o: Office, png: string, columns: number, now: number): RenderElement {
31  const { Box, Text } = E
32  const alt = summary(o)
33  let picture: RenderElement
34  if (surface === 'terminal') {
35    // a picture where the terminal can show one (kitty, Ghostty), its alt elsewhere; cells are about twice as tall as wide
36    const cols = Math.max(20, Math.min(columns, 88))
37    picture = <E.Image key="office" source={{ png }} columns={cols} rows={Math.round((cols * H) / W / 2)} alt={`${alt} (le bureau s’affiche dans un terminal qui montre les images : kitty, Ghostty)`} />
38  } else {
39    const Svg = (E as unknown as DeskEls).Svg
40    const width = Math.max(W, Math.min(MAX_PX, columns * 8))
41    const height = Math.round((width * H) / W)
42    const source =
43      `<svg xmlns="http://www.w3.org/2000/svg" width="${width}" height="${height}" viewBox="0 0 ${W} ${H}">` +
45    picture = <Svg key="office" source={source} alt={alt} width={width} height={height} />
46  }
47
48  const row = (key: string, dot: 'claude' | 'warning' | 'success' | 'error' | 'inactive', name: string, role: string, what: string, time: string) => (
49    <Box key={key} flexDirection="row" columnGap={1}>
50      <Text color={dot}>●</Text>
51      <Box width={NAME_W} flexShrink={0}>
52        <Text wrap="truncate-end">{name}</Text>
53      </Box>
54      <Box width={ROLE_W} flexShrink={0}>
55        <Text dimColor wrap="truncate-end">
56          {role}
57        </Text>
58      </Box>
59      <Box flexGrow={1} flexShrink={1} minWidth={0}>
60        <Text wrap="truncate-end">{what}</Text>
61      </Box>
62      {time ? <Text dimColor>{time}</Text> : null}
63    </Box>
64  )
65  const memberRow = (m: Member) =>
66    row(
67      m.id,
68      m.endedAt === null ? 'claude' : m.ok ? 'success' : 'error',
69      m.name,
70      ROLES[m.role].label,
71      m.endedAt === null ? m.label : `${m.label} · ${m.task}`,
72      clock((m.endedAt ?? now) - m.startedAt),
73    )
74  const s = o.stats
75  const counts = [
76    `${s.agents} agent${s.agents > 1 ? 's' : ''}`,
77    `${s.searches} recherches`,
78    `${s.pages} pages`,
79    `${s.reads} lectures`,
80    `${s.writes} écritures`,
81    `${s.commands} commandes`,
82  ].join(' · ')
83
84  return (
85    <Box key="bureau" flexDirection="column" rowGap={1}>
86      <Box flexDirection="column">
87        <Text wrap="truncate-end">
88          <Text color="claude">▣ </Text>
89          <Text bold>Bureau</Text>
90          <Text dimColor>{` · ${alt}`}</Text>
91        </Text>
92        {picture}
93      </Box>
94      <Box flexDirection="column">
95        {row('chef', o.leadLabel === null ? 'inactive' : 'claude', 'Max', 'Claude, chef', o.leadLabel ?? 'Attend ton prochain message', '')}
96        {[...o.members.values()].map(memberRow)}
97        <Text dimColor wrap="truncate-end">
98          {counts}
99        </Text>
100      </Box>
101    </Box>
102  )
103}
104

1// Les métiers du bureau, et la traduction en français de ce que fait vraiment chaque agent :
2// chaque outil de Claude Code devient une action (une icône, une animation, une bulle).
3import type { ActKind, MissionStats, OfficeEvent, Role } from './protocol';
4
5export interface RoleInfo {
6  /** le nom du métier, tel qu'il s'affiche dans le bureau */
7  label: string;
8  icon: string;
9  color: string;
10  /** l'agent Claude Code (subagent_type) qui fait ce métier */
11  type: string;
12  what: string;
13}
14
15export const ROLES: Record<Role, RoleInfo> = {
16  chef: { label: 'Chef de projet', icon: '⭐', color: '#FF8A3D', type: '', what: 'Il reçoit ta demande, fait le plan, répartit le travail et assemble le rendu.' },
17  recherche: { label: 'Recherche', icon: '🔎', color: '#4FB3FF', type: 'chercheur', what: 'Cherche sur internet : concurrents, prix, avis, actualités, sources.' },
18  code: { label: 'Code', icon: '💻', color: '#3DDC97', type: 'developpeur', what: 'Code, sites, scripts, automatisations : ce qui se lance et se teste.' },
19  design: { label: 'Design', icon: '🎨', color: '#FF6FA8', type: 'designer', what: 'Pages web soignées, maquettes, visuels, mise en forme.' },
20  redaction: { label: 'Rédaction', icon: '✍️', color: '#A98BFF', type: 'redacteur', what: 'Posts, e-mails, articles, scripts vidéo, rapports.' },
21  analyse: { label: 'Analyse', icon: '📊', color: '#FFC93D', type: 'analyste', what: 'Chiffres, tableaux, fichiers, comparatifs, calculs.' },
22  renfort: { label: 'Renfort', icon: '🤖', color: '#9AA3B5', type: '', what: 'Un coup de main sur une tâche à part.' },
23};
24
25/** Les outils Claude Code de chaque métier (le chef a tous ceux de la séance). */
26export const ROLE_TOOLS: Record<Role, string[]> = {
27  chef: ['Agent', 'TodoWrite', 'Read', 'Write', 'Edit', 'Glob', 'Grep', 'WebSearch', 'WebFetch', 'Bash'],
28  recherche: ['WebSearch', 'WebFetch', 'Read', 'Glob', 'Grep'],
29  code: ['Read', 'Write', 'Edit', 'Glob', 'Grep', 'Bash', 'WebFetch'],
30  design: ['Read', 'Write', 'Edit', 'Glob', 'Grep', 'WebFetch'],
31  redaction: ['Read', 'Write', 'Edit', 'Glob', 'Grep'],
32  analyse: ['Read', 'Write', 'Edit', 'Glob', 'Grep', 'Bash'],
33  renfort: [],
34};
35
36/** Ce que veut dire chaque outil, en français (pour la fiche des métiers). */
37export const TOOL_INFO: Record<string, string> = {
38  Agent: 'appelle un membre de l’équipe', TodoWrite: 'écrit et coche le plan', Read: 'lit un fichier', Write: 'crée un fichier',
39  Edit: 'retouche un fichier', Glob: 'cherche des fichiers', Grep: 'cherche dans les fichiers', WebSearch: 'cherche sur internet',
40  WebFetch: 'lit une page web', Bash: 'lance une commande',
41};
42
43/** Le métier d'un agent, d'après le type d'agent que le chef a appelé. */
44export function roleOfType(type: string): Role {
45  for (const [role, info] of Object.entries(ROLES) as [Role, RoleInfo][]) if (info.type && info.type === type) return role;
46  return 'renfort';
47}
48
49/** Les prénoms des robots, par métier (jamais deux fois le même dans une mission). */
50export const NAMES: Record<Role, string[]> = {
51  chef: ['Max'],
52  recherche: ['Iris', 'Hugo', 'Léa', 'Malo', 'Zoé', 'Noé', 'Inès', 'Tom', 'Jade', 'Sacha', 'Lou', 'Nils'],
53  code: ['Ada', 'Linus', 'Grace', 'Alan', 'Margaret', 'Dennis'],
54  design: ['Frida', 'Coco', 'Henri', 'Sonia', 'Saul'],
55  redaction: ['Colette', 'Victor', 'Simone', 'Jules', 'George'],
56  analyse: ['Marie', 'Blaise', 'Émilie', 'Gaspard', 'Ada'],
57  renfort: ['Bob', 'Lulu', 'Gaston', 'Nina', 'Momo', 'Kiki'],
58};
59
60const base = (p: unknown) => (typeof p === 'string' ? p.split(/[\\/]/).filter(Boolean).pop() ?? p : '');
61export const cut = (s: unknown, n = 60) => {
62  const t = String(s ?? '').replace(/\s+/g, ' ').trim();
63  return t.length > n ? t.slice(0, n - 1) + '…' : t;
64};
65export const host = (u: unknown) => {
66  try { return new URL(String(u)).hostname.replace(/^www\./, ''); } catch { return cut(u, 40); }
67};
68
69const MCP_NAMES: Record<string, string> = {
70  gmail: 'Gmail', google_drive: 'Google Drive', notion: 'Notion', google_calendar: 'Google Agenda', calendar: 'Google Agenda',
71  slack: 'Slack', github: 'GitHub', stripe: 'Stripe', hubspot: 'HubSpot', airtable: 'Airtable',
72};
73
74/** Le nom lisible d'un connecteur MCP : mcp__claude_ai_Gmail__search_threads → Gmail */
75export function mcpName(tool: string): { server: string; action: string } {
76  const parts = tool.split('__');
77  const raw = (parts[1] ?? '').replace(/^claude_ai_/, '').replace(/^plugin_[^_]+_/, '');
78  const server = MCP_NAMES[raw.toLowerCase()] ?? raw.replace(/[_-]+/g, ' ').replace(/\b\w/g, (c) => c.toUpperCase());
79  return { server, action: (parts[2] ?? '').replace(/[_-]+/g, ' ') };
80}
81
82/** L'action, sa phrase (courte, pour la bulle) et le détail complet (pour le panneau). */
83export function describeAct(tool: string, input: Record<string, unknown> | undefined): { kind: ActKind; label: string; detail: string } {
84  const i = input ?? {};
85  switch (tool) {
86    case 'WebSearch': return { kind: 'search', label: `Je cherche « ${cut(i.query, 44)} »`, detail: String(i.query ?? '') };
87    case 'WebFetch': return { kind: 'web', label: `Je lis ${host(i.url)}`, detail: String(i.url ?? '') };
88    case 'Read': return { kind: 'read', label: `Je lis ${cut(base(i.file_path), 36)}`, detail: String(i.file_path ?? '') };
89    case 'Glob': return { kind: 'read', label: 'Je fouille le dossier', detail: String(i.pattern ?? '') };
90    case 'Grep': return { kind: 'read', label: `Je cherche « ${cut(i.pattern, 30)} »`, detail: `${i.pattern ?? ''}${i.path ? ' dans ' + i.path : ''}` };
91    case 'LS': return { kind: 'read', label: 'Je regarde le dossier', detail: String(i.path ?? '') };
92    case 'Write': return { kind: 'write', label: `J’écris ${cut(base(i.file_path), 36)}`, detail: String(i.file_path ?? '') };
93    case 'Edit':
94    case 'MultiEdit': return { kind: 'edit', label: `Je retouche ${cut(base(i.file_path), 34)}`, detail: String(i.file_path ?? '') };
95    case 'NotebookEdit': return { kind: 'edit', label: `Je retouche ${cut(base(i.notebook_path), 34)}`, detail: String(i.notebook_path ?? '') };
96    case 'Bash': {
97      const c = String(i.command ?? '').replace(/\s+/g, ' ').trim();
98      return { kind: 'bash', label: `Je lance ${c.length <= 34 ? `« ${c} »` : cut(i.description || c, 40)}`, detail: String(i.command ?? '') };
99    }
100    case 'TodoWrite': return { kind: 'plan', label: 'Je mets le plan à jour', detail: '' };
101    case 'Skill': return { kind: 'skill', label: `J’applique la méthode ${cut(i.skill ?? i.name, 24)}`, detail: String(i.args ?? '') };
102    case 'ToolSearch': return { kind: 'other', label: 'Je cherche le bon outil', detail: String(i.query ?? '') };
103  }
104  if (tool.startsWith('mcp__')) {
105    const { server, action } = mcpName(tool);
106    return { kind: 'mcp', label: `Je passe par ${server}`, detail: action };
107  }
108  return { kind: 'other', label: `J’utilise ${tool}`, detail: '' };
109}
110
111export const emptyStats = (): MissionStats => ({ agents: 0, searches: 0, pages: 0, reads: 0, writes: 0, commands: 0 });
112
113/** Les compteurs de la mission (recherches, pages lues…), mis à jour événement par événement. */
114export function countStats(s: MissionStats, ev: OfficeEvent) {
115  if (ev.k === 'hire') s.agents++;
116  if (ev.k !== 'act') return;
117  if (ev.kind === 'search') s.searches++;
118  else if (ev.kind === 'web') s.pages++;
119  else if (ev.kind === 'read') s.reads++;
120  else if (ev.kind === 'write' || ev.kind === 'edit') s.writes++;
121  else if (ev.kind === 'bash') s.commands++;
122}
123
124/** Remplace le chemin du dossier de la mission par « . » partout où il apparaît en entier. */
125export function relToFolder(text: string, folder: string): string {
126  if (!folder) return text;
127  const esc = folder.replace(/[.*+?^${}()|[\]\\]/g, '\\$&');
128  return text.replace(new RegExp(esc + '(?=$|[/"\'\\s])', 'g'), '.').replace(/(^|[\s"'])\.\//g, '$1');
129}
130
131/** La commande telle qu'elle sera lancée, juste rendue lisible (le dossier de la mission devient « . »). Rien n'est caché. */
132export function readableCommand(cmd: unknown, folder: string): string {
133  return relToFolder(String(cmd ?? ''), folder).trim().replace(/^cd\s+(?:"\."|'\.'|\.)\s*&&\s*/, '');
134}
135
136const FULL_MAX = 72;
137
138/**
139 * La demande de permission : la phrase de la bulle, le détail complet, et `full`
140 * (vrai seulement si la bulle montre toute l'action : on peut alors répondre directement dans la bulle).
141 */
142export function permissionText(tool: string, input: Record<string, unknown> | undefined, folder: string): { label: string; detail: string; full: boolean } {
143  const i = input ?? {};
144  if (tool === 'Bash') {
145    const c = readableCommand(i.command, folder);
146    const full = c.length > 0 && c.length <= FULL_MAX && !c.includes('\n');
147    return { label: `Je peux lancer « ${full ? c : cut(c, 48)} » ?`, detail: c, full };
148  }
149  if (tool === 'Write' || tool === 'Edit' || tool === 'MultiEdit' || tool === 'NotebookEdit') {
150    const raw = String(i.file_path ?? i.notebook_path ?? '');
151    const rel = relToFolder(raw, folder);
152    const inside = !!folder && raw.startsWith(folder + '/') && !rel.includes('..');
153    return { label: `Je peux ${tool === 'Write' ? 'écrire' : 'modifier'} ${inside ? rel : raw} ?`, detail: raw, full: inside && rel.length <= FULL_MAX };
154  }
155  if (tool === 'WebFetch') return { label: `Je peux lire ${host(i.url)} ?`, detail: String(i.url ?? ''), full: false };
156  const detail = relToFolder(JSON.stringify(i, null, 2), folder);
157  const clipped = detail.length > 1500 ? detail.slice(0, 1499) + '…' : detail;
158  if (tool.startsWith('mcp__')) {
159    const { server, action } = mcpName(tool);
160    return { label: `Je peux passer par ${server} (${action}) ?`, detail: clipped, full: false };
161  }
162  return { label: `Je peux utiliser ${tool} ?`, detail: clipped, full: false };
163}
164

1// Le plan du bureau : une grille de 22 × 16 cases de 16 pixels, vue de dessus (en 3/4, comme dans
2// les jeux en pixel art). Chaque métier a son coin, ses bureaux et ses chaises ; Max est au centre,
3// devant le tableau du plan ; la porte est en bas, c'est par là qu'arrive l'équipe.
