hush

1// Hush: free radio and any song, in one quiet line above the prompt, with a small
2// DJ Clawd who listens along.
3//
4// Radio comes from bin/hush, a small native helper that streams with the system
5// AVPlayer and listens on a unix socket. Songs come from hum, a free player that plays
6// through YouTube's own embed in a window you can see. Hush starts hum when it is not
7// running and talks to its loopback remote over HTTP. hooks/logic.mjs holds the pure parts.
8//
9//   /music                     start the last station, or pause and resume
10//   /music <song or artist>    play it in hum: /music frank ocean nights
11//   /music next | prev | pause | stop
12//   /music lofi | jazz | chill | classical | nature | radio
13//   /music vol 40
14//   /music clawd               show or hide DJ Clawd
15//   /music big                 switch between the big panel (the default) and the one-line band for songs
16//
17// When Claude asks a permission question the music steps down and Clawd lifts one
18// headphone cup. Both come back when the question is answered. The host reads
19// on(...) and $.noun.method(...) from source, so they are written out in full.
20//
21// The big panel is on by default. It draws the cover, the title, artist, lyric line,
22// progress and buttons while a song plays through hum. The terminal gets cells and an aurora
23// (hooks/panel.mjs holds its pure parts) and a picture where it can show one. The desktop gets
24// one SVG, the stage (hooks/stage.mjs), that moves by itself. Radio keeps the one-line band.
25
26import { stageSvg, STAGE_HEIGHT } from "./stage.mjs";
27import { clamp, duckCommand, humView, livePosition, parseArgs, route, VOLUME_STEP } from "./logic.mjs";
28import {
29  auroraCells,
30  BONE,
31  BONE_DIM,
32  BONE_SOFT,
33  canShowImages,
34  captionLines,
35  chooseLayout,
36  clock,
37  COVER_KEEP,
38  COVER_SCRIPT,
39  coverKey,
40  coverUrls,
41  encodeCells,
42  FALLBACK_ACCENT,
43  FALLBACK_COLORS,
44  fit,
45  fromBase64,
46  hex,
47  mix,
48  PANEL_BG,
49  PANEL_BG_HEX,
50  PANEL_MAX_COLUMNS,
51  PANEL_PAD,
52  palette,
53  panelGeometry,
54  parseBmp,
55  pillColor,
56  placeholderCells,
57  progressRuns,
58  quadrantCells,
59  timeLabels,
60  tone,
61  TRACK,
62} from "./panel.mjs";
63
64const STATIONS = [
65  { id: "lofi", name: "lofi", color: "#d97757", url: "https://radio.nia.nc/radio/8020/lofi-hq-stream.aac" },
66  { id: "jazz", name: "jazz", color: "#e0af68", url: "https://smoothjazz.cdnstream1.com/2585_128.mp3" },
67  { id: "chill", name: "chill", color: "#9b87f5", url: "https://0n-chillout.radionetz.de/0n-chillout.aac" },
68  { id: "classical", name: "classical", color: "#7fb7a0", url: "https://stream.srg-ssr.ch/m/rsc_de/aacp_96" },
69  { id: "nature", name: "nature", color: "#6fa8c7", url: "https://purenature-mynoise.radioca.st/stream" },
70];
71const HUM_COLOR = "#d97757";
72const CLAWD_COLOR = "#d97757";
73
74const RELEASE_URL = "https://github.com/anzal1/hush/releases/latest/download/hush-macos";
75const HUM_INSTALL = "github:anzal1/hum";
76const HUM_DEFAULT_PORT = 3737;
77const POLL_MS = 2500;
78const HUM_POLL_MS = 1000;
79const HUM_STATE_MS = 1500;
80const HUM_PLAY_MS = 25000;
81const HUM_WAIT_MS = 90000;
82// How long /music waits before answering and finishing in the background.
83const ANSWER_MS = 7000;
84const HUM_MISSES = 10;
85const BAR_CELLS = 10;
86const COLLAPSE_CELLS = 4;
87const MAX_COLUMNS = 100;
88const CLAWD_ZONE = 12;
89const AURORA_MS = 125;
90const AURORA_MISSES = 20;
91const AURORA_STALE_MS = 4000;
92const COVER_MS = 30000;
93const PROBE_MS = 1500;
94const EPOCH = Date.now();
95const SESSION = Math.random().toString(36).slice(2, 8);
96
97// What the radio helper last said: { state, station, title, volume, ducked, pos, dur }.
98let status = { state: "off", station: "", title: "", volume: 55, ducked: false, pos: 0, dur: 0 };
99let stationIndex = 0;
100let source = "radio";
101let hum = null;
102let humPort = HUM_DEFAULT_PORT;
103let humMisses = 0;
104let humBusy = false;
105let humDucked = false;
106let humSeen = "";
107let finding = "";
108let timer = null;
109let timerMs = 0;
110let failures = 0;
111let isLit = false;
112let clawdOn = true;
113let big = true; // the panel is the default; /music big toggles the quiet band
114let canImages = false;
115let cover = emptyCover("");
116let panelSite = null;
117let auroraTimer = null;
118let auroraBusy = false;
119let auroraMisses = 0;
120let auroraBlocked = "";
121let lineTimer = null;
122let imagesBlocked = false;
123let probed = "";
124let walk = CLAWD_ZONE - 7;
125let nod = false;
126
127export function register(on) {
128  on("session.start", async ($, e, next) => {
129    const started = await next(e);
130    await $.command.register({
131      name: "music",
132      description: "Free radio and any song above the prompt",
133      argumentHint: "[song or artist | next | prev | pause | stop | lofi | jazz | chill | classical | nature | radio | vol <0-100> | clawd]",
134      immediate: true,
135    });
136    const kept = await $.store.get("station").catch(() => undefined);
137    if (typeof kept === "number" && kept >= 0 && kept < STATIONS.length) {
138      stationIndex = kept;
139    }
140    const saved = await $.store.get("volume").catch(() => undefined);
141    if (typeof saved === "number") {
142      status.volume = saved;
143    }
144    const port = Number.parseInt((await $.env.get("HUM_PORT").catch(() => undefined)) ?? "", 10);
145    humPort = port > 0 && port < 65536 ? port : HUM_DEFAULT_PORT;
146    const clawd = await $.store.get("clawd").catch(() => undefined);
147    if (typeof clawd === "boolean") {
148      clawdOn = clawd;
149    }
150    const wide = await $.store.get("big").catch(() => undefined);
151    if (typeof wide === "boolean") {
152      big = wide;
153    }
154    const term = {
155      TERM_PROGRAM: (await $.env.get("TERM_PROGRAM").catch(() => undefined)) ?? "",
156      TERM: (await $.env.get("TERM").catch(() => undefined)) ?? "",
157      KITTY_WINDOW_ID: (await $.env.get("KITTY_WINDOW_ID").catch(() => undefined)) ?? "",
158      GHOSTTY_RESOURCES_DIR: (await $.env.get("GHOSTTY_RESOURCES_DIR").catch(() => undefined)) ?? "",
159      TMUX: (await $.env.get("TMUX").catch(() => undefined)) ?? "",
160      HUSH_COVER: (await $.env.get("HUSH_COVER").catch(() => undefined)) ?? "",
161    };
162    canImages = canShowImages(term);
163    const running = await ask($, "status");
164    if (running && (running.state === "playing" || running.state === "loading" || running.state === "paused")) {
165      adopt(running);
166      watch($);
167    }
168    return started;
169  });
170
171  // A command hook has ten seconds. Starting hum (the first time it is also downloaded) and
172  // waiting for its tab can take longer, so answer in time and let the rest finish on its own;
173  // the outcome arrives as a toast.
174  on("command.run", { command: "music" }, async ($, e) => {
175    const work = runCommand($, e.args.trim());
176    const text = await Promise.race([work, $.clock.sleep(ANSWER_MS).then(() => null)]);
177    if (text !== null) {
178      return { text };
179    }
180    work.then((t) => t && $.ui.toast(`hush: ${t}`)).catch(() => undefined);
181    return { text: "Starting hum. The song plays in the hum tab once it connects; click that tab once if your browser asks." };
182  });
183
184  // Claude Code's own guard hides classic.PermissionRequest from installed mods, so the
185  // question is caught here instead: the verdict "ask" means a dialog is about to open.
186  on("tool.check", async ($, e, next) => {
187    const verdict = await next(e);
188    if (verdict && verdict.decision === "ask") {
189      await duck($, true);
190    }
191    return verdict;
192  });
193
194  on("tool.call", { tool: "AskUserQuestion" }, async ($, e, next) => {
195    await duck($, true);
196    return next(e);
197  });
198
199  on("tool.call", async ($, e, next) => {
200    if (clawdOn && isPlaying() && !isDucked()) {
201      nod = true;
202      $.ui.invalidate("ui.render");
203      $.clock.after(220, () => {
204        nod = false;
205        $.ui.invalidate("ui.render");
206      });
207    }
208    return next(e);
209  });
210
211  // The classic.* events are hidden from installed mods when an organization guard is loaded, so
212  // the music comes back on events that are not: a tool result being recorded, a turn ending, or
213  // a new prompt.
214  on("session.append", { door: "tool-result" }, async ($, e, next) => {
215    await duck($, false);
216    return next(e);
217  });
218
219  on("turn.complete", async ($, e, next) => {
220    await duck($, false);
221    return next(e);
222  });
223
224  on("prompt.submit", async ($, e, next) => {
225    await duck($, false);
226    return next(e);
227  });
228
229  on("classic.PostToolUse", async ($, e, next) => {
230    await duck($, false);
231    return next(e);
232  });
233
234  on("classic.PostToolUseFailure", async ($, e, next) => {
235    await duck($, false);
236    return next(e);
237  });
238
239  on("classic.PermissionDenied", async ($, e, next) => {
240    await duck($, false);
241    return next(e);
242  });
243
244  on("classic.Stop", async ($, e, next) => {
245    await duck($, false);
246    return next(e);
247  });
248
249  on("classic.UserPromptSubmit", async ($, e, next) => {
250    await duck($, false);
251    return next(e);
252  });
253
254  on("ui.focus", async ($, e, next) => {
255    const wasLit = isLit;
256    isLit = e.component === "AbovePrompt" && e.plugin === $.plugin.name && Boolean(e.element);
257    if (isLit !== wasLit) {
258      $.ui.invalidate("ui.render");
259    }
260    return next(e);
261  });
262
263  on("ui.render", { component: "AbovePrompt" }, async ($, e, next) => {
264    lastSurface = e.surface;
265    if (e.props.hasSurvey || !isActive()) {
266      leavePanel($, e);
267      return next(e);
268    }
269    const ui = $.ui.resolve(e);
270    const width = e.props.bodyColumns ?? 80;
271    const columns = Math.min(width - COLLAPSE_CELLS, MAX_COLUMNS);
272    const panelColumns = Math.min(width - COLLAPSE_CELLS, PANEL_MAX_COLUMNS);
273    const song = source === "hum" && finding === "" ? humView(hum, now()) : null;
274    const layout = chooseLayout({
275      big,
276      isSong: song !== null,
277      surface: e.surface,
278      columns: width,
279      rows: e.props.maxRows ?? 0,
280      canImages: canImages && !imagesBlocked,
281    });
282    const beneath = await next(e);
283    if (layout.mode === "panel") {
284      const drawn = e.surface === "desktop" ? desktopPanel($, ui, song, columns) : terminalPanel($, ui, e, layout, song, panelColumns);
285      return ui.Box({ flexDirection: "column", children: [drawn, beneath] });
286    }
287    leavePanel($, e);
288    return ui.Box({ flexDirection: "column", children: [band($, ui, columns), beneath] });
289  });
290
291  on("session.end", async ($, e, next) => {
292    await duck($, false);
293    stop();
294    return next(e);
295  });
296}
297
298// ---------- helper process ----------
299
300async function paths($) {
301  const home = await $.env.get("HOME");
302  const dir = `${home}/.claude/hush`;
303  return { bin: `${$.plugin.root}/bin/hush`, socket: `${dir}/h.sock` };
304}
305
306// Sends one command; resolves the helper's JSON reply, or null when it is not running.
307async function ask($, command) {
308  const { bin, socket } = await paths($);
309  try {
310    const run = await $.process.run([bin, "ctl", socket, command], { timeoutMs: 4000 });
311    if (run.exitCode !== 0) {
312      return null;
313    }
314    return JSON.parse(run.stdout.trim());
315  } catch {
316    return null;
317  }
318}
319
320async function exists($, path) {
321  const run = await $.process.run(["/bin/test", "-x", path]).catch(() => ({ exitCode: 1 }));
322  return run.exitCode === 0;
323}
324
325// Makes sure the helper runs, building it from source (or downloading it) when the binary is missing.
326async function ensureHelper($) {
327  if (await ask($, "status")) {
328    return true;
329  }
330  const { bin, socket } = await paths($);
331  const root = $.plugin.root;
332  if (!(await exists($, bin))) {
333    const built = (await exists($, "/usr/bin/swiftc"))
334      ? await $.process
335          .run(["/usr/bin/swiftc", "-O", `${root}/native/hush.swift`, "-o", bin], { timeoutMs: 180000 })
336          .catch(() => ({ exitCode: 1 }))
337      : await download($, RELEASE_URL, bin);
338    if (built.exitCode !== 0) {
339      return false;
340    }
341  }
342  await $.process.run(
343    ["/bin/sh", "-c", 'mkdir -p "$(dirname "$1")"; nohup "$0" daemon "$1" >/dev/null 2>&1 &', bin, socket],
344    { timeoutMs: 5000 },
345  );
346  for (let i = 0; i < 25; i += 1) {
347    await $.clock.sleep(120);
348    if (await ask($, "status")) {
349      return true;
350    }
351  }
352  return false;
353}
354
355async function download($, url, target) {
356  return $.process
357    .run(["/bin/sh", "-c", 'mkdir -p "$(dirname "$2")" && curl -fsSL "$1" -o "$2" && chmod +x "$2"', "sh", url, target], {
358      timeoutMs: 240000,
359    })
360    .catch(() => ({ exitCode: 1 }));
361}
362
363// ---------- hum ----------
364
365function humUrl(path) {
366  return `http://127.0.0.1:${humPort}${path}`;
367}
368
369function now() {
370  return Date.now();
371}
372
373// One request to hum's loopback remote. Resolves the parsed JSON, or null when hum does not answer in time.
374async function humFetch($, path, init, ms) {
375  let timeout;
376  const late = new Promise((resolve) => {
377    timeout = $.clock.after(ms, () => resolve(null));
378  });
379  const reply = await Promise.race([$.http.fetch(humUrl(path), init).catch(() => null), late]);
380  timeout.cancel();
381  if (!reply || !reply.ok) {
382    return null;
383  }
384  try {
385    return JSON.parse(reply.text);
386  } catch {
387    return null;
388  }
389}
390
391async function humState($) {
392  return humFetch($, "/api/remote/state", undefined, HUM_STATE_MS);
393}
394
395async function humSend($, body, ms = HUM_STATE_MS) {
396  const init = { method: "POST", headers: { "content-type": "application/json" }, body: JSON.stringify(body) };
397  return humFetch($, "/api/remote", init, ms);
398}
399
400// Puts npx on PATH however Node was installed. A mod's shell does not load the person's shell
401// setup, so a Node that only nvm, Volta, fnm, mise or asdf knows about is otherwise invisible;
402// the last resort asks the person's own login shell where npx is.