4import type { Role } from './protocol';
5
6export const T = 16;
7export const COLS = 22;
8export const ROWS = 16;
9export const W = COLS * T;
10export const H = ROWS * T;
11
12export type FurnKind =
13  | 'desk' | 'chefDesk' | 'chair' | 'chefChair' | 'plantBig' | 'plantTall' | 'plantSmall' | 'rack' | 'printer'
14  | 'cooler' | 'coffee' | 'sofa' | 'tableLow' | 'shelf' | 'lamp' | 'easel' | 'bin' | 'jukebox';
15
16export interface Furn {
17  id: string;
18  kind: FurnKind;
19  /** case en haut à gauche de l'emprise au sol */
20  tx: number;
21  ty: number;
22  /** emprise au sol, en cases (bloque le passage) */
23  w: number;
24  h: number;
25  role?: Role;
26  seed?: number;
27}
28
29export interface Seat {
30  id: string;
31  role: Role;
32  /** la case où le robot s'arrête avant de s'asseoir */
33  tile: [number, number];
34  /** les pieds du robot une fois assis (en pixels) */
35  x: number;
36  y: number;
37  deskId: string;
38}
39
40export interface Zone { role: Role; label: string; x: number; y: number; w: number; h: number }
41
42/** Les coins du bureau (le tapis au sol et l'étiquette). */
43export const ZONES: Zone[] = [
44  { role: 'recherche', label: 'Recherche', x: 1, y: 3, w: 6, h: 6 },
45  { role: 'code', label: 'Atelier code', x: 15, y: 3, w: 6, h: 3 },
46  { role: 'design', label: 'Studio design', x: 15, y: 6, w: 6, h: 3 },
47  { role: 'redaction', label: 'Rédaction', x: 1, y: 10, w: 6, h: 3 },
48  { role: 'analyse', label: 'Analyse', x: 15, y: 10, w: 4, h: 3 },
49  { role: 'chef', label: 'Max, chef de projet', x: 9, y: 6, w: 4, h: 3 },
50];
51
52const furn: Furn[] = [];
53const seats: Seat[] = [];
54
55function desk(role: Role, tx: number, ty: number) {
56  const id = `desk-${role}-${tx}-${ty}`;
57  furn.push({ id, kind: 'desk', tx, ty, w: 2, h: 1, role, seed: tx * 31 + ty });
58  furn.push({ id: `chair-${id}`, kind: 'chair', tx, ty: ty - 1, w: 0, h: 0, role });
59  seats.push({ id: `seat-${id}`, role, tile: [tx, ty - 1], x: (tx + 1) * T, y: ty * T - 1, deskId: id });
60}
61
62// Recherche : deux rangées de trois bureaux (c'est le coin le plus demandé, un chercheur par sujet)
63for (const ty of [5, 8]) for (const tx of [1, 3, 5]) desk('recherche', tx, ty);
64// Atelier code
65for (const tx of [15, 17, 19]) desk('code', tx, 5);
66// Studio design
67for (const tx of [15, 17]) desk('design', tx, 8);
68// Rédaction
69for (const tx of [1, 3, 5]) desk('redaction', tx, 12);
70// Analyse
71for (const tx of [15, 17]) desk('analyse', tx, 12);
72
73// Le bureau du chef, face à toi
74furn.push({ id: 'chefDesk', kind: 'chefDesk', tx: 9, ty: 7, w: 4, h: 1, role: 'chef' });
75furn.push({ id: 'chefChair', kind: 'chefChair', tx: 10, ty: 6, w: 0, h: 0, role: 'chef' });
76export const CHEF_SEAT: Seat = { id: 'seat-chef', role: 'chef', tile: [10, 6], x: 11 * T, y: 7 * T - 1, deskId: 'chefDesk' };
77
78// Le matériel et la déco
79furn.push({ id: 'rack', kind: 'rack', tx: 14, ty: 3, w: 1, h: 1 });
80furn.push({ id: 'printer', kind: 'printer', tx: 12, ty: 4, w: 1, h: 1 });
81furn.push({ id: 'cooler', kind: 'cooler', tx: 9, ty: 4, w: 1, h: 1 });
82furn.push({ id: 'easel', kind: 'easel', tx: 19, ty: 8, w: 1, h: 1 });
83furn.push({ id: 'plant-design', kind: 'plantBig', tx: 20, ty: 8, w: 1, h: 1, seed: 3 });
84furn.push({ id: 'plant-entry-l', kind: 'plantTall', tx: 8, ty: 14, w: 1, h: 1, seed: 5 });
85furn.push({ id: 'plant-entry-r', kind: 'plantBig', tx: 13, ty: 14, w: 1, h: 1, seed: 9 });
86furn.push({ id: 'plant-analyse', kind: 'plantTall', tx: 20, ty: 11, w: 1, h: 1, seed: 11 });
87furn.push({ id: 'sofa', kind: 'sofa', tx: 2, ty: 14, w: 3, h: 1 });
88furn.push({ id: 'tableLow', kind: 'tableLow', tx: 2, ty: 13, w: 2, h: 0 });
89furn.push({ id: 'lamp', kind: 'lamp', tx: 1, ty: 14, w: 1, h: 1 });
90furn.push({ id: 'shelf', kind: 'shelf', tx: 5, ty: 14, w: 2, h: 1 });
91furn.push({ id: 'coffee', kind: 'coffee', tx: 16, ty: 14, w: 3, h: 1 });
92furn.push({ id: 'jukebox', kind: 'jukebox', tx: 14, ty: 14, w: 2, h: 1 });
93furn.push({ id: 'plant-coffee', kind: 'plantBig', tx: 19, ty: 14, w: 1, h: 1, seed: 21 });
94furn.push({ id: 'lamp-r', kind: 'lamp', tx: 20, ty: 14, w: 1, h: 1 });
95furn.push({ id: 'bin', kind: 'bin', tx: 7, ty: 12, w: 0, h: 0 });
96
97export const FURNITURE = furn;
98export const SEATS = seats;
99
100/** Les points de passage importants. Les pieds d'un robot debout sur une case : (x*16+8, y*16+13). */
101export const SPOTS = {
102  door: [10, 15] as [number, number],
103  doorOut: { x: 11 * T, y: 16 * T + 6 },
104  /** là où Max t'accueille, et où il te présente le rendu */
105  reception: [10, 12] as [number, number],
106  receptionPx: { x: 11 * T, y: 12 * T + 13 },
107  /** devant le tableau du plan */
108  board: [10, 3] as [number, number],
109  boardPx: { x: 11 * T, y: 3 * T + 13 },
110  /** devant le bureau du chef : on y rend son rapport */
111  deliver: [[10, 8], [11, 8], [9, 8], [12, 8], [10, 9], [11, 9]] as [number, number][],
112  /** pour ceux qui n'ont pas de bureau libre */
113  overflow: [[7, 4], [8, 7], [13, 6], [7, 10], [14, 10], [8, 11], [13, 11], [7, 13]] as [number, number][],
114};
115
116/** Le tableau du plan, accroché au mur du fond (en pixels). */
117export const BOARD = { x: 128, y: 7, w: 96, h: 35 };
118export const WINDOWS = [{ x: 22, y: 8, w: 66, h: 32 }, { x: 264, y: 8, w: 66, h: 32 }];
119export const NEON = { x: 97, y: 11 };
120export const CLOCK = { x: 232, y: 13 };
121export const POSTER = { x: 252, y: 12, w: 10, h: 14 };
122export const DOOR = { x: 160, y: 228, w: 32, h: 28 };
123
124/** La grille des cases où l'on peut marcher. */
125export function walkGrid(): boolean[][] {
126  const g: boolean[][] = [];
127  for (let y = 0; y < ROWS; y++) {
128    g.push([]);
129    for (let x = 0; x < COLS; x++) g[y].push(x >= 1 && x <= 20 && y >= 3 && y <= 14);
130  }
131  // la porte
132  g[15][10] = true;
133  g[15][11] = true;
134  for (const f of FURNITURE) {
135    for (let y = f.ty; y < f.ty + f.h; y++) for (let x = f.tx; x < f.tx + f.w; x++) if (g[y]?.[x] !== undefined) g[y][x] = false;
136  }
137  return g;
138}
139
140export const tileFeet = (t: [number, number]) => ({ x: t[0] * T + 8, y: t[1] * T + 13 });
141

1// La boîte à outils du pixel art : des toiles minuscules dessinées pixel par pixel, puis agrandies
2// sans flou. Tout le bureau (meubles, robots, icônes) est dessiné ici, en code : aucune image externe.
3
4import { Canvas, type Ctx } from '../canvas';
5export type { Canvas };
6export type G = Ctx;
7
8export function makeCanvas(w: number, h: number): Canvas {
9  return new Canvas(Math.max(1, Math.ceil(w)), Math.max(1, Math.ceil(h)));
10}
11
12export function g2d(c: Canvas): G {
13  const g = c.getContext('2d', { willReadFrequently: false })!;
14  g.imageSmoothingEnabled = false;
15  return g;
16}
17
18export function rect(g: G, x: number, y: number, w: number, h: number, color: string) {
19  g.fillStyle = color;
20  g.fillRect(Math.round(x), Math.round(y), Math.round(w), Math.round(h));
21}
22
23export function px(g: G, x: number, y: number, color: string) {
24  g.fillStyle = color;
25  g.fillRect(Math.round(x), Math.round(y), 1, 1);
26}
27
28/** Une ligne horizontale ou verticale d'un pixel. */
29export function hline(g: G, x: number, y: number, w: number, color: string) { rect(g, x, y, w, 1, color); }
30export function vline(g: G, x: number, y: number, h: number, color: string) { rect(g, x, y, 1, h, color); }
31
32/** Ajoute un contour d'un pixel autour de tout ce qui est opaque (la silhouette « pixel art »). */
33export function outline(c: Canvas, color: string, opts: { diagonal?: boolean; skipBottom?: boolean } = {}) {
34  const g = c.getContext('2d')!;
35  const w = c.width, h = c.height;
36  const img = g.getImageData(0, 0, w, h);
37  const d = img.data;
38  const solid = (x: number, y: number) => x >= 0 && y >= 0 && x < w && y < h && d[(y * w + x) * 4 + 3] > 40;
39  const out: number[] = [];
40  for (let y = 0; y < h; y++) {
41    for (let x = 0; x < w; x++) {
42      if (solid(x, y)) continue;
43      let hit = solid(x - 1, y) || solid(x + 1, y) || solid(x, y - 1) || (!opts.skipBottom && solid(x, y + 1));
44      if (!hit && opts.diagonal) hit = solid(x - 1, y - 1) || solid(x + 1, y - 1) || solid(x - 1, y + 1) || solid(x + 1, y + 1);
45      if (hit) out.push(x, y);
46    }
47  }
48  g.fillStyle = color;
49  for (let i = 0; i < out.length; i += 2) g.fillRect(out[i], out[i + 1], 1, 1);
50  return c;
51}
52
53/**
54 * Un sprite décrit en texte : une ligne par rangée de pixels, un caractère par pixel.
55 * « . » ou « » = transparent ; les autres caractères renvoient à la palette.
56 */
57export function fromRows(rows: string[], pal: Record<string, string>): Canvas {
58  const h = rows.length;
59  const w = Math.max(...rows.map((r) => r.length));
60  const c = makeCanvas(w, h);
61  const g = g2d(c);
62  for (let y = 0; y < h; y++) {
63    const r = rows[y];
64    for (let x = 0; x < r.length; x++) {
65      const ch = r[x];
66      if (ch === '.' || ch === ' ') continue;
67      const col = pal[ch];
68      if (col) px(g, x, y, col);
69    }
70  }
71  return c;
72}
73
74export function mirror(src: Canvas): Canvas {
75  const c = makeCanvas(src.width, src.height);
76  const g = g2d(c);
77  g.translate(src.width, 0);
78  g.scale(-1, 1);
79  g.drawImage(src, 0, 0);
80  return c;
81}
82
83// ── Couleurs ──
84function parse(hex: string): [number, number, number] {
85  const h = hex.replace('#', '');
86  const n = parseInt(h.length === 3 ? h.split('').map((c) => c + c).join('') : h, 16);
87  return [(n >> 16) & 255, (n >> 8) & 255, n & 255];
88}
89const toHex = (r: number, g: number, b: number) => '#' + [r, g, b].map((v) => Math.max(0, Math.min(255, Math.round(v))).toString(16).padStart(2, '0')).join('');
90
91export function mix(a: string, b: string, t: number): string {
92  const [r1, g1, b1] = parse(a);
93  const [r2, g2, b2] = parse(b);
94  return toHex(r1 + (r2 - r1) * t, g1 + (g2 - g1) * t, b1 + (b2 - b1) * t);
95}
96export const lighten = (c: string, t: number) => mix(c, '#ffffff', t);
97export const darken = (c: string, t: number) => mix(c, '#100c1c', t);
98export function rgba(hex: string, a: number) {
99  const [r, g, b] = parse(hex);
100  return `rgba(${r},${g},${b},${a})`;
101}
102
103/** Un petit générateur pseudo-aléatoire, pour que le grain du bois soit toujours le même. */
104export function rng(seed: number) {
105  let s = seed >>> 0 || 1;
106  return () => ((s = (s * 1664525 + 1013904223) >>> 0) / 4294967296);
107}
108
109// ── La palette du bureau (le soir, chez VibesMoney : noir, bois chaud, un seul orange) ──
110export const P = {
111  ink: '#15121d',
112  inkSoft: '#231e2e',
113  // murs
114  wallTop: '#14111c',
115  wallFace: '#262236',
116  wallFace2: '#2c2740',
117  wallLine: '#1f1b2d',
118  wallHi: '#37314d',
119  baseboard: '#191523',
120  // sol : parquet sombre et chaud
121  floor1: '#3f3138',
122  floor2: '#46363d',
123  floor3: '#3a2d34',
124  floorSeam: '#30252c',
125  floorHi: '#504048',
126  // bois clair des bureaux
127  wood: '#c08a57',
128  woodHi: '#d9a46c',
129  woodLight: '#e7bb84',
130  woodFront: '#9b6a3e',
131  woodDark: '#77502e',
132  woodLeg: '#563821',
133  // bois sombre (le bureau du chef)
134  ebony: '#2a2530',
135  ebonyHi: '#3b3443',
136  ebonyFront: '#1e1a24',
137  // métal et matériel
138  metal: '#9a9fb5',
139  metalHi: '#cfd2e0',
140  metalDark: '#62667c',
141  tech: '#262431',
142  techMid: '#363443',
143  techHi: '#4d4a5e',
144  screenOff: '#1a1f2e',
145  // l'orange VibesMoney
146  orange: '#ff8a3d',
147  orangeHi: '#ffb27a',
148  orangeLight: '#ffd2a8',
149  orangeDark: '#d9622a',
150  orangeDeep: '#9e4019',
151  // verdure
152  leafDeep: '#1f4733',
153  leafDark: '#285e40',
154  leaf: '#348050',
155  leafHi: '#52a868',
156  leafLight: '#86cf7c',
157  pot: '#b8643f',
158  potHi: '#d9875a',
159  potDark: '#8a462a',
160  potWhite: '#e9e5ef',
161  potWhiteShade: '#bdb7c9',
162  // papier
163  paper: '#f6f2e9',
164  paperShade: '#d8d1c3',
165  paperLine: '#a19a8c',
166  // tissu des fauteuils
167  fabric: '#2e2a3d',
168  fabricHi: '#403a54',
169  fabricDark: '#211d2c',
170  white: '#f7f5fc',
171  shadow: 'rgba(8,6,16,0.38)',
172};
173

1// Le contrat entre le bureau (navigateur) et le pont (serveur Node qui pilote Claude Code).
2// Tout passe par une seule connexion WebSocket, en JSON. Syntaxe « effaçable » uniquement :
3// ce fichier est lu tel quel par Node (sans compilation) et par Vite.
4
5/** Les métiers du bureau. « chef » = l'agent principal, celui à qui tu parles. */
6export type Role = 'chef' | 'recherche' | 'code' | 'design' | 'redaction' | 'analyse' | 'renfort';
7
8/** Ce que fait un agent à un instant : sert à l'animation, à l'icône et à la bulle. */
9export type ActKind = 'search' | 'web' | 'read' | 'write' | 'edit' | 'bash' | 'plan' | 'skill' | 'mcp' | 'other';
10
11export interface PlanItem { text: string; status: 'pending' | 'in_progress' | 'completed' }
12
13/** Un fichier produit par l'équipe, dans le dossier de la mission. */
14export interface FileInfo { path: string; name: string; ext: string; size: number; at: number; by: string }
15
16export interface MissionStats { agents: number; searches: number; pages: number; reads: number; writes: number; commands: number }
17
18export type MissionStatus = 'working' | 'done' | 'stopped' | 'error';
19
20export interface MissionInfo {
21  id: string;
22  title: string;
23  prompt: string;
24  /** le dossier de la mission, sur ton ordinateur */
25  folder: string;
26  createdAt: number;
27  endedAt?: number;
28  /** temps de travail cumulé (toutes les reprises comprises) */
29  workMs: number;
30  status: MissionStatus;
31  sessionId?: string;
32  model?: string;
33  stats: MissionStats;
34  files: FileInfo[];
35  /** le dernier message du chef, une fois la mission rendue */
36  final?: string;
37}
38
39/**
40 * Ce qui se passe dans le bureau. `who` vaut « chef » ou l'identifiant d'un agent de l'équipe
41 * (l'identifiant de l'appel Agent qui l'a fait venir).
42 */
43export type OfficeEvent =
44  | { k: 'start'; text: string }
45  | { k: 'init'; model: string; auth: string }
46  | { k: 'think'; who: string }
47  | { k: 'typing'; who: string; text: string }
48  | { k: 'say'; who: string; text: string }
49  | { k: 'plan'; items: PlanItem[] }
50  | { k: 'hire'; id: string; role: Role; type: string; name: string; task: string; prompt: string }
51  | { k: 'act'; who: string; id: string; kind: ActKind; tool: string; label: string; detail: string }
52  | { k: 'act_done'; who: string; id: string; ok: boolean }
53  /** le rapport qu'un agent rend au chef */
54  | { k: 'report'; who: string; text: string }
55  /** un agent a fini son travail et quitte son poste */
56  | { k: 'leave'; who: string; ok: boolean; tokens: number; tools: number; ms: number }
57  | { k: 'file'; file: FileInfo; isNew: boolean }
58  /** full = la bulle montre l'action en entier (sinon, on répond dans le panneau, où tout est affiché) */
59  | { k: 'ask'; who: string; requestId: string; tool: string; label: string; detail: string; full: boolean }
60  | { k: 'ask_done'; requestId: string; allow: boolean; cancelled?: boolean }
61  | { k: 'end'; ok: boolean; text: string; ms: number; stopped?: boolean }
62  | { k: 'error'; message: string };
63
64/** Un événement daté, tel qu'il est enregistré. */
65export interface Logged { at: number; ev: OfficeEvent }
66
67export interface ClaudeInfo { found: boolean; version?: string; path?: string }
68
69/** Une version enregistrée d'un fichier rendu (à chaque modification par l'équipe). */
70export interface VersionInfo { id: string; at: number; size: number; by: string }
71
72/** Un passage d'un agent au bureau (pour l'historique de l'équipe). */
73export interface TeamEntry {
74  missionId: string;
75  missionTitle: string;
76  at: number;
77  id: string;
78  name: string;
79  role: Role;
80  task: string;
81  status: 'working' | 'done' | 'failed';
82  tools: number;
83  tokens: number;
84  ms: number;
85  report: string;
86}
87
88export interface Settings {
89  /** le cerveau du chef : '' = le modèle par défaut de Claude Code */
90  chefModel: string;
91  /** le cerveau de l'équipe : sonnet, haiku, opus, fable ou inherit (le même que le chef) */
92  teamModel: string;
93  /** auto : l'équipe décide seule et ne demande que pour les gestes risqués ; ask : elle demande avant chaque commande */
94  permission: 'auto' | 'ask';
95}
96
97export interface Quota { fiveHour: number; resetsAt: number | null }
98
99// ── Navigateur → serveur ──
100export type ClientMsg =
101  | { t: 'start'; prompt: string }
102  | { t: 'say'; text: string }
103  | { t: 'stop' }
104  | { t: 'answer'; requestId: string; allow: boolean }
105  | { t: 'new' }
106  | { t: 'open'; missionId: string; file?: string }
107  /** ouvre le dossier du bureau (ou son règlement) */
108  | { t: 'open_root'; rules?: boolean }
109  | { t: 'read'; missionId: string; file: string; version?: string }
110  | { t: 'versions'; missionId: string; file: string }
111  | { t: 'team_history' }
112  | { t: 'replay'; missionId: string }
113  | { t: 'settings'; settings: Partial<Settings> };
114
115// ── Serveur → navigateur ──
116export type ServerMsg =
117  | { t: 'hello'; claude: ClaudeInfo; dir: string; settings: Settings; quota: Quota | null; missions: MissionInfo[]; current: { mission: MissionInfo; log: Logged[] } | null; build?: string }
118  | { t: 'mission'; mission: MissionInfo }
119  | { t: 'ev'; missionId: string; at: number; ev: OfficeEvent }
120  | { t: 'closed'; missionId: string }
121  | { t: 'replay'; mission: MissionInfo; log: Logged[] }
122  | { t: 'file_text'; missionId: string; file: string; text: string; truncated: boolean; version?: string }
123  | { t: 'versions'; missionId: string; file: string; list: VersionInfo[] }
124  | { t: 'team_history'; entries: TeamEntry[] }
125  | { t: 'quota'; quota: Quota }
126  | { t: 'settings'; settings: Settings }
127  | { t: 'toast'; kind: 'info' | 'error'; text: string };
128

1// Le dessin d'une image du bureau : la pièce, puis les meubles et les robots rangés du fond vers
2// l'avant (ceux du fond passent derrière), les effets, et enfin la lumière (le soir et la nuit,
3// la pièce s'assombrit et ce sont les écrans, les lampes et le néon qui éclairent).
4// Tout se dessine sur une toute petite image (352 × 256 pixels), agrandie sans flou : ça ne coûte presque rien.
5import type { ActKind } from './protocol';
6import { furniturePlacement } from './furniture';
7import { BOARD, CLOCK, FURNITURE, H, NEON, T, W, WINDOWS, type Furn } from './layout';
8import { g2d, makeCanvas, P, rgba, rng, type G } from './pixels';
9import { ANCHOR_X, ANCHOR_Y, robotSprite } from './robots';
10import { drawRoom, neon, signs, type TimeOfDay } from './room';
11import { ROLES } from './activity';
12import type { Actor, World } from './world';
13import type { Canvas } from '../canvas';
14
15interface Placed { f: Furn; c: Canvas; x: number; y: number; sortY: number }
16
17const SCREEN: Record<ActKind, string> = {
18  search: '#7fd6ff', web: '#7fffc4', read: '#cfe3ff', write: '#fff0d4', edit: '#fff0d4', bash: '#8affb0',
19  plan: '#ffd27a', skill: '#ffe08a', mcp: '#c9b4ff', other: '#dfe6ff',
20};
21
22const AMBIENT: Record<TimeOfDay, string> = { day: '#ffffff', evening: '#a596b2', night: '#3b3961' };
23
24/** Les couleurs du néon (clique dessus pour passer à la suivante). */
25export const NEON_COLORS: [string, string][] = [
26  [P.orange, P.orangeLight], ['#ff5fa2', '#ffc2dd'], ['#3fd8ff', '#c8f4ff'], ['#3ddc97', '#c6f7de'], ['#a98bff', '#e2d8ff'],
27];
28const DISCO = ['#ff5fa2', '#3fd8ff', '#ffd166', '#3ddc97', '#a98bff', '#ff8a3d'];
29
30export class Renderer {
31  private bg: Canvas | null = null;
32  private bgTod: TimeOfDay | null = null;
33  private light = makeCanvas(W, H);
34  private lg = g2d(this.light);
35  private placed: Placed[] = FURNITURE.map((f) => { const p = furniturePlacement(f); return { f, c: p.s.c, x: p.x, y: p.y, sortY: p.sortY }; });
36  private stars: { x: number; y: number; p: number }[] = [];
37
38  constructor() {
39    const r = rng(7);
40    for (const w of WINDOWS) for (let i = 0; i < 9; i++) this.stars.push({ x: w.x + 2 + Math.floor(r() * (w.w - 4)), y: w.y + 1 + Math.floor(r() * 12), p: r() * 6 });
41  }
42
43  draw(g: G, world: World, tod: TimeOfDay, now: Date) {
44    if (!this.bg || this.bgTod !== tod) { this.bg = drawRoom(tod); this.bgTod = tod; }
45    const t = world.time;
46    g.globalCompositeOperation = 'source-over';
47    g.globalAlpha = 1;
48    g.drawImage(this.bg, 0, 0);
49    if (tod === 'night') this.twinkle(g, t);
50    if (tod === 'day') this.clouds(g, t);
51    this.clockHands(g, now);
52    this.board(g, world, t);
53    // le néon (sa couleur change quand on clique dessus ; il grésille de temps en temps)
54    const [tube, core] = NEON_COLORS[world.neonIndex];
55    if (Math.sin(t * 0.9) <= 0.985) neon(g, tube, core);
56    // les écriteaux : le nom du coin, et combien d'agents y travaillent en ce moment
57    const busy = new Map<string, number>();
58    for (const a of world.actors.values()) if (a.seated && a.role !== 'chef') busy.set(a.role, (busy.get(a.role) ?? 0) + 1);
59    signs(g, (role) => busy.get(role) ?? 0);
60
61    // qui est assis à quel bureau
62    const atDesk = new Map<string, Actor>();
63    for (const a of world.actors.values()) if (a.seated && a.seat) atDesk.set(a.seat.deskId, a);
64
65    // du fond vers l'avant
66    const items: { y: number; k: number; draw: () => void }[] = [];
67    for (const p of this.placed) {
68      const shake = (world.wiggles.get(p.f.id) ?? 0) > t ? Math.round(Math.sin(t * 42)) : 0;
69      items.push({ y: p.sortY, k: 0, draw: () => { g.drawImage(p.c, p.x + shake, p.y); this.furnitureLive(g, p, world, atDesk.get(p.f.id) ?? null, t); } });
70    }
71    for (const a of world.actors.values()) {
72      items.push({ y: a.seated && a.seat ? a.seat.y : a.y, k: 1, draw: () => this.actor(g, a, world) });
73    }
74    items.push({ y: world.cat.sortY, k: 2, draw: () => world.cat.draw(g) });
75    items.sort((a, b) => a.y - b.y || a.k - b.k);
76    for (const it of items) it.draw();
77
78    if (t < world.discoUntil) this.discoBall(g, t);
79    world.fx.draw(g);
80    if (tod === 'day') this.sunbeams(g);
81    else this.lighting(g, world, tod, atDesk, t);
82    if (t < world.discoUntil) this.discoSpots(g, t, world.discoUntil - t);
83  }
84
85  private actor(g: G, a: Actor, world: World) {
86    const seated = a.seated && !!a.seat;
87    const x = Math.round(a.x);
88    // sur la musique, ceux qui ne marchent pas hochent la tête en rythme
89    const y = Math.round(a.y) - (world.musicOn && world.time < world.bobUntil && !a.moving ? 1 : 0);
90    g.globalAlpha = a.alpha;
91    if (!seated) {
92      g.fillStyle = 'rgba(8,6,16,0.32)';
93      g.fillRect(x - 5, y - 1, 10, 2);
94      g.fillRect(x - 4, y - 2, 8, 1);
95    }
96    const sprite = robotSprite(a.role, a.pose, seated ? 'down' : a.dir, a.frame, a.eyes);
97    g.drawImage(sprite, x - ANCHOR_X, y - ANCHOR_Y);
98    g.globalAlpha = 1;
99  }
100
101  /** Les parties vivantes des meubles : écrans allumés, voyants, imprimante, rapports sur le bureau du chef. */
102  private furnitureLive(g: G, p: Placed, world: World, who: Actor | null, t: number) {
103    const f = p.f;
104    if (f.kind === 'desk' && who) {
105      const on = t - who.actAt < 9;
106      const col = on && who.act ? SCREEN[who.act] : '#5b6b8c';
107      switch (f.role) {
108        case 'code': {
109          // le reflet de l'écran sur les bords des moniteurs
110          for (const mx of [1, 22]) {
111            g.fillStyle = col;
112            g.fillRect(p.x + mx, p.y + 1, 9, 1);
113          }
114          break;
115        }
116        case 'design': {
117          const cols = ['#ff6fa8', '#ffd166', '#4fb3ff', '#a98bff', P.orange];
118          for (let i = 0; i < 11; i++) {
119            g.fillStyle = cols[(i + Math.floor(t * (on ? 6 : 1))) % cols.length];
120            g.fillRect(p.x + 10 + i, p.y + 12 + (i % 3 === 0 ? 1 : 0), 1, i % 2 ? 2 : 3);
121          }
122          break;
123        }
124        case 'analyse': {
125          g.fillStyle = '#141a2c';
126          g.fillRect(p.x + 23, p.y + 2, 7, 6);
127          const bars = ['#ffd166', P.orange, '#4fb3ff', '#3ddc97'];
128          for (let i = 0; i < 4; i++) {
129            const h = on ? 2 + Math.floor((Math.sin(t * 3 + i * 1.7) + 1) * 1.6) : 2 + (i % 3);
130            g.fillStyle = bars[i];
131            g.fillRect(p.x + 24 + i + (i > 1 ? 1 : 0), p.y + 7 - h, 1, h);
132          }
133          this.logo(g, p.x + 14, p.y + 10, on, t);
134          break;
135        }
136        default:
137          this.logo(g, p.x + 15, p.y + 10, on, t);
138      }
139    }
140    if (f.kind === 'chefDesk') {
141      if (who) this.logo(g, p.x + 31, p.y + 10, true, t);
142      // les rapports rendus, empilés dans la corbeille
143      const n = Math.min(world.inbox, 7);
144      for (let i = 0; i < n; i++) {
145        g.fillStyle = P.ink;
146        g.fillRect(p.x + 46 + (i % 2), p.y + 10 - i, 12, 3);
147        g.fillStyle = i % 2 ? P.paperShade : P.paper;