403const FIND_NODE = [
404  'H="${HOME:-$(cd ~ && pwd)}";',
405  'PATH="$PATH:/opt/homebrew/bin:/usr/local/bin:$H/.volta/bin:$H/.local/share/mise/shims:$H/.asdf/shims";',
406  'd=$(ls -1d "$H"/.nvm/versions/node/*/bin "$H"/.local/share/fnm/node-versions/*/installation/bin "$H/Library/Application Support/fnm/node-versions"/*/installation/bin 2>/dev/null | sort -r | while IFS= read -r x; do [ -x "$x/npx" ] && { echo "$x"; break; }; done);',
407  '[ -n "$d" ] && PATH="$d:$PATH";',
408  'command -v npx >/dev/null 2>&1 || { p=$("${SHELL:-/bin/zsh}" -ilc "command -v npx" 2>/dev/null | tail -1); [ -n "$p" ] && PATH="$(dirname "$p"):$PATH"; };',
409  "",
410].join(" ");
411
412// Starts hum's server, detached. hum only opens its own tab when it has a terminal, so
413// HUM_NO_OPEN is set and Hush opens the visible player itself once the server answers.
414async function startHum($) {
415  await $.process
416    .run(
417      [
418        "/bin/sh",
419        "-c",
420        FIND_NODE + 'HUM_NO_OPEN=1 PORT="$1" nohup npx -y -p "$2" hum >/dev/null 2>&1 &',
421        "sh",
422        String(humPort),
423        HUM_INSTALL,
424      ],
425      { timeoutMs: 5000 },
426    )
427    .catch(() => undefined);
428}
429
430async function openHum($) {
431  await $.process.run(["/usr/bin/open", `http://localhost:${humPort}`], { timeoutMs: 5000 }).catch(() => undefined);
432}
433
434// Makes sure a hum window is open: starts the server when nothing answers, opens the player
435// when the server has no window, then waits for a window to connect.
436async function ensureHum($) {
437  let state = await humState($);
438  if (state && state.connected > 0) {
439    return "";
440  }
441  finding = "opening hum…";
442  $.ui.invalidate("ui.render");
443  if (!state) {
444    await startHum($);
445  }
446  let opened = false;
447  for (let waited = 0; ; waited += 500) {
448    if (state && state.connected > 0) {
449      return "";
450    }
451    if (state && !opened) {
452      await openHum($);
453      opened = true;
454    }
455    if (waited >= HUM_WAIT_MS) {
456      break;
457    }
458    await $.clock.sleep(500);
459    state = await humState($);
460  }
461  if (state) {
462    return `hum is running but its player window is not open. Open http://localhost:${humPort} and run /music again.`;
463  }
464  return `hum needs to be open to play songs. Start it with: npx -y -p ${HUM_INSTALL} hum, then run /music again.`;
465}
466
467// Sends a song to hum, which plays it in its own visible YouTube player.
468async function playOnHum($, cmd) {
469  finding = `finding ${cmd.query}…`;
470  $.ui.invalidate("ui.render");
471  try {
472    const problem = await ensureHum($);
473    if (problem) {
474      return problem;
475    }
476    finding = `finding ${cmd.query}…`;
477    $.ui.invalidate("ui.render");
478    await quietRadio($);
479    const reply = await humSend($, cmd, HUM_PLAY_MS);
480    if (!reply) {
481      return "hum did not answer. Check that its player window is still open.";
482    }
483    if (!reply.ok) {
484      return reply.text || "hum could not play that.";
485    }
486    source = "hum";
487    humMisses = 0;
488    humSeen = "";
489    hum = (await humState($)) ?? hum;
490    watch($);
491    cue($);
492    wantCover($);
493    return reply.text || `Playing ${cmd.query} in hum`;
494  } finally {
495    finding = "";
496    $.ui.invalidate("ui.render");
497  }
498}
499
500// Stops the radio before a song starts, so the two never play together.
501async function quietRadio($) {
502  stopTimer();
503  if (status.state === "playing" || status.state === "loading" || status.state === "paused") {
504    await ask($, "stop");
505  }
506  status = { ...status, state: "off", title: "", ducked: false, pos: 0, dur: 0 };
507}
508
509// Hands the sound back to the radio: hum is paused (and restored if it was stepped down).
510async function leaveHum($) {
511  if (source !== "hum") {
512    return;
513  }
514  const view = humView(hum, now());
515  if (view && view.state === "playing") {
516    await humSend($, { cmd: "pause" });
517  }
518  if (humDucked) {
519    await humSend($, { cmd: "unduck" });
520  }
521  dropHum();
522}
523
524function dropHum() {
525  stopTimer();
526  stopAurora();
527  stopLine();
528  cover = emptyCover("");
529  source = "radio";
530  hum = null;
531  humDucked = false;
532  humMisses = 0;
533  humSeen = "";
534}
535
536async function pollHum($) {
537  if (humBusy || source !== "hum") {
538    return;
539  }
540  humBusy = true;
541  try {
542    const state = await humState($);
543    if (source !== "hum") {
544      return;
545    }
546    const view = humView(state, now());
547    if (!view) {
548      humMisses += 1;
549      if (state) {
550        hum = state;
551      }
552      if (humMisses >= HUM_MISSES) {
553        stop();
554      }
555      $.ui.invalidate("ui.render");
556      return;
557    }
558    humMisses = 0;
559    const before = humView(hum, now());
560    hum = state;
561    if (!before || before.title !== view.title) {
562      cue($);
563    }
564    wantCover($);
565    syncAurora($);
566    // the desktop picture carries the lyric and the time itself; a redraw there only for what it cannot know
567    const seen =
568      lastSurface === "desktop" && big
569        ? [view.name, view.album, view.upNext, view.state, view.ducked, view.volume, view.hasLyrics, cover.key, Boolean(cover.jpg)].join("|")
570        : [view.name, view.line, view.next, view.album, view.upNext, view.state, view.ducked, view.volume, Math.floor(view.pos)].join("|");
571    if (seen !== humSeen) {
572      humSeen = seen;
573      $.ui.invalidate("ui.render");
574    }
575    scheduleLine($, view);
576  } finally {
577    humBusy = false;
578  }
579}
580
581// ---------- commands ----------
582
583async function runCommand($, args) {
584  return perform($, parseArgs(args, STATIONS.map((s) => s.id)));
585}
586
587// Works out what an intent means for the current source, then does it.
588async function perform($, intent) {
589  const view = humView(hum, now());
590  const plan = route(intent, {
591    source,
592    humLive: view !== null,
593    radioActive: isActive(),
594    radioVolume: status.volume,
595    humVolume: view ? view.volume : 0,
596    stationIndex,
597  });
598  if (plan.target === "hum") {
599    return performHum($, plan);
600  }
601  if (plan.target === "radio") {
602    return performRadio($, plan);
603  }
604  if (plan.action === "big") {
605    big = !big;
606    await $.store.set("big", big).catch(() => undefined);
607    if (big) {
608      wantCover($);
609    } else {
610      panelSite = null;
611      auroraBlocked = "";
612      stopAurora();
613    }
614    $.ui.invalidate("ui.render");
615    return big
616      ? "Big panel on. Songs through hum get it; radio keeps its band"
617      : "Big panel off. Back to the one-line band";
618  }
619  clawdOn = !clawdOn;
620  await $.store.set("clawd", clawdOn).catch(() => undefined);
621  $.ui.invalidate("ui.render");
622  return clawdOn ? "DJ Clawd is back" : "DJ Clawd is off";
623}
624
625async function performHum($, plan) {
626  if (plan.action === "play") {
627    return playOnHum($, plan.cmd);
628  }
629  if (plan.action === "volume") {
630    if (!plan.cmd) {
631      return `Volume is ${humView(hum, now())?.volume ?? 0}. Use /music vol 0-100`;
632    }
633    hum = { ...hum, volume: plan.level };
634    $.ui.invalidate("ui.render");
635    await humSend($, plan.cmd);
636    return `Volume ${plan.level}`;
637  }
638  const reply = await humSend($, plan.cmd);
639  if (plan.action === "stop") {
640    dropHum();
641    $.ui.invalidate("ui.render");
642    return "Music stopped";
643  }
644  if (!reply) {
645    return "hum did not answer. Check that its player window is still open.";
646  }
647  if (!reply.ok) {
648    return reply.text || "hum could not do that.";
649  }
650  if (plan.action === "next" || plan.action === "prev") {
651    return reply.text || (plan.action === "next" ? "Next song" : "Previous song");
652  }
653  const playing = plan.cmd.cmd === "resume" || (plan.cmd.cmd === "toggle" && hum && !hum.playing);
654  hum = { ...hum, playing, position: livePosition(hum, now()), at: now() };
655  syncAurora($);
656  $.ui.invalidate("ui.render");
657  return playing ? "Playing" : "Paused";
658}
659
660async function performRadio($, plan) {
661  await leaveHum($);
662  if (plan.action === "station") {
663    return startStation($, plan.index);
664  }
665  if (plan.action === "next") {
666    return startStation($, stationIndex + 1);
667  }
668  if (plan.action === "prev") {
669    return startStation($, stationIndex - 1);
670  }
671  if (plan.action === "stop") {
672    await ask($, "stop");
673    stop();
674    $.ui.invalidate("ui.render");
675    return "Music stopped";
676  }
677  if (plan.action === "volume") {
678    if (plan.level === null) {
679      return `Volume is ${status.volume}. Use /music vol 0-100`;
680    }
681    await setVolume($, plan.level);
682    return `Volume ${status.volume}`;
683  }
684  return toggle($);
685}
686
687async function toggle($) {
688  await togglePause($);
689  return status.state === "paused" ? "Paused" : "Playing";
690}
691
692async function startStation($, index) {
693  stationIndex = (index + STATIONS.length) % STATIONS.length;
694  const station = STATIONS[stationIndex];
695  if (!(await ensureHelper($))) {
696    return "Hush could not start its player. It needs macOS, and either Xcode's command line tools or a network connection to GitHub.";
697  }
698  await ask($, `vol ${status.volume}`);
699  await ask($, "resume");
700  const reply = await ask($, `play ${station.url} ${station.name}`);
701  if (reply) {
702    adopt(reply);
703  }
704  await $.store.set("station", stationIndex).catch(() => undefined);
705  watch($);
706  cue($);
707  $.ui.invalidate("ui.render");
708  return `Playing ${station.name}. ctrl+x tab for controls`;
709}
710
711async function togglePause($) {
712  const paused = status.state === "paused";
713  const reply = await ask($, paused ? "resume" : "pause");
714  if (reply) {
715    adopt(reply);
716  }
717  $.ui.invalidate("ui.render");
718}
719
720async function setVolume($, value) {
721  const clamped = clamp(value, 0, 100);
722  status = { ...status, volume: clamped };
723  await ask($, `vol ${clamped}`);
724  await $.store.set("volume", clamped).catch(() => undefined);
725  $.ui.invalidate("ui.render");
726}
727
728// Steps the sound down for a question and back up after, on whichever source is playing.
729async function duck($, wanted) {
730  if (source === "hum") {
731    const body = duckCommand(wanted, humDucked);
732    if (!body || (wanted && !isActive())) {
733      return;
734    }
735    humDucked = wanted;
736    if (hum) {
737      hum = { ...hum, ducked: wanted };
738    }
739    syncAurora($);
740    $.ui.invalidate("ui.render");
741    await humSend($, body);
742    return;
743  }
744  if (!isActive() || status.ducked === wanted) {
745    return;
746  }
747  status = { ...status, ducked: wanted };
748  $.ui.invalidate("ui.render");
749  await ask($, `${wanted ? "duck" : "unduck"} ${SESSION}`);
750}
751
752// ---------- state ----------
753
754function isActive() {
755  if (finding !== "") {
756    return true;
757  }
758  if (source === "hum") {
759    return humView(hum, now()) !== null;
760  }
761  return status.state === "playing" || status.state === "loading" || status.state === "paused";
762}
763
764function isPlaying() {
765  if (source === "hum") {
766    return humView(hum, now())?.state === "playing";
767  }
768  return status.state === "playing";
769}
770
771function isDucked() {
772  return source === "hum" ? humDucked || Boolean(hum?.ducked) : status.ducked;
773}
774
775function adopt(reply) {
776  const index = STATIONS.findIndex((s) => s.name === reply.station);
777  if (index >= 0) {
778    stationIndex = index;
779  }
780  status = { ...status, ...reply };
781}
782
783// Polls the source that is playing: the radio helper every 2.5 s, hum every second.
784function watch($) {
785  const ms = source === "hum" ? HUM_POLL_MS : POLL_MS;
786  if (timer && timerMs === ms) {
787    return;
788  }
789  stopTimer();
790  timerMs = ms;
791  timer = $.clock.every(ms, () => {
792    void (source === "hum" ? pollHum($) : poll($));
793  });
794}
795
796function stopTimer() {
797  if (timer) {
798    timer.cancel();
799    timer = null;
800  }
801}
802
803function stop() {
804  dropHum();
805  finding = "";
806  status = { ...status, state: "off", title: "", ducked: false, pos: 0, dur: 0 };
807}
808
809async function poll($) {
810  const reply = await ask($, "status");
811  if (!reply || reply.state === "idle") {
812    stop();
813    $.ui.invalidate("ui.render");
814    return;
815  }
816  if (reply.state === "failed") {
817    failures += 1;
818    if (failures <= STATIONS.length) {
819      await startStation($, stationIndex + 1);
820      return;
821    }
822    stop();
823    await ask($, "stop");
824    $.ui.invalidate("ui.render");
825    return;
826  }
827  failures = 0;
828  const moved = reply.state === "playing" && Math.abs((reply.pos ?? 0) - (status.pos ?? 0)) >= 2;
829  const changed = reply.state !== status.state || reply.title !== status.title || reply.ducked !== status.ducked || moved;
830  adopt(reply);
831  if (changed) {
832    $.ui.invalidate("ui.render");
833  }
834}
835
836// DJ Clawd walks in from the left of his spot whenever a new song or station starts.
837function cue($) {
838  if (!clawdOn) {
839    return;
840  }
841  walk = 0;
842  const step = () => {
843    walk += 1;
844    $.ui.invalidate("ui.render");
845    if (walk < CLAWD_ZONE - 7) {
846      $.clock.after(120, step);
847    }
848  };
849  $.clock.after(120, step);
850}
851
852// ---------- drawing ----------
853
854// A hotkey makes the engine draw a "h:" prefix, so only the focused band carries them.
855function keyed(letter) {
856  return isLit ? { hotkey: letter } : {};
857}
858
859// DJ Clawd: the banner mascot's head with headphones. One cup lifts when you are being asked something.
860function clawdFace() {
861  if (isDucked()) {
862    return "(▐▛█▜▌ '";
863  }
864  return nod ? "(▐▙█▟▌)" : "(▐▛█▜▌)";
865}
866
867// One line: note, title, a tag, a bar, buttons, DJ Clawd. Narrower terminals drop the
868// bar first, then the tag, then DJ Clawd, then the buttons.
869function band($, ui, columns) {
870  const { Box, Text, Button } = ui;
871  const song = source === "hum" ? humView(hum, now()) : null;
872  const isSong = song !== null;
873  const view = song ?? status;
874  const station = STATIONS[stationIndex];
875  const accent = isSong ? HUM_COLOR : station.color;
876  const ducked = isDucked();
877  const quiet = ducked || view.state === "paused";
878  const loading = finding !== "" || view.state === "loading";
879  let title = status.title || `${station.name} radio`;
880  if (finding) {
881    title = finding;
882  } else if (isSong) {
883    title = song.name;
884  } else if (status.state === "loading") {
885    title = "tuning…";
886  }
887  const tag = isSong ? (view.dur > 0 ? `${clock(view.pos)} / ${clock(view.dur)}` : "") : `${station.name} · live`;
888  // A song with lyrics gives the bar's room to the lyric line; the clock in the tag shows progress.
889  const showBar = columns >= 70 && !(isSong && song.hasLyrics);
890  const showTag = columns >= 56 && tag !== "";
891  const showButtons = columns >= 44;
892  const showClawd = clawdOn && columns >= 84 && view.state === "playing" && !finding;
893  const lit = isLit && showButtons;
894  const showVolButtons = lit && columns >= 70;
895  const barText = showBar ? BAR_CELLS + 1 : 0;
896  const tagText = showTag ? tag.length + 2 : 0;
897  let buttonsText = 0;
898  if (showButtons) {
899    buttonsText = showVolButtons ? 40 : lit ? 24 : 12;
900  }
901  const clawdText = showClawd ? CLAWD_ZONE + 2 : 0;
902  const titleCells = Math.max(8, columns - 2 - tagText - barText - buttonsText - clawdText - 1);
903
904  const parts = [Text({ color: accent, dimColor: quiet, children: "♪ " })];
905  if (isSong && song.hasLyrics && !finding && titleCells >= 40) {
906    // Title and artist keep a fixed share, so the buttons stay put while the lyric changes.
907    const nameCells = Math.min(song.name.length, Math.max(16, Math.floor(titleCells * 0.5)));
908    const lyricCells = titleCells - nameCells - 2;
909    parts.push(Text({ dimColor: quiet, children: fit(song.name, nameCells).padEnd(nameCells) }));
910    parts.push(Text({ children: "  " }));
911    parts.push(Text({ color: accent, dimColor: quiet, italic: true, children: fit(song.line, lyricCells).padEnd(lyricCells) }));
912  } else {
913    parts.push(Text({ dimColor: quiet || loading, children: fit(title, titleCells).padEnd(titleCells) }));
914  }
915  if (showTag) {
916    parts.push(Text({ dimColor: true, children: `  ${tag}` }));
917  }
918  if (showBar) {
919    let filled;
920    if (isSong) {
921      filled = view.dur > 0 ? Math.round((view.pos / view.dur) * BAR_CELLS) : 0;
922    } else {
923      const effective = ducked ? Math.round(status.volume * 0.35) : status.volume;
924      filled = status.state === "paused" ? 0 : Math.round((effective / 100) * BAR_CELLS);
925    }
926    filled = clamp(filled, 0, BAR_CELLS);
927    parts.push(Text({ children: " " }));
928    parts.push(Text({ color: accent, dimColor: quiet, children: "━".repeat(filled) }));
929    parts.push(Text({ dimColor: true, children: "─".repeat(BAR_CELLS - filled) }));
930  }
931  if (showButtons) {
932    parts.push(Text({ children: "  " }));
933    parts.push(
934      Button({ key: "prev", label: "‹", ...keyed("h"), plain: true, dimColor: !lit, onPress: () => void press($, "prev") }),
935    );
936    parts.push(Text({ children: " " }));
937    parts.push(
938      Button({
939        key: "play",
940        label: view.state === "paused" ? "play" : "pause",
941        ...keyed("p"),
942        plain: true,
943        autoFocus: true,
944        dimColor: !lit,
945        onPress: () => void press($, "pause"),
946      }),
947    );
948    parts.push(Text({ children: " " }));
949    parts.push(
950      Button({ key: "next", label: "›", ...keyed("l"), plain: true, dimColor: !lit, onPress: () => void press($, "next") }),
951    );
952    if (showVolButtons) {
953      parts.push(Text({ children: "  " }));
954      parts.push(Button({ key: "down", label: "-", hotkey: "j", plain: true, onPress: () => void press($, "down") }));
955      parts.push(Text({ dimColor: true, children: ` vol ${view.volume} ` }));
956      parts.push(Button({ key: "up", label: "+", hotkey: "k", plain: true, onPress: () => void press($, "up") }));
957    }
958  }
959  if (showClawd) {
960    parts.push(Text({ children: " ".repeat(Math.max(1, walk + 1)) }));
961    parts.push(Text({ color: CLAWD_COLOR, children: clawdFace() }));
962  }
963  const row = Box({ flexDirection: "row", paddingX: 1, children: parts });
964  if (!lit) {
965    return row;
966  }
967  const hint = Text({
968    dimColor: true,
969    children: showVolButtons
970      ? ` p pause · h l ${isSong ? "song" : "station"} · j k volume · esc back to the prompt`
971      : ` p pause · h l ${isSong ? "song" : "station"} · esc back to the prompt`,
972  });
973  return Box({ flexDirection: "column", children: [row, hint] });
974}
975
976// ---------- big panel ----------
977
978function emptyCover(key) {
979  return { key, state: "none", png: "", jpg: "", thumb: null, cells: "", cellsKey: "", colors: FALLBACK_COLORS, accent: FALLBACK_ACCENT };
980}
981
982// Starts reading the cover of the song that plays, when the big panel is on and it is a new song.
983// The work runs in the background; the panel draws a stand-in until the cover is ready.
984function wantCover($) {
985  if (!big || source !== "hum" || !hum || !hum.track) {
986    return;
987  }
988  const key = coverKey(hum.track);
989  if (cover.key === key) {
990    return;
991  }
992  cover = emptyCover(key);
993  void loadCover($, key, hum.track);
994}
995
996// Downloads the cover and makes its files with sips (see COVER_SCRIPT), then reads them.
997async function loadCover($, key, track) {
998  const home = await $.env.get("HOME").catch(() => undefined);
999  const urls = coverUrls(track);
1000  let found = null;
1001  if (home && urls.length > 0) {
1002    const root = `${home}/.claude/hush/art`;
1003    const dir = `${root}/${key}`;
1004    const run = await $.process
1005      .run(["/bin/sh", "-c", COVER_SCRIPT, "sh", dir, root, String(COVER_KEEP), ...urls], { timeoutMs: COVER_MS })
1006      .catch(() => ({ exitCode: 1 }));
1007    if (run.exitCode === 0) {
1008      found = await readCover($, dir);
1009    }
1010  }
1011  if (cover.key !== key) {
1012    return;
1013  }
1014  cover = found ? { ...emptyCover(key), ...found, state: "ready" } : emptyCover(key);
1015  $.ui.invalidate("ui.render");
1016}
1017
1018async function readCover($, dir) {
1019  try {
1020    const small = await $.fs.read(`${dir}/cells.bmp`, { as: "bytes" });
1021    const image = parseBmp(fromBase64(small.base64));
1022    if (!image) {
1023      return null;
1024    }
1025    const jpg = await $.fs.read(`${dir}/cover.jpg`, { as: "bytes" });
1026    const png = canImages ? await $.fs.read(`${dir}/cover.png`, { as: "bytes" }) : { base64: "" };
1027    const found = palette(image.rgba);
1028    // The pixels are kept, and cut to cells when drawn, since the cover's size follows the room.
1029    return { png: png.base64, jpg: jpg.base64, thumb: image, colors: found.colors, accent: found.accent };
1030  } catch {
1031    return null;
1032  }
1033}
1034
1035// The cover as cells at the size asked for, made once per size.
1036function coverCells(geo) {
1037  const key = `${geo.cover}x${geo.rows}`;
1038  if (cover.cellsKey !== key) {
1039    cover.cellsKey = key;
1040    const words = cover.thumb
1041      ? quadrantCells(cover.thumb.rgba, cover.thumb.width, cover.thumb.height, geo.cover, geo.rows)
1042      : placeholderCells(geo.cover, geo.rows, cover.colors);
1043    cover.cells = encodeCells(words);
1044  }
1045  return cover.cells;
1046}
1047
1048// The aurora moves while the terminal panel is on screen and the song plays: one Raster
1049// repainted about eight times a second with $.ui.blit, never the whole tree. It stops when the
1050// music is paused or stepped down, the panel is replaced, or the band has not been drawn for a while.
1051function auroraTime() {
1052  return (now() - EPOCH) / 1000;
1053}
1054
1055function syncAurora($) {
1056  const wanted = panelSite !== null && siteKey(panelSite) !== auroraBlocked && source === "hum" && isPlaying() && !isDucked();
1057  if (!wanted) {
1058    stopAurora();
1059    return;
1060  }
1061  if (!auroraTimer) {
1062    auroraTimer = $.clock.every(AURORA_MS, () => {
1063      void auroraFrame($);
1064    });
1065  }
1066}
1067
1068// A surface that keeps refusing the blits is left alone until the panel is drawn again from scratch.
1069function siteKey(site) {
1070  return `${site.requestId}:${site.columns}x${site.rows}`;
1071}
1072
1073function stopAurora() {
1074  if (auroraTimer) {
1075    auroraTimer.cancel();
1076    auroraTimer = null;
1077  }
1078  auroraMisses = 0;
1079}
1080
1081// The next lyric line is drawn the moment it starts, not at the next poll: when it is due within
1082// the next second and a bit, the tree is drawn again then.
1083function scheduleLine($, view) {
1084  stopLine();
1085  if (lastSurface === "desktop" && big) {
1086    return;
1087  }
1088  if (view.state !== "playing" || typeof view.nextIn !== "number" || view.nextIn > 1.4) {
1089    return;
1090  }
1091  lineTimer = $.clock.after(Math.max(30, Math.round(view.nextIn * 1000) + 30), () => {
1092    lineTimer = null;
1093    $.ui.invalidate("ui.render");
1094  });
1095}
1096
1097function stopLine() {
1098  if (lineTimer) {
1099    lineTimer.cancel();
1100    lineTimer = null;
1101  }
1102}
1103
1104async function auroraFrame($) {
1105  const site = panelSite;
1106  if (auroraBusy) {
1107    return;
1108  }
1109  if (!site || now() - site.at > AURORA_STALE_MS) {
1110    stopAurora();
1111    return;
1112  }
1113  auroraBusy = true;
1114  try {
1115    const cells = encodeCells(auroraCells(site.columns, site.rows, auroraTime(), cover.colors, 1));
1116    const result = await $.ui.blit({ requestId: site.requestId, key: "aurora", cells, columns: site.columns, rows: site.rows });
1117    auroraMisses = result && result.deny ? auroraMisses + 1 : 0;
1118  } catch {
1119    auroraMisses += 1;
1120  } finally {
1121    auroraBusy = false;
1122  }
1123  if (auroraMisses >= AURORA_MISSES) {
1124    auroraBlocked = siteKey(site);
1125    stopAurora();
1126  }
1127}
1128
1129// The terminal's name in the environment is only a hint: the engine decides whether it really
1130// draws pictures, and a blit is refused when it draws the alt instead. When that stays so, the
1131// cover is drawn as cell art. The first look comes after the terminal has had time to answer.
1132function probeImage($, requestId, png, key, attempt) {
1133  $.clock.after(attempt === 0 ? PROBE_MS : PROBE_MS * 2, async () => {
1134    if (cover.key !== key || panelSite === null) {
1135      return;
1136    }
1137    const result = await $.ui.blit({ requestId, key: "cover", source: { png } }).catch(() => undefined);
1138    if (!result || !result.deny || !result.deny.includes("alt")) {
1139      return;
1140    }
1141    if (attempt === 0) {
1142      probeImage($, requestId, png, key, 1);
1143      return;
1144    }
1145    imagesBlocked = true;
1146    $.ui.invalidate("ui.render");
1147  });
1148}
1149
1150// The panel is not drawn (band, survey or nothing playing): the aurora has nothing to paint.
1151function leavePanel($, e) {
1152  if (e.surface === "terminal") {
1153    panelSite = null;
1154    auroraBlocked = "";
1155    stopAurora();
1156  }
1157}
1158
1159function glowLevel(song) {
1160  if (isDucked()) {
1161    return 0.3;
1162  }
1163  return song.state === "paused" ? 0.45 : 1;
1164}
1165
1166// The colours the panel's words and bar take from the cover: the two strongest colours, lifted
1167// to read on the dark background (and let down when the music is quiet), and a deep one for the
1168// play button, dark enough for white words.
1169function look(quiet) {
1170  const fade = (rgb) => (quiet ? mix(rgb, PANEL_BG, 0.5).map(Math.round) : rgb.map(Math.round));
1171  return {
1172    from: fade(tone(cover.colors[0], 0.58, 0.5)),
1173    to: fade(tone(cover.colors[1], 0.68, 0.5)),
1174    pill: fade(pillColor(cover.colors[0])),
1175  };
1176}
1177
1178// Prev, play or pause, next, then the volume (when focused and there is room) and DJ Clawd.
1179// `room` is how many cells the row has. The play button is a pill in the cover's colour, the
1180// others plain words, so the main action reads at a glance. DJ Clawd stays in big mode, at the
1181// end of this row.
1182function controlsRow($, ui, song, columns, room, tint) {
1183  const { Box, Text, Button } = ui;
1184  const lit = isLit;
1185  const playing = song.state !== "paused";
1186  const parts = [
1187    Button({ key: "prev", label: "‹ prev", ...keyed("h"), plain: true, dimColor: !lit, onPress: () => void press($, "prev") }),
1188    Text({ children: "   " }),
1189    Box({
1190      backgroundColor: hex(tint.pill),
1191      children: Button({
1192        key: "play",
1193        label: playing ? "  pause  " : "   play  ",
1194        ...keyed("p"),
1195        plain: true,
1196        autoFocus: true,
1197        onPress: () => void press($, "pause"),
1198      }),
1199    }),
1200    Text({ children: "   " }),

1// The desktop stage: the player in the Claude app's Code tab, one composed picture. The cover
2// and its light on the left; the title, the lyric being sung, a progress bar and the time in
3// the middle; DJ Clawd at his booth on the right. The song's next minutes are written into the
4// picture (lyric lines fade in at their times, the bar glides, the time ticks), so it moves by
5// itself and the band is only redrawn when something else changes (the track, play or pause,
6// a question, the volume) or every two minutes to carry the timeline on. A redraw builds it
7// from the current position, and the loops take their phase from the clock, so a rebuilt
8// picture carries on exactly where the old one was.
9import { hex } from "./panel.mjs";
10
11export const STAGE_HEIGHT = 196;
12export const STAGE_LIMIT = 126000;
13const W = 760;
14const BG = "#131315";
15const BONE = "#f6f2ec";
16const BEAT = 0.5; // a steady groove: the player's audio is sealed inside YouTube's frame
17
18const esc = (s) => String(s ?? "").replace(/[&<>"']/g, (c) => ({ "&": "&amp;", "<": "&lt;", ">": "&gt;", '"': "&quot;", "'": "&#39;" })[c]);
19const fit = (s, n) => (String(s).length > n ? `${String(s).slice(0, n - 1).trimEnd()}…` : String(s));
20const n2 = (v) => Number(v.toFixed(2));
21
22// The engine refuses an Svg over 131072 characters: a picture that comes out too big is built
23// again with a shorter window of the song ahead, and at the last without the cover.