148        g.fillRect(p.x + 47 + (i % 2), p.y + 10 - i, 10, 2);
149      }
150    }
151    if (f.kind === 'printer' && t < world.printUntil) {
152      const prog = 1 - (world.printUntil - t) / 1.8;
153      const h = Math.max(1, Math.round(Math.min(1, prog * 1.6) * 6));
154      g.fillStyle = P.paper;
155      g.fillRect(p.x + 4, p.y + 8, 8, h);
156      g.fillStyle = P.paperLine;
157      if (h > 3) g.fillRect(p.x + 5, p.y + 10, 5, 1);
158      g.fillStyle = Math.floor(t * 8) % 2 ? '#3ddc97' : '#1f6b45';
159      g.fillRect(p.x + 13, p.y + 9, 1, 1);
160    }
161    if (f.kind === 'rack') {
162      for (let i = 0; i < 6; i++) {
163        const blink = Math.sin(t * (2 + (i % 3)) + i * 2.3) > -0.2;
164        g.fillStyle = blink ? (i % 4 === 0 ? '#ff8a3d' : i % 3 === 0 ? '#4fb3ff' : '#3ddc97') : '#1f3a2e';
165        g.fillRect(p.x + 3, p.y + 7 + i * 4, 1, 1);
166        g.fillStyle = Math.sin(t * 5 + i) > 0.6 ? '#3ddc97' : '#1f3a2e';
167        g.fillRect(p.x + 5, p.y + 7 + i * 4, 1, 1);
168      }
169    }
170    if (f.kind === 'jukebox') this.jukeboxLights(g, p, world, t);
171    if (f.kind === 'coffee') {
172      g.fillStyle = Math.floor(t * 1.5) % 2 ? P.orange : P.orangeDark;
173      g.fillRect(p.x + 14, p.y + 2, 1, 1);
174    }
175  }
176
177  /** Les néons de l'arche du jukebox : éteints au repos, ils défilent et pulsent sur la musique. */
178  private jukeboxLights(g: G, p: Placed, world: World, t: number) {
179    const on = world.musicOn;
180    const arcs: [number, string, string][] = [[11, '#ff5fa2', '#5a2a3e'], [9, P.orange, '#5a3a24'], [7, '#3fd8ff', '#1f3e4a']];
181    arcs.forEach(([r, col, dim], i) => {
182      for (let a = 0; a <= 16; a++) {
183        const ang = Math.PI + (a / 16) * Math.PI;
184        const x = p.x + 16 + Math.round(Math.cos(ang) * r);
185        const y = p.y + 15 + Math.round(Math.sin(ang) * r);
186        const lit = on && (Math.floor(t * 8) + a + i * 3) % 6 !== 0;
187        g.fillStyle = lit ? col : dim;
188        g.fillRect(x, y, 1, 1);
189      }
190    });
191    if (on) {
192      // le disque tourne
193      const a = t * 8;
194      g.fillStyle = P.orangeLight;
195      g.fillRect(p.x + 16 + Math.round(Math.cos(a) * 3), p.y + 20 + Math.round(Math.sin(a) * 1.5), 1, 1);
196      // les barres du vumètre
197      for (let i = 0; i < 5; i++) {
198        const h = 1 + Math.round((world.musicLevel * 4) * (0.6 + 0.4 * Math.sin(t * 9 + i * 1.7)));
199        g.fillStyle = i % 2 ? '#ff5fa2' : P.orange;
200        g.fillRect(p.x + 7 + i * 4, p.y + 32 - h, 2, h);
201      }
202    }
203  }
204
205  /** La boule à facettes du mode soirée. */
206  private discoBall(g: G, t: number) {
207    const cx = 176, cy = 30;
208    g.fillStyle = '#8a8ea2';
209    g.fillRect(cx, 0, 1, cy - 5);
210    for (let y = -5; y <= 5; y++) {
211      const w = Math.round(Math.sqrt(25 - y * y));
212      for (let x = -w; x <= w; x++) {
213        const k = (x + y + Math.floor(t * 10)) & 3;
214        g.fillStyle = k === 0 ? '#ffffff' : k === 1 ? '#c9cbd6' : k === 2 ? '#8a8ea2' : DISCO[(x * 7 + y * 3 + Math.floor(t * 6)) % DISCO.length];
215        g.fillRect(cx + x, cy + y, 1, 1);
216      }
217    }
218  }
219
220  /** Les taches de lumière colorées qui tournent sur le sol pendant le mode soirée. */
221  private discoSpots(g: G, t: number, left: number) {
222    const fade = Math.min(1, left / 1.5);
223    g.globalCompositeOperation = 'lighter';
224    for (let i = 0; i < 9; i++) {
225      const a = t * (0.7 + i * 0.13) + i * 2.1;
226      const x = 176 + Math.cos(a) * (60 + i * 12);
227      const y = 140 + Math.sin(a * 1.3) * (40 + i * 4);
228      const grd = g.createRadialGradient(x, y, 0, x, y, 14);
229      grd.addColorStop(0, rgba(DISCO[i % DISCO.length], 0.32 * fade));
230      grd.addColorStop(1, rgba(DISCO[i % DISCO.length], 0));
231      g.fillStyle = grd;
232      g.fillRect(x - 14, y - 14, 28, 28);
233    }
234    g.globalCompositeOperation = 'source-over';
235  }
236
237  /** Deux petits nuages qui passent derrière les fenêtres, en journée. */
238  private clouds(g: G, t: number) {
239    for (const w of WINDOWS) {
240      g.save();
241      g.beginPath();
242      g.rect(w.x, w.y, w.w, 11);
243      g.clip();
244      for (let i = 0; i < 2; i++) {
245        const span = w.w + 30;
246        const x = w.x - 15 + ((t * (3 + i * 2) + i * 40 + w.x) % span);
247        const y = w.y + 3 + i * 4;
248        g.fillStyle = 'rgba(255,255,255,0.85)';
249        g.fillRect(Math.round(x), y, 9, 2);
250        g.fillRect(Math.round(x) + 2, y - 1, 5, 1);
251      }
252      g.restore();
253    }
254  }
255
256  /** Le petit cube orange au dos de l'ordinateur, qui s'allume quand l'agent travaille. */
257  private logo(g: G, x: number, y: number, on: boolean, t: number) {
258    g.fillStyle = on ? (Math.sin(t * 6) > -0.6 ? P.orange : P.orangeHi) : '#8a5a3e';
259    g.fillRect(x, y, 2, 2);
260  }
261
262  private clockHands(g: G, now: Date) {
263    const cx = CLOCK.x + 7, cy = CLOCK.y + 7;
264    const m = now.getMinutes() + now.getSeconds() / 60;
265    const h = (now.getHours() % 12) + m / 60;
266    const hand = (angle: number, len: number, color: string) => {
267      g.fillStyle = color;
268      for (let i = 0; i <= len; i++) g.fillRect(Math.round(cx + Math.sin(angle) * i), Math.round(cy - Math.cos(angle) * i), 1, 1);
269    };
270    hand((h / 12) * Math.PI * 2, 3, '#2b2836');
271    hand((m / 60) * Math.PI * 2, 4, '#2b2836');
272    g.fillStyle = P.orange;
273    g.fillRect(cx, cy, 1, 1);
274  }
275
276  private twinkle(g: G, t: number) {
277    for (const s of this.stars) {
278      const a = (Math.sin(t * 1.6 + s.p) + 1) / 2;
279      if (a < 0.35) continue;
280      g.fillStyle = `rgba(255,255,255,${(a * 0.9).toFixed(2)})`;
281      g.fillRect(s.x, s.y, 1, 1);
282    }
283  }
284
285  /** En journée : de grands rayons de soleil qui tombent des fenêtres. */
286  private sunbeams(g: G) {
287    g.save();
288    g.beginPath();
289    g.rect(T, 3 * T, W - 2 * T, H - 4 * T);
290    g.clip();
291    g.globalCompositeOperation = 'lighter';
292    for (const w of WINDOWS) {
293      g.fillStyle = 'rgba(255,236,190,0.06)';
294      g.beginPath();
295      g.moveTo(w.x + 4, 48);
296      g.lineTo(w.x + w.w - 4, 48);
297      g.lineTo(w.x + w.w + 26, 120);
298      g.lineTo(w.x + 30, 120);
299      g.closePath();
300      g.fill();
301    }
302    g.globalCompositeOperation = 'source-over';
303    g.restore();
304  }
305
306  private lighting(g: G, world: World, tod: TimeOfDay, atDesk: Map<string, Actor>, t: number) {
307    const l = this.lg;
308    l.globalCompositeOperation = 'source-over';
309    l.fillStyle = AMBIENT[tod];
310    l.fillRect(0, 0, W, H);
311    l.globalCompositeOperation = 'lighter';
312    const night = tod === 'night';
313    const add = (x: number, y: number, r: number, color: string, a: number) => {
314      const grd = l.createRadialGradient(x, y, 0, x, y, r);
315      grd.addColorStop(0, rgba(color, a));
316      grd.addColorStop(0.55, rgba(color, a * 0.45));
317      grd.addColorStop(1, rgba(color, 0));
318      l.fillStyle = grd;
319      l.fillRect(x - r, y - r, r * 2, r * 2);
320    };
321    // le néon (il grésille de temps en temps)
322    const flick = Math.sin(t * 0.9) > 0.985 ? 0.25 : 1;
323    const neonCol = NEON_COLORS[world.neonIndex][0];
324    add(NEON.x + 12, NEON.y + 12, 52, neonCol, 0.75 * flick);
325    // les fenêtres : coucher de soleil ou clair de lune
326    for (const w of WINDOWS) add(w.x + w.w / 2, w.y + w.h + 8, 58, night ? '#7080d0' : '#ff9a6a', night ? 0.42 : 0.55);
327    // le tableau du plan, éclairé
328    add(176, 28, 52, '#fff6e8', night ? 0.28 : 0.22);
329    // la lampe du chef et le liseré orange de son bureau
330    add(9 * T + 12, 7 * T - 6, 40, '#ffd9a0', 0.8);
331    add(11 * T, 7 * T + 14, 44, P.orange, 0.32);
332    // les lampadaires, le café, le serveur
333    if (!world.lampsOff.has('lamp')) add(1 * T + 8, 14 * T - 12, 52, '#ffcf8a', 0.85);
334    if (!world.lampsOff.has('lamp-r')) add(20 * T + 8, 14 * T - 12, 52, '#ffcf8a', 0.85);
335    // le jukebox, qui pulse sur la musique
336    if (world.musicOn) add(15 * T, 13 * T + 4, 30 + world.musicLevel * 18, ['#ff5fa2', P.orange, '#3fd8ff'][Math.floor(t * 1.5) % 3], 0.35 + world.musicLevel * 0.45);
337    // les yeux du chat brillent dans le noir
338    add(world.cat.x + (world.cat.right ? 4 : -4), world.cat.y - 8, 4, P.orange, 0.5);
339    add(16 * T + 14, 14 * T - 8, 14, P.orange, 0.5);
340    add(14 * T + 4, 3 * T + 6, 18, '#5fd0ff', 0.35);
341    add(11 * T, 15 * T + 8, 30, '#ffe2b8', 0.4);
342    if (t < world.printUntil) add(12 * T + 8, 4 * T - 2, 16, '#9effa8', 0.6);
343    // les écrans éclairent les visages
344    for (const a of atDesk.values()) {
345      const on = t - a.actAt < 9;
346      const col = on && a.act ? SCREEN[a.act] : '#8fa4d0';
347      const sx = a.seat!.x, sy = a.seat!.y - 12;
348      add(sx, sy, on ? 26 : 18, a.role === 'design' && on ? '#ff9fd0' : col, on ? 0.75 : 0.35);
349    }
350    // un projecteur doux suit Max (le patron reste toujours bien visible)
351    const chef = world.chef;
352    add(chef.x, (chef.seated && chef.seat ? chef.seat.y : chef.y) - 8, 26, '#ffe2c4', 0.42);
353    // les yeux des robots
354    for (const a of world.actors.values()) {
355      if (a.alpha < 0.3) continue;
356      add(a.x, (a.seated && a.seat ? a.seat.y : a.y) - 13, 7, P.orange, 0.55);
357    }
358    g.globalCompositeOperation = 'multiply';
359    g.drawImage(this.light, 0, 0);
360    // un léger halo sur ce qui brille
361    g.globalCompositeOperation = 'lighter';
362    const glow = (x: number, y: number, r: number, color: string, a: number) => {
363      const grd = g.createRadialGradient(x, y, 0, x, y, r);
364      grd.addColorStop(0, rgba(color, a));
365      grd.addColorStop(1, rgba(color, 0));
366      g.fillStyle = grd;
367      g.fillRect(x - r, y - r, r * 2, r * 2);
368    };
369    glow(NEON.x + 12, NEON.y + 12, 20, neonCol, 0.32 * flick);
370    for (const a of world.actors.values()) if (a.alpha > 0.3) glow(a.x, (a.seated && a.seat ? a.seat.y : a.y) - 13, 4, P.orange, 0.35);
371    for (const a of atDesk.values()) if (t - a.actAt < 9) glow(a.seat!.x, a.seat!.y - 6, 8, a.act ? SCREEN[a.act] : '#ffffff', 0.18);
372    g.globalCompositeOperation = 'source-over';
373  }
374
375  /** Le plan, au feutre sur le tableau : une ligne par étape, cochée quand elle est faite. */
376  private board(g: G, world: World, t: number) {
377    const items = world.plan.slice(0, 5);
378    const x0 = BOARD.x + 4;
379    items.forEach((it, i) => {
380      const y = BOARD.y + 12 + i * 4;
381      const done = it.status === 'completed';
382      const doing = it.status === 'in_progress';
383      // la case
384      g.fillStyle = done ? '#2fbf71' : doing ? (Math.floor(t * 3) % 2 ? P.orange : P.orangeDark) : '#8a8ea2';
385      g.fillRect(x0, y, 3, 3);
386      if (!done) { g.fillStyle = '#f4f5f9'; g.fillRect(x0 + 1, y + 1, 1, 1); }
387      // la ligne écrite à la main
388      const len = Math.max(18, Math.min(78, Math.round(it.text.length * 1.5)));
389      const ink = done ? '#b4b7c6' : doing ? '#3a2f44' : '#2b2836';
390      g.fillStyle = ink;
391      for (let k = 0; k < len; k++) {
392        if ((k * 7 + i * 3) % 11 === 0) continue; // des petits blancs entre les « mots »
393        g.fillRect(x0 + 6 + k, y + 1 + (Math.sin((k + i * 5) * 0.9) > 0.6 ? -1 : 0), 1, 1);
394      }
395      if (done) { g.fillStyle = '#2fbf71'; g.fillRect(x0 + 5, y + 1, len + 2, 1); }
396    });
397    if (world.plan.length > 5) { g.fillStyle = '#8a8ea2'; g.fillRect(x0 + 6, BOARD.y + 32, 1, 1); g.fillRect(x0 + 8, BOARD.y + 32, 1, 1); g.fillRect(x0 + 10, BOARD.y + 32, 1, 1); }
398    // qui fait quoi : une petite tête de robot par agent, en bas à droite du tableau, cochée quand il a rendu son travail
399    const team = world.assignments.slice(-12);
400    team.forEach((a, i) => {
401      const x = BOARD.x + BOARD.w - 8 - (team.length - 1 - i) * 6;
402      const y = BOARD.y + 27;
403      g.fillStyle = a.status === 'done' ? '#2fbf71' : a.status === 'failed' ? '#e5484d' : ROLES[a.role].color;
404      g.fillRect(x, y, 4, 4);
405      g.fillStyle = '#15121d';
406      g.fillRect(x + 1, y + 1, 2, 1);
407      if (a.status === 'working' && Math.floor(t * 2 + i) % 2) { g.fillStyle = '#ff8a3d'; g.fillRect(x + 1, y + 1, 1, 1); }
408    });
409  }
410}
411

1// La pièce elle-même : le parquet, les tapis de chaque coin, les murs, les grandes fenêtres sur la
2// ville (le ciel suit l'heure), le néon VibesMoney, le tableau du plan, l'horloge et la porte.
3// Tout ça ne bouge pas : c'est dessiné une fois, puis recopié à chaque image.
4import { ROLES } from './activity';
5import { pixelText, textWidth } from './font';
6import { BOARD, CLOCK, H, NEON, T, W, WINDOWS, ZONES } from './layout';
7import { g2d, hline, lighten, makeCanvas, mix, P, px, rect, rng, vline, type G } from './pixels';
8import type { Canvas } from '../canvas';
9
10export type TimeOfDay = 'day' | 'evening' | 'night';
11
12const SKY: Record<TimeOfDay, { bands: string[]; city: string; city2: string; lit: string; litRate: number }> = {
13  day: { bands: ['#4f9fe8', '#68b1ef', '#83c2f3', '#a3d3f6', '#c3e3f8'], city: '#6f80a8', city2: '#8494b9', lit: '#d4e2f5', litRate: 0.08 },
14  evening: { bands: ['#2a2453', '#43306a', '#6c3a72', '#a64a6c', '#dc6a5c', '#ff9d5c'], city: '#1d1631', city2: '#2a2040', lit: '#ffcf6b', litRate: 0.22 },
15  night: { bands: ['#0a0a20', '#0f0f2c', '#151538', '#1c1a45', '#231e50'], city: '#0a0816', city2: '#120f22', lit: '#ffcf6b', litRate: 0.32 },
16};
17
18function floor(g: G) {
19  const r = rng(42);
20  const top = 3 * T;
21  const colors = [P.floor1, P.floor2, P.floor3, P.floor1];
22  // des lames de parquet de 6 pixels, aux raccords décalés
23  for (let y = top; y < H; y += 6) {
24    let x = -Math.floor(r() * 20);
25    while (x < W) {
26      const len = 18 + Math.floor(r() * 22);
27      const col = colors[Math.floor(r() * colors.length)];
28      rect(g, x, y, len, 5, col);
29      hline(g, x, y, len, mix(col, P.floorHi, 0.5));
30      rect(g, x, y + 5, len, 1, P.floorSeam);
31      vline(g, x + len - 1, y, 5, P.floorSeam);
32      if (r() < 0.12) px(g, x + 4 + Math.floor(r() * (len - 8)), y + 2, P.floorSeam);
33      x += len;
34    }
35  }
36}
37
38function rug(g: G, x: number, y: number, w: number, h: number, color: string) {
39  const base = mix(color, '#2b2232', 0.72);
40  const edge = mix(color, '#2b2232', 0.5);
41  const inner = mix(color, '#2b2232', 0.62);
42  const px0 = x * T + 2, py0 = y * T + 2, pw = w * T - 4, ph = h * T - 4;
43  rect(g, px0 + 1, py0, pw - 2, ph, base);
44  rect(g, px0, py0 + 1, pw, ph - 2, base);
45  // bordure
46  hline(g, px0 + 1, py0, pw - 2, edge);
47  hline(g, px0 + 1, py0 + ph - 1, pw - 2, edge);
48  vline(g, px0, py0 + 1, ph - 2, edge);
49  vline(g, px0 + pw - 1, py0 + 1, ph - 2, edge);
50  // un liseré intérieur, et un motif discret
51  hline(g, px0 + 3, py0 + 3, pw - 6, inner);
52  hline(g, px0 + 3, py0 + ph - 4, pw - 6, inner);
53  vline(g, px0 + 3, py0 + 3, ph - 6, inner);
54  vline(g, px0 + pw - 4, py0 + 3, ph - 6, inner);
55  for (let yy = py0 + 7; yy < py0 + ph - 6; yy += 6) for (let xx = px0 + 7 + ((yy / 6) % 2) * 3; xx < px0 + pw - 6; xx += 6) px(g, xx, yy, inner);
56}
57
58function backWall(g: G) {
59  rect(g, 0, 0, W, 5, P.wallTop);
60  rect(g, 0, 5, W, 39, P.wallFace);
61  // boiseries : un panneau bas plus sombre, une cimaise
62  rect(g, 0, 31, W, 13, P.wallFace2);
63  hline(g, 0, 30, W, P.wallHi);
64  hline(g, 0, 31, W, P.wallLine);
65  for (let x = 8; x < W; x += 22) vline(g, x, 33, 9, P.wallLine);
66  hline(g, 0, 5, W, P.wallHi);
67  rect(g, 0, 44, W, 4, P.baseboard);
68  hline(g, 0, 44, W, P.wallHi);
69  // l'ombre du mur sur le sol
70  g.fillStyle = 'rgba(8,6,16,0.35)';
71  g.fillRect(0, 48, W, 2);
72  g.fillStyle = 'rgba(8,6,16,0.18)';
73  g.fillRect(0, 50, W, 2);
74}
75
76function windowPane(g: G, wx: number, wy: number, ww: number, wh: number, tod: TimeOfDay, seed: number) {
77  const sky = SKY[tod];
78  const r = rng(seed);
79  // cadre
80  rect(g, wx - 3, wy - 3, ww + 6, wh + 6, '#1a1724');
81  rect(g, wx - 2, wy - 2, ww + 4, wh + 4, '#3b3550');
82  // le ciel, en bandes (comme dans les vieux jeux)
83  const bh = Math.ceil(wh / sky.bands.length);
84  sky.bands.forEach((c, i) => rect(g, wx, wy + i * bh, ww, bh, c));
85  if (tod === 'evening') {
86    for (let i = 0; i < 9; i++) rect(g, wx + 30 + i - 4, wy + wh - 10 - Math.round(Math.sqrt(16 - (i - 4) ** 2)), 1, 6, '#ffd27a');
87  }
88  if (tod === 'night' && seed === 1) {
89    rect(g, wx + 10, wy + 5, 6, 6, '#f2efd8');
90    rect(g, wx + 9, wy + 6, 8, 4, '#f2efd8');
91    px(g, wx + 12, wy + 7, '#d6d2b8');
92    px(g, wx + 14, wy + 9, '#d6d2b8');
93  }
94  if (tod === 'day') {
95    for (const [cx, cy, cw] of [[wx + 8, wy + 6, 12], [wx + 36, wy + 10, 9]]) {
96      rect(g, cx, cy, cw, 3, '#ffffff');
97      rect(g, cx + 2, cy - 2, cw - 5, 2, '#ffffff');
98      hline(g, cx, cy + 3, cw, '#dcecf8');
99    }
100  }
101  // la ville au loin
102  let x = wx;
103  while (x < wx + ww) {
104    const bw = 4 + Math.floor(r() * 8);
105    const bhh = 7 + Math.floor(r() * 13);
106    const far = r() < 0.4;
107    const top = wy + wh - bhh + (far ? 3 : 0);
108    rect(g, x, top, Math.min(bw, wx + ww - x), wy + wh - top, far ? sky.city2 : sky.city);
109    for (let yy = top + 2; yy < wy + wh - 1; yy += 2) {
110      for (let xx = x + 1; xx < Math.min(x + bw - 1, wx + ww - 1); xx += 2) if (r() < sky.litRate) px(g, xx, yy, sky.lit);
111    }
112    x += bw;
113  }
114  // montants et traverse
115  vline(g, wx + Math.floor(ww / 2), wy, wh, '#3b3550');
116  vline(g, wx + Math.floor(ww / 2) + 1, wy, wh, '#2a2538');
117  hline(g, wx, wy + 11, ww, '#3b3550');
118  // un reflet sur la vitre
119  for (let i = 0; i < 6; i++) px(g, wx + 4 + i, wy + 14 - i, 'rgba(255,255,255,0.18)');
120  // l'appui de fenêtre
121  rect(g, wx - 4, wy + wh + 2, ww + 8, 3, '#4a4560');
122  hline(g, wx - 4, wy + wh + 2, ww + 8, '#625c7c');
123}
124
125function whiteboard(g: G) {
126  const { x, y, w, h } = BOARD;
127  rect(g, x - 2, y - 2, w + 4, h + 4, '#7a7e93');
128  rect(g, x - 1, y - 1, w + 2, h + 2, '#c2c5d4');
129  hline(g, x - 1, y - 1, w + 2, '#e6e8f0');
130  rect(g, x, y, w, h, '#f4f5f9');
131  // un reflet en biais
132  for (let i = 0; i < 18; i++) px(g, x + w - 30 + i, y + 2 + Math.floor(i / 2), '#ffffff');
133  // le rebord et les feutres
134  rect(g, x + 4, y + h + 2, w - 8, 2, '#8a8ea2');
135  hline(g, x + 4, y + h + 2, w - 8, '#b3b6c6');
136  rect(g, x + 12, y + h + 1, 5, 1, '#e5484d');
137  rect(g, x + 19, y + h + 1, 5, 1, '#3d8ad1');
138  rect(g, x + 26, y + h + 1, 5, 1, '#2b2836');
139  rect(g, x + w - 18, y + h + 1, 6, 2, '#e9e5ef');
140  // le titre, au feutre orange
141  pixelText(g, 'LE PLAN', x + 4, y + 3, P.orangeDark);
142  hline(g, x + 4, y + 9, textWidth('LE PLAN'), P.orange);
143}
144
145const SIGN: Record<string, string> = { recherche: 'RECHERCHE', code: 'CODE', design: 'DESIGN', redaction: 'RÉDACTION', analyse: 'ANALYSE', chef: 'CHEF' };
146
147/** Les écriteaux posés au coin de chaque tapis, avec le nombre d'agents au travail dans le coin. */
148export function signs(g: G, busy: (role: string) => number) {
149  for (const z of ZONES) {
150    const n = busy(z.role);
151    const label = (SIGN[z.role] ?? z.label.toUpperCase()) + (n > 0 && z.role !== 'chef' ? ` ${n}` : '');
152    const color = ROLES[z.role].color;
153    const w = textWidth(label) + 6;
154    const x = z.x * T + 4, y = z.role === 'chef' ? (z.y + z.h) * T - 12 : z.y * T + 3;
155    rect(g, x + 1, y, w - 2, 9, '#120f19');
156    rect(g, x, y + 1, w, 7, '#120f19');
157    hline(g, x + 1, y, w - 2, mix(color, '#120f19', 0.45));
158    pixelText(g, label, x + 3, y + 2, lighten(color, 0.15));
159  }
160}
161
162/** Le néon : la tête du robot VibesMoney, en tubes de couleur (orange par défaut). */
163export function neon(g: G, tube: string, core: string) {
164  const { x, y } = NEON;
165  // antenne
166  vline(g, x + 12, y, 3, tube);
167  rect(g, x + 11, y - 2, 3, 2, tube);
168  // contour de la tête
169  rect(g, x + 1, y + 3, 23, 1, tube);
170  rect(g, x + 1, y + 20, 23, 1, tube);
171  rect(g, x + 1, y + 3, 1, 18, tube);
172  rect(g, x + 23, y + 3, 1, 18, tube);
173  hline(g, x + 2, y + 4, 21, core);
174  // la visière et les yeux
175  rect(g, x + 5, y + 8, 15, 1, tube);
176  rect(g, x + 5, y + 15, 15, 1, tube);
177  rect(g, x + 5, y + 8, 1, 8, tube);
178  rect(g, x + 19, y + 8, 1, 8, tube);
179  rect(g, x + 8, y + 10, 3, 3, core);
180  rect(g, x + 14, y + 10, 3, 3, core);
181  // le petit support au mur
182  px(g, x + 3, y + 22, '#3b3550');
183  px(g, x + 21, y + 22, '#3b3550');
184}
185
186function clockFace(g: G) {
187  const { x, y } = CLOCK;
188  rect(g, x + 3, y, 8, 14, '#2b2836');
189  rect(g, x, y + 3, 14, 8, '#2b2836');
190  rect(g, x + 1, y + 1, 12, 12, '#2b2836');
191  rect(g, x + 2, y + 2, 10, 10, '#f2f0f7');
192  rect(g, x + 4, y + 1, 6, 12, '#f2f0f7');
193  rect(g, x + 1, y + 4, 12, 6, '#f2f0f7');
194  px(g, x + 7, y + 2, '#2b2836');
195  px(g, x + 7, y + 11, '#2b2836');
196  px(g, x + 2, y + 7, '#2b2836');
197  px(g, x + 11, y + 7, '#2b2836');
198}
199
200function poster(g: G) {
201  const x = 252, y = 12;
202  rect(g, x, y, 10, 14, '#c08a57');
203  rect(g, x + 1, y + 1, 8, 12, '#16121f');
204  // une courbe qui monte, en orange
205  const pts = [[2, 10], [3, 9], [4, 9], [5, 7], [6, 6], [7, 4], [8, 3]];
206  for (const [px_, py_] of pts) px(g, x + px_, y + py_, P.orange);
207  px(g, x + 8, y + 2, P.orangeLight);
208}
209
210function sideWalls(g: G) {
211  for (const x0 of [0, W - T]) {
212    rect(g, x0, 0, T, H, P.wallTop);
213    const inner = x0 === 0 ? T - 2 : x0;
214    vline(g, inner, 5, H - 5, '#2c2740');
215    vline(g, x0 === 0 ? inner + 1 : inner + 1, 5, H - 5, '#1d1a28');
216  }
217  // l'ombre des murs de côté sur le sol
218  g.fillStyle = 'rgba(8,6,16,0.25)';
219  g.fillRect(T, 3 * T, 2, H - 4 * T);
220  g.fillRect(W - T - 2, 3 * T, 2, H - 4 * T);
221}
222
223function frontWall(g: G) {
224  const y = 15 * T;
225  rect(g, 0, y, 10 * T, T, P.wallTop);
226  rect(g, 12 * T, y, W - 12 * T, T, P.wallTop);
227  hline(g, 0, y, 10 * T, '#2c2740');
228  hline(g, 12 * T, y, W - 12 * T, '#2c2740');
229  // l'encadrement de la porte
230  for (const x of [10 * T - 2, 12 * T]) {
231    rect(g, x, y - 2, 2, T + 2, '#3b3550');
232    vline(g, x, y - 2, T + 2, '#4d4666');
233  }
234  // le paillasson orange
235  const mx = 10 * T + 2, my = 14 * T + 3;
236  rect(g, mx, my, 2 * T - 4, 10, P.orangeDeep);
237  for (let i = 0; i < 4; i++) hline(g, mx + 2, my + 2 + i * 2, 2 * T - 8, i % 2 ? P.orangeDark : P.orange);
238}
239
240/** Dessine toute la pièce (sans les meubles) dans une image de la taille du bureau. */
241export function drawRoom(tod: TimeOfDay): Canvas {
242  const c = makeCanvas(W, H);
243  const g = g2d(c);
244  floor(g);
245  for (const z of ZONES) rug(g, z.x, z.y, z.w, z.h, ROLES[z.role].color);
246  backWall(g);
247  WINDOWS.forEach((w, i) => windowPane(g, w.x, w.y, w.w, w.h, tod, i + 1));
248  whiteboard(g);
249  clockFace(g);
250  poster(g);
251  sideWalls(g);
252  frontWall(g);
253  return c;
254}
255

1// Le monde du bureau : les robots, ce qu'ils font, où ils vont. Chaque événement venu de Claude Code
2// devient une petite mise en scène : un membre de l'équipe arrive par la porte, va à son bureau, tape
3// ou lit selon ce qu'il fait vraiment, se lève pour rendre son rapport au chef, puis repart.