24export function stageSvg(args) {
25  for (const ahead of [150, 75, 30, 0]) {
26    const svg = buildStage({ ...args, ahead });
27    if (svg.length <= STAGE_LIMIT) return svg;
28  }
29  return buildStage({ ...args, ahead: 0, jpeg: "" });
30}
31
32function buildStage({ title, artist, album = "", upNext = "", lyrics = [], pos = 0, dur = 0, playing, ducked, colors, accent, jpeg, clawd = true, clock = 0, ahead = 150 }) {
33  const [c0, c1, c2] = colors.map(hex);
34  const ac = hex(accent);
35  const live = playing && !ducked;
36  const dim = !live;
37  const H = STAGE_HEIGHT;
38  const phase = (d, shift = 0) => `begin="-${n2((clock + shift) % d)}s"`;
39  const drift = (attr, values, d) =>
40    live ? `<animate attributeName="${attr}" values="${values}" dur="${d}s" ${phase(d)} repeatCount="indefinite" calcMode="spline" keyTimes="0;0.5;1" keySplines="0.45 0 0.55 1;0.45 0 0.55 1"/>` : "";
41
42  const S = 150, CX = 24, CY = (H - S) / 2;
44  const useArt = (x, y, size) => `<use href="#art" transform="translate(${x} ${y}) scale(${n2(size / 100)})"/>`;
45
46  const TX = 200;
47  const label = ducked ? "TURNED DOWN" : playing ? "NOW PLAYING" : "PAUSED";
48  const eq = live
49    ? [0, 5, 10]
50        .map((dx, i) => {
51          const lo = [3, 8, 4][i], hi = [10, 3, 11][i], d = [0.86, 1.04, 0.72][i];
52          return `<rect x="${TX + 104 + dx}" width="2.5" rx="1.25" fill="${ac}"><animate attributeName="height" values="${lo};${hi};${lo}" dur="${d}s" ${phase(d)} repeatCount="indefinite"/><animate attributeName="y" values="${46 - lo};${46 - hi};${46 - lo}" dur="${d}s" ${phase(d)} repeatCount="indefinite"/></rect>`;
53        })
54        .join("")
55    : "";
56  const sub = album && album !== title ? `<tspan fill-opacity="0.5"> · ${esc(fit(album, 24))}</tspan>` : "";
57  const words = [
58    `<text x="${TX}" y="46" font-size="10" font-weight="700" letter-spacing="2.3" fill="${ac}" fill-opacity="${dim ? 0.6 : 0.95}">${label}</text>${eq}`,
59    `<text x="${TX}" y="78" font-size="28" font-weight="760" letter-spacing="-0.7" fill="${BONE}" fill-opacity="${dim ? 0.75 : 1}">${esc(fit(title, 22))}</text>`,
60    `<text x="${TX}" y="101" font-size="14.5" fill="${BONE}" fill-opacity="${dim ? 0.48 : 0.7}">${esc(fit(artist, 30))}${sub}</text>`,
61  ].join("");
62
63
64  // the song: the lyric being sung over the next one, each shown for its own span; a bar that
65  // glides to the end; the elapsed time ticking second by second
66  const TW = 300;
67  const clockText = (sec) => `${Math.floor(sec / 60)}:${String(Math.floor(sec % 60)).padStart(2, "0")}`;
68  let lines = "";
69  const timed = lyrics.filter((l) => l && typeof l.t === "number").sort((a, b) => a.t - b.t);
70  if (timed.length) {
71    for (let i = 0; i < timed.length; i++) {
72      const start = timed[i].t, end = i + 1 < timed.length ? timed[i + 1].t : dur || start + 8;
73      if (end <= pos) continue;
74      if (start - pos > ahead) break;
75      const b0 = n2(Math.max(0, start - pos)), b1 = n2(end - pos);
76      const shown = start <= pos;
77      const now = timed[i].text?.trim() ? timed[i].text : "\u266a";
78      const next = i + 1 < timed.length ? timed[i + 1].text || "" : "";
79      const line = (y, size, weight, fill, op, text) => {
80        const enter = shown ? "" : `<animate attributeName="opacity" from="0" to="${op}" begin="${b0}s" dur="0.28s" fill="freeze"/><animate attributeName="y" from="${y + 5}" to="${y}" begin="${b0}s" dur="0.32s" fill="freeze" calcMode="spline" keyTimes="0;1" keySplines="0.2 0.7 0.3 1"/>`;
81        const leave = live ? `<set attributeName="opacity" to="0" begin="${b1}s"/>` : "";
82        return `<text x="${TX}" y="${y}" font-size="${size}" font-weight="${weight}" fill="${fill}" opacity="${shown ? op : 0}">${esc(fit(text, size > 15 ? 34 : 42))}${live ? enter : ""}${leave}</text>`;
83      };
84      lines += line(126, 16.5, 650, ac, dim ? 0.6 : 1, now);
85      if (next) lines += line(147, 14, 400, BONE, dim ? 0.3 : 0.42, next);
86      if (!live) break;
87    }
88  } else {
89    lines =
90      `<text x="${TX}" y="126" font-size="15.5" font-style="italic" fill="${BONE}" fill-opacity="0.72">${esc(fit(album || "No synced lyrics for this one", 36))}</text>` +
91      (upNext ? `<text x="${TX}" y="147" font-size="13.5" fill="${BONE}" fill-opacity="0.42">up next  \u00b7  ${esc(fit(upNext, 36))}</text>` : "");
92  }
93  const frac = dur > 0 ? Math.min(1, pos / dur) : 0;
94  const w0 = n2(TW * frac);
95  const glide = live && dur > pos ? `<animate attributeName="width" from="${w0}" to="${TW}" dur="${n2(dur - pos)}s" fill="freeze"/>` : "";
96  const knob = live && dur > pos ? `<animate attributeName="cx" from="${TX + w0}" to="${TX + TW}" dur="${n2(dur - pos)}s" fill="freeze"/>` : "";
97  const bar =
98    `<rect x="${TX}" y="164" width="${TW}" height="3" rx="1.5" fill="${BONE}" fill-opacity="0.12"/>` +
99    `<rect x="${TX}" y="164" width="${w0}" height="3" rx="1.5" fill="url(#prog)">${glide}</rect>` +
100    `<circle cx="${TX + w0}" cy="165.5" r="4.5" fill="${BONE}" fill-opacity="${dim ? 0.6 : 0.95}">${knob}</circle>`;
101  let ticks = "";
102  if (live && dur > pos) {
103    const first = Math.floor(pos);
104    for (let k = first; k < Math.min(dur, first + ahead + 30); k++) {
105      const b0 = n2(Math.max(0, k - pos)), b1 = n2(k + 1 - pos);
106      ticks += `<tspan x="${TX}" visibility="${k === first ? "visible" : "hidden"}">${clockText(k)}${k === first ? "" : `<set attributeName="visibility" to="visible" begin="${b0}s"/>`}<set attributeName="visibility" to="hidden" begin="${b1}s"/></tspan>`;
107    }
108  } else {
109    ticks = `<tspan x="${TX}">${clockText(pos)}</tspan>`;
110  }
111  const times =
112    `<text y="186" font-size="11" fill="${BONE}" fill-opacity="0.62">${ticks}</text>` +
113    (dur ? `<text x="${TX + TW}" y="186" text-anchor="end" font-size="11" fill="${BONE}" fill-opacity="0.38">${clockText(dur)}</text>` : "");
114
115  return [
116    `<svg xmlns="http://www.w3.org/2000/svg" width="4000" height="${H}" viewBox="0 0 ${W} ${H}" preserveAspectRatio="xMidYMid meet" font-family="-apple-system, 'SF Pro Display', 'Helvetica Neue', Arial, sans-serif">`,
117    `<defs>${art}`,
118    `<clipPath id="cv"><rect x="${CX}" y="${CY}" width="${S}" height="${S}" rx="14"/></clipPath>`,
119    `<clipPath id="col"><rect x="${TX - 4}" y="0" width="330" height="${H}"/></clipPath>`,
120    `<filter id="haze" x="-50%" y="-50%" width="200%" height="200%"><feGaussianBlur stdDeviation="44"/></filter>`,
121    `<filter id="lift" x="-50%" y="-50%" width="200%" height="200%"><feGaussianBlur stdDeviation="15"/></filter>`,
122    `<filter id="soft" x="-50%" y="-50%" width="200%" height="200%"><feGaussianBlur stdDeviation="14"/></filter>`,
123    `<linearGradient id="prog" x1="0" x2="1"><stop offset="0" stop-color="${c1}"/><stop offset="1" stop-color="${ac}"/></linearGradient>`,
124    `<linearGradient id="sheen" x1="0" y1="0" x2="0" y2="1"><stop offset="0" stop-color="#fff" stop-opacity="0.16"/><stop offset="0.5" stop-color="#fff" stop-opacity="0"/></linearGradient>`,
125    `<linearGradient id="cone" x1="0" y1="0" x2="0" y2="1"><stop offset="0" stop-color="${c1}" stop-opacity="0.34"/><stop offset="1" stop-color="${c1}" stop-opacity="0"/></linearGradient>`,
126    `<radialGradient id="vinyl"><stop offset="0.36" stop-color="#121214"/><stop offset="0.37" stop-color="#202024"/><stop offset="1" stop-color="#0c0c0e"/></radialGradient>`,
127    `</defs>`,
128    `<rect x="-2000" y="-200" width="${W + 4000}" height="${H + 400}" fill="${BG}"/>`,
129    `<g opacity="${dim ? 0.3 : 0.55}" filter="url(#haze)">${useArt(-60, -200, 540)}</g>`,
130    `<g filter="url(#haze)" opacity="${dim ? 0.14 : 0.3}">`,
131    `<ellipse cx="120" cy="86" rx="170" ry="110" fill="${c0}">${drift("cx", "120;220;120", 19)}</ellipse>`,
132    `<ellipse cx="360" cy="10" rx="180" ry="70" fill="${c1}">${drift("cx", "360;250;360", 27)}</ellipse>`,
133    `<ellipse cx="660" cy="160" rx="190" ry="80" fill="${c2}">${drift("cy", "160;120;160", 23)}</ellipse>`,
134    `</g>`,
135    `<rect x="${CX + 10}" y="${CY + 16}" width="${S - 20}" height="${S - 10}" rx="16" fill="${c0}" filter="url(#lift)" fill-opacity="${dim ? 0.3 : 0.7}"/>`,
136    `<g clip-path="url(#cv)">${useArt(CX, CY, S)}<rect x="${CX}" y="${CY}" width="${S}" height="${S}" fill="url(#sheen)"/></g>`,
137    `<rect x="${CX + 0.5}" y="${CY + 0.5}" width="${S - 1}" height="${S - 1}" rx="13.5" fill="none" stroke="#fff" stroke-opacity="0.12"/>`,
138    `<g clip-path="url(#col)">${words}${lines}${bar}</g>`,
139    times,
140    clawd ? booth({ x: 528, H, live, playing, ducked, ac, c1, phase, drift, useArt, clock }) : "",
141    `</svg>`,
142  ].join("");
143}
144
145// ---------------- DJ Clawd
146
147// His routine over 16 beats, in half beats: which pose each arm holds. d = hands on the decks,
148// s = working the record, e = holding an ear cup, u = a hand raised. Looks follow the work.
149const ROUTINE = {
150  left: "dddddddd" + "sdsdsdsd" + "dddddddd" + "eeeedddd",
151  right: "dddddddd" + "dddddddd" + "sdsdsdsd" + "dddduudd",
152};
153const LOOK = "00000000" + "LLLLLLLL" + "RRRRRRRR" + "00000000"; // where his eyes are turned
154const BLINKS = [13, 27]; // half beats at which he blinks
155
156function booth({ x, H, live, playing, ducked, ac, c1, phase, drift, useArt, clock }) {
157  const u = 6.5;
158  const O = "#d97757", E = "#1b1410", P = "#2a2a2e";
159  const top = H - 56; // the desk's top edge
160  const bw = 216;
161  const ox = bw / 2 - 6 * u, oy = top - 5 * u; // where Clawd stands
162  const cycle = BEAT * 16, slots = 32;
163  const keyTimes = Array.from({ length: slots }, (_, i) => n2(i / slots)).join(";");
164  // one switch per half beat, so poses change like frames of a sprite
165  const frames = (seq, on) =>
166    live
167      ? `<animate attributeName="opacity" values="${[...seq].map((c) => (c === on ? 1 : 0)).join(";")}" keyTimes="${keyTimes}" calcMode="discrete" dur="${cycle}s" ${phase(cycle)} repeatCount="indefinite"/>`
168      : "";
169  const px = (x0, y0, w, h, fill = O) => `<rect x="${n2(x0 * u)}" y="${n2(y0 * u)}" width="${n2(w * u)}" height="${n2(h * u)}" fill="${fill}"/>`;
170  // one arm in each pose, drawn for the left side; the right is its mirror
171  const POSES = {
172    d: px(-2.4, 2, 2.4, 1) + px(-3.4, 2, 1, 3.6) + px(-4, 5.4, 2.2, 1.1),
173    s: px(-2.4, 2, 2.4, 1) + px(-4, 2, 1, 3.6) + px(-4.8, 5.4, 2.2, 1.1),
174    e: px(-1.2, 2.2, 1.2, 1) + px(-1.9, 0.6, 1, 2.6) + px(-2.1, 0.2, 1.3, 1.1),
175    u: px(-1.2, 2, 1.2, 1) + px(-2, -2.4, 1, 4.4) + px(-2.3, -3.3, 1.6, 1.1),
176  };
177  const restPose = ducked ? { left: "d", right: "e" } : { left: "d", right: "d" };
178  const arm = (side) => {
179    const seq = ROUTINE[side];
180    const mirror = side === "right" ? ` transform="matrix(-1 0 0 1 ${12 * u} 0)"` : "";
181    const poses = Object.entries(POSES)
182      .map(([k, shape]) => {
183        const shown = live ? seq[0] === k : restPose[side] === k;
184        return `<g opacity="${shown ? 1 : 0}">${shape}${frames(seq, k)}</g>`;
185      })
186      .join("");
187    return `<g${mirror}>${poses}</g>`;
188  };
189  const body = [[1, 0], [11, 0], [11, 2], [12, 2], [12, 4], [11, 4], [11, 6], [1, 6], [1, 4], [0, 4], [0, 2], [1, 2]]
190    .map(([a, b], i) => `${i ? "L" : "M"}${a * u} ${b * u}`)
191    .join(" ");
192  // eyes: they glance at the deck being worked, blink now and then, and look to the prompt when asked
193  const lookX = ducked ? -0.6 * u : 0;
194  const glance = live
195    ? `<animateTransform attributeName="transform" type="translate" values="${[...LOOK].map((c) => (c === "L" ? `${-0.5 * u} 0` : c === "R" ? `${0.5 * u} 0` : "0 0")).join(";")}" keyTimes="${keyTimes}" calcMode="discrete" dur="${cycle}s" ${phase(cycle)} repeatCount="indefinite"/>`
196    : "";
197  const blink = live
198    ? `<animate attributeName="height" values="${Array.from({ length: slots }, (_, i) => (BLINKS.includes(i) ? n2(u * 0.2) : u)).join(";")}" keyTimes="${keyTimes}" calcMode="discrete" dur="${cycle}s" ${phase(cycle)} repeatCount="indefinite"/>`
199    : "";
200  const eye = (ex) => `<rect x="${ex * u + lookX}" y="${u}" width="${u}" height="${playing || ducked ? u : n2(u * 0.35)}" fill="${E}">${blink}</rect>`;
201  const cupLifted = ducked;
202  const clawd = [
203    `<g transform="translate(${ox} ${oy})" shape-rendering="crispEdges">`,
204    `<g>`,
205    live ? `<animateTransform attributeName="transform" type="translate" values="0 0;0 ${n2(u * 0.35)};0 0" dur="${BEAT}s" ${phase(BEAT)} repeatCount="indefinite" calcMode="spline" keyTimes="0;0.5;1" keySplines="0.4 0 0.6 1;0.4 0 0.6 1"/>` : "",
206    `<path d="${body} Z" fill="${O}"/>`,
207    `<g>${glance}${eye(3)}${eye(8)}</g>`,
208    `<path d="M ${-0.2 * u} ${2 * u} Q ${6 * u} ${-5 * u} ${12.2 * u} ${2 * u}" fill="none" stroke="${P}" stroke-width="${u * 0.9}" stroke-linecap="round"/>`,
209    px(-1, 1, 2, 3, P),
210    `<g${cupLifted ? ` transform="translate(${u * 1.6} ${-u * 1.8}) rotate(26 ${12 * u} ${2 * u})"` : ""}>${px(11, 1, 2, 3, P)}</g>`,
211    `</g>`,
212    `</g>`,
213  ].join("");
214  const arms = `<g transform="translate(${ox} ${oy})" shape-rendering="crispEdges"><g>${live ? `<animateTransform attributeName="transform" type="translate" values="0 0;0 ${n2(u * 0.35)};0 0" dur="${BEAT}s" ${phase(BEAT)} repeatCount="indefinite" calcMode="spline" keyTimes="0;0.5;1" keySplines="0.4 0 0.6 1;0.4 0 0.6 1"/>` : ""}${arm("left")}${arm("right")}</g></g>`;
215
216  const spin = (d) => (live ? `<animateTransform attributeName="transform" type="rotate" from="0" to="360" dur="${d}s" ${phase(d)} repeatCount="indefinite"/>` : "");