4import type { ActKind, OfficeEvent, PlanItem, Role } from './protocol';
5import { Cat } from './cat';
6import { Fx } from './fx';
7import { iconFor } from './icons';
8import { CHEF_SEAT, SEATS, SPOTS, T, WINDOWS, tileFeet, walkGrid, type Seat } from './layout';
9import { findPath, type Tile } from './path';
10import type { Dir, Eyes, Pose } from './robots';
11
12type Pt = { x: number; y: number };
13
14type Task =
15  | { t: 'walk'; tile: Tile; face?: Dir; then?: Pt }
16  | { t: 'slide'; to: Pt; face?: Dir; speed?: number }
17  | { t: 'sit'; seat: Seat }
18  | { t: 'stand' }
19  | { t: 'wait'; ms: number; pose?: Pose; dir?: Dir; eyes?: Eyes }
20  | { t: 'call'; fn: () => void }
21  | { t: 'fade'; to: number; ms: number };
22
23const WALK_SPEED = 58; // pixels par seconde
24
25export class Actor {
26  id: string;
27  role: Role;
28  name: string;
29  x: number;
30  y: number;
31  dir: Dir = 'down';
32  pose: Pose = 'stand';
33  frame = 0;
34  eyes: Eyes = 'open';
35  seat: Seat | null = null;
36  seated = false;
37  standSpot: Tile | null = null;
38  tasks: Task[] = [];
39  cur: Task | null = null;
40  curT = 0;
41  path: Pt[] = [];
42  moving = false;
43  alpha = 1;
44  act: ActKind | null = null;
45  actAt = -99;
46  thinkAt = -99;
47  carrying = false;
48  asks = 0;
49  cheerUntil = 0;
50  happyUntil = 0;
51  sadUntil = 0;
52  reported = false;
53  delivered = false;
54  left = false;
55  gone = false;
56  animT = 0;
57  nextBlink = 1 + Math.random() * 3;
58  blinkUntil = 0;
59  nextLook = 2 + Math.random() * 3;
60  look: Eyes = 'open';
61  lookUntil = 0;
62  deliverSpot = -1;
63
64  constructor(id: string, role: Role, name: string, x: number, y: number) {
65    this.id = id;
66    this.role = role;
67    this.name = name;
68    this.x = x;
69    this.y = y;
70  }
71
72  get tile(): Tile {
73    if (this.seated && this.seat) return this.seat.tile;
74    return [Math.max(0, Math.floor(this.x / T)), Math.max(0, Math.min(15, Math.floor((this.y - 2) / T)))];
75  }
76
77  /** Le haut de la tête (pour accrocher les bulles). */
78  get head(): Pt { return { x: this.x, y: this.y - 22 }; }
79
80  get busy() { return !!this.cur || this.tasks.length > 0; }
81}
82
83export class World {
84  actors = new Map<string, Actor>();
85  fx = new Fx();
86  grid = walkGrid();
87  private seatOf = new Map<string, string>();
88  private deliverTaken = new Set<number>();
89  time = 0;
90  speed = 1;
91  /** les rapports posés sur le bureau du chef */
92  inbox = 0;
93  printUntil = 0;
94  boardUntil = 0;
95  missionActive = false;
96  plan: PlanItem[] = [];
97  /** qui fait quoi : écrit au tableau, coché quand l'agent a rendu son travail */
98  assignments: { id: string; role: Role; name: string; task: string; status: 'working' | 'done' | 'failed' }[] = [];
99  private planSize = -1;
100  // ── la vie du bureau (et ses œufs de Pâques) ──
101  cat = new Cat();
102  /** la couleur du néon (clique dessus pour en changer) */
103  neonIndex = 0;
104  /** les meubles qui frémissent (plantes…) : identifiant → jusqu'à quand */
105  wiggles = new Map<string, number>();
106  /** les lampes éteintes */
107  lampsOff = new Set<string>();
108  /** le mode soirée (boule à facettes, tout le monde danse) */
109  discoUntil = 0;
110  /** la musique du jukebox : est-ce qu'elle joue, et l'énergie des basses (0 à 1) */
111  musicOn = false;
112  musicLevel = 0;
113  bobUntil = 0;
114  private noteAt = 0;
115  private steamAt = 0;
116  private waveAt = 6;
117  rosterVersion = 0;
118  private rosterListeners = new Set<() => void>();
119
120  constructor() {
121    this.resetAll();
122  }
123
124  get chef() { return this.actors.get('chef')!; }
125
126  onRoster(fn: () => void) { this.rosterListeners.add(fn); return () => this.rosterListeners.delete(fn); }
127  private rosterChanged() {
128    this.rosterVersion++;
129    for (const fn of this.rosterListeners) fn();
130  }
131
132  /** Le bureau vide, Max à l'accueil (début, nouvelle mission, rediffusion). */
133  resetAll() {
134    this.actors.clear();
135    this.seatOf.clear();
136    this.deliverTaken.clear();
137    this.fx = new Fx();
138    this.inbox = 0;
139    this.printUntil = 0;
140    this.boardUntil = 0;
141    this.missionActive = false;
142    this.plan = [];
143    this.assignments = [];
144    this.planSize = -1;
145    const p = SPOTS.receptionPx;
146    this.actors.set('chef', new Actor('chef', 'chef', 'Max', p.x, p.y));
147    this.rosterChanged();
148  }
149
150  // ── Les tâches ──
151  private queue(a: Actor, ...tasks: Task[]) { a.tasks.push(...tasks); }
152
153  private startTask(a: Actor, task: Task) {
154    a.curT = 0;
155    switch (task.t) {
156      case 'walk': {
157        if (a.seated) { a.seated = false; this.standUp(a); }
158        const tiles = findPath(this.grid, a.tile, task.tile);
159        a.path = (tiles ?? [task.tile]).map(tileFeet);
160        if (task.then) a.path.push(task.then);
161        break;
162      }
163      case 'slide':
164        a.path = [task.to];
165        break;
166      case 'sit':
167        a.path = [{ x: task.seat.x, y: task.seat.y }];
168        break;
169      case 'stand':
170        if (a.seated) { a.seated = false; this.standUp(a); }
171        break;
172    }
173  }
174
175  private standUp(a: Actor) {
176    if (!a.seat) return;
177    const f = tileFeet(a.seat.tile);
178    a.x = f.x + (a.seat.x - f.x > 4 ? 6 : 0);
179    a.y = f.y;
180  }
181
182  /** Avance une tâche. Renvoie vrai quand elle est finie. */
183  private runTask(a: Actor, task: Task, dt: number): boolean {
184    switch (task.t) {
185      case 'walk':
186      case 'slide':
187      case 'sit': {
188        const speed = (task.t === 'slide' && task.speed) || (task.t === 'sit' ? 30 : WALK_SPEED);
189        let budget = speed * dt;
190        while (budget > 0 && a.path.length) {
191          const p = a.path[0];
192          const dx = p.x - a.x, dy = p.y - a.y;
193          const d = Math.hypot(dx, dy);
194          if (d > 0.01 && task.t !== 'sit') a.dir = Math.abs(dx) > Math.abs(dy) ? (dx > 0 ? 'right' : 'left') : dy > 0 ? 'down' : 'up';
195          if (d <= budget) { a.x = p.x; a.y = p.y; a.path.shift(); budget -= d; }
196          else { a.x += (dx / d) * budget; a.y += (dy / d) * budget; budget = 0; }
197        }
198        a.moving = a.path.length > 0 && task.t !== 'sit';
199        if (a.path.length) return false;
200        a.moving = false;
201        if (task.t === 'sit') { a.seated = true; a.seat = task.seat; a.dir = 'down'; }
202        else if (task.face) a.dir = task.face;
203        return true;
204      }
205      case 'stand':
206        return true;
207      case 'wait':
208        if (task.dir) a.dir = task.dir;
209        return a.curT * 1000 >= task.ms;
210      case 'call':
211        task.fn();
212        return true;
213      case 'fade': {
214        const step = dt / Math.max(0.05, task.ms / 1000);
215        a.alpha = task.to > a.alpha ? Math.min(task.to, a.alpha + step) : Math.max(task.to, a.alpha - step);
216        return a.alpha === task.to;
217      }
218    }
219  }
220
221  // ── Les places ──
222  private assignSeat(role: Role): Seat | null {
223    const free = (r: Role | null) => SEATS.find((s) => (r === null || s.role === r) && !this.seatOf.has(s.id)) ?? null;
224    return free(role) ?? (role === 'renfort' ? free(null) : null);
225  }
226
227  private overflowSpot(): Tile {
228    const used = new Set([...this.actors.values()].map((a) => a.standSpot?.join(',')).filter(Boolean));
229    return SPOTS.overflow.find((t) => !used.has(t.join(','))) ?? SPOTS.overflow[0];
230  }
231
232  private nearestWindow(a: Actor): Pt {
233    const w = a.x < 176 ? WINDOWS[0] : WINDOWS[1];
234    return { x: w.x + w.w / 2, y: w.y + w.h - 4 };
235  }
236
237  /** Les rapports se posent ici, dans la corbeille du bureau du chef. */
238  get inboxPt(): Pt { return { x: 9 * T + 52, y: 7 * T - 2 }; }
239  get printerPt(): Pt { return { x: 12 * T + 8, y: 4 * T - 4 }; }
240
241  // ── Les événements ──
242  apply(ev: OfficeEvent, live: boolean) {
243    const chef = this.chef;
244    switch (ev.k) {
245      case 'start':
246        this.missionActive = true;
247        chef.thinkAt = this.time;
248        if (live) {
249          if (!chef.seated && !chef.busy) this.queue(chef, { t: 'wait', ms: 500, pose: 'wave', dir: 'down' }, { t: 'walk', tile: CHEF_SEAT.tile }, { t: 'sit', seat: CHEF_SEAT });
250          else if (!chef.seated) this.queue(chef, { t: 'walk', tile: CHEF_SEAT.tile }, { t: 'sit', seat: CHEF_SEAT });
251        } else this.snapSeat(chef, CHEF_SEAT);
252        break;
253      case 'think': {
254        const a = this.actors.get(ev.who);
255        if (a) a.thinkAt = this.time;
256        break;
257      }
258      case 'plan': {
259        this.plan = ev.items;
260        const n = ev.items.length;
261        const fresh = n !== this.planSize;
262        this.planSize = n;
263        if (live && fresh) {
264          // Max va écrire le plan au tableau
265          chef.tasks = chef.tasks.filter((t) => t.t !== 'sit');
266          this.queue(chef,
267            { t: 'walk', tile: SPOTS.board, face: 'up', then: SPOTS.boardPx },
268            { t: 'call', fn: () => { this.boardUntil = this.time + 1.6; } },
269            { t: 'wait', ms: 1600, pose: 'write', dir: 'up' },
270            { t: 'call', fn: () => { this.fx.sparkle(SPOTS.boardPx.x, 24, 10, '#ffffff'); } },
271            { t: 'walk', tile: CHEF_SEAT.tile },
272            { t: 'sit', seat: CHEF_SEAT },
273          );
274        } else if (live) {
275          this.fx.sparkle(SPOTS.boardPx.x + (Math.random() - 0.5) * 60, 22, 5, '#3ddc97');
276        }
277        break;
278      }
279      case 'hire': {
280        if (this.actors.has(ev.id)) break;
281        const seat = this.assignSeat(ev.role);
282        const a = new Actor(ev.id, ev.role, ev.name, SPOTS.doorOut.x - 8 + Math.random() * 16, SPOTS.doorOut.y);
283        if (!this.assignments.some((x) => x.id === ev.id)) this.assignments.push({ id: ev.id, role: ev.role, name: ev.name, task: ev.task, status: 'working' });
284        if (seat) { this.seatOf.set(seat.id, a.id); a.seat = seat; }
285        else a.standSpot = this.overflowSpot();
286        this.actors.set(a.id, a);
287        this.rosterChanged();
288        if (live) {
289          a.alpha = 0;
290          a.dir = 'up';
291          this.fx.beam(SPOTS.doorOut.x, 15 * T + 10);
292          this.queue(a,
293            { t: 'fade', to: 1, ms: 250 },
294            { t: 'slide', to: tileFeet(SPOTS.door), speed: 40 },
295          );
296          if (seat) this.queue(a, { t: 'walk', tile: seat.tile }, { t: 'sit', seat });
297          else this.queue(a, { t: 'walk', tile: a.standSpot!, face: 'down' });
298          // Max se tourne vers celui qu'il appelle
299          chef.happyUntil = this.time + 0.8;
300        } else if (seat) this.snapSeat(a, seat);
301        else { const f = tileFeet(a.standSpot!); a.x = f.x; a.y = f.y; }
302        break;
303      }
304      case 'act': {
305        const a = this.actors.get(ev.who);
306        if (!a) break;
307        a.act = ev.kind;
308        a.actAt = this.time;
309        if (!live) break;
310        this.fx.floatIcon(a.x + (a.seated ? 0 : 1), a.y - 24, iconFor(ev.kind));
311        if (ev.kind === 'search' || ev.kind === 'web') this.fx.data(this.nearestWindow(a), { x: a.x, y: a.y - 8 }, ev.kind === 'web' ? '#3ddc97' : '#7fd6ff');
312        break;
313      }
314      case 'report': {
315        const a = this.actors.get(ev.who);
316        if (!a || a.reported) break;
317        a.reported = true;
318        if (live) this.deliver(a);
319        else this.inbox++;
320        break;
321      }
322      case 'leave': {
323        const asg = this.assignments.find((x) => x.id === ev.who);
324        if (asg) asg.status = ev.ok ? 'done' : 'failed';
325        const a = this.actors.get(ev.who);
326        if (!a || a.left) break;
327        a.left = true;
328        if (!live) { this.remove(a); break; }
329        if (ev.ok && !a.reported) { a.reported = true; this.deliver(a); }
330        if (!ev.ok) a.sadUntil = this.time + 2;
331        this.exit(a);
332        break;
333      }
334      case 'file':
335        if (live) {
336          this.printUntil = this.time + 1.8;
337          this.fx.floatIcon(this.printerPt.x, this.printerPt.y - 6, 'paper');
338        }
339        break;
340      case 'ask': {
341        const a = this.actors.get(ev.who) ?? chef;
342        a.asks++;
343        if (live) this.fx.floatIcon(a.x, a.y - 26, 'alert');
344        break;
345      }
346      case 'ask_done':
347        for (const a of this.actors.values()) if (a.asks > 0) { a.asks = Math.max(0, a.asks - 1); break; }
348        break;
349      case 'end':
350        this.missionActive = false;
351        for (const a of this.actors.values()) if (a !== chef && !a.left) { a.left = true; if (live) this.exit(a); else this.remove(a); }
352        if (live) {
353          if (ev.ok) { this.fx.rain(22 * T); chef.happyUntil = this.time + 3; }
354          chef.tasks = [];
355          this.queue(chef,
356            { t: 'walk', tile: SPOTS.reception, then: SPOTS.receptionPx },
357            { t: 'wait', ms: 100, dir: 'down' },
358            { t: 'call', fn: () => {
359              if (ev.ok) {
360                chef.cheerUntil = this.time + 2.6;
361                this.fx.confetti(chef.x, chef.y - 20, 60);
362              } else chef.sadUntil = this.time + 2.5;
363            } },
364          );
365        } else {
366          chef.tasks = [];
367          chef.cur = null;
368          chef.seated = false;
369          chef.x = SPOTS.receptionPx.x;
370          chef.y = SPOTS.receptionPx.y;
371          chef.dir = 'down';
372        }
373        break;
374      case 'error':