217  const deck = (cx) => {
218    const cy = top + 9;
219    return [
220      `<g transform="translate(${cx} ${cy}) scale(1 0.34)">`,
221      `<circle r="40" fill="#09090b"/><circle r="37" fill="url(#vinyl)"/>`,
222      [30, 25, 20].map((r) => `<circle r="${r}" fill="none" stroke="#2c2c31" stroke-width="0.8"/>`).join(""),
223      `<g>${spin(1.8)}`,
224      `<clipPath id="lab${cx}"><circle r="12.5"/></clipPath><g clip-path="url(#lab${cx})">${useArt(-12.5, -12.5, 25)}</g>`,
225      `<path d="M -34 -6 A 35 35 0 0 1 -6 -34" stroke="#fff" stroke-opacity="0.16" stroke-width="2" fill="none"/>`,
226      `</g><circle r="2" fill="#ccc"/></g>`,
227      `<g transform="translate(${cx + 32} ${cy - 10}) rotate(${playing ? 28 : 8})"><rect x="-1" y="0" width="2" height="22" rx="1" fill="#8a8a92"/><rect x="-2.5" y="20" width="5" height="4" rx="1" fill="#b9b9c2"/></g>`,
228      `<circle cx="${cx + 32}" cy="${cy - 10}" r="3" fill="#55555c"/>`,
229    ].join("");
230  };
231  const meter = (mx, d0) => {
232    let s = "";
233    for (let k = 0; k < 8; k++) {
234      const fill = k >= 6 ? ac : k >= 4 ? c1 : "#7fd1a8";
235      const op = live ? (k < 3 ? 0.9 : 0.12) : k < 1 ? 0.5 : 0.1;
236      const flick = live && k >= 3 ? `<animate attributeName="fill-opacity" values="0.12;0.9;0.12;0.12" keyTimes="0;${n2(0.12 + k * 0.02)};${n2(0.4 + k * 0.03)};1" dur="${n2(BEAT * (k % 2 ? 1 : 2))}s" begin="-${n2((clock + d0 + k * 0.07) % BEAT)}s" repeatCount="indefinite"/>` : "";
237      s += `<rect x="${mx}" y="${top + 41 - k * 4.2}" width="7" height="3" rx="1" fill="${fill}" fill-opacity="${op}">${flick}</rect>`;
238    }
239    return s;
240  };
241  return [
242    `<g transform="translate(${x} 0)">`,
243    `<path d="M ${bw / 2 - 30} -10 L ${bw / 2 + 30} -10 L ${bw + 10} ${top + 10} L -10 ${top + 10} Z" fill="url(#cone)" filter="url(#soft)" opacity="${live ? 0.9 : 0.35}">${drift("opacity", "0.7;1;0.7", BEAT * 8)}</path>`,
244    clawd,
245    `<rect x="0" y="${top}" width="${bw}" height="${H - top + 20}" rx="10" fill="#1b1b1f"/>`,
246    `<rect x="1" y="${top}" width="${bw - 2}" height="1.5" fill="${ac}" fill-opacity="${live ? 0.55 : 0.2}"/>`,
247    `<rect x="0" y="${top + 26}" width="${bw}" height="${H - top}" fill="#151518"/>`,
248    `<text x="20" y="${top + 46}" font-family="Georgia, 'Times New Roman', serif" font-style="italic" font-size="15" fill="${BONE}" fill-opacity="0.26">hum</text>`,
249    deck(46),
250    deck(bw - 46),
251    arms,
252    meter(bw / 2 - 12, 0.11),
253    meter(bw / 2 + 5, 0.27),
254    `<rect x="${bw / 2 - 16}" y="${top + 49}" width="32" height="2" rx="1" fill="#2e2e33"/>`,
255    `<rect y="${top + 46}" width="7" height="7" rx="1.5" fill="#c9c9d1" x="${bw / 2 - 12}">${live ? `<animate attributeName="x" values="${bw / 2 - 12};${bw / 2 + 5};${bw / 2 - 12}" dur="${BEAT * 32}s" ${phase(BEAT * 32)} repeatCount="indefinite" calcMode="spline" keyTimes="0;0.5;1" keySplines="0.45 0 0.55 1;0.45 0 0.55 1"/>` : ""}</rect>`,
256    `</g>`,
257  ].join("");
258}
259

1// Pure logic for Hush: no host calls, so tests can run it directly.
2//
3// Hush plays two kinds of audio. Radio goes through the native helper. Songs go through
4// hum (https://github.com/anzal1/hum), which plays through YouTube's own embed in a visible
5// window. This file decides what a /music command means for each, and how hum's state is
6// turned into the line (or the big panel) shown above the prompt.
7
8export const LYRIC_LEAD = 0.15;
9export const VOLUME_STEP = 10;
10
11export function clamp(value, low, high) {
12  return Math.max(low, Math.min(high, value));
13}
14
15// Where the song is right now: hum's report plus the time since it was made, while it plays.
16export function livePosition(state, now) {
17  if (!state || typeof state.position !== "number") {
18    return 0;
19  }
20  let seconds = state.position;
21  if (state.playing && typeof state.at === "number") {
22    seconds += Math.max(0, now - state.at) / 1000;
23  }
24  if (state.duration > 0) {
25    seconds = Math.min(seconds, state.duration);
26  }
27  return Math.max(0, seconds);
28}
29
30// The last synced line that has started by `seconds`, a little early so the eye is not behind the voice.
31export function lyricLine(lyrics, seconds) {
32  if (!Array.isArray(lyrics)) {
33    return "";
34  }
35  const cutoff = seconds + LYRIC_LEAD;
36  let best = null;
37  for (const entry of lyrics) {
38    if (entry && typeof entry.t === "number" && entry.t <= cutoff && (best === null || entry.t >= best.t)) {
39      best = entry;
40    }
41  }
42  return best && typeof best.text === "string" ? best.text.trim() : "";
43}
44
45// The line being sung, the one after it, and how many seconds until that one starts (null
46// when there is none). Blank lines in the file are interludes: `line` is "" for one, and the
47// next line skips them. Before the first line, `line` is "" and `next` is the first line.
48export function lyricWindow(lyrics, seconds) {
49  const none = { line: "", next: "", nextIn: null };
50  if (!Array.isArray(lyrics)) {
51    return none;
52  }
53  const cutoff = seconds + LYRIC_LEAD;
54  let best = null;
55  for (const entry of lyrics) {
56    if (entry && typeof entry.t === "number" && entry.t <= cutoff && (best === null || entry.t >= best.t)) {
57      best = entry;
58    }
59  }
60  let next = null;
61  for (const entry of lyrics) {
62    if (entry && typeof entry.t === "number" && typeof entry.text === "string" && entry.text.trim() !== "" && entry.t > cutoff && (next === null || entry.t < next.t)) {
63      next = entry;
64    }
65  }
66  return {
67    line: best && typeof best.text === "string" ? best.text.trim() : "",
68    next: next ? next.text.trim() : "",
69    nextIn: next ? next.t - cutoff : null,
70  };
71}
72
73// What the band draws for hum, or null when no hum window has a track.
74export function humView(state, now) {
75  if (!state || !(state.connected > 0) || !state.track) {
76    return null;
77  }
78  const pos = livePosition(state, now);
79  const artist = state.track.artist || "";
80  const title = state.track.title || artist || "hum";
81  const lyrics = Array.isArray(state.lyrics) ? state.lyrics : [];
82  const window = lyricWindow(lyrics, pos);
83  const queue = Array.isArray(state.upNext) ? state.upNext.find((x) => typeof x === "string" && x.trim() !== "") : "";
84  return {
85    state: state.playing ? "playing" : "paused",
86    title,
87    artist,
88    name: artist && artist !== title ? `${title} · ${artist}` : title,
89    id: typeof state.track.id === "string" ? state.track.id : "",
90    art: typeof state.track.art === "string" ? state.track.art : "",
91    line: window.line,
92    next: window.next,
93    nextIn: window.nextIn,
94    hasLyrics: lyrics.length > 0,
95    album: typeof state.track.album === "string" && state.track.album !== title ? state.track.album.trim() : "",
96    upNext: typeof queue === "string" ? queue.trim() : "",
97    pos,
98    dur: state.duration > 0 ? state.duration : 0,
99    volume: Number.isFinite(state.volume) ? state.volume : 0,
100    ducked: Boolean(state.ducked),
101  };
102}
103
104// What the person typed after /music, as an intent. Stations are matched by id.
105export function parseArgs(args, stations) {
106  const [first = "", ...rest] = args.split(/\s+/).filter(Boolean);
107  const word = first.toLowerCase();
108  if (word === "") {
109    return { kind: "bare" };
110  }
111  const index = stations.findIndex((id) => id === word);
112  if (index >= 0 && rest.length === 0) {
113    return { kind: "station", index };
114  }
115  if (word === "radio" && rest.length === 0) {
116    return { kind: "radio" };
117  }
118  // Only a bare word is a command, so "next level" and "stop making sense" are song searches.
119  if (word === "next" && rest.length === 0) {
120    return { kind: "next" };
121  }
122  if ((word === "prev" || word === "previous") && rest.length === 0) {
123    return { kind: "prev" };
124  }
125  if ((word === "stop" || word === "off") && rest.length === 0) {
126    return { kind: "stop" };
127  }
128  if (word === "vol" || word === "volume") {
129    const n = Number.parseInt(rest[0] ?? "", 10);
130    return { kind: "vol", value: Number.isNaN(n) ? null : n };
131  }
132  if (word === "clawd" && rest.length === 0) {
133    return { kind: "clawd" };
134  }
135  if (word === "big" && rest.length === 0) {
136    return { kind: "big" };
137  }
138  if ((word === "pause" || word === "play") && rest.length === 0) {
139    return { kind: word };
140  }
141  const query = (word === "play" || word === "song" ? rest : [first, ...rest]).join(" ");
142  return query === "" ? { kind: "bare" } : { kind: "search", query };
143}
144
145// What an intent does, given where the sound comes from now. ctx is
146// { source: "radio" | "hum", humLive, radioActive, radioVolume, humVolume, stationIndex }.
147// Returns { target, action, ... }. A hum plan carries `cmd`, the body to POST to hum.
148// `source` is the source to switch to once the plan has worked, when it changes.
149export function route(intent, ctx) {
150  const onHum = ctx.source === "hum" && ctx.humLive;
151  const hum = (action, cmd, extra = {}) => ({ target: "hum", action, cmd, ...extra });
152  const radio = (action, extra = {}) => ({ target: "radio", action, ...extra });
153  switch (intent.kind) {
154    case "search":
155      return hum("play", { cmd: "play", query: intent.query }, { source: "hum" });
156    case "station":
157      return radio("station", { index: intent.index, source: "radio" });
158    case "radio":
159      return radio("station", { index: ctx.stationIndex, source: "radio" });
160    case "bare":
161    case "pause":
162    case "play":
163      if (onHum) {
164        const cmd = intent.kind === "pause" ? "pause" : intent.kind === "play" ? "resume" : "toggle";
165        return hum(intent.kind, { cmd });
166      }
167      return ctx.radioActive ? radio("toggle") : radio("station", { index: ctx.stationIndex, source: "radio" });
168    case "toggle":
169      return onHum ? hum("toggle", { cmd: "toggle" }) : radio("toggle");
170    case "next":
171      return onHum ? hum("next", { cmd: "next" }) : radio("next");
172    case "prev":
173      return onHum ? hum("prev", { cmd: "prev" }) : radio("prev");
174    case "stop":
175      return onHum ? hum("stop", { cmd: "pause" }, { source: "radio" }) : radio("stop");
176    case "vol": {
177      const current = onHum ? ctx.humVolume : ctx.radioVolume;
178      let level = null;
179      if (typeof intent.value === "number") {
180        level = clamp(intent.value, 0, 100);
181      } else if (typeof intent.delta === "number") {
182        level = clamp(current + intent.delta, 0, 100);
183      }
184      return onHum ? hum("volume", level === null ? null : { cmd: "volume", level }, { level }) : radio("volume", { level });
185    }
186    default:
187      return { target: "local", action: intent.kind };
188  }
189}
190
191// The hum command that ducks or restores, or null when nothing needs sending.
192export function duckCommand(wantDucked, alreadyDucked) {
193  if (wantDucked === alreadyDucked) {
194    return null;
195  }
196  return { cmd: wantDucked ? "duck" : "unduck" };
197}
198

1// Pure parts of Hush's big panel: no host calls, so tests can run them directly.
2//
3// The panel is the richer view above the prompt while a song plays through hum: the cover,
4// an aurora in the cover's colours, the title, artist and lyric lines, progress and buttons.
5// This file reads the cover's pixels (a small BMP that /usr/bin/sips wrote), picks the
6// colours, makes the cell art for the terminal and the SVG for the desktop, and decides
7// which layout fits.
8//
9// The terminal art is drawn in quadrant blocks: every cell carries 2x2 pixels in two colours,
10// so a cover is twice as sharp across as half blocks give, and the aurora is dithered across
11// the same sub-pixels so a glow reads as light and not as steps.
12
13export const BACKGROUND = [8, 7, 11];
14export const BACKGROUND_HEX = "#08070b";
15export const BONE = "#f6f2ec";
16export const BONE_SOFT = "#b9b1a6";
17export const BONE_DIM = "#8a8379";
18export const TRACK = [38, 35, 46];
19
20// Claude Code paints a Raster's colours in 16 levels a channel (the nearest multiple of 17),
21// whatever is sent, so the cell art is made on that grid. The panel's own background is the
22// grid colour nearest hum's #08070b, so that the aurora's dark cells and the card around them
23// are one colour and no box shows.
24export const GRID = 17;
25export const PANEL_BG = [17, 17, 17];
26export const PANEL_BG_HEX = "#111111";
27
28// hum's own warm colours, used until a cover has been read or when there is none.
29export const FALLBACK_COLORS = [
30  [196, 112, 78],
31  [140, 110, 214],
32  [92, 142, 176],
33  [14, 11, 18],
34];
35export const FALLBACK_ACCENT = [235, 160, 128];
36
37export const PANEL_MIN_COLUMNS = 60;
38export const PANEL_MAX_COLUMNS = 120;
39export const PANEL_ROWS = 8;
40export const PANEL_ROWS_MAX = 10;
41export const PANEL_ROOM = 2;
42export const COVER_COLUMNS = 16;
43export const COVER_ROWS = 8;
44export const RIBBON_ROWS = 2;
45export const PANEL_GAP = 2;
46export const PANEL_PAD = 1;
47export const SVG_LIMIT = 131072;
48export const SVG_WIDTH = 560;
49export const SVG_HEIGHT = 148;
50export const UPPER_HALF = 0x2580;
51export const EIGHTHS = [" ", "\u258f", "\u258e", "\u258d", "\u258c", "\u258b", "\u258a", "\u2589", "\u2588"];
52// Quadrant glyphs by mask: 1 upper left, 2 upper right, 4 lower left, 8 lower right.
53export const QUADRANTS = [" ", "\u2598", "\u259d", "\u2580", "\u2596", "\u258c", "\u259e", "\u259b", "\u2597", "\u259a", "\u2590", "\u259c", "\u2584", "\u2599", "\u259f", "\u2588"];
54
55export function fit(text, cells) {
56  if (cells <= 0) {
57    return "";
58  }
59  return text.length <= cells ? text : `${text.slice(0, Math.max(0, cells - 1))}…`;
60}
61
62export function clock(total) {
63  const seconds = Math.floor(total);
64  const m = Math.floor(seconds / 60);
65  const s = String(seconds % 60).padStart(2, "0");
66  return `${m}:${s}`;
67}
68
69// ---------- bytes ----------
70
71const B64 = "ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/";
72
73// Base64 by hand: the module's environment is not promised the newer Uint8Array helpers.
74export function toBase64(bytes) {
75  let out = "";
76  for (let i = 0; i < bytes.length; i += 3) {
77    const a = bytes[i];
78    const b = i + 1 < bytes.length ? bytes[i + 1] : 0;
79    const c = i + 2 < bytes.length ? bytes[i + 2] : 0;
80    out += B64[a >> 2] + B64[((a & 3) << 4) | (b >> 4)];
81    out += i + 1 < bytes.length ? B64[((b & 15) << 2) | (c >> 6)] : "=";
82    out += i + 2 < bytes.length ? B64[c & 63] : "=";
83  }
84  return out;
85}
86
87export function fromBase64(text) {
88  const clean = String(text).replace(/[^A-Za-z0-9+/]/g, "");
89  const out = new Uint8Array(Math.floor((clean.length * 3) / 4));
90  let n = 0;
91  for (let i = 0; i < clean.length; i += 4) {
92    const a = B64.indexOf(clean[i]);
93    const b = B64.indexOf(clean[i + 1]);
94    const c = i + 2 < clean.length ? B64.indexOf(clean[i + 2]) : -1;
95    const d = i + 3 < clean.length ? B64.indexOf(clean[i + 3]) : -1;
96    out[n++] = (a << 2) | (b >> 4);
97    if (c >= 0) {
98      out[n++] = ((b & 15) << 4) | (c >> 2);
99    }
100    if (d >= 0) {
101      out[n++] = ((c & 3) << 6) | d;
102    }
103  }
104  return out.slice(0, n);
105}
106
107// ---------- BMP ----------
108
109// Reads an uncompressed BMP (24 or 32 bits a pixel, rows bottom up or top down, as sips
110// writes them) into { width, height, rgba }. Returns null for anything else.
111export function parseBmp(bytes) {
112  if (!bytes || bytes.length < 54 || bytes[0] !== 0x42 || bytes[1] !== 0x4d) {
113    return null;
114  }
115  const view = new DataView(bytes.buffer, bytes.byteOffset, bytes.byteLength);
116  const offset = view.getUint32(10, true);
117  const dib = view.getUint32(14, true);
118  if (dib < 40) {
119    return null;
120  }
121  const width = view.getInt32(18, true);
122  const rawHeight = view.getInt32(22, true);
123  const bits = view.getUint16(28, true);
124  const compression = view.getUint32(30, true);
125  const height = Math.abs(rawHeight);
126  const topDown = rawHeight < 0;
127  const plain = compression === 0 || (compression === 3 && bits === 32);
128  if (!plain || (bits !== 24 && bits !== 32) || width < 1 || height < 1 || width > 1024 || height > 1024) {
129    return null;
130  }
131  const stride = Math.floor((bits * width + 31) / 32) * 4;
132  if (offset + stride * height > bytes.length) {
133    return null;
134  }
135  const step = bits / 8;
136  const rgba = new Uint8Array(width * height * 4);
137  for (let y = 0; y < height; y += 1) {
138    const row = offset + (topDown ? y : height - 1 - y) * stride;
139    for (let x = 0; x < width; x += 1) {
140      const at = row + x * step;
141      const to = (y * width + x) * 4;
142      rgba[to] = bytes[at + 2];
143      rgba[to + 1] = bytes[at + 1];
144      rgba[to + 2] = bytes[at];
145      rgba[to + 3] = 255;
146    }
147  }
148  return { width, height, rgba };
149}
150
151// ---------- colour ----------
152
153function rgbToHsl([r, g, b]) {
154  r /= 255;
155  g /= 255;
156  b /= 255;
157  const max = Math.max(r, g, b);
158  const min = Math.min(r, g, b);
159  const l = (max + min) / 2;
160  if (max === min) {
161    return [0, 0, l];
162  }
163  const d = max - min;
164  const s = l > 0.5 ? d / (2 - max - min) : d / (max + min);
165  let h;
166  if (max === r) {
167    h = (g - b) / d + (g < b ? 6 : 0);
168  } else if (max === g) {
169    h = (b - r) / d + 2;
170  } else {
171    h = (r - g) / d + 4;
172  }
173  return [h / 6, s, l];
174}
175
176function hslToRgb([h, s, l]) {
177  if (!s) {
178    return [l, l, l].map((v) => Math.round(v * 255));
179  }
180  const q = l < 0.5 ? l * (1 + s) : l + s - l * s;
181  const p = 2 * l - q;
182  const f = (t) => {
183    t = (t + 1) % 1;
184    if (t < 1 / 6) return p + (q - p) * 6 * t;
185    if (t < 1 / 2) return q;
186    if (t < 2 / 3) return p + (q - p) * (2 / 3 - t) * 6;
187    return p;
188  };
189  return [f(h + 1 / 3), f(h), f(h - 1 / 3)].map((v) => Math.round(v * 255));
190}
191
192function distance(a, b) {
193  return Math.hypot(a[0] - b[0], a[1] - b[1], a[2] - b[2]);
194}
195
196// A few characterful colours from a cover, in the spirit of hum's public/palette.js: pixels
197// are bucketed, saturated mid tones score highest, and near duplicates are dropped. Returns
198// { colors: four glow colours (the last a deep shade), accent: a light one for text }.
199export function palette(rgba) {
200  const buckets = new Map();
201  for (let i = 0; i + 3 < rgba.length; i += 4) {
202    if (rgba[i + 3] < 128) {
203      continue;
204    }
205    const key = (rgba[i] >> 4) * 256 + (rgba[i + 1] >> 4) * 16 + (rgba[i + 2] >> 4);
206    const b = buckets.get(key) || { n: 0, r: 0, g: 0, b: 0 };
207    b.n += 1;
208    b.r += rgba[i];
209    b.g += rgba[i + 1];
210    b.b += rgba[i + 2];
211    buckets.set(key, b);
212  }
213  if (buckets.size === 0) {
214    return { colors: FALLBACK_COLORS.map((c) => c.slice()), accent: FALLBACK_ACCENT.slice() };
215  }
216  // A grey cover has no colour to take: hum's own warm colours stand in rather than an arbitrary hue.
217  let colourful = 0;
218  for (const b of buckets.values()) {
219    if (rgbToHsl([b.r / b.n, b.g / b.n, b.b / b.n])[1] > 0.14) {
220      colourful += b.n;
221    }
222  }
223  if (colourful < rgba.length / 4 / 40) {
224    return { colors: FALLBACK_COLORS.map((c) => c.slice()), accent: FALLBACK_ACCENT.slice() };
225  }
226  const ranked = [...buckets.values()]
227    .map((b) => {
228      const rgb = [b.r / b.n, b.g / b.n, b.b / b.n];
229      const [, s, l] = rgbToHsl(rgb);
230      return { rgb, score: b.n * (0.25 + s * 1.6) * (l < 0.07 || l > 0.95 ? 0.15 : 1) };
231    })
232    .sort((a, b) => b.score - a.score);
233  const picks = [];
234  for (const r of ranked) {
235    if (picks.every((p) => distance(p, r.rgb) > 58)) {
236      picks.push(r.rgb);
237    }
238    if (picks.length === 4) {
239      break;
240    }
241  }
242  while (picks.length < 4) {
243    const [h, s, l] = rgbToHsl(picks[0] || [90, 60, 140]);
244    picks.push(hslToRgb([(h + 0.08 * picks.length) % 1, s, l]));
245  }
246  // Lifted into a glowing but dark range, so text reads on top.
247  const colors = picks.map((rgb, i) => {
248    const [h, s, l] = rgbToHsl(rgb);
249    return hslToRgb([h, Math.max(s, 0.38), i === 3 ? 0.07 : Math.min(Math.max(l, 0.3), 0.52)]);
250  });
251  const vivid = [...picks].sort((a, b) => rgbToHsl(b)[1] - rgbToHsl(a)[1])[0];
252  const [ah, as] = rgbToHsl(vivid);
253  return { colors, accent: hslToRgb([ah, Math.max(as, 0.55), 0.7]) };
254}
255
256export function hex(rgb) {
257  return `#${rgb.map((v) => clampByte(v).toString(16).padStart(2, "0")).join("")}`;
258}
259
260function clampByte(v) {
261  return Math.max(0, Math.min(255, Math.round(v)));
262}
263
264function pack(r, g, b) {
265  return (clampByte(r) << 16) | (clampByte(g) << 8) | clampByte(b);
266}
267
268// ---------- terminal cells ----------
269
270// Cell words for a Raster: [code point, foreground, background] per cell, row by row.
271// Base64 of the little-endian bytes is the Raster's `cells`.
272export function encodeCells(words) {
273  const bytes = new Uint8Array(words.length * 4);
274  for (let i = 0; i < words.length; i += 1) {
275    const w = words[i];
276    bytes[i * 4] = w & 255;
277    bytes[i * 4 + 1] = (w >>> 8) & 255;
278    bytes[i * 4 + 2] = (w >>> 16) & 255;
279    bytes[i * 4 + 3] = (w >>> 24) & 255;
280  }
281  return toBase64(bytes);
282}
283
284export function mix(a, b, t) {
285  return [a[0] + (b[0] - a[0]) * t, a[1] + (b[1] - a[1]) * t, a[2] + (b[2] - a[2]) * t];
286}
287
288// A colour kept in its hue at the lightness asked for (0 to 1), and at least `minSat` saturated.
289export function tone(rgb, lightness, minSat = 0) {
290  const [h, s] = rgbToHsl(rgb);
291  return hslToRgb([h, Math.max(s, minSat), lightness]);
292}
293
294// A deep shade of the cover's strongest colour for the play button. Yellows and greens turn to
295// mud when they are darkened, so they are swung towards amber first.
296export function pillColor(rgb) {
297  const [h] = rgbToHsl(rgb);
298  const swung = h > 0.1 && h < 0.3 ? 0.1 - (0.3 - h) * 0.15 : h;
299  return hslToRgb([swung, 0.6, 0.36]);
300}
301
302function luma(c) {
303  return 0.2126 * c[0] + 0.7152 * c[1] + 0.0722 * c[2];
304}
305
306function smooth(a, b, x) {
307  const t = Math.max(0, Math.min(1, (x - a) / (b - a)));
308  return t * t * (3 - 2 * t);
309}
310
311// The part of a picture that fits a cols x rows block of cells. A cell is about twice as tall
312// as it is wide, so the block's own shape is cols : 2 * rows, and a picture of another shape is
313// cropped from its middle rather than squeezed.
314export function cropRect(width, height, cols, rows) {
315  const shape = cols / (rows * 2);
316  let cw = width;
317  let ch = height;
318  if (width / height > shape) {
319    cw = Math.max(1, Math.round(height * shape));
320  } else {
321    ch = Math.max(1, Math.round(width / shape));
322  }
323  return { x0: Math.floor((width - cw) / 2), y0: Math.floor((height - ch) / 2), cw, ch };
324}
325
326// Box-averages a part of an RGBA picture down to cols x rows pixels of RGB, over the background where see-through.
327function resample(rgba, width, height, cols, rows, rect = { x0: 0, y0: 0, cw: width, ch: height }) {
328  const out = new Float64Array(cols * rows * 3);
329  for (let y = 0; y < rows; y += 1) {
330    const y0 = rect.y0 + Math.floor((y * rect.ch) / rows);
331    const y1 = Math.max(y0 + 1, rect.y0 + Math.floor(((y + 1) * rect.ch) / rows));
332    for (let x = 0; x < cols; x += 1) {
333      const x0 = rect.x0 + Math.floor((x * rect.cw) / cols);
334      const x1 = Math.max(x0 + 1, rect.x0 + Math.floor(((x + 1) * rect.cw) / cols));
335      let r = 0;
336      let g = 0;
337      let b = 0;
338      let n = 0;
339      for (let sy = y0; sy < y1 && sy < height; sy += 1) {
340        for (let sx = x0; sx < x1 && sx < width; sx += 1) {
341          const at = (sy * width + sx) * 4;
342          const a = rgba[at + 3] / 255;
343          r += rgba[at] * a + BACKGROUND[0] * (1 - a);
344          g += rgba[at + 1] * a + BACKGROUND[1] * (1 - a);
345          b += rgba[at + 2] * a + BACKGROUND[2] * (1 - a);
346          n += 1;
347        }
348      }
349      const to = (y * cols + x) * 3;
350      const k = Math.max(1, n);
351      out[to] = r / k;
352      out[to + 1] = g / k;
353      out[to + 2] = b / k;
354    }
355  }
356  return out;
357}
358
359// A picture as half blocks: each cell is ▀ with the upper pixel as its foreground and the
360// lower as its background, so cols x rows cells carry cols x 2*rows pixels.
361export function halfBlockCells(rgba, width, height, cols, rows) {
362  const px = resample(rgba, width, height, cols, rows * 2);
363  const words = new Uint32Array(cols * rows * 3);
364  for (let y = 0; y < rows; y += 1) {
365    for (let x = 0; x < cols; x += 1) {
366      const top = (y * 2 * cols + x) * 3;
367      const bottom = ((y * 2 + 1) * cols + x) * 3;
368      const at = (y * cols + x) * 3;
369      words[at] = UPPER_HALF;
370      words[at + 1] = pack(px[top], px[top + 1], px[top + 2]);
371      words[at + 2] = pack(px[bottom], px[bottom + 1], px[bottom + 2]);
372    }
373  }
374  return words;
375}
376
377// A gentle lift before the picture is cut down to a few pixels, which is what makes a cover
378// read crisply at this size: a little more contrast and colour, then an unsharp mask (the
379// picture minus a blur of itself, added back). `px` is w x h pixels of RGB, 0 to 255; the
380// pixels are twice as tall as they are wide on screen, so the blur is narrower downwards.
381export function enhance(px, w, h, { contrast = 1.1, saturation = 1.2, sharpen = 0.75 } = {}) {
382  const out = new Float64Array(px.length);
383  for (let i = 0; i < px.length; i += 3) {
384    const l = luma([px[i], px[i + 1], px[i + 2]]);
385    for (let k = 0; k < 3; k += 1) {
386      let v = l + (px[i + k] - l) * saturation;
387      v = 127.5 + (v - 127.5) * contrast;
388      out[i + k] = Math.max(0, Math.min(255, v));
389    }
390  }
391  if (!(sharpen > 0) || w < 3 || h < 3) {
392    return out;
393  }
394  const across = new Float64Array(px.length);
395  for (let y = 0; y < h; y += 1) {
396    for (let x = 0; x < w; x += 1) {
397      const a = (y * w + Math.max(0, x - 1)) * 3;
398      const b = (y * w + x) * 3;
399      const c = (y * w + Math.min(w - 1, x + 1)) * 3;
400      for (let k = 0; k < 3; k += 1) {
401        across[b + k] = (out[a + k] + 2 * out[b + k] + out[c + k]) / 4;
402      }
403    }
404  }
405  const sharp = new Float64Array(px.length);
406  for (let y = 0; y < h; y += 1) {
407    for (let x = 0; x < w; x += 1) {
408      const a = (Math.max(0, y - 1) * w + x) * 3;
409      const b = (y * w + x) * 3;
410      const c = (Math.min(h - 1, y + 1) * w + x) * 3;
411      for (let k = 0; k < 3; k += 1) {
412        const blur = (across[a + k] + 6 * across[b + k] + across[c + k]) / 8;
413        sharp[b + k] = Math.max(0, Math.min(255, out[b + k] + sharpen * (out[b + k] - blur)));
414      }
415    }
416  }
417  return sharp;
418}
419
420// The best way to show four pixels (upper left, upper right, lower left, lower right; each
421// [r, g, b]) in one cell: a glyph of the sixteen quadrant blocks and a colour for each side,
422// whichever leaves the least squared error. The lighter side is the foreground. When
423// nothing beats one flat colour the cell is a space of that colour. Returns { glyph, fg, bg }.