375        chef.sadUntil = this.time + 2;
376        break;
377    }
378  }
379
380  private snapSeat(a: Actor, seat: Seat) {
381    a.tasks = [];
382    a.cur = null;
383    a.seat = seat;
384    a.seated = true;
385    a.x = seat.x;
386    a.y = seat.y;
387    a.dir = 'down';
388    a.alpha = 1;
389  }
390
391  /** Il se lève, prend son rapport et va le poser sur le bureau du chef. */
392  private deliver(a: Actor) {
393    let spot = SPOTS.deliver.findIndex((_, i) => !this.deliverTaken.has(i));
394    if (spot < 0) spot = Math.floor(Math.random() * SPOTS.deliver.length);
395    this.deliverTaken.add(spot);
396    a.deliverSpot = spot;
397    this.queue(a,
398      { t: 'stand' },
399      { t: 'call', fn: () => { a.carrying = true; } },
400      { t: 'walk', tile: SPOTS.deliver[spot], face: 'up' },
401      { t: 'call', fn: () => {
402        a.carrying = false;
403        this.fx.paper({ x: a.x, y: a.y - 12 }, this.inboxPt, () => { this.inbox++; this.fx.sparkle(this.inboxPt.x, this.inboxPt.y, 6, '#ffd2a8'); });
404        a.happyUntil = this.time + 1.2;
405        this.chef.happyUntil = this.time + 1.2;
406      } },
407      { t: 'wait', ms: 700, dir: 'up' },
408      { t: 'call', fn: () => { this.deliverTaken.delete(spot); a.delivered = true; } },
409    );
410  }
411
412  /** Il repart par la porte (et libère son bureau). */
413  private exit(a: Actor) {
414    this.queue(a,
415      { t: 'call', fn: () => { if (a.seat) this.seatOf.delete(a.seat.id); } },
416      { t: 'walk', tile: SPOTS.door },
417      { t: 'call', fn: () => this.fx.beam(SPOTS.doorOut.x, 15 * T + 10) },
418      { t: 'slide', to: { x: a.x, y: SPOTS.doorOut.y }, speed: 40 },
419      { t: 'fade', to: 0, ms: 200 },
420      { t: 'call', fn: () => this.remove(a) },
421    );
422  }
423
424  private remove(a: Actor) {
425    if (a.seat && this.seatOf.get(a.seat.id) === a.id) this.seatOf.delete(a.seat.id);
426    if (a.deliverSpot >= 0) this.deliverTaken.delete(a.deliverSpot);
427    a.gone = true;
428    this.actors.delete(a.id);
429    this.rosterChanged();
430  }
431
432  // ── Une image ──
433  /** Fait avancer le monde. Renvoie vrai si quelque chose bouge (pour savoir à quel rythme redessiner). */
434  update(dtReal: number): boolean {
435    const dt = Math.min(0.1, dtReal) * this.speed;
436    this.time += dt;
437    this.fx.update(dt);
438    let moving = this.fx.busy || this.time < this.printUntil || this.time < this.boardUntil;
439    const chef = this.chef;
440    // la vapeur du café
441    if (this.time > this.steamAt) { this.steamAt = this.time + 0.35; this.fx.steam(16 * T + 11, 13 * T + 4); }
442    // le chat
443    if (this.cat.update(dt, this.time, this.grid, (x, y) => this.fx.floatIcon(x, y, 'zzz'))) moving = true;
444    // le jukebox : des notes qui s'envolent quand il joue
445    if (this.musicOn && this.time > this.noteAt) {
446      this.noteAt = this.time + 0.7 + Math.random() * 0.5;
447      this.fx.floatIcon(14 * T + 10 + Math.random() * 12, 13 * T + 2, Math.random() < 0.5 ? 'note' : 'note2');
448    }
449    if (this.musicOn) moving = true;
450    // le mode soirée : des étincelles, et tout le monde danse
451    if (this.time < this.discoUntil) {
452      moving = true;
453      if (Math.random() < 0.25) this.fx.sparkle(32 + Math.random() * 288, 60 + Math.random() * 160, 2, ['#ff6fa8', '#4fb3ff', '#ffd166', '#3ddc97', '#ff8a3d'][Math.floor(Math.random() * 5)]);
454    }
455    for (const until of this.wiggles.values()) if (until > this.time) moving = true;
456    for (const a of this.actors.values()) {
457      if (a.id.startsWith('demo-') && this.time - a.actAt > 2 + Math.random() * 3) {
458        const kinds: ActKind[] = a.role === 'recherche' ? ['search', 'web'] : a.role === 'code' ? ['write', 'bash'] : a.role === 'analyse' ? ['read', 'write'] : ['write', 'edit'];
459        a.act = kinds[Math.floor(Math.random() * kinds.length)];
460        a.actAt = this.time;
461        this.fx.floatIcon(a.x, a.y - 24, iconFor(a.act));
462      }
463    }
464    // Max salue de temps en temps quand il attend à l'accueil
465    if (!this.missionActive && !chef.busy && !chef.seated && this.time > this.waveAt) {
466      this.waveAt = this.time + 9 + Math.random() * 6;
467      this.queue(chef, { t: 'wait', ms: 1200, pose: 'wave', dir: 'down' });
468    }
469    for (const a of [...this.actors.values()]) {
470      if (!a.cur && a.tasks.length) { a.cur = a.tasks.shift()!; this.startTask(a, a.cur); }
471      if (a.cur) {
472        const task = a.cur;
473        a.curT += dt;
474        if (this.runTask(a, task, dt) && a.cur === task) a.cur = null;
475      }
476      this.animate(a, dt);
477      if (a.moving || a.cur || a.seated || a.cheerUntil > this.time) moving = true;
478    }
479    return moving;
480  }
481
482  // ── Les petits gestes du bureau (quand on clique sur les objets) ──
483  neonNext() {
484    this.neonIndex = (this.neonIndex + 1) % 5;
485    this.fx.sparkle(97 + 12, 11 + 11, 10, '#ffffff');
486  }
487
488  wiggle(id: string, x: number, y: number) {
489    this.wiggles.set(id, this.time + 1.1);
490    this.fx.sparkle(x, y, 6, '#86cf7c');
491  }
492
493  coffee() {
494    for (let i = 0; i < 12; i++) this.fx.steam(16 * T + 9 + Math.random() * 6, 13 * T + 4 - Math.random() * 4);
495    this.fx.floatIcon(16 * T + 12, 13 * T - 2, 'coffee');
496  }
497
498  cooler() {
499    for (let i = 0; i < 6; i++) this.fx.sparkle(9 * T + 8, 3 * T + 4 - i, 1, '#bfe3ff');
500    this.fx.floatIcon(9 * T + 8, 3 * T - 4, 'drop');
501  }
502
503  toggleLamp(id: string) {
504    if (this.lampsOff.has(id)) this.lampsOff.delete(id); else this.lampsOff.add(id);
505  }
506
507  /** Le mode soirée : la boule à facettes descend, et toute l'équipe danse. */
508  disco(seconds = 16) {
509    this.discoUntil = this.time + seconds;
510    for (const a of this.actors.values()) a.cheerUntil = this.discoUntil;
511    this.fx.rain(22 * T, 70);
512  }
513
514  /** Pour la visite guidée sans mission : un agent par coin, assis à son bureau, qui travaille. */
515  demoTeam(on: boolean) {
516    const demo: [string, Role, string][] = [['demo-1', 'recherche', 'Iris'], ['demo-2', 'recherche', 'Hugo'], ['demo-3', 'code', 'Ada'], ['demo-4', 'design', 'Frida'], ['demo-5', 'redaction', 'Colette'], ['demo-6', 'analyse', 'Marie']];
517    if (on) {
518      for (const [id, role, name] of demo) {
519        if (this.actors.has(id)) continue;
520        const seat = this.assignSeat(role);
521        if (!seat) continue;
522        const a = new Actor(id, role, name, seat.x, seat.y);
523        this.seatOf.set(seat.id, id);
524        this.snapSeat(a, seat);
525        a.act = Math.random() < 0.5 ? 'search' : 'write';
526        a.actAt = this.time;
527        this.actors.set(id, a);
528      }
529    } else {
530      for (const [id] of demo) { const a = this.actors.get(id); if (a) this.remove(a); }
531    }
532    this.rosterChanged();
533  }
534
535  petCat() {
536    this.cat.pet(this.time);
537    this.fx.floatIcon(this.cat.x, this.cat.y - 12, 'heart');
538  }
539
540  /** La musique : appelé à chaque image avec l'énergie des basses. */
541  setMusic(on: boolean, level: number, beat: boolean) {
542    this.musicOn = on;
543    this.musicLevel = level;
544    if (beat) this.bobUntil = this.time + 0.12;
545  }
546
547  private animate(a: Actor, dt: number) {
548    a.animT += dt;
549    const t = this.time;
550    const recent = t - a.actAt < 9;
551    let pose: Pose;
552    if (a.cur?.t === 'wait' && a.cur.pose) pose = a.cur.pose;
553    else if (a.moving) pose = a.carrying ? 'carry' : 'walk';
554    else if (a.asks > 0) pose = 'raise';
555    else if (a.cheerUntil > t) pose = 'cheer';
556    else if (a.carrying) pose = 'carry';
557    else if (a.seated) {
558      if (recent && a.act && ['write', 'edit', 'bash', 'plan'].includes(a.act)) pose = 'type';
559      else if (recent) pose = 'read';
560      else pose = 'sit';
561    } else pose = 'stand';
562    if (pose !== a.pose) { a.pose = pose; a.animT = 0; }
563    const ft = a.animT;
564    switch (pose) {
565      case 'walk': a.frame = Math.floor(ft * 8) % 4; break;
566      case 'carry': a.frame = a.moving ? Math.floor(ft * 8) % 4 : 0; break;
567      case 'type': a.frame = Math.floor(ft * 7) % 2; break;
568      case 'cheer': case 'wave': a.frame = Math.floor(ft * 6) % 2; break;
569      case 'raise': a.frame = Math.floor(ft * 3) % 2; break;
570      case 'write': a.frame = Math.floor(ft * 5) % 2; break;
571      default: a.frame = 0;
572    }
573    if (pose === 'carry' && a.moving) {
574      // en marchant avec sa feuille : on garde la pose « porter », jambes en mouvement
575      a.frame = Math.floor(ft * 8) % 4;
576    }
577    // le regard
578    if (t > a.nextBlink) { a.blinkUntil = t + 0.12; a.nextBlink = t + 2.2 + Math.random() * 3.5; }
579    if (t > a.nextLook) {
580      const opts: Eyes[] = ['left', 'right', 'open', 'open', 'up'];
581      a.look = opts[Math.floor(Math.random() * opts.length)];
582      a.lookUntil = t + 0.8 + Math.random() * 0.8;
583      a.nextLook = t + 2.5 + Math.random() * 3;
584    }
585    let eyes: Eyes = 'open';
586    if (a.happyUntil > t || pose === 'cheer') eyes = 'happy';
587    else if (a.sadUntil > t) eyes = 'down';
588    else if (pose === 'type') eyes = 'down';
589    else if (pose === 'read') eyes = Math.floor(ft * 2.2) % 2 ? 'left' : 'right';
590    else if (pose === 'write') eyes = 'up';
591    else if (t - a.thinkAt < 2.5 && !a.moving) eyes = 'up';
592    else if (a.lookUntil > t && !a.moving) eyes = a.look;
593    if (a.blinkUntil > t && eyes !== 'happy') eyes = 'blink';
594    a.eyes = eyes;
595  }
596}
597

1// PNG out of an RGBA buffer, for a hooks module that has no canvas to call toDataURL on: 8-bit RGB, each row
2// filtered with Sub, compressed with deflate (LZ77 over a hash chain, fixed Huffman codes). Pixel art is mostly
3// runs, so a 352 × 256 frame comes out at a few tens of kilobytes.
4
5const CRC = (() => {
6  const t = new Uint32Array(256)
7  for (let n = 0; n < 256; n++) {
8    let c = n
9    for (let k = 0; k < 8; k++) c = c & 1 ? 0xedb88320 ^ (c >>> 1) : c >>> 1
10    t[n] = c >>> 0
11  }
12  return t
13})()
14
15function crc32(bytes: Uint8Array, start: number, end: number): number {
16  let c = 0xffffffff
17  for (let i = start; i < end; i++) c = CRC[(c ^ bytes[i]!) & 255]! ^ (c >>> 8)
18  return (c ^ 0xffffffff) >>> 0
19}
20
21function adler32(bytes: Uint8Array): number {
22  let a = 1
23  let b = 0
24  for (let i = 0; i < bytes.length; i++) {
25    a = (a + bytes[i]!) % 65521
26    b = (b + a) % 65521
27  }
28  return ((b << 16) | a) >>> 0
29}
30
31class Bits {
32  private out: number[] = []
33  private acc = 0
34  private n = 0
35  /** `count` bits of `value`, least significant first, as deflate packs them. */
36  put(value: number, count: number) {
37    for (let i = 0; i < count; i++) {
38      this.acc |= ((value >> i) & 1) << this.n
39      if (++this.n === 8) {
40        this.out.push(this.acc)
41        this.acc = 0
42        this.n = 0
43      }
44    }
45  }
46  /** A Huffman code, most significant bit first. */
47  code(value: number, count: number) {
48    for (let i = count - 1; i >= 0; i--) this.put((value >> i) & 1, 1)
49  }
50  bytes(): Uint8Array {
51    if (this.n > 0) this.out.push(this.acc)
52    return Uint8Array.from(this.out)
53  }
54}
55
56const LEN_BASE = [3, 4, 5, 6, 7, 8, 9, 10, 11, 13, 15, 17, 19, 23, 27, 31, 35, 43, 51, 59, 67, 83, 99, 115, 131, 163, 195, 227, 258]
57const LEN_EXTRA = [0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 1, 2, 2, 2, 2, 3, 3, 3, 3, 4, 4, 4, 4, 5, 5, 5, 5, 0]
58const DIST_BASE = [1, 2, 3, 4, 5, 7, 9, 13, 17, 25, 33, 49, 65, 97, 129, 193, 257, 385, 513, 769, 1025, 1537, 2049, 3073, 4097, 6145, 8193, 12289, 16385, 24577]
59const DIST_EXTRA = [0, 0, 0, 0, 1, 1, 2, 2, 3, 3, 4, 4, 5, 5, 6, 6, 7, 7, 8, 8, 9, 9, 10, 10, 11, 11, 12, 12, 13, 13]
60
61function literal(b: Bits, v: number) {
62  if (v < 144) b.code(0x30 + v, 8)
63  else if (v < 256) b.code(0x190 + v - 144, 9)
64  else if (v < 280) b.code(v - 256, 7)
65  else b.code(0xc0 + v - 280, 8)
66}
67
68function lengthCode(b: Bits, len: number) {
69  let i = LEN_BASE.length - 1
70  while (LEN_BASE[i]! > len) i--
71  literal(b, 257 + i)
72  b.put(len - LEN_BASE[i]!, LEN_EXTRA[i]!)
73}
74
75function distCode(b: Bits, dist: number) {
76  let i = DIST_BASE.length - 1
77  while (DIST_BASE[i]! > dist) i--
78  b.code(i, 5)
79  b.put(dist - DIST_BASE[i]!, DIST_EXTRA[i]!)
80}
81
82/** Raw deflate: one final block of fixed Huffman codes. */
83function deflate(data: Uint8Array): Uint8Array {
84  const b = new Bits()
85  b.put(1, 1) // final block
86  b.put(1, 2) // fixed Huffman
87  const WIN = 32768
88  const head = new Int32Array(1 << 15).fill(-1)
89  const prev = new Int32Array(WIN)
90  const hash = (i: number) => ((data[i]! << 10) ^ (data[i + 1]! << 5) ^ data[i + 2]!) & 0x7fff
91  const insert = (i: number) => {
92    if (i + 2 >= data.length) return
93    const h = hash(i)
94    prev[i % WIN] = head[h]!
95    head[h] = i
96  }
97  let i = 0
98  while (i < data.length) {
99    let bestLen = 0
100    let bestDist = 0
101    if (i + 2 < data.length) {
102      let j = head[hash(i)]!
103      let chain = 48
104      while (j >= 0 && i - j <= WIN && chain-- > 0) {
105        let l = 0
106        while (l < 258 && i + l < data.length && data[j + l] === data[i + l]) l++
107        if (l > bestLen) {
108          bestLen = l
109          bestDist = i - j
110          if (l === 258) break
111        }
112        const nj = prev[j % WIN]!
113        if (nj >= j) break
114        j = nj
115      }
116    }
117    if (bestLen >= 3) {
118      lengthCode(b, bestLen)
119      distCode(b, bestDist)
120      for (let k = 0; k < bestLen; k++) insert(i + k)
121      i += bestLen
122    } else {
123      literal(b, data[i]!)
124      insert(i)
125      i++
126    }
127  }
128  literal(b, 256) // end of block
129  return b.bytes()
130}
131
132function chunk(type: string, body: Uint8Array): Uint8Array {
133  const out = new Uint8Array(12 + body.length)
134  const v = new DataView(out.buffer)
135  v.setUint32(0, body.length)
136  for (let i = 0; i < 4; i++) out[4 + i] = type.charCodeAt(i)
137  out.set(body, 8)
138  v.setUint32(8 + body.length, crc32(out, 4, 8 + body.length))
139  return out
140}
141
142/** A PNG of `w × h` RGBA pixels, alpha dropped (the office is opaque). */
143export function encodePng(rgba: Uint8ClampedArray, w: number, h: number): Uint8Array {
144  // filter Sub on every row: the difference with the pixel to the left, mostly zeros in flat colour
145  const raw = new Uint8Array(h * (1 + w * 3))
146  let k = 0
147  for (let y = 0; y < h; y++) {
148    raw[k++] = 1
149    for (let x = 0; x < w; x++) {
150      const i = (y * w + x) * 4
151      for (let c = 0; c < 3; c++) raw[k++] = (rgba[i + c]! - (x > 0 ? rgba[i - 4 + c]! : 0)) & 255
152    }
153  }
154  const z = deflate(raw)
155  const zlib = new Uint8Array(2 + z.length + 4)
156  zlib[0] = 0x78
157  zlib[1] = 0x01
158  zlib.set(z, 2)
159  new DataView(zlib.buffer).setUint32(2 + z.length, adler32(raw))
160  const ihdr = new Uint8Array(13)
161  const hv = new DataView(ihdr.buffer)
162  hv.setUint32(0, w)
163  hv.setUint32(4, h)
164  ihdr[8] = 8 // bit depth
165  ihdr[9] = 2 // RGB
166  const parts = [Uint8Array.of(137, 80, 78, 71, 13, 10, 26, 10), chunk('IHDR', ihdr), chunk('IDAT', zlib), chunk('IEND', new Uint8Array(0))]
167  const out = new Uint8Array(parts.reduce((n, p) => n + p.length, 0))
168  let o = 0
169  for (const p of parts) {
170    out.set(p, o)
171    o += p.length
172  }
173  return out
174}
175
176const B64 = 'ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/'
177
178export function base64(bytes: Uint8Array): string {
179  let out = ''
180  for (let i = 0; i < bytes.length; i += 3) {
181    const a = bytes[i]!
182    const b = bytes[i + 1]
183    const c = bytes[i + 2]
184    out += B64[a >> 2]! + B64[((a & 3) << 4) | ((b ?? 0) >> 4)]!
185    out += b === undefined ? '=' : B64[((b & 15) << 2) | ((c ?? 0) >> 6)]!
186    out += c === undefined ? '=' : B64[c & 63]!
187  }
188  return out
189}
190

1// A canvas for a hooks module, which has no DOM: just enough of CanvasRenderingContext2D for the office engine of
2// Le Bureau des agents to draw unchanged. Integer pixels on an RGBA buffer, with fillStyle (hex, rgb[a] and radial
3// gradients), fillRect, drawImage, globalAlpha, the source-over, lighter and multiply composites, save/restore,
4// rectangular clips, filled polygons, getImageData, and the translate/scale pair the engine uses to mirror sprites.
5
6type RGBA = [number, number, number, number]
7
8class RadialGradient {
9  private stops: { at: number; c: RGBA }[] = []
10  constructor(
11    readonly x: number,
12    readonly y: number,
13    readonly r: number,
14  ) {}
15  addColorStop(at: number, color: string) {
16    this.stops.push({ at, c: parseColor(color) })
17    this.stops.sort((a, b) => a.at - b.at)
18  }
19  colorAt(px: number, py: number): RGBA {
20    const t = this.r > 0 ? Math.min(1, Math.hypot(px - this.x, py - this.y) / this.r) : 1
21    const s = this.stops
22    if (s.length === 0) return [0, 0, 0, 0]
23    if (t <= s[0]!.at) return s[0]!.c
24    for (let i = 1; i < s.length; i++) {
25      const a = s[i - 1]!
26      const b = s[i]!
27      if (t <= b.at) {
28        const k = b.at > a.at ? (t - a.at) / (b.at - a.at) : 1
29        return [a.c[0] + (b.c[0] - a.c[0]) * k, a.c[1] + (b.c[1] - a.c[1]) * k, a.c[2] + (b.c[2] - a.c[2]) * k, a.c[3] + (b.c[3] - a.c[3]) * k]
30      }
31    }
32    return s[s.length - 1]!.c
33  }
34}
35
36const colorCache = new Map<string, RGBA>()
37
38export function parseColor(s: string): RGBA {
39  const hit = colorCache.get(s)
40  if (hit) return hit
41  let c: RGBA = [0, 0, 0, 1]
42  const t = s.trim()
43  if (t.startsWith('#')) {
44    let h = t.slice(1)
45    if (h.length === 3 || h.length === 4) h = h.split('').map(x => x + x).join('')
46    const n = parseInt(h.slice(0, 6), 16)
47    c = [(n >> 16) & 255, (n >> 8) & 255, n & 255, h.length === 8 ? parseInt(h.slice(6, 8), 16) / 255 : 1]
48  } else {
49    const m = /rgba?\(([^)]+)\)/.exec(t)
50    if (m) {
51      const p = m[1]!.split(',').map(x => parseFloat(x))
52      c = [p[0] ?? 0, p[1] ?? 0, p[2] ?? 0, p[3] ?? 1]
53    } else if (t === 'transparent') c = [0, 0, 0, 0]
54    else if (t === 'white') c = [255, 255, 255, 1]
55    else if (t === 'black') c = [0, 0, 0, 1]
56  }
57  colorCache.set(s, c)
58  return c
59}
60
61type Composite = 'source-over' | 'lighter' | 'multiply'
62type Clip = { x0: number; y0: number; x1: number; y1: number }
63type Saved = { alpha: number; op: Composite; fill: string | RadialGradient; clip: Clip; sx: number; sy: number; tx: number; ty: number }
64
65export class Canvas {
66  data: Uint8ClampedArray
67  private ctx: Ctx | null = null
68  constructor(
69    public width: number,
70    public height: number,
71  ) {
72    this.data = new Uint8ClampedArray(width * height * 4)
73  }
74  getContext(_kind?: string, _opts?: unknown): Ctx {
75    this.ctx ??= new Ctx(this)
76    return this.ctx
77  }
78}
79
80export class Ctx {
81  globalAlpha = 1
82  globalCompositeOperation: Composite = 'source-over'
83  fillStyle: string | RadialGradient = '#000'
84  imageSmoothingEnabled = false
85  private clipR: Clip
86  private stack: Saved[] = []
87  private path: [number, number][][] = []
88  // the only transform the engine uses: translate then scale by ±1, to mirror a sprite
89  private sx = 1
90  private sy = 1
91  private tx = 0
92  private ty = 0
93
94  constructor(readonly canvas: Canvas) {
95    this.clipR = { x0: 0, y0: 0, x1: canvas.width, y1: canvas.height }
96  }
97
98  save() {
99    this.stack.push({ alpha: this.globalAlpha, op: this.globalCompositeOperation, fill: this.fillStyle, clip: { ...this.clipR }, sx: this.sx, sy: this.sy, tx: this.tx, ty: this.ty })
100  }
101  restore() {
102    const s = this.stack.pop()
103    if (!s) return
104    this.globalAlpha = s.alpha
105    this.globalCompositeOperation = s.op
106    this.fillStyle = s.fill
107    this.clipR = s.clip
108    this.sx = s.sx
109    this.sy = s.sy
110    this.tx = s.tx
111    this.ty = s.ty
112  }
113  translate(x: number, y: number) {
114    this.tx += x * this.sx
115    this.ty += y * this.sy
116  }
117  scale(x: number, y: number) {
118    this.sx *= x
119    this.sy *= y
120  }
121
122  createRadialGradient(_x0: number, _y0: number, _r0: number, x1: number, y1: number, r1: number) {
123    return new RadialGradient(x1, y1, r1)
124  }
125
126  /** One device pixel: the colour blended in with the alpha and composite of the moment. */
127  private put(x: number, y: number, c: RGBA) {
128    const cl = this.clipR
129    if (x < cl.x0 || y < cl.y0 || x >= cl.x1 || y >= cl.y1) return
130    const d = this.canvas.data
131    const i = (y * this.canvas.width + x) * 4
132    const a = c[3] * this.globalAlpha
133    if (a <= 0) return
134    const op = this.globalCompositeOperation
135    if (op === 'lighter') {
136      d[i] = d[i]! + c[0] * a
137      d[i + 1] = d[i + 1]! + c[1] * a
138      d[i + 2] = d[i + 2]! + c[2] * a
139      d[i + 3] = d[i + 3]! + a * 255
140      return
141    }
142    if (op === 'multiply') {
143      d[i] = d[i]! * (1 - a) + ((d[i]! * c[0]) / 255) * a
144      d[i + 1] = d[i + 1]! * (1 - a) + ((d[i + 1]! * c[1]) / 255) * a
145      d[i + 2] = d[i + 2]! * (1 - a) + ((d[i + 2]! * c[2]) / 255) * a
146      return
147    }
148    const da = d[i + 3]! / 255
149    const oa = a + da * (1 - a)
150    if (oa <= 0) return
151    d[i] = (c[0] * a + d[i]! * da * (1 - a)) / oa
152    d[i + 1] = (c[1] * a + d[i + 1]! * da * (1 - a)) / oa
153    d[i + 2] = (c[2] * a + d[i + 2]! * da * (1 - a)) / oa
154    d[i + 3] = oa * 255
155  }
156
157  /** A user-space rectangle as device pixels, through the mirror transform. */
158  private span(x: number, y: number, w: number, h: number): Clip {
159    const ax = this.tx + this.sx * x
160    const bx = this.tx + this.sx * (x + w)
161    const ay = this.ty + this.sy * y
162    const by = this.ty + this.sy * (y + h)
163    return { x0: Math.round(Math.min(ax, bx)), x1: Math.round(Math.max(ax, bx)), y0: Math.round(Math.min(ay, by)), y1: Math.round(Math.max(ay, by)) }
164  }
165
166  fillRect(x: number, y: number, w: number, h: number) {
167    const r = this.span(x, y, w, h)
168    const f = this.fillStyle
169    if (typeof f === 'string') {
170      const c = parseColor(f)
171      for (let py = r.y0; py < r.y1; py++) for (let px = r.x0; px < r.x1; px++) this.put(px, py, c)
172    } else {
173      for (let py = r.y0; py < r.y1; py++) for (let px = r.x0; px < r.x1; px++) this.put(px, py, f.colorAt(px + 0.5, py + 0.5))
174    }
175  }
176
177  clearRect(x: number, y: number, w: number, h: number) {
178    const r = this.span(x, y, w, h)
179    const d = this.canvas.data
180    for (let py = Math.max(0, r.y0); py < Math.min(this.canvas.height, r.y1); py++)
181      for (let px = Math.max(0, r.x0); px < Math.min(this.canvas.width, r.x1); px++) d.fill(0, (py * this.canvas.width + px) * 4, (py * this.canvas.width + px) * 4 + 4)
182  }
183
184  drawImage(src: Canvas, ...a: number[]) {
185    let sx = 0
186    let sy = 0
187    let sw = src.width
188    let sh = src.height
189    let dx: number
190    let dy: number
191    let dw: number
192    let dh: number
193    if (a.length >= 8) [sx, sy, sw, sh, dx, dy, dw, dh] = a as [number, number, number, number, number, number, number, number]
194    else if (a.length >= 4) [dx, dy, dw, dh] = a as [number, number, number, number]
195    else {
196      ;[dx, dy] = a as [number, number]
197      dw = sw
198      dh = sh
199    }
200    const r = this.span(dx, dy, dw, dh)
201    const flipX = this.sx < 0
202    const flipY = this.sy < 0
203    const s = src.data
204    const W = r.x1 - r.x0
205    const H = r.y1 - r.y0
206    if (W <= 0 || H <= 0) return
207    const c: RGBA = [0, 0, 0, 0]
208    for (let j = 0; j < H; j++) {
209      const v = flipY ? H - 1 - j : j
210      const syy = Math.floor(sy + (v * sh) / H)
211      if (syy < 0 || syy >= src.height) continue
212      for (let i = 0; i < W; i++) {
213        const u = flipX ? W - 1 - i : i
214        const sxx = Math.floor(sx + (u * sw) / W)
215        if (sxx < 0 || sxx >= src.width) continue
216        const k = (syy * src.width + sxx) * 4
217        const alpha = s[k + 3]!
218        if (alpha === 0) continue
219        c[0] = s[k]!
220        c[1] = s[k + 1]!
221        c[2] = s[k + 2]!
222        c[3] = alpha / 255
223        this.put(r.x0 + i, r.y0 + j, c)
224      }
225    }
226  }
227
228  getImageData(x: number, y: number, w: number, h: number) {
229    const out = new Uint8ClampedArray(w * h * 4)
230    const d = this.canvas.data
231    for (let j = 0; j < h; j++) for (let i = 0; i < w; i++) {
232      const sx = x + i
233      const sy = y + j
234      if (sx < 0 || sy < 0 || sx >= this.canvas.width || sy >= this.canvas.height) continue
235      out.set(d.subarray((sy * this.canvas.width + sx) * 4, (sy * this.canvas.width + sx) * 4 + 4), (j * w + i) * 4)
236    }
237    return { data: out, width: w, height: h }
238  }
239
240  // ── paths: rectangles (for clips) and polygons (filled) ──
241  beginPath() {
242    this.path = []
243  }
244  moveTo(x: number, y: number) {
245    this.path.push([[x, y]])
246  }
247  lineTo(x: number, y: number) {
248    if (this.path.length === 0) this.path.push([])
249    this.path[this.path.length - 1]!.push([x, y])
250  }
251  closePath() {}
252  rect(x: number, y: number, w: number, h: number) {
253    this.path.push([
254      [x, y],
255      [x + w, y],
256      [x + w, y + h],
257      [x, y + h],
258    ])
259  }
260  clip() {
261    // the engine clips to one rectangle at a time: its bounds, met with the clip already set
262    const pts = this.path.flat()
263    if (!pts.length) return
264    const r = this.span(Math.min(...pts.map(p => p[0])), Math.min(...pts.map(p => p[1])), 0, 0)
265    const r2 = this.span(Math.max(...pts.map(p => p[0])), Math.max(...pts.map(p => p[1])), 0, 0)
266    const cl = this.clipR
267    this.clipR = { x0: Math.max(cl.x0, Math.min(r.x0, r2.x0)), y0: Math.max(cl.y0, Math.min(r.y0, r2.y0)), x1: Math.min(cl.x1, Math.max(r.x0, r2.x0)), y1: Math.min(cl.y1, Math.max(r.y0, r2.y0)) }
268  }
269  fill() {
270    const f = this.fillStyle
271    const solid = typeof f === 'string' ? parseColor(f) : null
272    for (const poly of this.path) {
273      if (poly.length < 3) continue
274      const pts = poly.map(([x, y]) => [this.tx + this.sx * x, this.ty + this.sy * y] as [number, number])
275      const y0 = Math.floor(Math.min(...pts.map(p => p[1])))
276      const y1 = Math.ceil(Math.max(...pts.map(p => p[1])))
277      for (let py = y0; py < y1; py++) {
278        const cy = py + 0.5
279        const xs: number[] = []
280        for (let i = 0; i < pts.length; i++) {
281          const [ax, ay] = pts[i]!
282          const [bx, by] = pts[(i + 1) % pts.length]!
283          if ((ay <= cy && by > cy) || (by <= cy && ay > cy)) xs.push(ax + ((cy - ay) / (by - ay)) * (bx - ax))
284        }
285        xs.sort((p, q) => p - q)
286        for (let k = 0; k + 1 < xs.length; k += 2) {
287          for (let px = Math.round(xs[k]!); px < Math.round(xs[k + 1]!); px++) this.put(px, py, solid ?? (f as RadialGradient).colorAt(px + 0.5, cy))
288        }
289      }
290    }
291  }
292}
293