424export function quadrantFit(p) {
425  const mean = (mask) => {
426    let n = 0;
427    const sum = [0, 0, 0];
428    for (let i = 0; i < 4; i += 1) {
429      if (mask & (1 << i)) {
430        n += 1;
431        sum[0] += p[i][0];
432        sum[1] += p[i][1];
433        sum[2] += p[i][2];
434      }
435    }
436    return [sum[0] / n, sum[1] / n, sum[2] / n];
437  };
438  const error = (mask, c) => {
439    let e = 0;
440    for (let i = 0; i < 4; i += 1) {
441      if (mask & (1 << i)) {
442        e += (p[i][0] - c[0]) ** 2 + (p[i][1] - c[1]) ** 2 + (p[i][2] - c[2]) ** 2;
443      }
444    }
445    return e;
446  };
447  const flat = mean(15);
448  const flatError = error(15, flat);
449  let best = null;
450  for (let m = 1; m <= 7; m += 1) {
451    const a = mean(m);
452    const b = mean(15 - m);
453    const e = error(m, a) + error(15 - m, b);
454    if (best === null || e < best.e) {
455      best = { m, a, b, e };
456    }
457  }
458  if (best === null || best.e + 1 >= flatError) {
459    return { glyph: 0x20, fg: flat, bg: flat };
460  }
461  return luma(best.a) >= luma(best.b)
462    ? { glyph: QUADRANTS[best.m].codePointAt(0), fg: best.a, bg: best.b }
463    : { glyph: QUADRANTS[15 - best.m].codePointAt(0), fg: best.b, bg: best.a };
464}
465
466// The nearest colour on the 16-level grid Claude Code paints a Raster in.
467export function snapColor(c) {
468  return [0, 1, 2].map((k) => Math.max(0, Math.min(255, Math.round(c[k] / GRID) * GRID)));
469}
470
471// Like quadrantFit for pixels that already sit on the grid: the two colours are chosen from the
472// pixels themselves, so nothing has to be averaged off the grid, whichever pair leaves
473// the least squared error. The lighter is the foreground.
474export function quadrantSnap(p) {
475  const uniq = [];
476  for (const c of p) {
477    if (!uniq.some((u) => u[0] === c[0] && u[1] === c[1] && u[2] === c[2])) {
478      uniq.push(c);
479    }
480  }
481  if (uniq.length === 1) {
482    return { glyph: 0x20, fg: uniq[0], bg: uniq[0] };
483  }
484  const dist = (a, b) => (a[0] - b[0]) ** 2 + (a[1] - b[1]) ** 2 + (a[2] - b[2]) ** 2;
485  let best = null;
486  for (let i = 0; i < uniq.length; i += 1) {
487    for (let j = i + 1; j < uniq.length; j += 1) {
488      const light = luma(uniq[i]) >= luma(uniq[j]) ? uniq[i] : uniq[j];
489      const dark = light === uniq[i] ? uniq[j] : uniq[i];
490      let mask = 0;
491      let e = 0;
492      for (let k = 0; k < 4; k += 1) {
493        const dl = dist(p[k], light);
494        const dd = dist(p[k], dark);
495        if (dl <= dd) {
496          mask |= 1 << k;
497          e += dl;
498        } else {
499          e += dd;
500        }
501      }
502      if (best === null || e < best.e) {
503        best = { e, mask, light, dark };
504      }
505    }
506  }
507  if (best.mask === 0 || best.mask === 15) {
508    return { glyph: 0x20, fg: best.light, bg: best.light };
509  }
510  return { glyph: QUADRANTS[best.mask].codePointAt(0), fg: best.light, bg: best.dark };
511}
512
513// Cells from a grid of sub-pixels (rgb, 2 * cols wide and 2 * rows tall). With `onGrid` the
514// pixels are on the colour grid already and the cell's colours are picked from them; without, they
515// are averaged and then snapped to the grid.
516function quadrantWords(sub, cols, rows, onGrid = false) {
517  const words = new Uint32Array(cols * rows * 3);
518  const sw = cols * 2;
519  const at = (x, y) => {
520    const i = (y * sw + x) * 3;
521    return [sub[i], sub[i + 1], sub[i + 2]];
522  };
523  for (let row = 0; row < rows; row += 1) {
524    for (let col = 0; col < cols; col += 1) {
525      const four = [at(col * 2, row * 2), at(col * 2 + 1, row * 2), at(col * 2, row * 2 + 1), at(col * 2 + 1, row * 2 + 1)];
526      const cell = onGrid ? quadrantSnap(four) : quadrantFit(four);
527      const fg = onGrid ? cell.fg : snapColor(cell.fg);
528      const bg = onGrid ? cell.bg : snapColor(cell.bg);
529      const to = (row * cols + col) * 3;
530      words[to] = cell.glyph;
531      words[to + 1] = pack(fg[0], fg[1], fg[2]);
532      words[to + 2] = pack(bg[0], bg[1], bg[2]);
533    }
534  }
535  return words;
536}
537
538// A picture as quadrant blocks: cols x rows cells carrying 2 * cols x 2 * rows pixels, each cell
539// two colours and a glyph. The picture is cropped to the block's shape, cut down, given the
540// lift of `enhance`, then every cell is fitted (see quadrantFit). Pass `{ sharpen: 0 }` and the
541// like to change the lift.
542export function quadrantCells(rgba, width, height, cols, rows, lift) {
543  const sw = cols * 2;
544  const sh = rows * 2;
545  const px = resample(rgba, width, height, sw, sh, cropRect(width, height, cols, rows));
546  return quadrantWords(enhance(px, sw, sh, lift), cols, rows);
547}
548
549// Stand-in cover when there is no picture: a soft diagonal wash of the palette.
550export function placeholderCells(cols, rows, colors) {
551  const w = cols * 2;
552  const h = rows * 2;
553  const rgba = new Uint8Array(w * h * 4);
554  for (let y = 0; y < h; y += 1) {
555    for (let x = 0; x < w; x += 1) {
556      const k = (x / Math.max(1, w - 1) + y / Math.max(1, h - 1)) / 2;
557      const from = k < 0.5 ? colors[0] : colors[1];
558      const to = k < 0.5 ? colors[1] : colors[2];
559      const f = k < 0.5 ? k * 2 : (k - 0.5) * 2;
560      const at = (y * w + x) * 4;
561      rgba[at] = from[0] + (to[0] - from[0]) * f;
562      rgba[at + 1] = from[1] + (to[1] - from[1]) * f;
563      rgba[at + 2] = from[2] + (to[2] - from[2]) * f;
564      rgba[at + 3] = 255;
565    }
566  }
567  return quadrantCells(rgba, w, h, cols, rows, { contrast: 1, saturation: 1, sharpen: 0 });
568}
569
570// ---------- aurora ----------
571
572// An ordered dither threshold in (0, 1) for a sub-pixel, from the 4x4 Bayer matrix.
573const BAYER4 = [0, 8, 2, 10, 12, 4, 14, 6, 3, 11, 1, 9, 15, 7, 13, 5];
574export function bayer(x, y) {
575  return (BAYER4[(y & 3) * 4 + (x & 3)] + 0.5) / 16;
576}
577
578function lattice(ix, iy, seed) {
579  let h = (Math.imul(ix, 0x27d4eb2d) ^ Math.imul(iy, 0x165667b1) ^ Math.imul(seed, 0x9e3779b1)) | 0;
580  h = Math.imul(h ^ (h >>> 15), 0x85ebca6b);
581  h = Math.imul(h ^ (h >>> 13), 0xc2b2ae35);
582  h ^= h >>> 16;
583  return (h >>> 0) / 4294967296;
584}
585
586// Smooth value noise, 0 to 1.
587function noise(x, y, seed) {
588  const ix = Math.floor(x);
589  const iy = Math.floor(y);
590  const fx = x - ix;
591  const fy = y - iy;
592  const u = fx * fx * (3 - 2 * fx);
593  const v = fy * fy * (3 - 2 * fy);
594  const a = lattice(ix, iy, seed);
595  const b = lattice(ix + 1, iy, seed);
596  const c = lattice(ix, iy + 1, seed);
597  const d = lattice(ix + 1, iy + 1, seed);
598  return a + (b - a) * u + (c - a) * v + (a - b - c + d) * u * v;
599}
600
601// Three octaves of it, 0 to 1 and mostly near the middle.
602export function fbm(x, y, seed) {
603  return noise(x, y, seed) * 0.57 + noise(x * 2.03 + 17.1, y * 2.03 + 3.7, seed + 1) * 0.29 + noise(x * 4.1 + 5.3, y * 4.1 + 9.2, seed + 2) * 0.14;
604}
605
606const AURORA_HUES = 20;
607const AURORA_PEAK = 135;
608
609// The aurora: a slow ribbon of the cover's colours, brightest where its lobes gather and gone
610// to nothing at its ends and edges, so it glows out of the dark. `t` is seconds and `level`
611// (0 to 1) dims it. It is worked out on a grid of quadrant sub-pixels (twice as many across
612// and down as there are cells) in smooth noise. Claude Code paints a Raster in 16 levels a
613// channel, which on a dark glow is a few steps and shows as bands, so each sub-pixel is
614// rounded to the grid with an ordered (Bayer) dither: the two nearest colours are woven into
615// each other and the eye reads the level between. Each cell then takes the quadrant block that
616// fits its four sub-pixels.
617export function auroraCells(columns, rows, t, colors, level = 1) {
618  const words = new Uint32Array(columns * rows * 3);
619  if (columns < 1 || rows < 1) {
620    return words;
621  }
622  const sw = columns * 2;
623  const sh = rows * 2;
624  const drift = t * 0.045;
625  const edge = Math.min(18, Math.max(3, columns * 0.22));
626  const lobe = new Float64Array(sw);
627  const centre = new Float64Array(sw);
628  const spread = new Float64Array(sw);
629  const hue = [];
630  const glow = [];
631  // Light of the cover's colours, kept lively: a dull cover still gives a glow with some colour in it.
632  const ramp = [colors[0], colors[1], colors[2]].map((c) => {
633    const [h, s, l] = rgbToHsl(c);
634    return hslToRgb([h, Math.max(s, 0.5), Math.min(0.62, Math.max(l, 0.46))]);
635  });
636  for (let sx = 0; sx < sw; sx += 1) {
637    const x = (sx + 0.5) / 2;
638    const gather = smooth(0.26, 0.8, fbm(x * 0.06 + drift * 2.2, 1.7, 11));
639    const ray = 0.8 + 0.2 * noise(x * 0.8 - drift * 5, 4.2, 23);
640    const ends = smooth(0, edge, x) * smooth(0, edge, columns - x);
641    lobe[sx] = (0.1 + 0.9 * gather) * ray * ends * ends;
642    centre[sx] = sh * (0.5 + 0.2 * (fbm(x * 0.04 - drift * 2.4, 8.3, 31) - 0.5) * 2);
643    spread[sx] = Math.max(1.1, sh * (0.22 + 0.08 * fbm(x * 0.07 + drift * 2, 2.2, 41)));
644    const g = 0.1 + (x / columns) * 0.6 + 0.32 * fbm(x * 0.03 - drift * 1.4, 5.9, 53) + drift * 0.5;
645    const step = Math.round((((g % 1) + 1) % 1) * AURORA_HUES) / AURORA_HUES;
646    const k = step * 3;
647    const i = Math.floor(k) % 3;
648    const f = smooth(0, 1, k - Math.floor(k));
649    const c = mix(ramp[i], ramp[(i + 1) % 3], f);
650    hue.push(c);
651    // the same peak brightness for any colour: a pale yellow is held back, a deep purple pushed
652    glow.push(Math.max(0.9, Math.min(1.7, AURORA_PEAK / Math.max(40, luma(c)))));
653  }
654  const sub = new Float64Array(sw * sh * 3);
655  for (let sy = 0; sy < sh; sy += 1) {
656    const y = sy + 0.5;
657    const fadeIn = Math.min(2.4, sh * 0.36);
658    const window = smooth(0, fadeIn, y) * smooth(0, fadeIn * 1.15, sh - y);
659    for (let sx = 0; sx < sw; sx += 1) {
660      const d = (y - centre[sx]) / spread[sx];
661      // a bright core in a wide, faint haze, so it reads as light spilling and not as a bar
662      const light = Math.max(0, (Math.exp(-0.5 * d * d) * 0.82 + Math.exp(-0.5 * (d / 3) * (d / 3)) * 0.45) * lobe[sx] * window * level);
663      const threshold = bayer(sx, sy);
664      const at = (sy * sw + sx) * 3;
665      const c = hue[sx];
666      for (let k = 0; k < 3; k += 1) {
667        const value = PANEL_BG[k] + c[k] * glow[sx] * light;
668        sub[at + k] = Math.max(0, Math.min(15, Math.floor(value / GRID + threshold))) * GRID;
669      }
670    }
671  }
672  return quadrantWords(sub, columns, rows, true);
673}
674
675// ---------- layout ----------
676
677// Which view to draw. `big` is the person's choice, `isSong` is true while hum has a track
678// (the radio always keeps its band). `rows` is the room the band may take.
679// Returns { mode: "band" } or { mode: "panel", cover: "image" | "cells" | "svg" }.
680export function chooseLayout({ big, isSong, surface, columns, rows, canImages }) {
681  const band = { mode: "band" };
682  if (!big || !isSong) {
683    return band;
684  }
685  if (surface === "terminal") {
686    if (!(columns >= PANEL_MIN_COLUMNS) || !(rows >= PANEL_ROWS + PANEL_ROOM)) {
687      return band;
688    }
689    return { mode: "panel", cover: canImages ? "image" : "cells" };
690  }
691  if (surface === "desktop") {
692    return { mode: "panel", cover: "svg" };
693  }
694  return band;
695}
696
697// Whether this terminal draws pictures: kitty and Ghostty do, and tmux passes none through.
698// `env` holds the values of TERM_PROGRAM, TERM, KITTY_WINDOW_ID, GHOSTTY_RESOURCES_DIR and TMUX,
699// and HUSH_COVER ("cells" or "image") forces the answer.
700export function canShowImages(env) {
701  const forced = String(env.HUSH_COVER || "").toLowerCase();
702  if (forced === "cells") {
703    return false;
704  }
705  if (forced === "image") {
706    return true;
707  }
708  if (env.TMUX) {
709    return false;
710  }
711  const program = String(env.TERM_PROGRAM || "").toLowerCase();
712  const term = String(env.TERM || "").toLowerCase();
713  return Boolean(env.KITTY_WINDOW_ID || env.GHOSTTY_RESOURCES_DIR) || program === "ghostty" || term.includes("kitty") || term.includes("ghostty");
714}
715
716// Cells across the panel's right-hand column: what is left after padding, the cover and the gap.
717export function panelWidths(columns, cover = COVER_COLUMNS, gap = PANEL_GAP) {
718  const text = Math.max(10, columns - PANEL_PAD * 2 - cover - gap);
719  return { cover, gap, text, bar: Math.max(6, text - 15) };
720}
721
722// How big the terminal panel is, measured from the room the engine gives (`maxRows`, what the
723// band may take) and the cells across. The cover is square (twice as many columns as rows, a
724// cell being about twice as tall as wide) and as tall as the room allows, 8 to 10 rows, leaving
725// one row of slack for the focus hint. The words beside it are a two row ribbon of aurora and six
726// lines (title, artist, two caption lines, progress, buttons); a ninth row adds a gap under the
727// artist and a tenth another above the progress. Narrow terminals keep the smaller cover. A row
728// of padding above and below is added when there is plenty of room.
729// Returns { rows, cover, gap, text, bar, ribbon, gapA, gapB, pad }.
730export function panelGeometry(columns, maxRows) {
731  let rows = Math.max(PANEL_ROWS, Math.min(PANEL_ROWS_MAX, Math.floor(maxRows) - PANEL_ROOM));
732  if (columns < 76) {
733    rows = Math.min(rows, PANEL_ROWS);
734  }
735  const cover = rows * 2;
736  const gap = rows >= 9 ? 3 : PANEL_GAP;
737  const w = panelWidths(columns, cover, gap);
738  return {
739    rows,
740    cover,
741    gap,
742    text: w.text,
743    bar: Math.max(6, w.text - 12),
744    ribbon: RIBBON_ROWS,
745    gapA: rows >= 9 ? 1 : 0,
746    gapB: rows >= 10 ? 1 : 0,
747    pad: maxRows >= rows + 4 ? 1 : 0,
748  };
749}
750
751// ---------- progress ----------
752
753// The progress bar as filled and empty cell counts.
754export function progressBar(pos, dur, cells) {
755  const share = dur > 0 ? Math.max(0, Math.min(1, pos / dur)) : 0;
756  const filled = Math.round(share * cells);
757  return { filled, empty: cells - filled };
758}
759
760// The bar to eighths of a cell: whole cells, then one of ▏▎▍▌▋▊▉ for the part, then the rest.
761export function progressEighths(pos, dur, cells) {
762  const share = dur > 0 ? Math.max(0, Math.min(1, pos / dur)) : 0;
763  const eighths = Math.round(share * cells * 8);
764  return { full: Math.floor(eighths / 8), part: eighths % 8, cells, eighths };
765}
766
767// The bar as runs of text to draw: { text, color: [r, g, b], track }. The filled part is
768// a gradient from `from` to `to` across the filled cells (so both colours show from the start),
769// cut into a few steps so neighbouring cells share a run; the part cell is an eighth block over the
770// track; the rest is track (a run of spaces on a dim background).
771export function progressRuns(pos, dur, cells, from, to) {
772  const { full, part } = progressEighths(pos, dur, cells);
773  const filled = full + (part > 0 ? 1 : 0);
774  const runs = [];
775  const push = (text, color, track) => {
776    const last = runs[runs.length - 1];
777    if (last && last.track === track && last.color[0] === color[0] && last.color[1] === color[1] && last.color[2] === color[2] && !last.single) {
778      last.text += text;
779    } else {
780      runs.push({ text, color, track });
781    }
782  };
783  for (let i = 0; i < full; i += 1) {
784    const k = filled > 1 ? Math.round((i / (filled - 1)) * 8) / 8 : 0;
785    push(EIGHTHS[8], mix(from, to, k).map(Math.round), false);
786  }
787  if (part > 0) {
788    const k = filled > 1 ? 1 : 0;
789    runs.push({ text: EIGHTHS[part], color: mix(from, to, k).map(Math.round), track: true, single: true });
790  }
791  if (cells - filled > 0) {
792    push(" ".repeat(cells - filled), TRACK, true);
793  }
794  return runs;
795}
796
797// Times that keep their width, so the bar does not shift as the minutes roll over: both are
798// as wide as the song's length.
799export function timeLabels(pos, dur) {
800  const total = dur > 0 ? clock(dur) : "";
801  const width = Math.max(total.length, 4);
802  return { elapsed: clock(pos).padStart(width, " "), total: total === "" ? "" : total.padStart(width, " ") };
803}
804
805// ---------- caption ----------
806
807// The two lines under the artist. With synced lyrics: the line being sung (an interlude is
808// three dots) and the next one. Without: the album, and what is up next, so there is never a
809// gap. Each is { role, label, text }; role is "now", "next", "album", "queue" or "quiet".
810export function captionLines(song) {
811  const queue = song.upNext ? { role: "queue", label: "up next", text: song.upNext } : null;
812  if (song.hasLyrics) {
813    return {
814      kind: "lyrics",
815      first: { role: "now", label: "", text: song.line || "· · ·" },
816      second: song.next ? { role: "next", label: "", text: song.next } : queue || { role: "quiet", label: "", text: "· · ·" },
817    };
818  }
819  return {
820    kind: "about",
821    first: { role: "album", label: "", text: song.album || "no synced lyrics for this one" },
822    second: queue || { role: "quiet", label: "", text: song.album ? "no synced lyrics for this one" : "end of the queue" },
823  };
824}
825
826// ---------- cover files ----------
827
828// A folder name for a track: its id when it is a plain one, else a hash of title and artist.
829export function coverKey(track) {
830  const id = track && typeof track.id === "string" ? track.id : "";
831  if (/^[A-Za-z0-9_-]{4,40}$/.test(id)) {
832    return id;
833  }
834  const text = `${track?.title || ""}|${track?.artist || ""}`;
835  let hash = 5381;
836  for (let i = 0; i < text.length; i += 1) {
837    hash = (Math.imul(hash, 33) + text.charCodeAt(i)) >>> 0;
838  }
839  return `t${hash.toString(16)}`;
840}
841
842// Where to fetch a cover from: hum's art, then YouTube's thumbnail. http and https only.
843export function coverUrls(track) {
844  const urls = [];
845  if (track && typeof track.art === "string" && /^https?:\/\//.test(track.art)) {
846    urls.push(track.art);
847  }
848  if (track && typeof track.id === "string" && /^[A-Za-z0-9_-]{6,20}$/.test(track.id)) {
849    urls.push(`https://i.ytimg.com/vi/${track.id}/mqdefault.jpg`);
850  }
851  return urls;
852}
853
854export const COVER_KEEP = 40;
855
856// A shell script for one cover, run by /bin/sh with: folder, art folder, how many to keep, then
857// the urls. It downloads with curl and makes cover.png (the terminal's Image), cover.jpg (the
858// desktop's Svg) and cells.bmp (read in JS for the cell art and the colours), all with sips.
859// cells.bmp is 64 pixels square, enough for a 20 column cover at two pixels a cell with room to
860// average. A folder that already has the three files is only touched, which keeps the newest ones.
861export const COVER_SCRIPT = `
862set -e
863d="$1"; root="$2"; keep="$3"; shift 3
864if [ -s "$d/cover.png" ] && [ -s "$d/cover.jpg" ] && [ -s "$d/cells.bmp" ]; then /usr/bin/touch "$d"; exit 0; fi
865/bin/mkdir -p "$d"
866trap 'rc=$?; [ "$rc" -ne 0 ] && /bin/rm -rf "$d"; exit "$rc"' EXIT
867cd "$d"
868got=0
869for u in "$@"; do
870  if /usr/bin/curl -fsSL --proto '=http,https' --max-time 10 --max-filesize 8000000 -o raw "$u" 2>/dev/null; then got=1; break; fi
871done
872[ "$got" = 1 ]
873w=$(/usr/bin/sips -g pixelWidth raw | /usr/bin/awk '/pixelWidth/ {print $2}')
874h=$(/usr/bin/sips -g pixelHeight raw | /usr/bin/awk '/pixelHeight/ {print $2}')
875s=$(( w < h ? w : h ))
876/usr/bin/sips -c "$s" "$s" -s format png raw --out sq.png >/dev/null
877/usr/bin/sips -z 192 192 -s format png sq.png --out cover.png >/dev/null
878/usr/bin/sips -z 216 216 -s format jpeg -s formatOptions 68 sq.png --out cover.jpg >/dev/null
879/usr/bin/sips -z 64 64 -s format bmp sq.png --out cells.bmp >/dev/null
880/bin/rm -f raw sq.png
881trap - EXIT
882if [ -n "$root" ] && [ "$keep" -gt 0 ]; then
883  cd "$root"
884  /bin/ls -1t | /usr/bin/tail -n +"$((keep + 1))" | while IFS= read -r old; do /bin/rm -rf "$root/$old"; done
885fi
886`;
887
888// ---------- desktop svg ----------
889
890function esc(text) {
891  return String(text).replace(/&/g, "&amp;").replace(/</g, "&lt;").replace(/>/g, "&gt;").replace(/"/g, "&quot;");
892}
893
894// The desktop's picture: the cover with rounded corners on a haze of itself (the cover blown
895// up and blurred, so the card takes its colours), a soft shadow of its first colour, a drifting
896// glow, then the title, artist and album and three bars that dance while it plays. The glow and
897// bars move by SMIL when `animated`. It holds nothing that changes while a song plays (no
898// lyric, no clock), so the same source is drawn every second and the animation keeps going.
899export function panelSvg({ title, artist, album = "", colors, accent, jpeg, animated, dim }) {
900  const [c0, c1, c2, c3] = colors.map(hex);
901  const ac = hex(accent);
902  const move = (attr, values, dur) =>
903    animated ? `<animate attributeName="${attr}" values="${values}" dur="${dur}s" repeatCount="indefinite" calcMode="spline" keyTimes="0;0.5;1" keySplines="0.45 0 0.55 1;0.45 0 0.55 1"/>` : "";
904  const blob = (cx, cy, r, color, opacity, moves) =>
905    `<ellipse cx="${cx}" cy="${cy}" rx="${r}" ry="${Math.round(r * 0.7)}" fill="${color}" fill-opacity="${opacity}">${moves}</ellipse>`;
906  const bar = (x, low, high, dur) => {
907    const h = animated ? low : Math.round((low + high) / 2);
908    const motion = animated
909      ? `<animate attributeName="height" values="${low};${high};${low}" dur="${dur}s" repeatCount="indefinite" calcMode="spline" keyTimes="0;0.5;1" keySplines="0.45 0 0.55 1;0.45 0 0.55 1"/>` +
910        `<animate attributeName="y" values="${46 - low};${46 - high};${46 - low}" dur="${dur}s" repeatCount="indefinite" calcMode="spline" keyTimes="0;0.5;1" keySplines="0.45 0 0.55 1;0.45 0 0.55 1"/>`
911      : "";
912    return `<rect x="${x}" y="${46 - h}" width="3" height="${h}" rx="1.5" fill="${ac}" fill-opacity="${dim ? 0.45 : 0.95}">${motion}</rect>`;
913  };
914  const glowOpacity = dim ? 0.18 : 0.42;
915  const hazeOpacity = dim ? 0.3 : 0.62;
916  const art = jpeg
918    : `<rect id="art" width="108" height="108" fill="url(#wash)"/>`;
919  const sub = album && album !== title ? `<text x="152" y="130" font-size="12" fill="${BONE}" fill-opacity="0.42">${esc(fit(album, 52))}</text>` : "";
920  const svg = [
921    `<svg xmlns="http://www.w3.org/2000/svg" width="${SVG_WIDTH}" height="${SVG_HEIGHT}" viewBox="0 0 ${SVG_WIDTH} ${SVG_HEIGHT}" font-family="-apple-system, 'Helvetica Neue', Arial, sans-serif">`,
922    `<defs>`,
923    art,
924    `<clipPath id="frame"><rect width="${SVG_WIDTH}" height="${SVG_HEIGHT}" rx="16"/></clipPath>`,
925    `<clipPath id="cover"><rect x="20" y="20" width="108" height="108" rx="14"/></clipPath>`,
926    `<clipPath id="words"><rect x="152" y="0" width="${SVG_WIDTH - 152 - 20}" height="${SVG_HEIGHT}"/></clipPath>`,
927    `<filter id="soft" x="-60%" y="-60%" width="220%" height="220%"><feGaussianBlur stdDeviation="30"/></filter>`,
928    `<filter id="haze" x="-20%" y="-20%" width="140%" height="140%"><feGaussianBlur stdDeviation="38"/></filter>`,
929    `<filter id="lift" x="-40%" y="-40%" width="180%" height="180%"><feGaussianBlur stdDeviation="13"/></filter>`,
930    `<linearGradient id="wash" x1="0" y1="0" x2="1" y2="1"><stop offset="0" stop-color="${c0}"/><stop offset="0.6" stop-color="${c1}"/><stop offset="1" stop-color="${c2}"/></linearGradient>`,
931    `<linearGradient id="shade" x1="0" y1="0" x2="1" y2="0"><stop offset="0" stop-color="${BACKGROUND_HEX}" stop-opacity="0.12"/><stop offset="0.32" stop-color="${BACKGROUND_HEX}" stop-opacity="0.55"/><stop offset="1" stop-color="${BACKGROUND_HEX}" stop-opacity="0.72"/></linearGradient>`,
932    `<linearGradient id="sheen" x1="0" y1="0" x2="0" y2="1"><stop offset="0" stop-color="#ffffff" stop-opacity="0.16"/><stop offset="0.45" stop-color="#ffffff" stop-opacity="0"/></linearGradient>`,
933    `</defs>`,
934    `<g clip-path="url(#frame)">`,
935    `<rect width="${SVG_WIDTH}" height="${SVG_HEIGHT}" fill="${BACKGROUND_HEX}"/>`,
936    `<g filter="url(#haze)" opacity="${hazeOpacity}"><use href="#art" transform="translate(-110 -170) scale(7.4)"/></g>`,
937    `<g filter="url(#soft)">`,
938    blob(150, 40, 150, c0, glowOpacity, move("cx", "150;270;150", 17) + move("cy", "40;80;40", 23)),
939    blob(360, 120, 170, c1, glowOpacity, move("cx", "360;210;360", 21) + move("cy", "120;60;120", 19)),
940    blob(520, 30, 140, c2, glowOpacity, move("cx", "520;420;520", 25) + move("cy", "30;84;30", 29)),
941    blob(60, 140, 110, c3, glowOpacity + 0.1, move("cx", "60;150;60", 31)),
942    `</g>`,
943    `<rect width="${SVG_WIDTH}" height="${SVG_HEIGHT}" fill="url(#shade)"/>`,
944    `<rect x="26" y="34" width="96" height="104" rx="16" fill="${c0}" filter="url(#lift)" fill-opacity="${dim ? 0.35 : 0.8}"/>`,
945    `<g clip-path="url(#cover)"><use href="#art" x="20" y="20"/><rect x="20" y="20" width="108" height="108" fill="url(#sheen)"/></g>`,
946    `<rect x="20.5" y="20.5" width="107" height="107" rx="13.5" fill="none" stroke="${BONE}" stroke-opacity="0.16"/>`,
947    `<g clip-path="url(#words)">`,
948    `<text x="152" y="44" font-size="10" font-weight="600" letter-spacing="2.6" fill="${ac}" fill-opacity="${dim ? 0.6 : 0.95}">NOW PLAYING</text>`,
949    bar(256, 4, 12, 0.9),
950    bar(262, 10, 4, 1.1),
951    bar(268, 6, 13, 0.8),
952    `<text x="152" y="82" font-size="26" font-weight="700" letter-spacing="-0.3" fill="${BONE}"${dim ? ' fill-opacity="0.78"' : ""}>${esc(fit(title, 28))}</text>`,
953    `<text x="152" y="107" font-size="15" fill="${BONE}" fill-opacity="${dim ? 0.5 : 0.74}">${esc(fit(artist, 46))}</text>`,
954    sub,
955    `</g>`,
956    `</g>`,
957    `</svg>`,
958  ].join("");
959  // Too big only if the picture is: draw it again without.
960  if (svg.length > SVG_LIMIT && jpeg) {
961    return panelSvg({ title, artist, album, colors, accent, jpeg: null, animated, dim });
962  }
963  return svg;
964}
965
